Quick Start Instruction manual
Product name: Key Finder and Multimedia Remote Control
Model number: KMR930
Manual ver_1.2
Features:
Key Finder
Presenter
Music player
Camera remote shutter
Video Camera recorder
Specification:
Bluetooth 4.0 compatible
Maximum Operate range: 40m (Outdoor), 20m (Indoor)
Dimension: 54.5 mm x 32 mm x 12 mm
Battery: CR2032
Inst
alling / Replacing the Batteries
3V lithium battery (CR2032) is included in the package.
Use only 3V lithium batteries. Do not use or replace the battery with different
types of batteries. Doing so will damage the electronics of the device.
Keys definition:
Top key
Left key
Up key
Right key
Bottom key
Battery Level
Pair Key
Setup Procedures
Installation
Prior to first use, Download and install "Key Finder" application to your iOS
device.
(Bluetooth 4.0 capabilities, e.g. iPhone 4S, iPhone 5, NewiPad and iPadMini)
Connect to iOS Device via Bluetooth
Turn Bluetooth "On" under the "Settings" menu on the
iOS device.
Press and hold the Top Key until the RED/BLUE LED is
ON (approximately 3 seconds).
First time to open "Key Finder" application on your iOS device,
The screen will show you " Please press this button to select your
keyfinder for pairing".
After press the button, will show the Devices List and show your device
listed, press "Pair" button to start the Pairing.
Press the "Pair" to
start the pairing.
The Bluetooth icon will light ON & the device have "Beep Beep" sound
upon successful connection.
Reminder: The Key Finder device will turn off when no pairing after 30s.
Operation
Menu Screen: S
elect the activate function
Keychain Screen
Music Player Screen
Presenter Screen
Camera remote shutter Screen
Video Camera Recorder Screen
After connected, the
Bluetooth icon will
light ON.
Camera Remote Sutter Screen:
The Pop-Up instruction will show the all keys definitions and press any key to
start the Camera.
Video Camera Recording Screen:
The Pop-Up instruction will show the all keys definitions and press any key to
start the Video Camera.
Music Player Screen:
The Pop-Up instruction will show the all keys definitions and press any key to
start the Music Player.
Presenter Screen:
The Pop-Up instruction will show the all keys definitions and press any key to
start the Presenter. (Supported Pdf file only)
Choose open PDF file:
1.
Select and Open on the
application listed
2. Select and Open with Key Finder:
Keychain Screen:
Press device top key to start the Keychain or back to main screen.
On Keychain Screen:
Turn On/Off the keychain feature
On/Off Out Of Range Alert
Near/Far Range Alert
On/Off Link Loss Alert
Select iPhone/iPad Alert Level
Find Keyfinder
The device have "Beep Beep" sound
up
on press the Tab
Silence Keyfinder
Press the Tab to stop
the device "Beep Beep" sound
On/
Off Show Pop-Up instructions
FCC Caution
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment .End users must follow the specific operating instructions
for satisfying RF exposure compliance.This transmitter must not be co-located or
operating in conjunction with any other antenna or transmitter.
