SAMSUNG Evergreen User Manual

PORTABLE Quad-BAND

MOBILE PHONE

User Manual

Please read this manual before operating your

phone, and keep it for future reference.

Printed in Korea
GH68-31952A

Intellectual Property

All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or
software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions. Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade secrets, copyrights, software, computer programs,
and related documentation and other works of authorship. You may not infringe or otherwise violate the
rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to)
modify, prepare derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or ownership in the Intellectual Property is transferred to
you. All applicable rights of the Intellectual Property shall remain with SAMSUNG and its suppliers.

©2010 Samsung Electronics Canada, Inc.
SAMSUNG is a registered trademark of Samsung Electronics Co., Ltd. and its related entities.

T9 Text Input is licensed by Tegic Communications and is covered by U.S. Pat. 5,818,437; U.S. Pat.
5,953,541; U.S. Pat. 6,011,554 and other patents pending.

ACCESS® and NetFront™ are trademarks or registered trademarks of ACCESS Co., Ltd. in Japan and
other countries.

The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark
and “B Design”) are registered trademarks and are wholly owned by the Bluetooth SIG.

microSD™ and the microSD logo are Trademarks of the SD Card Association.

Some software components of this product incorporate source code covered under GNU General Public
License (GPL), GNU Lesser General Public License (LGPL), OpenSSL License, BSD License and other
open source licenses. To obtain the source code covered under the open source licenses, please visit:
http://opensource.samsung.com.

The privacy and copyright laws of Canada govern the disclosure, reproduction and distribution of data,
media and other content, including music and video content. Certain activities, including downloads or
transfer by any means (including, via cable, Bluetooth® or otherwise) of such content may be an
infringement of privacy or copyright law. Neither Samsung Electronics Canada Inc. nor any of its affiliates

shall be liable or responsible for any data or content disclosed, reproduced, downloaded or distributed by
the user of this equipment.

Dynamic Noise Suppression from Audience™

Your phone is equipped with an advanced voice processing chip that delivers clear mobile calls by
suppressing background noise, intermittent sounds (like a siren or nearby conversation), and echoes,
allowing you to hear and be heard nearly anywhere.

How Does It Work?

Based on the intelligence of the human hearing system, the technology:

•

Captures, evaluates and distinguishes all the sound signals surrounding your phone, and the person you're speaking

with.

•

Then isolates the primary voice in conversation and filters out the background noise - so the person you're calling

hears only your voice, without disturbing background noise.

•

Dynamically equalizes and adjusts voice volume to optimize your calling experience, so you can hear clearly and don't

need to speak louder to overcome surrounding noise.

The noise suppression technology is built-in and already enabled in your new mobile phone. So it's ready to
provide unsurpassed voice clarity with every call.

Disclaimer of Warranties; Exclusion of Liability

EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE
ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG
MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF
THE PRODUCT; THE PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT
OR THE COMPONENTS CONTAINED THEREIN; OR COMPLIANCE OF THE PRODUCT WITH THE
REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING THERETO.
NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN
EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE
PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND
RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH
OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL
DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS.

Table of Contents

Section 1: Getting Started ............................. 1

Setting Up Your Phone ...........................................1

Charging a Battery ..................................................5

Switching the Phone On or Off ...............................6

Locking and Unlocking the Screen ......................... 7

Setting Up Your Voice Mail .....................................7

Section 2: Understanding Your Phone ........8

Features of Your Phone .........................................8

Front Closed View (Portrait Mode) .........................8

Front Open View (Landscape Mode) ....................10

Side Views of Your Phone .................................... 12

Rear View of Your Phone .....................................13

Display Layout ......................................................13

Menu Navigation ...................................................16

Multitask Functions ...............................................17

Section 3: Entering Text .............................. 19

Using the QWERTY Keypad ................................19

Changing the Text Input Mode .............................21

Section 4: Call Functions .............................25

Displaying Your Phone Number ...........................25

Making a Call ........................................................25

Making a Call Using Speed Dial ...........................27

Making a Call from Contacts .................................27

Answering a Call ...................................................27

Options During a Call ............................................28

Recent Calls .........................................................31

Call Time ...............................................................34

Data Counter ........................................................34

Section 5: Messaging ...................................37

Types of Messages ...............................................37

Creating and Sending Messages ..........................37

Viewing New Received Messages ........................39

Using Message Options ........................................40

Outbox ..................................................................41

Drafts ....................................................................41

Voicemail ..............................................................41

i

Deleting Messages ...............................................41

Messaging Settings ...............................................42

Templates .............................................................45

Delete by Folder ....................................................46

Used Space ..........................................................46

Section 6: Calendar ..................................... 47

Section 7: Browser ...................................... 50

Home ....................................................................50

Enter URL .............................................................52

Bookmarks ............................................................52

Saved pages .........................................................53

History ...................................................................53

Browser Settings ...................................................54

Section 8: Alarms ......................................... 55

Section 9: Camera ........................................ 57

Using the Camera .................................................57

Camera Options ....................................................58

Using the Camcorder ............................................62

Camcorder Options ...............................................63

ii

Section 10: Photos ....................................... 67

Section 11: Videos ........................................ 70

Get New Videos ................................................... 71

Record Video ........................................................ 71

Section 12: Tools .......................................... 72

Camera ................................................................. 72

Music Player ......................................................... 72

Using Playlists ...................................................... 75

Voice Recognition ................................................77

Record Audio ........................................................ 79

Alarms .................................................................. 80

Calendar ............................................................... 80

Recent Calls ......................................................... 81

Eco Walk ..............................................................81

Tasks .................................................................... 82

Memo ................................................................... 82

Calculator ............................................................. 83

Tip Calculator .......................................................83

Eco Calculator ...................................................... 84

Converter .............................................................. 84

World Clock ..........................................................85

Timer ....................................................................86

Stopwatch .............................................................86

<Service Provider> Menu .....................................86

Section 13: My Stuff ..................................... 87

Photos ..................................................................87

Music ....................................................................87

Images ..................................................................88

Sounds .................................................................90

Videos ...................................................................93

Games and Apps ................................................. 93

Other Files ...........................................................94

Section 14: Contacts .................................... 96

Contact Settings ...................................................96

Adding a New Contact ..........................................97

Using Contacts ...................................................100

Contacts Entry Options .......................................101

Finding My Own Phone Number ........................ 101

FDN Mode ..........................................................101

Group Settings ....................................................103

Adding Speed Dial Entries ..................................104

Using the Service Dialing Numbers ....................105

Managing Contact Entries ..................................105

Section 15: Changing Your Settings .........108

Sound Profile ......................................................108

Display ................................................................111

Time and Date ....................................................113

Phone Settings ...................................................114

Call Settings ........................................................121

Connectivity ........................................................122

Network Selection ...............................................126

Configuring Your Phone’s USB Settings ............126

Network Profile Configuration .............................127

Applications Settings ..........................................129

Memory Management .........................................131

Section 16: Health and Safety Information .....

134

Safety Warnings .................................................134

Safety Precautions ..............................................136

Warranty Disclaimer: Proper use of a touch screen

handset ...........................................................138

UL Certified Travel Adapter ................................138

iii

Important usage information ...............................139

Radio frequency safety .......................................141

Section 17: Warranty Information ............. 143

Standard Limited Warranty .................................143

Index ............................................................. 149

iv

Section 1: Getting Started

This section explains how to start using your phone
by first configuring your hardware, activating your
service, and then setting up your voice mail.

Setting Up Your Phone

Prior to use it is necessary to install both the battery
and SIM into their corresponding internal
compartments. The microSD™ card slot is also
located in this same internal area.

1.

Remove the battery cover by placing your
thumbnail into the slot at the bottom of the
phone (1). If you have fragile nails, use a
pointed object.

2.

Lift the cover up and off the phone (2).

Getting Started 1

Installing the SIM Card

When you subscribe to a cellular network, you are
provided with a plug-in SIM card loaded with your
subscription details, such as your PIN, available
optional services, and many others features.

Important!:

The plug-in SIM card information and its contacts

can be easily damaged by scratching or
bending, so be careful when handling, inserting,
or removing the card. Keep all SIM cards out of
reach of small children.

• Carefully slide the SIM card into the SIM

card socket until the card locks into place.

•

Make sure the card’s gold contacts face into the
phone and that the upper-left angled corner of
the card is positioned as shown.

2

Note:

If the card is not inserted correctly, the phone does not
detect the SIM card. Re-orient the card back into the
slot.

Installing the Memory Card

Your phone also supports the use of a memory
card (microSD) for data storage of such things as
data, music, pictures, and video files. This type of
memory card is designed for use with this mobile
phone and other devices.

1.

Push the microSD card into the slot until it
clicks (as shown). Make sure the microSD’s
gold contact pins face downward and the
card is securely inserted.

Note:

Your device has been tested to support up to a 16GB
memory card.

Getting Started 3

Installing the Battery



1.

Insert the battery into the opening on the
back of the phone, making sure the
connectors align (1).

2.

Gently press down to secure the battery (2).

B8

3.

Replace the battery cover onto the back of
the phone in the direction shown by the
arrow (1).

4

4.

Press down along the bottom of the phone
until you hear a light click (2).

5.

Press down firmly along the edges to ensure
that the cover is flush with the phone (3).

Note:

Make sure the battery is properly installed before
switching on the phone.

Charging a Battery

Your phone is powered by a rechargeable Li-ion
battery. The Travel Adapter that is used to charge
the battery is included with your phone. Use only
Samsung-approved batteries and chargers.

Note:

Long backlight settings, searching for service, vibrate
mode, browser use, and other variables may reduce
the battery’s talk and standby times.

You can use the phone while the battery is
charging, but it will require additional charging time.

Note:

You must fully charge the battery before using your
phone for the first time. A discharged battery
recharges fully in approximately 4 hours.

Using the Travel Adapter

1.

With the battery installed, temporarily open the
plastic cover (lower right side of phone) and plug
in the wall charger’s connector into the jack.

Important!:

Verify that the handset battery is installed p rior to

connection. If the battery is not properly installed
and the wall charger is connected, the handset
may power off and on continuously, preventing
proper operation.

Note:

The wall charger’s connector attaches to the phone at
a slight angle.

Getting Started 5

2.

Plug the flat end of the Travel Adapter into
the Power/Accessory Interface connector
and the other end into a standard AC wall
outlet.

3.

When charging is finished, remove the flat
end from the interface connector jack on the
phone.

Note:

Failure to unplug the wall charger before you remove
the battery, can cause damage to the phone.

Low Battery Indicator

When the battery is weak and only a few minutes of
talk time remain, the battery icon ( ) blinks
and the device sounds a warning tone at regular
intervals. In this condition, your phone conserves
its remaining battery power by reducing the
backlight’s brightness and entering a dimming
mode. For a quick check of your battery level,
glance at the battery charge indicator located in the

6

upper-right corner of your device’s display. Five
bars ( ) indicate a full charge.

When the battery level becomes too low, the phone
automatically turns off.

Switching the Phone On or Off

1.

Press and hold or until the phone
switches on.

The phone launches the activation splash
screen and then proceeds to search for the
network. Once the network has been found,
you can make or receive calls.

Note:

The display language is preset to English at the
factory. To change the language, use the Language
menu. For more information, refer to “Changing Your
Settings” on page 108.

2.

Press and hold until the phone switches
off.

Locking and Unlocking the Screen

1.

To lock the phone screen, press and hold

.

2.

To unlock the phone screen when closed,
press the

Unlock

OK

soft key.

soft key and then press the

Setting Up Your Voice Mail

1.

In Idle mode, press and hold .

You may be prompted to enter a password.

2.

Follow the tutorial to create a password,
record a greeting, and record your name.

Note:

These steps may be different depending on
your network.

Accessing Your Voice Mail

1.

In Idle mode, press and hold .

2.

When connected, follow the voice prompts
from the voice mail center.

Accessing Your Voice Mail From Another
Phone

1.

Dial your wireless phone number.

2.

When you hear your voicemail greeting,
press the asterisk key (*).

3.

Enter your passcode using the QWERTY
keypad.

Getting Started 7

Section 2: Understanding Your Phone

7

3

2

1

4

5

8

9

6

10

11

14

13

12

This section outlines some key features of your
phone. It also displays the screen and the icons
that display when the phone is in use.

Features of Your Phone

Your phone is lightweight, easy-to-use and offers
many useful features. The following list outlines a
few of the features included in your phone.

•

User friendly, menu driven access to features and

options

•

Can user display and keypad in portrait or landscape

mode

•

Ready access to the Internet

•

Built-in Bluetooth technology

•

Improved conversational messaging format

•

microSD card compatibility for use in data storage and

access

8

Front Closed View (Portrait Mode)

1.

Earpiece: allows you to hear the caller.

2.

Display: shows the information needed to

operate your phone, such as the received
signal strength, phone battery level, time,
etc.

3. Left Soft key

: allows you to select actions or
menu items corresponding to the bottom left
line on the display screen.

4.

Talk/Send key: allows you to power on the

phone, make or answer a call, and access
Recent Calls. Press and hold to redial the
last phone number.

5.

Messaging key: opens the Conversations

screen so you can compose a text or
multimedia message or view your
messages.

6. Voicemail key

: allows you to press and hold

to automatically dial your voicemail.

7. Alphanumeric keypad

: Use these keys to
enter numbers, letters and some special
characters. Press and hold to enter
an International call prefix.

8. Microphone

: allows the other callers to hear

you when you are speaking to them.

9. Silent Profile key

: press and hold in Idle
mode to toggle between Silent sound profile
and Normal sound profile.

10.

Back key: allows you to return to the

previous menu. This key also allows you to
return to the previous page within the Web
browser. In Idle mode, press this key to
display the Calendar in Month view.

11.

Power/End key: ends a call. Press and hold

for three seconds to turn the phone on or off.
While in a menu, pressing this key once
cancels the current input and twice returns
the phone to Idle mode.

Understanding Your Phone 9

10

7

3

2

1

4

5

6

8

9

12. Right Soft key

: allows you to select actions or
menu items corresponding to the bottom
right line on the display screen.

13.

OK/Confirm key: when navigating through a

menu accepts the highlighted choice in the
menu. If you press once in Idle mode, Mobile
Web launches.

14.

Navigation keys: these keys allow you to

scroll through phone menu options and
provide shortcuts to phone functions from
standby mode.

•Up

: displays the Create message screen.

•Down

: displays Contacts.

•Left

: displays the My Stuff menu.

•Right

: displays the Inbox.

Front Open View (Landscape Mode)

By sliding open the phone in Landscape Mode, you
have full access to a QWERTY keypad.

1. Left Soft key

: allows you to select actions or

menu items corresponding to the bottom left
line on the display screen.

2. Function key:

allows you to enter numbers
and symbols corresponding with the
numbers or symbols on each key on the
keypad. Press once to add one number or
symbol. Press twice to add multiple numbers
or symbols.

3.

Messaging key: opens the Conversations

screen so you can compose a text or
multimedia message or view your
messages.

4. Numeric keys

: allows you to enter numbers

when you press the FN key first.

5.

Navigation keys: these keys allow you to

scroll through phone menu options and
provide shortcuts to phone functions from
standby mode.

6.

OK/Confirm key: when navigating through a

menu accepts the highlighted choice in the
menu. If you press once in Idle mode, Mobile
Web launches.

7. Right Soft key

: allows you to select actions or
menu items corresponding to the bottom
right line on the display screen.

8. Enter key

: allows you start a new line when

typing a message.

9.

Back key: allows you to return to the

previous menu. This key also allows you to
return to the previous page within the Web
browser. In Idle mode, press this key to
display the Calendar in Month view.

For more information on the keypad, see “Using the
QWERTY Keypad” on page 19.

Understanding Your Phone 11

Side Views of Your Phone

3

2

1

4

5

1. Volume keys

: allows you to adjust the ringer
volume while in standby mode or adjust the
voice volume during a call. When receiving
an incoming call, briefly press either volume
key to mute the ring tone. Press and hold
either volume key to reject a call and send it

12

directly to voicemail. Adjusts text size when
reading a message or using the browser.

2. Memory card port

: Your phone has an
external memory port for a microSD or
microSDHC card.

3. Camera key

: in Idle mode, press to launch
the camera. In camera mode, press to take a
picture.

4.

Multitasking key: opens the application

switch window which allows you to select
from a group of different applications without
having to exit from the currently active
application. These options include Call,
Messaging, Mobile Web, Music Player,
Games, and End all.

5. Headset/power adapter/data cable jack

: allows
you to plug in the travel adapter (power), PC
connection cable (data transfer), and
optional headset.

Rear View of Your Phone

1

2

Indicators

Main Display

Soft Key

Time and Date

Indicators

Display Layout

Your display screen provides a wealth of
information about the phone’s status and
options.The display has 3 main areas:

1. Camera lens

shoot videos.

2. Speaker

: allows you to hear music.

: is used to take pictures and

Understanding Your Phone 13

Indicator Icons

This list identifies the symbols you’ll see on your
phone’s display and Indicator area:

Displays your current signal strength.
The greater the number of bars, the
stronger the signal.

Indicates that the Airplane Mode is
active. You cannot send or receive
calls or access online information.

Displays when you are out of your
service area.

Displays when a call is in progress.

Displays your battery’s charge level.
The more bars you see, the more
power you have remaining.

14

Displays when your connection to an
EDGE network is active.

Displays when your phone is
communicating with the EDGE
network.

Displays when your connection to a 3G
network is active.

Displays when your phone is
communicating with the 3G network.

Displays when an internal microSD
memory card is detected.

Displays when the phone is connected
to a computer via USB cable
connection.
Displays within the Indicators area
when a new text message is received.

Displays within the Indicators area
when a new Multimedia message is
received.

Displays within the Indicators area
when a new voice mail is received.

Displays within the Indicators area
when a new WAP message is received.

Displays when Inbox is full - Text
Message.

Displays when you set an alarm to ring at
a specified time. For more information,
refer to “Alarms” on page 80.

Displays when Call forwarding is set to
Forward always. For more information,
refer to “Call Settings” on page 121.

Displays when the Sound profile is set
to Normal.

Displays when the Sound profile is set
to Silent or the volume has been
manually lowered below level 1.

Displays when the Sound profile is set
to Driving.

Displays when the Sound profile is set
to Outdoor.

Displays when the Sound profile is set
to Eco.

Displays when Bluetooth is activated.

Displays when a Bluetooth stereo
headset has been paired with the
phone.

Understanding Your Phone 15

For more details on configuring your phone’s
settings, see “Changing Your Settings” on
page 108.

Menu Navigation

Menus and sub-menus can be accessed by
scrolling through them using the Navigation keys or
by using the shortcut keys.

16

Accessing a Menu Function by Scrolling

1.

In Idle mode, press the Menu soft key and
scroll using the Navigation keys to reach a
main menu item, Settings for example. Press
the Select soft key or the key to enter
the menu.

2.

If the menu contains sub-menus, Phone for
example, you can access them by first
highlighting the option and then by pressing
the Select soft key or the key. If the
menu you selected contains further options,
repeat this step.

3.

To scroll through these menus, press either
the Up or Down Navigation key or the
Vol ume key (located on the left side of your
phone). Press the Select soft key or the
key to make your selection.

4.

To return to the previous menu level, press
the Back soft key or the key.

5.

To exit the menu without changing the
settings, press the key.

Using Shortcut Numbers

Numbered menu items, such as menus, sub­menus, and options can be quickly accessed by
using their shortcut numbers. In Menu mode, Main
Menus can be accessed by pressing the number
keys (1 to 0, * and #) corresponding to their location
on the screen.

Example:

Accessing the Music Player.

1.

In Idle mode, press the Menu soft key.

2.

Press the key for Messaging.

3.

Press the key for Inbox.
Your message inbox is displayed.

Multitask Functions

Pressing the Multitasking key on the right side of
the handset allows you to choose one of the
following functions:

•

Call

: allows you to make a voice call while using the
handset for other tasks. If Music Player is active, it is
muted during the call.

Understanding Your Phone 17

Messaging

•

: allows you to send a text or multimedia

message while using the handset for other tasks.

•

Mobile Web

: allows you to launch the Mobile Web

browser while using the handset for other tasks.

•

Music Player:

allows you to launch the music player

while using the handset for other tasks

•

Games

: allows you to quickly access Games while

using the handset for other tasks.

•

End all?

: closes all running applications or tasks and

returns you to the Idle screen.

18

Section 3: Entering Text

Navigation
Keys

Right Soft
Key

Left Soft
Key

OK/Confirm

This section describes how to select the desired
text entry mode when entering characters using the
QWERTY keyboard-style keypad.

This section also describes how to use the T9
predictive text entry system to reduce the number
of key strokes needed to enter text.

Using the QWERTY Keypad

Your phone has a QWERTY (

text input. You can enter text as you would when
using a computer’s keyboard. To access the
QWERTY keypad, slide your phone open in the
landscape position to expose the keypad.

) keypad to support easy and quick

The keys are labelled with the alphabet on the
lower half and numbers and symbols on the upper

Entering Text 19

half. Press the key corresponding to the character
you want to enter. To switch between upper case
characters and lower case characters, press

. You can move the cursor by pressing the

Navigation key.

In addition, you can use the following function keys:

Press to delete characters. Press
and hold to delete all text.

Press to start a new line.

20

Press twice to select CAP LOCK.
Press once more to remove CAP
LOCK.

Press to enter symbols or numbers

indicated on the upper portion of
each key.

Press twice to select Function lock.
Press once more to remove
Function lock.

Short press inserts a space. Press
and hold in Idle mode to set phone to
Silent mode.

Press to display the symbols grid.
