Samsung AW1000A, AW0700A, AW0700B, AW1200A User Manual
OWNER’S
INSTRUCTIONS
AW0700A
AW0700B
AW0800A
AW1000A
AW1010A
AW1200A
AW1210A
AW1800A
WINDOW-TYPE
ROOM AIR CONDITIONER
( Cool )
E
DB68-01926A(2)
S
The following safety precautions must be taken when using your air conditioner.
Safety Precautions
1 The unit must be plugged into an independent circuit.
The air conditioner must be installed in accordance with national wiring regulations and
safety regulations wherever applicable.
2 Some installation locations may require installation of a short circuit breaker or grounding.
4 MAKE sure that the unit is correctly ventilated at all times :
do NOT place clothing or other materials over it.
5 NEVER spill any kind of liquid into the unit. Should this happen, unplug the unit and contact
an authorized service center.
6 Do NOT insert anything between the air outlet blades because the inner fan may be damaged
and could cause injury. Keep children away from the unit.
7 Do NOT place any obstacles in front of the unit.
8 Users of this product are cautioned not to attempt repairs.
Instead, they are requested to directly contact a designated service center or the outlet
at which the product was purchased.
9 Do not use an extension cord with this product.
10 The appliance is not intended for use by young children without supervision ;
young children should be supervised to ensure that they do not play with the appliance.
11 Never store or ship the air conditioner upside down or sideways to avoid damage to the
compressor.
3 If the supply cord is damaged, it must be replaced by a special cord or assembly available
from the manufacturer or its service agent.
The manufacturer does not assume responsibility for accidents or injury
caused by an incorrectly installed air conditioner. If you are unsure about
installation, contact an installation specialist.
CCCCAAAAUUUUTTTTIIIIOOOONN
NN
E-
2
Contents
◆ PREPARING
YOUR AIR CONDITIONER
■ Safety Precautions ......................................................................................... 2
■ Description of Each Component .................................................................... 4
■ Getting Started ............................................................................................... 5
◆ OPERATING YOUR AIR CONDITIONER
■ Cooling Your Room ........................................................................................ 6
■ Ventilating Your Room .................................................................................... 7
■ Switching the Air Conditioner Off .................................................................... 8
■ Selecting Energy Saving Mode ...................................................................... 8
■ Adjusting the Air Flow Direction Horizontally .................................................. 9
■ Adjusting the Air Flow Direction Vertically ...................................................... 9
◆ R
ECOMMENDATIONS F
OR USE
■ Power Failure ................................................................................................. 10
■ Temperature and Humidity Ranges ................................................................ 10
■ Cleaning Your Air Conditioner ........................................................................ 11
■ Solving Common Problems ............................................................................ 13
■ Technical Specifications ................................................................................. 13
E-
3
Air filter
(The air filter is
located in inside.)
Air inlet (Inside)
Air outlet
Thermostat control
Operating mode
selection dial
Operating mode
selection dial
Thermostat control
Energy Saver switch
Swing switch
Outer air flow blades
(up/down orientation)
Air inlet (Outside)
Ventilation lever
Power plug (The type of
power plug may
differ, depending on the
local power supply.)
Inner air flow blades
(right/left orientation)
AW0700A/AW0700B/
AW0800A/AW1000A/
AW1200A/AW1800A
AW1010A/AW1210A
Description of Each Component
E-
4
❄ The design and shape are subject to
change, depending on the model.
Getting Started
You have just purchased a Samsung window-type room air conditioner which should be
installed following your Owner’s Instructions.
Your Owner's Instructions contain much valuable information on using your air conditioner.
Please take the time to read them as they will help you take full advantage of the unit's
features.
The illustrations in the step-by-step procedures use four different symbols:
E-
5
PRESS PUSH IMPORTANT NOTE
☛
➢
