OWNER’S
DB98-23387A E H
INSTRUCTIONS
AW 0 7 P 1H E A / E A A
AW 12 P 1H E A / E A A
AW 2 4 P 1H E A / E A A
AW 0 9 P 1 H E A / E A A
AW 1 8 P 1H E A / E A A
Window-type Room Air Conditioner
(Cool)
(1)
E-2
Safety Precautions
The following safety precautions must be taken when using your air conditioner.
Users of this product are cautioned not to attempt repair of this product at their
own
discretion. Instead, they are requested to directly contact a designated
service
center or the outlet at which the product was purchased.
Never spill any kind of liquid into the unit. Should this happen, unplug or main
switch
off the unit and contact an authorized service center.
Do not insert anything between the air outlet blades because the inner fan may
be
damaged and could cause injury. Keep children away from the unit.
Do not place any obstacles in front of the unit.
Do not spray liquid of any kind into the indoor unit. Should this happen, switch off
the
breaker used for your air conditioner and contact your installation specialist.
Make sure that the unit is correctly ventilated at all times:
Do
not place clothing or other materials over it.
If the wireless remote control will not be used for a long time, remove the
batteries.
(If applicable)
When using a wireless remote control, the distance should not be more than 7
meters
from the air conditioner. (If applicable)
WARNING
DURING OPERATION
Risk of electric shock. • Can cause injury or death. • Disconnect all
remote
electric power supplies before servicing, installing or cleaning.
• This must be done by the manufacturer or its service agent or a similar
qualified
person in order to avoid a hazard.
Register your product at www.samsung.com/global/register
D
ISPOSING OF THE UNIT
OTHERS
The air conditioner must be plugged into its own specific power source, which
must be installed in compliance with national wiring,earthing and safety
regulations.
If the power cord is damaged in any way, it must be replaced by the manufacturer
or its service agent or a similarly qualified person in order to avoid a hazard.
This device must be installed according to the national electrical rules.
The appliance must be installation that the plug should be easily accessible
after installation.
If the fuse on PC board is broken please change it with the type of T 3.15A 250V.
The breaker of the air conditioner should be all-pole switch; and the distance
between its two contacts should be no less than 3.5mm. Such means for
disconnection must be incorporation in the fixed wiring.
Before throwing out the device, it is necessary to pull back the battery cells and
rid of them safely for recycling reasons.
get
When you need to dispose of the unit, consult your dealer. If pipes are removed
incorrectl
injur
Please recycle or dispose of the packaging material for this product in an
environmentally
Never store or ship the air conditioner upside down or sideways to avoid damage
to
The appliance is not intended for use by young children or infirm persons without
supervision:
with
Max current is measured according to IEC standard for safety and current is
measured
y, refrigerant may blow out and come into contact with your skin,causing
y. Releasing refrigerant into the atmosphere also damages the environments.
responsible manner.
the compressor.
Young children should be supervised to ensure that they do not play
the appliance.
according to ISO standard for energy efficiency.
E-3
Contents
PREPARING YOUR AIR CONDITIONER
Safety Precautions
Air Conditioning Unit-Main Parts and Control Panel
CoolingYour Room
Ai
ring Your Room
Switching the Air Conditioner O
ff
Adjusting the Air Fl
ow Direction Horizontally
Adjusting the Air Fl
ow Direction Vertically
OPERATION YOUR AIR CONDITIONER
Temperature and Humidity Ranges
Cleanin
g Your Air Conditioner
Solving Common Pro
blems
Technical Specitications
RECOMMENDATIONS FOR USE
2
4
5
6
6
7
7
8
9
9
10
CCCCAAAAUUUUTTTTIIIIOOOONN
NN
"The high inrush current of the starting compressor motor can have adverse effects to
the ope
ration of other equipment under unfavorable mains conditions.This equipment
does not comply with the rel
evant technical standards for the limitation of voltage
fluctuations and fli
cker."
Be
fore connection this equipment to the power supply system, please report to your
suply autho
rity and obtain the consent.
Do not connect other elect
ric appliances to the same supply lines.
The maxi
mum permissible system impedance at the power junction box is 0.24 ohms.
Usuall
y, the maximum permissible mains impedance will not be exceeded when the
branch to the power outlet is fed from a junction box with a rated current of 32A.
I
NSTALLATION
The illustrations in the step-by-step procedures use four dif ferent symbols:
AW18
**
HSILGNE
7
Air Conditioning Unit - Main Parts and Control Panel
The desing and shape are subject to
change according to the model.
Air inlet(Insi
The air filter
located in side
d
e
)
i
s
Air Out
Power plug
let
Inner air
flow blades
(right/left orientation)
Outer air
(up/down orientation)
Air inlet (Outsi
Ventilation lever
Power Cable
The type of the
may differ according to the
type of local power supply.
f
ow blades
l
d
e
ower plug
p
)
E-4
AW**P1HEA
Coolest
AW**P1HEAA
Cooling Your Room
You must select the Cool mode if you wish to lower the temperature
in your room. Y ou can also set the fan speed.
1 Select the operating mode and fan speed.
To cool y our r oom with a... Set the operating mode
selection dial to...
High
fan speed
Between HIGH and LOW
Low fan speed
The air conditioner star ts up in Cool mode.
:
Result
The fan starts up at the speed selected.
You can change modes at any time.
2 To adjust the temperature, turn the temperature control dial
to the desired position.
Possible temperature s: Betwee n 18 C and 29 C inclusive.
The air conditioner starts cooling if the room temperature is
:
Result
higher than the selected temperature.
HI COOL
MED COOL
LOW COOL
HSILGNE
AW**P1HEA
3 To control the direction of the air flow, refer to page 7
AW**P1HEAA
AW**P1HEA
AW**P1HEAA
E-5
Airing Your Room
If the atmosphere in your room is stale, you can air it using
the Fan feature and if necessary, evacuate the stale air outside.
1 If you wish to evacuate stale air outside, push the ventilation lever on the front
of the unit to the right and the open position ( ).
AW**P1HEA
AW**P1HEAA
Result:
Otherw
Result:
2 Set the operating mode selection dial to the HI FAN or LOW FAN
position.
Resu
3 To control the direction of the air flow, refer to page 7.
The air inside the room circulates and stale air is evacuated outside.
is
e, push the ventilation lever to the left and the closed position ( ).
The air simply circulates inside the ro
FAN: The fan turns rapidly.
HI
LOW FAN : The fan turns sl owly.
lt: The air conditioner starts up in Fan mode.
om
.
AW**P1HEA
AW**P1HEAA
E-6
Switching the Air Conditioner Off
You can switch the air conditioner off whenever you want.
1 To switch the unit off, simply set the operating mode selection dial
to the OFF position.
: The air conditioner stops operating.
Resu
lt
E-7
If you orient the air flow blades downwards and the unit operates
in Cool mode for long periods of time, dew may:
Form on the surface of the blades
Drip from the blades
Adjusting the Air Flow Direction Horizontally
Adjusting the Air F
low Direction Vertically
HSILGNE
Depending on the position of the unit in your room, you can adjust the
orientation of the inner air flow blades on the right-hand side of the
unit, thus increasing the efficiency of the air conditioner.
1 Set the air flow blade swing switch to the on position.
Resul
t:
The inner blades swing automatically left and right.
2 To stop the blades moving left and right, set the air flow blade swing
switch to the off position.
To stop the blades in a specific position and orient the air flow in
the corresponding direction, simply set the switch to the off
position when the blades are in the desired position.
Again depending on the position of the unit in
your room, you can adjust the
orientation of the outer air flow blades on the right-hand side of the unit.
RECOMME
NDATION When... Adjust the blades to face...
Cooling U
p
wards.
Adjust the air f
low blades to the desired position, by pushing them
upwards or downwards.
Temperature and Humidity Ranges
The following table indicates the temperature and humidity ranges
within which the air conditioner can be used.
Mo
de Indoor Temperature OutdoorTemperature Indoor Humidity
Cooling 21 C to 32 C app
If the air conditioner is used at.
Higher temp
Lower temperature
Higher humidity
erature
levels
rox. 21 C to 43 C approx. 80% or less
.. Then...
The automatic protection
and the air conditioner stopped.
A water leakage or some other malfunction may happen
if the heat
Water may condense on and drip from the surface of the unit
if it is used for long periods.
exchanger freezes.
feature may be triggered
CCCCAAAAUUUUTTTTIIIIOOOONN
NN
E-8
Cleaning Your Air Conditioner
Be sure to clean the air filter periodically to maintain the air conditioner
in the best condition for a long period of time.
1 Hold the front grille handle, slightly pull it to the left side and open the front
grille.
2 Pull the air filter to the right side.
3 Remove all dust on the air filter with a vacuum cleaner or brush.
4 When you have finished, insert the air filter back into its original position.
5 Wipe the surface of the unit with a neutral detergent and then wipe it again
with dry cloth.
(Be sure not to use benzene, solvent or other chemical products.)
IMPOR
TANT When cleaning the air conditioner, turn it off and pull out
the p
ower plug.
The rem
oval of the front grille makes it easier to clean the air
conditioner. Open the grille as much as possible.
1 Grasp the lower part of the front
grille and the front grille handle,
then open the
grille.(The open
angle of front
grille has not to be
exceeded 25 degree)
2 Lift the front
grille slightly and
rem
ove it from the front panel.
3 Reassem
bling of front grille
should be done in r
everse
order of disassem
bly.
If you... Then...
Will not be using the
air conditioner for a
long period of time
Have not used the air
conditioner for a long
period of time
Set the ope
rating mode selection dial
to "LOW FAN" and let it run of a few
hours to dry the inside of the air
conditioner thoroughly.
Switch the air conditioner off and
unplug it from the wall socket.
Clean the filter and outer surfaces.
Set the ope
rating mode selection dial
to "LOW FAN" and let it run of a few
hours to dry the inside of the air
conditioner thoroughly.
The air conditioner has two or three
grille grooves depending on the model.
Removal and reassembly of the Front Grille
Solving Common Problems
Before contacting the after-sales service, perform the following simple checks.
They may save you the time and expense of an unnecessary call.
PROBLEM
EXPLAN
ATION / SOLUTION
The air conditioner does no
t
operate at all
The air conditioner does no
t
coo
l
The air fl
ow direction does not
change when you set the air
flow blade swing switch to the
on position
Odours are pe
rmeated in the
room during air conditioning
Che
ck that the circuit breaker used for the air conditioner
has not been triggered.
Che
ck that the power cable is plugged into a wall socket and the
socket is switched on, if necessary.
Che
ck that the correct operating mode has been selected
(cooling or airing).
Che
ck that the correct operating mode has been selected.
The room tempe
rature may be too low.
Dust m
ay be blocking the air filter;
refer to page 9 cleaning instructions.
Che
ck that there is no obstacle blocking the air flow into or out of the unit.
Che
ck that the air conditioner has been switched on;
if necessary, turn the operating mode selection dial;
refer to page 7.
Air the room.
E-
9
Technical Specifications
Design and specifications are subject to change without notice.
Model Power Supply
HSILGNE
HEA/EAA
******
220-240V~, 50Hz
E-
10
Installation
Before installation, be sure to check the installation area
for the air conditioner, and drain hose.
Che
ckpoints prior t o ins tallation
Installation Condi tion
s
1 Check the cabinet and front grille of the unit for any harmful defects
such as scratches.
1 A s the unit is heavy, the wall or window of the installation area should
have sufficient strength and durability for operation of the air conditioner,
and for prevention of any vibration or noise.
If it is weak, reinforcement work should be performed separately.
2 It is advisa
ble to install the air conditioner in the north or west side to
prevent the effect of direct sunlight.
When installing it in the south or east side due to unavoidable
circumstances, it is advisable to install the sunshade to prevent the
direct sunlight.
In this case, take care not to cause any hindrance to the flow of outside air .
3 When installing the air conditioner, be sure to obtain sufficient space on
the rear side of the unit for smooth flow of air.
When operating the air conditioner in closed areas such as inner building
with cooling operation, and result in trouble with the unit.
See the illustration below.
2 Be sure to che
ck the power supply.
- Re
fer to the specifications on the label attached to the unit.
The appliance
must be fixed well by screw or similar method.
Fence, wall
or other
obstacle
If the
wall is greater than 150mm thick.
cut the wall back on a 45 angle if possible.
500mm 500mm
75mm
min.
300mm
500mm
150mm min.
"A"
Approx.3
Awning
750mm
100mm or more
4545
Outdoor Side
Indoor Side
MODEL
AW07/AW09
AW12
AW18/AW24
"A"
145
170
260
E-
11
Installation of th e Drain Tube
Fix the d
rain tube as shown in the figure.
Installation of th e Drain
Pan
The procedure
for installing the drain pan should be determined by the
condition of the installing area.
1 Open the front
grille; refer to page 9.
3 Rem
ove the front panel.
4Remove four screws on the lower, right and left sides of the unit.
5 Remove the chassis from the cabinet.
6 Remove the rubber cap inserted into the basepan.
7 Fix the drain pan as shown in the figure, and then connect the drain hose.
(You can use any commercially-available drain hose.)
8 Install the cabinet at the specified area after installing the drain pan,
and then re-assemble it in the original condition.
1
Follow steps 6 and 7 only
2 Remove the screw lo ca ted a t the l ower sectio n of th e front gri lle .
It i s secur ed in the s ection dependi ng on t he mode l.
In the case of an area where the drain pan can not be direct
ly
installed on the rear side of the unit after installing the air conditioner.
Example
: High storage
In the case of an area where the drain pan can be directly installed
on the rear side of the unit after installing the air conditioner.
3-1 Press both sides of the cabinet in the direction of the arrow
as shown in the figure.
3-2 Pull the l
ower part of the front panel slightly forward.
(below three inches)
3-3 Lift the front panel up
ward.
Applying
excessive force to remove the front panel may cause
damage to the tab; be sure not to use excessive force.
Secure the front panel to the case
by replacing the screw removed in
step 2. If a screw not removed in step 2. secure the panel with a
supplied screw.
Rubber cap
Screws(2EA)
Gasket
Rear
DrainTube
Bottom-Side View with
Drain Pan and Hose in Place
Rubber cap
Drain Hose
Rear
Drain Pan
Screw
HSILGNE
THIS AIR CONDITIONER IS MANUFACTURED BY:
Contact SAMSUNG WORLD WIDE
If you have any comments or questions regarding a Samsung products, contact the SAMSUNG
customer care center.
Country
HONG KONG
Customer Care Center
2862 6001
Web Site
www.samsung.com/hk
Loading...
