Salamander Designs SNC20C-B User Manual

TM

SYNERGY SYSTEM

Salamander Designs Ltd. • 800-535-5659 • www.SalamanderDesigns.com ©2006 Salamander Designs Ltd. Synergy System, Patented.

Limited Warranty

Five full years Salamander Designs Ltd will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or destruction of other
equipment consequential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing material. Any damage incurred in
a shipment not in original packaging shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only.

Doc No. 500-980/v10.06 SNC -1/4

BEFORE YOU BEGIN:

• Unpack all parts and read instructions carefully before beginning.

• Shelf pegs and door hinges must slide into the channels of the post in the correct order.
They cannot be removed individually without disassembling the whole unit.

1

90

O

B.Connect Post

Screw foot with metal washer through bottom
shelf and into the end of each extruded post.
Hand tighten fully and use wrench to tighten
nut onto underside of shelf.

A.Square Post

Square the post to the bottom shelf.

Connect Posts to Bottom Shelf

!

Short Post

WARNING: Tighten by screwing the leveler foot NOT the post.

Leveler Foot

Hex Nut

Washer

TM

Model: SNC20

Model: SNC30

Doc No. 500-980/v10.06 SNC - 2/4

2

Add Shelf Pegs

A.Pegs for Shelves

Insert one shelf peg down each post.
NOTE: There are two varieties of shelf pegs
(A and B). They are designed to cradle the
shelf in place. Refer to drawing.

B

A

A B

B

A.Insert Hardware

Combine the 1” threaded studs with flat nuts.
Slide 2 sets of hardware down the two outside
posts and 4 sets down the center post. Allow
studs to remain loose at bottom of post.

B.Position & Secure Studs

Align the Spacer Tool at the top of each post,
then position top studs through the small “Rear
Panel” hole. Repeat this step with the bottom
studs aligning the Tool along the bottom of post
to set spacing for cable passage. Use the hex key
to secure the top and bottom studs to the posts.

C.Place Rear Panels

Secure each panel in place with thumb nuts.

Attach Rear Panels

3

TIP

To ease installation of rear
panels gently place the unit
face down on the floor to
improve aligning of panels.

A

2X

2X

4X

B. Adjust Peg Height

Position the shelf peg through the Spacer
Tool and tighten at desired height. See
step 4 for fine tuning.

Note:

If installing door(s), use 2 sets
of shelf pegs at the top of short
posts to act as door stops.

www.salamanderdesigns.com

1 2 3 4 5 6 7 8 9

REAR P

ANEL

EXTENDED

REAR P
ANEL

S

2
0 /
S
VDO

REAR PANEL
S30 / S

40

4

1/
2

"

SPACER

6"

TOOL

8"

8"

TOOL

6"

SPACER

"

1/2

4

S30 / S40

L

REAR PANE

VDO

S20

/ S

L

R P

REA

ANE

END

ED

EXT

ANE

L

R P

REA

1 2 3 4 5 6 7 8 9

www.salamanderdesigns.com

8"

TOOL

6"

SPACER

"

1/2

4

S30 / S40

ANEL

REAR P

S20 / SVDO

L

ANE

REAR P

ED

EXT

END
L

ANE

R P

REA

1 2 3 4 5 6 7 8 9

www.salamanderdesigns.com

B. Fine Tuning

Use the bubble level to precisely adjust
the adjustable shelves. Be sure to level
both sides as well as front to back. Use
the hex key to tighten each peg.

E. Double-Width Shelf

Place double-width shelf on brackets.

D. Rubber Pad

Place rubber pads on top of center posts.

A

D

Doc No. 500-980/v10.06 SNC - 3/4

4

Placing Shelves

A. Secure Top

5

Top Assembly

C

C.Heavy Duty Bracket

Install heavy duty brackets down outer posts
to support the double/triple- width shelf.
Place rubber shelf tabs through bracket.

A. Adjustable Shelves

Place shelves from the bottom up. Angle
the shelf in between the front post and
set on top of shelf pegs.

E

If assembling model SNC20, skip to step C.

Secure top with the connector bolts.
Place the plastic plugs in the front center holes.

Doc No. 500-980/v10.06 SNC 4/4

(300-470)

Washer

(300-540)

Connector Bolt

(P-300-320) - Leveler Foot

6x

6x

6x

(P-400-040) - Level

(400-060) - 3/16” Hex Key

1x

1x

Rear Panel Hardware - (PHK-240)

2x

8x

8x

8x

(400-070) - 1/8” Hex Key

(300-560) - Flat Nut

(300-530) - ThumbNut

(300-510) - Stud

Double-Width Shelf Hardware - (PHK-510)

Parts

6 - Aluminum Posts 2 - Adjustable Shelf (SNC30 only)
1 - Top Shelf 1 - Spacer Tool
1 - Bottom Shelf 2 - Rear Panel
1 - Double Width Shelf 2 - Heavy Duty Shelf Bracket

(PHK-370)
Shelf Peg “B”- Right

(PHK-380)
Shelf Peg “A” - Left

4x

4x

(300-490)

Low Head Screw

(300-610)

Rubber Tab

1x

(400-035) - Wrench

4x

(300-560) - Flat Nut

2x

(400-070) - 1/8” Hex Key

1x

(301-280)
Cap Plug

(300-265)
Post Cap

1x

1x

1x

(PHK-370)
Shelf Peg “B”- Right
SNC30 Only

(PHK-380)
Shelf Peg “A” - Left
SNC30 Only

4x

4x
