Samsung 2233GW User Manual

LCD Monitor

User Manual

Safety Instructions

Notational

Note

These safety instructions must be followed to ensure your safety and prevent property damage.

Make sure to read the instructions carefully and use the product in the correct manner.

Warning / Caution

Otherwise, it may result in death or personal injury. Otherwise, it may result in personal injury or property damage.

Notational Conventions

Power

Prohibited

Do not disassemble

Do not touch

When not used for extended period of time, set your computer to DPM. If using screen saver, set it to active screen mode. The images here are for reference only, and are not applicable in all cases (or

countries). Shortcut to Anti-Afterimage Instructions

Do not use a damaged power cord or plug or a damaged or loose power

outlet.

Important to read and understand at all times

Disconnect the plug from the outlet

Ground to prevent an electric shock

• Otherwise, this may result in electric shock or fire.

Do not touch the power plug with wet hands when removing or plug-

ging the plug into the outlet.

• Otherwise, this may result in electric shock.

Make sure to connect the power cord to a grounded power outlet.

• Otherwise, it may result in electric shock or personal injury.

1

Safety Instructions

Ensure that the power plug is plugged into the power outlet firmly and

correctly.

• Otherwise, this may result in fire.

Do not forcefully bend or pull the power plug and do not place any

heavy material on it.

• Otherwise, this may result in fire.

Do not connect multiple appliances to the same power outlet.

• Otherwise, this may cause fire due to overheating.

Do not disconnect the power cord while using the monitor.

• Otherwise, this may result in damage to the product due to electric shock.

To disconnect the apparatus from the mains, the plug must be pulled out from the mains socket, therefore the mains plug shall be readily operable.

Installation

• This may cause electric shock or fire.

Use only the power cord provided by our company. Do not use the provided power cord of another product.

• Otherwise, this may result in fire or electric shock.

Be sure to contact an authorized Service Center when installing your monitor in a location with heavy dust, high or low temperatures, high humidity, and exposed to chemical substances and where it operates for 24 hours such as at airports, train stations etc.

Failure to do so may cause serious damage to your monitor.

Do not drop the monitor when moving it.

• This may cause damage to the product or the person carrying it.

When installing the product in a cabinet or rack, make sure that the front end of the bottom of the product does not project out.

• Otherwise, it may fall or cause personal injury.

• Use a cabinet or rack of a size appropriate to the product.

DO NOT PLACE CANDLES,MOSQUITO REPELLANT,CIGARETTES AND ANY HEATING APPLIANCES NEAR THE PRODUCT.

• Otherwise, this may cause fire.

2

Safety Instructions

Keep heating appliances as far away from the power cord or the product as possible.

• Otherwise, this may result in electric shock or fire.

Do not install it in a badly ventilated location such as a bookcase or closet.

• Otherwise, this may result in fire due to an increase in the internal

temperature.

Put down the monitor carefully.

• Failing to do so may damage the monitor.

Do not place the front of the product on the floor.

• Otherwise, this may result in damage to the screen display.

Ensure that an authorized installation company installs the wall mount.

Clean

• Otherwise, it may fall and cause personal injury.

• Make sure to install the specified wall mount.

Install your product in a well ventilated location. Ensure that there is a clearance of more than 10 cm from the wall.

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Ensure that the packaging vinyl is kept away from children.

• Otherwise, it may result in serious harm (suffocation) if children play

with it.

If the height of your monitor is adjustable, do not place any object or part of your body on the stand when lowering it.

• This may cause damage to the product or the person carrying it.

When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a slightly moistened, soft fabric.

Do not spray cleaner directly onto the surface of the product.

• Otherwise, this may result in the discoloration and distortion of the

structure and the screen surface may peel off.

Clean the product using a soft cloth with a monitor cleaner only. If you must use a cleaner other than the monitor cleaner, dilute it with water at a ratio of 1:10.

3

Safety Instructions

When cleaning the power plug pins or dusting the power outlet, clean it with a dry cloth.

• Otherwise, it may result in fire.

When cleaning the product, make sure to disconnect the power cord.

• Otherwise, it may result in electric shock or fire.

When cleaning the product, disconnect the power cord and clean it softly with a dry cloth.

• (Do not use chemicals such as wax, benzene, alcohol, thinner, mos-

quito repellant, lubricant, or cleaner.) These may change the appearance of the product surface and peel off the indication labels on the product.

Since the product housing is easily scratched, make sure to use the specified cloth only.

• Use the specified cloth adding only a little water. As the product may

be scratched if there is any foreign material on the cloth, make sure to shake it thoroughly before using it.

When cleaning the product, do not spray water directly onto the main body of the product.

Others

• Ensure that water does not enter the product and that it is not wet.

• Otherwise, this may result in electric shock, fire or a malfunction.

The product is a high voltage product. Ensure that users do not disassemble, repair or modify the product themselves.

• Otherwise, this may result in electric shock or fire. If the product

needs to be repaired, contact a Service Center.

If there is a strange smell or a strange sound or smoke is coming from the product, disconnect the power plug immediately and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

Do not place this product in a location exposed to moisture, dust, smoke, water, or in a car.

• Otherwise, this may result in electric shock or fire.

When you drop the product or the case is broken, turn the power off and disconnect the power cord. Contact a Service Center.

• Otherwise, this may result in electric shock or fire.

4

Safety Instructions

If thunder or lightening is occurring, do not touch the power cord or antenna cable.

• Otherwise, this may result in electric shock or fire.

Do not try to move the monitor by pulling only the wire or the signal cable.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Do not lift or move the product back and forwards or right and left while only holding the power cord or signal cables.

• Otherwise, it may fall and result in electric shock, damage to the

product or fire due to damage to the cable.

Make sure that the ventilating opening is not blocked by a table or curtain.

• Otherwise, it may result in fire due to an increase in the internal tem-

perature.

Do not place any containers containing water, vases, flowerpots, medicines as well as any metal on the product.

• If water or a foreign material enters the product, disconnect the power

cord and contact a Service Center.

• This may result in a product malfunction, electric shock, or fire.

Do not use or keep combustible spray or flammable material near the product.

• Otherwise, this may result in an explosion or fire.

Do not insert any metal, such as chopsticks, coins, pins and steel, or flammable objects, such as matches or paper, inside the product (through the ventilating openings, input and output terminals, etc).

• If water or foreign material enters the product, disconnect the power

cord and contact a Service Center.

• Otherwise, this may result in electric shock or fire.

When using a fixed screen for a long time, an afterimage or stain may occur.

• If you are not using your product for a long period of time, put it into

sleep mode or use a moving screen saver.

Set a resolution and frequency appropriate to the product.

• Otherwise, your eyesight may be damaged.

Keep the volume at a comfortable level when using the headphones.

• Excessively loud volume level may damage hearing.

5

Safety Instructions

If you continually move closer to the product screen, your eyesight may be failing.

To ease eye strain, take at least a five-minute break after every hour of using the monitor.

Do not install it in an unstable location such as an unstable rack or uneven surface or a location exposed to vibrations.

• Otherwise, it may fall and cause personal injury and/or damage the

product.

• If you use the product in a location exposed to vibrations, it may

damage the product and result in fire.

When moving the product, turn the power off and disconnect the power plug, antenna cable, and all the cables connected to the product.

• Otherwise, it may result in electric shock or fire.

Ensure that children do not hang onto the product or climb up onto the product.

• The product may fall and cause personal injury or death.

If you do not use the product for a long period of time, disconnect the power cord from the power outlet.

• Otherwise, this may result in overheating or fire due to dust, and may

result in fire due to electric shock or leakage.

Do not place any heavy items or toys or confectionery, such as cookies etc. that may attract the attention of children and to the product.

• Your children may hang onto the product causing it to fall and this

may result in personal injury or death.

Do not turn the product upside down or move it while holding only the stand.

• Otherwise, it may fall and result in personal injury and/or damage to

the product.

Do not place the product in a location exposed to direct sunlight or near any heat such as a fire or heater.

• This may reduce the lifetime of the product, and may result in fire.

Do not drop any objects onto the product or cause any impact to the product.

• Otherwise, this may result in electric shock or fire.

6

Safety Instructions

Do not use a humidifier or kitchen table near the product.

• Otherwise, this may result in electric shock or fire.

When there is a gas leak, do not touch the product or the power plug but ventilate immediately.

• If a spark occurs, it may cause an explosion or fire.

If the product has been turned on for a long time, the display panel becomes hot. Do not touch it.

• Keep the small accessories in a location out of the reach of children.

Be careful when adjusting the angle of the product or the height of the stand.

• This may result in personal injury as your hand or fingers may be-

come caught.

• Also, if you tilt the product too far, it may fall and cause personal

injury.

Do not install the product in a location low enough for children to reach.

• Otherwise, it may fall and result in personal injury.

• Since the front part of the product is heavy, install the product on a

level and stable surface.

Do not put any heavy objects on the product.

• This may result in personal injury and/or damage to the product.

Good Postures When Using the Monitor

When using the product, use it in the correct position.

• Keep your back straight while looking at the product.

• The distance between your eyes and the screen should be between 45 to 50 cm. Look at the screen from a slightly higher location than the height of the screen.

• When using the product, use it in the correct position.

• Adjust the angle so that light is not reflected on the screen.

• Place your arms perpendicular to your sides and allow your arms to be level with the back of the hand.

• Keep your elbow at 90 degrees.

• Keep your knees at greater than 90 degrees, and keep your heels firmly on the floor. Keep your arms lower than your heart.

7

Introduction

Package Contents

Note

Please make sure the following items are included with your monitor.

If any items are missing, contact your dealer.

Contact a local dealer to buy optional items.

Unpacking

Monitor

Manuals

Quick Setup Guide Warranty Card

(Not available in all loca-

Cables

D-Sub Cable Power Cord DVI Cable (option)

Others

User's Guide

tions)

Cleaning Cloth(Option) Cable holding ring

8

Note

Cleaning Cloth is only provided for highly polished black products as a product feature.

Your Monitor Initial Settings

Select the language using the up or down key.

The displayed content will disappear after 40 seconds.

Turn the Power button off and on. It will be displayed again.

Introduction

Front

It can be displayed up to three (3) times. Make sure to adjust the resolution of your PC before reaching the maximum count.

Note

The resolution displayed on the screen is the optimal resolution for this product.

Adjust your PC resolution so that it is the same as the optimal resolution for this product.

MENU button [MENU/ ]

Opens the on-screen menu and exits from the menu. Also use to exit the OSD menu or return to the previous menu.

Brightness button [ ]

When OSD is not on the screen, push the button to adjust brightness. Customized Key[ ]

9

Introduction

You can customize key assignment for the Custom button according to your preferences.

Note

You can configure the customized key for a required function via Setup > Customized Key.

Adjust buttons [ ]

These buttons allow you to adjust items in the menu.

Enter button [ ]

Activates a highlighted menu item. Push the ' ', then selects the video signal while the OSD is off. (When the ' '

button is pressed to change the input mode, a message appears in the upper left of the screen displaying the current mode -- analog or digital input signal.)

Note

• If you select the digital mode, you must connect your monitor to the graphic card's DVI port using the DVI cable.

Rear

• This function is not available for products with an Analog interface only.

AUTO button

Usethis button for auto adjustment. (Available in Analog mode only)

Power button [ ]

Use this button for turning the product on and off.

Power Indicator

This light is lit when operating normally, and blinks once when your adjustments are saved.

Note

See PowerSaver described in the manual for further information regarding power saving functions. For energy conservation, turn your monitor OFF when it is not needed or when leaving it unattended for long periods.

Note

The configuration at the back of the monitor may vary from product to product.

POWER port

10

DVI IN

Introduction

POWER port

Connect the power cord for your monitor to the POWER port on the back of the product.

DVI IN

Connect the DVI Cable to the DVI IN port on the back of your monitor.

Note

Applicable to the digital (DVI)-dedicated models only.

RGB IN

Kensington Lock

RGB IN

Connect the D-sub cable to the 15-pin, RGB IN port on the back of your monitor.

Kensington Lock

The Kensington lock is a device used to physically fix the system when using it in a public place. (The locking device has to be purchased separately.) For using a locking device, contact where you purchase it.

Note

The location of the Kensington Lock may be different depending on its model.

Using the Anti-Theft Kensington Lock

1. Insert the locking device into the Kensington slot on the Monitor locking direction .

11

and turn it in the

Introduction

2. Connect the Kensington Lock cable.

3. Fix the Kensington Lock to a desk or a heavy stationary object.

Note

See Connecting Cables for further information regarding cable connections.

Cable holding ring

• Fix the cables using the holding ring, as shown in the figure.

12

Connections

Connecting Cables

Use a connection appropriate for your computer.

Using the D-sub (Analog) connector on the video card.

• Connect the signal cable to the 15-pin, D-sub port on the back of your monitor.

Using the DVI (Digital) connector on the video card.

• Connect the DVI Cable to the DVI IN Port on the back of your Monitor.

13

Connect the power cord for your monitor to the power port on the back of the monitor.

Plug the power cord for the monitor into a nearby outlet.

Note

If the monitor and the computer are connected, you can turn them on and use them.

Using the Stand

Folding the base

Connections

Note

You can tilt the monitor upwards at an angle of -1° to 16°. ( ±1.0°)

Attaching a Base

This monitor accepts a 100 mm x 100 mm VESA-compliant mounting interface pad.

Note

The VESA dimensions given above are an example. The VESA dimensions may differ depending on the product.

14

Connections

A. Monitor B. Mounting interface pad (Sold separately)

1. Turn off your monitor and unplug its power cord.

2. Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen.

3. Remove the stand from the LCD monitor.

4. Align the mounting interface pad with the holes in the rear cover mounting pad and secure it with four screws that came with the arm-type base, wall mount hanger or other base.

• Do not use screws longer than the standard dimension, as they may damage the inside of the Monitor.

• For wall mounts that do not comply with VESA standard screw specifications, the length of the screws may differ depending on their specifications.

• Do not use screws that do not comply with the VESA standard screw specifications.

Do not fasten the screws too tightly, as this may damage the product or cause the product to fall, leading to personal injury.

Samsung is not liable for these kinds of accidents.

• Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.

• To mount the monitor on a wall, you should purchase the wall mounting kit that allows you to mount the monitor at least 10 cm away from the wall surface.

• Contact the nearest Samsung Service Center for more information. Samsung Electronics will not be responsible for damages caused by using a base other than those specified.

• Please use Wall Mount according to the International standards.

15

Using the Software

Monitor Driver

Note

When prompted by the operating system for the monitor driver, insert the CD-ROM included with this monitor. Driver installation is slightly different from one operating system to another. Follow the directions appropriate for the operating system you have.

Prepare a blank disk and download the driver program file at the Internet web site shown here.

Internet web site :

http://www.samsung.com/ (Worldwide)

Installing the Monitor Driver (Automatic)

1. Insert CD into the CD-ROM drive.

2. Click "Windows".

3. Choose your monitor model in the model list, then click the "OK" button.

4. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button (Microsoft® Windows® XP/2000 Operating System).

16

Using the Software

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

Installing the Monitor Driver (Manual)

Microsoft® Windows Vista™‚ Operating System

1. Insert your Manual CD into your CD-ROM drive.

2.

Click

(Start) and "Control Panel". Then, double-click on "Appearance and Personalization".

3. Click "Personalization" and then "Display Settings".

4. Click "Advanced Settings...".

5. Click "Properties" in the "Monitor" tab. If the "Properties" button is deactivated, it means the configuration for your monitor is completed. The monitor can be used as is.

If the message "Windows needs..." is displayed, as shown in the figure below, click "Continue".

17

Using the Software

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system. The certified driver will be posted on Samsung Monitor homepage.

6. Click "Update Driver..." in the "Driver" tab.

7. Check the "Browse my computer for driver software" checkbox and click "Let me pick from a list of device drivers on my computer".

8. Click "Have Disk...” and select the folder (for example, D:\Drive) where the driver setup file is located, and click "OK".

18

Using the Software

9. Select the model that matches your monitor from the list of monitor models on the screen, and click "Next".

10.

Click "Close" → "Close" → "OK" → "OK" on the following screens displayed in sequence.

Microsoft® Windows® XP Operating System

19

Using the Software

1. Insert CD into the CD-ROM drive.

2.

Click "Start" → "Control Panel" then click the "Appearance and Themes" icon.

3. Click "Display" icon and choose the "Settings" tab then click "Advanced...".

4. Click the "Properties" button on the "Monitor" tab and select "Driver" tab.

5. Click "Update Driver..." and select "Install from a list or..." then click "Next" button.

6. Select "Don't search, I will..." then click "Next" and then click "Have disk".

20

Using the Software

7. Click the "Browse" button then choose A:(D:\Driver) and choose your monitor model in the model list and click the "Next" button.

8. If you can see following message window, then click the "Continue Anyway" button. Then click "OK" button.

Note

This monitor driver is under certifying MS logo, and this installation doesn't damage your system.

The certified driver will be posted on Samsung Monitor homepage.

http://www.samsung.com/

9. Click the "Close" button then click "OK" button continually.

21

Using the Software

10. Monitor driver installation is completed.

Microsoft® Windows® 2000 Operating System

When you can see "Digital Signature Not Found" on your monitor, follow these steps.

1. Choose "OK" button on the "Insert disk" window.

2. Click the "Browse" button on the "File Needed" window.

3. Choose A:(D:\Driver) then click the "Open" button and then click "OK" button.

How to install

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

4. Choose "Monitor".

Case1 : If the "Properties" button is inactive, it means your monitor is properly configured. Please stop installation

Case2 : If the "Properties" button is active, click the "Properties" button then follow next steps continually.

5. Click "Driver" and then click on "Update Driver..." then click on the "Next" button.

6. Choose "Display a list of the known drivers for this device so that I can choose a specific driver" then click "Next" and then click "Have disk".

7. Click the "Browse" button then choose A:(D:\Driver).

8. Click the "Open" button, then click "OK" button.

9. Choose your monitor model and click the "Next" button then click "Next" button.

10. Click the "Finish" button then the "Close" button.

If you can see the "Digital Signature Not Found" window then click the "Yes" button. And click the "Finish" button then the "Close" button.

Microsoft® Windows® Millennium Operating System

1. Click "Start", "Setting", "Control Panel".

2. Double click the "Display" icon.

3. Select the "Settings" tab and click "Advanced Properties" button.

22

Using the Software

4. Select the "Monitor" tab.

5. Click the "Change" button in the "Monitor Type" area.

6. Choose "Specify the location of the driver".

7. Choose "Display a list of all the driver in a specific location..." then click "Next" button.

8. Click the "Have Disk" button.

9. Specify A:\(D:\driver) then click "OK" button.

10. Select "Show all devices" and choose the monitor that corresponds to the one you connected to your computer and click "OK".

11. Continue choosing "Close" button and "OK" button until you close the Display Properties dialogue box.

Microsoft® Windows® NT Operating System

1. Click "Start", "Settings", "Control Panel", and then double-click "Display" icon.

2. In Display Registration Information window, click Settings Tab and then click "All Display Modes".

3. Select a mode that you wish to use (Resolution, Number of colors and Vertical frequency) and then click "OK".

4. Click "Apply" button if you see the screen working normally after clicking "Test". If the screen is not normal, change to a different mode (lower mode of resolution, colors or frequency).

Note

If there is no Mode at All Display Modes, select the level of resolution and vertical frequency by referring to the Preset Timing Modes in the user guide.

Linux Operating System

To execute X-Window, you need to make the X86Config file, which is a type of system setting file.

1. Press "Enter" at the first and the second screen after executing the X86Config file.

2. The third screen is for setting your mouse.

3. Set a mouse for your computer.

4. The next screen is for selecting a keyboard.

5. Set a Keyboard for your computer.

6. The next screen is for setting your monitor.

7. First of all, set a horizontal frequency for your monitor. (You can enter the frequency directly.)

8. Set a vertical frequency for your monitor. (You can enter the frequency directly.)

9. Enter the model name of your monitor. This information will not affect the actual execution of X-Window.

10. You have finished setting up your monitor. Execute X-Window after setting other requested hardware.

23

Natural Color Natural Color Software Program

One of the recent problems in using a computer is that the color of the images printed out by a printer or other images scanned by a scanner or a digital camera are not the same as those shown on the monitor. The Natural Color S/W is the very solution for this problem. It is a color administration system developed by Samsung Electronics in association with Korea Electronics & Telecommunications Research Institute (ETRI). This system is available only for Samsung monitors and makes the color of the images on the monitor the same as the printed or scanned images. For more information, refer to Help (F1) in the software program.

The Natural Color is provided online. You can download it from the website below and install; http://www.samsung.com/us/consumer/learningresources/monitor/naturalcolorexpert/pop_down-

load.html

MagicTune™

Using the Software

Installation

1. Insert the installation CD into the CD-ROM drive.

2. Click the MagicTune™ installation file.

3. Select installation Language, Click "Next".

4. When the Installation Shield Wizard window appears, click "Next".

5. Select "I agree to the terms of the license agreement" to accept the terms of use.

6. Choose a folder to install the MagicTune™ program.

7. Click "Install".

8. The "Installation Status" window appears.

9. Click "Finish".

Note

If the popup window to install the software for the main screen is not displayed, proceed with the installation using the MagicTune executable file on the CD.

24

10. When the installation is complete, the MagicTune™ executable icon appears on your desktop. Double-click the icon to start the program.

MagicTune™ execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key.

Installation Problems

The installation of MagicTune™ can be affected by such factors as the video card, motherboard and the network environment.

System Requirements

OS

• Windows 2000

• Windows XP Home Edition

• Windows XP Professional

• Windows Vista™

Using the Software

Uninstall

It is recommended using MagicTune™ in Windows® 2000 or later.

Hardware

• 32 MB Memory above

• 60 MB Hard disk space above

For more information, visit the MagicTune™ website.

The MagicTune™ program can be removed only by using the "Add or Remove Programs" option of the Windows® Control Panel.

Perform the following steps remove MagicTune™.

1.

Go to [Task Tray] → [Start] → [Settings] and select [Control Panel] in the menu. If the program runs on Windows® XP, go to [Control Panel] in the [Start] menu.

2. Click the "Add or Remove Programs" icon in Control Panel.

3. In the "Add or Remove Programs" screen, scroll down to find "MagicTune™." Click on it to highlight it.

4. Click the "Change/Remove" button to remove the program.

5. Click "Yes" to begin the uninstall process.

6. Wait until the "Uninstall Complete" dialog box appears.

Note

Visit the MagicTune™ website for technical support for MagicTune™, FAQs (questions and answers) and software upgrades.

25

MultiScreen

Using the Software

The software may not be supported depending on the model.

Installation

1. Insert the installation CD into the CD-ROM drive.

2. Click the MultiScreen installation file.

3. When the Installation Shield Wizard window appears, click "Next".

4. Select "I agree to the terms of the license agreement" to accept the terms of use.

5. Choose a folder to install the MultiScreen‚ program.

6. Click "Install".

7. The "Installation Status" window appears.

Note

If the popup window to install the software for the main screen is not displayed, proceed with the installation using the MultiScreen executable file on the CD.

8. Click "Finish".

9. When the installation is complete, the Multiscreen executable icon appears on your desktop. Double-click the icon to start the program.

Multiscreen execution icon may not appear depending on specification of computer system or monitor. If that happens, press F5 Key.

Installation Problems

The installation of MultiScreen can be affected by such factors as the video card, motherboard and the network environment.

26

System Requirements

OS

• Windows 2000

• Windows XP Home Edition

• Windows XP Professional

• Windows Vista™

It is recommended using MultiScreen in Windows® 2000 or later.

Hardware

• 32 MB Memory above

• 60 MB Hard disk space above

Uninstall

Using the Software

The Multiscreen program can be removed only by using the "Add or Remove Programs" option of the Windows® Control Panel.

Perform the following steps remove Multiscreen. Select "Setting/Control Panel" on the "Start" menu and then double-click "Add/Delete a program". Select Multiscreen from the list and then click the "Add/Delete" button.

27

Adjusting the Monitor

Direct Functions AUTO

When the 'AUTO' button is pressed, the auto adjustment screen appears as shown in the animated screen on the center.

Auto adjustment allows the monitor to self-adjust to the incoming Analog signal. The values of Fine, Coarse and Position are adjusted automatically.

(Available in Analog mode only, so “AUTO” icon of OSD is gray in Digital mode.)

If auto adjustment does not work properly, press 'AUTO' button again to adjust picture with more

accuracy.

If you change resolution in the control panel, auto function will be executed automatically.

OSD Lock & Unlock

This is the function that locks the OSD in order to keep the current states of settings or prevent others from adjusting the current settings.

Lock : Hold down the MENU button for more than five (5) seconds to activate the OSD adjustment lock function.

Unlock : Hold down the MENU button for more than five (5) seconds to deactivate the OSD adjustment lock function.

When pressing the AUTO button after locking the OSD

When pressing the MENU button after locking the OSD

Note

Though the OSD adjustment lock function is activated, you can still adjust the brightness and contrast, and adjust Customized Key

( ) using the Direct button.

Customized key

You can customize key assignment for the Custom button according to your preferences.

28

To view the operating screen displayed when pressing the [ ] button after configuring the customized key for a function, click the name of each function.

(MagicBright - MagicColor - Color Effect - Image Size)

Brightness

Adjusting the Monitor

Note

You can configure the customized key for a required function via Setup > Customized Key.

ImageSize ： Supplied for the wide models only such as 16:9 or 16:10.

SOURCE

When OSD is not on the screen, push the Brightness ( ) button to adjust brightness.

Selects the video signal while the OSD is off.

Note

Not applicable to analogue (D-SUB)-or-digital (DVI)dedicated models.

OSD Function

Top Menus Sub Menus

PICTURE Bright-

ness Fine

COLOR Magic-

Color Color Ef-

fect

Contrast Sharpness Magic-

Bright

Red Green Blue Color Tone

Gamma

29

Coarse

Adjusting the Monitor


SIZE & POSITION

SETUP&RESET

INFORMATION

H-Position

Reset Menu Trans-

Auto Source

V-Position Image Size Menu H-Po-

sition

Language Off Timer

parency PC/AV Mode Display

Time

On/Off Customized

Key

Menu V-Position

Off Timer Setting

Menu Description

Brightness (Not available in MagicBright mode of Dynamic Contrast.)

You can use the on-screen menus to change the brightness according to personal preference.

The larger the number, the brighter the screen. The smaller the number, the darker the screen.

Contrast (Not available in MagicBright mode of Dynamic Contrast.)

You can use the on-screen menus to change the contrast according to personal preference.

The larger the number, the brighter the screen. The smaller the number, the darker the screen.

( Not available in MagicColor mode of Full and Intelligent. )

Sharpness Changes the clearance of image.

The larger the number, the clearer the screen. The smaller the number, the less clear the screen.

( Not available in MagicColor mode of Full and Intelligent. )

MagicBright

Push the button to circle through available preconfigured modes. MagicBright is a new feature providing optimum viewing environment

depending on the contents of the image you are watching. Currently seven different modes are available: Custom, Text, Internet, Game, Sport, Movie and Dynamic Contrast. Each mode has its own pre-

30

Menu Description

configured brightness value. You can easily select one of seven settings by simply pressing Customized Key control button.

• Custom

Although the values are carefully chosen by our engineers, the preconfigured values may not be comfortable to your eyes depending on your taste.

If this is the case, adjust the brightness and contrast by using the OSD menu.

• Text

For documentations or works involving heavy text.

• Internet

For working with a mixture of images such as texts and graphics.

• Game

Adjusting the Monitor

For watching motion pictures such as a game.

• Sport

For watching motion pictures such as a sport.

• Movie

For watching motion pictures such as a DVD or Video CD.

• Dynamic Contrast Dynamic Contrast is to automatically detect distribution of input-

ted visual signal and adjust to create optimum contrast.

Coarse Removes noise such as vertical stripes.

The larger the number, the more the screen increases vertically. The smaller the number, the more the screen decreases vertically.

Coarse adjustment may move the screen image area. You may relocate it to the center using the horizontal control menu.

(Available in Analog mode only)

Fine Removes noise such as horizontal stripes.

If the noise persists even after Fine tuning, repeat it after adjusting the frequency (clock speed).

(Available in Analog mode only)

31

Color

Adjusting the Monitor

Menu Description

MagicColor MagicColor is a new technology that Samsung has exclusively devel-

oped to improve digital image and to display natural color more clearly without disturbing image quality.

• Off - Returns to the original mode.

• Demo - The screen before applying MagicColor appears on the right and the screen after applying MagicColor appears on the left.

• Full - Displays not only vivid natural color but also more realistic natural skin color with clearness.

• Intelligent - Displays vivid natural color with clearness.

Red Adjusts individual Red color balance.

The larger the number, the closer it is to red. ( Not available in MagicColor mode of Full and Intelligent. )

Green Adjusts individual Green color balance.

The larger the number, the closer it is to green. ( Not available in MagicColor mode of Full and Intelligent. )

Blue Adjusts individual Blue color balance.

The larger the number, the closer it is to blue. ( Not available in MagicColor mode of Full and Intelligent. )

Color Tone The tone of the color can be changed and one of four modes can be

selected. ( Not available in MagicColor mode of Full and Intelligent. )

• Cool - Makes whites bluish.

• Normal - Keeps whites white.

• Warm - Makes whites reddish.

• Custom - Select this mode when you want to adjust the image according to your preferences.

32

Adjusting the Monitor

Menu Description

Color Effect You can change the overall mood by changing the screen colors.

( Not available in MagicColor mode of Full and Intelligent. )

• Off - This applies an achromatic color to the screen to adjust the screen effects.

• Grayscale - The default colors of black and white are displayed.

• Green - This applies the green color effect to a black and white screen.

• Aqua - This applies the aqua color effect to a black and white screen.

• Sepia - This applies the Sepia color effect to a black and white screen.

Gamma Gamma correction changes the luminance of the colors with inter-

mediate luminance.

• Mode 1 : Sets the screen to the default brightness.

SIZE & POSITION

Menu Description

H-Position Changes the horizontal position of the monitor's entire display.

• Mode 2 : Sets the screen to bright.

• Mode 3 : Sets the screen to dim.

You can move the position of the screen to the left and right by pressing the and buttons, respectively.

(Available in Analog mode only)

Note

When TV signal is input in AV mode ,select “Screen Fit “to adjust horizontal position in 0-6 levels.

V-Position Changes the vertical position of the monitor's entire display.

You can move the position of the screen downwards and upwards by pressing the and buttons, respectively.

33

Menu Description

(Available in Analog mode only)

Note

When TV signal is input in AV mode ,select “Screen Fit “to adjust vertical position in 0-6 levels.

Image Size

Note

Supplied for the wide models only such as 16:9 or 16:10. You can change the size of the screen displayed on your monitor.

PC signals

• Auto - The screen is displayed in accordance with the screen aspect ratio of the input signals.

• Wide - A full screen is displayed regardless of the screen aspect ratio of the input signals.

Adjusting the Monitor

Note

• Signals not available in the standard mode table are not supported.

• If the wide screen which is the optimal resolution for the monitor is set on your PC, this function is not performed.

AV signals

• 4 : 3 - Sets the picture to 4:3 normal mode.

• 16 : 9- Sets the picture to 16:9 wide mode.

• Screen Fit- Use the function to see the full image without any cutoff when DVI (480p/576p/720p/1080i/1080p) signals are input.

Note

It can only be selected if an external input is connected to the DVI terminal and the 'PC/AV Mode' is set to 'AV'.

• 4 : 3 - Sets the picture to 4:3 normal mode.

• Wide-Sets the picture to 16:10 wide mode.

• Screen Fit- Use the function to see the full image without any cutoff when DVI (480p/576p/720p/1080i/1080p) signals are input.

Note

• It can only be selected if an external input is connected to the DVI terminal and the 'PC/AV Mode' is set to 'AV'.

• When the panel is of 16:10,the screen size options include “4:3”,”wide “,”Screen fit“.

34

SETUP&RESET

Menu Description

Reset Reverts the product settings to factory defaults.

Adjusting the Monitor

• Yes

• No

Menu Transparency

Language You can select the language used to display the menus.

Off Timer On/ Off

Off Timer Setting The monitors will turn off automatically at the specified time. Auto Source Select Auto Source for the monitor to automatically select the signal

Change the transparency of the background of the OSD.

• Off : The menus are displayed in the normal way (non-transparently).

• On : The menus are displayed transparently.

You can choose one of nine languages.

Note

The language chosen affects only the language of the OSD. It has no effect on any software running on the computer.

You can enable or disable the Off Time function.

• Off

• On

source.

• Auto

• Manual

Note

Not applicable to analogue (D-SUB)-or-digital (DVI)-dedicated models.

35

Adjusting the Monitor

Menu Description

PC/AV Mode This function allows the screen to be displayed at the optimal quality

in accordance with the size of the screen when a 480P, 576P, 720P, 1080i, or 1080P video signal is input in DVI mode.

Set to "PC" when connected to a PC, Set to "AV" when connected to an AV device.

If not set to "AV", the screen may not be displayed normally. (Unavailable in Analog mode)

Note

Supplied for the wide models only such as 16:9 or 16:10.

Display Time The menu will be automatically turned off if no adjustments are made

for a certain time period. You can set the amount of time the menu will wait before it is turned

off.

• 5 sec

Customized Key You can specify a function which will be activated when the Custom-

INFORMATION

Menu Description

INFORMATION

• 10 sec

• 20 sec

• 200 sec

ized Key ( )is pressed.

Shows a video source, display mode on the OSD screen.

Note

For models with an Analog interface only, “Analog/Digital“is not shown in the”Information”.

36

Troubleshooting

Self-Test Feature Check

Note

Your monitor provides a self test feature that allows you to check whether your monitor is functioning properly.

Self-Test Feature Check

1. Turn off both your computer and the monitor.

2. Unplug the video cable from the back of the computer.

3. Turn on the monitor. If the monitor is functioning properly, you will see a box in the illustration below.

Note

For models with an Analog interface only, “Analog/Digital” is not shown in the Warning Message OSD.

This box appears during normal operation if the video cable becomes disconnected or damaged.

4. Turn off your monitor and reconnect the video cable; then turn on both your computer and the monitor.

If your monitor screen remains blank after using the previous procedure, check your video controller and computer system; your monitor is functioning properly.

Warning Messages

If there is something wrong with the input signal, a message appears on the screen or the screen goes blank although the power indicator LED is still on. The message may indicate that the monitor is out of scan range or that you need to check the signal cable.

Note

For models with an Analog interface only, “Analog/Digita” is not shown in the Warning Message OSD.

37

Environment

The location and the position of the monitor may influence the quality and other features of the monitor.

If there are any sub woofer speakers near the monitor, unplug and relocate the woofer to another room.

Remove all electronic devices such as radios, fans, clocks and telephones that are within 3 feet (one meter) of the monitor.

Useful Tips

A monitor recreates visual signals received from the computer. Therefore, if there is a problem with the computer or the video card, this can cause the monitor to become blank, have poor coloring, become noisy, and video mode not supported, etc. In this case, first check the source of the problem, and then contact the Service Center or your dealer.

Judging the monitor's working condition If there is no image on the screen or a "Not Optimum Mode", "Recommended Mode **** x ****

60 Hz" message comes up, disconnect the cable from the computer while the monitor is still powered on.

Troubleshooting

If there is a message coming up on the screen or if the screen goes white, this means the monitor is in working condition.

In this case, check the computer for trouble.

Check List

Note

Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.

No images on the screen. I cannot turn on the monitor.

Q: Is the power cord connected properly?

A: Check the power cord connection and supply. Q: Can you see "Check Signal Cable" on the screen?

A: (Connected using the D-sub cable)

Check the signal cable connection.

(Connected using the DVI cable)

If you still see an error message on the screen when the monitor is connected properly, check to see if the monitor status is set to analog.

If you still see an (error) message on the screen when the monitor is connected properly, check to see if the monitor status is set to analog. Press ‘ the input signal source.

Q: If the power is on, reboot the computer to see the initial screen (the login screen), which can be

seen.

A: If the initial screen (the login screen) appears, boot the computer in the applicable mode (the

safe mode for Windows ME/XP/2000) and then change the frequency of the video card.

38

’ button to have the monitor double-check

Troubleshooting

(Refer to the Preset Timing Modes)

If the initial screen (the login screen) does not appear, contact the Service Center or your dealer.

Q: Can you see "Not Optimum Mode", "Recommended Mode **** x **** 60 Hz" on the screen?

A: You can see this message when the signal from the video card exceeds the maximum resolution

and frequency that the monitor can handle properly.

A: Adjust the maximum resolution and frequency that the monitor can handle properly.

A: If the display exceeds SXGA or 75 Hz, a "Not Optimum Mode", "Recommended Mode ****

x **** 60 Hz" message is displayed. If the display exceeds 85 Hz, the display will work properly but the "Not Optimum Mode", "Recommended Mode **** x **** 60 Hz" message appears for one minute and then disappears.

Please change to the recommended mode during this one-minute period.

(The message is displayed again if the system is rebooted.)

Q: There is no image on the screen. Is the power indicator on the monitor blinking at 1 second

intervals?

A: The monitor is in PowerSaver mode.

A: Press a key on the keyboard to activate the monitor and restore the image on the screen.

A:

If there is still no image, press the ' ' button. Then press any key on the keyboard again to activate the monitor and restore the image on the screen.

Q: Connected using the DVI cable?

A: You may get a blank screen if you boot the system before you connect the DVI cable, or dis-

connect and then reconnect the DVI cable while the system is running as certain types of graphic cards do not send out video signals. Connect the DVI cable and then reboot the system.

I cannot see the On Screen Display.

Q: Have you locked the On Screen Display (OSD) Menu to prevent changes?

A: Unlock the OSD by pressing the [MENU/ ] button for at least 5 seconds.

The screen shows strange colors or just black and white.

Q: Is the screen displaying only one color as if looking at the screen through a cellophane paper?

A: Check the signal cable connection.

A: Make sure the video card is fully inserted in its slot.

Q: Have the screen colors become strange after running a program or due to a crash between ap-

plications?

A: Reboot the computer.

Q: Has the video card been set properly?

A: Set the video card by referring to the video card manual.

39

Troubleshooting

The screen suddenly has become unbalanced.

Q: Have you changed the video card or the driver?

A: Adjust screen image position and size using the OSD.

Q: Have you adjusted the resolution or frequency to the monitor?

A: Adjust the resolution and frequency at the video card.

(Refer to the Preset Timing Modes)

Q: The screen can be unbalanced due to the cycle of the video card signals. Readjust Position by

referring to the OSD.

The screen is out of focus or OSD cannot be adjusted.

Q: Have you adjusted the resolution or frequency on the monitor?

A: Adjust the resolution and frequency of the video card.

(Refer to the Preset Timing Modes)

LED is blinking but no images on the screen.

Q: Is the frequency properly adjusted when checking the Display Timing on the menu?

A: Adjust the frequency properly by referring to the video card manual and the Preset Timing

Modes.

(The maximum frequency per resolution may differ from product to product.)

There are only 16 colors shown on the screen. The screen colors have changed after changing the video card.

Q: Have the Windows colors been set properly?

A: Windows XP :

Set the resolution at the Control Panel → Appearance and Themes → Display → Settings.

A: Windows ME/2000 :

Set the resolution at the Control Panel → Display → Settings.

Q: Has the video card been set properly?

A: Set the video card by referring to the video card manual.

There is a message that reads "Unrecognized monitor, Plug & Play (VESA DDC) monitor found".

Q: Have you installed the monitor driver?

A: Install the monitor driver according to the Driver Installation Instructions.

Q: See the video card manual to see if the Plug & Play (VESA DDC) function can be supported.

A: Install the monitor driver according to the Driver Installation Instructions.

My computer is on and the LED is blinking. However, only a blank screen is displayed on the monitor.

Q: Check whether your computer is in hibernation mode (The monitor turns off).

40

Troubleshooting

A: Move your mouse or press any key to display the screen again.

Problems related to Audio.

Q: No sound. A: Ensure that the audio cable is firmly connected to both the audio-in port on your monitor and

the audio-out port on your sound card. (Refer to Connecting Cables).

Check the volume level. Q: Sound level is too low. A: Check the volume level.

If the volume is still too low after turning the control to its maximum, check the volume control

on the computer sound card or software program.

Check when MagicTune™ does not function properly.

Q: MagicTune™ feature is found only on PC (VGA) with Window OS that supports Plug and Play. A: To check whether your PC is available for MagicTune™ feature, follow the steps below (When

Windows is XP);

Control Panel → Performance and Maintenance → System → Hardware → Device Manager

→ Monitors → After deleting Plug and Play monitor, find 'Plug and Play monitor' by searching

new Hardware. A: MagicTune™ is an additional software for the monitor. Some graphic cards may not support

your monitor. When you have a problem with the graphic card, visit our website to check the

compatible graphic card list provided.

http://www.samsung.com/monitor/magictune

MagicTune™ doesn't work properly.

Q: Have you changed your PC or video graphic card? A: Download the latest program. The program can be downloaded http://www.samsung.com/mon-

itor/magictune Q: Did you install the program? A: Reboot the computer after installing the program for the first time. If a copy of the program is

already installed, remove it, reboot the computer, and then install the program again. You need

to reboot the computer for it to operate normally after installing or removing the program.

Note

Visit the MagicTune™ website and download the installation software for MagicTune™ MAC.

Check the following items if there is trouble with the monitor.

Check if the power cord and the video cables are properly connected to the computer. Check if the computer beeps more than 3 times when booting. (If it does, request an a service for the main board of the computer.)

41

Q & A

Troubleshooting

If you installed a new video card or if you assembled the PC, check if the installed the adapter(video) driver and the monitor driver.

Check if the scanning ratio of the video screen is set to between 56 Hz ~ 75 Hz.

(Do not exceed 75 Hz when using the maximum resolution.)

If you have problems in installing the adapter (video) driver, boot the computer in Safe Mode, remove the Display Adapter in the "Control Panel → System → Device Administrator" and then reboot the computer to reinstall the adapter (video) driver.

Note

If problems repeatedly occur, contact an authorized service center.

Q: How can I change the frequency?

A: The frequency can be changed by reconfiguring the video card.

A: Note that video card support can vary, depending on the version of the driver used. (Refer to the

computer or the video card manual for details.)

Q: How can I adjusts the resolution?

A: Windows XP:

Set the resolution in the Control Panel → Appearance and Themes → Display → Settings.

A: Windows ME/2000:

Set the resolution in the Control Panel → Display → Settings.

* Contact the video card manufacturer for details.

Q: How can I set the Power Saving function?

A: Windows XP:

Set the resolution in the Control Panel → Appearance and Themes → Display → Screen Saver.

Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Man-

ual).

A: Windows ME/2000:

Set the resolution at the Control Panel → Display → Screen Saver.

Set the function in the BIOS-SETUP of the computer. (Refer to the Windows / Computer Man-

ual).

Q: How can I clean the outer case/LCD Panel?

A: Disconnect the power cord and then clean the monitor with a soft cloth, using either a cleaning

solution or plain water.

Do not leave any detergent or scratches on the case. Do not let any water enter the monitor.

42

Troubleshooting

Note

Before calling for assistance, check the information in this section to see if you can remedy any problems yourself. If you do need assistance, please call the phone number on the Information section or contact your dealer.

43

Specifications

General

Model Name SyncMaster 633NW

LCD Panel

Size 15.6 inch (39 cm)

General

Display area

Pixel Pitch 0.252 mm(H) x 0.252 mm(V)

Synchronization

Horizontal 30 ~ 61 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7 M

Resolution

Optimum resolution 1360 x 768@60 Hz

Maximum resolution 1360 x 768@60 Hz

Input Signal, Terminated

RGB Analog,

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

344.232 mm(H) x 193.536 mm(V)

90 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable, 1500 +/- 20 mm

Dimensions (W x H x D) / Weight (Simple Stand)

386 x 264.5 x 67.2 mm (15.2 x 10.4 x 2.6 inch) (Without Stand)

386 x 315.8 x 186.6 mm (15.2 x 12.4 x 7.3 inch) (With Stand)/ 2.55 kg (5.62 lbs)

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 20 % ~ 80 %, non-condensing

Temperature : -4°F ~ 140°F (-20°C ~ 60°C)

Storage

Humidity : 10 % ~ 80 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

18 watts

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Less than 1 watts Less than 1 watts

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Display Mode

IBM, 640 x 350 31.469 70.086 25.175 +/-

IBM, 640 x 480 31.469 59.940 25.175 -/-

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1024 x 768 60.023 75.029 78.750 +/+

Horizontal Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1360 X 768

47.712

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.015 85.500 +/+

Specifications

General

Model Name SyncMaster 733A

LCD Panel

Size 17 inch (43 cm)

General

Display area

Pixel Pitch 0.264 mm (H) x 0.264 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1280 x 1024@60 Hz

Maximum resolution 1280 x 1024@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

337.920 mm (H) x 270.336 mm (V)

135 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

380.6 x 349 x 72.3 mm / 15.0 x 13.7 x 2.8 inch (Without Stand)

380.6 x 397.1 x 200 mm / 15.0 x 15.6 x 7.9 inch (With Stand), 3.8 kg / 8.4 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator On Blinking

Power Consumption 30 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Display Mode

IBM，640 x 350

IBM，640 x 480

IBM，720 x 400

MAC，640 x 480

MAC，832 x 624

MAC，1152 x 870

VESA，640 x 480

VESA，800 x 600

VESA，1024 x 768

Horizontal Frequency

(kHz)

31.469 70.086 25.175 +/-

31.469 59.940 25.175 -/-

31.469 70.087 28.322 -/+

35.000 66.667 30.240 -/-

49.726 74.551 57.284 -/-

68.681 75.062 100.000 -/-

37.861 72.809 31.500 -/-

37.500 75.000 31.500 -/-

35.156 56.250 36.000 +/+

37.879 60.317 40.000 +/+

48.077 72.188 50.000 +/+

46.875 75.000 49.500 +/+

48.363 60.004 65.000 -/-

56.476 70.069 75.000 -/-

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA，1024 x 768

VESA，1152 x 864

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1280 X 800 49.702 59.810 83.500 -/+

60.023 75.029 78.750 +/+

67.500 75.000 108.000 +/+

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 733A

LCD Panel

Size 17 inch (43 cm)

Display area

Pixel Pitch 0.264 mm (H) x 0.264 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1280 x 1024@60 Hz

Maximum resolution 1280 x 1024@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

337.920 mm (H) x 270.336 mm (V)

PLUS

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

135 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

380.6 x 349 x 72.3 mm / 15.0 x 13.7 x 2.8 inch (Without Stand)

380.6 x 397.1 x 200 mm / 15.0 x 15.6 x 7.9 inch (With Stand), 3.8 kg / 8.4 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator On Blinking

Power Consumption 30 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Display Mode

IBM，640 x 350

IBM，640 x 480

IBM，720 x 400

MAC，640 x 480

MAC，832 x 624

MAC，1152 x 870

VESA，640 x 480

VESA，800 x 600

VESA，1024 x 768

Horizontal Frequency

(kHz)

31.469 70.086 25.175 +/-

31.469 59.940 25.175 -/-

31.469 70.087 28.322 -/+

35.000 66.667 30.240 -/-

49.726 74.551 57.284 -/-

68.681 75.062 100.000 -/-

37.861 72.809 31.500 -/-

37.500 75.000 31.500 -/-

35.156 56.250 36.000 +/+

37.879 60.317 40.000 +/+

48.077 72.188 50.000 +/+

46.875 75.000 49.500 +/+

48.363 60.004 65.000 -/-

56.476 70.069 75.000 -/-

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA，1024 x 768

VESA，1152 x 864

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1280 X 800 49.702 59.810 83.500 -/+

60.023 75.029 78.750 +/+

67.500 75.000 108.000 +/+

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 733N

LCD Panel

Size 17 inch (43 cm)

General

Display area

Pixel Pitch 0.264 mm (H) x 0.264 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1280 x 1024@60 Hz

Maximum resolution 1280 x 1024@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

337.920 mm (H) x 270.336 mm (V)

135 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

380.6 x 349 x 72.3 mm / 15.0 x 13.7 x 2.8 inch (Without Stand)

380.6 x 397.1 x 200 mm / 15.0 x 15.6 x 7.9 inch (With Stand), 3.8 kg / 8.4 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator On Blinking

Power Consumption 30 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Display Mode

IBM, 640 x 350 31.469 70.086 25.175 +/-

IBM, 640 x 480 31.469 59.940 25.175 -/-

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Horizontal Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1280 x 800 49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.000 108.000 +/+

59.810

83.500 -/+

Specifications

General

Model Name SyncMaster 733N

LCD Panel

Size 17 inch (43 cm)

Display area

Pixel Pitch 0.264 mm (H) x 0.264 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1280 x 1024@60 Hz

Maximum resolution 1280 x 1024@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

337.920 mm (H) x 270.336 mm (V)

PLUS

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

135 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

380.6 x 349 x 72.3 mm / 15.0 x 13.7 x 2.8 inch (Without Stand)

380.6 x 397.1 x 200 mm / 15.0 x 15.6 x 7.9 inch (With Stand), 3.8 kg / 8.4 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator On Blinking

Power Consumption 30 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Display Mode

IBM, 640 x 350 31.469 70.086 25.175 +/-

IBM, 640 x 480 31.469 59.940 25.175 -/-

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Horizontal Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1280 x 800 49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.000 108.000 +/+

59.810

83.500 -/+

Specifications

General

Model Name SyncMaster 733NW

LCD Panel

Size 17 inch (43 cm)

General

Display area

Pixel Pitch 0.255 mm(H) x 0.255 mm(V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.2 M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog,

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

367.2 mm(H) x 229.5 mm(V)

Maximum Pixel Clock

136.75 MHz (Analog)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable, 1500 +/- 20 mm

Dimensions (W x H x D) / Weight (Simple Stand)

410.9 x 302.5 x 64.5 mm (16.2 x 11.9 x 2.5 inch) (Without Stand)

410.9 x 351.2 x 187 mm (16.2 x 13.8 x 7.4 inch) (With Stand)/ 2.8 kg (6.17 lbs)

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 32 °F ~ 104°F (0°C ~ 40°C)

Operating

Humidity : 20 % ~ 80 %, non-condensing

Temperature : -4°F ~ 140°F (-20°C ~ 60°C)

Storage Humidity : 10 % ~ 80 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

20 watts

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Less than 1 watts Less than 1 watts

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 640 x 350 31.469 70.086 25.175 +/-

IBM, 640 x 480 31.469 59.940 25.175 -/-

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1280 x 800 49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

60.000 108.000 +/+

59.810

83.500 -/+

Specifications

General

Model Name SyncMaster 933BW

LCD Panel

Size 19 inch (48 cm)

General

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

408.24 mm (H) x 255.15 mm (V)

Maximum Pixel Clock

137 MHz (Analog, Digital)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

DVI-D to DVI-D connector, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 8.82 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933BW

LCD Panel

Size 19 inch (48 cm)

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB

408.24 mm (H) x 255.15 mm (V)

PLUS

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

137 MHz (Analog, Digital)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

DVI-D to DVI-D connector, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 8.82 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933GW

LCD Panel

Size 19 inch (48 cm)

General

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

408.24 mm (H) x 255.15 mm (V)

Maximum Pixel Clock

137 MHz (Analog, Digital)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

DVI-D to DVI-D connector, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 8.82 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933GW

LCD Panel

Size 19 inch (48 cm)

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog, DVI(Digital Visual Interface) Compliant Digital RGB

408.24 mm (H) x 255.15 mm (V)

PLUS

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

137 MHz (Analog, Digital)

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

DVI-D to DVI-D connector, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 8.82 lbs

VESA Mounting Interface

75 mm x 75 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage

Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY 2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

On

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Blinking

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933NW

LCD Panel

Size 19 inch (48 cm)

General

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

408.24 mm (H) x 255.15 mm (V)

Maximum Pixel Clock

137 MHz

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 10.7 lbs

VESA Mounting Interface

75.0 mm x 75.0 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator ON Blinking

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933NWPLUS

LCD Panel

Size 19 inch (48 cm)

General

Display area

Pixel Pitch 0.2835 mm (H) x 0.2835 mm (V)

Synchronization

Horizontal 30 ~ 81 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1440 x 900@60 Hz

Maximum resolution 1440 x 900@75 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

408.24 mm (H) x 255.15 mm (V)

Maximum Pixel Clock

137 MHz

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

451.0 x 331.7 x 72.4 mm / 17.8 x 13.1 x 2.9 inch (Without Stand)

451.0 x 379.3 x 200.0 mm / 17.8 x 14.9 x 7.9 inch (With Stand), 4 kg / 10.7 lbs

VESA Mounting Interface

75.0 mm x 75.0 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator ON Blinking

Power Consumption 34 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

MAC, 1152 x 870 68.681 75.062 100.000 -/-

VESA, 640 x 480 31.469 59.940 25.175 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1152 x 864 67.500 75.000 108.000 +/+

VESA, 1280 x 800

VESA, 1280 X 960

VESA, 1280 X 1024 63.981 60.020 108.000 +/+

VESA, 1280 X 1024 79.976 75.025 135.000 +/+

VESA, 1440 X 900 55.935 59.887 106.500 -/+

VESA, 1440 X 900 70.635 74.984 136.750 -/+

49.702

60.000

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

59.810 83.500 +/+

60.000 108.000 +/+

Specifications

General

Model Name SyncMaster 933SN

LCD Panel

Size 18.5 inch (47 cm)

General

Display area

Pixel Pitch 0.3 mm (H) x 0.3 mm (V)

Synchronization

Horizontal 31 ~ 80 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1360 x 768@60 Hz

Maximum resolution 1360 x 768@60 Hz

Input Signal, Terminated

RGB Analog

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

409.8 mm (H) x 230.4 mm (V)

Maximum Pixel Clock

89 MHz

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

453.3 x 299.3x 69.8 mm / 17.9 x 11.8x 2.8inch (Without Stand)

453.3 x 354.9 x 176.6 mm / 17.9 x13.9 x 6.9 inch (With Stand), 3.65 kg / 9.8 lbs

VESA Mounting Interface

75.0 mm x 75.0 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Operating

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator ON Blinking

Power Consumption 18 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1360 X 768 47.712 60.000 85.500 +/+

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz

Specifications

General

Model Name SyncMaster 933SN

LCD Panel

Size 18.5 inch (47 cm)

Display area

Pixel Pitch 0.3 mm (H) x 0.3 mm (V)

Synchronization

Horizontal 31 ~ 80 kHz

Vertical 56 ~ 75 Hz

Display Color

16.7M

Resolution

Optimum resolution 1360 x 768@60 Hz

Maximum resolution 1360 x 768@60 Hz

Input Signal, Terminated

RGB Analog

409.8 mm (H) x 230.4 mm (V)

PLUS

0.7 Vp-p ± 5 %

Separate H/V sync, Composite, SOG

TTL level (V high ≥ 2.0 V, V low ≤ 0.8 V)

Maximum Pixel Clock

89 MHz

Power Supply

AC 100 - 240 V~ (+/- 10 %), 50/60 Hz ± 3 Hz

Signal Cable

15pin - to - 15pin D-sub cable, Detachable

Dimensions (W x H x D) / Weight (Simple Stand)

453.3 x 299.3x 69.8 mm / 17.9 x 11.8x 2.8inch (Without Stand)

453.3 x 354.9 x 176.6 mm / 17.9 x13.9 x 6.9 inch (With Stand), 3.65 kg / 9.8 lbs

VESA Mounting Interface

75.0 mm x 75.0 mm (For use with Specialty(Arm) Mounting hardware.)

Environmental considerations

Operating

Temperature : 50°F ~ 104°F (10°C ~ 40°C)

Humidity : 10 % ~ 80 %, non-condensing

Temperature : -4°F ~ 113°F (-20°C ~ 45°C)

Storage Humidity : 5 % ~ 95 %, non-condensing

Plug and Play Capability

This monitor can be installed on any Plug & Play compatible system. The interaction of the monitor and the computer systems will provide the best operating conditions and monitor settings. In most cases, the monitor installation will proceed automatically, unless the user wishes to select alternate settings.

Dot Acceptable

TFT-LCD panels manufactured by using advanced semiconductor technology with precision of 1ppm (one millionth) above are used for this product. But the pixels of RED, GREEN, BLUE and WHITE color appear to be bright sometimes or some black pixels may be seen. This is not from bad quality and you can use it without any problems.

Note

Design and specifications are subject to change without prior notice.

Class B Equipment (Information Communication equipment for residential use)

This product complies with the Electromagnetic Compatibility Directives for residential use and can be used in all areas including common residential areas. (Class B equipment emits less electromagnetic waves than Class A equipment.)

Specifications

PowerSaver

This monitor has a built-in power management system called PowerSaver. This system saves energy by switching your monitor to low-power mode when it has not been used for a certain amount of time. The monitor automatically returns to normal operation when you press a key on the keyboard. For energy conservation, turn your monitor OFF when it is not needed, or when leaving it unattended for long periods. The PowerSaver system operates with a VESA DPM compliant video card installed in your computer. Use the software utility installed on your computer to set up this feature.

State Normal Operation Power saving mode

Power Indicator ON Blinking

Power Consumption 18 watts Less than 1 watts Less than 1 watts

This monitor is EPA ENERGY STAR® compliant and ENERGY2000 compliant when used with a computer equipped with VESA DPM functionality.

As an ENERGY STAR ENERGY STAR

®

Partner, SAMSUNG has determined that this product meets the

®

guidelines for energy efficiency.

Power off (Power button)

EPA/ENERGY 2000

Off

Specifications

Preset Timing Modes

If the signal transferred from the computer is the same as the following Preset Timing Modes, the screen will be adjusted automatically. However, if the signal differs, the screen may go blank while the power LED is on. Refer to the video card manual and adjusts the screen as follows.

Horizontal

Display Mode

IBM, 720 x 400 31.469 70.087 28.322 -/+

MAC, 640 x 480 35.000 66.667 30.240 -/-

MAC, 832 x 624 49.726 74.551 57.284 -/-

VESA, 640 x 480 37.861 72.809 31.500 -/-

VESA, 640 x 480 37.500 75.000 31.500 -/-

VESA, 800 x 600 35.156 56.250 36.000 +/+

VESA, 800 x 600 37.879 60.317 40.000 +/+

VESA, 800 x 600 48.077 72.188 50.000 +/+

VESA, 800 x 600 46.875 75.000 49.500 +/+

VESA, 1024 x 768 48.363 60.004 65.000 -/-

VESA, 1024 x 768 56.476 70.069 75.000 -/-

VESA, 1024 x 768 60.023 75.029 78.750 +/+

VESA, 1360 X 768 47.712 60.000 85.500 +/+

Frequency

(kHz)

Vertical

Frequency (Hz)

Pixel Clock

(MHz)

Sync Polarity

(H/V)

Horizontal Frequency

The time to scan one line connecting the right edge to the left edge of the screen horizontally is called the Horizontal Cycle and the inverse number of the Horizontal Cycle is called the Horizontal Frequency. Unit: kHz

Vertical Frequency

Like a fluorescent lamp, the screen has to repeat the same image many times per second to display an image to the user. The frequency of this repetition is called the Vertical Frequency or Refresh Rate. Unit: Hz
