OPERATOR'S MANUAL
CARRIER WITH HYDRAULIC
EXTENSION
FISHER
Serial number:
Translation of the original manual
IN0937USA001
2016.04.13
EDITION NO. 1
DO NOT
OPERATE THE MACHINE WHEN
ANY UNAUTHORIZED PERSONNEL
IS WITHIN 170' / 50M FROM THE
MACHINE.
NOTE
Keep this manual for future use.
Vocabulary:
Fisher – extension arm, tooling carrier.
Cooperating device – mowing head, attachment type: PT3-190, PT4-250, PG 150,
PG 200.
Vehicle – machine other than tractor, at which the Fisher machine is mounted
(e.g. telescopic loader).
Well-proven design with thousands of machines in regular use in many countries and quality
materials used ensure high durability and reliability of SaMASZ machines.
We congratulate you on the purchase of your new SaMASZ machine and wish you much pleasure
and the very best work results through the years to come.
Operator's Manual
Contents page
FISHER
1. IDENTIFYING THE MACHINE ................................................................................................... 2
2. INTRODUCTION ........................................................................................................................... 2
3. INTENDED USE ............................................................................................................................ 3
3.1. Technical data ............................................................................................................................. 3
3.2. Design and working principle .................................................................................................... 4
3.2.1. Mounting work heads ............................................................................................................ 5
3.3. Equipment and spare parts.......................................................................................................... 5
4. SAFETY PRECAUTIONS ............................................................................................................. 5
4.1. General safety rules and regulations ........................................................................................... 5
4.2. Transport..................................................................................................................................... 7
4.2.1. Moving machine onto another vehicle for transport.............................................................. 7
4.3. Residual risk ............................................................................................................................... 8
4.3.1. Residual risk assessment ........................................................................................................ 9
4.4. Operator's qualifications ........................................................................................................... 10
4.5. Safety labels and their meaning ................................................................................................ 10
5. OPERATION ................................................................................................................................ 11
5.1. Attaching the carrier to the vehicle .......................................................................................... 11
5.2. Attaching work head to the carrier ........................................................................................... 13
5.3. Preparing the machine for transport ......................................................................................... 14
5.4. Moving the extension arm with mowing head from transport to working position ................. 14
5.4.1. Side position ........................................................................................................................ 15
5.4.2. Central position .................................................................................................................... 16
5.5. Operation .................................................................................................................................. 17
5.5.1. Operating control panel ....................................................................................................... 18
5.6. Operating hydraulics ................................................................................................................ 18
5.7. Maintenance and service .......................................................................................................... 18
5.7.1. Daily maintenance ............................................................................................................... 18
5.7.2. After-season maintenance .................................................................................................... 19
5.7.3. Storage ................................................................................................................................. 19
6. LUBRICATION ............................................................................................................................ 19
7. MAINTENANCE AND SERVICE .............................................................................................. 20
8. MALFUNCTIONS AND THEIR REPAIR .................................................................................. 20
9. REPAIR AND WITHDRAWAL FROM USE ............................................................................. 21
10. WARRANTY CARD ............................................................................................................ 21
11. WARRANTY TERMS .......................................................................................................... 22
11.1. Warranty claim procedure ...................................................................................................... 22
11.2. Warranty repairs record ......................................................................................................... 23
Carrier with hydraulic extension
- 1 -
Operator's Manual
Data plate includes:
- name and adress of the ma
nufacturer,
-
model year,
- CE marking means, that the produce
-
version number,
conforms to 2006/42/EC Directive and
-
machine weight,
harmonized standards,
-
id number,
- machine symbol,
-
barcode.
- date of manufacture,
1. IDENTIFYING THE MACHINE
Data place is attached on the extension arm's beam and the mowing head as shown in Fig. 1.
FISHER
Carrier with hydraulic extension
Fig. 1. Data plate location
NOTE:
Should the contents of the herein manual be unclear, ask the manufacturer or your dealer for
more detailed information on the machine.
2. INTRODUCTION
This operator’s manual should be considered as the machine's basic equipment. If the machine is
handed over to another user, it should be in working condition, and include this operator's
manual, EC declaration of conformity and its basic equipment.
This operator’s manual is essential for safe and proper use of this machine and should be read
before anyone operates this machine.
The machine is manufactured according to international safety rules.
Respecting recommendations herein shall ensure use safety.
Please contact the manufacturer if you have any queries relating to the operation and service of
the machine.
This operator's manual remains an integral part of the machine's equipment.
GENERAL PRECAUTION
When operating the machine always respect warnings and safety
rules marked with this sign.
WARNING!
The machine must not be operated by persons who have not familiarized themselves
with contents of this manual as well as by personnel not holding the required
authorizations to operate tractors and telescopic loaders, children in particular.
WARNING!
Shifting the extension arm with mounted support feet may damage the feet!
- 2 -
Carrier with hydraulic extension
Minimum transport dimensions
Length [
ft in /
mm]
2′ 6″ /
760
Width [
ft in /
mm]
7′ 3″ / 2,
200
Height [
ft in /
mm]
3′ 1″ /
940 (
2
′ /
620
– without feet)
Parking feet
2 pcs
Control
Vehicle's hydraulics / operator's panel
saw
- return hose with case drain);
Hydraulic pressure [bar]
210
Required electric connectors
12V (lighter outlet)
Working range from inside loader [
ft in /
mm]
PT 5′ 9″-9′ 3″ / 1,750
- 2,810
PG 5′ 6″-8′ 11″ /
1,670
- 2,730
Movement range
Work head rotation [ ° ]
100
Side shift [
ft in /
mm]
3′ 6″ /
1,060
Weight with mounting frame [
lbs /
kg] 551 /
250
Max. oil flow capacity for head feeding [
L
/min]
100
3. INTENDED USE
Operator's Manual
FISHER
The FISHER carrier enables aggregation of work heads such as PG 150, PG 200, PT3-190
and PT4-250 with front loaders on tractors and loaders. Application of the carrier allows for
performing simple municipal works such as branch, hedge trimming, etc. with no need of using
an extension arm.
WARNING!
Do not use the machine for purposes other than those listed in this manual.
Otherwise it will be classified as misuse and could release the manufacturer
from responsibility for any damages. The machine should be used, serviced
and repaired only by personnel familiar with its characteristics and with safety
regulations. Tampering with the machine may release the manufacturer from
responsibility for any resulting malfunctions or damages.
3.1. Technical data
The SaMASZ manufactured carrier features the following parameters (Tab. 1):
Tab. 1. General specification
FISHER
Required hydraulic connectors
2 pairs (4 hoses),
I pair - double acting - to control the side shift
and turn cylinders;
II pair - single acting - header operation (PT
- 3 -
Operator's Manual
–
–
–
–
–
–
–
–
–
–
3.2. Design and working principle
6
7
10
5
1
Carrier with hydraulic extension
FISHER
2
4
8
3
9
8
Fig. 2. Parts of
The carrier consists of the following basic assemblies:
1
Hitch, 6
2
Extension cylinder, 7
3
Extension arm, 8
4
Rotary arm, 9
5
Rotation cylinder, 10
The carrier is equipped with removable hitch (1), therefore enabling the machine to be
aggregated with various vehicles. Extension arm (3) mounted in linkage frame (9) enables tooling
movement over the distance of 1.06m, and holder with mounting plate (6) rotates the attached tooling
by 100°.
Demountable support feet (8) facilitate removal of the carrier with the mounted work head.
The
Fisher machine is equipped with safety breakaway device (10) to reduce damages to a minimum
on contact with solid obstacles when operating. Control panel (7) enables selection of hydraulic parts
to be fed from the vehicle.
Holder with mounting plate,
Control panel,
Support feet,
Linkage frame,
Safety breakaway device.
- 4 -
Carrier with hydraulic extension
3.2.1. Mounting work heads
Operator's Manual
FISHER
To mount a work head on the FISHER carrier, use mounting plate shown in Fig. 3.
Fig. 3. Work head mounting plate
3.3. Equipment and spare parts
The FISHER carrier is sold with the following standard equipment:
Warranty card,
Operator's manual with list of spare parts,
Spray paint (150ml).
Optional extra equipment:
Counterweight for EURO II hitch,
Lock for EURO II hitch,
Hitch frames.
4. SAFETY PRECAUTIONS
4.1. General safety rules and regulations
The carrier should be controlled only from the operator's station. Do not leave the controls before
the machine operation is over.
Before leaving the operator's station, lock the controls to prevent any unexpected machine
movements.
Please make sure that no unauthorized personnel remains within the danger area of at least 164 ft
(50m). Keep particular caution when operating near roads and in stony areas.
Perform any maintenance and adjustment work only when the drive is disconnected and rotor has
stopped completely.
When driving on public roads always comply with local traffic regulations, especially on the
warning lights.
CAUTION!
Make sure to perform any service and repair operations with the tractor drive
shut off and after all rotating parts have stopped completely.
WARNING!
Keep children away from the machine when operating and idle.
Any time when performing repairs on the machine lifted with front loader's or loader's arms, be
certain to secure it against falling with a support.
When operating the machine, make sure the tractor is always equipped with the operator's cabin.
Never start the machine if persons or animals are present around the machine.
- 5 -
Operator's Manual
Respect safety labels regarding hazards, and warning signs placed on the machine.
Before you start the vehicle, the Fisher carrier is aggregated with, make sure that all drives are
FISHER
turned off and the levers that turn the hydraulics are in neutral position.
Carrier with hydraulic extension
Never leave the vehicle’s engine running without supervision. Before you leave the vehicle, turn
off the engine and remove the key from its ignition.
Never operate the machine when driving backwards.
Never get onto the machine.
Permissible inclination of the machine on a slope when working and during transport is 8°.
Exceeding this incline can result in machine overturn.
Never stand between vehicle and machine unless the aggregation is secured against moving by
the vehicle’s brake.
When the parts of the machine need replacement, use only original spare parts as described in the
spare parts list.
Hydraulic hoses should be periodically checked and if any damage to the hoses have occurred or
if they have been used more than the required period, replace with new ones. Replace only with
hoses conforming to the manufacturer's specifications.
Period of use of hydraulic hoses should not exceed 5 years (including storage time).
Before any service works on the hydraulics, stop the vehicle's engine and take the ignition key
out.
Do not drain oil onto the ground, to the sewerage system, into rivers or lakes. For temporal
storage of used oils use tight tanks only.
Used oils contain substances harmful for the natural environment and should be delivered to a
proper used oil treatment plant.
Never use scotch tape to repair hydraulic hoses.
When connecting hydraulic hoses to the vehicle’s hydraulic connectors, make sure that there is no
pressure in both the vehicle’s and the machine’s hydraulic system.
Check, and if needed adjust, tightness of hydraulic connectors, as they can become loose during
the operation, what may lead to damaging the engine and the hydraulic pump.
When operating the hydraulics, always wear protective glasses and gloves. Hydraulic oil leaking
under pressure (16MPa) may penetrate the skin and cause its infection thereafter. If this occurred,
immediately visit a doctor.
The machine should be stored under a roof and in a way as to not be hazardous both to people or
animals.
Mount and dismount the machine on even and paved surface while keeping particular attention.
Before moving, make sure whether there are no unauthorized personnel directly nearby the
machine, give an acoustic signal.
For any break in the machinery operation turn off the drive.
Periodically check bolts and other fasteners. Do not operate with damaged or worn fasteners.
Do not operate the machine after dusk.
Do not leave the aggregate on slopes without any protection.
Do not leave the tractor's cabin or loader when driving.
In the event of a serious failure, stop the machine's drive, turn off the vehicle's engine and take
out the ignition key. Then call for technical service, and if an accident (in this case: road accident)
occurs, respect first aid rules and contact responsible authorities.
Do not transport any persons on the machine.
- 6 -
Operator's Manual
4.2. Transport
Have all persons (children in particular) not involved in the actual work with the machine move
FISHER
away from the area and limit the zone where the operations are to be carried out.
Carrier with hydraulic extension
For transport convert the machine to transport position (it. 5.3).
Before the vehicle mounted machine is set in its transport position, make sure that all rotating
parts have come to a complete standstill.
Do not drive over 16 mph / 25 km/h.
Drive slower if road conditions are poor, especially on irregular surfaces or steep slopes.
4.2.1. Moving machine onto another vehicle for transport
The driver and the carrier are responsible for the machine's transport safety. Any equipment and
parts must be secured for transport. To put the machine onto another vehicle in a safe way, please
obey the following rules:
Grab machine by any lifting devices only in places indicated by hook sign (Fig. 5),
For machine lifting, use only lifting devices with hoisting capacity larger than machine’s weight
shown in data plate. This also applies to ropes and chains used for lifting,
Do not lift if transport belts, belt suspensions, ropes are damaged. Whenever damage to these
parts occurs, replace with new ones,
When mounting slings, chains, handles etc., always set the machine's center of gravity properly
(Fig. 4),
To safely support the machine, use belts of adequate length so that the angle between them is no
greater than 120°, and the angle between the strand and the vertical is no greater than 60°,
Collapsible parts should be blocked in transport position,
No one should be within the range of action of the machine lifting when any transporting
operations are being carried out,
The machine should be protected from shifting on the vehicle's trailer,
Before transporting in the given position (Fig. 5), check whether the rotary arm is secured with
pin (S).
Fig. 4. Location of center of gravity
- 7 -
Operator's Manual
FISHER
Carrier with hydraulic extension
S
Fig. 5. Moving machine onto another vehicle
WARNING!
Securing the maneuver area and providing safety for operation performed is
the responsibility of the person in charge of moving of the machine.
4.3. Residual risk
Despite the fact, that SaMASZ Sp. z o.o. Białystok company – the manufacturer of the machine
takes the responsibility for the machine design and manufacturing, in order to eliminate hazard,
certain risk when operating the machine is unavoidable.
Major source of risk results from the following operations:
operation of machine by minors and operators not being familiarized with operator's manual,
operation of machine by personnel under influence of alcohol or other abusive substances,
failure to keep caution while transporting and moving the machine during operation,
transport of personnel on the machine,
presence of personnel and animals within the machine operating range,
service and adjustment operations with engine running.
1. Risk of being caught or pulled in
This risk occurs when (1) changing position of the machine, (2) operating near rotating parts,
and (3) working without safety guards.
During operation, maintenance and adjustment, always wear protective gloves, shoes and
clothing without loose elements, belts, etc. Always respect warnings on safety labels attached to the
machine.
- 8 -
Operator's Manual
85 dB.
FISHER
2. Risk of cutting injury
This risk is present when replacing working parts with sharp edges. During any maintenance
Carrier with hydraulic extension
and repair works, always wear safety gloves.
3. Risk of injury from liquid ejection out of hydraulic system
When connecting hydraulic hoses to and from both the vehicle’s and the tooling carrier's
hydraulic connectors, make sure that there is no pressure in both the vehicle’s and the machine’s
hydraulic system.
When operating the hydraulics, always wear protective glasses and gloves. Regularly check
hydraulic hoses for leaks.
NOTE:
Present residual risk results mainly from erroneous actions of the machine’s operator and
failure to follow the instruction manual.
4. Forbidden actions
During machine’s operation, do not do the following:
never unblock the machine, make any regulations or repairs of the machine while it is in motion,
never change order of operation and maintenance activities described in operator’s manual,
never operate the machine when it is not in working order or has damaged safety guards,
never get your hands and legs close to rotating parts of the machine,
during repair and maintenance of the machine, always comply with descriptions included in
operator’s manual; always do these activities when the vehicle’s drive is off,
before any works, focus your attention solely on the tasks to do,
never operate the machine under influence of alcohol, drugs, or strong medicines that impair your
attention,
do not wear clothes or jewelry that are too loose or too tight. Too loose clothing or jewelry may
be pulled in by the rotating parts of the machine,
the machine should not be operated by children or by handicapped people.
When describing residual risk, the work head complies with the state of the art in technology on
the date it was manufactured.
NOTE:
Despite following the specified instructions and prohibitions, residual risk is still present.
4.3.1. Residual risk assessment
Such risk can be minimized by doing the following:
thorough familiarizing yourself with operator’s manual,
allow no persons within the machine operation range,
adjust, maintain and lubricate the machine with the engine off,
only skilled persons should perform repairs of the machine,
operate the machine after having learned the operator’s manual,
protect the machine against access of children and any unauthorized personnel,
When the risk of exposure to noise cannot be avoided or eliminated by any
protective means or organization of work, the employer must:
1) provide the operator with individual means of noise protection if the noise level
in work place exceeds 80 dB.
2) provide the operator with individual means of noise protection and supervise the
correctness of its usage, if the noise level in work place reaches or exceeds
- 9 -
Operator's Manual
4.4. Operator's qualifications
FISHER
The machine and tractor's operator should hold license to drive a tractor, i.e. of the following
categories: B or C (C1) or D (D1). Holding a license to drive a tractor with a trailer is also acceptable;
this applies to categories: T or B+E or C+E or D+E. To operate the machine no special medical
certificates, or additional qualifications are required. It is sufficient to receive instructions given by
Carrier with hydraulic extension
the SaMASZ personnel at the machine commissioning.
4.5. Safety labels and their meaning
IMPORTANT
All warning labels should be clean and legible,
Lost or damaged labels must be replaced,
New labels can be ordered at the Manufacturer.
N-03
Read the operator’s manual before
use
N-11
Lubrication points
Before any service or repair
disconnect the power supply
Transport holder for machine
N-04
N-40
handling
N-07
O
Do not operate the if any
personnel remains within 164 ft
(50m) from the machine
N-50
Do not remain in the machine
swinging area
N-52
Wear protective gloves
Avoid contact with liquid coming out
N-117
under pressure
NOTE:
Any spare part used for repair of the machine should have all safety labels provided by the
manufacturer.
- 10 -
Operator's Manual
FISHER
Carrier with hydraulic extension
5. OPERATION
NOTE:
Fig. 6. Location of safety labels on the machine
For the machine storing period, cylinder rods are lubricated at SaMASZ with protective
grease in order to protect them against weather conditions that can shorten their service life.
Before any operation with the machine remove excess grease coming out of cylinder rods.
5.1. Attaching the carrier to the vehicle
Mount the carrier on front loader's or loader-excavator's holder (Fig. 7) and secure as
recommended by the holder's manufacturer.
Du to hitch interchangeability, the Fisher carrier can be aggregated with various vehicles (Fig. 8).
Ask manufacturer or your dealer on hitch availability.
- 11 -
Operator's Manual
Fig. 7. Attaching carrier to front loader
FISHER
Carrier with hydraulic extension
Fig. 8. The Fisher carrier connections
- 12 -
Operator's Manual
FISHER
After having mounted the carrier, connect hydraulic hoses (A) for side shift and tooling
rotation supply and hoses (B) for work head supply (PT circular saw, PG branch grinder) (Fig. 8).
Remember to adjust oil flow rate [L/min] to work head's demand – see Tab. 1.
WARNING!
If Fisher is aggregated with PT circular saw, the motor of which has no third
oil separation pipe, then the return hose (B - female connector) must be
connected to a connector on a vehicle with pressure-less return line. Otherwise
hydraulic motor can be damaged.
If the vehicle has no hydraulic connector with pressure-less return line, refer to
the instruction manual, or consult the vehicle's manufacturer where pressureless return line can be connected to the tank.
Carrier with hydraulic extension
Depending on the type of vehicle, with which the carrier is aggregated, it is allowable to
replace connectors or extend hydraulic hoses on the user's own. If the oil flow rate is not adequate,
SaMASZ offers ZH hydraulic power pack to be mounted on the rear 3-point linkage, Cat. II with
maximum flow of 130L/min – pressure 200bar.
WARNING!
Extending or using too thin hydraulic hoses for work head supply can lead to
overheating the pack, improper operation of the tooling attached or its damage.
Connect 3-pin controller plug (C) to corresponding socket on the machine, and lighter outlet
(D) to 12V cigarette outlet.
WARNING!
When connecting hydraulic hoses and electric cables to front loader's arms, in
machine rotation points, provide and leave some allowance, so that during the
operation they are not damaged.
5.2. Attaching work head to the carrier
The Fisher carrier enables aggregation of the following work heads: PG 150, PG 200, PT3-190,
PT4-250. To attach a work head to the carrier:
position the vehicle and the carrier set, so that the holder with mounting plate (Fig. 2, item 6)
overlaps the head's plate;
using six M14 bolt connections (B) joint the two plates together. Tighten the bolts with torque
corresponding to their property classes (Tab. 2). Central M30 bolt connection (C) is not required,
however it facilitates the head rotation by 180°, if needed;
connect hydraulic connectors (D) and secure the hoses by clipping them with chain (E) (Fig. 9).
- 13 -
Operator's Manual
FISHER
Carrier with hydraulic extension
Fig. 9. Attaching work head to the carrier
To detach a work head, follow the same steps, position the machine on an even ground and
turn the vehicle's drive on. Then disconnect the push-in fittings and loosen bolts in mounting holder.
NOTE:
The carrier is equipped with a set of hydraulic push-in fittings for quick work head mounting
and demounting.
5.3. Preparing the machine for transport
To prepare the machine for transport do the following:
lift the machine approx. 0.2m above the ground;
remove support feet (A) (Fig. 9);
check whether rotary arm is secured with pin (S) (Fig. 5), otherwise – secure the arm with pin;
if the carrier has circular saw or branch trimmer mounted on, protect the sharp edges.
5.4. Moving the extension arm with mowing head from transport to working position
The Fisher carrier enables operation in side and central position.
- 14 -
Operator's Manual
FISHER
5.4.1. Side position
To set the machine in side position, do the following (Fig. 10):
Carrier with hydraulic extension
In order to improve safety lower the machine as low as possible and set it in such way that axis of
rotation (P) of the arm is vertical;
Unlock and remove pin (S), turn the arm by 180° and secure again with pin (S) – longitudinal
opening;
Install safety breakaway device (D) by joining the rotary arm with the extension arm.
(P)
180°
(S)
(D)
Fig. 10. Setting carrier in side working position
- 15 -
Operator's Manual
FISHER
5.4.2. Central position
To set the machine in central position, do the following (Fig. 11):
Carrier with hydraulic extension
In order to improve safety lower the machine as low as possible and set it in such way that axis of
rotation (P) of the arm is vertical;
Unlock and remove pin (S), and then deflect the arm;
Install safety breakaway device (D) in the place shown by joining the rotary arm with the
suspension frame.
(P)
(S)
(D)
Fig. 11. Setting carrier in central working position
- 16 -
Carrier with hydraulic extension
5.5. Operation
Operator's Manual
FISHER
WARNING!
Before operating learn the operator's manual for the attached work head.
Please note that in working position, and with the arm extended to its maximum in particular, the
centre of gravity is shifted. To improve the vehicle's stability it is recommended that with EURO type
hitch – lock (A) counterweight (B) are used (Fig. 12).
Fig. 12. Counterweight on Fisher carrier
Fig. 13. Working position
- 17 -
Operator's Manual
LED indicator for
cylinder selection
LED indicator for
cylinder selection
FISHER
5.5.1. Operating control panel
The panel is used to choose a cylinder (either shift or rotation) to be operated with the vehicle's
hydraulics. For panel installation description, see section 5.1 herein (Fig. 8).
Carrier with hydraulic extension
–
shift
–
rotation
Switch
Fig. 14. Control panel
5.6. Operating hydraulics
Periodically check the condition of hydraulic hoses and fittings, and if damaged, replace them
with new ones. Irrespective of the above replace hydraulic hoses every 5 years including their storage
time. In the winter period it is recommended to store the machine in a dry, well ventilated room,
paying attention that hydraulic hoses are not deflected.
NOTE:
Oil used in hydraulic circuits is toxic. Before any servicing, oil replacement, the
operator should wear protective clothing.
Strictly follow the valid regulation on hazardous waste. Used oils should be drained to
special containers and taken to a specialized used oil treatment plant.
5.7. Maintenance and service
5.7.1. Daily maintenance
When you finish each day of operation carry out the following maintenance:
remove any grass, mud, etc. from the machine,
inspect all visible parts and components and their connections; tighten all loose bolts and nuts and
replace all damaged and/or worn parts,
lubricate all pins and cylinder joints,
visually check technical condition of the hydraulics: fasteners for tightness. When any
malfunctions are found, tighten the fasteners and replace seals.
check technical condition of connections between the machine and the vehicle.
- 18 -
Operator's Manual
x4
5.7.2. After-season maintenance
FISHER
At the end of the season clean, wash and dry the machine. Carefully grease unpainted surfaces
and 3-point linkage pins.
Carrier with hydraulic extension
Moreover:
examine the paintwork condition. If necessary, clean and paint any damaged points,
examine technical condition of the hydraulics as on daily maintenance. Moreover carefully check
the condition of hydraulic hoses. If necessary, replace them with new ones as required by the
manufacturer,
examine the technical condition of the machine's moving parts. If any clearance on pins is found,
replace them together with sliding bushings and tighten,
protect working parts (pins, joints, cylinder rods, etc.) against corrosion by applying a thin film of
solid grease on their surfaces.
5.7.3. Storage
Disconnect the machine and set it on support feet. It is recommended to store the aggregate on a
paved ground, preferably in roofed places, inaccessible to unauthorized personnel and animals.
After storing for winter period, before operating the machine, check its technical condition
while paying special attention to the hydraulics. Touch up the paintwork, lubricate and check the
condition of hydraulic hoses.
6. LUBRICATION
For machine lubrication use grease STP. Do not use any plant or animals based grease. Before
applying the grease, clean grease nipples and lubrication points.
Lubrication points are shown in (Fig. 15).
Fig. 15. Lubrication points on Fisher carrier
- 19 -
Operator's Manual
cut.
frame.
arm is lifted is less than 8000N.
FISHER
7. MAINTENANCE AND SERVICE
Tab. 2. Torque values for bolts
Carrier with hydraulic extension
8. MALFUNCTIONS AND THEIR REPAIR
In the event of a malfunction, immediately stop the machine and after the cutting assembly has
come to a complete stop, turn off the engine. Before disconnecting any of the hydraulic hoses, check
whether there is no pressure in the hydraulics and remember to cut-off the oil feed from the tan to the
machine's hydraulics. Hot or/and pressurized oil leak may cause serious bodily injuries. For the
machine's operator safety, stop the machine on an even ground. All hydraulic cylinders and moving
elements must be completely locked.
Defect Reason Repair
Shift cylinder cannot be
operated.
Rotation cylinder cannot
be operated, although
extension cylinder works
correctly.
Vibrations and noises
when extending the arm.
Rotary arm is lifting too
often.
Hydraulic connectors are not
connected to one pair of feed
connectors.
Hydraulic connectors are not
compatible with hydraulic
connectors on the vehicle.
Closed choke valve on the
cylinder (speed adjustment).
Control panel not connected.
Damaged solenoid.
No lubrication.
Damaged safety breakaway
device.
Connect hydraulic connectors correctly.
Replace the connectors for correct
ones.
Adjust choke valve.
Check if after the controller activation
the LED indicators are lit, check lighter
outlet and 3-pin plug at the machine.
Make sure that electric cables are not
Check if coil on the valve operates
correctly. Otherwise, replace the coil.
Replace the solenoid.
Lubricate the slides in suspension
Replace safety breakaway device if
force applied to the head, at which the
- 20 -
Operator's Manual
9. REPAIR AND WITHDRAWAL FROM USE
FISHER
Before any repair works, possibly related to admitting it for use, clean the machine thoroughly
Carrier with hydraulic extension
and remove any grass, dirt or mud.
After having inspected all bolt connections and pins for clearance, assess whether the machine
is in proper operating condition. If after having replaced some worn parts, the machine can be
operated further, replace all remaining damaged parts with new ones. Also replace fasteners (bolts,
nuts, cotters, etc.) with new ones.
If the machine cannot be repaired any more, it should be withdrawn from use. To do so, drain
oil from hydraulic hoses (to special tight tanks) and deliver it to a proper waste treatment company.
Clean the machine parts, dismantle and properly dispose of all plastic parts. Deliver it to a proper
waste treatment company for reuse. Remaining metal parts should be delivered to a breaker's yard.
After that, the machine can be scrapped.
When dismounting the aggregate and during disconnection of assemblies and parts in
particular, follow all safety precautions. Perform dismounting works wearing protective gloves.
Withdrawal of dismounted parts should conform with valid environment protection provisions.
10. WARRANTY CARD
CARRIER WITH HYDRAULIC EXTENSION:
Serial number
Manufacture date
Warrantor’s stamp
Controller’s signature
This product has been checked and deemed fully serviceable and cleared for use
Date of sale
Seller’s stamp
Seller’s signature
.
NOTE:
Warranty card – if not filled in, corrected or illegible – is not valid.
- 21 -
Operator's Manual
11. WARRANTY TERMS
Carrier with hydraulic extension
FISHER
11.1. Warranty claim procedure
1. The manufacturer warrants good quality and defect-free operation of the machine under this
warranty if the machine is operated in accordance with the operator's manual.
2. Faults or damages to the machine found within 12-month period from the date of purchase shall
be removed free of charge at the purchaser’s or the manufacturer’s.
3. Faults or damages should be submitted personally, in writing or by telephone. Repairs shall be
carried out within 14 days. Any repairs under the warranty should be carried out by authorized
SaMASZ service facilities.
4. Warranty claims regarding the product replacement or repayment are considered within 14 days
by the manufacturer.
5. The following conditions are not covered by warranty:
a) use for any other purpose than those described in the operator’s manual,
b) fortuitous events or other (see item 1), for which the manufacturer does not bear any
responsibility,
c) natural wear of parts such as sliding bushings and plates. These repairs may be done
only at Purchaser's cost:
d) damaged frame.
6. The Purchaser bears the costs of technical evaluation – if the Manufacturer finds that a
claimed product is free of defects and this is confirmed by technical report.
7. The Manufacturer has the right to cancel the warranty in the following cases:
a) hampering with the machine, modifications to its mechanical design or intentional
damages.
b) vast damage caused by random events or others, for which the Manufacturer does not
bear any responsibility,
c) lack of required records in the warranty card or filling in the warranty card
independently,
d) use of the machine for any purpose other than described in the operator's manual.
8. The Manufacturer can break the service agreement with immediate effect when the user does
not pay the invoice according to that agreement in a timely manner and the delay in payment is
longer than 30 days from maturity date. Breaking the service agreement by the Contractor due to
causes dependent on the user shall lead to termination of the warranty given for the particular
machine.
9. The Manufacturer shall not bear any compensation responsibility for the loss caused by the
machine breakdown during its operation.
NOTE:
Please ask your dealer to complete and return the warranty card with date and place of
purchase, and dealer's stamp and signature. Otherwise you may lose your warranty rights.
NOTE:
The Manufacturer reserves the right to introduce design changes.
NOTE:
The SaMASZ company is constantly working on the development of all of its machine types
and models. Therefore, any modifications of our machinery due to their form, equipment and
technology are likely. No claims can arise from data, drawings and descriptions included
herein as well as the spare parts list.
SaMASZ is not responsible for printing errors.
- 22 -
Operator's Manual
Date, stamp and signature of repair shop.
Date, stamp and signature of repair shop.
Date, stamp and signature of repair shop.
11.2. Warranty repairs record
Repair scope and spare parts replaced:
Carrier with hydraulic extension
FISHER
- 23 -
Loading...
