SAME DEUTZ-FAHR

Tractors

Range

The brand that represents tradition, associated
with safety, reliability and performance, from
generation to generation.
A generous and complete range of products,
offering unrivalled choice in terms of power,
specifi cations and confi gurations.
A global service reaching well beyond the
signature on a purchase contract, helping to
create a “family feeling” identifi able in that
unique, almost personal bond between owner
and tractor - and between owner and brand.

SAME Range.

Every need
accommodated

SAME Range

230 270

• NEW DEUTZ COMMON RAIL, EURO III,
24 VALVES, 6 CYLINDER INTERCOOLED,
TURBOCHARGED AND ELECTRONICALLY
CONTROLLED ENGINES WITH EXTERNAL
EXHAUST GAS RECIRCULATION SYSTEM

• AUTOMATIC 4-RATIO POWERSHIFT GEARBOX,
MAX. 50 KM/H, LIMITED TO 40 KM/H AT
ECONOMY ENGINE SPEED (FOR LEGAL
PURPOSES)

• 540 ECON – 1000 RPM REAR P.T.O.

• ELECTRONICALLY CONTROLLED REAR LIFT
WITH 10,500 KG LIFTING CAPACITY

• 3 INDEPENDENT HYDRAULIC SYSTEMS
(TRANSMISSION, STEERING AND LIFT,
HYDRAULIC CONTROL VALVES)

• HYDR AULIC FRONT AXLE SUSPENSION

• PNEUMATIC CAB SUSPENSION

• FRONT LIFT WITH 5100 KG LIFTING CAPACITY

DIAMOND 230 270

Max power
HP/kW

249/183 275/202

Hom. power (2000/25/EC) at
nominal engine speed

HP/kW

244/179 269/198

Cylinders/displacement n°/cc

6/7146 Turbo intercooler

Transmission

AUTOMATIC POWERSHIFT gearbox,

40 forward + 40 reverse gears with creeper,

shift-on-the-go hydraulic shuttle

Rear P.T.O. rpm 540 ECON/1000

Lifting capacity kg 10500

Weight kg 8410 9050

5

210

• DEUTZ COMMON RAIL, EURO III, TURBO
INTERCOOLED ENGINE WITH ELECTRONIC
ENGINE CONTROL

• AUTOMATIC POWERSHIFT GEARBOX

• SDS (SEQUENTIAL DRIVE SYSTEM) FOR
MEMORISING REPETITIVE OPERATING
SEQUENCES

• SBA/ASM AUTOMATIC TRACTION CONTROL

• HYDROSTATIC STEERING WITH
INDEPENDENT HYDRAULIC SYSTEM

• CAB SUSPENSION WITH SELF­COMPENSATING PNEUMATIC DAMPERS

• CLOSED-CENTRE HYDRAULIC

CIRCUIT WITH 113 L/MIN., VARIABLE

DELIVERY, LOAD SENSING PUMP

IRON 210

Max power
HP/kW

220/162

Hom. power (2000/25/EC) at

nominal

engine speed

HP/kW

213/157

Cylinders/displacement n°/cc 6/7146 Turbo intercooler

Transmission

AUTOMATIC POWERSHIFT gearbox,

27 forward + 27 reverse gears with creeper

Rear P.T.O. rpm 540 ECON/1000

Lifting capacity kg 10000

Weight kg 7520

SAME Range

• NEW DEUTZ COMMON R AIL, EURO
III, 12 OR 24 VALVES, 6 CYLINDER
INTERCOOLED, TURBOCHARGED
AND ELECTRONICALLY
CONTROLLED ENGINES WITH
EXHAUST GAS RECIRCULATION
SYSTEM

• 4-RATIO POWERSHIFT GEARBOX,
MAX. 50 KM/H, LIMITED TO 40
KM/H AT ECONOMY ENGINE SPEED
(FOR LEGAL PURPOSES)

• HYDROSTATIC STEERING WITH
INDEPENDENT HYDRAULIC SYSTEM

• SELF-COMPENSATING, HYDRAULIC,
FRONT A XLE AND CAB SUSPENSION
SYSTEMS

• SBA/ASM AUTOMATIC TR ACTION
CONTROL

• CLOSED-CENTRE HYDRAULIC
CIRCUIT WITH 120 L/MIN., VARIABLE
DELIVERY, LOAD SENSING PUMP
SINGLE PIECE, GALVANISED METAL
BODY

• NEW “HI-LINE” VERSIONS

AVAILABLE

130 140 160 175 185

IRON 130 140 160 175 185

Max power
HP/kW

132/97 143/105 166/122 180/132 192/141

Homologated power
(2000/25/EC) at nominal
engine speed HP/kW

132/97 143/105 163/120 176/129 184/135

Cylinders/displacement
n°/cc

6/6057 Turbo Intercooler

Transmission

POWERSHIFT gearbox, 40 forward + 40 reverse gears with creeper,

shift-on-the-go hydraulic shuttle

Rear P.T.O. rpm 540/1000/540 ECON/1000 ECON

Lifting capacity kg

6200 (9200 with

supplementary jacks)

9200

Weight kg 5460 5610 5880 5970 6750

7

• NEW DEUTZ COMMON RAIL, EURO III, 24 VALVES,
6 CYLINDER INTERCOOLED, TURBOCHARGED AND
ELECTRONICALLY CONTROLLED ENGINES WITH
EXTERNAL EXHAUST GAS RECIRCULATION SYSTEM

• STEPLESS, HYDROSTATIC-MECHANICAL
TRANSMISSION WITH FOUR RANGES AND THREE

DRIVING STRATEGIES MAX. 50 KM/H AT ECONOMY

ENGINE SPEED, LIMITED TO 40 KM/H AT SUPER­ECONOMY ENGINE SPEED (FOR LEGAL PURPOSES)

• SELF-COMPENSATING, HYDR AULIC, FRONT AXLE
AND CAB SUSPENSION SYSTEMS

• SBA/ASM AUTOMATIC TRACTION CONTROL

• CLOSED-CENTRE HYDRAULIC CIRCUIT WITH 120
L/MIN., VARIABLE DELIVERY, LOAD SENSING PUMP

IRON CONTINUO 150 170

Max homologated power
HP/kW

165/121 184/135

Homologated power (2000/25/EC)
at nominal engine speed HP/kW

165/121 169/124

Cylinders/displacement n°/cc 6/6057 Turbo intercooler

Transmission Stepless, hydrostatic-mechanical transmission

Rear P.T.O. rpm 540/1000/540 ECON/1000 ECON

Lifting capacity kg 9200

Weight kg 6525 6630

15 0 170

SAME Range

100 110 120

IRON 100 110 120

Max homologated power
(2000/25/EC) HP/kW

112/82 118/87 126/93

Max homologated power
(ECE R24.03) HP/kW

101/74 110/81 120/88

Cylinders/displacement n°/cc

4/4038

Turbo Intercooler

6/6057

Turbo Intercooler

4/4038

Turbo Intercooler

Transmission

POWERSHIFT gearbox,

36 forward + 12 reverse gears with creeper,

shift-on-the-go hydraulic shuttle

Rear P.T.O. rpm 540/1000/540 ECON/1000 ECON-Synchro

Lifting capacity kg 6200

Weight kg 4440 4850 4440

• DEUTZ EURO II LIQUID-COOLED 4
AND 6-CYLINDER TURBODIESEL
ENGINES

• 3-RATIO POWERSHIFT GEARBOX,
MAX. 50 KM/H, LIMITED TO 40
KM/H AT ECONOMY ENGINE SPEED
(FOR LEGAL PURPOSES)

• HYDRAULIC SYSTEM WITH FIXED
OR VARIABLE DISPLACEMENT
PUMP WITH LOAD SENSING

• ELECTRONICALLY CONTROLLED
RADAR-EQUIPPED REAR LIFT
AND 4-SPEED HYDRAULIC P.T.O.:
540/540E AND 1000/1000E RPM

• MAXIMUM COMFORT
GUARANTEED BY AUTOMATICALLY
CONTROLLED HYDRAULIC
SUSPENSION ON FRONT AXLE AND
CAB

• NEW “HI-LINE” VERSIONS

AVAILABLE
