Sakura HBK-23DL, HBK-23BP, HBK-23AL, HBK-23BL Operation / Installation / Service Manual

Sakura Air Conditioner
User-friendly, Earth-friendly

Evaporative Air Cooler (Vol.2)

(Operation / Installation / Service Manual)

HBK-23DL / BP

Ref, S- 116 / 03 / 10

HBK-23AL / BP HBK-23BL / BP

Touch screen controller

Hand-held remote controller

CONTENTS

1 . SA

FETY PRECAUTIONS…………..………………………… 1

2 . PRODUCT

INTRODUCTION………………………………… 1

3 . SPE

CIFICATIONS……………………………..……………… 2

4 . APPLICABLE RANGE………………………………………

… 3

5 . OPERATING ENVIRONMENT…………………..…………… 3

6 . UNIT

PARTS IDENTIFICATIONS………………….………… 4

7 . PACK

ING LIST……………………………………….………… 4

8

. SAFETY CAUTION…………………………………………..… 4

9

. CIRCUIT DIAGRAM…………………………………………… 6

10

. MAIN CONTROL BOARD………………..…………………… 7

11

. OPERATING INSTRUCTIONS……………..………………… 8

12

. INSTALLATION INSTRUCTIONS……………….……………

13

. CLEANING AND MAINTENANCE…………....……………… 14

14 . TROUBLE SHOOTING…………………………………………

SAKURA – Total Air Conditioning Solution

Please read this instruction carefully before using

PAGE

9

15

1.Do not put your hand or other stuff in the air outlet of the operatin machine.Otherwise,it may cause injury.

2.Do

not place heavy object on the unit,keep child away from the unit

3.Do

not put gas cooker in the place which the unit can blow directly. Otherwise,it may cause carbon

monoxi

de poisoning.

4.Do

not disassemble or modify the unit since the wrong operation may cause water leakage,fire or electric

shock

.

5.Do

add water from the water inlet of the unit

6.Do not install the unit in the place full of explosive and flammable materials.

7.When

not using the unit for a long time,please drain the water tank of all the water.Then keep the unit

ope

rating in fan mode for 10 minutes to dry the cooling pad,then turn off the power switch.

8.Always

ensure effective earthing.

The

environment friendly air conditioner has following advantages:

Power saving:it can save over 80% compared with traditional air conditioner Environment friendly:No

harmful

material,no freon during operating. High Efficiency:Use the min.power to make the max cooling

and

purifing effect. Working Principle:The evaporative air cooler produces effective cooling by combining a

natural

process-water evaporation-with a simple,reliable air-moving system.Fresh outside air is filtered

throu

gh the saturated evaporative media cooled by evaporation,and circulated by a blower wheel. Water

from

the bottom pan of the unit is pumped to the top and allowed to flow down over the evaporation cooling

pads of the spot cooler,evenly saturating the pads. Then a powerful blower pulls air through the

pads,forcing the water to evaporate which decrease the ambient temp.The cool air is then blown by the unit

at

a high velocity where you direct the cool air to go.

1

SAKURA – Total Air Conditioning Solution

1 SAFETY PRECAUTIONS

2 PRODUCT INTRODUCTION

Outdoor air

Fan

Cold air

Water

pump

Evapora

tion

heat exchanger

Water tank

Sketch Map of Operating Principle

2

SAKURA – Total Air Conditioning Solution

3 SPECIFICATION

Model No.

HBK-23DL/BP

HBK-23BL/BP

HBK-23AL/BP

Max Air Volume

23000 m3/h

Voltage/Frequency

220V/50HZ

Current

0.68~5

Power

150W~1100W

Motor

High efficient and waterproof type

Fan Type

Axial Fan

Water Tank Vloume

25L

Dimension(mm)

1100×1100×950

1100×1125×950

1100×1100×1040

Net Weight

69

71

78

Applicable Area

100~150 m2

Air Outlet Size

670×670 mm

Noise

≥ 60dB

Water Consumption

5-20 L/H

Due to the features of evaporative air cooler,like cooling,humidifing,air exchanging,it's mainly

applicable

for the places need to be cooling and ventilating,like:

1.Electronic,shoes,printworks,plastic,clothes,printing,packing factories,etc.

2.

Texitle,machine,ceramics,chemicals,glasses,hardware,leather factories,etc.

3.Hospi

tal,school,waitingroom,internetbar,shopping mall,supermarkets,etc.

4.Some

public places like kitchen,vegetable market,clubs,parking lot,bus station,etc.

5.Gree

nhouses,flowers and fowl farm,etc.

6.The

room which has requirements of high humidifing.

1.Ambient temp.: 2 ~ 45

2.Ambient

humidity: ≤90%

3.Atmospheric

pressure:86KPa~106Kpa

4.

Water should be processed with softening,water temp. 0 ~ 45, water pressure 0.15~0.6Mpa

5.Input

voltage should be within 10% of rated voltage

6.No

corrosive gas around.

SAKURA – Total Air Conditioning Solution

3

4 APPLICABLE RANGE

5 OPERATING ENVIRONMENT

ITEM NAME QTY.

1 Evaporative Air Cooler 1

2 USER'S MANUAL 1

To provent injury to the user or other people or property damage,the following instructions must be

followed:

This symbol indicates CAUTION

This symbol indicates NEVER DO THIS

This symbol indicates ALWAYS DO THIS

4

SAKURA – Total Air Conditioning Solution

6 STRUCTURE CHART

7 PACKING LIST

8 SAFETY CAUTIONS

5

SAKURA – Total Air Conditioning Solution

No using in the environment of explosive and flammable meterials

Keep the unit working in a flat place

Make the air outlet&inlet not close to wall,curtain,etc.,it may affect the performance

Only authorised service technician are allowed for repair or maintenance

6

SAKURA – Total Air Conditioning Solution

9 CIRCUIT DIAGRAM

7

SAKURA – Total Air Conditioning Solution

10 MAIN CONTROL BOARD

“on/off” :Touch this button to turn on or turn off

“cooling”: Touch this botton, change to cooling mode in the running situation.

“ventilation” :Touch this botton,change to fan only mode.

“clean”:Touch this botton, the unit will be cleaned automatically.

“swing”:Touch this botton to turn on or turn off the swing

increase wind speed :Touch this botton to increase wind speed

decrease wind speed: Touch this botton to decrease wind speed.

temperature display

water level display

8

SAKURA – Total Air Conditioning Solution

11 OPERATING INSTRUCTIONS

1. After water inflow,water inlet and water level will be controlled by floater automatically.

2. After power on, the unit will be in stand-by condition.

3.

After power on,press

to run in cooling mode,fan will start after submerged pump run for 2 minutes;If

any water shortage,fan will start without delay,and the unit will be run in fan only mode.Touch

again to

stop

cooling.

4.

After power on,press

to run in ventilation mode,and fan will start.Press it again to stop.

5. After power on,press

to run in clean mode.Drainage pump start and run for 2 minutes.Press it again

to stop cleaning

6.

Under the condition of ventilation or cooling,if need swing function,press .Press it again to stop.

7.

It will take 3 seconds to run into a new working mode during mode switching.

8.

The water inlet and water level is controlled by the floater.If water level display shows in one grill,it means no

water or not enough water;If shows in 3 grill,it means water reach to required level.In low water level,the

subme

rged pump will not work.Please keep the water inlet pipe through.The system default time is 12 hours.

9.

Press

for 5 seconds in power off condition,the auto drainage time could be adjusted from every 0~72

hours.For

0 means it will not drainage automically.The system default time is 12 hours.

10. Press

for 5 seconds in power off condition,the frequency could be adjusted from 0-50 HZ.The

system default is 50HZ.

11. Press

for 5 seconds in power off condition,the direction of fan rotation could be adjusted.When

setting at “0”,the fan will operate in a normal directio

n .At “1”,the fan will run in an opposite direction.The

system default is “0”(Note that it’s not suitable to

run in an opposite direction for a long time,please be

cautious to use this )

12.

The duration time for backlight is around one minute.The backlight will be on if touch any button in power off

con

dition.And the button can only work when backlight is on.

13.

Touch “ON/OFF” to turn off the machine.

14.

Do not put any heavy stuff on the top of the unit.

15.

During operation, make sure that there’s no any object to cover or bolck the air inlet and air outlet.Do not put

your hand or other object to the air outlet and air inlet.

16.

If not using the unit for a long time or in the winter,please drain the water out of the tank,and keep the unit

run

ning for 10 minutes in ventilation mode,to dry the cooling pads.Then cut off the power and cover the

cabinet by diaphragm for next time using.

17. Suggest to drain the water out of the tank every week and clean the filter.If using in the dirty

envi

ronment,please drain the tank for more

. Installation Methods: 1

Installation Drawing for Down Discharge Unit

SAKURA – Total Air Conditioning Solution

12 INSTALLATION

9

Installation Drawing for Side Discharge Unit

SAKUR Total Air Conditioning Solution A –

10

Installation Drawing for Up Discharge Unit

SAKURA – Total Air Conditioning Solution

11

Mounting Bracket Planform

Mounting Bracket Side View

SAKUR Total Air Conditioning Solution A –

12

2

Make sure to read th

. Important Notice for Installation

e use instructions and carry out the work by strictly complying with the

sed

space, the air outlet should be installed, so as to keep the balance of air outlet

（2 ）B

stalled horizontally, and the space between machine and wall

（3）

23DS/B,23BS/B

and 23AS/B,it is better to install air pipe.

ameter

should be

（4）

ir volume, so as to make the air volume of the branch pipe reach the

（5）I
（6）L ent is required for the air pipe. As for the down discharge model, four

air

（7）W

nc

e ladder shall be installed near the unit (the ideal material is stainless steel),

（8）W

s an burglar mesh is installed on the windowl, try to

（9）

rity

out

pr

oject plan.

（1）The equipment is suitable to use in an open space. If it is required to install the equipment

in

a clo

volume

and air inlet.

efore

installing the bracket of the air conditioner, the level line shall be fixed with level bar.

The

bracket shall be in

should

be between 280 to 330mm. (It varies from different locations).The indoor controller

shall

be at least 1.5m above the floor, and the soldering and installation of mounting

bracket

shall be stable. It shall be installed horizontally. The unit shall be installed

ou

tdoors, and the dynamic load of the mounting bracket shall be more than 250kg. If the

bracket

is installed 3 meters above the ground, it shall be added with guard rail. The water

supply

pipe and drainage pipe shall be properly installed. The water supply pipe shall be

ins

talled with pipe filer, so as to keep the incoming water clean. The drainage pipe shall

be

kept unblocked, which shall adopt PVC pipe and be connected and installed with

speed

glue.

It

is not recommended to install air pipe for model no., 18DS/B,18BS/B and 18AS/B;While

for

model no.

When

installing air pipe,the length should be within 30 meters,and the diameter of pipe

should

be changed by every 10 meters.For the first 10 meters,the di

800*

500 MM,for the second should be 700*500 MM,for the third should be 600*500MM.

The area of airflow outlet shall not be less than 1m

2

, or the length and size of the air pipe

shall be made according to the design standard. After the air pipe enters the wall, the

airflow

outlet shall be not less than 2.2 meters above the ground (excluding special

circums

tances).

If

there is branch air pipe, the air deflector must be installed on the branch pipe to regulate

or

balance the a

design

value.

f need low noise, the silencing elbows shall be used, so as to meet the requirement.

eak-

proof treatm

10mm drainage vents shall be left on the bottom of the waterproof elbow. When the

pipe

is connected to the room through the top of the building, leak-proof treatment is

required for the top building, so as to avoid the rainwater running into the room along the

air

pipe.

hen

the outdoor unit is installed on the wall without window or far from window, an

maintena

so as to facilitate the maintenance.

hen

the outdoor unit is installed under the window, the glass window shall be movable,

o as to open it when necessary. If

install a movable door with lock on the burglar mesh in case of any maintenance.

Before

testing the machine, check whether the water level is between the normal range. If

the water level is too high or low, please adjust the float ball. Pull the dust and impu

of the water pipe, check the power supply and if there is any leakage on the water

inlet/outlet pipe, then the testing can be started.

SAKURA – Total Air Conditioning Solution

13

Clean cooling pad

Disconnect the power,unscrew the 6 screws on the shutter,then pulls the shutter slightly,and

ke off the cooling pads assy.

ta

Attention:

Do

not make too high water pressure，not use acidity or alkalinity detergent

◆ r tank

utton

after power on and power off after 2 minutes

nnect

power,unscrew the screws on the shutterand take off the shutter

Cle t

which

easy to create bubble and

Clean wate

Method:

1.

Press "drain" b

2.

Disco

3.

Clean the bottom with soft brush

4.

Clean the dirt from the water level sensor

5. Clean

the water pump,drainage pump and filter with brush

an

he cabinet

Clean

the cabinet with soft detergent(Do not use the detergent

ha

rd brush)

SAKUR Total Air Conditioning Solution A –

13 CLEAN AND MAINTENANCE

14

Problem Possible causes What to do

Air cooler does not start

1.

The air cooler is unplugged

2.Swithch button does not work

4.

Too low voltage

1.Check the power

2.Re

place the main control board

phase

4.Check

the voltage

3.Check the

3.Lack of phase

1.Submerged pump broken 1.Replace the pump

Fuse blown frequent

2.Cooling pad or filter blocked 2.Clean pads or filter

flat place

kage

n

. Broken

flat place

k

utlet assy.

let

assy.

ute assy.

1.Keep the unit in a

1. Unit not in a

2.Re

pair the water tan

2. Water tank lea

3.Re

place the water o

3. Water outlet assy. Broke

Water leakage

4.Re

place the water in

4. Water inlet assy.broken

5.Adjust

the float ball

5. Water level exceed

6.Check

the water distrib

6. Water distribute assy

7.Cl

ean the pads

7.Dirty cooling pads

1.Replace the fan blade

Nois

e

ut of shape

h

1. Fan blade demaged or o

2.Replace motor

2. Motor abrasire

3.Clean

the bolcks

3.T ere sundries block the airout

d or too low wind

ng pad or filter pads and filter

oa

rd

am

aged or not

1.Clean or replace

1. Blocking on cooli

2.Replace main control b

2. Main control board damage

3.Check if motor d

3. Motor no working

No win

4.Check the phase

4.Lack of phase on motor

1.Add water

1. Lack of water

Air cooler does not cool as it

sho

uld

m

aged

in

g

bro

ken

trol

board

in control board

2.Check

water level sensor

2. Failure on water control syste

3.Replace submerged pump 3. Drainage pump dam

4.Replace main con

4. Cooling button no work

5.Replace ma

5.Main control board

White precipitate in cabinet ate1.Mineral substance exceed normal r

1.Increase

drainaging rate

and

filter

SAKURA – Total Air Conditioning Solution

14 TROUBLESHOOTING

SAKURA CORPORATION

Tel: [phone] Fax: [phone] E-mail: [e-mail] URL: www.sakura-aircon.com

15
