Sailor 6222, 6222 VHF DSC User Manual

USER MANUAL

SAILOR 6222 VHF DSC

SAILOR 6222 VHF DSC

User manual

Document number: 98-131184-A
Release date: January 24, 2011

Disclaimer

Any responsibility or liability for loss or damage in connection with the use of this
product and the accompanying documentation is disclaimed by Thrane & Thrane. The
information in this manual is provided for information purposes only, is subject to
change without notice and may contain errors or inaccuracies.

Manuals issued by Thrane & Thrane are periodically revised and updated. Anyone
relying on this information should acquire the most current version e.g. from

http://www.thrane.com or from the distributor.

Thrane & Thrane is not responsible for the content or accuracy of any translations or
reproductions, in whole or in part, of this manual from any other source.

Copyright

© 2011 Thrane & Thrane A/S. All rights reserved.

Trademark Acknowledgements

• Thrane & Thrane is a registered trademark of Thrane & Thrane A/S in the European

Union and the United States.

• SAILOR is a registered trademarks of Thrane & Thrane A/S.

• Other product and company names mentioned in this manual may be trademarks or
trade names of their respective owners.

GPL notification

The software included in this product contains copyrighted software that is licensed
under the GPL/LGPL. The verbatim licenses can be found online at:

http://www.gnu.org/licenses/old-licenses/gpl-2.0.html
http://www.gnu.org/licenses/old-licenses/lgpl-2.1.html

You may obtain the complete corresponding source code from us for a period of three
years after our last shipment of this product, which will be no earlier than December 31,
2015, by sending a money order or check for DKK 50 to:

SW Technology/GPL Compliance,
Thrane & Thrane A/S,
Lundtoftegaardsvej 93D
2800 Lyngby
DENMARK

Please write "source for product SAILOR 6222 VHF DSC" in the memo line of your
payment.

You may also find a copy of the source at http://www.thrane.com/foss.
This offer is valid to anyone in receipt of this information.

Warranties

Any attempt to install or execute software not supplied by Thrane & Thrane on this
device will result in the warranty being void. Any attempt to modify the software on this
device in a way not specified by Thrane & Thrane will result in the warranty being void.

iv

Safety warning 1

The following general safety precautions must be observed during all
phases of operation, service and repair of this equipment. Failure to comply
with these precautions or with specific warnings elsewhere in this manual
violates safety standards of design, manufacture and intended use of the
equipment. Thrane & Thrane assumes no liability for the customer's failure
to comply with these requirements.

Ground the equipment

To minimise shock hazard, the SAILOR 6222 VHF DSC unit must be connected
to an electrical ground and the cable instructions must be followed.

RF exposure hazards and instructions

Your Thrane & Thrane radio set generates electromagnetic RF (radio
frequency) energy when transmitting. To ensure that you and those around
you are not exposed to excessive amounts of energy and thus to avoid health
hazards from excessive exposure to RF energy, all persons must be at least
3ft (0.9 m) away from the antenna when the radio is transmitting.

Warranty limitation

IMPORTANT - The radio is a sealed waterproof unit (classified IPX8). To
create and maintain its waterproof integrity it was assembled in a controlled
environment using special equipment. The radio is not a user maintainable
unit, and under no circumstances should the unit be opened except by
authorized personnel. Unauthorized opening of the unit will invalidate the
warranty.

Installation and service

Installation and general service must be done by skilled service personnel.

Compass safe distance

Minimum safety distance: 0.85 m from the SAILOR 6222 VHF DSC.

v

Emergency calls

MM

MM

M

AA

AA

A

YY

YY

Y

DD

DD

D

AA

AA

A

YY

YY

Y

NANA

NANA

NA

MEME

MEME

ME of the

VV

VV

V

EE

EE

E

SS

SS

S

SS

SS

S

ELEL

ELEL

EL in distress

CC

CC

C

ALAL

ALAL

AL

LL

LL

L

SS

SS

S

IGNIGN

IGNIGN

IGN or other

IDENIDEN

IDENIDEN

IDEN

TT

TT

T

IFICIFIC

IFICIFIC

IFIC

AA

AA

A

TT

TT

T

IONION

IONION

ION

MM

MM

M

MM

MM

M

S

S

SS

S

II

II

I

(If the initial alert is sent by DSC)

PP

PP

P

OO

OO

O

SS

SS

S

ITIT

ITIT

IT

IONION

IONION

ION

given as

ll

ll

l

atat

atat

at

itit

itit

it

udeude

udeude

ude and

longitlongit

longitlongit

longit

udeude

udeude

ude

or

If latitude and longitude are not known

or if time is insufficient,

in relation to a known geographical location

NANA

NANA

NA

TURETURE

TURETURE

TURE of distress

Kind of

AA

AA

A

SS

SS

S

SS

SS

S

II

II

I

SS

SS

S

TT

TT

T

ANCANC

ANCANC

ANC

EE

EE

E required

Any other useful

INFINF

INFINF

INF

OROR

OROR

OR

MM

MM

M

AA

AA

A

TT

TT

T

IONION

IONION

ION

MM

MM

M

AA

AA

A

YY

YY

Y

DD

DD

D

AA

AA

A

YY

YY

Y

-M-M

-M-M

-M

AA

AA

A

YY

YY

Y

DD

DD

D

AA

AA

A

YY

YY

Y

-M-M

-M-M

-M

AA

AA

A

YY

YY

Y

DD

DD

D

AA

AA

A

YY

YY

Y

This is

NANA

NANA

NA

ME-NAME-NA

ME-NAME-NA

ME-NA

ME-NAME-NA

ME-NAME-NA

ME-NA

MEME

MEME

ME

CC

CC

C

ALAL

ALAL

AL

LL

LL

L

SS

SS

S

IGNIGN

IGNIGN

IGN

or other IDENTIFICATION

MM

MM

M

MM

MM

M

SS

SS

S

II

II

I

(If the initial alert is sent by DSC)

Use the

HANDHAND

HANDHAND

HAND

SS

SS

S

ETET

ETET

ET

for voice calling

LL

LL

L

ifif

ifif

if

t Ct C

t Ct C

t C

ovov

ovov

ov

erer

erer

er

PP

PP

P

rr

rr

r

ee

ee

e

ss

ss

s

s RED Buttons RED Button

s RED Buttons RED Button

s RED Button

until beep sounds continuously
(more than 3 seconds)

SHIP‘s NAME:

CALLSIGN:

MMSI:

OWN OWN

OWN OWN

OWN

IDID

IDID

ID

99-132140

Press

VHF
MF
HF4
HF6
HF8
HF12
HF16

Channel 70

2187.5 kHz

4207.5 kHz

6312.0 kHz

8414.5 kHz

12577.0 kHz

16804.5 kHz

Channel 16

2182.0 kHz

4125.0 kHz

6215.0 kHz

8291.0 kHz

12290.0 kHz

16420.0 kHz

- - - - -

2174.5 kHz

4177.5 kHz

6268.0 kHz

8376.5 kHz

12520.0 kHz

16695.0 kHz

DD

DD

D

SCSC

SCSC

SC

RR

RR

R

adiadi

adiadi

adi

otot

otot

ot

elephonelephon

elephonelephon

elephon

yy

yy

y

NBDPNBDP

NBDPNBDP

NBDP

DIDI

DIDI

DI

SS

SS

S

TRETRE

TRETRE

TRE

SS

SS

S

SS

SS

S

and C and C

and C and C

and C

OMOM

OMOM

OM

MM

MM

M

UNICUNIC

UNICUNIC

UNIC

AA

AA

A

TT

TT

T

IONION

IONION

ION

FREQUENCIEFREQUENCIE

FREQUENCIEFREQUENCIE

FREQUENCIE

SS

SS

S

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Remember to use the correct HF-procedures
Don‘t forget your EPIRB is the secondary means of
alerting

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

vi

Preface 2

Radio for occupational use

The SAILOR 6222 VHF DSC fulfils the requirements of the Marine
Equipment Directive 96/98/EC and the amending Directive
2002/75/EC and is intended for use in maritime environment.

SAILOR 6222 VHF DSC is designed for occupational use only and
must be operated by licensed personnel only.

SAILOR 6222 VHF DSC is not intended for use in an uncontrolled
environment by general public.

SAILOR 6222 VHF DSC is designed for installation by a skilled
service person.

vii

Training information 3

The SAILOR 6222 VHF DSC is designed for occupational use only
and is also classified as such. It must be operated by licensed
personnel only. It must only be used in the course of employment
by individuals aware of both the hazards as well as the way to
minimize those hazards

The radio is thus NOT intended for use in an uncontrolled
environment by general public. The SAILOR 6222 VHF DSC has
been tested and complies with the FCC RF exposure limits for
Occupational Use Only. The radio also complies with the following
guidelines and standards regarding RF energy and
electromagnetic energy levels including the recommended levels
for human exposure:

• FCC OET Bulletin 65 Supplement C, evaluating compliance with
FCC guidelines for human exposure to radio frequency
electromagnetic fields.

• American National Standards Institute (C95.1) IEEE standard for
safety levels with respect to human exposure to radio frequency
electromagnetic fields, 3 kHz to 300 GHz

• American National Standards Institute (C95.3) IEEE
recommended practice for the measurement of potentially
hazardous electromagnetic fields - RF and microwaves.

Below the RF exposure hazards and instructions in safe operation
of the radio within the FCC RF exposure limits established for it are
described.

Warning

Your Thrane & Thrane radio set generates electromagnetic RF
(radio frequency) energy when it is transmitting. To ensure that
you and those around you are not exposed to excessive amounts of
that energy (beyond FCC allowable limits for occupational use) and
thus to avoid health hazards from excessive exposure to RF
energy, FCC OET bulletin 65 establishes an Maximum Permissible
Exposure (MPE) radius of 3 ft. (0.9m) for the maximum power of
your radio (25W selected) with an half wave omni-directional

viii

antenna having a maximum gain of 3 dB (5.2dBi). This means all
persons must be at least 3 ft. (0.9m) away from the antenna when
the radio is transmitting.

Installation

1. An omni-directional antenna with a maximum power gain of

5.2 dBi must be mounted at least 9.6 ft. (2.9m) above the

highest deck where people may be staying during radio
transmissions. The distance is to be measured vertically from
the lowest point of the antenna. This provides the minimum
separation distance which is in compliance with RF exposure
requirements and is based on the MPE radius of 3 ft. (0,9m)
plus the 6.6 ft. (2m) height of an adult.

2. On vessels that cannot fulfil requirements in item 1, the antenna
must be mounted so that its lowest point is at least 3 ft. (0.9m)
vertically above the heads of people on deck and all persons
must be outside the 3 ft. (0.9m) MPE radius during radio
transmission.

• Always mount the antenna at least 3ft (0.9m) from possible

human access.

• Never touch the antenna when transmitting

• Use only authorized T&T accessories.

3. If the antenna has to be placed in public areas or near people
with no awareness of the radio transmission, the antenna must
be placed at a distance not less than 6 ft. (1.8m) from possible
human access.

Failure to observe any of these warnings may cause you or other
people to exceed FCC RF exposure limits or create other dangerous
conditions.

ix

Manual overview

This manual has the following chapters and appendices:

• Introduction contains a description of the VHF radio.

• Operation explains how to make and receive voice and DSC

calls over VHF, including how to use and set-up scanning,
watch and replay.

• Service & maintenance contains support information including

lists of accessories and a troubleshooting guide.

• Appendix with Technical specifications and Maritime channels.

Related documents

Important

All installation information and instructions are not covered in this
manual. Please download the SAILOR 6222 VHF DSC Installation
manual (98-132904) at http://extranet.thrane.com/.

In the installation manual you can read how to mount the VHF radio
and how to connect accessories and external equipment, including
detailed system configuration examples with cable specifications.

Title and description Document number

SAILOR 6222 VHF DSC, Installation guide 98-132281

SAILOR 6222 VHF DSC Installation manual

(download only)

98-132904

SAILOR 6101 and 6103 Alarm Panel,
Installation and user manual

98-130981

Emergency call sheet 98-132369

x

xi

Table of Contents

Chapter 1 Introduction

VHF radio with DSC Class A ................................................ 1

Accessories available .........................................................4

Chapter 2 Operation

Overview ............................................................................9

General use and navigation ............................................. 10

VHF radio communication .................................................15

Watch ................................................................................19

Scan .................................................................................20

DSC calls ...........................................................................21

Handling multiple calls — DSC and voice ..........................34

Phone book ......................................................................35

Replay function ................................................................ 37

Setup ...............................................................................38

Chapter 3 Service & maintenance

Contact for support ...........................................................47

Maintenance .................................................................... 47

Troubleshooting guide .....................................................49

Warranty and returning units for repair ...........................53

App. A Technical specifications

Transceiver unit SAILOR 6222 VHF DSC .............................55

General DSC specifications ...............................................58

Table of Contents

xii

NMEA data rates and formats ...........................................59

SAILOR 6090 Power Converter 24—12 V ............................ 60

App. B Maritime channels

International channels (INT) ............................................. 61

US channels .....................................................................62

CA channels .....................................................................63

BI channels ......................................................................64

Glossary .........................................................................................65

Index .........................................................................................67

1

Chapter 1

1111

Introduction

Introduction 1

VHF radio with DSC Class A

SAILOR 6222 VHF DSC, your
new VHF radio with full DSC
functionality, is approved to
MED, FCC and Industry
Canada and is waterproof to
the IPx8 and IPx6 standard.
As part of the required safety
equipment, use the SAILOR
6222 VHF DSC in an
emergency situation. However
the best way to guarantee
functionality in an emergency situation, is to use the radio in daily
communication on board.

The VHF radio is a simplex/semi duplex VHF radio. It is designed with an easy­to-use menu-driven setup. You use the soft-keys and the keypad to enter the
desired functions, you browse and select a setting using the right selection
wheel knob. The large display can be customized for optimum readability and
visibility both day and night with several color themes.

The VHF radio can replay the last 240 s of received voice messages. This is a
useful feature to minimize misunderstandings and to record messages when
the radio is unattended.

With SAILOR connection boxes the VHF radio connects easily to external
equipment like additional handsets, water proof hand microphones, control
speaker microphone, alarm panel or external speaker. The Ethernet interface
enables the VHF radio to be connected to ThraneLINK for remote control and
service updates.

For a list of accessories available for the VHF radio see Accessories available
on page 4 and check with your nearest distributor.

Chapter 1: Introduction

2 VHF radio with DSC Class A

Controls on the front plate

1. Loudspeaker.

2. Four soft keys with function title in the display.

3. Large display.

4. Keys 0 to 9 to enter numbers or text.

5. DW button to toggle the watch function (dual or triple).

6. 16/C quick selection key for channel 16 and the programmed call channel.

7. Connector for Handset or Handmicrophone.

8. Distress button for sending a Distress alert.

9. Squelch control to mute background noise.

10. Volume wheel knob with key-press function for volume control and power
on/off.

11. Selector wheel knob with key-press function for general operation, display
color selection and dimming.

12. 1W button to toggle between high and low power.

13. Replay button to play back up to 240 s voice message.

5

6

7 8 9 10 11 12 13

1

2

3

4

Chapter 1: Introduction

VHF radio with DSC Class A 3

1111

Introduction

SAILOR 6222 VHF DSC display

The picture shows the display
after start-up. The display holds
various fields of information,
depending on the currently
selected function.

1. Functions you can select with

the soft keys. If there are more
than 4 functions in the list
press the soft key MORE to
display further functions.

2. Current working channel.

3. System property icons with information relevant for the currently selected

functions.

4. Channel properties next to the currently selected VHF channel (if any).

5. Service line containing current temporary information relevant for the

current channel or function.

6. Current state: RX or TX

7. DSC window with DSC information (MMSI number, position information

and UTC time of position and origin), or specific information relevant to
other functions, e.g. Replay, etc.).

For a detailed description of the information shown for each of the functions
available see the chapter Operation on page 9.

5

6

4

ALERT

RELAY

CALL

MORE

MMSI:123456789

INT

LO

DISTRESS/CALL

16

LAT: N 12°34.5678
LON:E 123°45.6789

(GPS)

22:07

RX

3

21

7

Chapter 1: Introduction

4 Accessories available

Accessories available

Accessory Description

SAILOR 6201
Handset with cradle
(additional)

One SAILOR 6201 Handset with
cradle is included in the delivery
of the SAILOR 6222 VHF DSC.
You can connect another 2
SAILOR 6201 Handsets.

SAILOR 6203
Handset with cradle

SAILOR 6203 Handset with
cradle, waterproof to IPx6.

SAILOR 6202 Hand
Microphone

You can use the SAILOR 6202
(waterproof to IPx6 and IPx8) Hand
Microphone instead of the handset.

SAILOR 6204 Control
Speaker Microphone

With the SAILOR 6204 Control
Speaker Microphone you can control
the VHF functions of the SAILOR
6222 VHF DSC.

SAILOR 6207
Connection Box for
parallel handsets

The SAILOR 6207 Connection Box
including Connection Cable 406209­941 is used for easy installation of
several SAILOR 6201/03 Handsets

Chapter 1: Introduction

Accessories available 5

1111

Introduction

SAILOR 6208 Control
Unit Connection Box

The SAILOR 6208 Connection Box
including Connection Cable 406208­941 is used for easy installation of
external equipment and accessories:

• Max. 4 SAILOR 6204 Control Speaker Microphones

•VDR

•SAILOR6270 External loudspeaker

• Alarm panels and GPS input

Connection cables 5m connection cable for bulkhead mount: Use this cable

in installations where the SAILOR 6201 or 6203 Handset
is not connected directly to the SAILOR 6222 VHF, but
located in a different position.

5m Connection cable, 1x10 pole: Use this cable in
installations when connecting external equipment to the
SAILOR 6222 VHF. This cable is included in the SAILOR
6207 Connection Box for parallel handsets.

5 m Connection cable for SAILOR 6204 Control Speaker
Microphone, 1x12 pole (part number: 406204-940)

SAILOR 6270
External
loudspeaker

If you need an additional external
loudspeaker you can connect a
SAILOR 6270 Loudspeaker. It provides
6 W output power.

SAILOR 6103 Multi
Alarm Panel

With the SAILOR 6103 Multi Alarm
Panel you can activate GMDSS Distress
Alarms. The Multi Alarm Panel can be
connected to the SAILOR 6222 VHF DSC
via the Ethernet interface (LAN
connector, ThraneLINK).

Accessory Description

Chapter 1: Introduction

6 Accessories available

SAILOR 6197
Ethernet Switch

The SAILOR 6197 Ethernet Switch
is used in installations with
SAILOR 6103 GMDSS Alarm Panels
and in installations with
ThraneLINK. The Ethernet switch
has 5 ports.

SAILOR 6090 Power
Converter 24 V to
12 V DC

The SAILOR 6090 Power Converter
is used to provide 12 V DC for the
SAILOR 6222 VHF DSC from a 24 V
DC power source.

Accessory Description

Chapter 1: Introduction

Accessories available 7

1111

Introduction

System configuration — example

The SAILOR 6222 VHF DSC can be customized to suit your installation. The
following illustration is one example of a system. For further configuration
examples see the installation manual, Appendix B, System configurations.

Speaker Microphone

Control

(NMEA)

GPS, AIS, etc.

Speaker (8 ohm)

External

SAILOR 6204

SAILOR 6201/03

Handset Option

SAILOR 6201/03

Remote Control + Service

ETHERNET port

99-128194-J

406209-940

Cable

406209-940

Cable

(without DSC)

LAN

12V DC

110/220V AC

Handset Option

Handset

SAILOR 6201/03

Handmicrophone

SAILOR 6202

Alarm

DSC Call

AUX

GPS

ACC. Port

VDR

Max 4 SAILOR 6204

Power Converter

SAILOR 6090

SAILOR 6208

Connection Box

Power

Power Supply

SAILOR N163S

SAILOR 6208

Connection Box

SAILOR 6207

Connection Box

for Parallel Handsets

406208-941

Cable

AUX. Port

CTRL. Port

406209-941

Cable

24V DC

VHF DSC

6222

Multi Alarm Panel

SAILOR 6103

12V Battery

24V DC

Aerial

RX/TX

Aerial

RX/DSC

Chapter 1: Introduction

8 Accessories available

9

Chapter 2

2222

Operation

Operation 2

Overview

In this chapter you find detailed instructions and guidelines for:

• General use and navigation

• VHF radio communication

• Watch

• Scan

• DSC calls

• Handling multiple calls — DSC and voice

• Phone book

• Replay function

• Setup

Note

Before using the VHF radio make sure that the VHF and DSC antennas,
power cable and other external equipment are connected properly. For
installation instructions see the SAILOR 6222 VHF DSC Installation manual
(download only).

Chapter 2: Operation

10 General use and navigation

General use and navigation

Power on and volume in handset and speaker

The VHF radio has a dual-function on/off wheel knob for power
on/off and volume control.

To power on the VHF radio press the on/off wheel knob.

To power off the VHF radio, press and hold the on/off wheel
knob and follow the instructions in the display.

To adjust the speaker volume, turn the volume wheel knob (clockwise =
louder, counter clockwise = softer, until muted). When muted, is shown
in the display.

To adjust the volume of the handset earpiece see Radio setup on page 39.

Working channel and changing settings

Use the selector wheel knob to browse and select:

• To browse and select settings, turn the selector wheel knob
and press for accept.

• To select a working channel use the selector wheel knob or
enter the channel number using the keypad. You can change channels
whenever the channel designator is displayed.

Note

A single, short press on the 16/C key always brings you to
channel 16, the international calling and distress channel,

no matter what state the radio is in.

Chapter 2: Operation

General use and navigation 11

2222

Operation

Speaker devices

The VHF radio can be equipped with the following speaker devices:

• SAILOR 6201/6203 Handset with cradle and PTT (Push To Talk) button.

• SAILOR 6202 Handmicrophone with PTT button.

• SAILOR 6204 Control Speaker Microphone with PTT button.

See Radio setup on page 39 for controlling the connected speaker devices.

DSC and MMSI number

The MMSI is a unique, 9-digit identifier assigned to your ship. When the VHF
radio is powered on for the first time, the vessel’s MMSI number is
programmed in the radio. This is typically done during installation of the radio
and described in the installation manual.

Important

The MMSI number must be programmed into the VHF radio to
use any DSC functionality. The radio will prompt for the MMSI
number at each power-up until the MMSI has been entered.
You can use the radio in normal VHF mode.

Caution! Without a programmed MMSI number the

Distress button will not work!

Chapter 2: Operation

12 General use and navigation

Position and MMSI number

The position and MMSI number for the SAILOR
6222 VHF DSC radio is always shown in the DSC
window (the lower half of the radio’s display)
in stand-by mode. The display shows also the
current (latest) position (if a GPS is connected),
the UTC and position type and GPS Status.

Enter position manually (no GPS)

If you need to enter the vessel’s position and UTC of position manually, do as
follows:

1. Press the soft key POS. If it is not in the display, press the soft key MORE
until POS appears. Note that POS is not available when the radio is
engaged in a session.

2. Turn and press the selector wheel knob to select the value you want to
change. Then use the keypad or press and turn the selector wheel knob to
enter the current position or UTC time.

3. Press the soft key SAVE to save the new value. The display shows (Man) in
the lower right corner.

4. After you have entered a value manually or overruled the GPS input, a soft
key UseGPS appears in the display if the GPS is available. Press this soft key
if you decide to use the data from the connected GPS.

5. Press the soft key EXIT to return to normal use.

If the GPS was present and then disappears a warning appears in the display
after 10 minutes. Follow the instructions on the screen.

CALL

ALERT

DROBOS

MORE

MMSI:123456789

INT

INTERSHIP/PORT

10

LAT: N 12°34.5678
LON:E 123°45.6789

(GPS)

22:07

Chapter 2: Operation

General use and navigation 13

2222

Operation

Soft-key functions

A number of functions of the SAILOR
6222 VHF DSC are accessed and set
using the four soft keys to the left of the
display. The current function of a soft
key is shown in the display next to the
soft key.

Use the soft key MORE to display further
soft key functions.

The following soft-key functions are available from top-level standby:

CALL

ALERT

DROBOS

MORE

MMSI:123456789

INT

DISTRESS/CALL

16

LAT: N 12°34.5678
LON:E 123°45.6789

(GPS)

22:07

Soft key Function

CALL To make DSC non-distress calls

ALERT To make a distress call with assigned category

DROBOS Make a distress relay call on behalf of someone else

POS Current position from GPS, including UTC time and MMSI

number

SCAN Scanning menu with start, stop and tag function

PHBOOK Phone book

LOCAL Local mode, 10 dB attenuation

SETUP Setup pages for Radio setup, Channel setup, Power Supply,

DSC setup, DSC call logs, System setup and Controller setup.
