02_ features
For easy future reference write the model and serial number
down. You will find your model number on the right side of
the air conditioner.
Model #
Serial #
features of your new
air conditioner
• Slim & Smart Design
Extremely slim and compact design will allow this air conditioner to fit in any kind of interior
space.
•
function generates hydrogen(H) and oxygen(O2) to attack undesirable air contaminants
such as bacteria, pollen, and odor. It makes you breathe better as if you were staying around
waterfalls, ocean surf, rivers and mountains.
• 2Way air outlet
There are two separate air outlets for cooling and heating. Having warmer air coming out
from the bottom part of the air outlet will spread the warm air evenly throughout the room.
Stay cooler and warmer in every corner of your room.
•
Cost Efficient System
Your new air conditioner not only provides maximum cooling power in the summer, but can
also be an efficient heating method in the winter with the advanced “Heat Pump” system.
This technology is up to 300% more efficient than electrical heating, so you can further
reduce its running cost. Now, meet year-round needs with one air conditioner.
AVXTJ£ª£ª_IB IM_E_29814.indd 2 2009-3-10 16:47:06
Page 3
safety information _03
ENGLISH
safety information
To prevent electric shock, disconnect the power before servicing, cleaning, and installing the unit.
SAFETY INFORMATION
Before using your new air conditioner, please read this manual thoroughly to ensure that you know how to
safely and efficiently operate the extensive features and functions of your new appliance.
Because the following operating instructions cover various models, the characteristics of your air
conditioner may differ slightly from those described in this manual. If you have questions, call your nearest
contact center or find help and information online at www.samsung.com.
What the icons and signs in this user manual mean:
WARNING
Risk of death or serious personal injury.
CAUTION
Potential risk of personal injury or material damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when
using your air conditioner, follow these basic safety instructions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the contact center for help.
Recommended instructions or useful information for use.
These warning signs are here to prevent injury to you and others.
Please follow them carefully.
After reading this section, keep it in a safe place for future reference.
SEVERE WARNING SIGNS
Do not place the air conditioner near hazardous substances or equipment that
releases free flames to avoid fire, explosions or injuries.
• Potential risk of fire hazard or explosion.
Do not block or place items in front of the air conditioner. Do not step, hang onto, or
place heavy items on the air conditioner.
• Potential risk of personal injury.
Do not install the outdoor unit at an unstable place or elevated surface where there is
potential risk of falling.
• If the outdoor unit falls, it may cause personal injury or loss or property.
Any changes or modifications performed not following by the installation manual,
failure or damage may occur on the condition. In this case, user will be responsible for
all the repair expenses.
AVXTJ£ª£ª_IB IM_E_29814.indd 3 2009-3-10 16:47:06
Page 4
04_ safety information
safety information
SEVERE WARNING SIGNS
If any gas or impurities other than R410A refrigerant come into the refrigerant pipe,
serious problem may occur and it may cause injury.
Do not spray flammable gases such as insecticide near the air conditioner.
• Potential risk of electric shock, fire or unit malfunction.
Do not insert anything such as fingers or branches into the air conditioner vents.
• Keep children away from the air conditioner. Potential risk of personal injury.
Do not cut the power plug and connect to a different power cable.
Never attempt to lengthen the power cable.
• Potential risk of fire or electric shock.
Do not yank the power cable and touch the power plug with hands.
• Potential risk of fire or electric shock.
Never use a damaged power plug, power cable, or loosened power receptacle.
• Potential risk of fire or electric shock.
The electric work must be done by qualified service technician in accordance with the
national wiring regulations with rated cables.
• If the capacity of the power cable is insufficient or electric work have not done properly, electric
shock or fire may occur.
You should connect the power cable into the power cable terminal and fasten it with a
clamp.
Do not connect the air conditioner with heating apparatus or attempt to disassemble,
remodel or repair it by yourself.
• Potential risk of malfunction, electric shock or fire. If repairs are needed, consult the contact center.
Consult the place of purchase or a contact center to disassemble or reinstall the air
conditioner.
• Potential risk of unit malfunction, water leakage, electric shock, or fire.
Consult the place of purchase or contact center to install the air conditioner.
• Improper installation carries a risk of unit malfunction, water leakage, electric shock or fire.
• If installing in specialty areas, such as a factory complex or saline coastal area, consult the place of
purchase or contact center for specific installation details.
Install the air conditioner with the support bracket securely fastened to use for an
extended period of time.
• If the air conditioner falls, it may cause personal injury or loss of property.
If the indoor unit gets wet, turn the power off immediately and call your nearest
contact center.
• Potential risk of fire or electric shock.
Install an exclusive circuit breaker and short-circuit breaker for the air conditioner.
• Potential risk of electric shock or fire.
If the power cable is damaged, the manufacturer or a qualified service technician
must replace it.
Always make sure that the power supply is compliant with current safety standards.
Always install the air conditioner in compliance with current local safety standards.
Verify that the voltage and frequency of the power supply comply with the
specifications and that the installed power is sufficient to ensure the operation of any
other domestic appliance connected to the same electric lines.
The air conditioner must be installed in accordance with national wiring regulations
and safety regulations wherever applicable.
AVXTJ£ª£ª_IB IM_E_29814.indd 4 2009-3-10 16:47:07
Page 5
safety information _05
ENGLISH
Install the supplied cables firmly. Fix them securely so that external force is not
exerted to the terminal block.
• If the connection is loose, heat may generate and cause electric shock or fire.
Use a rated circuit breaker only.
• Never use steel wires or copper wires as a circuit breaker. It may cause fire or unit malfunction.
Use an exclusive power source for the air conditioner.
• Potential risk of electric shock or fire.
Do not put undue stress or place heavy object on the power cable.
Do not bend the power cable excessively.
• Potential risk of fire or electric shock.
Always verify that electric connections (cable entry, section of leads, protections...)
are compliant with the electric specifications and with the instructions provided in the
wiring scheme.
Always verify that all connections comply with the standards applicable to the
installation of air conditioners.
Use a receptacle that has a ground terminal. The receptacle must be used exclusively
for the air conditioner.
• Improper electrical grounding may cause electric shock or fire.
Be sure to ground the unit. Do not connect the ground wire to gas or water pipes,
lighting rods, or telephone grounding lines.
• If the unit is not properly grounded, electric shock may result.
Always verify that a suitable grounding connection is available.
Disconnect the air conditioner from power supply before it is repaired or
disassembled.
CAUTION SIGNS
Connect the refrigerant tubes first then the electrical lines, when installing the unit.
Always disassemble the electric lines before the refrigerant tubes.
Verify that the air conditioner is connected to the power supply in accordance with the
instructions provided in the wiring diagram included in the manual.
The manufacturer shall not be responsible for damage originating from unauthorized
changes or the improper connection of electric and hydraulic lines.
Failure to comply with these instructions or to comply with the requirements set
forth in the “Operating limits” table, included in the manual, and shall immediately
invalidate the warranty.
Ensure no water gets into the air conditioner.
• Potential risk or electric shock.
Turn off the air conditioner using the provided remote control or control accessory
(if provided). Do not unplug to turn off the unit (unless there is an immediate danger).
Do not open the front grille during operation.
• Potential risk of electric shock or unit malfunction.
Cool air should not flow directly towards people, pets, and plants.
• It is harmful to your health, pets, and plants.
Do not run the air conditioner for an extended period of time in a room with the door
closed or with babies, elderly or disabled people.
• Open the door or windows to ventilate your room at least once an hour to prevent oxygen shortage.
Do not drink drain water coming out of the air conditioner.
• Potential risk of health hazard.
AVXTJ£ª£ª_IB IM_E_29814.indd 5 2009-3-10 16:47:07
Page 6
06_ safety information
safety information
CAUTION SIGNS
Do not expose the dust filter to direct sunlight while drying.
• Strong direct sunlight may deform the dust filter.
Do not allow children to climb on the air conditioner.
Use only rated accessories and install the air conditioner with rated equipments.
• If you do not use the rated accessories, the air conditioner may drop from its place, water may leak
or electric shock or fire may occur.
Do not use the air conditioner as a cooling precision instrument for food, pets, plants,
cosmetics or machinery.
Do not give excessive shock to the air conditioner.
• Potential risk of fire or unit malfunction.
Do not spray water directly on the air conditioner or use benzene, thinner or alcohol to
clean the surface of the unit.
• Potential risk of electric shock or fire.
• Potential risk of damage to the air conditioner.
Do not place any objects, especially containers with liquid.
Do not touch the pipe connected to the air conditioner.
This appliance should be installed according to the provided installation manual.
Install the shortest possible length of pipe.
• If the length of pipe gets unnecessarily long, the life of air conditioner can be shorten and become
inefficient.
Install the power cable and communication cable of the indoor and outdoor unit at
least 1m away from the electric appliance.
Install the indoor unit away from lighting apparatus using the ballast.
• If you use the wireless remote control, reception error may occur due to the ballast of the lighting
apparatus.
For maximum safety, installers should always carefully read the following warnings.
Do not install the air conditioner in following places.
• Place where there is mineral oil or arsenic acid.
• Resin parts flame and the accessories may drop or water may leak. The capacity of the heat
exchanger may reduce or the air conditioner may be out of order.
• The place where corrosive gas such as sulfurous acid gas generates from the vent pipe or air outlet.
• The copper pipe or connection pipe may corrode and refrigerant may leak.
• The place where there is a machine that generates electromagnetic waves.
The air conditioner may not operate normally due to control system.
• The place where there is a danger of existing combustible gas, carbon fiber of flammable dust.
• The place where thinner or gasoline is handled Gas may leak and it may cause fire.
If the air conditioner is installed in a small room, measures must be taken to prevent
the refrigerant concentration in the room from exceeding the safety limit in the event
of refrigerant leakage.
Consult a dealer regarding the appropriate measures to prevent the allowable
concentration from being exceeded.
• If the refrigerant leaks, and cause the concentration limit to be exceeded, hazards due to lack of
oxygen in the room may result.
Install the air conditioner away from direct exposure to sunlight, heating apparatus,
and humid places.
• Hang curtains on windows to boost cooling efficiency and to avoid the risk of electric shock.
The air conditioner is composed of moving parts. Keep children away from the unit to
avoid physical injury.
AVXTJ£ª£ª_IB IM_E_29814.indd 6 2009-3-10 16:47:07
Page 7
safety information _07
ENGLISH
Check for damage on delivery. If damaged, do not install the air conditioner and call
the place of purchase immediately.
Insert the dust filter before operating the air conditioner.
• If there is no dust filter inside the air conditioner, accumulated dust may shorten the life of the air
conditioner and cause electricity waste.
Keep indoor temperatures stable and not extremely cold, especially where there are
children, elderly or disabled people.
Clean the dust filter every 2 weeks. Clean the filter more frequently if the air
conditioner is operated in dusty areas.
The packaging material and used batteries of the remote controller (optional) must be
disposed of in accordance with the national standards.
The refrigerant used in the air conditioner must be treated as chemical waste. Dispose
the refrigerant following national standards.
Have a qualified service technician install the air conditioner and perform a trial
operation.
Firmly connect the drain hose to the air conditioner for proper water drainage.
Install the outdoor unit where operating noise and vibration will not disturb your
neighbor and in a well-ventilated area with no obstacle.
• Potential risk of malfunction.
• Operating noise may disturb your neighbor.
Make sure that children take precautions against access to the air conditioner and
they do not play with the unit.
When using a wireless remote control, the distance should not be more than 7 meters
from the air conditioner.
If the remote control is not used for a long period of time, remove the batteries to
prevent leakage of electrolyte.
When cleaning the outdoor unit, touch the heat exchanger radiator fins with extreme
care.
• Wearing thick gloves can protect your hands.
Make sure that the condensed water dripping from the drain hose runs out properly
and safely.
Store the operation and installation manual in a safe location and remember to hand it
over to the new owner if the air conditioner is sold or transferred.
All the materials used for the manufacture and packaging of the air conditioner are
recyclable.
After completing the installation, always carry out a functional test and provide the
instructions on how to operate the air conditioner to the user.
The appliance is not intended for use by young children or infirm persons without
supervision: Young children should be supervised to ensure that they do not play with
the appliance.
Clean the air conditioner after the inner fan stops operating.
• Potential risk of injury or electric shock.
Inspect the condition, electric connections, pipes and external case of the air
conditioner regularly by a qualified service technician.
Do not open doors and windows in the room being cooled during operation unless
necessary.
Do not block the air conditioner vents. If objects block the air flow, it may cause unit
malfunction or poor performance.
Make sure there are no obstacles under the indoor unit.
• Potential risk of fire or loss of property.
Make sure that there are no obstacles or covers that block the air conditioner.
Allow sufficient space for air circulation.
• Insufficient ventilation may result in poor performance.
AVXTJ£ª£ª_IB IM_E_29814.indd 7 2009-3-10 16:47:07
Page 8
08_ safety information
safety information
CAUTION SIGNS
Make sure the voltage and frequency of the electric system are compatible with the
air conditioner.
If a power outage occurs while the air conditioner is working, turn off the power
source immediately.
Max current is measured according to IEC standard for safety and current is
measured according to ISO standard for energy efficiency.
The unit must be plugged into an independent circuit if applicable or connect the
power cable to the auxiliary circuit breaker. An all pole disconnection from the power
supply must be incorporated in the fixed wiring with a contact opening of >3mm.
After connecting the power cable between the indoor/outdoor unit, attach the cover
of component box securely and make sure it is not loose.
For the power cable, use the grade of H07RN-F or H05RN-F materials.
The unbalanced power must be maintained within 10% of supply rating among whole
indoor units.
If the power is unbalanced greatly, it may shorten the life of the condenser.
If the unbalanced power is exceeded over 10% of supply rating, the indoor unit is
protected, stopped and the error mode indicates.
To protect the product from water and possible shock, you should keep the power
cable and the connection cord of the indoor and outdoor units in the protection tube.
Connect the power cable to the auxiliary circuit breaker.
You must keep the cable in a protection tube.
Keep distances of 50mm or more between power cable and communication cable.
Maximum length of power cable is decided within 10% of power drop. If it exceeds,
you must consider another power supplying method.
The circuit breaker (MCCB, ELB) should be considered more capacity, if many indoor
units are connected from one breaker.
Use solderless ring terminal to connect the power cable to the power terminal block.
Use an appropriate screwdriver for tightening the terminal screws.
Over-tightening the terminal screws may break them.
Ensure the off-on and protection switches are properly installed.
Do not use the air conditioner if damaged. If problems occur, immediately stop
operation and disconnect the plug from the power supply.
If the air conditioner will not be used for an extended period of time (for example, over
several months), unplug the power from the wall.
Call the place of purchase or a contact center if repairs are needed.
• Potential risk of fire or electric shock if disassembly or repairs are attempted by a non-qualified
service technician.
If you smell burning plastic, hear strange sounds, or see smoke coming from the unit,
unplug the air conditioner immediately and call a contact center.
• Potential risk of fire or electric shock.
AVXTJ£ª£ª_IB IM_E_29814.indd 8 2009-3-10 16:47:07
Page 9
contents _09
ENGLISH
contents
VIEWING YOUR AIR CONDITIONER
BEFORE USE
10
10 Checking the indoor unit
10
Main parts
10 Mode indicator and control button
11
Removing the front panel
11
Viewing the power button and parts under the panel
12 Checking the remote control
13
Remote control display
13 Using the remote control
13 Installing the batteries
OPERATING BASIC FUNCTION
14
14 Turning the air conditioner on and off
14 Selecting operation mode
14 Auto
15 Cool
16 Dry
17 Fan
18 Heat
19
Adjusting the air flow direction
19 Vertical air flow
19 Horizontal air flow
USING ADVANCED FUNCTION
20
20 Setting the Timer
20 On Timer
21 Off Timer
22 Combining ON and Off timer
23 Using the
function
CLEANING AND MAINTAINING THE AIR
CONDITIONER
24
24 Cleaning the exterior
24 Cleaning the filter
24 Air filter
25 Anti-allergy filter
26 Replacing the filter
26 Deodorizing filter
27 Maintaining your air conditioner
27 Periodical checks
28 Internal protections via the unit control system
APPENDIX
29
29 Troubleshooting
30 Operation ranges
INSTALLING YOUR AIR CONDITIONER
31
31 Installation part
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be
disposed of with other household waste at the end of their working life. To prevent possible harm to the environment or human health from uncontrolled waste
disposal, please separate these items from other types of waste and recycle them responsibly to promote the sustainable reuse of material resources
.
Household users should contact either the retailer where they purchased this product, or their local government office, for details of where and how they
can take these items for environmentally safe recycling
.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories
should not be mixed with other commercial wastes for disposal.
This product has been determined to be in compliance with the Low Voltage Directive (2006/95/EC), and the Electromagnetic
Compatibility Directive (2004/108/EEC) of the European Union.
AVXTJ£ª£ª_IB IM_E_29814.indd 9 2009-3-10 16:47:08
Page 10
10_ viewing
viewing your air conditioner
before use
Congratulations on the purchase of the air conditioner. We hope you enjoy the features of your air
conditioner and stay cool or warm with optimal efficiency.
Please read the user manual to get started and to make the best use of the air conditioner.
CHECKING THE INDOOR UNIT
Carefully unpack your air conditioner, and check the unit to make sure it is not damaged.
Main parts
Your air conditioner may slightly look different from illustration shown above depending on
your model.
Mode indicator and Control button
Air intake
Mode indicator and
Control button
Air outlet
(Cooling/Heating)
Air outlet
(Heating)
Blade pin lever
Blade pin lever
indicator
Fan mode indicator
Timer indicator
Remote control sensor
Power indicator
Power button
Deice indicator
AVXTJ£ª£ª_IB IM_E_29814.indd 10 2009-3-10 16:47:09
Page 11
viewing _11
ENGLISH
REMOVING THE FRONT PANEL
Grab the top portion of the front panel and pull the front cover towards yourself. Unhook the safety string
and lift up the front panel.
Viewing the power button and parts under the panel
You may locate the Power button among with the mode indicators. When the front panel is
open, you may locate the temperature sensor and the
Air flow switch. Temperature sensor is
located on the top left side of the air conditioner just above the anti-allergy/deodorizing filter slot
and the Air flow switch is located on the top right corner of the air conditioner.
You can turn on the air conditioner in Auto mode by pressing the Power button.
When you set the Air flow switch on Auto, it will open the bottom air outlet in Cool, Heat and
Fan modes. However, in Silence mode, the bottom air outlet will be closed. Also, in Cool mode,
the bottom air outlet will be closed within an hour. When you set the Air flow switch on Off, the
bottom air outlet will be closed.
The room temperature sensor measures indoor room temperature.
Air flow switch
Power button
Room temperature sensor
AVXTJ£ª£ª_IB IM_E_29814.indd 11 2009-3-10 16:47:14
Page 12
12_ viewing
viewing your air conditioner
before use
CHECKING THE REMOTE CONTROL
You can activate the air conditioner by pointing the remote control away from it. When using the remote
control, always point it directly at the air conditioner.
Each time you press the button, a short beep will sound and a transmit indicator appears
on the remote control display.
Remote control display
Power
Turn on/off the air conditioner,
Mode
Set one of the 5 operating modes.
(See pages 14~18 for instructions.)
Fan
Adjust how much air flows
through the air conditioner with
the 4 different fan speeds such as
Auto/Low/Medium/High.
On Timer
Set the On Timer on.
Off Timer
Set the Off Timer off.
Set the mpi mode on/off.
Air swing
Activate/Deactivate air flow blade movement
automatically up and down.
Temp
Increase/Decrease the temperature by 1˚C.
Time
Increase/Decrease the time.
Set
Set the current Timer.
Cancel
Cancel the current Timer.
AVXTJ£ª£ª_IB IM_E_29814.indd 12 2009-3-10 16:47:15
Page 13
viewing _13
ENGLISH
Remote control display
Using the remote control
• Point the remote control towards the remote control sensor of the unit.
• When properly pressing the button on the remote control, you will hear beep sound
from the unit.
• The signal may not be received well of electronic lighting style fluorescent lamps,
such as inverter fluorescent lamps are in the same space.
• If other electrical products operate by the remote control, call your nearest contact center.
Installing the batteries
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries with separate battery return systems.)
This marking on the battery, manual or packaging indicates that the batteries in this product should not be disposed of
with other household waste at the end of their working life. Where marked, the chemical symbols Hg, Cd or Pb indicate
that the battery contains mercury, cadmium or lead above the reference levels in EC Directive 2006/66. If batteries are
not properly disposed of, these substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please separate batteries from other types of waste and
recycle them through your local, free battery return system.
Operation mode
indicator
Set temperature/time
indicator
Air swing indicator
Low battery indicator
Transmit indicator
On Timer indicator
Off Timer indicator
Fan speed indicator
Auto
Low
Medium
High
indicator
1. Push the lever as arrow
indicates on the rear side
of the remote control and
pull up.
2. Insert two AAA batteries.
Check and match the “+” and
“-” signs accordingly. Make
sure you have inserted the
batteries in correct position.
3.
Close the cover by place it
back to its original position.
You should hear click sound
when the cover is locked
properly.
AVXTJ£ª£ª_IB IM_E_29814.indd 13 2009-3-10 16:47:17
Page 14
14_ operating
operating basic function
TURNING THE AIR CONDITIONER ON AND OFF
Press the Power button on the remote control.
You will hear a ringing sound and the air flow blade will move up
and down automatically when air conditioner is properly on. The air
conditioner will operate in the most recent operation mode used or
Auto mode.
When you turn off the air conditioner, air flow blade will stop moving
and remain closed.
Turning on/off your air conditioner without the remote control.
You can operate your air conditioner by pressing the
Power button on the right bottom side of the
air conditioner.
SELECTING OPERATION MODE
Auto
In Auto mode, the air conditioner will automatically set the temperature and fan speed depending
on the room temperature detected by the room temperature sensor.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operation mode.
Press the Mode button on the remote control until
operation mode indicator displays Auto.
The air conditioner will automatically set the fan
speed, and operation mode to Cool or Heat depends
on the room temperature.
When you press the
Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the Temperature.
Press the Temp or button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between the
range of 16˚C~30˚C.
You can decrease/increase the temperature by 1
˚C.
• When the air conditioner is already operating in another mode, press the Mode button
until Auto mode indicator appears on the remote control display.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
AVXTJ£ª£ª_IB IM_E_29814.indd 14 2009-3-10 16:47:24
Page 15
operating _15
ENGLISH
Cool
In Cool mode, the air conditioner will cool your room. You can adjust the temperature and the fan
speed to feel cooler in hot season.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Cool mode indicator appears on the remote control
display.
The air conditioner operates in Cool mode and
will lower the temperature in your room.
When you press the
Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the temperature.
Press the Temp or button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between
the range of 16˚C~30˚C.
You can decrease/increase the temperature by 1
˚C.
4. Set the fan speed.
Press the Fan or button on the remote control to
set the desired fan speed.
If room temperature reaches desired value, the air
conditioner will shut off cooling for a while and just the
fan runs.
When you press the
Fan or button, fan speed
will change in order of Auto, Low, Medium and High.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
• If current outside temperatures are much higher than the selected indoor temperature,
it may take time to bring the inner temperature to the desired coolness.
AVXTJ£ª£ª_IB IM_E_29814.indd 15 2009-3-10 16:47:31
Page 16
16_ operating
operating basic function
SELECTING OPERATION MODE
Dry
The air conditioner in Dry mode acts like a dehumidifier by removing moisture from the indoor air.
Dry mode makes the air feel refreshing in a humid climate.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Dry mode and Auto fan speed indicator appear on the
remote control display.
In Dry mode temperature will be set automatically and
will appear on the remote control display.
When you press the
Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Temperature/Fan speed cannot be adjusted while using this mode.
• Air flow can be adjusted manually. (See page 19 for instructions.)
AVXTJ£ª£ª_IB IM_E_29814.indd 16 2009-3-10 16:47:35
Page 17
operating _17
ENGLISH
Fan
Fan mode can be selected to ventilate your room. Fan mode will be helpful to refresh the stale air
in your room.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Fan mode indicator appears on the remote control
display.
The air conditioner operates in Fan mode.
When you press the
Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the fan speed.
Press the Fan Speed button on the remote control to
set the desired fan speed.
When you press the
Fan or button, fan speed
will change in order of Low, Medium and High.
• When you are using the remote control, make sure correct indicator which matches your
selection appears on the remote control display.
• Air flow can be adjusted manually. (See page 19 for instructions.)
AVXTJ£ª£ª_IB IM_E_29814.indd 17 2009-3-10 16:47:40
Page 18
18_ operating
operating basic function
SELECTING OPERATION MODE
Heat
The air conditioner heats as well as cools. Warm your room with this versatile appliance in the
cold of winter.
1. Turn on the air conditioner.
Press the Power button on the remote control.
2. Set the operating mode.
Press the Mode button on the remote control until
Heat mode indicator appears on the remote control
display.
The air conditioner operates in Heat mode and warms
your room.
When you press the Mode button, mode will change
in order of Auto, Cool, Dry, Fan and Heat.
3. Set the temperature.
Press the Temp or button on the remote control
to decrease or increase the desired temperature.
You can set the desired temperature between
the range of 16˚C~30˚C.
You can decrease/increase the temperature by 1˚C.
4. Set the fan speed.
Press the Fan or button on the remote control to
set the desired fan speed.
If room temperature reaches desired value, heating will
stop for a while.
• When you press the Fan or button, fan speed
will change in order of Auto, Low, Medium and
High.
• Fan may not operate for about 3~5 minutes at the
beginning to prevent any cold blasts while the air
conditioner is warming up.
• Air flow can be adjusted manually. (See page 19 for instructions.)
• Since the air conditioner heats the room by taking heat energy from outdoor air, the
heating capacity may decrease when outdoor temperatures are extremely low. If you feel
the air conditioner insufficiently heats, using an additional heating appliance in combination
with the air conditioner is recommended.
AVXTJ£ª£ª_IB IM_E_29814.indd 18 2009-3-10 16:47:48
Page 19
operating _19
ENGLISH
ADJUSTING THE AIR FLOW DIRECTION
Air flow can be directed to your desired position.
Vertical air flow
Air flow blades move up and down.
1. Press the Air swing button on the remote control.
Air swing indicator will be on and the number of indicator lights move up and down.
Air flow blades move up and down continuously to circulate the air.
To keep the air flow direction in a constant position, press the Air swing button on the
remote control again.
Vertical air flow direction is adjustable when the air conditioner is cooling the room.
Horizontal air flow
Make sure one of the blade pins that stick out of the air flow blades is not broken.
1. Move the blade pins left or right to keep the air flow direction in a constant position you
prefer.
To avoid any injuries, please move the blade pin after stopping Air Swing mode.
While the air conditioner cools the room, operate the appliance with the air flow blades
pointing upwards. If the unit operates in Cool mode for an extended period of time with the
air flow blades pointing downward, moisture may generate from the temperature difference
and thus carries the risk of electric shock or unit malfunction.
Cooling/Heating
Heating
CAUTION
AVXTJ£ª£ª_IB IM_E_29814.indd 19 2009-3-10 16:47:53
Page 20
20_ using advanced functions
using advanced functions
SETTING THE TIMER
This advanced Timer function allows you to turn on/off your air conditioner automatically even when you are
away. Simply set the time and your air conditioner will turn on/off automatically.
On timer
This function allows you to turn on the air conditioner
automatically within the time range of 24 hours. On timer
is available while your air conditioner is on/off.
1. Press the On Timer button on the remote control.
On timer indicator blinks on the remote control display.
2. Set the time you want the air conditioner to turn on automatically.
Press the Time or button on the remote control
to change the time setting while On timer indicator
is blinking. You can set the time up to 24 hours,
increasing in 30 minute unit up to first 3 hours and in
hourly unit after first 3 hours.
3. Press the Set/Cancel button on the remote control to
active it on.
The remote control display will show the hour(s) you
have set.
The air conditioner will operate automatically at set time and then On timer indicator
disappears. If On timer is not set within 10 seconds, the air conditioner will end setting.
4. Set the operating mode.
Press the Mode button on the remote control until the
desired mode appears on the remote control display.
The air conditioner will operate in the mode you set.
On timer function is available in Auto/Cool/Dry/Fan/
Heat mode.
• Temperature can also be adjusted. (See step 3 on page 15 for instructions.)
• After the set up while the unit is off, approximately after 10 seconds, all the other
indicators will be gone except the On timer indicator and remaining time.
• Setting time allows you to change by pressing the On Timer button. Press the Time
or button to change time setting and then press the Set/Cancel button to active it on.
AVXTJ£ª£ª_IB IM_E_29814.indd 20 2009-3-10 16:48:00
Page 21
using advanced functions _21
ENGLISH
To deactivate the On timer
1. Press the Set/Cancel button on the remote control.
On timer you set will be canceled and On timer indicator will disappear.
Off timer
This function allows you to turn off the air conditioner automatically within the time range of 24
hours. Off timer is functional when the unit is operating.
1. Press the Off Timer button on the remote control.
Off timer indicator blinks on the remote control display.
2. Set the time you want the air conditioner to turn off
automatically.
Press the Time or button on the remote control
to change the time setting while Off timer indicator
is blinking. You can set the time up to 24 hours,
increasing in 30 minute unit up to first 3 hours and in
hourly unit after first 3 hours.
3. Press the Set/Cancel button on the remote control to
active it on.
The remote control display will show the hour(s) you
have set.
The air conditioner will operate automatically at set time and then Off timer indicator
disappears. If Off timer is not set within 10 seconds, the air conditioner will end setting
.
• Setting time allows you to change by pressing the Off Timer button. Press the Time
or button to change time setting and then press the Set/Cancel button to active it on.
• You can combine Off timer function with On timer function to turn on and then off the air
conditioner at the desired time. (See page 22 for instructions.)
To deactivate the Off timer
1. Press the Set/Cancel button on the remote control.
Off timer you set will be canceled and Off timer indicator will disappear.
Off timer function is available in Auto/Cool/Dry/Fan/Heat mode.
AVXTJ£ª£ª_IB IM_E_29814.indd 21 2009-3-10 16:48:04
Page 22
22_ using advanced functions
using advanced functions
SETTING THE TIMER
Combining On timer and Off timer
You can combine the On timer and Off timer together for
more convenient use of the timer function.
1. Set the On timer.
Press the On Timer button.
Set the time with Time or button.
Press Set/Cancel button to activate the On timer.
See page 20 for more detail instructions on setting On timer.
2. Set the Off timer.
Press the Off Timer button.
Set the time with Time or button.
Press Set/Cancel button to activate the Off timer.
When you set the time, there can be two possible
options:
On timer is shorter than Off timer
The air conditioner will turn on and then off
automatically. Set up should be done while the air
conditioner is off.
For example, If the On timer is set at 3 hours and the Off timer at 5 hours, the air
conditioner will turn off automatically 3 hours after the set time and then operate for next 2
hours before turning off automatically.
On timer is longer than Off timer
The air conditioner will turn off and then on
automatically. Set up should be done while the air
conditioner is operating.
For example, If the On timer is set at 3 hours and
the Off timer at 1 hour, the air conditioner will turn off
automatically an hour after the set time and remain off
for 2 hours before turning on automatically.
See page 21 for more detail instructions on setting Off
timer.
To deactivate the timer combination
1. Press the Set/Cancel button on the remote control.
Both of the On and Off timer will be canceled and the indicators will disappear.
AVXTJ£ª£ª_IB IM_E_29814.indd 22 2009-3-10 16:48:11
Page 23
using advanced functions _23
ENGLISH
USING THE FUNCTION
, Micro Plasma Ion, generates hydrogen(H) and oxygen(O2) to remove a polluted substance and
decomposition of such harmful particles. It makes you breathe better as if you were staying around
waterfalls, ocean surf, rivers and mountains.
1. Press the button on the remote control.
indicator will appears on the remote control
display and the air conditioner generates MPI.
• The mode can be selected whether the air
conditioner is on/off.
•
The mode will be on automatically when you
turn on the air conditioner.
To deactivate mode
1. Press the button on the remote control.
mode you set will be canceled and blue light will turn off.
AVXTJ£ª£ª_IB IM_E_29814.indd 23 2009-3-10 16:48:15
Page 24
24_cleaning and maintaining
cleaning and maintaining the
air conditioner
CLEANING THE EXTERIOR
1. Wipe the surface of the unit with a slightly wet or dry cloth when
needed.
Do not use Benzene, Thinner or Clorox
TM
.
They may damage the surface of the air conditioner and can create a
risk of fire.
CLEANING THE FILTER
When cleaning the filter, make sure to unplug the power from the unit. No special tools are needed to clean
it.
Air filter
Washable air filter captures large particles from the air. The filter is cleaned with a vacuum or by
hand washing. Filter clean indicator will light up when air filter need to be cleaned.
1. Open the front panel.
Grab the top portion of the front panel and
pull the front cover towards yourself. Unhook
the safety string and lift up the front panel.
2. Grab the handle and slightly
press the air filter down to bent
the air filter. Then, pull the Air
filter towards you and lift it up to
remove the Air filter.
3. Clean the Air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with
running water and dry it in a ventilated area.
• For the best conditions, repeat every two weeks.
• If the Air filter dries in a confined (or humid) area, odors may generate. If it occurs,
re-clean and dry it in a well-ventilated area.
4. Insert the Air filter back in its original position.
5. Close the front panel.
Grab the side of the front panel and place the bottom first, then push the panel.
CAUTION
AVXTJ£ª£ª_IB IM_E_29814.indd 24 2009-3-10 16:48:19
Page 25
cleaning and maintaining _25
ENGLISH
Anti-allergy filter
Washable Anti-allergy filter leads to reduction in allergens that thrive in polluted air. The filter is
cleaned with a vacuum or by hand washing.
1. Open the front panel.
Grab the top portion of the front panel and pull
the front cover towards yourself. Unhook the
safety string and lift up the front panel.
2. Grab the handle and slightly press the air filter down to bent the air filter. Then, pull the Air
filter towards you and lift it up to remove the Air filter.
3. Pull and slide out the Anti-allergy filter.
4. Clean the Anti-allergy filter with a vacuum cleaner or soft brush. Then rinse it with running
water and dry it in a ventilated area.
5. Install the Anti-allergy filter back in position.
6. Close the front panel.
Grab the side of the front panel and place the bottom first, then push the panel.
Clean the Anti-allergy filter every 3 months. The cleaning term may differ on usage and
environmental conditions.
AVXTJ£ª£ª_IB IM_E_29814.indd 25 2009-3-10 16:48:22
Page 26
26_cleaning and maintaining
cleaning and maintaining the
air conditioner
REPLACING THE FILTER
Replacement filter may be purchased from the retail store or ordered from the dealer where you purchased
the unit. If you cannot find one, please call a contact center.
Deodorizing filter
Deodorizing filter absorbs efficiently cigarette smoke, pet odors and other unpleasant smells.
Deodorizing filter cleaning is simple, just remove old filter and install a new one.
1. Open the front panel.
Grab the top portion of the front panel and
pull the front cover towards yourself. Unhook
the safety string and lift up the front panel.
2. Grab the handle and slightly press the air filter down to bent the air filter. Then, pull the Air
filter towards you and lift it up to remove the Air filter.
3. Pull and slide out the Deodorizing filter.
4. Install the new Deodorizing filter back in position.
5. Close the front panel.
Grab the side of the front panel and place the bottom first, then push the panel.
• The replacement timing of the Deodorizing filter differs depending on usage and
environmental conditions.
• Even if Deodorizing and Anti-allergy filters are installed in an inverted position it will not
significantly affect its filtration system.
AVXTJ£ª£ª_IB IM_E_29814.indd 26 2009-3-10 16:48:24
Page 27
cleaning and maintaining _27
ENGLISH
MAINTAINING YOUR AIR CONDITIONER
If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in
best condition.
1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and disconnect
the power plug. There may be internal damage if moisture is left in components.
2. Before using the air conditioner again, dry the inner components of the air conditioner again
by running in Fan mode for 3 to 4 hours. This helps remove odors which may have generated
from dampness.
Periodical checks
Refer to the following chart to maintain the air conditioner properly.
Type Description Monthly
Every 4
months
Once a
year
Indoor unit
Clean the air filter (1)
Clean the condensate drain pan (2)
Thoroughly clean the heat exchanger (2)
Clean the condensate drain pipe (2)
Replace the remote control batteries (1)
Outdoor unit
Clean the heat exchanger on the outside of
the unit (2)
Clean the heat exchanger on the inside of
the unit (2)
Clean the electric components with jets of
air (2)
Verify that all the electric components are
firmly tightened (2)
Clean the fan (2)
Verify that all the fan assembly is firmly
tightened (2)
Clean the condensate drain pan (2)
The checks and maintenance operations described are essential to guarantee the
efficiency of the air conditioner. The frequency of these operations varies according to the
characteristics of the area, the amount of dust, etc.
(1) The described operations should be performed more frequently if the area of installation
is very dusty.
(2) These operations must always be performed by qualified personnel. For more detailed
information, see the Installation Manual.
AVXTJ£ª£ª_IB IM_E_29814.indd 27 2009-3-10 16:48:25
Page 28
28_cleaning and maintaining
cleaning and maintaining the
air conditioner
MAINTAINING YOUR AIR CONDITIONER
Internal protections via the unit control system
This internal protection operates if an internal fault occurs in the air conditioner.
Type Description
Against cold air
The internal fan will be off to against cold air when the heat pump is
heating.
De-ice cycle
The internal fan will be off to against cold air when the heat pump is
heating.
Anti-protection of
internal battery
The compressor will be off to protect internal battery when the air
conditioner operates in Cool mode.
Protect compressor
The air conditioner does not start operating immediately to protect the
compressor of the outdoor unit after it has been started.
If the heat pump is operating in Heat mode, De-ice cycle is actuated to remove frost from
an outdoor unit that may have deposited at low temperatures.
The internal fan is switched off automatically and restarted only after the de-ice cycle is
completed.
AVXTJ£ª£ª_IB IM_E_29814.indd 28 2009-3-10 16:48:25
Page 29
appendix _29
ENGLISH
appendix
TROUBLESHOOTING
Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary
expenses.
PROBLEM SOLUTION
The air conditioner does
not operate immediately
after it has been
restarted.
• Because of the protective mechanism, the appliance does not start
operating immediately to keep the unit from overloading.
The air conditioner will start in 3 minutes.
The air conditioner does
not work at all.
• Check that the power plug is properly connected. Insert the power plug
into the wall socket correctly.
• Check if the circuit breaker is switched off.
• Check if there is a power failure.
• Check your fuse. Make sure it is not blown out.
The temperature does
not change.
• Check if you selected Fan mode.
Press the
Mode button on the remote control to select another mode.
The cool(warm) air does
not come out of the air
conditioner.
• Check if the set temperature is higher (lower) than the current
temperature. Press the Temperature
button on the remote control to
change the set temperature. Press the
Temperature or button to
increase
or decrease the temperature.
• Check if the air filter is blocked by dirt. Clean the Air filter every two weeks.
• Check if the air conditioner has just been turned on. If so, wait 3 minutes.
The fan speed does not
change.
• Check if you selected Auto or Dry mode.
The air conditioner automatically adjusts the fan speed to Auto in Auto/Dry
mode.
Timer function does not
set.
• Check if you press the Set/Cancel button on the remote control after you
have set the time.
Odors permeate in the
room during operation.
• Check if the appliance is running in a smoky area or if there is a smell
entering from outside. Operate the air conditioner in Fan mode or open
the windows to air out the room.
The air conditioner
makes a bubbling sound.
• A bubbling sound may be heard when the refrigerant is circulating through
the compressor. Let the air conditioner operate in a selected mode.
Water is dripping from
the air flow blades.
• Check if the air conditioner has been cooling for an extended period of
time with the air flow blades pointed downwards. Condensation may
generate due to the difference in temperature.
Remote control is not
working.
• Check if your batteries are depleted.
• Make sure batteries are correctly installed.
• Make sure nothing is blocking your remote control sensor.
• Check that there are strong lighting apparatus near the air conditioner.
Strong light which comes from fluorescent bulbs or neon signs may
interrupt the electric waves.
AVXTJ£ª£ª_IB IM_E_29814_3.10.09.indd 29 2009-3-10 16:54:24
Page 30
30_ appendix
appendix
OPERATION RANGES
The table below indicates the temperature and humidity ranges the air conditioner can be operated within.
Refer to the table for efficient use.
MODE
OPERATIONAL TEMPERATURE
INDOOR HUMIDITY IF OUT OF CONDITIONS
INDOOR OUTDOOR
COOLING 18˚C to 32˚C -5˚C to 43˚ 80% or less
Condensation may occur on
the indoor unit with risk to have
either water blow off or drops on
the floor.
HEATING
27˚C or less -20˚C to 24˚C -
Internal protection triggers and
the air conditioner will stop.
DRYING 18˚C to 32˚C -5˚C to 43˚C -
Condensation may occur on
the indoor unit with risk to have
either water blow off or drops on
the floor.
The standardized temperature for heating is 7˚C. If the outdoor temperature drops to 0˚C or below,
the heating capacity can be reduced depending on the temperature condition.
If the cooling operation is used at over 32˚C(indoor temperature), it does not cool at its full capacity.
Installation Part
AVXTJ£ª£ª_IB IM_E_29814.indd 30 2009-3-10 16:48:25
Page 31
installing your air conditioner _31
ENGLISH
Performing Leak Test & Insulation
LEAK TEST WITH NITROGEN(before opening valves)
In order to detect basic refrigerant leaks, before recreating the
vacuum and recirculating the R410A, it’s responsible of installer
to pressurize the whole system with nitrogen(using a pressure
regulator) at a pressure above 4.1MPa(gauge).
LEAK TEST WITH R410A(after opening valves)
Before opening valves, discharge all the nitrogen into the
system and create vacuum. After opening valves check leaks
using a leak detector for refrigerant R410A.
Leak test
6.
The pipes & cable should be gone through the bottom
back hole.
7.
Hanging the indoor unit on the Bracket Hanger, then fix the
Indoor Unit by using 4 Screws.
Case 1. Installing on the floor : Must fix 4 screws on the wall,
make the indoor not to fall down(For safety installation).
Case 2. Hanging on the wall : Follow the installation guide
supplied in the accessory part.
Screw positions are specified on the installation guide.
1.
When you install the indoor with side-pipe connection,
please make space more than 300mm from the wall.
2.
When you install the indoor at the inclined floor, please
lean the set toward the drain hose and pipe connection to
prevent water overflowing.
3. Please remove the items when set is installed.
AVXTJH028/036EE : 6 Items
AVXTJH056EE : 7 Items.
4.
The body front should be opened to connect pipes.
Please release the 4 screws of body front and then pull it
out from the bottom of the set.
5.
Make a hole on the wall.
300mm
300mm
Position
of drain
Ø60~65mm
Inside
room
Outside
room
Drain hose
Less than 70mm
75mm
Position
of drain
Discharge all the nitrogen to create a vacuum and
charge the system.
CAUTION
Screw Hole
Screw Hole
Indoor Unit Installation
It is recommended to install the Y-joint before installing the
indoor unit.
Installation Part
AVXTJ£ª£ª_IB IM_E_29814.indd 31 2009-3-10 16:48:31
Page 32
32_installing your air conditioner
1.
To avoid condensation problems, place T13.0 or thicker
Acrylonitrile Butadien Rubber separately around each
refrigerant pipe.
Always make the seam of pipes face upwards.
Note
2.
Wind insulating tape around the pipes and drain hose
avoiding to compress the insulation too much.
3.
Finish wrapping insulating tape around the rest of the
pipes leading to the outdoor unit.
4.
The pipes and electrical cables connecting the indoor unit
with the outdoor unit must be fixed to the wall with
suitable ducts.
Once you have checked that there are no leaks in the system,
you can insulate the piping and hose.
Insulation
All refrigerant connection must be accessible, in order
to permit either unit maintenance or removing it
completely.
CAUTION
No gap
NBR(T13.0 or thicker)
5.
Select the insulation of the refrigerant pipe.
Insulate the gas side and liquid side pipe referring to the
thickness according to the pipe size.
The thickness according to the pipe size is a standard of
the indoor temperature of 27°C and humidity of 80%.
If installing in an unfavorable conditions, use thicker one.
Insulator’s heat-resistance temperature should be more
than 120°C.
Pipe size
(mm)
Minimum thickness
of insulation (mm)
Remarks
PE foam
EPDM
foam
Ø6.35~Ø15.88 13 10
If you install the pipe
underground, at the seaside,
a spa or on the lake, use 1 grade
thicker one according to the
pipe size.
- 25 19
Install the insulation not to get wider and use the
adhesives on the connection part of it to prevent
moisture from entering.
Wind the refrigerant pipe with insulation tape
if it is exposed to outside sunlight.
Install the refrigerant pipe respecting that the
insulation does not get thinner on the bent part or
hanger of pipe.
Add the additional insulation if the insulation
plate gets thinner.
CAUTION
Additional insulation
Refrigerant pipe insulation
a× 3
a
Hanger
CAUTION
Must fit tightly against body
without any gap.
Insulation cover pipe
Indoor unit
Be sure to overlap
the insulation
Drain hose installation
When installing the drain hose for the indoor unit,
check if condensation draining is adequate.
When passing the drain hose through the 65mm hole drilled
in the wall, check the following:
The hose must
NOT slant upwards.
The end of the drain hose must
NOT be placed under water.
Do NOT bend the hose in
different directions.
Keep a clearance of at least
5cm between the end of the
hose and the ground.
5cm
less
Do NOT place the end of the
drain hose in a hollow.
Ditch
AVXTJ£ª£ª_IB IM_E_29814.indd 32 2009-3-10 16:48:35
Page 33
installing your air conditioner _33
ENGLISH
Wiring Work
Silver solder
1.
Before wiring work, you must turn off all power source.
2.
Indoor unit power should be supplied through the
breaker(MCCB, ELB) separated by the outdoor power.
3.
The power cable should be used only copper wires.
4.
Connect the power cable{1(L), 2(N)} among the units within
maximum length and communication cable(F1, F2) each.
5.
Connect V1, V2(for DC12V) and F3, F4(for communication)
when installing the wired remote Control.
Power and communication cable connection
N L
N L
N L
N L
Indoor Unit 1
Outdoor
Unit
Wired Remote
Control
220-240V~
ELB : Essential Installation
Ceiling, wall-mounted indoor unit.
Indoor Unit 2 Indoor Unit 3
Indoor Unit 4 Indoor Unit 5 Indoor Unit 6
EEV kit
Selecting compressed ring terminal
Norminal
dimensions
for cable
(mm
2
)
Norminal
dimensions
for screw
(mm
)
B D d1 E F L d2 t
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Standard
dimension
(mm)
Allowance
(mm)
Min. Min. Max.
Standard
dimension
(mm)
Allowance
(mm)
Min.
1.5
4 6.6
±0.2 3.4
+0.3
-0.2
1.7
±0.2 4.1 6 16 4.3
+0.2
0
0.7
4 8
2.5
4 6.6
±0.2 4.2
+0.3
-0.2
2.3
±0.2 6 6 17.5 4.3
+0.2
0
0.8
4 8.5
4 4 9.5 ±0.2 5.6
+0.3
-0.2
3.4
±0.2 6 5 20 4.3
+0.2
0
0.9
Specification of electronic wire
Power supply MCCB ELB
Power
cable
Earth
cable
Communication
cable
Max : 242
V
Min : 198V
X A
X A, 30mmA
0.1 sec
2.5mm
2
2.5mm20.75~1.5mm
2
Decide the capacity of ELB and MCCB by below formula.
The capacity of ELB, MCCB X [A] = 1.25 X 1.1 X ∑Ai
X
: The capacity of ELB, MCCB
∑Ai : Sum of Rating currents of each indoor unit.
Refer to each installation manual about the rating current of indoor unit.
Decide the power cable specification and maximum length
within 10% power drop among indoor units.
Coef: 1.55
Lk: Distance among each indoor unit[m],
Ak: Power cable specification[mm2], ik: Running current of each unit[A]
∑ (
Coef
×35.6×Lk×ik
) <
10% of input
voltage[V]
1000×Ak
n
k=1
1.
If necessary, connect the 2 meter extension drain hose to
the drain hose.
2.
If you use the extension drain hose, insulate the inside of
the extension drain hose with a shield.
3.
Fit the drain hose into 1 of 2 drain hose holes, then fix the
end of the drain hose tightly with a clamp.
If you don’t use the other drain hose hole, block it with a
rubber stopper.
4.
Pass the drain hose under the refrigerant pipe, keeping the
drain hose tight.
5.
Pass the drain hose through the hole in the wall.
Check if it slants downwards as seen in the picture.
The hose will be fixed permanently into position
after finishing the installation and the gas leak test.
Shield
Drain hose Extension drain hose
(No default resource)
Drain hose installation
6-Ways to connect Drain Hose and Pipe
Knock out
�
WARNING
Power off before connecting any wires;
Indoor PBA will be damaged while V1,V2,F3,F4
short each other.
AVXTJ£ª£ª_IB IM_E_29814.indd 33 2009-3-10 16:48:38
Page 34
34_installing your air conditioner
Indoor Unit Setting
1.
Before installing the indoor unit, assign an address to the
indoor unit according to the air conditioning system plan.
2.
The address of the indoor unit is assigned by adjusting
MAIN(SW01, SW02) and RMC(SW03, SW04) rotary switches.
Additional Functions
Setting MAIN Address
The MAIN address is for communication between the
indoor unit and the outdoor unit. Therefore, you must
set it to operate the air conditioner properly.
You can set the MAIN address from ‘00’ to ‘99’ by mixing
SW01 and SW02.
The MAIN address from ‘00’ to ‘99’ should differ from
each other.
Check the indoor unit address on the plan that you are
to install and set the address according to the plan.
You may not need to set MAIN address if you
selected Auto Address Setting from the outdoor
unit: see details on the outdoor unit installation
manual.
Note
When MAIN address is set as “12”.
For Example
Setting RMC Address
The SW03, SW04 RMC switch is the address setting
switch for controlling the indoor unit with the centralized
controller.
You must set the SW03, SW04 and K2 switch when using
the centralized controller.
When RMC address is set as “12”.
For Example
SW03 SW04
No. Function ON OFF
SW05
K1 - - -
K2 Centralized controller Not use Use
K3 - - -
K4 - - -
No. Function ON OFF
SW0
6
K5
Heating Current Temperature Compensation
+2°C +5°C
K6 Filter Time
1,000
hours
2,000
hours
K7 - - -
K8 - - -
No. Function ON OFF
SW0
7
K9
Indoor Expansion Valve
For Heating Stop
Fix 80 step 0 or 80 step
K10
Wired Remocon Group
Master
Not Use Use
K11 External control Not Use Use
K12 - - -
SW01 SW02
SW03
SW05 SW06 SW07
SW04
AVXTJ£ª£ª_IB IM_E_29814.indd 34 2009-3-10 16:48:45
Page 35
memo _35
ENGLISH
AVXTJ£ª£ª_IB IM_E_29814.indd 35 2009-3-10 16:48:45
Page 36
IFSE P
Ne
RGD
HuPo
DB98-29814A(1)
QUESTIONS OR COMMENTS?
COUNTRY CALL OR VISIT US ONLINE AT
BELGIUM 02 201 2418
www.samsung.com/be (Dutch)
www.samsung.com/be_fr (French)
CZECH REPUBLIC 800 - SAMSUNG (800-726786) www.samsung.com/cz
DENMARK 8 - SAMSUNG(7267864) www.samsung.com/dk
FINLAND 30 - 6227 515 www.samsung.com/fi
FRANCE 01 4863 0000 www.samsung.com/fr
GERMANY 01805 - SAMSUNG(726-7864 € 0,14/Min) www.samsung.com/de
HUNGARY
06-80-SAMSUNG(726-7864) www.samsung.com/hu
ITALIA
800-SAMSUNG(726-7864) www.samsung.com/it
LUXEMBURG 0035 (0)2 261 03 710 www.samsung.com/lu
NETHERLANDS 0900-SAMSUNG (0900-7267864) (€ 0,10/Min) www.samsung.com/nl
NORWAY
3 - SAMSUNG(7267864) www.samsung.com/no
POLAND
0 801 1SAMSUNG(172678)
022-607-93-33
www.samsung.com/pl
PORTUGAL
80820-SAMSUNG(726-7864) www.samsung.com/pt
SLOVAKIA
0800-SAMSUNG(726-7864) www.samsung.com/sk
SPAIN
902 - 1 - SAMSUNG (902 172 678) www.samsung.com/es
SWEDEN 075 - SAMSUNG(726 78 64) www.samsung.com/se
U.K 0845 SAMSUNG (7267864) www.samsung.com/uk
EIRE 0818 717 100 www.samsung.com/ie
AUSTRIA 0810 - SAMSUNG(7267864, € 0.07/min) www.samsung.com/at
Switzerland 0848 - SAMSUNG(7267864, CHF 0.08/min) www.samsung.com/ch
AUSTRALIA 1300 362 603 www.samsung.com/au
New zealand 0800 SAMSUNG (0800 726 786) www.samsung.com/nz
"EEE Yönetmeliğine Uygundur"
"This EEE is compliant with RoHS"
AVXTJ£ª£ª_IB IM_E_29814_5.05.09.indd 36 2009-5-5 13:21:24
Page 37
Air Conditioner
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please
register your product at
www.samsung.com/global/register
Console Type Series
Floor : AVXTJ
AVXTJ｣ｪ｣ｪ_IB IM_E_29814.indd 37 2009-05-08 ｿﾀﾀ・10:18:38
Loading...
