SAMSUNG CS-15K8MJ0Q Service Manual Part List

Electrical Parts List

Samsung Electronics 7-1

ASSY COVER REAR

1 M0002 AA90-01975T ASSY COVER REAR;CS15K8X/BWT S.N.A ..2 T0015 AA64-01731G CABINET BACK;15K8,HIPS,V2,G4309

..2 T0214 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- S.N.A ..2 T0069 AA60-00091J SPACER-FEL T;-,FELT,330X10,-,-,BLK,T0.5,- S.N.A

ASSY COVER FRONT

1 M0001 AA90-03244L ASSY COVER FRONT;CS15K8MJ0X/BWT S.N.A ..2 T0081 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A

..2 AV+CF 6006-001095 SCREW-ASS’Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) S.N.A ..2 SC016 AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- S.N.A ..2 T0081 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, S.N.A ..2 T0003 AA91-00619U ASSY CABINET FRONT;15K8,(SPK),CIS,S907P+ ...3 T0081 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0081 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0081 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0607 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- S.N.A ...3 CIS7 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, S.N.A ...3 T0238 AA64-00816B WINDOW REMOCON;-,21A8,-,PC,V0,VIOLET,- S.N.A ...3 T0059 AA64-00818B INDICATOR LED;21A8,ACRYL,-,CLR,-,-,...3 T0578 AA64-01303C INLAY AV;21A8,PS SHEET,T0.3,ISC-00061S,M S.N.A ...3 T0022 AA64-01370B KNOB CONTROL;15K8,ABS,-,-,-,HB,G3676,-,S ...3 T0023 AA64-01371B KNOB POWER;15K8,ABS,-,-,-,HB,G3676,-,SV9 ...3 CIS3 AA64-01730V CABINET FRONT;15K8,HIPS,HB,G4309,S907P+D S.N.A ...3 T0057 AA64-70127A BADGE-BRAND;ALL,AL,T1.4,6.3,L40,SAMSUNG, S.N.A ...3 AA65-00011C CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A ...3 AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A ...3 T0522 AA96-10137B ASSY SPEAKER;-,8OHM,3W,3001-001020,AA39- S.N.A

....4 T0082 3001-001020 SPEAKER;3W,8OHM,90DB,140HZ

....4 T0245 AA39-20505M LEAD CONNECTOR-ASSY;,4P,350,700MM,YSH025

ASSY FIXING

1 AA91-06700A ASSY FIXING;KS1A,MAC,THE OTHERS,CP2 S.N.A ..2 T0245 AA39-20010D LEAD CONNECTOR-ASSY;,1P,400,YFH800-01,S,

..2 AA65-30009A CLAMPER CORE-FBT;-,ABS,V0,-,BLK,- S.N.A ..2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A ..2 CLAMP AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, S.N.A ..2 AA65-30111A CLAMPER CORE-WIRE;ALL MODEL,NYLON,V0,-,W S.N.A ..2 T0066 AA96-20109B ASSY POWER CORD;-,CP2/NO(4.0),H/C250,KKP S.N.A ...3 3811-000401 WIRE-PVC CU;BCWA,300V,ROLL,17/0.16mm,#22 S.N.A ...3 T0077 AA39-10006X CBF POWER CORD;-,KKP419C,KLCE-2F,2.286MT ...3 AA61-20284A HOLDER;P-CORD,PP,-,-,-,BLK,VO,KE-002 S.N.A ..2 AA61-01364A HOLDER-COVER;KS1A,NYLON66,BLK,V2 S.N.A

ASSY CHASSIS

1 M0017 AA91-07012A ASSY CHASSIS;CTV S.N.A ..2 T0073 AA94-13425A ASSY PCB MAIN;CTV

...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A ...3 T0090 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P ,BK,8...3 IC112 1103-001106 IC-EEPROM;C81DC,1028x8Bit,DIP,8P,300MIL, ...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T ...3 P803T 1404-001265 THERMISTOR-PTC;4.5OHM/100OHM,+30/-20%,22

...3 C598 2201-000446 C-CERAMIC,DISC;3.3NF,20%,400V,Y5U,BK,15X ...3 CR410S 2301-001456 C-FILM,LEAD-OTHER;5.1NF,5%,1.6KV,BK,29X9 ...3 CX801S 2306-000318 C-FILM,LEAD-PPF;220NF,20%,250V,BK,-,22.5 ...3 CR402S 2306-000350 C-FILM,LEAD-PPF;270NF,5%,400V,BK,26X18.5 ...3 C701 2401-002213 C-AL;150uF,+30-10%,450V,GP,BK,25x35 ...3 SF101S 2904-001063 FILTER-SA W AV;38.9MHz,SIP5K,TP,18.5dB,B/ ...3 SW801S 3403-001134 SWITCH-PUSH;250V,5A,DPST,ON-OFF,...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V,4A,TIME-LAG,GLASS,5. ...3 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,...3 CN906 3711-000628 CONNECTOR-HEADER;BOX,11P ,1R,2.5MM,STRAIG ...3 JS701 3722-000497 JACK-PIN;4P,3.4mm,SN,BLK,...3 T0119 AA09-00354A IC MICOM;TDA9381/N2/3I,SPM-802EEN4,64P,3 ...3 T801S AA26-00134A TRANS SWITCHING;,CS21S5T,160V~260V,PM2 P ...3 T0616 AA26-00201A TRANS FBT;FCA173B,KS1A-1,3.8mH,FERRITE,1 ...3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH, ...3 T0296 AA27-00122A COIL LINEARITY;90UH,90UH,L81 DR10x10,7.5 ...3 LX801S AA29-30001B FILTER LINE NOISE;-,-,-,-,27MH,-,-,-,ST, ...3 RM901 AA32-00015A MODULE REMOCON;FRP-3521H31,38KHZ,940MM,M ...3 T0245 AA39-20620C LEAD CONNECTOR-ASSY;,9P,500MM,YBNH250-09 ...3 TU01S AA40-00077A TUNER;TECC0949PL35A(S),PAL,181CH,38.9MHZ ...3 GT301 AA60-40012D PIN-GT,ASSY;T1.6,6-12.5-,NYLON66 S.N.A ...3 IC801S AA96-00242D ASSY H/S;SCREWAA62-30186B,5Q0765RTH,OIL S.N.A

....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A

....4 T0086 1203-002916 IC-PWM CONTROLLER;KA5Q0765RTH-YDTU,TO-22

....4 T0081 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW S.N.A

....4 CIS AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H S.N.A

....4 CIS AA63-30189A COVER-HEATSINK;-,PC-ABS,T0.8,-,-,V0,NTR, S.N.A

...3 D806 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,DR S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 T0083 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 AA62-00045A HEA T SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A

...3 IC601 AA96-00244G ASSY H/S;-,AUDIO,AA62-00046A,TDA8944J,BR S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 T0085 1201-001741 IC-AUDIO AMP;TDA8944J,DBS,17P,937MIL,DUA

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 AA61-10162B BRACKET-IC;-,SBHG-1,T1.0,-,-,-,100 S.N.A

....4 AA62-00046A HEA T SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A

...3 IC301 AA96-00244M ASSY H/S;SCREWAA64-00046A,LA78040N,OIL S S.N.A

....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A

....4 T0088 1204-002121 IC-VERTICAL DEF.;LA78040N,TO220,7P,-,PLA

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 CIS AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A

...3 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,- S.N.A

....4 T0087 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI

....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

....4 AA62-00055A HEA T SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-, S.N.A

...3 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A ...3 IC501 AA96-50311A ASSY H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A

....4 T0074 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA

....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

....4 AA62-30175D HEA T SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A

...3 AA97-14287A ASSY AUTO-MAIN;CS15K50S/NWT S.N.A

....4 D201 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D811 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D901 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D804 0401-000006 DIODE-SWITCHING;BAV21,250V ,200MA,DO-35,T

....4 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP

....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T

7-1 CS15K8MJ0X/BWT

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

7. Electrical Parts List

You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr

....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP,600V,1.5A,-,TP

....4 T0083 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,TO-220F,TP

....4 T0083 0402-001352 DIODE-RECTIFIER;GUF15G-20A,400V,1.5A,MEL

....4 T0083 0402-001443 DIODE-RECTIFIER;EGP20K,800V,2A,TO-220F,T

....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO

....4 DZ016 0403-000700 DIODE-ZENER;TZP33A,5%,1000MW,DO-41,TP

....4 DZ016 0403-000720 DIODE-ZENER;MTZJ9.1B,8.57-9.01V,500MW,DO

....4 DZ016 0403-001140 DIODE-ZENER;RD10ESAB-T4,9.7-10.2V,400MW,

....4 DZ016 0403-001221 DIODE-ZENER;UZ39BSB,35.36-37.19V,500MW,D

....4 DZ016 0403-001317 DIODE-ZENER;MTZJ3.0B,3.01-3.22V,500MW,DO

....4 DZ016 0403-001318 DIODE-ZENER;MTZJ4.3B,4.17-4.43V,500MW,DO

....4 DZ016 0403-001319 DIODE-ZENER;MTZJ4.7C,4.68-4.93V,500MW,DO

....4 DZ016 0403-001322 DIODE-ZENER;MTZJ8.2B,7.78-8.19V,500MW,DO

....4 DZ016 0403-001327 DIODE-ZENER;MTZJ18A,16.22-17.06V,500MW,D

....4 DZ016 0403-001328 DIODE-ZENER;MTZJ22A,20.15-21.2V,500MW,DO

....4 T0156 0501-000283 TR-SMALL SIGNAL;KSA539,PNP,400mW,TO-92,T

....4 T0156 0501-000369 TR-SMALL SIGNAL;KSC2331-Y,NPN,1000mW,TO-

....4 T0156 0501-000389 TR-SMALL SIGNAL;KSC815,NPN,400mW,TO-92,T

....4 Q902 0504-001159 TR-DIGITAL;SRC1211M,NPN,400MW ,10KOHM,TO-

....4 Q703 0504-001159 TR-DIGITAL;SRC1211M,NPN,400MW ,10KOHM,TO-

....4 VX801S 1405-000187 VARISTOR;750V,1250A,12.5x7mm,TP

....4 R125 2001-000004 R-CARBON;200KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000005 R-CARBON;390ohm,5%,1/8W,AA,TP ,1.8x3.2mm

....4 R125 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000011 R-CARBON;75KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R075 2001-000016 R-CARBON(S);1OHM,5%,1/2W,AA,TP ,2.4X6.4MM

....4 R075 2001-000019 R-CARBON(S);10OHM,5%,1/2W,AA,TP ,2.4X6.4M

....4 R075 2001-000022 R-CARBON(S);33OHM,5%,1/2W,AA,TP ,2.4X6.4M

....4 R075 2001-000037 R-CARBON(S);330OHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R125 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000258 R-CARBON;1.8KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000319 R-CARBON;120KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000325 R-CARBON;120OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000563 R-CARBON;27KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000591 R-CARBON;3.3KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000645 R-CARBON;330KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000689 R-CARBON;390KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000739 R-CARBON;4.7MOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000878 R-CARBON;6.2KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000947 R-CARBON;7.5KOHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-000969 R-CARBON;75OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R125 2001-001006 R-CARBON;82OHM,5%,1/8W,AA,TP ,1.8X3.2MM

....4 R075 2001-001037 R-CARBON(S);0.39OHM,5%,1/2W,AA,TP ,2.4X6.

....4 R075 2001-001062 R-CARBON(S);10MOHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R075 2001-001078 R-CARBON(S);15KOHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R075 2001-001088 R-CARBON(S);1KOHM,5%,1/2W,AA,TP ,2.4X6.4M

Electrical Parts List

7-2 Samsung Electronics

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

Electrical Parts List

Samsung Electronics 7-3

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

....4 R075 2001-001108 R-CARBON(S);22KOHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R075 2001-001114 R-CARBON(S);270OHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R075 2001-001116 R-CARBON(S);27OHM,5%,1/2W,AA,TP ,2.4X6.4M

....4 R075 2001-001122 R-CARBON(S);3.9KOHM,5%,1/2W,AA,TP ,2.4X6.

....4 R075 2001-001138 R-CARBON(S);390OHM,5%,1/2W,AA,TP ,2.4X6.4

....4 R075 2001-001150 R-CARBON(S);470KOHM,5%,1/2W,AA,TP ,2.4X6.

....4 R503 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP ,3.7

....4 R502H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7

....4 R501H 2002-001008 R-COMPOSITION;1.8Kohm,10%,1/2W,AA,TP,3.7

....4 RX801S 2002-001011 R-COMPOSITION;3.3Mohm,5%,1/2W,AA,TP,3.7x

....4 RY801S 2002-001012 R-COMPOSITION;8.2Mohm,5%,1/2W,AA,TP,3.7x

....4 R413 2003-000592 R-METAL OXIDE(S);22ohm,5%,2W,AF,TP,4x12m

....4 R827 2003-000998 R-METAL OXIDE;300ohm,5%,2W,AF,TP,3.9x10m

....4 R802 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x

....4 R834 2003-001040 R-METAL OXIDE(S);47Kohm,5%,2W,AF,TP,3.9x

....4 R403 2003-001093 R-METAL OXIDE(S);12Kohm,5%,2W,AF,TP,3.9x

....4 R316 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x

....4 R315 2003-002009 R-METAL OXIDE(S);390ohm,5%,2W,AF,TP,3.9x

....4 R303 2003-002152 R-METAL OXIDE;1OHM,5%,2W,AG,TP,6X16MM

....4 R402 2003-002178 R-METAL OXIDE(S);1Kohm,5%,2W,AG,TP,3.9x1

....4 R407 2003-002209 R-METAL OXIDE(S);47Kohm,5%,2W,AG,TP,3.9X

....4 R811 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9

....4 R812 2003-002239 R-METAL OXIDE(S);100KOHM,5%,2W,AF,TP,3.9

....4 R024 2004-001371 R-METAL(S);1.5Kohm,1%,1/2W,AA,TP,2.4x6.4

....4 R024 2004-001402 R-METAL(S);6.8Kohm,1%,1/2W,AA,TP,2.4x6.4

....4 R219 2004-001914 R-METAL;39Kohm,2%,1/8W,AA,TP,1.8x3.5mm

....4 R024 2004-002011 R-METAL(S);110Kohm,1%,1/2W,AA,TP,2.4x6.4

....4 R024 2004-004089 R-METAL(S);123Kohm,1%,1/2W,AA,TP,2.5x6.5

....4 R305 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m

....4 R304 2008-000253 R-FUSIBLE(S);0.47ohm,5%,1W,AF,TP,3.9x10m

....4 R825 2008-000284 R-FUSIBLE(S);0.1OHM,10%,2W,AF,TP,3.9X10M

....4 R824 2008-000294 R-FUSIBLE(S);33ohm,5%,2W,AF,TP,3.9x10mm

....4 R815 2008-001087 R-FUSIBLE(S);1.8ohm,5%,2W,AG,TP ,3.9x12mm

....4 R814 2008-001087 R-FUSIBLE(S);1.8ohm,5%,2W,AG,TP ,3.9x12mm

....4 R421 2008-001109 R-FUSIBLE(S);0.18ohm,10%,2W,AG,TP ,3.9x12

....4 R420 2008-001110 R-FUSIBLE(S);68ohm,5%,2W,AG,TP ,3.9X12mm

....4 R505 2008-001135 R-FUSIBLE(S);3.9ohm,5%,1W,AF,TP,3.9x10mm

....4 C598 2201-000259 C-CERAMIC,DISC;0.18NF,10%,500V,Y5P ,TP,5.

....4 C598 2201-000556 C-CERAMIC,DISC;0.47NF,10%,500V,Y5P ,TP,5.

....4 C598 2201-000573 C-CERAMIC,DISC;0.047NF,5%,50V,C0G,TP ,5X3

....4 C598 2201-000599 C-CERAMIC,DISC;0.56NF,10%,500V,Y5P ,TP,5.

....4 C598 2201-000611 C-CERAMIC,DISC;0.056NF,5%,50V,C0G,TP ,7X3

....4 C598 2201-000639 C-CERAMIC,DISC;0.68NF,10%,2KV,Y5P ,TP,9X5

....4 C598 2201-000723 C-CERAMIC,DISC;4.7NF,20%,3KV,Y5U,TP ,16X5

....4 C598 2201-000991 C-CERAMIC,DISC;0.56NF,10%,2KV,Y5P ,TP,7.5

....4 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P ,TP

....4 C689 2202-000127 C-CERAMIC,MLC-AXIAL;10nF,+80-20%,25V,Y5V

....4 C689 2202-000210 C-CERAMIC,MLC-AXIAL;270pF,10%,50V,Y5P ,TP

....4 C689 2202-000279 C-CERAMIC,MLC-AXIAL;47pF,5%,50V,SL,TP ,3.

....4 C689 2202-000632 C-CERAMIC,MLC-AXIAL;100nF,20%,50V,Z5U,TP

....4 C689 2202-000796 C-CERAMIC,MLC-AXIAL;1NF,10%,50V,Y5P ,TP,3

....4 C689 2202-000829 C-CERAMIC,MLC-AXIAL;0.82NF,10%,50V,Y5P ,T

....4 C2560 2301-000004 C-FILM,LEAD-PEF;2.2nF,5%,100V ,TP,5.5X10X

....4 C2560 2301-000013 C-FILM,LEAD-PEF;4.7nF,5%,100V ,TP,10.5x12

....4 C2560 2301-000014 C-FILM,LEAD-PEF;6.8nF,5%,100V ,TP,5.8x12.

....4 C2560 2301-000016 C-FILM,LEAD-PEF;22nF,5%,100V ,TP,7.2x4.5x

....4 C2560 2301-000148 C-FILM,LEAD-PEF;10nF,5%,100V ,TP,7x3.2x7m

....4 C2560 2301-000204 C-FILM,LEAD-PEF;2.7nF,5%,50V ,TP,7.4x3.9x

....4 C2560 2301-000213 C-FILM,LEAD-PEF;220nF,5%,250V ,TP,21.5x11

....4 C2560 2301-000233 C-FILM,LEAD-PEF;3.9nF,10%,100V ,TP,5.8x12

....4 C2560 2301-000253 C-FILM,LEAD-PEF;39NF,5%,100V ,TP,7.5X4.5X

....4 C2560 2301-000314 C-FILM,LEAD-PEF;8.2nF,5%,50V ,TP,6.5x3.0x

....4 C420 2301-001065 C-FILM,LEAD-PPF;47nF,5%,630V,TP ,19x15.5x

....4 C806 2301-001435 C-FILM,LEAD-PPF;1.5nF,5%,1.2kV,TP ,15x8x1

....4 C225 2301-001664 C-FILM,LEAD-OTHER;100nF,3%,50V,TP ,20x16x

....4 C2560 2305-000149 C-FILM,LEAD-PEF;100nF,5%,100V ,TP,12x12.5

....4 C2560 2305-000285 C-FILM,LEAD-PEF;220NF,5%,100V ,TP,10.5X5.

....4 C2560 2305-000289 C-FILM,LEAD-PEF;220nF,5%,63V ,TP,-,5mm

....4 C2560 2305-000382 C-FILM,LEAD-PEF;4.7nF,5%,400V ,TP,-,5mm

....4 C2560 2305-000412 C-FILM,LEAD-PEF;470nF,5%,63V ,TP,-,5mm

....4 C2560 2305-000665 C-FILM,LEAD-PEF;100nF,5%,63V ,TP,7.5x4.0x

....4 C701 2401-000025 C-AL;100uF,20%,16V,GP ,TP,6.3x11,5

....4 C701 2401-000050 C-AL;10uF,20%,16V,GP ,TP,5x11,2.5

....4 C701 2401-000262 C-AL;100uF,20%,160V,HR,TP ,16x25,7.5

....4 C701 2401-000302 C-AL;100uF,20%,25V,GP ,TP,6.3x11,5

....4 C701 2401-000360 C-AL;100uF,20%,50V,GP ,TP,8x11.5,5

....4 C701 2401-000365 C-AL;100uF,20%,50V,WT,TP,10x12.5mm,

....4 C701 2401-000430 C-AL;10uF,20%,250V,GP ,TP,10x16mm,5m

....4 C701 2401-000471 C-AL;10uF,20%,50V,BP ,TP,5x11,5mm

....4 C701 2401-000480 C-AL;10uF,20%,50V,GP ,TP,5x11,5

....4 C701 2401-000481 C-AL;10uF,20%,50V,WT,TP,5x11,5

....4 C701 2401-000560 C-AL;1uF,20%,160V,GP ,TP,6.3x11,5

....4 C701 2401-000603 C-AL;1UF,20%,50V,GP ,TP,5X11,2

....4 C701 2401-000649 C-AL;2.2uF,20%,50V,BP ,TP,5x11,5

....4 C701 2401-000660 C-AL;2.2uF,20%,50V,GP ,TP,5x11,5

....4 C701 2401-000722 C-AL;2200uF,20%,25V,WT,TP,16x25,7.5

....4 C701 2401-000758 C-AL;0.22UF,20%,50V,GP ,TP,5X11,5

....4 C701 2401-000913 C-AL;22uF,20%,16V,GP ,TP,5x11,5

....4 C701 2401-000927 C-AL;22uF,20%,250V,GP ,TP,13x20,5

....4 C701 2401-000962 C-AL;22uF,20%,50V,GP ,TP,5x11,5

....4 C701 2401-001101 C-AL;330uF,20%,16V,GP ,TP,8x11.5,5

....4 C701 2401-001176 C-AL;33uF,20%,25V,GP ,TP,5x11,5

....4 C701 2401-001192 C-AL;33uF,20%,50V,GP ,TP,6.3x11,5

....4 C701 2401-001232 C-AL;4.7uF,20%,250V,GP ,TP,10x12.5,5

....4 C701 2401-001486 C-AL;47uF,20%,160V,HR,TP ,13x20mm,5m

....4 C701 2401-001989 C-AL;4.7uF,20%,50V,BP ,TP,5x11,5

....4 C701 2401-001998 C-AL;1000uF,20%,25V,GP ,TP,10x20,5mm

....4 C701 2401-002288 C-AL;470uF,20%,25V,WT,TP,10x20,5

....4 C701 2401-002619 C-AL;47uF,20%,25V,GP ,TP,5x11,5

....4 C701 2401-003028 C-AL;100uF,20%,25V,WT,TP,6.3x11,5

....4 L904 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534

....4 L902 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534

....4 L202 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534

....4 L103 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534

....4 J142 2701-000115 INDUCTOR-AXIAL;10uH,10%,3070

....4 L404 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534

....4 L302 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534

....4 L301 2701-000142 INDUCTOR-AXIAL;1uH,10%,2534

....4 L903 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534

....4 L205 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534

....4 L201 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534

....4 L405 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298

....4 L102 2701-000159 INDUCTOR-AXIAL;22uH,10%,4298

....4 L104 2701-000168 INDUCTOR-AXIAL;3.3uH,5%,2534

....4 L706 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534

....4 L703 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534

....4 L204 2701-000184 INDUCTOR-AXIAL;4.7uH,10%,2534

....4 L804 2701-001030 INDUCTOR-AXIAL;43uH,10%,4514

....4 Z202 2903-001240 FILTER-CERAMIC;TR,5.5MHz,-,28dB,-,TP,-

....4 Z203 2903-001246 FILTER-CERAMIC;TR,5.5MHz,-,-,-,TP,multi.

....4 L2514 3301-000287 BEAD-AXIAL;,3.5x1.0x6.0mm,3000mA,TP,,,50

....4 SW905 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1

....4 SW904 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1

....4 SW903 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1

....4 SW902 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1

....4 SW901 3404-001252 SWITCH-TACT;12VDC,50MA,130GF,7.5X7.1,1

....4 FD801S 3601-001163 FUSE-AXIAL LEAD;125V,7A,-,EPOXY,2.4X7.1M

....4 F801A 3602-000114 FUSE-HOLDER;-,-,30mohm

....4 F801B 3602-000114 FUSE-HOLDER;-,-,30mohm

....4 CN906 3711-002643 CONNECTOR-HEADER;BOX,4P,1R,2.5mm,STRAIGH

....4 EL804 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A

....4 EL802 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A

....4 EL801 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A

....4 EL404 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A

....4 EL403 6042-000001 EYELET;ID2.2,OD2.7,L3.1,NI+SN,BSP3-1/2H S.N.A

....4 EY819 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY821 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY822 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY823 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY824 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY818 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY807 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY808 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY809 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY810 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY813 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY825 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY851 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY852 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY853 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY860 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY861 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY850 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY827 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY828 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY829 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY830 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY833 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY803 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY406 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY407 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY408 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY409 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY410 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY405 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY101 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY401 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY402 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY403 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY404 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY411 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY422 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY423 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY501 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY801 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY802 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY420 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY412 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY414 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY415 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY416 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 EY419 6042-000002 EYELET;ID1.5,OD2,L2.8,NI+SN,BSP3-1/2H S.N.A

....4 FIX02 AA37-00001A CONNECTOR-FBT FIX PIN;JM-3500,CPTTV,0.36

....4 FIX01 AA37-00001A CONNECTOR-FBT FIX PIN;JM-3500,CPTTV,0.36

....4 GT803 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT804 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT805 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT806 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT807 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT101 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT501 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT502 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT801 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 GT802 AA60-40014A PIN-GT,ASSY;AUTO S.N.A

....4 0 AA41-00849B PCB MAIN;CS21D8,FR-1,1L,B,1.6T,245*245,M S.N.A

....4 F101 2901-000297 FILTER-EMI ON BOARD;-,3A,-,-,3.5x5,TP,-

...3 X901 2801-004033 CRYSTAL-UNIT;12MHZ,30PPM,28-AAM,30PF,30O ..2 T0006 AA95-01724A ASSY SUB-A/V ,FRONT;S4,KS1A,MONO,AA95-014 ...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A ...3 JE601 3722-000143 JACK-PHONE;1P(VER),3.4PI,AG,BLK,NO ...3 JR01 3722-001282 JACK-PIN;2P(3P),3.2mm,AU,BLK,...3 T0245 AA39-20461C LEAD CONNECTOR-ASSY;,11P,300MM,YBNH250-1 ...3 AA97-07134A ASSY AUTO-A/V FRONT;-S4,KS1A,PAL,AA95-01 S.N.A

....4 R075 2001-001153 R-CARBON(S);47OHM,5%,1/2W,AA,TP ,2.4X6.4M

....4 C689 2202-000121 C-CERAMIC,MLC-AXIAL;100pF,10%,50V,Y5P ,TP

....4 C689 2202-000222 C-CERAMIC,MLC-AXIAL;3.3nF,20%,16V,Y5P ,TP

....4 C701 2401-000025 C-AL;100uF,20%,16V,GP ,TP,6.3x11,5

....4 LE04 2701-000114 INDUCTOR-AXIAL;10uH,10%,2534

....4 LE01 2701-000158 INDUCTOR-AXIAL;22uH,10%,2534

....4 PCB AA41-00568A PCB-FRONT AV;S4/C5,FR-1,1L,A,1.6T,245X24 S.N.A

ASSY CPT

1 T0521 AA91-07346E ASSY CPT;15 SDI FLAT,BARE,EUROPE,+380MG S.N.A ..2 T0089 AA27-00252A COIL DEGAUSSING;,15INCH,10%,70TS,4.5OHM,

..2 T0527 AA65-30107A CLAMPER CORE-D,COIL;20~22 INCH,NYLON 66, S.N.A ..2 T0521 AA91-02166K ASSY CPT;A36QDT351X,15,+380MG,BARE,SMV- S.N.A ...3 T0063 AA03-00146A CRT COLOR;A36QDT351X,380MG,2.5MH,22.5MH, ...3 T0079 AA27-00002A MAGNET CONVERGENCE;JH291-SC-OB,29.1MM,-, ...3 T0078 AA27-00161A DEFLECTION YOKE;,CDY-MT1501A,S/T,A36QDT3 ...3 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1 S.N.A ..2 AA98-70014G ASSY TBC WIRE(P);-,15inch,NTSC,1P,KS2A/C S.N.A

ASSY P/MATERIAL

1 AA92-03065Y ASSY P/MATERIAL;15K8 S.N.A ..2 6902-000001 BAG AIR;LDPE,T0.2,L1800,W1000,TRP,,,LDPE S.N.A

..2 6902-000004 BAG PE;HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 S.N.A ..2 6902-000061 BAG AIR;LDPE,T0.2,L1000,W500,TRP,,, S.N.A ..2 T0214 AA60-40006A PIN-STAPLE;AUTO,33X17.8X2.4,H18,33X17.8X S.N.A

ASSY ACCESSORY

1 M0245 AA92-03223A ASSY ACCESSORY;CS15K8X/BWT S.N.A ..2 T0080 AA26-90001C TRANS MATCHING;-,300ohm/75ohm,PAL,40-890

..2 T0075 AA42-00003A ANT ROD;-,3S,720mm,ABS,UL/CSA,..2 T0074 AA59-00198F REMOCON;,TM59,DREAM,24,L/GRAY ,MONO,P AL-T ..2 T0289 AA63-00239C COVER-AV;21A8,HIPS,-,-,-,HB,G4309,SV907P ..2 T0269 AA68-01120A MANUAL SERVICE;-,-,CIS,A4,6PAGE(FOLD),W/ S.N.A ..2 AA68-01402A MANUAL-GOOD WILL LETTER;,CIS,B5,1PAGE,A/ S.N.A ..2 6902-000009 BAG PE;HDPE,T0.03,L400,W240,TRP,8,2,PE M S.N.A ..2 AA68-00816B CARD WARRANTY-01;,RUSSINA,2,W/P 120G,BOT S.N.A ..2 6801-001073 CARD-REGISTRATION;RUS,XEV,RUS,MOJO100,-, S.N.A

Electrical Parts List

7-4 Samsung Electronics

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

Electrical Parts List

Samsung Electronics 7-5

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

..2 M0148 AA68-01296E MANUAL USERS-05;15K2/15K9,RUS,W/P100G,KS

ASSY COVER REAR

1 M0002 AA90-03293E ASSY COVER REAR;20H4,HB,BLK,KS1A,RCA4P S.N.A ..2 T0081 6003-001026 SCREW-T APTITE;RH,+,B,M4,L15,ZPC(BLK),SWR S.N.A

..2 T0069 AA60-00091J SPACER-FEL T;-,FELT,330X10,-,-,BLK,T0.5,- S.N.A ..2 T0081 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, S.N.A ..2 T0015 AA64-01029G CABINET BACK;20H4,HIPS,HB,BLK ..2 T0214 AA65-30008A CLAMPER CORE-CORD;-,PE,HB,-,BLK,- S.N.A

ASSY COVER FRONT

1 M0001 AA90-04621E ASSY COVER FRONT;CS20H4MJ0X/RCH S.N.A ..2 T0081 6003-001268 SCREW-T APTITE;TH,+,B,M4,L12,ZPC(YEL),SWR

..2 SC016 AA60-10050R SCREW-ASSY;-,SWRCH18A,M5,L31.5,HH,+,WC,- S.N.A ..2 T0003 AA96-00957F ASSY COVER P-C/FRONT;20H4,HIPS HB,BLK,SP ...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0081 6003-001019 SCREW-T APTITE;RH,+,B,M4,L12,ZPC(BLK),SWR ...3 T0607 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- S.N.A ...3 CIS7 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, S.N.A ...3 T0578 AA64-01309Q INLAY AV;PS SHEET,21D8,T0.3,S15A MONO GO S.N.A ...3 T0003 AA64-02796G CABINET-FRONT;20H4,HIPS,HB,BLK,BK708P,EG S.N.A ...3 T0023 AA64-02799A KNOB-POWER;20H4,ABS,HB,BLK,NO-SILK ...3 T0022 AA64-02801A KNOB-CONTROL;20H4,ABS,HB,BLK ...3 T0299 AA64-02803A WINDOW-RMC,LED;20H4,ACRYL,CLR S.N.A ...3 T0057 AA64-70123D BADGE-BRAND;-,AL,-,-,L=50,SAMSUNG,GOLD,R S.N.A ...3 AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, S.N.A ...3 T0522 AA96-10146C ASSY SPEAKER;-,8ohm,5W ,3001-000274,350/7 S.N.A

....4 T0082 3001-000274 SPEAKER;5W,8OHM,90DB,160HZ

....4 T0245 AA39-20505M LEAD CONNECTOR-ASSY ;,4P,350,700MM,YSH025

...3 T0156 AA61-00721C HOLDER-RAIL;H4,HIPS,V0,GRAY S.N.A ..2 T0527 AA65-30107A CLAMPER CORE-D,COIL;20~22 INCH,NYLON 66, S.N.A

ASSY CPT

1 T0521 AA91-06623A ASSY CPT;CB20V10MJA0XXST,KS1A,MAC S.N.A ..2 T0521 AA91-04028A ASSY CPT;CS20H2X/SMA,MALAYSIA,0MG S.N.A

...3 T0063 AA03-10029X CRT COLOR;A48KRD82X(H),0MG,2.20MH,30.0MH ...3 T0079 AA27-00002A MAGNET CONVERGENCE;JH291-SC-OB,29.1MM,-, ...3 T0078 AA27-50004W DEFLECTION YOKE;,DSE-1992LL(1H),PCL,A48K ...3 AA63-60028A SPACER-DY;-,NEOPRENE,-,-,-,BLK,-,-,V0 W1 S.N.A ..2 AA98-70014B ASSY TBC WIRE(P);-,20,NTSC,1P,- S.N.A ..2 T0089 AA27-00254A COIL DEGAUSSING;,20INCH,10%,70TS,4.5OHM,

ASSY CHASSIS

1 M0017 AA91-06733L ASSY CHASSIS;CS20H4MJ0X/RCH,KS1A S.N.A ..2 T0073 AA94-13232L ASSY PCB MAIN;CS20H4MJ0X/RCH,KS1A,MAC

...3 0202-000187 SOLDER-WIRE FLUX;-,RS60S,D1.2,63Sn/37Pb S.N.A ...3 T0090 0502-001160 TR-POWER;2SD2499,NPN,50000mW,TO-3P,BK,8...3 PC801S 0604-001032 PHOTO-COUPLER;TR,170-260%,300mW,DIP-4,ST ...3 IC112 1103-001106 IC-EEPROM;C81DC,1028x8Bit,DIP,8P,300MIL, ...3 IC101 1204-001583 IC-IF CIRCUIT;U4468B,DIP,16P,-,PLASTIC,5 ...3 NT802S 1404-001045 THERMISTOR-NTC;4.7ohm,15%,2900K,35.0mW,T ...3 P803T 1404-001265 THERMISTOR-PTC;4.5OHM/100OHM,+30/-20%,22 ...3 C598 2201-000446 C-CERAMIC,DISC;3.3NF ,20%,400V,Y5U,BK,15X ...3 CR402S 2306-000195 C-FILM,LEAD-PPF;360NF,5%,400V ,BK,26X19X1 ...3 CX801S 2306-000318 C-FILM,LEAD-PPF;220NF,20%,250V ,BK,-,22.5 ...3 CR410S 2306-000327 C-FILM,LEAD-PPF;6.3nF,3%,1.6KV ,TP,28.5x1

...3 C701 2401-003339 C-AL;220uF ,20%,400V,GP,BK,30x35,10 ...3 SF101S 2904-001143 FILTER-SAW AV;38.9MHz,SIP5K,ST,18dB,B/G, ...3 SF102S 2904-001224 FILTER-SAW AV;38.9MHz,SIP5K,ST,16.3dB,B/ ...3 SW801S3403-001134 SWITCH-PUSH;250V,5A,DPST ,ON-OFF,...3 FP801S 3601-000281 FUSE-CARTRIDGE;250V ,4A,TIME-LAG,GLASS,5. ...3 V999S 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,...3 CN906 3711-000628 CONNECTOR-HEADER;BOX,11P,1R,2.5MM,STRAIG ...3 JS701 3722-000497 JACK-PIN;4P,3.4mm,SN,BLK,...3 T0119 AA09-00351A IC MICOM;TDA9381/N2/3I,SPM-802MAN4,64P,3 ...3 T801S AA26-00043A TRANS SWITCHING;-,-,-,AC90~260V,125/12.5 ...3 T0616 AA26-00201A TRANS FBT;FCA173B,KS1A-1,3.8mH,FERRITE,1 ...3 T401 AA26-50001B TRANS-HORIZ.DRIVE;-,-,-,7.1mH,-,-,102uH, ...3 T0296 AA27-00053A COIL LINEARITY;-,193uH,DR10X10 C:4.35,7. ...3 LX801S AA29-30001D FILTER LINE NOISE;SQ1913,-,6.0MH,0.8A,...3 RM901 AA32-00015A MODULE REMOCON;FRP-3521H31,38KHZ,940MM,M ...3 T0245 AA39-20620C LEAD CONNECTOR-ASSY;,9P,500MM,YBNH250-09 ...3 TU01S AA40-00076A TUNER;TECC0949PG35A(S),PAL,181CH,38.9MHZ ...3 GT301 AA60-40012D PIN-GT,ASSY;T1.6,6-12.5-,NYLON66 S.N.A ...3 IC801S AA96-00242D ASSY H/S;SCREWAA62-30186B,5Q0765RTH,OIL S.N.A

....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A

....4 T0086 1203-002916 IC-PWM CONTROLLER;KA5Q0765RTH-YDTU,TO-22

....4 T0081 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW S.N.A

....4 CIS AA62-30186B HEAT SINK-ES;-,-,-,SILVER,171J + COVER-H S.N.A

....4 CIS AA63-30189A COVER-HEA TSINK;-,PC-ABS,T0.8,-,-,V0,NTR, S.N.A

...3 D806 AA96-00243D ASSY H/S;-,BRIDGE,AA62-00045A,D06U20S,DR S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 T0083 0402-001374 DIODE-RECTIFIER;FFPF06U20S,200V,6A,TO-22

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 AA62-00045A HEAT SINK-PS;-,-,T1.0,-,-,DREAM,-,-,-,-, S.N.A

...3 IC601 AA96-00244G ASSY H/S;-,AUDIO,AA62-00046A,TDA8944J,BR S.N.A

....4 0205-000129 GREASE-SILICON;SC102,JAPAN S.N.A

....4 T0085 1201-001741 IC-AUDIO AMP;TDA8944J,DBS,17P,937MIL,DUA

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 AA61-10162B BRACKET-IC;-,SBHG-1,T1.0,-,-,-,100 S.N.A

....4 AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A

...3 IC301 AA96-00244M ASSY H/S;SCREWAA64-00046A,LA78040N,OIL S S.N.A

....4 CIS 0205-001027 OIL-SILICON;G746,-,- S.N.A

....4 T0088 1204-002121 IC-VERTICAL DEF.;LA78040N,TO220,7P,-,PLA

....4 T0081 6003-000335 SCREW-TAPTITE;RH,+,2S,M3,L8,ZPC(YEL),SWR S.N.A

....4 CIS AA62-00046A HEAT SINK-PS;-,-,T1.0,-,D1(DREAM) 60X25X S.N.A

...3 IC802 AA96-00245A ASSY H/S;-,-,AA62-00055A,KA7632,- S.N.A

....4 T0087 1203-001939 IC-POSI.FIXED REG.;7632,SIP,10P,-,PLASTI

....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

....4 AA62-00055A HEAT SINK-PS;-,-,T1.0,-,35*15*25,D1,-,-, S.N.A

...3 LD901 AA96-00555A ASSY LED GUIDE;-,-,UEX-LD-030,GREEN S.N.A ...3 IC501 AA96-50311A ASSY H/S;-,VIDEO,AA62-30175D,TDA6107Q,- S.N.A

....4 T0074 1201-001159 IC-VIDEO AMP;6107,ZSIP,9P,-,SINGLE,-,PLA

....4 T0081 6003-000334 SCREW-TAPTITE;RH,+,2S,M3,L6,ZPC(YEL),SWR

....4 AA62-30175D HEAT SINK-PS;-,SECC,T1.0,-,33X15X30 FT-2 S.N.A

...3 AA97-14208L ASSY AUTO-MAIN;CS20H4MJ0X/RCH,KS1A,MAC S.N.A

....4 D901 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D811 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D808 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D804 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D201 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D103 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 D101 0401-000005 DIODE-SWITCHING;1N4148,75V,150MA,DO-35,T

....4 T0083 0402-000254 DIODE-RECTIFIER;RGP10J,600V,1A,DO-41,TP

....4 T0083 0402-000546 DIODE-RECTIFIER;TVR10G,400V,1.0A,DO-41,T

....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP ,600V,1.5A,-,TP

Electrical Parts List

7-6 Samsung Electronics

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

7-2 CS20H4MJ0X/RCH

You can search for the updated part code through ITSELF web site. URL : http://itself.sec.samsung.co.kr

Electrical Parts List

Samsung Electronics 7-7

Level Loc. No. Code No. Description ; Specification Remark Level Loc. No. Code No. Description ; Specification Remark

....4 T0083 0402-001111 DIODE-RECTIFIER;1N5397GP ,600V,1.5A,-,TP

....4 T0083 0402-001321 DIODE-RECTIFIER;1A4G,400,1A,TO-220F,TP

....4 T0083 0402-001352 DIODE-RECTIFIER;GUF15G-20A,400V,1.5A,MEL

....4 T0083 0402-001443 DIODE-RECTIFIER;EGP20K,800V,2A,TO-220F,T

....4 DZ016 0403-000508 DIODE-ZENER;MTZJ5.6B,5.45-5.73V,500MW,DO

....4 DZ016 0403-000510 DIODE-ZENER;MTZJ6.2B,5.96-6.27V,500MW,DO

....4 DZ016 0403-000699 DIODE-ZENER;TZP27B,27-30.8V,1000MW,DO-41
