Samsung GH68-28507A User Manual
http://www.samsung.com/ca
Printed in China
Imprimé en Chine
Code No.: GH68-28507A
CA. 04/2010. Rev. 1.0
English ...................................................................................1
Français ...............................................................................21
Contents
Getting started
Your headset overview ......................................................................... 3
Button functions .................................................................................... 4
Charging the headset ........................................................................... 4
Wearing the headset ............................................................................8
Using your headset
Turning the headset on or off................................................................9
Pairing and connecting the headset ................................................... 10
Using call functions............................................................................. 12
Appendix
Frequently asked questions................................................................ 14
Certication and Safety approvals ...................................................... 16
UL certied travel adapter ..................................................................17
Warranty and parts replacement ........................................................ 18
Specications .....................................................................................19
1
English
English
Take the time to read through this user manual before using WEP570 Bluetooth
Headset.
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc. worldwide—
Bluetooth QD ID: B015914
More information about Bluetooth is available at www.bluetooth.com.
Safety precautions
Never disassemble or modify your headset for any reason. Doing this may
•
cause the headset to malfunction or become combustible. Bring the headset to
an authorized service center to repair it.
When using your headset while driving, follow local regulations in the country or
•
region you are in.
Avoid storage at high temperatures (above 50 °C/122 °F), such as in a hot
•
vehicle or in direct sunlight, as this can damage performance and reduce
battery life.
Do not expose the headset or any of its supplied parts to rain or other liquids.
•
At very high volumes, prolonged listening to the headset can damage your hearing.
2
Getting started
This section explains the proper use of your Bluetooth headset.
Your headset overview
Volume button
Talk button
English
Charger jack
Ear hook
Earpiece
Power switch
Indicator light
Make sure you have the following items with your headset:
Travel adapter, Car cradle, User manual, Earpiece cover, Ear hook.
The items supplied with your headset may vary depending on your region.
Charging contact
Microphone
3
Button functions
Button Function
Power Slide the switch to turn the headset on or off.
Press to make or answer a call.
Talk
Volume
•
Press to end a call.
•
Press and hold to enter Pairing mode.
•
Press to adjust the volume.
•
During a call, press and hold to mute the microphone.
•
Charging the headset
This headset has a rechargeable internal battery which is non-removable. Ensure
that you fully charge the battery before using the headset for the rst time.
4
The battery will gradually wear out while charging or discharging because it is a
•
consumable part.
•
The headset is not able to operate while charging. Try connecting after charging is
completed.
•
When charging the headset in very hot temperatures, the red indicator light ashes
and charging will stop. This is a normal event to protect the headset from damage.
Unplug the travel adapter from the headset. You can charge the headset normally
below 50°C/122°F (±5°C/9°F)
Charging the headset using the travel adapter
1 Plug the small end of the travel adapter into the charger jack.
English
5
2 Plug the large end of the travel adapter into a power outlet.
During charging, the indicator light will turn red. If charging does not begin,
unplug the travel adapter and plug it in again.
3 When the headset is fully charged, the indicator light changes to blue. Unplug
the travel adapter from the power outlet and the headset.
Use only a Samsung-approved travel adapter. Unauthorized travel adapters may
cause an explosion or damage to the headset.
Charging the headset using the car cradle
1 Plug the headset into the car cradle.
Make sure the direction of the headset is as shown in the gure when plugging
the headset into the cradle. If inserted in the incorrect direction, your headset
will not be charged and may be damaged.
To the car cigarette
lighter socket
6
2 Plug the car cradle’s cigar jack into your car’s cigarette lighter socket.
During charging, the indicator light will turn red. If charging does not begin,
unplug the car cradle and the headset and plug them in again.
3 When the headset is fully charged, the indicator light changes to blue. Unplug the
car cradle from the lighter socket and unplug the headset from the car cradle.
You can also charge other devices using the car cradle. Connect the device to the
•
USB port on the car cradle with a USB cable.
If you connect a device that does not comply with the USB standard, charging may
•
not work properly.
Checking the battery level
At the same time, press and hold the Volume down button and the Talk button.
Depending on the battery level, the indicator light ashes 5 times in one of the
following colors:
Battery level Indicator light color
Above 80% Blue
80 ~ 20% Violet
Below 20% Red
English
7
When the battery power is low
The headset beeps and the indicator light ashes red. Recharge the battery. If the
headset powers off during a call, the call will be automatically transferred to the
phone.
Wearing the headset
Place the headset on your ear.
Depending on what ear you are going to wear the headset, simply adjust the ear
hook accordingly.
Left
Right
8
Using your headset
This section explains how to turn the headset on, pair and connect to the phone,
and use various functions.
Activated functions and features may differ depending on the types of your phone.
•
Some devices, especially those that are not tested or approved by Bluetooth SIG,
•
may be incompatible with your headset.
Turning the headset on or off
Slide the power switch to turn the headset on. The blue indicator light
•
ashes 4 times.
Slide the power switch to turn the headset off. Both blue and red indicator
•
lights ash.
English
9
Pairing and connecting the headset
Pairing will create a unique and encrypted wireless link between two Bluetooth-
enabled devices, such as a Bluetooth phone and your Bluetooth headset.
To use the headset with other Bluetooth devices, the devices must be paired. When
trying to pair the two devices, keep the headset and the phone reasonably close
together. After pairing, you can connect the two devices.
Pairing and connecting the headset with a phone
1 Enter Pairing mode.
With the headset turned on, press and hold the Talk button until the indicator
•
light stays lit.
When you turn on the headset for the rst time, it automatically enters
•
Pairing mode.
2 Activate the Bluetooth feature on your phone and search for the headset (see
your phone’s user manual).
10
