68379 Owner’s Manual

Section One - Profile
Overview

Thanks for purchasing of our model: CD30DM (digital camera with MP3 music
format function). It not only can take photos but also has the built-in PC camera and
MP3 function. This camera is equipped with 8MB SDRAM for photo and 16MB flash
for MP3: if you want to download the photos in the camera to your computer, you
are only required to connect the USB cable to your computer and your camera; It is
also possible to use the built-in PC camera to hold a video conference via the
internet, enabling you to have a face to face online conversation with others.

Product Package Contents

* Digital Camera * User’s Manual * Earphone
* Software CD * USB cable

System Requirements

¾ Windows98 SE/2000/ME/XP
¾ 125MB free hard disk space or above, 32MB or more RAM
¾ Color Monitor (Suggest at least 800*600 24 bit or above)
¾ Available USB Interface and CD-ROM

To Know Digital Camera

A. Earphone Hole
B. Shutter Button
C. LED
D. Viewfinder
E. Start/Function Button
F. LCD
G. Stop Button
H. Play/Pause Button
I. Hanging Strap Hole
J. VOL(+) Button
K. VOL(-) Button
L. Forward Button
M. Backward Button
N. Lens
O. USB Socket

P. SD/MMC card Socket
Q. Lock Button
R. Switch Button
S. Battery Box

Section Two - Install Battery

1. Open the battery door.

2. Please place two AAA batteries according to the pole directions for batteries on
the battery box.

3. Close the battery box cover.
Note:
When you use the USB cable to connect the camera with a computer, it is
unnecessary to use the batteries because the camera use the power provided by
the computer through the USB interface.

Warning

1. Don’t open the battery box at will, because the power cut will cause the photos
lost in the camera.

2. If you don’t use the camera for a long time, please take out of the batteries for fear

of the discharging or corrosion of the batteries.

3. Please don’t put the battery into fire for fear of explosion

Automatically enter the energy saving status

If the camera is not used in 30s, the camera will auto enter the energy saving status.

IMPORTANT NOTE: TO ACHIEVE THE BEST CLARITY, MAKE CERTAIN THAT

THE DISTANCE BETWEEN THE CAMERA AND THE SUBJECT
IS “5” FEET.

68379 Software Installation

IMPORTANT: Before attempting to install the software, make sure that you do
not have the camera or the USB cable attached to your computer. This will
affect the install process and will cause your installation to fail. Do not
connect the cable to the computer until the entire installation process of both
PhoTags Express and the Camera Driver has been completed. We suggest

you follow the step by step instructions that will appear on your screen
during the installation process.

SECTION Three- Software, Camera Driver & MP3 Driver Installation

1. Insert the CD into your CD-Rom drive. Make sure that your camera is

not

2. Select the “Install Software and camera drivers” option on the Install

3. On the “Install your camera software” screen, click the “Install” button

4. On the “PhoTags Express" screen, click the “Next” button.

connected to the computer.

menu.

to install PhoTags Express followed by the installation of PhoTags
WebCam Express and your Camera driver.

5. Please review the license terms and click the “Agree” button to
continue.

6. Let the “PhoTags Express” installer create the folder where the program
will be installed to, and then click “Install”

7. Click “Finish” to let the “PhoTags Express” installer finish the installation
program.

8. This will automatically launch the Install shield for the camera driver.
Click “Next” to continue.

9. Once the program has finished installing you will have to restart your
computer.

10. After restarting your computer, make sure that the CD is still in your
CD-Rom drive. Select the “Install MP3 drivers” option on the Install

menu.
Note: Please install MP3 driver if your operation system is Windows

98 SE. And you needn’t install this driver if your operation system is
Windows 2000/ME/XP.

11. This will automatically launch the Install shield for the MP3 driver. Click
“Next” to continue.

12. Once the program has finished installing you will have to restart your
computer.

13. You have successfully installed the “PhoTags Express” software, the
“PhoTags WebCam Express” software, the Camera driver and the MP3
driver.
