Hardware Manual
Document 26/844; Version E 1 | 30.04.2006
The PCD7.D61xx series
Controls Division
Manual: PCD7.D61xx series│Document 26 / 844│Version E 1│30.04.2006
Saia-Burgess Controls Ltd. Contents
0-1
0
0 Contents
0.1 Document history ............................................................................................ 0-
2
0.2 Trademarks ..................................................................................................... 0-2
1 Introductio
n
1.1 Certificates and Directives .............................................................................. 1-
2
2 Product descriptio
n
3 Commissionin
g
3.1 Power supply .................................................................................................. 3-
1
3.2 Earthing concept ............................................................................................. 3-
2
3.3 Installation ....................................................................................................... 3-
2
3.4 Switch-on ........................................................................................................ 3-
2
4 Technical dat
a
4.1 Physical dimensions ....................................................................................... 4-
1
4.2 Electrical data ................................................................................................. 4-
5
4.3 Environmental conditions ................................................................................ 4-
5
4.4 Interfaces ........................................................................................................ 4-
6
5 Maintenance and suppor
t
5.1 Battery changing ............................................................................................. 5-
1
5.2 Replacing background lighting ........................................................................ 5-
1
5.3 Cleaning .......................................................................................................... 5-
1
5.4 Usage instructions for touch screens .............................................................. 5-
1
6 Appendi
x
6.1 Icons ............................................................................................................... 6-
1
Address of Saia-Burgess ................................................................................ 6-
2
Manual: PCD7.D61xx series│Document 26 / 844│Version E 1│30.04.2006
Saia-Burgess Controls Ltd. Contents
0-2
0
0.1 Document history
Document-no. Version Change Publication Remarks
026/844 E1 30.04.2006 Initial version
0.2 Trademarks
Saia® is a registered trademark of Saia-Burgess Electronics AG.
Microsoft, Windows 2000, Windows XP, Windows CE and the Windows logo are either
registered trademarks or trademarks of Microsoft Corporation in the USA and/or other
countries.
Technical changes are subject to the state of technology.
Saia-Burgess Controls AG, 2005. © All rights reserved
Published in Switzerland
Manual: PCD7.D61xx series│Document 26 / 844│Version E 1│30.04.2006
Saia-Burgess Controls Ltd. Introduction
1-1
1
1 Introduction
Please read the manual before you use the controls for the first time, and keep it in a
safe place for later use.
Target group
This manual is written for users with prior knowledge of PC and automation
technology.
Conventions used
[KEY] Keystrokes entered by the user are shown in square brackets,
e.g. [CTRL] or [DEL]
Courier Screen output is shown in Courier font, e.g. C:\>
Courier Bold Keyboard input by the user is shown in
Courier Bold font, e.g. C:\>DIR
Italics Names of buttons, menus or other screen elements to be
selected, and product names, are given in italics.
Safety instructions
Wherever hazardous faults could occur in the automation system, i.e. a fault could
cause major damage to materials or people, additional external precautions must be
taken or devices installed (e.g. independent limit switches, mechanical locks etc.), to
assure/force a safe operating state in the event of a fault.
The user is responsible for checking suitability for the intended purpose, or for use
under the specified conditions. Saia-Burgess Controls AG offers no guarantee in this
area.
Qualified staff
The unit described here may only be set up and operated in conjunction with this
document. A device may only be commissioned and operated by qualified staff.
Qualified staff in the meaning of the safety instructions in this documentation are
people authorised to commission, ground and label devices, systems and electric
circuits according to the standards of the security policy.
Manual: PCD7.D61xx series│Document 26 / 844│Version E 1│30.04.2006
Saia-Burgess Controls Ltd.
Certifi cates and Directives
Introduction
1-2
1
Proper use
The device may only be used for the scenarios specified in the catalogue and the
technical description, and only in conjunction with third-party devices recommended
or approved by Saia-Burgess Controls AG. Trouble-free and safe operation of the
device depends on appropriate transport, storage, setup and assembly, as well as
careful operation and maintenance.
1.1 Certificates and Directives
The following apply to the product described in this documentation:
EMC Directive
DC power supply
Devices with DC power supply meet the requirements of EC Directive 89/336/EEC
on electromagnetic compatibility and are suitable for use in the following area in
accordance with their CE marking:
Area of use Requirement for
Noise emission Resistance to interference
Industry EN 61000-6-4: 2001 EN 61000-6-2: 2001
Declaration of Conformity
The EC Declarations of Conformity and associated documentation can be provided
to the competent authorities in accordance with the above EC Directive. Your sales
representative can supply copies on request.
Assembly guidelines
Observe the assembly guidelines and safety instructions given in this documentation
when commissioning and operating the devices.
Manual: PCD7.D61xx series│Document 26 / 844│Version E 1│30.04.2006
Saia-Burgess Controls Ltd. Product description
2-1
2
2 Product description
The series comprises the PCD7.D6120TV010 and PCD7.D6150TV010 models.
User side
Colour TFT display with resistive touch
(PCD7.D6120TV010 and PCD7.D6150TV010)
Slot side
COM1/COM2 LAN1/LAN2
VGA Earth screw
PS2 mouse/keyboard Power supply
USB1/USB2 Compact flash (external)
