Page 1

This user manual includes detailed usage instructions for your camera. Please read this manual thoroughly.

Click a topic

Basic troubleshooting

Quick reference

Contents

Basic functions

Extended functions

Shooting options

Playback/Editing

ST75/ST76/ST77/ST78/ST79

Settings

Appendixes

Index

Page 2

Health and safety information

Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera.

Warning—situations that could cause injury to yourself or others

Do not disassemble or attempt to repair your camera.

This may result in electric shock or damage to the camera.

Do not use your camera near ﬂammable or explosive gases and liquids.

This may cause a ﬁre or explosion.

Do not insert ﬂammable materials into the camera or store these materials near the camera.

This may cause a ﬁre or electric shock.

Do not handle your camera with wet hands.

This may result in electric shock.

Prevent damage to subjects’ eyesight.

Do not use the ﬂash in close proximity (closer than 1 m/3 ft) to people or animals. If you use the ﬂash too close to your subject’s eyes, this can cause temporary or permanent eyesight damage.

Keep your camera away from small children and pets.

Keep your camera and all accessories out of the reach of small children and animals. Small parts may cause choking or serious injury if swallowed. Moving parts and accessories may present physical dangers as well.

Do not expose the camera to direct sunlight or high temperatures for an extended period of time.

Prolonged exposure to sunlight or extreme temperatures can cause permanent damage to your camera’s internal components.

Avoid covering the camera or charger with blankets or clothes.

The camera may overheat, which may distort the camera or cause a ﬁre.

Do not handle the power supply cord or go near the charger during a thunderstorm.

This may result in electric shock.

If liquid or foreign objects enter your camera, immediately disconnect all power sources, such as the battery or charger, and then contact a Samsung service center.

Page 3

Health and safety information

Caution—situations that could cause damage to your camera or other equipment

Remove the batteries from your camera when storing it for an extended period of time.

Installed batteries may leak or corrode over time and cause serious damage to your camera.

Use only authentic, manufacturer-recommended, Lithium-ion replacement batteries. Do not damage or heat the battery.

Inauthentic, damaged, or heated batteries may cause a ﬁre or personal injury.

Use only Samsung-approved batteries, chargers, cables and accessories.

• Using unauthorized batteries, chargers, cables or accessories

can cause batteries to explode, damage your camera, or cause injury.

• Samsung is not responsible for damage or injuries caused by

unapproved batteries, chargers, cables or accessories.

Use the battery only for its intended purpose.

Misusing the battery may cause a ﬁre or electric shock.

Do not touch the ﬂash while it ﬁres.

The ﬂash is very hot when ﬁred and may burn your skin.

When you use the AC charger, turn off the camera before you disconnect the power to the AC charger.

Failing to do so may result in ﬁre or electric shock.

Disconnect the charger from the wall socket when not in use.

Failing to do so may result in ﬁre or electric shock.

Do not use a damaged power supply cord, plug, or loose outlet when you charge batteries.

This may cause a ﬁre or electric shock.

Do not allow the AC charger to come in contact with the +/terminals on the battery.

This may cause a ﬁre or electric shock.

Do not force the camera’s parts or apply pressure to the camera.

This may cause your camera to malfunction.

Page 4

Health and safety information

Exercise caution when you connect cables or adapters and install batteries and memory cards.

If you force the connectors, improperly connect cables, or improperly install batteries and memory cards, you can damage ports, connectors, and accessories.

Keep cards with magnetic strips away from the camera case.

Information stored on the card may be damaged or erased.

Never use a damaged charger, battery, or memory card.

This may result in electric shock or camera malfunction or cause a ﬁre.

Check that the camera is operating properly before use.

The manufacturer takes no responsibility for any loss of ﬁles or damage that may result from camera malfunction or improper use.

You must plug the small end of the USB cable into your camera.

If the cable is reversed, it may damage your ﬁles. The manufacturer is not responsible for any loss of data.

Page 5

Outline of the User Manual

• Microsoft Windows and the Windows logo are

registered trademarks of the Microsoft Corporation.

• Mac is a registered trademark of the Apple Corporation.

• microSD™ and microSDHC™ are registered

trademarks of the SD Association.

• Trademarks and trade names used in this manual are

the property of their respective owners.

• Camera speciﬁcations or contents of this manual may

be changed without prior notice due to upgrade of camera functions.

• Use this camera responsibly and adhere to all laws

and regulations concerning its use.

• You are not allowed to reuse or distribute any part of

this manual without prior permission.

Basic functions 12

Learn about your camera’s layout, icons, and basic functions for shooting.

Extended functions 32

Learn how to capture a photo and record a video by selecting a mode.

Shooting options 48

Learn how to set the options in Shooting mode.

Playback/Editing 72

Learn how to play back photos or videos, and edit photos. Also, learn how to connect your camera to your computer, photo printer, or TV.

Settings 97

Refer to options to conﬁgure your camera’s settings.

Appendixes 103

Get information about error messages, speciﬁcations, and maintenance.

Page 6

Indicators used in this manual

Shooting mode Indicator

Smart Auto

Program

Live Panorama

Picture in Picture

Scene

Movie

Shooting mode icons

These icons appear in the text when a function is available in a mode. See the example below. Note: The s mode may not support functions for all scenes.

For example:

S p N d s v

Available in Program and Movie modes

Icons used in this manual

Icon Function

Additional information

Safety warnings and precautions

Camera buttons. For example, [Shutter] represents the

[]

shutter button.

() Page number of related information

The order of options or menus you must select to perform a step; for example: Select



(represents Select

* Annotation

, and then select Photo Size).

 Photo Size

Page 7

Expressions used in this manual

Pressing the shutter

• Half-press [Shutter]: press the shutter halfway down

• Press [Shutter]: press the shutter all the way down

Half-press [Shutter] Press [Shutter]

Subject, background, and composition

• Subject: the main object in a scene, such as a person, animal,

or still life

• Background: the objects around the subject

• Composition: the combination of a subject and background

Background

Composition

Subject

Exposure (Brightness)

The amount of light that enters your camera determines the exposure. You can alter the exposure by changing the shutter speed, aperture value, or ISO sensitivity. By altering the exposure, your photos will be darker or lighter.

Normal exposure

Overexposure (too bright)

Page 8

Basic troubleshooting

Learn to solve common problems by setting shooting options.

The subject’s eyes appear red.

Photos have dust spots.

Photos are blurred.

Photos are blurred when shooting at night.

Subjects come out too dark because of backlighting.

Red eye occurs when the subject's eyes reﬂect light from the camera ﬂash.

•

Set the ﬂash option to Red-eye or Red-eye Fix. (p. 52)

•

If the photo has already been captured, select Red-eye Fix in the edit menu. (p. 86)

If dust particles are present in the air, you may capture them in photos when you use the ﬂash.

•

Turn off the ﬂash or avoid capturing photos in a dusty place.

•

Set ISO sensitivity options. (p. 54)

Blurring can occur if you capture photos in low light conditions or hold the camera incorrectly. Use the OIS/DIS function or half-press [Shutter] to ensure the subject is focused. (p. 30)

As the camera tries to let in more light, the shutter speed slows. This can make it difﬁcult to hold the camera steady long enough to capture a clear photo and may result in camera shake.

•

Select Night in s mode. (p. 39)

•

Turn on the ﬂash. (p. 52)

•

Set ISO sensitivity options. (p. 54)

•

Use a tripod to prevent your camera from shaking.

When the light source is behind the subject or when there is a high contrast between light and dark areas, the subject may appear too dark.

•

Avoid shooting toward the sun.

•

Select Backlight in s mode. (p. 39)

•

Set the ﬂash option to Fill in. (p. 52)

•

Adjust the exposure. (p. 63)

•

Set the Auto Contrast Balance (ACB) option. (p. 64)

•

Set the metering option to Spot if a subject is in the center of the frame. (p. 65)

Page 9

Quick reference

Capturing photos of people

• d

mode f 38

• s

mode > Beauty Shot f 41

• s

mode > Intelligent Portrait f 42

•

Red-eye/Red-eye Fix (to prevent or correct

red-eye)

•

Face Detection f 58

•

Self-Portrait f 59

Capturing photos at night or in the dark

• s

mode > Night, Sunset, Dawn f 39

•

Flash options f 52

•

ISO sensitivity (to adjust the sensitivity to light)

Capturing action photos

•

Continuous, Motion Capture f 68

Capturing photos of text, insects, or ﬂowers

• s

mode > Text f 39

•

Macro f 55

Adjusting the exposure (brightness)

•

ISO sensitivity (to adjust the sensitivity to light)

•

EV (to adjust exposure) f 63

•

ACB (to compensate for subjects against bright backgrounds)

•

Metering f 65

•

AEB (to capture 3 photos of the same scene with different exposures)

Capturing photos of scenery

• N

mode f 36

• s

mode > Landscape f 39

Applying effects to photos

• s

mode > Magic Frame f 40

• s

mode > Funny Face f 43

•

Smart Filter effects f 69

•

Image Adjust (to adjust Contrast, Sharpness, or Saturation)

Reducing camera shake

•

Optical Image Stabilization (OIS) f 29

•

Digital Image Stabilization (DIS) f 29

•

Viewing ﬁles by category in Smart Album

•

Viewing ﬁles as thumbnails f 76

•

Deleting all ﬁles on the memory card f 78

•

Viewing ﬁles as a slide show f 80

•

Viewing ﬁles on a TV f 89

•

Connecting your camera to a computer

•

Adjusting sound and volume f 99

•

Adjusting the brightness of the display

100

•

Changing the display language f 100

•

Setting the date and time f 100

•

Before contacting a service center f 114

Page 10

Basic functions

Unpacking ................................................................... 13

Camera layout ............................................................. 14

Inserting the battery and memory card ....................... 17

Charging the battery and turning on your camera ...... 18

Charging the battery ................................................... 18

Turning on your camera .............................................. 18

Performing the initial setup ......................................... 19

Learning icons ............................................................. 21

Selecting options or menus ........................................ 22

Using [MENU] ............................................................ 22

Using [Fn] .................................................................. 24

Setting the display and sound .................................... 25

Setting the display type ............................................... 25

Setting the sound ....................................................... 25

Capturing photos ......................................................... 26

Zooming .................................................................... 27

Reducing camera shake (OIS or DIS) ........................... 29

Tips for getting a clearer photo ................................... 30

................................................................. 12

Extended functions

Using the Smart Auto mode ........................................ 33

Using the Program mode ............................................ 35

Using the Live Panorama mode .................................. 36

Using the Picture-in-Picture mode .............................. 38

Using the Scene mode ................................................ 39

Using the Movie mode ................................................ 45

.......................................................... 32

Using the Magic Frame mode ..................................... 40

Using the Beauty Shot mode ....................................... 41

Using the Intelligent Portrait mode ................................ 42

Using the Funny Face mode ....................................... 43

Using the Night mode ................................................. 44

Using the Smart Scene Detection mode ...................... 47

Page 11

Contents

Shooting options

.............................................................. 48

Selecting a resolution and quality ............................... 49

Selecting a resolution .................................................. 49

Selecting an image quality ........................................... 50

Using the timer ............................................................ 51

Shooting in the dark .................................................... 52

Preventing red-eye ..................................................... 52

Using the ﬂash ........................................................... 52

Adjusting the ISO sensitivity ......................................... 54

Changing the camera’s focus ..................................... 55

Using macro .............................................................. 55

Using auto focus ........................................................ 55

Using tracking auto focus ............................................ 56

Adjusting the focus area .............................................. 57

Using Face Detection .................................................. 58

Detecting faces .......................................................... 58

Capturing a self portrait shot ........................................ 59

Capturing a smile shot ................................................ 59

Detecting eye blinking ................................................. 60

Using Smart Face Recognition .................................... 60

Registering faces as your favorites (My Star) ................. 61

Adjusting brightness and color ................................... 63

Adjusting the exposure manually (EV) ........................... 63

Compensating for backlighting (ACB) ........................... 64

Changing the metering option ...................................... 65

Selecting a White Balance setting ................................ 66

Using burst modes ...................................................... 68

Applying effects/Adjusting images .............................. 69

Applying Smart Filter effects ........................................ 69

Adjusting images ........................................................ 71

Page 12

Contents

Playback/Editing

............................................................... 72

Viewing photos or videos in Playback mode .............. 73

Starting Playback mode .............................................. 73

Viewing photos .......................................................... 79

Playing a video ........................................................... 81

Editing a photo ............................................................ 83

Resizing photos ......................................................... 83

Rotating a photo ......................................................... 83

Creating a close-up portrait ......................................... 84

Applying Smart Filter effects ........................................ 84

Adjusting your photos ................................................. 85

Creating a print order (DPOF) ....................................... 87

Viewing ﬁles on a TV ................................................... 89

Transferring ﬁles to your Windows computer ............. 90

Transferring ﬁles with Intelli-studio ................................. 91

Transferring ﬁles by connecting the camera as a removable disk

Disconnecting the camera (for Windows XP) ................. 94

........................................................... 93

Transferring ﬁles to your Mac computer ..................... 95

Printing photos with a PictBridge photo printer ......... 96

Settings

............................................................................. 97

Settings menu ............................................................. 98

Accessing the settings menu ...................................... 98

Sound ....................................................................... 99

Display ...................................................................... 99

Settings ................................................................... 100

Appendixes

..................................................................... 103

Error messages ......................................................... 104

Camera maintenance ................................................ 105

Cleaning your camera ............................................... 105

Using or storing the camera ...................................... 106

About memory cards ................................................ 107

About the battery ...................................................... 110

Before contacting a service center ........................... 114

Camera speciﬁcations ............................................... 117

Glossary ..................................................................... 121

FCC notice ................................................................. 126

Index .......................................................................... 127

Page 13

Basic functions

Learn about your camera’s layout, icons, and basic functions for shooting.

Unpacking

Camera layout

Inserting the battery and memory card

Charging the battery and turning on your camera

Performing the initial setup

Learning icons

………………………………… 13

……………………………… 14

………………………………… 18 Charging the battery Turning on your camera

……………………… 18

………………… 18

……………… 19

……………………………… 21

… 17

Selecting options or menus

Using [MENU] Using [Fn]

Setting the display and sound

Setting the display type Setting the sound

Capturing photos

Zooming Reducing camera shake (OIS or DIS)

Tips for getting a clearer photo

…………………………… 22

………………………………… 24

………………………………… 27

……………… 22

…………… 25

…………………… 25

………………………… 25

………………………… 26

…… 29

…………… 30

Page 14

Unpacking

The following items are included in your product box.

Optional accessories

Camera AC adapter/

USB cable

Rechargeable battery Strap

Quick Start Guide

Basic functions

Camera case A/V cable

Battery charger Memory card/

•

The illustrations may differ slightly from the items shipped with your product.

•

You can purchase optional accessories at a retailer or a Samsung service center. Samsung is not responsible for any problems caused by using unauthorized accessories.

Memory card adapter

Page 15

Camera layout

Before you start, familiarize yourself with your camera’s parts and their functions.

Shutter button

Flash

Lens

Tripod mount

Battery chamber cover

Insert a memory card and battery

Microphone

Basic functions

POWER button

Speaker

AF-assist light/Timer lamp

USB and A/V port

Accepts USB cable and A/V cable

Page 16

Camera layout

Status lamp

•

Blinking: When the camera is saving a photo or video, being read by a computer or printer, when the image is out of focus, or there is a problem charging the battery

•

Steady: When the camera is connected to a computer, charging the battery, or when the image is in focus

Display

Buttons

(p. 16)

Zoom button

•

In Shooting mode: Zoom in or out

•

In Playback mode: Zoom in on part of a photo or view ﬁles as thumbnails, or adjust the volume

Attaching the strap

Basic functions

Page 17

Camera layout

Buttons

Button Description

Access options or menus.

Select a shooting mode.

Mode

Description

Smart Auto: Capture a photo with a scene mode selected automatically by the camera.

Program: Capture a photo with settings you have set manually.

Live Panorama: Capture and combine a series of photos to create a panoramic image.

Picture in Picture: Capture or select a fullsized background photo, and then insert a smaller photo into the foreground to create a synthesized photo.

Scene: Capture a photo with options preset for a speciﬁc scene.

Movie: Record a video.

Button Description

Basic functions Other functions

Change the display option. Move up

Change the macro option. Move down

Change the ﬂash option. Move left

Change the timer option. Move right

Conﬁrm the highlighted option or menu.

Enter Playback mode.

•

Access options in Shooting mode.

•

Delete ﬁles in Playback mode.

Basic functions

Page 18

Inserting the battery and memory card

Learn how to insert the battery and an optional memory card into the camera.

Removing the battery and memory card

Memory card

Insert a memory card with the gold-colored contacts facing up.

Push the card gently until it disengages from the camera, and then pull it out of the slot.

Memory card

Rechargeable battery

Insert the battery with the Samsung logo facing up.

Basic functions

Battery lock

Slide the lock up to release the battery.

Rechargeable battery

You can use the internal memory for temporary storage if a memory card is not inserted.

Page 19

Charging the battery and turning on your camera

Charging the battery

Before you use the camera for the ﬁrst time, you must charge the battery. Plug the small end of the USB cable into your camera, and then plug the other end of the USB cable into the AC adapter.

Status lamp

•

Red light on: Charging

•

Red light off: Fully charged

•

Red light blinking: Error

Use only the AC adapter and USB cable supplied with your camera. If you use another AC adapter (such as SAC-48), the camera battery may not charge or work properly.

Basic functions

Turning on your camera

Press [POWER] to turn your camera on or off.

• The initial setup screen appears when you turn on the camera

for the ﬁrst time. (p. 19)

Turning on your camera in Playback mode

Press [P]. The camera turns on and immediately accesses Playback mode.

If you turn on your camera by pressing and holding [P] until the status lamp blinks, the camera does not emit any sounds.

Page 20

Performing the initial setup

When you turn on your camera for the ﬁrst time, the initial setup screen appears. Follow the steps below to conﬁgure the camera’s basic settings.

Press [t] to select Language, and then

press [

] or [o].

Press [D/c] to select a language, and then

press [

Press [D/c] to select Time Zone, and then

press [

] or [o].

Basic functions

Press [F/t] to select a time zone, and then press [o].

•

To set daylight-savings time, press [D].

Time Zone

London

[GMT +00:00] 2012/01/01 12:00PM

Back DST

Page 21

Performing the initial setup

Press [D/c] to select Date/Time Set, and then

press [

] or [o].

Time Zone

Date/Time Set

Date Type

Back Set

•

The screen may differ depending on the language selected.

Press [F/t] to select an item.

Press [D/c] to set the date and time, and then

press [

English London

YYYY MM DD

Basic functions

Press [D/c] to select Date Type, and then

press [

] or [o].

Press [D/c] to select a date type, and then

press [

Time Zone

Date/Time Set

Date Type

Back

•

The default date type may differ depending on the language selected.

Press [

English London

YYYY/MM/DD MM/DD/YYYY DD/MM/YYYY

Set

] to switch to Shooting mode.

Page 22

Learning icons

The icons the camera displays on the screen change according to the mode you select or the options you set.

Shooting options (left)

Icon Description

Actively moving subject

Shooting mode

Aperture value and shutter speed

Long time shutter

EV (Exposure Value)

White balance

Face tone

Face retouch

ISO sensitivity

Smart ﬁlter

Image adjust (constrast, sharpness, and saturation)

Sound Alive on

Burst option

Image Stabilization (OIS/DIS)

Shooting information

Icon Description

Available number of photos

Memory card not inserted (Internal memory)

Memory card inserted

•

: Fully charged

•

: Partially charged

•

: Empty (Recharge)

Available recording time

Auto focus frame

Camera shake

Icon Description

Photo resolution when Intelli zoom is on

Zoom indicator

Zoom ratio

Current time and date

Shooting options (right)

Icon Description

Photo resolution

Video resolution

Frame rate

Photo quality

Metering

Flash

Timer

Auto focus option

Face detection

Basic functions

Page 23

Selecting options or menus

To select an option or a menu, press [m] or [f].

Using [MENU]

To select options, press [m], and then press [D/c/F/t] or [o].

In Shooting mode, press [

Select an option or a menu.

•

To move up or down, press [D] or [c].

•

To move left or right, press [F] or [t].

Press [o] to conﬁrm the highlighted option or menu.

Basic functions

Going back to the previous menu

Press [

] again to go back to the previous menu.

Half-press [Shutter] to return to Shooting mode.

Page 24

Selecting options or menus

For example, to select a White Balance option in Program mode:

In Shooting mode, press [

Select p.

Press [

Press [D/c] to select a, and then press

[

] or [o].

Shooting

Sound

Display

Settings

Exit

Photo Size

Quality

ISO White Balance Smart Filter

Face Detection

Change

Basic functions

Press [D/c] to select White Balance, and then

press [

] or [o].

Photo Size Quality EV ISO White Balance

Smart Filter

Face Detection

Exit Back

Press [F/t] to select a White Balance option.

Daylight

Back

Press [o] to save your settings.

Move

Page 25

Selecting options or menus

Using [Fn]

You can access shooting options by pressing [f], but some options are not available.

Press [D/c] to scroll to .

For example, to select a White Balance option in Program mode:

In Shooting mode, press [

Select p.

Press [f].

Photo Size

Exit Move

Basic functions

White Balance

Exit Move

Press [F/t] to select a White Balance option.

Daylight

Exit Move

Press [o] to save your settings.

Page 26

Setting the display and sound

Learn how to change the basic display information and sound settings.

Setting the display type

You can select a display type for the Shooting or Playback mode. Each type displays different shooting or playback information. See the table below.

Show all photographic information.

Press [D] repeatedly to change the display type.

Mode

Shooting

Playback

Display type

•

Hide all information about shooting options.

•

Show all information about shooting options.

•

Hide all information about the current ﬁle.

•

Show information about the current ﬁle, except the shooting settings.

•

Show all information about the current ﬁle.

Basic functions

Setting the sound

Turn the sound your camera emits when you perform functions.

In Shooting or Playback mode, press [

Select O  Beep Sound.

Select an option.

Option

Off

1/2/3

Description

The camera does not emit any sounds.

The camera emits sounds.

Page 27

Capturing photos

Learn how to capture photos easily and quickly in Smart Auto mode.

In Shooting mode, press [

Select S.

Align your subject in the frame.

Basic functions

Half-press [Shutter] to focus.

•

A green frame means the subject is in focus.

•

A red frame means the subject is out of focus.

Press [Shutter] to capture a photo.

Press [P] to view the captured photo.

•

To delete the photo, press [f], and then select Yes .

Press [P] to return to Shooting mode.

See page 30 for tips to get clearer photos.

Page 28

Capturing photos

Zooming

You can capture close-up photos by adjusting the zoom.

Zoom ratio

Zoom out

•

The farther you rotate the zoom button, the faster the camera zooms in or out.

•

When you rotate the zoom button, the zoom ratio shown on the screen may change inconsistently.

Zoom in

Basic functions

Digital zoom

The Digital zoom is supported by default in Shooting mode. If you zoom in on a subject in Shooting mode and the zoom indicator is in the digital range, your camera is using the Digital zoom. By using both the 5X Optical zoom and 5X Digital zoom, you can zoom in up to 25 times.

Optical range

Zoom indicator

Digital range

•

The Digital zoom is not available with the Smart Filter effect or Tracking AF option.

•

If you capture a photo with the Digital zoom, the photo quality may be lower than normal.

Page 29

Capturing photos

Intelli zoom

If the zoom indicator is in the Intelli range, your camera is using the Intelli zoom. Photo resolution varies according to the zoom rate if you use the Intelli zoom. By using both the Optical zoom and Intelli zoom, you can zoom in up to 10 times.

Zoom indicator

Photo resolution when

the Intelli zoom is on

Optical range

Intelli range

•

The Intelli zoom is not available with the Smart Filter effect or Tracking AF option.

•

The Intelli zoom helps you capture a photo with less quality deterioration than the Digital zoom. However, the photo quality may be lower than when you use the Optical zoom.

•

The Intelli zoom is available only when you set a 4:3 resolution ratio. If you set another resolution ratio with Intelli zoom on, the Intelli zoom will be turned off automatically.

Basic functions

Setting Intelli zoom

In Shooting mode, press [

Select a  Intelli Zoom.

Select an option.

Icon

Description

Off: The Intelli zoom is deactivated.

On: The Intelli zoom is activated.

Page 30

Capturing photos

Reducing camera shake (OIS or DIS)

Reduce camera shake optically or digitally in Shooting mode. Reduce camera shake with the Optical Image Stabilizer (ST77/ST79) or the Digital Image Stabilizer (ST75/ST76/ST78).

Before correction

In Shooting mode, press [

Select a  OIS or DIS.

Select an option.

Icon

Description

Off: This function is deactivated.

On: This function is activated.

After correction

Basic functions

•

OIS or DIS may not function properly when:

- you move your camera to follow a moving subject

- you use the Digital zoom

- there is too much camera shake

- the shutter speed is slow (for example, when you capture night scenes)

- the battery is low

- you capture a close-up shot

•

If you use the OIS or DIS function with a tripod, your images may be blurred by the vibration of the OIS or DIS sensor. Deactivate the OIS or DIS function when you use a tripod.

•

If the camera is hit or dropped, the display will be blurry. If this occurs, turn off the camera, and then turn it on again.

•

The OIS or DIS function is not available when you set Burst options.

Page 31

Tips for getting a clearer photo

Holding your camera correctly

Half-pressing the shutter button

Half-press [Shutter] and adjust the focus. The camera adjusts the focus and exposure automatically.

The camera sets the aperture value and shutter speed automatically.

Focus frame

•

Press [Shutter] to capture the photo if the focus frame appears in green.

•

Change the composition and half-press [Shutter] again if the focus frame appears in red.

Ensure nothing is blocking the lens, ﬂash, or microphone.

Basic functions

Reducing camera shake

Set the Optical Image Stabilization option or Digital Image Stabilization option to reduce camera shake optically or digitally. (p. 29)

When is displayed

Camera shake

When you shoot in the dark, avoid setting the ﬂash option to Slow Sync or Off. The aperture remains open longer and it may be harder to hold the camera steady long enough to capture a clear photo.

•

Use a tripod or set the ﬂash option to Fill in. (p. 52)

•

Set ISO sensitivity options. (p. 54)

Page 32

Preventing your subject from being out of focus

It may be difﬁcult to get your subject in focus when:

there is little contrast between the subject and background (for example, when your subject is wearing clothing that is similar in color to the background)

the light source behind the subject is too bright

the subject is shiny or reﬂective

the subject includes horizontal patterns, such as blinds

the subject is not positioned in the center of the frame

Using the focus lock

Half-press [Shutter] to focus. When the subject is in focus, you can reposition the frame to change the composition. When you are ready, press [Shutter] to capture your photo.

•

When you capture photos in low light

•

When subjects are moving rapidly

Turn on the ﬂash. (p. 52)

Use the Continuous or Motion Capture function. (p. 68)

Basic functions

Page 33

Extended functions

Learn how to capture a photo and record a video by selecting a mode.

Using the Smart Auto mode

Using the Program mode

Using the Live Panorama mode

Using the Picture-in-Picture mode

Using the Scene mode

Using the Magic Frame mode Using the Beauty Shot mode Using the Intelligent Portrait mode Using the Funny Face mode Using the Night mode

Using the Movie mode

Using the Smart Scene Detection mode

………………………… 33

…………………………… 35

…………………… 36

……………………………… 39

……………………… 40

……………………… 41

………………………… 43

……………………………… 44

……………………………… 45

………………… 38

………………… 42

…………… 47

Page 34

Using the Smart Auto mode

In Smart Auto mode, your camera automatically chooses the appropriate camera settings based on the type of scene it detects. The Smart Auto mode is helpful if you are not familiar with the camera settings for various scenes.

In Shooting mode, press [

Select S.

Align your subject in the frame.

•

The camera automatically selects a scene. An appropriate scene icon appears at the top left of the screen. The icons are listed below.

Icon Description

Landscapes

Scenes with bright white backgrounds

Landscapes at night

Portraits at night

Landscapes with backlighting

4 5

Extended functions

Icon Description

Portraits with backlighting

Portraits

Close-up photos of objects

Close-up photos of text

Sunsets

Blue skies

Forested areas

Close-up photos of colorful subjects

Camera is stabilized or on a tripod (when shooting in the dark)

Actively moving subjects

Fireworks (when using a tripod)

Half-press [Shutter] to focus.

Press [Shutter] to capture the photo.

Page 35

Using the Smart Auto mode

•

If the camera does not recognize an appropriate scene mode, it uses the default settings for the S mode.

•

Even if it detects a face, the camera may not select a portrait mode depending on the subject's position or lighting.

•

The camera may not select the correct scene depending on the shooting conditions, such as camera shake, lighting, or distance to the subject.

•

Even if you use a tripod, the camera may not detect the mode if the subject is moving.

•

In S mode, the camera consumes more battery power, because it changes settings often to select appropriate scenes.

Extended functions

Page 36

Using the Program mode

In Program mode, you can set most options, except the shutter speed and aperture value, which the camera sets automatically.

In Shooting mode, press [

Select p.

Set the desired options.

•

For a list of options, refer to "Shooting options". (p. 48)

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

Extended functions

Page 37

Using the Live Panorama mode

In Live Panorama mode, you can capture a wide panoramic scene in a single photo. Capture and combine a series of photos to create a panoramic image.

With [Shutter] pressed, slowly move the camera in the

direction that will let it capture the rest of the panorama.

•

When the viewﬁnder is aligned with the next scene, the

Shooting example

camera captures the next photo automatically.

In Shooting mode, press [

Select N.

Align your subject in the frame, and then half-press

[Shutter] to focus.

•

Align the camera with the far left or the far right, or very top or bottom, of the scene you want to capture.

Press and hold [Shutter] to start shooting.

Extended functions

When you are ﬁnished, release [Shutter].

•

When you have captured all the necessary shots, the camera combines them into one panoramic photo.

Page 38

Using the Live Panorama mode

•

For best results when capturing panoramic photos, avoid the following:

- moving the camera too quickly or too slowly

- moving the camera too little to capture the next image

- moving the camera at irregular speeds

- shaking the camera

- changing the camera direction while capturing a photo

- shooting in dark places

- capturing moving subjects nearby

- shooting conditions where the brightness or color of light is changing

•

Selecting Live Panorama mode will disable the Digital and Optical zoom functions. If you select Live Panorama mode while the lens is zoomed in, the camera automatically zooms out to the default position.

•

In Live Panorama mode, some shooting options are not available.

•

The camera may stop shooting due to the shooting composition or movement within the scene.

•

In Live Panorama mode, your camera may not capture the last scene in its entirety if you stop moving the camera exactly where you want the scene to end. To capture the entire scene, move your camera slightly beyond the point where you want the scene to end.

Extended functions

Page 39

Using the Picture-in-Picture mode

In the PIP Shot mode, you can capture or select a full-sized background photo, and then insert a smaller photo into the foreground.

In Shooting mode, press [

Select d.

Half-press [Shutter] to focus, and then press [Shutter]

to capture the photo.

•

To select a background photo from your saved photos, press [

Album  a desired photo. You cannot select a video ﬁle or a photo captured in Live Panorama mode.

Press [o] to set the photo as a background image.

•

To recapture a background photo, press [

Press [o], and then press [D/c/F/t] to change

], and then select a  Background 

Back Move

the insertion point.

7 8

Extended functions

Press [o], and then press [D/c/F/t] to change the insertion size.

Press [o] to save the setting.

Half-press [Shutter] to focus, and then press [Shutter] to capture and insert a photo.

•

The insertion window appears larger when you half-press [Shutter], so that you can determine whether or not the subject is in focus.

To view the synthesized photo, press [P].

•

Press [P] again to return to Shooting mode.

•

When capturing background photos, the resolution is automatically set to and all photos captured are saved.

•

The ﬁnal Picture-in-Picture photos are saved as one combined ﬁle and the inserted photos are not saved separately.

•

When inserting an image, the resolution for the combined ﬁle is automatically set to .

•

The maximum size of the insertion window is 1/4 of the screen, and the aspect ratio stays the same when changing the size.

•

When using the Picture-in-Picture mode, the focus distance options are not available.

Page 40

Using the Scene mode

In Scene mode, you can capture a photo with options that are preset for a speciﬁc scene.

In Shooting mode, press [

Select s.

Select a scene.

Magic Frame Beauty Shot Intelligent Portrait Funny Face Night Landscape Text

Option Description

Magic Frame

Beauty Shot

Intelligent Portrait

Funny Face

Night

Capture scenes with various frame effects. (p. 40)

Capture a portrait with options to hide facial imperfections. (p. 41)

Automatically extract and save close-up portraits of an individual subject in a scene. (p. 42)

Capture a photo with funny face effects. (p. 43)

Capture scenes at night or in low lighting (using a tripod is recommended). (p. 44)

Option Description

Landscape

Text

Sunset

Dawn

Backlight

Beach & Snow

•

To change a scene mode, press [ select

Align your subject in the frame, and then half-press

Capture still-life scenes and landscapes.

Clearly capture text from printed or electronic documents.

Capture scenes at sunset, with natural-looking reds and yellows.

Capture scenes at sunrise.

Capture backlit subjects.

Reduce underexposure of subjects caused by sunlight reﬂected from sand or snow.

. You can select any of the scenes listed.

], and then

[Shutter] to focus.

Press [Shutter] to capture the photo.

Extended functions

Page 41

Using the Scene mode

Using the Magic Frame mode

In Magic Frame mode, you can apply various frame effects to your photos. The shape and the feel of the photos will change according to the frame you select.

In Shooting mode, press [

Select s  Magic Frame.

Press [

Select a  Frame.

Select an option.

Mural

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

In Magic Frame mode, the resolution is automatically set to .

Back

Move

Extended functions

Page 42

Using the Scene mode

Using the Beauty Shot mode

In Beauty Shot mode, you can capture a portrait with options to hide facial imperfections.

In Shooting mode, press [

Select s  Beauty Shot.

Press [

Select a  Face Tone.

Select an option.

•

For example, increase the face tone setting to make skin appear lighter.

Level 2

Press [

Back Move

Extended functions

Select a  Face Retouch.

Select an option.

•

For example, increase the face retouch setting to hide more imperfections.

Level 2

Back

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

When you use the Beauty Shot mode, the focus distance will be set to Auto Macro.

Move

Page 43

Using the Scene mode

Using the Intelligent Portrait mode

In Intelligent Portrait mode, you can extract and save close-up portraits of an individual subject in a scene. Once the camera detects a face from the scene, it automatically enlarges it and crops the image around the face. The camera then saves the full scene and two close-up portraits as three separate ﬁles.

In Shooting mode, press [

Select s  Intelligent Portrait.

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

•

The original photo and 2 cropped photos are showed on the display instantly and saved under consecutive ﬁle names.

Extended functions

•

The Intelligent Portrait mode will save only the original photo if:

- no face is detected

- more than 2 faces are detected

- the detected facial area is larger than a certain ratio

•

Cropped photos will be saved with the same aspect ratio (16:9) as the original or the inverse aspect ratio (9:16).

•

When you use the Intelligent Portrait mode, the focus distance will be set to Auto Macro.

Page 44

Using the Scene mode

Using the Funny Face mode

In Funny Face mode, you can distort your subject’s face with funny effects.

In Shooting mode, press [

Select s  Funny Face.

Aim the camera at the subject's face.

•

The camera detects faces with the face detection function.

Press [

Select a  Funny Effect  a funny effect.

•

You can review the face with the effect applied on the display.

Up Nose

Press [

Select a  Distortion Level.

Adjust the distortion level.

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

•

The Funny Face mode does not work if the camera cannot detect a face.

•

If the camera detects 2 or more faces, the effect will be applied only to the face nearest the camera.

•

When using the Funny Face mode, the focus distance options are not available.

Back

Move

Extended functions

Page 45

Using the Scene mode

Using the Night mode

In Night mode, you can use a slow shutter speed to extend the time the shutter stays open. Increase the aperture value to prevent overexposure.

In Shooting mode, press [

Select s  Night.

Press [

Select a  Long Time Shutter.

Select the aperture value or shutter speed.

Long Time Shutter

Aperture value Shutter speed

Select an option.

•

If you select AUTO, the aperture value or shutter speed will be adjusted automatically.

Align your subject in the frame, and then half-press

[Shutter] to focus.

Press [Shutter] to capture the photo.

•

Use a tripod to prevent blurry photos.

•

When using the Night mode, the focus distance options are not available.

Back

Move

Extended functions

Page 46

Using the Movie mode

In Movie mode, you can record HD videos of up to 20 minutes in length. The camera saves recorded videos as MJPEG ﬁles.

•

Some memory cards may not support high deﬁnition recording. If your card does not, set a lower resolution.

•

Memory cards with slow writing speeds will not support high-resolution videos. To record high-resolution videos, use memory cards with faster write speeds.

•

If you use the zoom function when recording a video, the camera may record the noise of the zoom operating. To decrease zoom noise, use the Sound Alive function. See Steps 7 and 8 below.

In Shooting mode, press [

Select v.

Press [

Select v  Frame Rate.

Select a frame rate (the number of frames per second).

•

As the frame rate increases, action appears more natural, but the ﬁle size also increases.

Press [

7 8

Extended functions

Select v  Sound Alive.

Select a Sound Alive option.

Icon Description

Sound Alive On: Turn on the Sound Alive function to reduce the zoom noise.

Sound Alive Off: Turn off the Sound Alive function. The camera can record the zoom noise.

Mute: Do not record sounds.

•

Do not block the microphone when you use the Sound Alive function.

•

Recordings made with Sound Alive may differ from actual sounds.

Page 47

Using the Movie mode

Set desired options.

•

For a list of options, refer to "Shooting options". (p. 48)

Press [Shutter] to start recording.

Press [Shutter] again to stop recording.

The camera allows you to temporarily pause a video while recording. With this function, you can record separate scenes as a single video.

• Press [o] to pause while recording.

• Press [o] to resume.

Extended functions

Pause recording

Stop Record

Page 48

Using the Movie mode

Using the Smart Scene Detection mode

In Smart Scene Detection mode, your camera automatically chooses the appropriate camera settings based on the scene it has detected.

In Shooting mode, press [

Select v.

Press [

Select v  Smart Scene Detection  On.

Align your subject in the frame.

•

The camera automatically selects a scene. An appropriate scene icon will appear at the top left of the screen.

Extended functions

Icon Description

Landscapes

Sunsets

Blue skies

Forested areas

Press [Shutter] to start recording.

Press [Shutter] again to stop recording.

•

If the camera does not recognize an appropriate scene mode, it uses the default settings for the Smart Scene Detection mode.

•

The camera may not select the correct scene depending on the shooting conditions, such as camera shake, lighting, and distance to the subject.

•

Smart Filter effects are not available in Smart Scene Detection mode.

Page 49

Shooting options

Learn how to set the options in Shooting mode.

Selecting a resolution and quality

Selecting a resolution Selecting an image quality

Using the timer

Shooting in the dark

Preventing red-eye Using the ﬂash Adjusting the ISO sensitivity

Changing the camera’s focus

Using macro Using auto focus Using tracking auto focus Adjusting the focus area

Using Face Detection

Detecting faces Capturing a self portrait shot Capturing a smile shot

…………………… 49

………………… 50

……………………………… 51

……………………… 52 ……………………… 52

…………………………… 52

……………… 54

…………… 55

……………………………… 55

………………………… 55

………………… 56

………………… 57

……………………… 58

…………………………… 58

……………… 59

…………………… 59

………… 49

Detecting eye blinking Using Smart Face Recognition Registering faces as your favorites

………………………………… 61

(My Star)

Adjusting brightness and color

Adjusting the exposure manually (EV) Compensating for backlighting (ACB) Changing the metering option Selecting a White Balance setting

Using burst modes

…………………… 60

…………… 60

…………… 63

…………… 65

………………………… 68

Applying effects/Adjusting images

Applying Smart Filter effects Adjusting images

………………………… 71

……………… 69

…… 63

…… 64

………… 66

……… 69

Page 50

Selecting a resolution and quality

Learn how to change the image resolution and quality settings.

Selecting a resolution

As you increase the resolution, your photo or video will include more pixels, so it can be printed on larger paper or displayed on a larger screen. When you use a high resolution, the ﬁle size will also increase.

Setting the photo resolution

In Shooting mode, press [

Select a  Photo Size.

Select an option.

Icon Description

4608 X 3456: Print on A1 paper.

4608 X 3072: Print on A1 paper in wide ratio (3:2).

4608 X 2592: Print on A2 paper in panorama ratio (16:9)

or play back on an HDTV.

3648 X 2736: Print on A3 paper.

2592 X 1944: Print on A4 paper.

Sps

Shooting options

Icon Description

1984 X 1488: Print on A5 paper.

1920 X 1080: Print on A5 paper in panorama ratio (16:9)

or play back on an HDTV.

1024 X 768: Attach to an email.

Setting the video resolution

In Video Shooting mode, press [

Select v  Movie Size.

Select an option.

Icon Description

1280 X 720 HQ: High-quality ﬁles to play back on an HDTV.

640 X 480: Files to play back on an analog TV.

320 X 240: Post on a web page.

Page 51

Selecting a resolution and quality

Selecting an image quality

Set the photo and video quality settings. Higher image quality settings will result in larger ﬁle sizes.

Setting the photo quality

The camera compresses and saves the photos you capture in the JPEG format.

In Shooting mode, press [

Select a  Quality.

Select an option.

Icon Description

Super Fine: Capture photos in super high quality.

Fine: Capture photos in high quality.

Normal: Capture photos in normal quality.

pds

Shooting options

Setting the video quality

The camera compresses and saves the videos you record in MJPEG format.

In Video Shooting mode, press [

Select v  Frame Rate.

Select an option.

Icon Description

30 FPS: Record 30 frames per second.

15 FPS: Record 15 frames per second.

Page 52

Using the timer

Learn how to set the timer to delay shooting.

Spdsv

In Shooting mode, press [t].

Off

Select an option.

Icon Description

Off: The timer is not active.

10 Sec: Capture a photo after a 10-second delay.

2 Sec: Capture a photo after a 2-second delay.

Double: Capture one photo after a 10-second delay

and another photo after a 2-second delay.

Available options may differ depending on the shooting conditions.

Shooting options

Press [Shutter] to start the timer.

•

The AF-assist light/timer lamp blinks. The camera will automatically capture a photo after the speciﬁed time has elapsed.

•

Press [Shutter] or [t] to cancel the timer.

•

Depending on the Face Detection options or the Focus Area options you selected, the timer function may not be available.

•

Timer options are not available if you set Burst options.

Page 53

Shooting in the dark

Learn how to capture photos at night or in low light conditions.

Preventing red-eye

If the ﬂash ﬁres when you capture a photo of a person in the dark, a red glow may appear in the person’s eyes. To prevent this, select Red-eye or Red-eye Fix. Refer to ﬂash options in “Using the ﬂash”.

Before correction

After correction

Shooting options

Using the ﬂash

Use the ﬂash when you capture photos in the dark or when you need more light in your photos.

In Shooting mode, press [F].

Select an option.

Icon Description

Spds

Auto

Off:

•

The ﬂash will not ﬁre.

•

The camera will display the shake warning when you are shooting in low light.

Page 54

Shooting in the dark

Icon Description

Red-eye Fix:

•

The ﬂash ﬁres twice when the subject or background is dark. The camera corrects red-eyes through its advanced software analysis.

•

There is an interval between the 2 bursts of the ﬂash. Do not move until the ﬂash ﬁres a second time.

Slow Sync:

•

The ﬂash ﬁres and the shutter stays open longer.

•

This option is recommended when you want to capture more ambient light to reveal more details in the background.

•

Use a tripod to prevent your photos from blurring.

•

The camera will display the shake warning when you are shooting in low light.

Fill in:

•

The ﬂash always ﬁres.

•

The camera automatically adjusts light intensity.

Shooting options

Icon Description

Red-eye:

•

The ﬂash will ﬁre twice when the subject or background is dark to reduce the red-eye effect.

•

There is an interval between the 2 bursts of the ﬂash. Do not move until the ﬂash ﬁres a second time.

Auto: The ﬂash will ﬁre automatically when the subject or background is dark.

Auto: The camera will select a proper ﬂash setting for the scene it detects in Smart Auto mode.

Available options may differ depending on the shooting conditions.

•

Flash options are not available if you set Burst options or select Self-Portrait or Blink Detection.

•

Make sure that your subjects are within the recommended distance from the ﬂash. (p. 118)

•

If light from the ﬂash is reﬂected or there is a substantial amount of dust in the air, tiny spots may appear in your photo.

Page 55

Shooting in the dark

Shooting options

Adjusting the ISO sensitivity

The ISO sensitivity is the measure of a ﬁlm’s sensitivity to light as deﬁned by the International Organization for Standardization (ISO). The higher ISO sensitivity you select, the more sensitive to light your camera becomes. Use a higher ISO sensitivity to capture better photos and reduce camera shake when not using the ﬂash.

In Shooting mode, press [

Select a  ISO.

Select an option.

•

Select to use an appropriate ISO sensitivity based on the brightness of the subject and lighting.

Higher ISO sensitivities may result in more image noise.

Page 56

Changing the camera’s focus

Learn how to adjust the camera’s focus to suit the subject and the shooting conditions.

Using macro

Use macro to capture close-up photos of subjects, such as ﬂowers or insects.

•

psv

Try to hold the camera ﬁrmly to prevent blurry photos. Turn off the ﬂash if the distance to the subject is less than 40 cm.

Shooting options

Using auto focus

To capture sharp photos, select the appropriate focus option according to your distance from the subject.

In Shooting mode, press [c].

Spsv

Normal (AF)

Page 57

Changing the camera’s focus

Select an option.

Icon Description

Normal (AF): Focus on a subject farther than 80 cm away. 250 cm when you use the zoom.

Macro: Focus on a subject that is 5-80 cm from the camera. 100-250 cm when you use the zoom.

Auto Macro:

•

Focus on a subject farther than 5 cm away. Farther than 100 cm away when you use the zoom.

•

It is set automatically in some shooting modes.

Available options may differ depending on the shooting conditions.

Shooting options

Using tracking auto focus

Tracking AF allows you to track and auto focus on your subject, even when you are moving.

In Shooting mode, press [

Select a  Focus Area  Tracking AF.

Focus on the subject you want to track, and then

press [

•

A focus frame appears on the subject and follows the subject as you move the camera.

•

The white frame means that your camera is tracking the subject.

•

When you half-press [Shutter], the green frame means that your subject is in focus.

Press [Shutter] to capture the photo.

Page 58

Changing the camera’s focus

•

If you do not select a focus area, the focus frame will appear in the center of the screen.

•

Tracking a subject may fail when:

- the subject is too small

- the subject moves excessively

- the subject is backlit or you are shooting in a dark place

- colors or patterns on the subject and the background are the same

- the subject includes horizontal patterns, such as blinds

- the camera shakes excessively

•

When tracking a subject fails, the focus frame will appear as a white single-line frame ( ).

•

If the camera fails to track the subject, you must reselect the subject to track.

•

If the camera fails to focus, the focus frame will change to a red single-line frame ( ).

•

If you use this function, you cannot set Face Detection options, Timer options, Intelli zoom, and Smart Filter effects.

Shooting options

Adjusting the focus area

You can get clearer photos by selecting an appropriate focus area according to your subject's location in the scene.

In Shooting mode, press [

Select a  Focus Area.

Select an option.

Icon Description

Center AF: Focus on the center of the frame (suitable when subjects are located at or near the center).

Multi AF: Focus on one or more of 9 possible areas.

Tracking AF: Focus on and track the subject. (p. 56)

Available options may differ depending on the shooting conditions.

Page 59

Using Face Detection

If you use Face Detection options, your camera can automatically detect a human face. When you focus on a human face, the camera adjusts the exposure automatically. Use Blink Detection to detect closed eyes or Smile Shot to capture a smiling face. You can also use Smart Face Recognition to register faces and prioritize the focus on them.

•

When your camera detects a face, it tracks the detected face automatically.

•

Face Detection may not be effective when:

- the subject is far from the camera

- it is too bright or too dark

- the subject is not facing the camera

- the subject is wearing sunglasses or a mask

- the subject’s facial expression changes drastically

- the subject is backlit or the lighting conditions are unstable

•

Face Detection is not available when you set the Smart Filter effects, Image adjustment, or Tracking AF.

•

Depending on the shooting options you selected, available Face Detection options may differ.

•

Depending on the Face Detection options you selected, the timer function may not be available.

•

When you set Face Detection options, the AF area is automatically set to Multi AF.

•

Depending on the Face Detection options you selected, Burst options may not be available.

•

When you set Smart Face Recognition option and capture photos of detected faces, they will be registered in the face list.

•

You can view registered faces in order of priority in Playback mode. (p. 75) Even though faces are registered successfully, they may not be classiﬁed in Playback mode.

•

A face detected with Smart Face Recognition option may not appear in the face list or Smart Album.

Shooting options

Detecting faces

Your camera automatically detects up to 10 human faces in one scene.

In Shooting mode, press [

Select a  Face Detection  Normal.

The closer you are to the subjects, the quicker your camera will detect faces.

The face nearest the camera or nearest the center of the scene appears in a white focus frame and the rest of the faces appear in gray focus frames.

Page 60

Using Face Detection

Capturing a self portrait shot

Capture photos of yourself. The camera sets the focus distance to close-up, and then emits a beep when ready.

In Shooting mode, press [

Select a  Face Detection  Self-Portrait.

Compose your shot with the lens facing you.

When you hear a quick beep, press [Shutter].

When faces are located in the center, the camera beeps rapidly.

If you turn Volume off in the sound settings, the camera will not emit a beep. (p. 99)

Shooting options

Capturing a smile shot

The camera automatically releases the shutter when it detects a smiling face.

In Shooting mode, press [

Select a  Face Detection  Smile Shot.

Compose your shot.

•

The camera automatically releases the shutter when it detects a smiling face.

When your subject smiles broadly, your camera can detect the smile more easily.

Page 61

Using Face Detection

Detecting eye blinking

If your camera detects closed eyes, it will automatically capture 2 photos in succession.

In Shooting mode, press [

Select a  Face Detection  Blink Detection.

Shooting options

Using Smart Face Recognition

The camera automatically registers faces that you frequently photograph. The Smart Face Recognition feature will automatically prioritize the focus on those faces and on favorite faces. The Smart Face Recognition feature is available only when you use a memory card.

In Shooting mode, press [

Select a  Face Detection  Smart Face Recognition.

• : Faces that you have registered as favorites.

(To register faces as favorites, refer to page 61.)

• : Faces that the camera has automatically registered.

Page 62

Using Face Detection

•

The camera may recognize and register faces incorrectly depending on lighting conditions, drastic changes in the subject's pose or face, and whether or not the subject is wearing glasses.

•

The camera can automatically register up to 12 faces. If the camera recognizes a new face when 12 faces have already been registered, it will replace the lowest priority face with the new one.

Shooting options

Registering faces as your favorites (My Star)

You can register your favorite faces to prioritize the focus and exposure on those faces. This feature is available only when you use a memory card.

In Shooting mode, press [

Select a  Smart FR Edit  My Star.

Align your subject’s face with the oval guideline, and then

press [Shutter] to register the face.

Back

Set

Page 63

Using Face Detection

•

Capture photos of one person at a time when registering faces.

•

Capture 5 photos of the subject’s face for best results: one each from the front, left, right, above, and below.

•

When capturing photos from the left, right, above, and below, instruct the subject not to turn his or her face more than 30 degrees.

•

You can register a face even if you capture only one photo of the subject's face.

When you are ﬁnished capturing the photos, the face list

appears.

•

Your favorite faces are indicated with a on the face list.

•

You can register up to 8 favorite faces.

•

The ﬂash will not ﬁre when you register a favorite face.

•

If you register the same face twice, you can delete one of the faces in the face list.

Shooting options

Viewing your favorite faces

In Shooting mode, press [

Select a  Smart FR Edit  Face List.

•

To change the ranking of your favorite faces, press [f], and then select Edit Ranking. (p. 74)

•

To delete a favorite face, press [f], and then select Delete. (p. 75)

Page 64

Adjusting brightness and color

Learn how to adjust the brightness and color for better image quality.

Adjusting the exposure manually (EV)

Depending on the intensity of the ambient light, your photos may be too bright or dark. In these cases, you can adjust the exposure to get a better photo.

Select a value to adjust the exposure.

•

The photo will be brighter as the exposure value increases.

•

When you adjust the exposure value, the icon will appear as shown below.

Darker (-)

In Shooting mode, press [

Select a or v  EV.

Neutral (0)S Brighter (+)

Press [o] to save your settings.

Shooting options

•

Once you adjust the exposure, the setting will be stored automatically. You may need to change the exposure value later to avoid overexposure or underexposure.

•

If you cannot decide on an appropriate exposure, select AEB (Auto Exposure Bracket). The camera will capture 3 consecutive photos, each with a different exposure: normal, underexposed, and overexposed. (p. 68)

Page 65

Adjusting brightness and color

Compensating for backlighting (ACB)

When the light source is behind your subject or there is high contrast between your subject and the background, your subject is likely to appear dark in the photo. In this case, set the Auto Contrast Balance (ACB) option.

Without ACB

In Shooting mode, press [

Select a  ACB.

With ACB

Shooting options

Select an option.

Icon Description

Off: ACB is off.

On: ACB is on.

•

The ACB feature is always on in Smart Auto mode.

•

The ACB feature is not available when you set Burst options or Smart Filter options.

Page 66

Adjusting brightness and color

Changing the metering option

The metering mode refers to the way in which a camera measures the quantity of light. The brightness and lighting of your photos will vary depending on the metering mode you select.

In Shooting mode, press [

Select a or v  Metering.

Select an option.

Icon Description

Multi:

•

Your camera divides the frame into several areas, and then measures the light intensity of each area.

•

Suitable for general photos.

Shooting options

Icon Description

Spot:

•

Center-weighted:

•

Your camera measures only the light intensity at the very center of the frame.

If a subject is not in the center of the frame, your photo may be improperly exposed.

Suitable for a subject with backlighting.

Your camera averages the meter reading of the entire frame with emphasis placed on the center.

Suitable for photos with subjects in the center of the frame.

Page 67

Adjusting brightness and color

Selecting a White Balance setting

The color of your photo depends on the type and quality of the light source. If you want the color of your photo to be realistic, select a White Balance setting that is appropriate for the lighting conditions, such as Auto WB, Daylight, Cloudy, or Tungsten.

Auto WB

Cloudy

Daylight

Tungsten

Shooting options

In Shooting mode, press [

Select a or v  White Balance.

Select an option.

Icon Description

Auto WB: Automatically set the White Balance based on the lighting conditions.

Daylight: For outdoor photos on a sunny day.

Cloudy: For outdoor photos on a cloudy day or in

shadows.

Fluorescent_H: For shooting under a daylight ﬂuorescent or 3-way ﬂuorescent light.

Fluorescent_L: For shooting under white ﬂuorescent light.

Tungsten: For shooting indoor photos under incandescent bulbs or halogen lamps.

Measure: Shutter: To use White Balance settings that you deﬁne. (p. 67)

Page 68

Adjusting brightness and color

Deﬁning your own White Balance

You can customize the White Balance by capturing a photo of a white surface, such as a piece of paper, under the lighting conditions in which you intend to capture a photo. The White Balance feature will help you to match the colors in your photo with the actual scene.

In Shooting mode, press [

Select a or v  White Balance.

Scroll to Measure: Shutter.

Aim the lens at a piece of white paper, and then

press [Shutter].

Shooting options

Page 69

Icon Description

Motion Capture: While you are pressing [Shutter], the camera captures maximum of 30 photos).

AEB:

•

Capture 3 consecutive photos, each with a different exposure: normal, underexposed, and overexposed.

•

Use a tripod to prevent blurry photos.

•

You can use the ﬂash, timer, ACB, and Smart Filter options only when you select Single.

•

When you select Motion Capture, your camera will set the resolution to and set the ISO sensitivity to Auto.

•

Depending on the Face Detection option you selected, some Burst options may not be available.

•

It may take longer to save the photos depending on the memory card capacity and performance.

photos (6 photos per second;

Using burst modes

It can be difﬁcult to capture photos of fast-moving subjects or capture natural facial expressions and gestures of your subjects in photos. Also, it can be difﬁcult to adjust the exposure correctly and select a proper light source. In these cases, select one of the burst modes.

In Shooting mode, press [

Select a  Drive.

Select an option.

Icon Description

Single: Capture a single photo.

Continuous:

•

While you are pressing [Shutter], the camera continuously captures photos.

•

The maximum number of photos depends on the capacity of your memory card.

Shooting options

Page 70

Applying effects/Adjusting images

Applying Smart Filter effects

Apply various ﬁlter effects to your photos and videos to create unique images.

Miniature Vignetting

Fish-eye Sketch

In Shooting mode, press [

Select a or v  Smart Filter.

Select an effect.

Shooting options

Available ﬁlters while capturing a photo

Icon Description

Normal: No effect

Miniature: Apply a tilt-shift effect to make the subject

appear in miniature.

Vignetting: Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras.

Half Tone Dot: Apply a halftone effect.

Sketch: Apply a pen sketch effect.

Fish-eye: Blacken the edges of the frame and distort

objects to imitate the visual effect of a ﬁsheye lens.

Defog: Make image clearer.

Classic: Apply a black and white effect.

Retro: Apply a sepia tone effect.

Negative: Apply a negative ﬁlm effect.

•

Depending on the option you select, the photo size may change to

or smaller automatically.

•

If you set Smart Filter effects, you cannot use the Face Recognition options, ACB, Burst options, Image Adjustment options, Intelli zoom, or Tracking AF.

Page 71

Applying effects/Adjusting images

Available ﬁlters while recording a video

Icon Description

Normal: No effect

Palette Effect 1: Create a vivid look with sharp contrast

and strong color.

Palette Effect 2: Make scenes clean and clear.

Palette Effect 3: Apply a soft brown tone.

Palette Effect 4: Create a cold and monotone effect.

Miniature: Apply a tilt-shift effect to make the subject

appear in miniature.

Vignetting: Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras.

Fish-eye: Distort close objects to imitate the visual effect of a ﬁsheye lens.

Defog: Make image clearer.

Classic: Apply a black and white effect.

Retro: Apply a sepia tone effect.

Negative: Apply a negative ﬁlm effect.

Shooting options

•

If you select Miniature, the miniature recording time is also displayed with the Miniature icon and is shorter than the real recording time.

•

If you select Miniature, you cannot record the video sound.

•

Depending on the option you select, the recording speed may change to and the recording resolution may change to or smaller automatically.

Page 72

Applying effects/Adjusting images

Adjusting images

Adjust the sharpness, saturation, or contrast of your photos.

In Shooting mode, press [

Select a  Image Adjust.

Select an option.

•

Contrast

•

Sharpness

•

Saturation

Image Adjust

Contrast

Sharpness Saturation

Back

-2 -1 0 +1 +2

Move

Shooting options

Press [F/t] to adjust each value.

Contrast Description

Decrease the color and brightness.

Increase the color and brightness.

Sharpness Description

Soften the edges on your photos (suitable for

editing the photos on your computer).

Sharpen the edges to improve the clarity of your

photos. This may also increase the noise in your photos.

Saturation Description

Decrease the saturation.

Increase the saturation.

Press [o] to save your settings.

•

Select 0 if you do not want to apply any effects (suitable for printing).

•

If you set adjustment functions, you cannot use Smart Filter options and Face Detection options.

Page 73

Playback/Editing

Learn how to play back photos or videos, and edit photos. Also, learn how to connect your camera to your computer, photo printer, or TV.

Viewing photos or videos in Playback mode

Starting Playback mode Viewing photos Playing a video

Editing a photo

Resizing photos Rotating a photo Creating a close-up portrait Applying Smart Filter effects Adjusting your photos Creating a print order (DPOF)

Viewing ﬁles on a TV

…………………………… 73

………………… 73

…………………………… 79

…………………………… 81

……………………………… 83

…………………………… 83

………………………… 83

…………………… 85

……………………… 89

……………… 84

…………… 87

Transferring ﬁles to your Windows computer

…………………………………… 90 Transferring ﬁles with Intelli-studio Transferring ﬁles by connecting the camera as a removable disk Disconnecting the camera (for Windows XP)

Transferring ﬁles to your Mac computer

Printing photos with a PictBridge photo printer

………………………… 94

………………………………… 96

………… 91

………… 93

… 95

Page 74

Viewing photos or videos in Playback mode

Learn how to play back photos or videos and how to manage ﬁles.

Starting Playback mode

View photos or play videos stored in your camera.

Press [P].

•

The most recent ﬁle will be displayed.

•

If the camera is off, it will turn on and display the most recent ﬁle.

Press [F/t] to scroll through ﬁles.

•

Press and hold [F/t] to scroll through ﬁles quickly.

•

If you want to view ﬁles stored in the internal memory, remove your memory card.

•

You may not be able to edit or play back ﬁles that were captured with other cameras, due to unsupported sizes (image size, etc) or codecs. Use a computer or another device to edit or play back these ﬁles.

Playback/Editing

Photo ﬁle information

Memory in use

File Information

Icon Description

Print order has been set (DPOF)

Protected ﬁle

Photo includes a registered face (Available only when you use a memory card.)

Folder name–File name

To display ﬁle information on the screen, press [D].

Page 75

Viewing photos or videos in Playback mode

Video ﬁle information

Play Capture

Icon Description

Video ﬁle

Protected ﬁle

Folder name–File name

Video length

Playback/Editing

Ranking your favorite faces

You can rank your favorite faces. The favorite face feature is available only when you insert a memory card into the camera.

In Playback mode, press [

Select u  Face List Edit  Edit Ranking.

Select a face from the list, and then press [o].

Face List Edit

Press [D/c] to change the ranking of the face,

and then press [

SetBack

Page 76

Viewing photos or videos in Playback mode

Deleting favorite faces

You can delete your favorite faces. The favorite face feature is available only when you insert a memory card into the camera.

In Playback mode, press [

Select u  Face List Edit  Delete.

Select a face, and then press [o].

Press [f].

When the pop-up message appears, select Yes.

Playback/Editing

Viewing ﬁles by category in Smart Album

View ﬁles by category, such as date, face, or ﬁle type.

In Playback mode, rotate [Zoom] to the left.

Press [

Select a category.

Type

Date

Color

Week

Face

Option Description

Type

Date

Color

Week

Face

Back Set

View ﬁles by the ﬁle type.

View ﬁles by the date they were saved.

View ﬁles by the dominant color of the image.

View ﬁles by the day of the week they were saved.

View ﬁles by recognized faces and favorite faces. (Up to 20 people)

Page 77

Viewing photos or videos in Playback mode

Press [F/t] to scroll through the ﬁles.

•

Press and hold [F/t] to scroll through ﬁles quickly.

Press [o] to return to the normal view.

•

When selecting Color, Etc appears if color is not extracted.

•

It may take some time for the camera to open Smart Album, change the category, or reorganize ﬁles.

Playback/Editing

Viewing ﬁles as thumbnails

Scan thumbnails of ﬁles.

In Playback mode, rotate [Zoom] to the left to view thumbnails (3 at a time). Rotate [Zoom] to the left once or twice more to display more thumbnails (9 or 20 at a time). Rotate [Zoom] to the right to return to the previous view.

Filter

To Description

Scroll through ﬁles

Delete ﬁles

Press [D/c/F/t].

Press [f], and then select Yes .

Page 78

Viewing photos or videos in Playback mode

Protecting ﬁles

Protect your ﬁles from accidental deletion.

In Playback mode, press [

Select u  Protect  Select.

•

To protect all ﬁles, select All  Lock.

Scroll to the ﬁle you want to protect, and then press

[

•

Press [o] again to cancel your selection.

Select Set

Press [f].

You cannot delete or rotate a protected ﬁle.

Protected ﬁle icon

Playback/Editing

Deleting ﬁles

Select ﬁles to delete in Playback mode.

Deleting a single ﬁle

You can select one ﬁle, and then delete it.

In Playback mode, select a ﬁle, and then press [f].

When the pop-up message appears, select Yes.

When viewing ﬁles in Smart Album or thumbnails view, press [f] to delete a ﬁle.

Page 79

Viewing photos or videos in Playback mode

Deleting multiple ﬁles

You can select multiple ﬁles, and then delete them at once.

In Playback mode, press [f].

When the pop-up message appears, select

Multiple Delete.

•

You can also delete multiple ﬁles in Playback mode by pressing [

Select.

Scroll to each ﬁle you want to delete, and then press

[

•

Press [o] again to cancel your selection.

Press [f].

When the pop-up message appears, select Yes.

], and then selecting u  Delete 

Playback/Editing

Deleting all ﬁles

You can select all ﬁles, and then delete them at once.

In Playback mode, press [

Select u  Delete  All.

When the pop-up message appears, select Yes.

•

All unprotected ﬁles are deleted.

Copying ﬁles to a memory card

Copy ﬁles from the internal memory to a memory card.

In Playback mode, press [

Select u  Copy to Card.

When the pop-up message appears, select Yes.

Page 80

Viewing photos or videos in Playback mode

Viewing photos

Enlarge part of a photo or view photos as a slide show.

Enlarging a photo

In Playback mode, rotate [Zoom] to the right to enlarge a portion of the photo. Rotate [Zoom] to the left to zoom out.

Enlarged area

Trim

Playback/Editing

To Description

Move the enlarged area

Press [D/c/F/t].

Press [o], and then select Yes .

Trim the enlarged photo

(The trimmed photo will be saved as a new ﬁle. The original photo is retained in its original form.)

When you view photos that were captured by another camera, the zoom ratio may differ.

Page 81

Viewing photos or videos in Playback mode

Viewing panoramic photos

View photos captured in Live Panorama mode.

In Playback mode, press [F/t] to scroll to a desired

panoramic photo.

•

The entire panoramic photo appears on the screen.

Press [o].

•

The camera automatically scrolls through the photo from left to right for a horizontal panoramic photo and from top to bottom for a vertical panoramic photo. The camera then switches to Playback mode.

•

While playing back a panoramic photo, press [o] to pause or resume.

•

After you have paused the playback of a panoramic photo, press [

D/c/F/t

vertically, depending on the direction you moved when capturing the photo.

Press [

The camera automatically scrolls through the panoramic photo only if the longest side of the photo is two or more times longer than the shortest side.

] to move the photo horizontally or

] to return to Playback mode.

Playback/Editing

Playing a slide show

Apply effects and audio to a slide show of your photos. The slide show function does not work for videos.

In Playback mode, press [

Select C.

Select a slide show effect option.

•

Skip to step 4 to start a slide show with no effects.

Option Description

Start

Images

Interval

Set whether or not to repeat the slide show. (Play, Repeat)

Set the photos you want to view as a slide show.

•

All*: View all photos in a slide show.

•

Date: View photos captured on a speciﬁc date in a slide show.

•

Select: View selected photos in a slide show.

•

Set the interval between photos. (1 sec*, 3 sec, 5 sec, 10 sec)

•

You must set the Effect option to Off to set the interval.

* Default

Page 82

Viewing photos or videos in Playback mode

Option Description

Music

Effect

Select Start  Play.

•

View the slide show.

•

Set background audio.

•

Set a scene change effect between photos. (Off*, Calm, Shine, Relax, Lively, Sweet)

•

Select Off to cancel effects.

•

When you use the Effect option, the interval between photos will be set to 1 second.

Select Repeat to loop the slide show.

Press [o] to pause the slide show. Press [o] again to resume the slide show.

•

Press [o], and then press [F/t] to stop the slide show and return to Playback mode.

•

Rotate [Zoom] to the left or right to adjust the volume level.

* Default

Playback/Editing

Playing a video

In Playback mode, you can view a video, and then capture parts of the playing video. You can save the captured segments as new ﬁles.

In Playback mode, select a video, and then press [o].

View the video.

Pause Stop

To Description

Scan backward

Pause or resume playback

Scan forward

Adjust the volume level

Press [F].

Press [o].

Press [t].

Rotate [Zoom] to the left or right.

Page 83

Viewing photos or videos in Playback mode

Capturing an image from video

While viewing a video, press [o] at the point where you

want to capture an image.

Press [c].

•

The resolution of the captured image will be the same as the original video.

•

The captured image is saved as a new ﬁle.

Playback/Editing

Page 84

Editing a photo

Learn how to edit photos.

•

The camera will save edited photos as new ﬁles.

•

When you edit photos, the camera will automatically convert them to a lower resolution. Photos that you rotate or resize manually are not automatically converted to a lower resolution.

•

You cannot edit the panoramic photos.

Resizing photos

Change the size of a photo and save it as a new ﬁle. You can also select a photo to be displayed when the camera turns on.

In Playback mode, select a photo, and then press

[

Select e  Resize.

Select an option.

•

Select Start Image to save the photo as a start image. (p. 99)

1984 X 1488

Back Move

Available resize options differ depending on the original size of the photo.

Playback/Editing

Rotating a photo

In Playback mode, select a photo, and then press

[

Select e  Rotate.

Select an option.

Right 90˚

Back Move

The camera will overwrite the original ﬁle.

Page 85

Editing a photo

Creating a close-up portrait

Extract the face of an individual subject from an existing photo.

In Playback mode, select a photo, and then

press [

Select e  Intelligent Portrait.

Select Save to crop the photo around the detected face.

•

2 cropped portraits are saved with consecutive ﬁle names.

Save

Back

The Intelligent Portrait feature will not function if:

- no face is detected

- more than 2 faces are detected

- the detected facial area is larger than a certain ratio

Move

Playback/Editing

Applying Smart Filter effects

Apply special effects to your photos.

In Playback mode, select a photo, and then press

[

Select e  Smart Filter.

Select an effect.

Miniature

Back

Icon Description

Normal: No effect

Miniature: Apply a tilt-shift effect to make the subject

appear in miniature.

Move

Page 86

Editing a photo

Icon Description

Vignetting: Apply the retro-looking colors, high contrast, and strong vignette effect of Lomo cameras.

Soft Focus: Hide facial imperfections or apply dreamy effects.

Old Film 1: Apply a vintage ﬁlm effect 1.

Old Film 2: Apply a vintage ﬁlm effect 2.

Half Tone Dot: Apply a halftone effect.

Sketch: Apply a pen sketch effect.

Fish-eye: Blacken the edges of the frame and distort

objects to imitate the visual effect of a ﬁsheye lens.

Defog: Make image clearer.

Classic: Apply a black and white effect.

Retro: Apply a sepia tone effect.

Negative: Apply a negative ﬁlm effect.

Playback/Editing

Adjusting your photos

Learn how to correct red-eye, adjust the skin tone, and adjust the brightness, contrast, or saturation. If the center of a photo is dark, you can adjust it to be brighter. The camera will save an edited photo as a new ﬁle, but may convert it to a lower resolution.

Adjusting dark subjects (ACB)

In Playback mode, select a photo, and then

press [

Select e  Image Adjust  ACB.

Press [o] to save your settings.

Page 87

Editing a photo

Removing red-eye

In Playback mode, select a photo, and then

press [

Select e  Image Adjust  Red-eye Fix.

Press [o] to save your settings.

Retouching faces

In Playback mode, select a photo, and then

press [

Select e  Image Adjust  Face Retouch.

Press [o].

Press [F/t] to adjust the skin tone.

•

As the number increases, the skin tone appears brighter and smoother.

Press [o] to save your settings.

Playback/Editing

Adjusting brightness, contrast, or saturation

In Playback mode, select a photo, and then

press [

Select e  Image Adjust.

Select an adjusting option.

Icon Description

Brightness

Contrast

Saturation

Press [o].

Press [F/t] to adjust the option.

Press [o] to save your settings.

Page 88

Editing a photo

Adding noise to the photo

In Playback mode, select a photo, and then

press [

Select e  Image Adjust  Add Noise.

Press [o] to save your settings.

Creating a print order (DPOF)

Select photos to print and save print options in the Digital Print Order Format (DPOF). This information is saved in the MISC folder on your memory card for convenient printing on DPOFcompatible printers.

In Playback mode, press [

Select u  DPOF  Standard  Select.

•

Select All to print all photos.

Playback/Editing

Scroll to a photo you want to print, rotate [Zoom] to the

left or right to select the number of copies, and then press [

•

If you select All, press [D/c] to select the number of copies, and then press [

Press [

Select u  DPOF  Size  Select.

•

Select All to choose the print size for all photos.

Scroll to a photo you want to print, rotate [Zoom] to the

left or right to select the print size, and then press [

•

If you select All, press [D/c] to select the print size, and then press [

Page 89

Editing a photo

Printing photos as thumbnails

Print photos as thumbnails to check all the photos at once.

In Playback mode, press [

Select u  DPOF  Index.

When the pop-up message appears, select Yes.

•

You can take the memory card to a print shop that supports DPOF (Digital Print Order Format) or you can print photos directly through a DPOF-compatible printer at home.

•

Photos with dimensions that are wider than the paper may be cut off on the left and right edges. Ensure that your photo dimensions are compatible with the paper you select.

•

You cannot set DPOF options for photos stored in the internal memory.

•

If you specify the print size, you can print photos only with DPOF 1.1-compatible printers.

Playback/Editing

Page 90

Viewing ﬁles on a TV

Play back photos or videos by connecting your camera to a TV with the A/V cable.

In Shooting or Playback mode, press [

Select n  Video Out.

Select the video signal output for your country or region.

(p. 102)

Turn off your camera and TV.

Connect your camera to your TV with the A/V cable.

VideoAudio

Playback/Editing

Turn on your TV, and then select the A/V video source

with the TV remote control.

Turn on your camera.

•

The camera automatically enters into Playback mode when you connect it to a TV.

View photos or play videos using the camera buttons.

•

Depending on the TV model, you may see some digital noise or part of an image may not appear.

•

Images may not be centered on the TV screen depending on your TV settings.

Page 91

Transferring ﬁles to your Windows computer

Transfer ﬁles to your Windows computer, edit them with Intelli-studio, and upload them to the web.

Requirements

Item Requirements

CPU

RAM

OS*

Hard disk capacity

Intel® Pentium®4 3.2 GHz or higher/ AMD Athlon™ FX 2.6 GHz or higher

Minimum 512 MB RAM (1 GB or more recommended)

Windows XP SP2, Windows Vista, or Windows 7 (32-bit editions)

250 MB or more (1 GB and above recommended)

•

CD-ROM drive

•

1024 X 768 pixels, 16-bit color display compatible monitor (1280 X 1024 pixels, 32-bit color display

Others

recommended)

•

USB 2.0 port

•

nVIDIA Geforce 7600GT or higher/ ATI X1600 series or higher

•

Microsoft DirectX 9.0c or higher

* A 32-bit version of Intelli-studio will be installed—even on 64-bit editions of

Windows XP, Windows Vista, and Windows 7.

Playback/Editing

•

The requirements are recommendation only. Intelli-studio may not work properly even when the computer meets the requirements, depending on the condition of your computer.

•

If your computer does not meet the requirements, videos may not play correctly or it may take longer to edit videos.

•

Install DirectX 9.0c or later before you use Intelli-studio.

•

Your computer must be running Windows XP, Windows Vista, or Windows 7 for you to connect the camera as a removable disk.

The manufacturer is not responsible for any damage that results from using unqualiﬁed computers such as a computer you assembled yourself.

Page 92

Transferring ﬁles to your Windows computer

Transferring ﬁles with Intelli-studio

You can download Intelli-studio from the linked webpage and install it on your computer. When you connect the camera to a computer with Intelli-studio installed, the program will launch automatically.

The battery will charge while the camera is connected to a computer with the USB cable.

In Shooting or Playback mode, press [

Select n  PC Software  On.

Turn off the camera.

Connect the camera to your computer with the

USB cable.

You must plug the small end of the USB cable into your camera. If the cable is reversed, it may damage your ﬁles. The manufacturer is not responsible for any loss of data.

Turn on the camera.

•

When the Intelli-studio installation pop-up appears on the computer screen, follow the on-screen instructions to complete the installation.

•

Once the Intelli-studio is installed on your computer, the computer recognizes the camera and launches the Intelli-studio automatically.

If you set the USB option to Select Mode, select Computer in the pop-up window.

Select a destination folder on your computer, and then

select Yes.

•

New ﬁles stored on the camera will automatically transfer to the selected folder.

•

If your camera has no new ﬁles, the pop-up window for saving new ﬁles will not appear.

For Windows Vista and Windows 7, select Run iLinker.exe from the Auto Play window to start Intelli-studio. If Run iLinker.exe does not appear on the computer, click Computer  Intelli-studio, and then follow the on-screen instructions to complete the Intelli-studio installation.

Playback/Editing

Page 93

Transferring ﬁles to your Windows computer

Using Intelli-studio

Intelli-studio allows you to play back and edit ﬁles. For details, select Help  Help from the program toolbar.

•

You can update the ﬁrmware of your camera by selecting Web Support  Upgrade ﬁrmware for the connected device from the program toolbar.

•

You cannot edit ﬁles directly on the camera. Transfer ﬁles to a folder on your computer before editing.

•

Intelli-studio supports the following formats:

- Videos: MP4 (Video: H.264, Audio: AAC), WMV (WMV 7/8/9), AVI (MJPEG)

- Photos: JPG, GIF, BMP, PNG, TIFF

543

6 7

Playback/Editing

Page 94

Transferring ﬁles to your Windows computer

No. Description

Open menus.

Display ﬁles in the selected folder.

Switch to the Photo edit mode.

Switch to the Video edit mode.

Switch to the Sharing mode (to send ﬁles by email or

upload ﬁles to websites, such as Flickr or YouTube).

Enlarge or reduce the thumbnails in the list.

Select a ﬁle type.

View ﬁles in the selected folder on your computer.

Show or hide ﬁles on the connected camera.

View ﬁles in the selected folder on the camera.

View ﬁles as thumbnails or on a map.

Browse folders stored on the camera.

Browse folders stored on your computer.

Move to the previous or next folder.

Print ﬁles, view ﬁles on a map, store ﬁles in My Folder, or

Playback/Editing

Transferring ﬁles by connecting the camera as a removable disk

Connect the camera to your computer as a removable disk.

In Shooting or Playback mode, press [

Select n  PC Software  Off.

Turn off the camera.

Connect the camera to your computer with the

USB cable.

You must plug the small end of the USB cable into your camera. If the cable is reversed, it may damage your ﬁles. The manufacturer is not responsible for any loss of data.

Page 95

Transferring ﬁles to your Windows computer

Turn on the camera.

•

The computer recognizes the camera automatically.

If you set the USB option to Select Mode, select Computer in the pop-up window.

On your computer, select My Computer 

Removable Disk  DCIM 100PHOTO.

Drag or save ﬁles to your computer.

Disconnecting the camera (for Windows XP)

With Windows Vista and Windows 7, the methods for disconnecting the camera are similar.

Verify that the status lamp is not blinking.

•

The status lamp blinks when transferring ﬁles. Wait until it stops.

Click on the tool bar at the bottom right of your

computer screen.

Click the pop-up message.

Click the message box that indicates the camera can be

removed safely.

Remove the USB cable.

The camera may not disconnect safely while Intelli-studio is running. End the program before disconnecting the camera.

Playback/Editing

Page 96

Transferring ﬁles to your Mac computer

When you connect the camera to a Macintosh computer, the computer will automatically recognize the device. You can transfer ﬁles directly from the camera to the computer without installing any programs.

Mac OS 10.4 or later is supported.

Turn off the camera.

Connect your camera to a Macintosh computer with the

USB cable.

You must plug the small end of the USB cable into your camera. If the cable is reversed, it may damage your ﬁles. The manufacturer is not responsible for any loss of data.

Playback/Editing

Turn on the camera.

•

The computer recognizes the camera automatically and displays a removable disk icon.

If you set the USB option to Select Mode, select Computer in the pop-up window.

Double-click the removable disk icon.

Drag or save ﬁles to your computer.

Page 97

Printing photos with a PictBridge photo printer

Print photos with a PictBridge-compatible printer by connecting your camera directly to the printer.

In Shooting or Playback mode, press [

Select n  USB  Printer.

Turn on the printer, and then connect your camera to the

printer with the USB cable.

If the camera is off, press [POWER] or [P] to turn it on.

•

The printer recognizes the camera automatically.

Press [F/t] to select a ﬁle to print.

•

Press [

See “Conﬁguring print settings”.

Press [o] to print.

•

Printing starts. Press [F] to cancel printing.

] to set printing options.

Playback/Editing

Conﬁguring print settings

Press [

] to conﬁgure print settings.

Images

Size

Layout

Type

Quality

Exit Print

Option Description

Images

Size

Layout

Type

Quality

Date Print

File Name

Reset

Some options may not be supported by some printers.

One Photo

Auto

Select whether to print the current photo or all photos.

Set the print size.

Set the number of photos to be printed on a single sheet of paper.

Set the type of paper.

Set the print quality.

Set to print the date.

Set to print the ﬁle name.

Reset settings to their default values.

Page 98

Settings

Refer to options to conﬁgure your camera’s settings.

Settings menu

Accessing the settings menu Sound Display Settings

………………………………………… 98

……………………… 98

……………………………………………… 99

……………………………………………… 100

Page 99

Settings menu

Learn to conﬁgure your camera's settings.

Accessing the settings menu

In Shooting or Playback mode, press [

Select a menu.

Shooting

Sound

Display

Settings

Exit Change

Option Description

Volume Start Sound Shutter Sound Beep Sound AF Sound

Sound: Set various camera sounds and the volume. (p. 99)

Display: Customize the display settings. (p. 99)

Settings: Customize the settings for the camera

system. (p. 100)

Select an item.

Volume Start Sound Shutter Sound Beep Sound AF Sound

Exit Back

Select an option.

Volume Start Sound Shutter Sound Beep Sound AF Sound

Back Set

Press [

Medium Off 1 1 On

Off Low Medium High

] to return to the previous screen.

Settings

Page 100

Settings menu

Sound

Item Description

Volume

Start Sound

Shutter Sound

Beep Sound

AF Sound

Set the volume of all sounds. (Off, Low, Medium*, High)

Set the sound the camera emits when you turn on your camera. (Off*, 1, 2, 3)

Set the sound the camera emits when you press the shutter button. (Off, 1*, 2, 3)

Set the sound the camera emits when you press the buttons or switch modes. (Off, 1*, 2, 3)

Set to emit a sound when you half-press the shutter button. (Off, On*)

* Default

Display

Item Description

Function Description

Start Image

Wallpapers

Date/Time Display

Settings

* Default

Display a brief description of an option or a menu. (Off, On*)

Set a start image to display when the camera turns on.

•

Off*: Display no start image.

•

Logo: Display a default image stored in the internal memory.

•

User Image: Select User Image from the photos you captured in the memory. (p. 83)

•

The camera will save only one User Image in the internal memory at a time.

•

If you select a new photo as a User Image or reset your camera, the camera will delete the current image.

Set a wallpaper image for the Mode and Menu screens.

Set whether or not to display the date and time on the camera's display. (Off*, On)

Samsung ECST76ZZBPBUS, EC-ST76ZZFBPSUS, EC-ST76ZZFBPBUS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Health and safety information

Basic troubleshooting

Quick reference

Contents

Basic functions

Unpacking

Camera layout

Inserting the battery and memory card

Charging the battery and turning on your camera

Charging the battery

Turning on your camera

Performing the initial setup

Learning icons

Selecting options or menus

Using [MENU]

Using [Fn]

Setting the display and sound

Setting the display type

Setting the sound

Capturing photos

Zooming

Reducing camera shake (OIS or DIS)

Tips for getting a clearer photo

Extended functions

Using the Smart Auto mode

Using the Program mode

Using the Live Panorama mode

Using the Picture-in-Picture mode

Using the Scene mode

Using the Magic Frame mode

Using the Beauty Shot mode

Using the Intelligent Portrait mode

Using the Funny Face mode

Using the Night mode

Using the Movie mode

Using the Smart Scene Detection mode

Shooting options

Selecting a resolution and quality

Selecting a resolution

Selecting an image quality

Using the timer

Shooting in the dark

Preventing red-eye

Adjusting the ISO sensitivity

Changing the camera’s focus

Using macro

Using auto focus

Using tracking auto focus

Adjusting the focus area

Using Face Detection

Detecting faces

Capturing a self portrait shot

Capturing a smile shot

Detecting eye blinking

Using Smart Face Recognition

Registering faces as your favorites (My Star)

Adjusting brightness and color

Adjusting the exposure manually (EV)

Compensating for backlighting (ACB)

Changing the metering option

Selecting a White Balance setting

Using burst modes

Applying effects/Adjusting images

Applying Smart Filter effects

Adjusting images

Playback/Editing

Viewing photos or videos in Playback mode

Starting Playback mode

Viewing photos

Playing a video

Editing a photo

Resizing photos

Rotating a photo

Creating a close-up portrait

Applying Smart Filter effects

Adjusting your photos
