Sagem my401V User Manual

User Guide

English

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (GSM 900 MHz and DCS 1800 MHz or PCS 1900 MHz) depending on the roaming arrangements with your network provider. We remind you that this phone is approved to meet European standards.

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Ensure that your SIM card is a 3 V SIM type t hat is compatible with your phone. Inserting an incompatible card will be indicated

by a message when your phone is switched on. Contact Vodafone. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card.

In order to display the IMEI on your phone's screen, type: *#06#.

SAGEM™ is a trademark of Sagem Communication SAFRAN Group. AT® is a registered trademark of Hayes Microcomputer Products Inc. Hayes® is a registered trademark of Hayes Microcomputer Products Inc. T9 is protected by one or more of the following US patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for worldwide. Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares. © 2003 GAMELOFT® - All rights reserved - GAMELOFT® is a registered trademark of GAMELOFT S.A. - All rights reserved. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France. The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.

Menus ........................................................... 6

Your phone package - Accessories........... 7

Description .................................................. 8

Navigation principles ................................ 10

Initial screen .............................................. 11

Activating your phone .............................. 12

Information on the Vodafone SIM card .................12

First use: installing your Vodafone SIM card and the

battery................................................................... 13

Removing the back cover ..................................... 13

Getting started ......................................................14

PIN number........................................................... 14

Setting time and date ............................................ 15

Network................................................................. 15

First call................................................................. 15

Receiving a call..................................................... 16

Switching off.......................................................... 16

Using your phone...................................... 17

Freeing the antenna.............................................. 17

Increase the efficiency of your phone ...................17

Charging the battery ............................................. 18

Contacts ..................................................... 19

Using the phonebook ............................................ 19

Storing a new contact ........................................... 19

Speed Dialing........................................................ 20

Calling a contact ...................................................20

4 Contents

Displaying a contact.............................................. 20

Contacts options................................................... 20

Groups ..................................................................22

Messaging.................................................. 23

Creating a message.............................................. 23

MMS postcard....................................................... 25

Receiving messages............................................. 26

Inbox .....................................................................26

Drafts .................................................................... 26

Sent Messages ..................................................... 27

Outbox ..................................................................27

Messenger............................................................ 27

Voicemail ..............................................................28

Templates............................................................. 28

Live! Studio........................................................... 28

Settings................................................................. 28

Local information................................................... 29

Groups ..................................................................29

Memory................................................................. 29

Camera ....................................................... 30

Taking and saving a photo.................................... 30

Taking a video....................................................... 31

My Files ...................................................... 32

Pictures................................................................. 32

Sounds.................................................................. 33

Videos ................................................................... 33

Exchanging objects with a PC and your phone .... 33

Vodafone live!............................................ 34

Games and applications ........................... 35

Organiser ................................................... 36

Alarm .....................................................................36

Timer .....................................................................36

Calendar................................................................36

Calculator and converter .......................................37

Todo ......................................................................38

Music player ..........................................................39

Settings ...................................................... 40

Phone ....................................................................40

Display...................................................................42

Messaging............................................................. 43

Connectivity........................................................... 43

Bluetooth ...............................................................44

Calls.......................................................................45

Networks................................................................46

Security..................................................................47

Player settings.......................................................49

Browser .................................................................49

Camera..................................................................49

Video .....................................................................49

End User Licence Agreement (EULA), for

the software ............................................... 58

Java™......................................................... 62

Troubleshooting ........................................ 66

Index........................................................... 69

Technical features..................................... 50

Care and safety information..................... 52

SAR .......................................................................52

Advice for limiting exposure to radiofrequency (RF)

fields ......................................................................52

Safety ....................................................................53

Environment ..........................................................54

Warranty..................................................... 55

Contents 5

Menus

Entertainment

Vodafone live!

Vodafone live! Enter URL Bookmarks History Settings Vodafone Mail What’s New? Live! Studio More Games More Sounds More Pictures News Sport

Organiser

Alarm Applications Timer Calendar Calculator Todo Vodafone Services Music player

(*) Service depending on the operator

6 Menus

Camera

Messaging

Create new Inbox Drafts Sent Messages Outbox Messenger (*) Vodafone Mail Voicemail Templates Live! Studio (*) Settings Local info Groups Memory

My Files

Pictures Sounds Videos

Call Log

Contacts

Settings

Phone Display Messaging Connectivity Calls Networks Security Player settings Browser Camera Video Help

Your phone package - Accessories

When you open the box, check that all items are present:

1 - Phone 2 - Charger 3 - Battery 4 - User guide

Accessories

We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories. You can also find (as an option) or order the following accessories:

- Pedestrian kit

- Bluetooth pedestrian kit

- Additional battery

- Additional charger

- USB cable (with associated drivers) to connect your phone to a PC

- Cigar lighter charger

- Wellphone CD

Note:

The front and back covers are not interchangeable.

Your phone package - Accessories 7

Description

Hold down: Switch on/off

In a call context: Reject a call - hang up In menus: Return to initial screen

Short

press: Activate/Deactivate hands-free mode (

do not bring the phone up to your ear) In dialling/phonebook/call log context: Call - receiving a call

Right key:

In initial screen: Access to Vodafone live! (shortcuts) In menus: Access to the selection shown on screen in the tab (*)

Left key:

In initial screen: Access to the main menu (shortcuts) In menus: Access to the selection shown on screen in the tab (*)

The four-directional navigation stick allows you to:

- Move the cursor on the screen by pushing the stick toward the

corresponding direction

- Confirm your selection by pressing the stick

- In initial screen:

• leftwards/rightwards: open

• downwards/upwards: open

Note:

in this manual, "press OK" means press the central key.

Press briefly and [OK]: activate or deactivate keypad locking

When composing a message:

Short press: switches from one editing mode to another (upper case/lower case, 123 mode) Long press: activate/deactivate T9 mode Hold down

: In idle screen: Silent mode

In call reception mode: Short press stops ring tone In ring tone setting mode: Activate/deactivate ring tone. Stops sound in video

or message playing, or in a game

2 to 9

Long press: access to Speed Dialing

(*) In this manual, when a function is chosen by pressing on this key, square brackets are used (e.g.: [

8 Description

Create new/My Files

Contacts/Vodafone live!

WARNING:

Save

in this mode

]).

Short press: Access to Camera menu

Camera

Mirror

IrDA (Infrared)

Description 9

Navigation principles

These basic principles bring a great intuitiveness to your phone.

Vali date

by pressing the key or the navigation stick.

Cancel

by pressing the key. The thumbnails at the bottom of the screen refer to the In the menus, a title bar reminds you of the previous level. From the home page, pressing the navigation stick displays the icons of the main menus. When pressing the navigation stick followed by a figure, you can display a menu directly. For instance, pressing the navigation

stick then

displays the Phonebook.

The

key is used to go from a menu to a sub-menu. The key is used to go from a sub-menu to a menu. The

key (press briefly) is used to go back to the initial screen (current function is abandoned).

In some menus there is a Help menu ( icon) which informs you on the various functions of the sub-menus.

10 Navigation principles

keys.

Initial screen

Vod afo ne

Initial screen 11

The initial screen contains the following information:

1 - The title bar icons:

Battery Calls forwarded Call (establishing the call) Call (hands free) Message (reception of a message, message memory full) FAX communication DATA communication Silent mode Message in answering machine WAP (@) communication GPRS Home zone Roaming

Only emergency call is possible

Keypad locking Protected WAP logon Protected WAP logon icon with certificate Signal strength level (5 bars).

2 - Network provider 3 - Date and time, in digital or analog mode 4 - Symbols and thumbnail centred on bottom line:

The main thumbnail shows that the menu can be accessed via the navigation stick

- : Short access to the main menu - : Short access to

- Information messages on calls, messages or network messages received

may also be displayed. They can be deleted by pressing key briefly.

Vodafone live!

Activating your phone

Information on the Vodafone SIM card

To use your phone, you need Vodafone SIM card. It contains personal information that you can modify:

- Secret codes (PIN(s): Personal Identification Numbers), these codes allow

you to protect access to your SIM card and phone

- Phonebook

- Messages

- How special services work.

Your phone is compatible with the SIM 3V cards.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact Vodafone immediately. Please keep your SIM card out of reach of young children.

12 Activating your phone

First use: installing your Vodafone SIM card and the battery

123

Slide the SIM card, with cut corner as shown on the phone, into the card holder

with fold face down.

Place the battery by positioning first the top of it, as shown on the battery.

Place the back cover, clicking in first the upper part then the lower.

Removing the back cover

Proceed as follows to remove the back cover (in case of replacement of the battery or the SIM card, for instance):

- Turn the phone back. Press on the centre part at the level of the notch (1) and lift the cover (2).

Activating your phone 13

Getting started

You are now ready to use your phone for the first time.

Switch on the phone by pressing the key. A short display appears. When you switch on your phone for the first time, you must configure it with various settings that will remain by default until

you choose to modify them (depending on model). After entering your PIN code, the phone activates the Vodafone settings and switches on again ; enter your PIN code again then the date and time, make your choice for the following settings: time zone, daylight savings, skin, wallpaper, screensaver,

ring tone, volume, vibrate and voicemail number. If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

PIN number

This is your SIM's secret code.

If access to the Vodafone SIM card is protected, the device prompts you to enter the PIN number: Enter the code for security reasons. Press [ If your phone indicates that the SIM is missing, press the key to switch off your phone and check that the SIM card is

correctly installed.

14 Activating your phone

between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen

] or the navigation stick to validate.

WARNING

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code provided by your operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the Vodafone SIM card is definitely locked. You must then contact your operator or your SMC to obtain a new card.

Setting time and date

When you use your phone for the first time, you need to set the date and time. In due course, when the battery is completely discharged, or if it has been removed, you will be prompted systematically to confirm date and time.

Setting the date

Set the date by entering it directly in numerical form or by using the navigation stick to increase or decrease the default values. Use the navigation stick to access the next (or last) data input field. Once the date is correct, press the key to validate.

Setting the time

Same procedure as for setting the date.

Network

From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on the screen. You are then ready to send or receive a call.

If the network icon appears, calls are possible on your operator's network. If the the icon and a network name are displayed, calls are possible on the network of a different operator. If the the icon is displayed without any network name, only the emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

First call

Dial the number of your correspondent. Press the key. During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call. Once communication has been established, the call icon stops flashing. You can adjust the sound level (volume) using the At the end of the conversation press the key to hang up.

Activating your phone 15

navigation stick.

Calling voicemail

In the initial screen, press and hold down the 1key.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the operators you can obtain the emergency service with or without SIM card or when the keypad is locked. It is enough to be in an area served by a network. To obtain the international emergency service, dial

112

then press the key.

Receiving a call

When you receive a call, the number of your correspondent is displayed when it is presented by the network. Press the key or the key to answer, and speak. To refuse the call, press the key or the key. To stop the ring tone or the vibrate, without refusing the call, press the key.

Hands-free mode

During a call, press the key and validate pressingOK (or ) or pressOK twice to switch into hands-free mode.

WARNING:

in this mode do not bring the phone up to your ear.

All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.

When a call is on hand, pressing [ holding a call, switching to mute mode, ending the call, displaying menus.

Secret mode ON

Pressing [ listens when you want to speak to other people.

Options

] allows you to have access to different functions: switching to hands-free mode,

] allows you to switch off the sound temporarily when you do not want that your correspondent

Switching off

Press the key (long press). The end message is displayed. The phone switches off.

16 Activating your phone

Using your phone

Freeing the antenna

The antenna is integrated in your phone, under the back cover at the top. Avoid putting your fingers on this area when the phone is switched ON. If your fingers obstruct the antenna, the phone may have to operate with a higher power level than usual; decreasing its efficiency quickly. It could also affect the

quality of your communications.

Non ionising radiation

To obtain maximum satisfaction from your phone, use it in a vertical position. Your personal safety can only be improved by doing so.

Increase the efficiency of your phone

- Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.

- Don't obstruct the antenna with your fingers.

- Activation of IrDA or Bluetooth functions reduces the phone battery life. We advise you to deactivate them when not in use.

Using your phone 17

Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time. It reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the phone displays the state (empty battery icon flashes). In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off in the middle of a call.

To recharge the battery:

Connect the charger to a socket. Plug the end of the cable into the side connector of the phone. The phone is then charging up. The battery icon is scrolling up and down to

indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable. When charging, the battery may warm up, this phenomenon is normal.

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc). If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on after a few minutes of charge. You can use the phone again when the Start option is displayed on the screen.

18 Using your phone

Contacts

The phonebook allows you to store numbers that you call regularly. These numbers can be stored in the SIM card or in the phone.

To store a contact in the phone memory, the following fields can be filled: last name, first name, numbers, emails, URL, numbers, address, company, birthday, comments, ringtone, photo. To store a contact in the SIM card, only the last name and number fields must be filled.

Using the phonebook

Display the

Contacts

The location where the contact is stored (SIM card or phone) is indicated by the icon at the top of the screen when the cursor is located on a contact.

Storing a new contact

There are two ways to store a contact:

1) by selecting

Contacts/Add contact/Telephone

- Then enter the last name and press OK.

- Enter the number and press

- Press [

Contacts 19

menu. The list of your contacts appears.

contact stored in the SIM card

contact stored in the phone

contact stored in the Fixed Dialling. See activation.

Contacts/[Options

Save

] to store it.

] or OK, then

SIM card

PIN2 number

Add phone contact

and

Fixed dialling

Add SIM contact

page 47 for more details about this

Speed Dialing

You can assign a short number to a contact (from 2 to 9).

- From the idle screen, make a long press on the short number selected.

- The Speed Dialing function is displayed.

- Enter the phone number of your contact or press the [

- Press [

] to confirm.

Contacts

] key to select a contact already saved.

Calling a contact

Several ways:

- Select a contact. Press the key to start the call.

- Select a contact, press

- Direct call from the idle screen (only for the contacts stored in the SIM card memory): type the number with which the

contact was saved then (example : 21 ) or the number then , the number is displayed, confirm.

, his number is displayed, press [

Call

] to start the call.

Displaying a contact

Select a contact from the list and press OK. The name, the phone number and the order number with which the contact is stored are displayed.

Note:

By directly pressing three characters, the phone will display the first contact saved in the phonebook, starting with it.

To display the different options, select a contact from the list and press [

Options

Contacts options

To display the various options, select a contact and press [

Edit contact

Modify what you want and validate then select

Send message

To send a SMS or a postcard to a contact (see chapter

Send By

To send a contact details by message, IrDA or Bluetooth (see chapters

20 Contacts

Options

Save

once the modifications completed.

Messaging

and

Connectivity

Add Speed-Dialing

You can assign one of the numbers proposed to the contact selected (see

Speed Dialing

on page 20).

Copy one to SIM/Copy to phone

This allows you to copy your phonebook contacts from one memory to the other. Only the name and the first phone number will be copied.

My numbers

You can create the entries corresponding to your own numbers in order to consult them when necessary. Enter the different details and validate.

Memory

Select

Memory

Telephone

various other features. If you lack memory, check if you can free some space from another feature.

SIM

and validate. Select

: the screen displays the amount of memory used. The memory capacity is shared between the phonebook and

: available memory only for contacts.

SIM

Telephone

and validate.

Delete/Delete all

This allows you to delete the contact selected or all the contacts.

Set as my card/Business card

The details of a contact stored in the phone memory can be saved in a business card.

- Select a contact and press [

- Select

Set as my card

SMS, MMS or IrDA.

Options

and [OK]. The details are saved as

Business card

. Then you can read it, modify it or send it by

Copy all to phone/Copy all to SIM

This allows you to copy all the SIM card contacts to the phone memory and vice versa.

Contacts 21

Synchronize

You can synchronize your phonebook with your archives stored in Vodafone’s network depending on the options offered by your subscription.

The local synchronisation with your computer is only computer originated, from Wellphone software; you have only to activate infrared, Bluetooth, or configure your USB connection in your phone.

Contacts synchronisation with a computer

Install Wellphone, software provided on CD, and click on DIRECTSYNC: you can synchronise your contacts stored in the phone memory with those of your Lotus Notes™ or Microsoft Outlook™ bases

Add to mailing list

This menu allows you to add a contact to a mailing list.

Settings

List choice:

phone switches on.

Filter criteria:

this menu allows you to select the default phonebook (SIM, Phone, SIM and Phone) displayed when the

this menu allows you to select the way to sort contacts in the phonebook (by name or first name).

Groups

A group allows you to send a same message to several recipients at the same time.

- In the phonebook, select the

Options

- Press [

- Select

- Enter a name and press OK.

- Then, on a list press [

22 Contacts

Add group

Options

Groups

]. Select

tab.

Add contact

each time you want to add a contact in the list.
