Samsung Gravity T SGH-t669, Gravity Touch User Manual

Download

Page 1

PORTABLE Quad-BAND

MOBILE PHONE

User Manual

Please read this manual before operating your

phone, and keep it for future reference.

Page 2

T669_UVJD8_CH_051210_F6

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

Samsung Telecommunications America (STA), LLC

Headquarters: Customer Care Center:

1301 E. Lookout Drive 1000 Klein Rd.

Richardson, TX 75082 Plano, TX 75074

Toll Free Tel: 1.888.987.HELP (4357)

Internet Address:

http://www.samsungusa.com

2010 Samsung Telecommunications America, LLC is a registered trademark of Samsung Electronics America, Inc.

and its related entities.

Do you have questions about your Samsung Mobile Phone? For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:

www.samsungtelecom.com/support

Page 3

T9 Text Input is licensed by Tegic Communications and is covered by U.S. Pat. 5,818,437; U.S. Pat. 5,953,541; U.S. Pat. 6,011,554 and other patents pending.

ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and other countries.

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.

microSD™ and the microSD logo are Trademarks of the SD Card Association.

Openwave® is a registered Trademark of Openwave, Inc.

Open Source Software

Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered under the open source licenses, please visit:

http://www.samsungnetwork.com/Home/opensource

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Page 4

Table of Contents

Section 1: Getting Started ........................................................................... 7

Activating Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Switching the Phone On or Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Setting Up Your Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Visual Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Section 2: Understanding Your Phone ...................................................... 15

Features of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Front View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Side Views of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Camera View of Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Display Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Unlocking the Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Section 3: Displays .................................................................................... 23

Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Widgets and the Widget Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Widget Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Main Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25

Section 4: Navigation ................................................................................ 26

Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Analog Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Birthday Events . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38

Digital Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Dual Clock (World clock) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Email box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Page 5

Games and Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Google Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Imaging Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Instant Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Widget Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Message Inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Message Composer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

My Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Social Buzz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

TeleNav GPS Navigator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Today . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Voice Mail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Voice recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Web Browser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Widget Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Accessing Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Widget Bar Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Widget Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49

Search . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Section 5: Call Functions ...........................................................................51

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Adjusting the Call Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Options During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Accessing the Contacts During a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Call Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Page 6

Section 6: Entering Text ............................................................................ 66

Using the QWERTY Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66

Changing the Text Input Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .67

Using T9 Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69

Using ABC Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Using Numeric . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Using Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70

Section 7: Understanding Your Contacts List ........................................... 72

Using Mobile Address Book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Storing a Number in the Phone’s Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .72

Storing a Number on the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73

Finding a Contact Entry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .74

Adding a New Caller Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

Dialing a Number from the SIM Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Deleting all of the Contacts Entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .76

Speed Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

My Profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .77

Contacts Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .78

Section 8: Messaging Applications ..........................................................84

Types of Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84

Creating an Audio Postcard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85

Text Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87

Picture Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89

Message inbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91

Social Buzz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .94

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .95

Email Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .97

Exchange Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .98

IM (Instant Messaging) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .99

Sentbox . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .100

Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Templates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103

Messaging settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .106

Delete by folder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109

Page 7

Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110

Section 9: Music ......................................................................................111

Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Playing Music Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Deleting Music Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Transferring Music Files to your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Managing your Music Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Section 10: Applications ..........................................................................119

Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Games and Apps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

Alarm Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Tasks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 129

Using the Voice Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

World Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Stopwatch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Birthday Widget . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Analog Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Digital Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Downloads . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Google Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

My Account . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

My Album Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136

Searching for Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138

Section 11: Camera ..................................................................................139

Using the Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Take and Send Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Page 8

Photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .142

Using the Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147

Recording and Sending a Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .147

Videos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .150

My Album Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .151

Section 12: Web Applications and Social Buzz ...................................... 152

Accessing the Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .152

RSS Feeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155

Browser Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .155

Social Buzz . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .156

YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .157

Section 13: Bluetooth and Services ........................................................ 158

Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158

Bluetooth Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .158

Section 14: Changing Your Settings ....................................................... 161

Widget Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .161

Sound Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .162

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .171

Command Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .172

Time & Date . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .173

Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .174

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .175

Airplane mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

PC connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .177

Smart Unlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178

Motion Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178

Call Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .178

Application Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .179

Enabling Data Roaming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .179

Network selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180

Memory Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .180

Reset Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .182

Page 9

Section 15: Health and Safety Information .............................................183

Health and Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 183

Please Note the Following Information When Using Your Handset . . . . . . . . . . . . . . . . . . . . . . 184

Samsung Mobile Products and Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

UL Certified Travel Adapter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Consumer Information on Wireless Phones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185

Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 191

Responsible Listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 192

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 194

Using Your Phone Near Other Electronic Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 195

FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices . . . . . . . . . . . . . . . . . . 195

Potentially Explosive Environments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197

FCC Notice and Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 198

Other Important Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 199

Product Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200

Availability of Various Features/Ring Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Battery Standby and Talk Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Battery Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 202

Section 16: Warranty Information ...........................................................204

Standard Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204

End User License Agreement for Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207

Index ........................................................................................................................ 212

Page 10

Section 1: Getting Started

This section explains how to start using your phone by first configuring your hardware, activating your service, and then setting up your Voicemail.

Activating Your Phone

When you subscribe to a cellular network, you are provided with a plug-in SIM card loaded with your subscription details, such as your PIN, available optional services, and many others features.

Removing the Cover

1. If necessary, switch off the phone by holding down until the power-off image displays.

2. Remove the cover by pulling up on the slot (see diagram), then lift the cover up and off the phone.

3. Place your thumbnail in the notch at the top (1) and lift it up and out (2) (as shown).

Pull up on the slot (1) Lift the cover up (2) and off the phone (3)

Page 11

Getting Started 8

Removing the Battery

䊳

Lift up (1) and remove (2) the battery.

Installing the SIM Card

Important!:

The plug-in SIM card and its contacts information can be easily damaged by scratching or bending, so be careful when handling, inserting, or removing the card. Keep all SIM cards out of reach of small children.

䊳

Carefully slide the SIM card into the SIM card socket until the card locks into place. Make sure that the card’s gold contacts face into the phone and that the upper-left angled corner of the card is positioned as shown.

Page 12

Note:

If the card is not inserted correctly, the phone does not detect the SIM card. Re-orient the card back into the slot.

Replacing the Battery

1. Slide the battery into the compartment so that the tabs on the end align with the slots at the bottom of the

phone. Be sure to line up the gold contacts.

2. Lightly press down on the battery until it snaps into place.

3. Check that the battery is properly installed before turning on the phone.

Page 13

Getting Started 10

Installing or Removing the Memory Card

Your phone supports an optional memory card (microSD™) for data storage of such things as music, pictures, video or other files. This type of memory card is designed for use with this mobile phone and other devices.

Note:

The Samsung device supports up to a 32 Gigabyte memory card.

1. Place the microSD card into the slot (as shown) and push lightly with your thumb or finger until you hear a

light click sound. Ensure the microSD’s gold contact pins face downward and the card is placed so that the

indentations on the card face the same direction as those illustrated.

2. Push the microSD card with your thumb a second time to eject it from the slot.

Page 14

Replacing the Cover

䊳

Press down on the corners of the battery cover until you hear a click. Verify that the battery cover is secured.

Correct

Incorrect

Page 15

Getting Started 12

Charging a Battery

Your phone is powered by a rechargeable Lithium ion battery. A wall charger, which is used for charging the battery, is included with your phone. Use only approved batteries and chargers. Ask your local Samsung dealer for further details.

You can use the phone while the battery is charging, but doing so requires additional charging time.

Note:

You must fully charge the battery before using your phone for the first time. A discharged battery recharges fully in approximately 4 hours.

1. With the battery installed, temporarily remove the plastic cover on the left side of the phone (as indicated)

and plug in the wall charger’s connector into the jack.

Important!:

Verify that the handset battery is installed prior to connecting the wall charger. If the battery is not installed and the wall charger is connected, the handset power cycles continuously, preventing proper operation.

Note:

The previous illustration displays the incorrect method for connecting the charger. If attempted, damage to the accessory port will occur therefore voiding the phone’s warranty.

Incorrect

Correct

Page 16

Plug the adapter’s power plug into a standard AC wall outlet.

3. When charging is finished, first unplug the adapter’s power plug from the AC wall outlet and then disconnect

the wall charger’s connector from the phone.

Warning!:

Failure to unplug the wall charger before you remove the battery can cause the phone to become damaged.

Low Battery Indicator

When the battery is weak and only a few minutes of talk time remain; a warning tone sounds and the “Low battery” message repeats at regular intervals on the display. In this condition, your phone conserves its remaining battery power, not by turning off the backlight, but by entering the dimming mode.

When the battery level becomes too low, the phone automatically turns off.

Switching the Phone On or Off

1. Press and hold until the phone switches on.

2. If the phone asks you to enter the phone password, use the keypad to enter this password and touch

Confirm

3. If the phone asks for a PIN, use the keypad to enter the PIN and touch

Confirm

. For more information, refer to

“Check PIN code” on page 175.

The phone searches for your network and after finding it, the term “

T-Mobile

” displays on the upper center of

your display. Now you can make or receive calls.

4. When you want to switch off the phone, press and hold until the power-off image displays.

Setting Up Your Voice Mail

For new users, follow the instructions below to set up voice mail:

1. From the Home screen, touch

Dialer

then press and hold until the phone dials voicemail.

You may be prompted to enter a password.

2. Follow the tutorial to create a password, a greeting, and your name.

Note:

These steps may be different depending on your network.

Page 17

Getting Started 14

Accessing Your Voice Mail

You can access your Voice Mail by either pressing and holding on the keypad, by using the phone’s menu, or by pressing the Voice Mail icon in the Widget bar. To access Voice Mail using the menu:

1. From the Home screen, touch

Dialer

then press and hold until the phone dials voice mail.

2. When connected, follow the voice prompts from the voice mail center.

Visual Voicemail

Visual Voicemail enables users to view a list of people who left a Voicemail message, and listen to the any message they want without being limited to chronological order.

Important!:

You must set up your Voice Mail before using this feature. Visual Voice Mail as well as download and install Visual Voicemail in order to activate the Voice Mail application.

1. From the Home screen, press then touch

Messaging

➔

Voicemail

2. When you select

Yes

to activate Visual Voicemail, the Visual Voicemail web page launches.

3. Follow the screen prompts to setup your account.

Page 18

Section 2: Understanding Your Phone

This section outlines some key features of your phone. It also displays the screen and the icons that display when the

phone is in use.

Features of Your Phone

Your phone is lightweight, easy-to-use and offers many significant features. The following list outlines a few of the features included in your phone.

•

Full touch screen phone with full QWERTY keyboard slide-out

•

Multiple messaging options (Exchange Email, Audio PostcardSM, Text, Picture, Video and Instant Messaging)

•

2MP Camera/Camcorder multi shot and 3x zoom

•

Full HTML browser

•

MP3 Music Player

•

Pre-loaded online widgets

•

Social Buzz application (MySpace, Facebook, Twitter)

•

Bluetooth Wireless Technology

•

Expandable Memory Slot, up to 32GB

•

Assisted GPS

•

Smart unlock screen

•

Etiquette mode feature

•

Command Bar shortcuts feature

Page 19

Understanding Your Phone 16

Front View of Your Phone

The following illustrations show the main elements of your phone:

Keys

The following list correlates to the illustrations.

1. Receiver allows you to hear the other caller and the different ring tones or sounds offered by

your phone.

2. Send key allows you to make or answer a call. Press and hold to dial the last contact entered.

Microphone is used

during phone calls and allows other callers to hear you clearly when you are speaking

to them. It is also used to make voice note recordings.

Page 20

Power-on/Off (Exit) key ends a call. Press and hold for two seconds to turn the phone on or off. While in the

Menu mode, it returns the phone to the Home screen and cancels your input.

Menu key

when pressed, displays the Main menu screen.

6. Display shows all the information needed to operate your phone, such as the received signal strength, phone

battery level, date, and time.

Side Views of Your Phone

The following illustrations show the external elements of your phone.

Volume keys allow you to adjust the ringer volume in standby mode or adjust the voice volume during a call.

When receiving an incoming call, pressing the volume key mutes the ring tone. Press and hold the volume key to reject a call.

Camera button

allows you to take pictures when you are in camera mode. It launches the camera with a press

and hold.

Hold button

locks and unlocks the phone.

Page 21

Understanding Your Phone 18

Power/Accessory Interface connector allows you to connect a power cable or optional accessories such

as a USB/data cable or a hands-free headset for convenient, hands-free conversations.

Camera View of Your Phone

The following illustration shows the external elements of your phone:

Display Layout

Your display screen provides a wealth of information about the phone’s status and options. The display has 3 areas:

Back Speaker

Camera lens

Indicators

Main Display area

Function categories

Widget bar

Page 22

Unlocking the Phone

When you first turn on the device the screen is locked (as shown) and displays the Smart unlock guide (see “Smart Unlock” on page 178.) Press and hold the lock icon on the side of the phone or draw a character to unlock the

phone.

Note:

Smart unlock must be setup before you can draw a character to unlock the phone. For more information, refer to “Smart Unlock” on page 178.

If you want to permanently unlock the phone:

䊳

From the Home screen, press then touch

Settings

➔

Phone settings

➔

Touch panel auto-lock

and

press the

Off

button.

Widget Bar

The Widget bar provides quick access to the items you use most frequently (Web, Photo, Message inbox, IM, Tips, Telenav, Voice recognition, Calendar, Bluetooth, Today, Message composer, Games and apps, Voice mail, Widget memo, Digital clock, Analog clock, Dual clock, Birthday, Voice recorder, Calculator, Weather, Imaging tools, Search, Google Maps, YouTube, Social Buzz, and Email box). For more information about the Widget bar, see “Widgets and the Widget Bar” on page 24.

Function categories

Function categories are also shortcuts to the Dialer (for dialing a number), Contacts (accessing the Contacts), Web (for Internet connection), and Messages (displays the icons for application access). While viewing the Main Menu, the Menu category changes to Home. The Home icon returns you to the Home screen where the time, date, and Widget bar display.

Page 23

Understanding Your Phone 20

Icons

This list identifies the symbols that appear on your phone’s display screen:

Displays the received signal strength. The greater the number of bars, the stronger the signal.

Displays when you are out of your service area.

Displays the level of your battery. The more bars you see, the more power you have remaining.

Displays while connecting to the 3G network.

Displays while your phone synchronizes with the computer.

Displays when a new text message is received.

Displays when a new voice mail is received.

Displays when a new picture message is received.

Displays when Call forwarding is set to Forward always. For more information, refer to “Call Settings” on page 178.

Displays when Sound profiles are set to Silent.

Displays when Sound profiles are set to Vibration.

Displays when Sound profiles are set to Driving.

Displays when Sound profiles are set to Outdoor.

Page 24

Backlight

A backlight illuminates the internal display and the keypad. When you press any key, the backlight turns on. Backlight turns off when no keys are pressed or pressed within a given period of time, depending on the

Backlight

menu setting. The display turns off after one minute to conserve battery power.

To specify the length of time the backlight is active, access the

Backlight

menu:

1. From the Home screen, press then touch Settings ➔ Display settings.

2. Touch Backlight time.

3. Select the duration

8 seconds, 15 seconds, 30 seconds, 1 minute, 3 minutes

, or

10 minutes

4. Touch

Save

to confirm your selection.

Brightness

After you set the backlight duration, set the brightness levels.

1. From the Home screen, press then touch Settings ➔ Display settings.

2. Touch Brightness.

3. Slide the Level bar from 1-5 to select the brightness level.

4. Touch

Save

to confirm your selection.

Display

Your phone has a display on the front of the phone which indicates when you have an incoming call or message. It also alerts you at a specified time when an alarm was set by turning on the backlight and displaying a corresponding icon on the screen.

The display shows the current time and date on a digital clock.

Help

Help uses the Web to display some of the unique features of your phone. You can search help files on the fly while traveling, at home or anywhere.

1. From the Home screen, press then touch Help.

2. The T-Mobile Help menu displays with the following options available:

Page 25

Understanding Your Phone 22

•Top Questions

: this option gives you a list of the top questions about your phone, including typing tips, setting up e-mail,

finding pictures and videos, personalizing your phone, and browsing the web.

• Troubleshooting

: this option gives you a list of different topics from which you can select if you are have a problem with your

phone.

• My Account

: this option provides you with account-specific information such as your current status, current activity, usage

details, plan and services, and bill summary.

•More Help

: you can get more browsing help topics.

• System Information

: this option provides software version, battery level, signal strength, IMEI, and memory details.

• Help Settings

: you can enable or disable Customer Care call assist.

Note:

The menus may vary, depending on your subscription.

Page 26

Section 3: Displays

This section explains the widget and menu navigation for your phone. It also includes an outline of all the available

menus associated with your phone.

Home Screen

The Home screen is the starting point for using the applications or widgets on your phone. Home consists of three workspaces that extend to the right and left beyond the initial display width to provide three workspaces for docking widgets, folders, shortcuts or applications. Each Home screen displays a different wallpaper to aid you in navigation.

䊳

Slide your finger horizontally to the left and right on the screen to view the Home screens.

Note:

A three-part indicator at the top of the workspace shows you which workspace is active.

Home ScreenHome Screen

Panel 1 Panel 2

Home Screen Panel 3

Indicates which panel is displayed

Page 27

Displays 24

Customizing the Home Screen

You can customize the Home screen by docking widgets on different panels of the Home screen, or selecting a new wallpaper so you can easily distinguish between each of the individual panels.

Selecting a New Wallpaper

There are several sources available for wallpapers. You can download an image from the Display settings menu, use an image, or photo.

1. From the Home screen, press then touch

Settings

➔

Display settings

➔

Wallpaper

Touch a wallpaper panel to replace.

– or –

2. From the Home screen, press then touch

Photos

3. Touch

Set as

➔

Wallpaper

once you select a photo and touch

Set

Widgets and the Widget Bar

The Widget bar provides quick access to frequently-used features via Widgets, which act as shortcuts to launch the

features. You can store widgets in the Widget bar, or place them on the Home screen for quick access.

By default, 19 widgets display. For more information about widgets, see “Using Shortcuts” on page 36.

Accessing Widgets

To access the widgets:

1. Tap the Widget bar tab, located on the left side of the main display to open the Widget (quick access) bar.

2. Tap the Widget bar tab again to close the Widget bar.

Moving Widgets

Once you drop a widget onto the Home screen, press, hold, and drag the widget to another place on the screen.

To place the widget back in the tool bar:

䊳

Tap the Widget bar tab, then press, hold and drag the widget back to the Widget bar. The widget will drop back into the bar in the new location.

Page 28

Widget Manager

The Widget manager allows you to select widgets to display in the Widget bar. You can select widgets that function offline or widgets that function online (such as MyAccount, web2go, and more).

Simply touch the pull-down menu and select Offline or Online, then touch the check mark box to the right of the item you want to display and touch

Save

to save your configuration. Items available for selection are:

Main Menus

The Home screen is the starting point for launching applications. For more information about the applications offered on the Home screen, see “Home Screen” on page 23.

• Analog clock • Google Maps • Tips

• Birthday • IM • Today

• Bluetooth • Imaging tools • Voice mail

• Calculator • Message composer • Voice recognition

• Calendar • Message inbox • Voice recorder

• Digital clock • Photo • Weather

• Dual clock • Search • Web

• Email inbox • Social Buzz • Widget memo

• Games and apps • TeleNav • YouTube

Page 29

Navigation 26

Section 4: Navigation

This section explains the menu navigation for your phone. It also includes an outline of all the available menus

associated with your phone.

Menu Navigation

You can tailor the phone’s range of functions to your needs using menus and sub-menus. Menus and sub-menus can be accessed by scrolling using the Navigation keys or by using the shortcuts.

Locking and Unlocking the Phone

When you first turn on the device the screen is locked and displays the Smart unlock guide (see “Smart Unlock” on page 178.)

䊳

Press and hold the

lock

button on the side of the phone or draw a character to unlock the phone.

Note:

Smart unlock must be setup before you can draw a character to unlock the phone. For more information, refer to “Smart Unlock” on page 178.

If you want to permanently unlock the phone:

䊳

From the Home screen, press then touch

Settings

➔

Phone settings

➔

Touch panel auto-lock

and

touch the

Off

button.

Page 30

Opening an Application

The Home screen is the first screen displayed. The Main Functions menu displays after you select the Menu icon.

To open an application from the main menu:

1. Tap the associated icon.

2. Press the

Back

icon to return to the main menu.

Adding and Removing Main Menu Items

You can customize main menus by:

•

Renaming the menus

•

Save up to three pages of menu items

•

Adding widgets to the Main menu

•

Moving menu items to another location or panel

To customize a Main menu:

1. From the Home screen, press to display the main menu.

2. Scroll to the panels that display a

Plus sign

icon then touch the icon to display the

Add menu

screen.

3. Scroll through the list and touch the name of the application to add to the Home screen panel.

Main Functions

Home Screen

Page 31

Navigation 28

Touch the icon in the upper right corner of the screen. Touch the - area of any application you want to delete. Touch

Save

to remove the selected applications or

Cancel

to return to the menu. Touch

Reset

to reset

the menu to a default set of applications.

Menu Lists

Once you display a menu list, tapping an item causes different functions, depending on which item you tapped. For example, you can open another list, add text to a message, send a message, play a song, or view a photo.

䊳

To access items in a list, tap the item:

Navigation

Using the touch screen display and the keys, you can navigate the features of your phone and enter characters. The following conventions are used in this manual to describe the navigation action in the procedures.

Page 32

Accessing a Menu Function by Scrolling

As you navigate through a menu, options display on the screen as scrollable lists.

To navigate a scrollable list:

1. From the Home screen, press

then touch an application.

2. From the list of applications you can:

•

Gently touch an entry to activate it.

•

Firmly touch and slide your finger up or down the screen to scroll through lists of menu items. Scrolling on this device requires a more firm touch on the screen than the gentle touch required to open menu items.

•

Flick the screen in an upward motion to quickly scroll through the list.

The following image illustrates how to access the Settings menu options:

Note:

Tapping or touching individual entries on the list opens the list entry.

Page 33

Navigation 30

Accessing a Menu Function by Pressing

Press phone keys and buttons to select or activate an item. For example: press the Navigation key to scroll through a menu.

Page 34

Accessing a Menu Function using Press and Hold

Some buttons and keys require you to press and hold them to activate a feature, for example, you press the Lock key to lock and unlock the phone.

Page 35

Navigation 32

Accessing a Menu Function by Touching

Use a brief touch to select items on the display or to enter text on the virtual QWERTY keyboard. For example: touch a widget to open the application.

Page 36

Accessing a Menu Function using Touch and Hold

Touch and hold an icon or key to open the available options, or to access a pop-up menu. For example: press and hold on a Home screen to access a menu of customization options.

Note:

When you touch and hold the widget it transfers and to the Home screen and launches the application.

Page 37

Navigation 34

Accessing the Home Screen

Slide means to quickly drag your finger vertically or horizontally on the screen to move the area of focus or to scroll through a list. For example: slide your finger left or right on the Home screen to scroll among the three screens.

Accessing Menu items using Drag and Drop

Drag and drop allows you to move items from one area of the screen to another. Touch and hold an item, then drag the item to a new location, before lifting your finger to drop it in the new location. For example: drag a widget from the Widget bar and drop it onto a Home screen.

Tip:

You can drag widgets from one panel of the Home screen panel to another.

Slide your finger Left or Right to Select the next panel

Page 38

Screen Rotation

The screen can be rotated to change the orientation from portrait (default) to landscape. For example: rotate to landscape orientation when entering text, to provide a larger keyboard, or when viewing web content to minimize scrolling.

Display settings

In this menu, you can change various settings for the wallpaper, brightness, or backlight.

䊳

From the Home screen, press then touch

Settings

➔

Display settings

. For more information, refer to

“Display Settings” on page 171.

Menus

The Home screen contains three pages of menu items. To display and access menu items displayed on pages two and three, slide the screen left or right. The indicator at the top of the home screen indicates which page you are viewing.

Page one displays many of the frequently accessed applications such as:

• Applications • Messaging

• Audio postcard • Photos

• Calendar • Settings

• Call log • Social Buzz

• Camera • Videos

• Help • Web

Page 39

Navigation 36

Page two displays personal information and entertainment applications such as:

Page three displays the tools available to help keep you organized and track time such as:

Using Shortcuts

The Widget bar provides quick access to the items you use most frequently (Web, Photo, Message inbox, IM, Tips,

Telenav, Voice recognition, Calendar, Bluetooth, Today, Message composer, Games and apps, Voice mail, Widget memo, Digital clock, Analog clock, Dual clock, Birthday, Voice recorder, Calculator, Weather, Imaging tools, Search, Google Maps, YouTube, Social Buzz, and Email box.

The default widgets are: Widget manager, Web, Photo, Message inbox, Tips, Telenav, Calendar, Bluetooth, Today,

Widget memo, Weather, Imaging tools, Search, Google Maps, YouTube, Social Buzz, Email box. The rest of the widgets are configurable.

The following table contains a description of each Widget, its function, and how to navigate through that particular

application. If the application is already described in another section of this user manual, then a cross-reference to that particular section is provided.

• Bluetooth • My Album Online

• Downloads • TeleNav

• Google Maps • Voicemail

• Music player • YouTube

• My Account

• Alarm • Exchange email

• Calculator • IM

• Email • Memo

Page 40

Alarm Clock

This feature allows you to:

• Set up to 10 alarms to ring at specified times.

• Set the phone to switch on automatically and ring the alarm even if the phone is switched

off.

To set the alarm:

1. From the Home screen, press then touch

Alarm

– or –

From the Home screen, open the Widget bar and tap the

Alarm

widget.

For more information, refer to “Alarm Clock” on page 126.

Analog Clock

The display shows the current time on an analog clock.

䊳

From the Home screen, open the Widget tray and touch, drag and drop the

Analog clock

onto the desktop to view the time in an analog format.

Birthday Events

Displays birthday events entered into the Contacts.

䊳

From the Home screen, open the Widget tray and touch, drag and drop the

Birthday

widget onto the desktop to view any scheduled Birthday events. When you add a

Birthday to the contact, a Birthday event is created and displays on the appropriate day.

For more information, refer to “Birthday Widget” on page 133.

Page 41

Navigation 38

Bluetooth

From this application you can activate Bluetooth and configure it so other Bluetooth devices can see your device by name.

䊳

From the Home screen, open the Widget tray and touch, drag and drop, then tap the

Bluetooth

icon to launch the Bluetooth application.

For more information, refer to “Bluetooth” on page 158.

Calculator

Using this feature you can use the phone as a calculator. The calculator provides the basic arithmetic functions; addition, subtraction, multiplication, and division. You can also use this as a scientific calculator.

䊳

From the Home screen, open the Widget tray and touch, drag and drop the

Calculator

onto the desktop.

For more information, refer to “Calculator” on page 131.

Calendar

With the Calendar feature, you can:

• Consult the calendar by month, week, or day.

• Set schedules and note anniversaries.

• Create an events list.

• Set an alarm to act as a reminder, if necessary.

• Check your event memory status.

䊳

From the Home screen, open the Widget tray and tap the

Calendar

widget to display the

Calendar.

For more information, refer to “Calendar” on page 134.

Page 42

Digital Clock

The display shows the current time on a digital clock.

䊳

From the Home screen, open the Widget tray and touch, drag and drop the

Digital clock

onto the desktop to view the time in a digital format.

For more information, refer to “Digital Clock” on page 135.

Dual Clock (World clock)

This feature allows you to find out what time it is another part of world.

䊳

From the Home screen, open the Widget tray and touch, drag and drop the Dual clock onto the desktop to view the time in dual locations.

Email box

Note:

When this widget is activated in Widget Manager, the widget displays on Panel 1 of the Home screen and not in the Widget bar.

1. From the Home screen, scroll to Panel 1 of the Home screen and tap the

Email box

widget. The Welcome screen displays.

2. Touch

to walk through the configuration wizard and configure Email.

Games and Apps

Provides access to Games and apps and other applications so you can download additional games from the T-Mobile website.

䊳

From the Home screen, open the Widget tray and tap the

Games and apps

widget to

launch the Games and apps menu.

For more information, refer to “Games and Apps” on page 125.

Page 43

Navigation 40

Google Maps

Google Maps allow you to track your current location, view real-time traffic issues, and view detailed destination directions. There is also a search tool included to help you locate places of interest or a specific address. You can view locations on a vector or aerial map, or you can view locations at the street level.

䊳

From the Home screen, open the Widget tray and tap the

Google Maps

widget.

For more information, refer to “Google Maps” on page 136.

Imaging Tools

The Imaging Tools icon displays shortcuts that you can use to take photos, create slideshows, manage and print photos, or use the service features provided by Flickr, Kodak, Photobucket, and Snapfish.

1. From the Home screen, open the Widget tray and tap the

Imaging tools

widget.

2. Select one of the services,

Photos, Take Ph oto, Flickr, Kodak, Photobucket

, or

Snapfish

3. Touch

Settings

and touch the check box next to each imaging tool you want to display in

this menu, then touch

Save

Instant Messaging

Instant Messaging (IM) is a way of sending short, simple messages that are delivered immediately to users online at that moment.

Before using this feature, you need to subscribe to a messenger service. For further details, contact your service provider.

䊳

From the Home screen, open the Widget tray and touch the IM widget to launch the

Select community

screen.

For more information, refer to “IM (Instant Messaging)” on page 99.

Page 44

Widget Memo

This feature allows you to create a memo.

1. From the Home screen, open the Widget tray and tap the

Memo

widget.

2. Tap the

Memo

widget again to insert a memo, then touch

Done

Message Inbox

The Message Inbox stores received messages.

䊳

From the Home screen, open the Widget tray and tap the Messages icon to display the

Inbox. From this screen you can move messages from the Inbox into other folders.

Message Composer

This application allows you to use Short Message Service (SMS) in order to send short messages. For more information, refer to “Text Messages” on page 87.

You can also use the Multi Media Service (MMS) to create multimedia messages to send and receive from other mobile phones. For more information, refer to “Picture Messages” on page 89.

1. From the Home screen, open the Widget tray and tap the

Message Composer

2. Touch

Create Message

then tap the screen to display the keyboard and create your

message.

Page 45

Navigation 42

Music Player

When you first view the Music Player application, the Music library screen displays the following:

• Current playlist

• All tracks

• Playlists

• Artists

• Albums

• Recently played

From this screen you can play your music files.

䊳

From the Home screen, press

Music player

For more information, refer to “Music Player” on page 111.

My Account

This option takes you to T-Mobile Help and provides categories such as Top Questions, Troubleshooting, My Account, More Help, System Information and Help Settings.

䊳

From the Home screen, open the Widget tray and tap

My Account

Photos

In this menu, you can view the list of photos downloaded from the web server, received in messages, or taken by the camera.

䊳

From the Home screen, open the Widget tray and touch


For more information, refer to “Photos” on page 120.

The Search application provides a single search tool to find information on your device, including Contacts, Calls, Video, Image or Music files, Scheduled events, Messages, or Applications.

1. From the Home screen, open the Widget tray and tap the

Widget.

2. Type the information you are looking for in the search field and touch

Done

Page 46

Social Buzz

This menu item lets you log in to your social networking applications (Twitter, Facebook, or MySpace) and get automatic status updates for each of these applications.

Important!:

Charges may apply when using social network applications.

1. From the Home screen, press then touch

Social Buzz

For more information, refer to “Social Buzz” on page 156.

TeleNav GPS Navigator

TeleNav is a driving aid that uses both audible and visual instruction for GPS navigation. For more information, refer to “TeleNav GPS” on page 126.

For more information, refer to “TeleNav GPS” on page 126.

Tips

Tips were designed to work with your browser to show you some of the unique features of your phone.

Contains user help about the following subjects:

- Using tips - Camera

- Physical keys - Photos

- Widget bar - Music player

- Volume - Bluetooth

- Making a call - More Help

- Contacts - Browser

1. From the Home screen, open the Widget tray and tap the

Tips

Widget to move it to the

Home screen.

For more information, refer to “Tips” on page 137.

Page 47

Navigation 44

Today

This menu displays the current day and date.

䊳

Touch, drag and drop the Today icon onto the desktop to view the current Day and Date.

For more information, refer to “Time & Date” on page 173.

Voice Mail

You can access your Voice Mail by either pressing and holding on the keypad, by using the phone’s menu, or by touching the Voice Mail widget in the Widget bar.

For more information, refer to “Voicemail” on page 95.

Voice recognition

An advanced voice software used to activate a wide variety of functions on your phone. Nuance® software automatically voice activates (up to 2,000 contacts) for voice dialing and searching. Speak a contact name naturally to dial, and use your voice to look up contacts, launch applications and navigate phone menus.

䊳

From the Home screen, open the Widget tray and tap the

Voice

widget to launch the

Nuance (Voice) application.

For more information, refer to “Voice Recognition” on page 59.

Voice Recorder

The Voice Recorder allows you to record an audio file up to one minute long and then immediately send it as a message.

1. From the Home screen, open the Widget tray and touch, drag and drop the

Voice

Recorder

widget onto the Home screen.

For more information, refer to “Using the Voice Recorder” on page 130.

Page 48

Weather

Provides weather information and alerts so you can cope with the elements. Enter the zip code for the area where you are located to activate the alerts.

1. From the Home screen, open the Widget tray and touch, drag and drop the

Weather

widget onto the Home screen.

2. Tap the

Weather

widget, enter your zip code, then touch

Done

Web Browser

The browser feature allows you to access the news headlines from the sites you select or browse the web if you need more information. This service requires a data plan. For further details, contact your service provider.

1. From the Home screen, open the Widget tray and touch, drag and drop the web2go

widget onto the Home screen.

2. Tap Go to open the Setup menu, then touch one of the News services and touch Save.

For more information, refer to “Accessing the Web” on page 152.

Widget Manager

In this menu you can select the items you want to display in the Widget bar (quick access menu).

1. From the Home screen, open the Widget bar and tap the Widget Manager widget.

2. Touch the check mark box to the right of the item you want to display.

3. Touch

Save

to save your configuration.

YouTube

YouTube is a video sharing website on which users can upload and share videos and view them in MPEG-4 format.

1. From the Home screen, press then touch YouTube.

2. From the Home screen, open the Wiedget bar and touch YouTube.

For more information, refer to “YouTube” on page 157.

Setup

Page 49

Navigation 46

Accessing Widgets

Widget Bar Navigation

You can drag the widgets to the desktop to use the application or feature, then drag it back to the Widget bar when you are finished.

Tap the Widget bar to open

Tap the Widget bar to close

Page 50

Dragging and Dropping

Certain menus allow you to move (drag and drop) an application onto the Main display screen. For example, you can drag the Music Player from the Shortcut menu onto the Main display screen using the drag and drop feature (see illustration).

To drag and drop an application or item onto the Main display:

1. Touch and hold the widget you want to move and drag it to the Main display screen.

2. Drop the widget by releasing your finger.

The application is now located in another menu or in the case of this example, on the Main display screen.

Drag from the Widget bar

Drop onto the Idle screen

Page 51

Navigation 48

Tapping

After you drag and drop an application to the desktop, tap on the application to display more information.

Page 52

Scrolling

The Widget bar contains up to 25 widgets, but can only display five widget icons at one time.

To view more widgets:

䊳

Swipe up and down along the Widget bar.

Tip:

Flick the screen in an upward motion to quickly scroll through the list.

Widget Settings

To select which items display or hide in the Widget bar:

1. From the Home screen, open the Widget bar and tap the

Widget Manager

widget.

2. Touch the check box to place a check mark next to the Widget you want to display.

Note:

By default fifteen of the widgets are checked and display, and seven of the widgets require activation. For more information, refer to “Widget Manager” on page 161.

3. Touch the check box again to remove the check mark and hide the widget.

Touch a checkbox to activate this Widget

Page 53

Navigation 50

Accessing the Home Screen

Search provides a single search tool to find different types of information on your device, including Contacts, Calls, Video, Image or Music files, Scheduled events, Messages, or Applications.

1. From the Home screen, open the Widget bar and tap the

widget.

2. Enter the name or numbers for which you are looking and touch

Done

Slide your finger Left or Right to Select the next panel

Page 54

Section 5: Call Functions

This section describes how to make or answer a call. It also explains the features and functionality associated with

making or answering a call. For more information, refer to “Call Settings” on page 178.

Making a Call

䊳

From the Home screen, touch the

Dialer

icon, and then enter the number you want to dial and press .

Note:

When you activate the Auto redial option in the Call settings menu, the phone automatically redials up to 10 times when the person does not answer the call or is already on the phone, provided your call is not sent to voice mail. For more information, refer to “Call Settings” on page 178.

Making an International Call

1. From the Home screen, touch the

Dialer

icon, then press and hold . The + character displays.

2. Enter the country code, area code, and phone number.

3. Press to make the call.

Correcting the Number

1. Touch to clear the last digit displayed.

2. Touch and hold to clear the entire display.

Ending a Call

1. Briefly press to end the call.

– or –

2. Touch the icon to the right of the phone number, or name if stored in Contacts, for which you want to end the

call.

Page 55

Call Functions 52

Redialing the Last Number

The phone stores the numbers of the calls you have dialed, received, or missed if the caller is identified.

To recall any of these numbers:

1. Touch

➔

Call log

to display the logs. All is the default but you can use the drop down list to select

All

calls, All, Missed calls

, or

Outgoing calls

(a list of the most recently used numbers in the order you dialed or

received them).

2. Select the number to view details.

3. Press to dial the number.

Adjusting the Call Volume

During a call, use the Volume keys on the left side of the phone, to adjust the earpiece volume.

䊳

Press the Up volume key to increase the volume level and the

Down

volume key to decrease the level.

From the Home screen, you can also adjust the ring volume using these keys.

Answering a Call

When somebody calls you, the phone rings and displays the incoming call image.

The caller’s phone number, or name if stored in Contacts, displays.

1. Press to answer the incoming call.

If the Any key option in the Answering mode menu is activated, you can touch any key to answer a call

except for the key. For more information, refer to “Call Settings” on page 178.

Note:

To reject an incoming call, press .

2. End the call by pressing .

Note:

You can answer a call while using Contacts or menu features. After ending the call, the phone returns to the function screen you were previously using.

Page 56

Options During a Call

Your phone provides a number of control functions that are available for use during a call.

Turning the Speakerphone on and off

While on a call, you can use your Speakerphone by pressing the

Speaker

icon to turn the speakerphone on or off.

Tip:

When the speaker is turned On, the color of the speaker is teal. When the speaker is turned

Off

, the color of the speaker is gray.

Switch to Bluetooth Headset

While on a call, switch to the Bluetooth headset instead of speaker by pressing the

Headset

icon.

Muting a Call

During a call you can activate the Mute feature. This feature is used, for example, during a multiparty call when you want to listen to the call but do not want to interrupt with background noise or talking.

1. Touch the

Mute

icon so the other caller cannot hear you speaking.

2. Touch the

Mute

icon to turn mute off and resume your conversation.

In-call options

Page 57

Call Functions 54

Viewing the Call log

During a call you can touch the

Call log

icon to view

All calls, All, Missed calls

, or

Outgoing calls

. This feature might

be useful if, during a call, you want to add another contact to a multiparty call.

1. Touch the

Call log

icon to view the call history

2. Press

Back

to return to the In call screen.

Placing a Call on Hold

You can place the current call on hold whenever you want. If your network supports this service, you can also make another call while a call is in progress.

To place a call on hold:

1. Touch

Hold

to place the current call on hold.

2. Touch

Retrieve

to activate the call that is on hold.

To make a new call while a call is in progress:

3. Enter the new phone number that you want to dial or look it up in Call history.

4. Touch

Hold

to place the first caller on hold.

5. Touch

New call

to dial the second call.

6. Dial the new phone number and press .

To switch between the two calls:

7. Touch

Swap

The In call number is now on hold and displays on the

On hold

tab, while the On hold number displays

on the

In call

tab.

Swapping Calls

䊳

Touch the

Swap

icon to place the current call on hold and then activate the previous call.

Page 58

Accessing the Contacts During a Call

You can search for a number in Contacts during a call.

1. Touch the

Contacts

icon to access the Contact lists.

2. Press when you are finished.

Ending a Call

1. Briefly press to end the call.

– or –

2. Touch the

End

icon to the right of the phone number for which you want to end the call.

Call Log

All incoming, outgoing and missed calls are listed in the Call history. You can also view Call time records or reset all the call time records.

1. From the Home screen, press then touch Call log.

2. Touch the

All calls

drop down to display the following options:

All (calls)

This menu lets you view the 90 most recent calls you received, dialed, and missed.

The name or number, if already stored in your Contacts, displays.

Note:

At any time while you are in Call history, you may use the drop down list to scroll between All, Missed calls, Outgoing calls, and Incoming calls.

Missed calls

This menu lets you view the 30 most recent calls you received, but did not answer. The name and number, if already stored in your Contacts, displays.

Viewing Missed Calls

When you are unable to answer a call for any reason, you can find out who is calling you, if this service is available, so that you can call the person back.

The number of calls you missed displays on the idle screen immediately after a call is missed.

Page 59

Call Functions 56

To view a missed call immediately:

1. If the display is off, press the

Lock

key to turn the display on. The missed calls display on the screen on the

Missed Calls

tab.

2. Press to call the displayed number.

Tip:

You can press at any time to exit the Missed Call feature.

Outgoing calls

This menu lets you view the 30 most recent calls you dialed.

The name and number, if already stored in your Contacts, displays.

Incoming calls

This menu lets you view the 30 most recent calls you received.

The name and number, if already stored in your Contacts, displays.

Accessing Call Log Messages

After you select a category of calls from the All calls drop-down you can view Missed calls, Received and Sent messages for a selected number.

1. From the Home screen, press then touch Call log.

2. Touch the

All calls

drop down and select one of the categories.

3. Touch one of the numbers in the list.

4. Touch the

Left

Right

Navigation key to display

Missed calls, Received msg.

, or

Sent msg.

information.

5. Touch

Contact details

to view the details for this contact.

6. Touch

Copy to dialing

screen to display the number on the Dialer screen and call this contact.

7. Press to exit the screen.

Page 60

Delete

Pressing this key allows you to delete the records in each call record separately, or you can delete all of your call records at one time.

1. Touch the check box beside the number in the

Delete

list to delete or select the

Select all

check box and touch

the

Delete

soft key. The selected number or all the numbers are deleted, and the list redisplays.

Note:

All

is selected, the list redisplays but it is empty.

Making a Multi-Party Call

A multi-party call is a network service that allows up to six people to participate in a multi-party or conference call.

For further details about subscribing to this service, contact T-Mobile customer service.

Setting up a Multi-Party Call

1. Call the first participant in the normal way.

2. Touch

New call

, enter the second phone number and press .

3. Touch

Join

The two calls are now joined into a multi-party call and displayed in the order in which they were called.

Important!:

A maximum of six callers can be joined to a single multi-party line. Additional callers participate in a new Multiparty session and held in conjunction with the previous multiparty call. You can swap or place each multi-party call on hold.

Having a Private Conversation With One Participant

When you have two participants in a multi-party session, you might be necessary to place one of those participants on hold so that a private conversation can be held with a single caller. While you are in a multi-party call:

1. Touch

Split

The short list of call participants displays the callers in the order they were dialed.

2. Select the number for the participant in which you want to speak privately.

You can now talk privately to that person while the other participants can continue to converse with each

other. If there is only one other participant, that person is placed on hold.

Page 61

Call Functions 58

To return to the multi-party call, touch the Join icon. All of the multi-party call participants can now hear each other.

Dropping One Participant

If the call is joined:

1. Press

Options

➔

Split

and highlight the number to split.

2. Press

Options

➔

End held call

to drop the call on hold.

3. Press

Options

➔

Swap

to switch to the other number to drop, then press

Options

➔

End held call

4. Press to end the multi-party call.

Putting a Call on Hold

You can place the current call on hold whenever you want. You can also make another call while you have a call in progress if your network supports this service.

To place a call on hold:

䊳

Touch the

Hold

icon.

To make a new call while you have a call in progress:

1. Call the first participant in the normal way.

2. Touch

New call

, enter the second phone number and press .

The first call is automatically placed on hold.

When you have both an active call and a call on hold, you may switch between the two calls.

To switch between the two calls:

1. Touch either the

Active call

tab, or the

On hold

tab, and touch the

Swap

icon. The current active call is placed

on hold and the call on hold is then reactivated so that you can continue conversing with that person.

2. To finish, end each call normally by pressing .

Page 62

Searching for a Number in Contacts

You can search for a number in Contacts during a call.

1. Touch the Contacts icon.

With Contacts displayed:

2. Touch the contact name displayed in the list to view the entry.

The Contact information displays.

Call Waiting

You can answer an incoming call while you have a call in progress, if this service is supported by the network and you must have previously set the Call waiting option to Activate. For more information, refer to “Call Settings” on page 178.

You are then notified of an incoming call by a call waiting tone.

To answer a new call while you have a call in progress:

1. Press to answer the incoming call. The first call is automatically put on hold.

2. To switch between the two calls, touch either the

In call

tab or the

On hold

call tab, then touch the swap icon.

3. To end a call on hold, touch the

On hold

tab, then touch the End call icon.

4. Touch

All calls

, or touch the call you wish to end and touch

Done

5. Press to end the current/remaining call.

Voice Recognition

Nuance is an advanced speech software used to activate a wide variety of functions on your phone. Nuance software automatically voice activates (up to 2,000 contacts) for voice dialing and searching. No prerecording or training needed. Speak a contact name naturally to dial, and use your voice to look up contacts, launch applications and navigate phone menus.

1. From the Home screen, press then touch

Applications

➔

Voice recognition

2. At the voice prompt, say a command. The list of available commands is listed below.

Note:

This list of voice commands is briefly displayed.

Page 63

Call Functions 60

Say a Command Options

• Call <Name or #>: dials a name or number listed in your contact list. If multiple numbers exist (i.e. home, work,

or other) say the name and the number type (location).

• Send Text <Name or #>: displays the Create Text Message screen.

• Lookup <Name>: allows you to use a voice command to locate and display contact information stored in

Contacts. For more information, refer to “Finding a Contact Entry” on page 74.

• Go to <Menu>: accesses all the features of your phone if they are activated, such as: Web, Calendar, Ringtones,

Tasks, Contacts, Voice mail, and Games.

• Check <Item>: lets you check your phone's status in the same report (Status, Messages, Missed Calls, Time,

Signal Strength, Network, Battery, My Phone Number, and Volume).

While the Say a command screen displays you have two options:

•

Tutori al

: provides examples of how to use the voice commands.

•

Settings

: lists the settings for voice command software such as: Confirmation, Adaptation, Audio Modes, Speakerphone, and

About.

If the phone does not recognize your command the Command not recognized screen displays with two options:

•

Restart

: touch and try the command options again.

Speak clearly when giving your command. There is no need for you to speak slowly or with added emphasis. The voice software has been optimized to understand your speech in its natural form. If it does not recognize your command after a few seconds, a voice prompt asks you to repeat the command. If it does not recognize your command again, the following message displays “Sorry, no match found,” and voice turns off.

Important!:

You must end your current Voice Commands call before you can make another call.

Voice Tips

•

Wait for the tone before you speak.

•

Speak clearly and at a normal volume.

•

There is no need to use paused speech. The voice software has been trained to recognize natural speech, and performs best

when you speak naturally.

•

In very noise environments, it may be helpful to use the supplied earset or optional Bluetooth headsets.

Page 64

Contacts Voice Activation

On startup, Nuance reads your Contacts and voice-activates all the names.

When you have add or change contacts, Nuance automatically reloads and voice-activates the list when you add or modify a contact.

Name Dialing

To use Name Dial, you need entries stored in your Contacts. For information on creating Contact entries, see “Storing a Number in the Phone’s Memory” on page 72.

To access Voice:

1. From the Home screen, press then touch

Applications

➔

Voice recognition

2. Say “Call” followed by the first and last name of the contact that you want to dial.

The name that you said is repeated through the earpiece and your phone dials the number.

3. If Nuance is not sure of the name that you said, a list of possible matches displays on the screen.

4. You are asked to confirm the correct name as Nuance displays the results. Say “Yes” or “No” to confirm or

reject the number when prompted.

The location is repeated through the earpiece and your phone dials the number.

Send Text Message

To access Voice:

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command”

message.

2. Say “Send Text” at a distance of 3-8 inches from the microphone. “Say the Name” plays through the

earpiece.

3. After you say a name, you might be prompted, “Did you say send text?” To confirm a name, wait for the

beep and then say “Yes.”

4. When the Text Message client launches, touch the screen and compose your text message.

Page 65

Call Functions 62

Name Lookup

To perform a name lookup, you will need to have some entries in your Contact list.

To access Voice:

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command”

message.

2. Say “Lookup” at a distance of 3-8 inches from the microphone. “Say the name” plays through the earpiece.

3. Say the name exactly as it displays in your Contacts, first name followed by last name.

4. The contact name displays on the screen with other information that you have entered for that contact.

Opening Applications

You can open an application or access a menu on your phone using Voice.

To access Voice:

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command” message.

2. Say “Go To” at a distance of 3-8 inches from the microphone. A list of options displays.

Note:

You can also say, “Go To” followed by the name of the application, such as, “Web”.

The spoken application menu option activates.

Page 66

Checking Phone Status

Use the Check command to see and hear status information from your phone, including its phone number, status, current signal strength, and battery level.

To check phone status:

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command” message.

2. Say “Check” at a distance of 3-8 inches from the microphone. A list of options displays.

The spoken application menu option displays.

Voice Settings

Confirmation

Nuance uses a confirmation list when a name or number is not clearly recognized. The software displays three choices and prompts you to select a choice.

You can modify the way Nuance uses the confirmation list in the settings. Each time Nuance activates you can choose to view the confirmation list even if there is only one choice. Additionally, you can choose never to view a confirmation list, even if there are multiple choices. When the name or number you speak is not recognized, the Automatic setting displays the confirmation list.

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command”

message.

2. From the “

Say a command

” screen, touch

Settings

➔

Confirmation

3. Select one of the following options:

•Automatic

: Nuance displays a confirmation list only when it is not sure if it has correctly recognized the name or number.

• Always Confirm

: Nuance always displays a confirmation list, even when there is only one choice.

• Never Confirm

: Nuance never displays a confirmation list.

Page 67

Call Functions 64

Adaptation

If Nuance frequently does not recognize your commands, adapting digit dialing to your voice improves the accuracy of digit.

After you adapt Digit Dial, your phone recognizes only your voice. Other users are not able to use the handset with Nuance unless the handset is reset to factory defaults.

Adapting requires recording multiple sequences of digits. The entire adaptation process takes approximately one minute.

1. From the Home screen, press then touch

Applications

➔

Voice recognition

After a brief pause, a list of available commands displays on the screen along with the “Say a command” message.

2. From the “

Say a command

” screen, touch

Settings ➔ Adaptation

3. Touch

Adapt Voice

4. Touch

Start

to begin adaptation or touch

Back

to cancel.

5. The screen displays an adaptation message. The entire adaptation process takes just a couple of minutes to

complete.

Tip:

Perform the adaptation process in a quiet room.

Audio Modes

Your voice software includes an interface that allows you to customize your voice, mode setting to match your experience and comfort level with voice commands.

1. From the Home screen, press then touch

Applications

➔

Voice recognition

. After a brief pause, a list of available commands displays on the screen along with the “Say a command”

message.

2. From the “

Say a command

” screen, touch

Settings

➔

Audio Modes

Page 68

Select one of the following options:

•Expert Mode

: turns off the voice and text prompts.

•Prompt Mode

: this is the default mode. Uses a voice prompt to confirm your selection and also displays a confirmation screen.

• Readout Mode

: displays text on the screen, then reads it out loud.

Speakerphone

The Speakerphone feature allows you to turn voice through the speakerphone On or Off. You can also automatically connect to the speakerphone if you select Automatic.

About

The About option displays information about Nuance including version number, LVR number, Build number, and device number.

Page 69

Entering Text 66

Section 6: Entering Text

This section outlines how to select the desired text input mode when entering characters into your phone. This section

also describes how to use the T9 predictive text entry system to reduce the number of key strokes associated with entering text.

Using the QWERTY Keyboard

This phone also offers the convenience of a slideout QWERTY keyboard. Using the QWERTY keyboard, you can type letters, numbers, punctuation, and other special characters into text entry fields or other applications simpler and faster than using the telephone keypad.

The following keys perform special functions when entering text:

Emoticon

displays a list of emoticons to insert into messages.

Alt

allows you to use characters displayed at the top of the QWERTY keys. Examples: $, @, #, !

Page 70

Sym/shift

displays pages of Symbols. Choose from an extensive list of symbols and other character sets. Alt+Sym/shift allows you to enter the Symbol displayed on the key. Also converts the alphabetic character into

uppercase. Changes the text input mode to Upper/Lower case mode.

www/.com

Alt+Sym/shift inserts www. Press www/.com key to enter the .com when entering a URL in the

browser, or when logging in to Instant Messenger.

Space

inserts an empty space.

allows you to accept the choices offered when navigating through a menu.

Return

moves the insertion point to the next line in a message.

Navigation keys

scrolls through the phone’s menu options.

Backspace

deletes the previous character, similar to the backspace key on a computer keyboard.

The keyboard provides dual-use keys labeled with alphabetic characters on the lower half and numbers and symbols on the upper half. Touch the key corresponding to the character you want to enter.

Changing the Text Input Mode

When using your phone, you often need to enter text, such as when storing a name in your Contacts, creating your personal greeting or scheduling events on your calendar. You can enter alphanumeric characters by using your phone’s keypad.

Your phone has the following text input modes:

•

ABC

: this mode allows you to enter letters by pressing the key labeled with the corresponding letter.

•

T9Ab

: this mode allows you to enter words with only one keystroke per letter. The T9 mode automatically compares the series of keystrokes you make with an internal linguistic dictionary to determine the most likely word, thus requiring fewer keystrokes than the traditional ABC mode.

•

Numeric

: this mode allows you to enter numbers. (Numeric displays on the external screen only).

•

Symbols

: this mode allows you to enter symbols, such as punctuation marks.

Note:

When you are in a field where you can enter characters, the text input mode indicator displays on the top right portion of the screen.

Page 71

Entering Text 68

Example:

Writing a text message.

There are two different methods for changing Text Input Mode, depending on which mode you are holding the device (portrait, or landscape). In Portrait mode a 3x4 numeric keypad displays with the default set to T9Ab (predictive text) mode. In Landscape mode a QWERTY keypad displays in Abc (text) mode.

Changing Text Input Mode - Portrait mode

1. Tap the screen to display the keypad.

2. Touch the

T9Ab

key and select from the following:

•

Abc

•

ABC

•

abc

•

Numeric

•

Symbols

Create message Portrait mode

Create message Landscape mode

Page 72

Using T9 Mode

T9 is a predictive text input mode that allows you to key in any character using single keystrokes. This text input mode is based on a built-in dictionary.

Note:

To mode works only in Portrait mode.

To enter a word in T9 mode:

1. When you are in T9 mode, start entering a word by pressing the 2 to 9 keys. Touch each key only once for

each letter.

Example:

To enter “Hello” in T9 mode, touch the 4, 3, 5, 5, and 6 keys.

The word that you are typing displays on the screen. It may change with each consecutive key that you touch.

2. Enter the whole word before editing or deleting the keystrokes.

3. When the word correctly displays, go to step 4.

If the word does not display correctly, other word choices display on the screen from which to choose. If these

choices do not include the word you want to use, add a new word into the T9 dictionary.

Example:

Both the words “Of” and “Me” use the 6 and 3 keys. The phone displays the most commonly used choice first.

4. Insert a space by pressing

Space

and start entering the next word.

To add a new word into the T9 dictionary:

1. If the word does not display in the alternate choices, touch the pull-down menu and select

Add word

2. Enter the word you want to add using ABC mode. For more information, refer to “Changing the Text Input

Mode” on page 67.

3. Touch Done to accept the newly added word.

The word is added to the T9 dictionary and becomes a word for the associated key press series.

Page 73

Entering Text 70

Note:

This feature may not be available for some languages.

•

To enter periods, hyphens, and other special characters, touch

Symbols

and then touch the corresponding key. If the symbol

does not display on the initial screen, touch the left or right key to display the next set of symbols. Press

T9Abc

to return to the T9Abc input mode.

•

To shift case in T9 mode, touch

Shift

and then touch the desired letter on the keypad. There are 3 cases: Initial capital, Capital

lock, and Lower case.

•

You can move the cursor by pressing the screen. To delete letters, touch . To clear the display, touch and hold

Using ABC Mode

To use ABC mode, use the 2 to 9 keys to enter your text.

䊳

Touch the key labeled with the letter you want:

•

Once for the first letter, twice for the second letter, and so on.

Using Numeric

The Numeric mode enables you to enter numbers into a text message.

䊳

Touch the keys corresponding to the digits you want to enter.

Using Symbols

Symbol mode enables you to insert symbols and punctuation marks into text. To display a list of symbols touch

Symbols

(portrait mode).

Entering Symbols in Portrait Mode:

1. To select a symbol, touch

Symbols

2. Touch the left or right arrow keys to display more symbols.

Entering Symbols in Landscape Mode:

1. Press

Alt

and touch the symbol on the key that displays the symbol you need.

2. Touch to clear the symbol(s). Touch and hold to clear the display.

Page 74

Tip:

The cursor moves to the right when you touch a different key. When entering the same letter twice or a different letter on the same key, wait for a few seconds for the cursor to automatically move to the right, and then select the next letter.

Keys

By default, the first letter of an entry is capitalized and all consecutive letters are kept in lowercase (unless you touch the Shift key). After entering a character, the cursor automatically advances to the next space after two seconds or when you enter a character on a different key.

Keys display in two formats: Portrait (keypad) and landscape (QWERTY keyboard). Depending on which format you are using (portrait or QWERTY), the keys are associated with different letters and/or characters. Refer to the following layouts to determine which keys are associated with letters, characters, or symbols.

Create New Message Portrait Keypad

Create New Message Landscape Keyboard

Page 75

Understanding Your Contacts List 72

Section 7: Understanding Your Contacts List

This section explains how to use and manage your Phonebook. You can save phone numbers to your phone’s memory

or to your SIM card.

Using Mobile Address Book

Use the following procedures to store a new contact to your phone.

Storing a Number in the Phone’s Memory

The default storage location for saving phone numbers to your Phonebook is your phone’s built-in memory.

Note:

Before you can save a contact to the Phone, Contact settings must be set to

Save new contacts to Phone

. For more information,

refer to “Save new contacts to” on page 81.

When you access the Phonebook for the first time, or if you use another SIM card in this phone, the Mobile Address Book feature copies the information stored on your SIM card to the phone’s memory and synchronizes with the T-Mobile network.

After the initial use of this feature, additional, new contact information stores directly to the phone’s memory and synchronizes with T-Mobile’s network during predetermined, timed intervals. For more information, refer to “Mobile backup” on page 80.

Note:

When storing an entry into your SIM card, note that only the Name and Number are saved. To save additional information for a particular contact, such as notes, e-mail, dates, and so on, it is important to save that Contact into your phone’s onboard memory.

1. From the Home screen, touch

Contacts

2. Touch

Create contact

3. Touch the

Phone

tab.

Important!:

The Phone or SIM tab determine where the new contact information saves.

4. Touch the

First name

field, enter a first name using the displayed keypad and touch

Done

5. Touch the

Last name

field, enter a last name using the displayed keypad and touch

Done

Page 76

Enter a phone number, email, or other information into one of the following fields using the displayed keypad and touch

Done

• Mobile

: assigns the number entered to the Mobile entry.

•Home

: assigns the number entered to the Home entry.

•Work

: assigns the number entered to the Office entry.

• Other number

: allows you to enter an additional phone number for this entry.

•Email

: assigns the number entered as private Email.

•IM

: allows you to enter the IM user name for the contact.

•Group

: allows you to assign this contact to a group.

•Ringtone

: allows you to select a sound to use as a ringtone.

• Birthday

: allows you to enter a birthday Month, Day, and Year for this contact.

• Address

: allows you to enter an address for this contact.

•Notes

: allows you to enter notes for this contact.

Note:

You can save up to 2,000 phonebook entries.

7. Touch

Add more fields

to add additional information.

8. Touch

Save

when you are finished.

Storing a Number on the SIM Card

The default storage location for saving phone numbers to your Phonebook is your phone’s built-in memory. To save a number to your SIM card, you first need to change the

Save new contacts

option. For more information, refer to

“Save new contacts to” on page 81.

Note:

To view numbers on the SIM card you must set

View contacts from

All

SIM

in the Contact settings menu.

1. From the Home screen, touch

Contacts

2. Touch

Create contact

3. Touch the

SIM

tab.

4. Touch the

Name

field, enter a name using the displayed keypad.

Page 77

Understanding Your Contacts List 74

Enter a numberin the Phone number field.

6. Touch

Save

when you are finished.

Note:

For further details about how to enter characters, see “Using ABC Mode” on page 70.

Finding a Contact Entry

You can store phone numbers and their corresponding names onto either your SIM card or phone’s built-in memory. They are physically separate but are used as a single entity, called Phonebook.

Depending on the storage size of the particular SIM card, the maximum number of phone numbers the card can store may differ.

1. From the Home screen, touch

Contacts

2. Touch the Contact entry.

– or –

Tap the

field, enter a contact name or number and touch

Done

– or –

Touch and hold the slide bar and drag to the desired name.

3. When you locate the entry, press to dial the number or touch:

•Edit

allows you to edit the Name and number for the selected contact.

•Delete

: allows you to delete the selected name and number from your Phonebook or delete multiple numbers. You are asked

to confirm that you want to delete the name and number by pressing

Yes

. Touch No to cancel.

•More

: allows you to

–

Print via Bluetooth:

sends the contents of the selected contact to a Bluetooth enabled printer.

–

Send namecard via

: allows you to select one or more contacts in which to send your namecard.

–

Copy to SIM

: allows you to copy contacts from the Phone to the SIM card.

•Back

: displays the previous screen.

Page 78

Making a Call from Contacts

Once you have stored phone numbers in the Contacts list, you can dial them easily and quickly by using the location numbers that were assigned to them.

Note:

If you cannot remember a location number, you must search the Phonebook to find an entry by name. For more information, refer to “Finding a Contact Entry” on page 74.

Delete

Important!:

Once contact entries are deleted, they cannot be recovered.

This option allows you to delete your contacts. For more information, refer to “Deleting all of the Contacts Entries” on page 76.

Adding a New Caller Group

1. From the Home screen, touch

Contacts

2. From the pull-down list select

Groups

3. Touch

Create group

4. Enter a name for the new group in the

Group name

field.

5. Touch the

Group picture

field and touch

Take photo

Caller image

6. If you selected

Take photo

in step 5, see “Take and Send Photos” on page 139.

– or –

If you selected

Caller image

in step 5, touch

Photos

, touch a photo in the list to represent this group, and touch

Add

7. Touch the

Group ringtone

field and select a sound from the

Sounds

folder.

8. Touch the

Group vibration

field, touch

Vibration 1-5

then touch

Save

9. Touch

Save

when you are finished. Your Caller group settings save.

10. Choose

Yes

if you want to add members to this group.

Page 79

Understanding Your Contacts List 76

11.

Select the contact(s) for this new group.

12. Touch

Add

. You have Added members to the New Caller Group.

Editing a Caller Group

1. From the Home screen, touch

Contacts

2. From the pull-down list select

Groups

3. Touch the group you want. When the group displays, touch

➔

Edit

4. Touch the field to edit, enter or select the new information and touch

Save

when you are finished.

Dialing a Number from the SIM Card

1. Touch

Dialer

2. Enter the location number for the phone number you want to dial and press .

The entry associated with the location number displays.

3. If you do not know the location number, touch a location number (for example, the number 2), then

touch .

The number assigned to this location displays.

4. Touch the phone icon (to the right of the number) to dial this number.

Deleting all of the Contacts Entries

You can delete all your entries from your phone’s memory, your SIM card, FDN, or All.

Important!:

Once Phonebook entries are deleted, they cannot be recovered.

1. From the Home screen, touch

Contacts

2. Touch Delete.

3. Touch Select all or touch the check box beside each entry you want to delete and touch Delete. The

selected entry or all of the Phonebook entries are deleted.

Page 80

Speed Dialing

Once you have stored phone numbers to Contacts, you can set up to 17 speed dial entries and then dial them easily whenever you want, simply by pressing the associated numeric key. In phone mode, to speed dial the numbers assigned to keys (2 to 18), touch and hold the appropriate key.

Setting Up Speed Dial Entries

1. From the Home screen, touch

Contacts

. Your contact list displays.

2. From the pull-down list select

Speed dial

3. Touch the keypad number key to where you want to assign the new speed-dialing number (keys 2

through 18). The contact list displays.

4. Touch a contact entry or search for a contact entry. The selected contact is now assigned to the number key

you pressed.

Note:

Memory location 1 is reserved for your Voice mail server number and this speed dial location can not be changed. The voice server number can be altered by editing the Voice mail number in the Contacts.

My Profile

My Profile allows you to create a virtual business card. Once completed, you can send the card to recipients as a V-card

attachment.

Note:

As with any profile, your profile can be associated with a group.

To create a profile:

1. From the Home screen, touch

Contacts

. Your contact list displays.

2. Touch

My profile

3. Touch

Edit

4. Touch the

My profile

field and enter a first name for this profile.

5. Touch the

Last name

field and enter a last name for this profile.

6. Touch one of the Phone number types (Mobile, Home, or other type) and enter the information into the field.

Page 81

Understanding Your Contacts List 78

Continue to enter the rest of the information into the appropriate fields.

8. Touch

Save

to confirm your information.

Contacts Management

From the Contacts settings menu you can view and save contact information to or from the phone, determine the order of the display name, view a list of your own numbers, or configure One hand operation.

䊳

From the Home screen, touch

Contacts ➔ More

Copy contacts

This option allows you to copy all contacts from your SIM memory to your Phone memory or from your Phone back onto your SIM card. For more information, refer to “Storing a Number on the SIM Card” on page 73.

1. From the Home screen, touch

Contacts

➔ More.

2. Touch

Copy contacts

3. Touch

Phone to SIM

SIM to phone

4. Touch the

Select all

check box or touch the check box next to each contact you want to copy and touch

Copy

If you select

Phone to SIM

, you can see the

Some info might be lost Continue?

prompt.

5. Touch

Yes

to continue, or No to cancel the copy.

The selected contact(s) is copied from Phone memory to SIM memory or from the SIM memory to the Phone

memory.

Page 82

Move contacts

The Move option allows you to move all contacts from your SIM card to your Phone or from your Phone back onto your SIM card.

1. From the Home screen, touch

Contacts

➔ More.

2. Touch

Move contacts

3. Touch

Phone to SIM

SIM to phone

4. Touch the

Select all

check box or touch the check box next to each contact you want to move and touch

Move

If you select

Phone to SIM

, you can see the

Some info might be lost Continue?

prompt.

5. Select

Yes

to continue, or No to cancel the move.

The selected contact(s) is moved from Phone memory to SIM memory or from the SIM memory to the Phone memory.

Send name card via Bluetooth

The Send name card via BT (Bluetooth) option allows you to send your name card to a Bluetooth enabled device.

1. Create a name card (My Profile). For more information, refer to “My Profile” on page 77.

2. From the Home screen, touch

Contacts

➔ More.

3. Touch

Send namecard via BT

4. Touch the checkbox to the right of the namecard you want to send to a Bluetooth enabled device.

Important!:

Bluetooth must be turned on (enabled) in order to send a namecard to a Bluetooth enabled device.

5. Touch the Bluetooth device to which you want to send the namecard.

The namecard automatically sends to the selected device.

Page 83

Understanding Your Contacts List 80

Mobile backup

T-Mobile backs up your Contacts list the first time you turn on your phone and each time you make a change to the address book.

Important!:

To manage your contacts and options regarding Mobile Backup, go to my.t-mobile.com. See your Terms & Conditions for further details.

1. From the Home screen, touch

Contacts

➔ More.

2. Touch

Mobile backup

3. Touch one of the following options:

•Last sync

: displays information about the last Mobile backup synchronization you performed.

–

Sync

: Touch to begin synchronizing your address book with Mobile Backup.

–

Detail

: Touch to see details including Sync date, Sync time, Sync result, and Number of items synced.

–

Back

: Displays the previous screen.

• About mobile backup

: displays help information about the Mobile Backup feature.

FDN contacts

FDN (Fixed Dial Number) mode, if supported by your SIM card, allows you to restrict your outgoing calls to a limited set of phone numbers.

The FDN List allows you to set up a list of numbers your phone may dial.

Use Security settings to enable FDN mode. For more information on changing this setting, see “Fixed Dialing Mode” on page 176.

To enable FDN mode, a PIN2 number is required. You can obtain your PIN2 from T-Mobile customer service.

Note:

FDN mode must first be enabled in the Security settings. For more information on changing this setting, see “Fixed Dialing Mode” on page 176.

To create an FDN contact list:

1. From the Home screen, touch

Contacts

2. Touch

➔

FDN contacts

Page 84

Touch

Create FDN

4. Enter your

PIN2 code

obtained from T-Mobile and touch

Confirm

Contact settings

The Phonebook settings menus allow you to choose where your contacts are saved. Available options are:

View and Save to

From this menu you can decide how you want to view or save contacts.

View contacts from

This option allows you to view all the contacts stored on the Phone, SIM, or All.

1. From the Home screen, press then touch

Contacts

➔

Contact settings

➔

View and Save to

2. Touch the

View contacts from

drop-down.

The following options are available:

•All

: allows you to view all contacts stored to the Phone’s memory and the SIM memory when you view the phonebook

• Phone

: allows you to view contacts stored to the Phone’s memory.

•SIM

: allows you to view contacts stored to the SIM memory.

Save new contacts to

The

Save new contacts to

option allows you to choose where your contacts are saved.

1. From the Home screen, press then touch

Contacts

➔

Contact settings

➔

View and Save to

2. Touch the

Save new contacts to

drop-down.

The following options are available:

• Phone

: new phonebook contacts are saved to your phone. Your phone comes with the default set to Phone memory.

•SIM

: new phonebook contacts are saved to your SIM card.

Page 85

Understanding Your Contacts List 82

Order of display name

This menu allows you to select the order of the display name. Selections are: First name Last name, or Last name First name.

1. From the Home screen, press then touch

Contacts

➔

Contact settings

➔

Order of display

name

2. Touch the radio button of the order you prefer and touch

Save

Own numbers

1. From the Home screen, press then touch

Contacts

➔

Contact settings

➔

Own numbers

2. Touch

Create

to create a new number and enter the Name and Number.

– or –

Touch

Remove

, touch the check box next to the number you want to remove, or touch

Select all

, then touch

Remove

One hand operation

The one-hand operation option is set to right-handed by default. You can set the power search tab to be either right-hand or left-hand “user friendly.”

1. From the Home screen, press then touch

Contacts

➔

Contact settings

➔

One hand

operation

Page 86

Touch

Right handed

Left handed

and touch

Save

Memory Status

You can check how many names and numbers are stored in the Phonebook, within the SIM card, Phone memory, and the FDN list. You can also see the current storage capacity of all three memories.

1. From the Home screen, press then touch

Contacts

➔

Memory status

The Phone, SIM and FDN status displays.

right-hand option

Screen with left-hand option

Screen with

Page 87

Messaging Applications 84

Section 8: Messaging Applications

This section describes how to send or receive different types of messages. It also explains the features and functionality associated with messaging.

Types of Messages

Your phone provides the following message types:

•

Audio postcard

•

Text Messages

•

Picture Messages

•

Voicemail

•

Exchange email

•

Instant Messaging

Message Icons on the Icon Line

Icons displayed at the top of the screen indicate new messages were received. For more information, refer to “Icons” on page 20.

Page 88

New Messages Tab

The New Messages Tab is an area that displays on the screen when a missed call, new message, or voicemail is sent to the phone.

There are three New Messages tabs that display icons are New message, Missed calls, and Voice mail message. You can search through missed calls or unviewed messages and select the associated message tab, and then touch the

View

Exit Selection

Creating an Audio Postcard

In this menu you can select a frame, take a picture and then record a voice message up to one minute long and send it as an Audio Postcard.

1. From the Home screen, press then press Audio postcard. The screen displays a default postcard

Landscape

mode.

2. Touch the Left or Right key to display more postcard frames.

– or –

Touch the

Choose Frame

icon to choose one of the 16 available frames.

3. To configure the camera for this Audio postcard touch

Setup

then touch the

Settings

➔

Camera

tab.

Page 89

Messaging Applications 86

Select one of the following options:

• White balance

: allows you to set this option from the following choices: Auto, Daylight, Incandescent, Fluorescent, or Cloudy.

• Effects

: allows you to change the color tone or apply special effects to the photo. Options include: None, Black and white,

Sepia, Negative, or Watercolor.

•Exposure meter

: allows you to set how the camera measures or meters the light source: Matrix, Centre-weighted or Spot.

• Image quality

: allows you to set the image quality to: Superfine, Fine, or Normal.

• Night mode

: allows you to set the camera options to capture night scenes.

5. To configure the settings touch

Setup

then touch the

Settings

➔

Settings

tab.

•Review

: allows you to set review preferences to on, off, or 5 seconds.

• GPS connection

: allows you to activate (turn On) or deactivate (turn Off) the GPS tracking feature.

• Shutter sound

: allows you to set the shutter sound: Shutter 1, Shutter 2, Shutter 3, or Off.

•Storage

: allows you to select phone or card storage.

6. Touch

Timer

to set a time delay before the camera takes the photo. Select the length of delay you want and

touch

Off, 2, 5

, or 10 seconds. When you touch the

Camera

key, the camera takes the photo after the

specified time elapses.

7. Touch

Brightness

to increase or decrease the brightness levels.

8. Adjust the image by aiming the camera at the subject.

9. Press the

Camera

key to take a picture.

10. Touch

Record voice

to add a voice message to the postcard.

11. Touch

Send to

when you are finished recording your message and select one of the following options:

• Recent recipients

: allows you to select a number or an address from the last 20 destinations you entered.

•Contacts

: allows you to enter the phone number you want from your Contacts list.

• Online albums

: displays a list of online albums to which you can save this Audio Postcard.

•New email

: allows you to enter a new email address in which to send this Audio Postcard.

• New number

: allows you to enter a new phone number in which to send this Audio Postcard.

Page 90

Text Messages

Short Message Service (SMS) allows you to send and receive short text messages to and from other mobile phones.

The Message icon ( ) displays when you receive a new text message. When the memory is full, the message icon flashes on your phone and you cannot receive any new messages. You must delete a message before you can receive additional messages.

䊳

Use the

Delete

option in each message box to erase obsolete messages.

Creating a Text message

In this menu, you can write and send a text message.

1. From the Home screen, touch

Messages

➔

Create message

➔

Message

2. Tap the screen to display the keyboard and create your message.

3. Touch

Back

when you finished entering your message.

Tip:

Sliding the QWERTY keyboard open displays the

QWERTY keyboard

. Holding the phone in the vertical position displays the

numeric

keypad

Page 91

Messaging Applications 88

Note:

For further details about entering characters, see “Using T9 Mode” on page 69. For more information about entering characters, see “Using ABC Mode” on page 70. You can enter up to 2000 standard Alphabet characters per page in your message. The message can be up to 20 pages long or a total of 2000 characters per page.

Important!:

If you add a page or another item to the message, the message type automatically changes to a Picture message.

4. Touch

Other

and select from the following:

•

Text template

: allows you to select a Text Template to attach to this message.

•

Insert from contacts

: allows you to select a contact profile from Contacts.

• Bookmarks

: allows you to select a URL to attach to this message.

5. Touch

Send to

6. Select one of the following from the

Send to

menu and touch

Add

when you are finished.

• Recent recipients

: allows you to select a number or an address from the last 10 destinations you entered.

•Contacts

: allows you to enter the phone number you want from your Contacts.

Create New MessageCreate New Message

Landscape (QWERTY) Keyboard Portrait Keypad

Page 92

• New number

: allows you to enter a phone number not already listed in the Contacts.

7. Touch the

field repeat step 3 to add additional recipients to this message.

– or –

Touch

and select

Add recipients

8. Touch

Send

when you are finished entering the destinations.

Picture Messages

This menu allows you to use the Multimedia Message Service (MMS).

Picture messaging is a messaging service that provides delivery of personal multimedia messages from phone to phone or from phone to email.

In addition to the familiar text content available via traditional text messages, multimedia messages can contain images, graphics, voice, and audio clips. A Picture Messaging message is a picture presentation contained in a single file. It is not a text file with attachments.

The Message icon ( ) displays when you receive a new picture message.

Using the Picture Message feature, your phone can receive and send messages that contain multimedia files, such as photos, sounds and images that you downloaded from the Internet and voice notes you recorded. This function is available only if it is supported by T-Mobile. Only phones that offer multimedia messaging features can receive and display picture messages.

Creating and Sending a Picture Message

1. From the Home screen, touch

Messages

➔

Create message

➔

Message

2. Tap the screen to display the keyboard and create your message.

Tip:

Sliding the QWERTY keyboard open displays the

QWERTY keyboard

. Holding the phone in the vertical position displays the

numeric

keypad

Note:

3. Touch

Back

when you finished entering your message.

Page 93

Messaging Applications 90

Touch


to add a picture to this message and select from the following, then touch

Add

• Take photo

: launches the camera and allows you to take a photo to attach to this message.

• Add from photos

: allows you to select a picture from the Photos album to attach to this message.

5. Touch

Sound

to add a sound to this message and select from the following, and then touch

Add

• Record sound

: allows you to record a voice message to attach to this message.

• Add from sounds

: allows you to select a sound from the Sounds folder to attach to this message.

6. Touch

Video

to add a video clip to this message and select from the following, and then touch

Add

• Record video

: allows you to record a video clip (up to 1019kb) to attach to this message.

• Add from videos

: allows you to select a video to add from the Videos folder.

7. Touch

Other

and select from the following:

• Text template

: allows you to select a Text Template to attach to this message.

• Insert from Contacts

: allows you to select a contact profile from the Contacts.

• Bookmarks

: allows you to select a URL to attach to this message.

8. Touch

and select from the following:

•Preview

: allows you to preview the message prior to sending.

• Add page

: allows you to add a page to this picture message.

• Add subject

: allows you to add a subject to this picture message.

• Add attachment

: allows you to add a File, Name card, Event, Task, or Memo as an attachment.

• Edit style

: allows you to select a page, modify the Background color, Font color, Font style, or Page duration for this picture

message.

• Sending options

: allows you to configure the sending options such as, Priority, Expiration, Delivery time, Request delivery report, Request read report, or Keep a copy. If the selected message is a text message, these options include: Reply path and Delivery report.

• Select language

: allows you to set the language for this message. Choices are: English, Français, or Español.

9. Touch

Send to

Page 94

10.

Select one of the following from the

Send to

menu and touch

Add

when you are finished.

• Recent recipients

: allows you to select a number or an address from the last 20 destinations you entered.

•Contacts

: allows you to enter the phone number you want from your Contacts.

• Online albums

: displays a list of online albums to which you can save this message.

• New email

: allows you to enter a new email address in which to send this message.

• New number

: allows you to enter a phone number not already listed in the Contacts.

The number or address you selected enters in the To field.

11. Touch

Send

Message inbox

The Message inbox stores received messages. You can tell what kind of message was received by the icon displayed. If the icon envelope is open then the message was read, otherwise a closed envelope displays.

The following types of messages may display in your inbox:

•

Text messages

•

Picture messages

•

Audio Postcard

When you enter the Message inbox, the list of messages displays with the sender’s phone numbers, or names, if available in your Contacts. After you read the message, the open envelope icon displays. If the Inbox is full when a new text message is received, or the SIM card is full, the text message saves to the phone and the Text message (saved to Phone) icon displays.

䊳

From the Home screen, touch

Messages

➔

Message inbox

Viewing a Text Message from the Inbox

1. From the Home screen, touch

Messages

➔

Message inbox

2. Select a text message from the list to view the message.

3. Press

to select from the following:

•Forward

: allows you to forward the text message to another person.

•

Save in Contacts

: allows you to Add New, or Update the contact information.

• Move to Phone/SIM

: moves the selected text message to either the Phone memory or the SIM card.

Page 95

Messaging Applications 92

• Move to folders

: moves the selected message to another folder.

•

Save as template

: saves the message as a text template.

•Save to

: saves the text message as an Event or as a Memo.

• Print via Bluetooth

: sends the selected text message to a Bluetooth enabled printer.

•Lock/Unlock

: Allows you to lock the message to protect it from deletion, or unlock the message to allow deletion.

Viewing a Picture Message from the Inbox

1. From the Home screen, touch

Messaging

➔

Message inbox

2. Select a picture message from the list to view the message.

3. Touch

to select from the following:

•Forward

: allows you to forward the text message to another person.

• Save in contacts

: allows you to save the number to Contacts.

• Move to phone

: moves this message to the phone’s memory (if it is not already stored to the Contact list or is stored on the

memory card).

• Move to folders

: moves the selected message to another folder.

• Save as template

: saves this message as a picture message template.

•Save to

: saves this message to an Event or Memo.

• Print via Bluetooth

: sends the selected message to a Bluetooth enabled printer.

•Properties

: displays the properties for the attached media.

•Lock/Unlock

: Allows you to lock the message to protect it from deletion, or unlock the message to allow deletion.

Viewing a Received Picture Message

When a new picture message comes in, the Messages tab displays the missed Picture Messaging Message icon.

1. From the Messages tab, press the

View

key to view the picture message.

Note:

The message displays as a missed Picture message.

2. Press the

Exit

soft key if you want to view the message later in the Message inbox.

3. Press to return to Idle mode.

Page 96

Listening to a Voice Note from the Inbox

1. From the Home screen, touch

Messages

➔

Message inbox

2. Select a voice note from the list.

3. Touch

Stop

to stop listening to the voice note.

4. After listening to a Voice Note, you may choose the following options:

• Reply to

: allows you to compose and send a reply to the sender by sending a message.

• Delete

: allows you to delete the selected message.

•More

–

Forward

: allows you to forward the message to another number.

–

Move to Folders

: moves the selected message to a personal folder. At the create folder prompt, touch OK. Enter a name for the new

folder and touch

Done

. Or, if a folder already exists, touch

Move

– Save in Contacts

stores the number in your Phone memory, or updates the information if the number is already saved.

– Save as template

: allows you to save the voice note as a template.

–

Print via Bluetooth

: sends the selected message to a Bluetooth enabled printer.

–

Save attachment

: saves the attached voice note to the Phone’s memory or to the Memory card.

–

Properties

: displays the properties for the attached media such as: Subject, Date, From, To, Size, Priority, Delivery report, and Read report.

–

Lock/Unlock

: locks the message to protect it from deletion, or unlocks it to allow deletion.

•Back

: displays the previous menu.

Viewing a Push Message in the Inbox

A Push Message is a method for your service provider to deliver content (such as, images, ringtones, software upgrades, information, and so on) to mobile phones that are WAP enabled. You cannot initiate or reply to WAP Push Messages. The WAP Push Message may direct you to go to a URL that is included in the message for further information and/or updates, or it may be information only.

1. From the Home screen, touch

Messages

➔

Message inbox

2. Touch a Push message in the list to view the message.

Page 97

Messaging Applications 94

After viewing a Push message, you may choose the following options:

•Reply

: allows you to send a reply to the sender by sending a message.

•Delete

: allows you to delete the selected push message.

•More

–

Forward

: allows you to forward the message to another number.

– Save in Contacts

stores the number in your Phone memory, or updates the information if the number is already saved.

– Save as template

: allows you to save the push message text as a template.

– Print via Bluetooth

: sends the message to a Bluetooth enabled printer.

Sorting Message Inbox Messages

Your Inbox messages can be sorted by Date, Sender, Type, Subject, Size, and Lock/Unlock.

To sort the Inbox:

1. From the Home screen, touch

Messages

➔

Message inbox

2. Touch

Sort by

and select a method by which you want to view the messages (Date, Sender, Type, Subject,

Size, Lock/Unlock).

Moving Messages from the Inbox

You can move messages from the Inbox to another folder or location.

To move messages:

1. From the Home screen, touch

Messages

➔

Message inbox

➔

Move

3. Touch the check box next to each message you want to move to another folder or location.

4. Touch

Move to folders

Social Buzz

When you first open this application the Status screen displays. After login to your social networking applications (Twitter, Facebook, or MySpace), status updates display automatically in the top box for any of your friends for each of these applications. Your Facebook status displays your status automatically as you post. You can view a stream of updates from friends, as well as your inbox or wall.

Page 98

Important!:

Charges may apply when using social network applications.

1. From Idle mode, press

Messages

➔

Social Buzz

2. Press

Continue

when the

Data Charges

screen displays.

Note:

The screen defaults to an Update and My Facebook Status screen.

3. Press the

Down

Navigation key to Sign in to some of the social networking services.

4. Press the

Down

Navigation key again to view

My Facebook

status and sign in.

The social network applications display at the top of the screen.

5. Press the

Left

Right

Navigation key until the desired social networking icon displays, then login to the

application.

6. Press

once you are signed in to refresh the screen, change settings, minimize the screen, exit, or view

help.

7. Press to exit the application.

8. Press

Yes

when “

Do you want to exit?

” displays to exit this application.

Voicemail

This menu helps you access your voice mailbox, if provided by your network. You can also setup Visual Voicemail from this menu.

1. From the Home screen, touch

Messages

➔

Voicemail

– or –

2. Touch and hold to connect to voice mail.

Important!:

Voice mail is a network feature and charges may apply. Please contact T-Mobile’s customer service for further details.

3. At the prompt, touch

Yes

if you want to activate Visual Voicemail (VVM), or No to reject VVM. The following

options display:

Page 99

Messaging Applications 96

•Delete

: deletes the selected or multiple voicemail messages.

•Sort by

: allows you to sort the drafts folder by Recipient, Type, Subject, or Size.

•More

–

Voicemail settings

: allows you to edit the name or center address for voicemail.

–

Call voicemail

: dials the voice mailbox.

–

Sync now

: synchronizes with the voicemail inbox and displays recent voicemail messages.

•Back

: displays the previous screen.

When you select

Yes

to activate Visual Voicemail, the Visual Voicemail web page displays.

Important!: Before using the Voice Mail feature, you must enter the voice server number obtained from T-Mobile customer service in

the Voice server number field.

• Voicemail settings

: allows you to record a greeting, change your PIN, or activate the voicemail feature.

• Call voicemail

: dials the voice mailbox.

•Sync now

: need a description for this option.

4. Follow the voice mail prompts.

Setting up Visual Voicemail

Important!: Before using the Voice Mail feature, you must enter the voice server number obtained from T-Mobile customer service in

the Voice server number field.

1. From the Home screen, touch

Messages

➔

Voicemail

2. At the prompt, touch

Yes

to activate Visual Voicemail.

3. Touch

Yes

at the prompt to launch the browser and activate this feature.

Page 100

Email Messages

Email enables you to review and create e-mail using AIM®, AOL®, Yahoo!® Mail, Comcast, Compuserve, Earthlink, Gmail, HotPOP, Juno, Mac, NetZero, SBC Yahoo!, Verizon and several other email services. You can also receive text message alerts when you receive an important e-mail.

Important!:

When you create an email account, the default setting for SSL options may be different, depending on the service provider. If you experience any issues with your email account and cannot access or use it, confirm whether your service provider supports an SSL connection (Secure Socket Layer).

Creating an Email message

1. From the Home screen, touch

Messages

➔

Create message

➔

2. Touch

Yes

at the prompt if you have not configured an email account to set one up.

3. Follow the prompts to configure the account.

– or –

4. Tap the field to add a recipient if an account is already configured.

5. Touch

Send

Managing email accounts

This menu allows you to manage your email account information. From this menu you can create, edit, or delete email accounts.

䊳

From the Home screen, touch

Messages

➔

Messaging settings

➔

Manage accounts

Editing Email account information

1. From the Home screen, touch

Messages

➔

Messaging settings

➔

Manage accounts

2. Touch an account name in the list.

3. Touch one or more of the fields to edit the account information, then touch

Save
