Sagem MY401L User Manual
ENGLISH
You have just purchased a SAGEM phone. We congratulate you! In order to use your phone efficiently and safely, we
recommend that you read this handbook carefully.
Your phone can be used internationally in the various networks ((GSM 850 MHz and PCS 1900 MHz) or (GSM 900 MHz,
DCS 1800 MHz or PCS 1900 MHz)) depending on the roaming arrangements with your operator.
Some services described in this guide may not be available from the network or when roaming, or may require a specific
subscription.
Remember to back up your data and programs frequently, and before sending the mobile phone for repair.
This phone, like any other wireless phone, operates using radio signals and networks. Connection in all locations and
conditions cannot be guaranteed. Therefore you should never rely solely on any wireless phone for essential communications
(for example, medical emergencies).
In some jurisdictions it may be unlawful to take a picture without notice to or the consent of all participants.
WARNING
Depending on the model, network configuration and associated subscription cards, certain functions may not be available.
Ensure that your SIM card is a 3 V SIM type that is compatible with your phone. Inserting an incompatible card will be
indicated by a message when your phone is switched on. Contact your operator.
Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may
be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card.
In order to display the IMEI on your phone's screen, type: *#06#.
SAGEM™ is a trademark of Sagem Communication SAFRAN Group.
AT® is a registered trademark of Hayes Microcomputer Products Inc.
Hayes® is a registered trademark of Hayes Microcomputer Products Inc.
T9 is protected by one or more of the following US patents: 5,818,437,
5,953,541, 5,187,480, 5,945,928, 6,011,554 and other patents are being applied for worldwide.
Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the
U.S. and other countries.
The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to
modify, translate, disassemble or even decompile all or part of these softwares.
© 2003 GAMELOFT® - All rights reserved - GAMELOFT® is a registered trademark of GAMELOFT S.A. - All rights reserved.
Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc.
3
Contents
Menus ........................................................... 6
Your phone package - Accessories........... 7
Description .................................................. 8
Navigation principles ................................ 10
Initial screen .............................................. 11
Activating your phone .............................. 12
Information on the SIM card .........................12
First use: installing the SIM card and
the battery.....................................................13
Removing the back cover .............................13
Getting started ..............................................14
PIN number................................................... 14
Setting time and date....................................15
Network......................................................... 15
First call ........................................................15
Receiving a call............................................. 16
Switching off .................................................16
Using your phone...................................... 17
Freeing the antenna...................................... 17
Increase the efficiency of your phone ........... 17
Charging the battery .....................................18
Phonebook................................................. 19
Using the phonebook.................................... 19
Storing a new contact ...................................19
Calling a contact ...........................................19
Contact options.............................................20
4 Contents
Messages ................................................... 22
Compose SMS ............................................. 22
Compose MMS............................................. 24
Receiving messages .................................... 25
Inbox............................................................. 26
Outbox .......................................................... 26
Sentbox ........................................................ 26
Drafts............................................................ 26
Templates..................................................... 26
Options .........................................................27
Memory......................................................... 27
Local information .......................................... 27
Calling Voice Mail ......................................... 28
Mailing list..................................................... 28
Camera ....................................................... 29
Taking and saving a photo ........................... 29
Taking a video .............................................. 31
Multimedia.................................................. 32
My Videos..................................................... 32
My Pictures................................................... 33
My Sounds.................................................... 33
Memory......................................................... 34
WAP ............................................................ 35
The WAP Menu ............................................ 35
Configuring WAP parameters....................... 36
WAP Logging on........................................... 37
Downloading objects .................................... 37
WAP Logging off........................................... 37
GPRS ........................................................... 37
Games ........................................................ 38
Applications............................................... 39
Organizer ......................................................39
Calculator...................................................... 40
Converter ......................................................41
Alarm.............................................................41
Timer............................................................. 41
ToDo .............................................................42
Services ........................................................43
Settings ...................................................... 44
Sounds.......................................................... 44
Display ..........................................................45
Camera .........................................................47
Languages ....................................................47
Contacts........................................................ 47
Calls ..............................................................48
Security .........................................................50
Networks .......................................................52
Shortcuts....................................................... 53
Date / Time ...................................................53
WAP settings ................................................54
Help...............................................................54
Connectivity............................................... 55
Bluetooth (depending on model)................... 55
IrDA (depending on model)........................... 55
Serial Speed .................................................56
Car kit - Headset ...........................................56
SyncML (depending on model) .....................56
Certification and safety information for the
United States and countries using FCC
standards ................................................... 58
FCC Part 15 statement ................................. 58
FCC SAR information ................................... 59
Safety Information ........................................ 60
Distance of operation.................................... 61
FDA consumer information on wireless
phones.......................................................... 61
Driving safety tips .........................................64
Certification and safety information for
Europe and countries using CE
standards ................................................... 65
CE conformance statement ..........................65
CE SAR information ..................................... 67
Safety information......................................... 68
Distance of operation.................................... 69
CE Environment ........................................... 69
For Customers in the United States ........ 70
Limited Warranty .......................................... 71
For customers outside the United States 74
Warranty ....................................................... 74
End User Licence Agreement (EULA), for
the software ............................................... 77
Java™......................................................... 81
Troubleshooting ........................................ 86
Index........................................................... 90
Technical features..................................... 57
Contents 5
Menus
Games
WAP
Applications
Organizer
Calculator
Converter
Alarm
Timer
ToDo
Services (Operatordependent service)
Messages
Compose
Inbox
Outbox
Sentbox
Drafts
Templates
6 Menus
Options
Memory
Local info.
Call Voice Mail
Mailing list
Camera
Video
Multimedia
My Videos
My Pictures
My Sounds
Memory
Help
Connectivity
Bluetooth (depending
on model)
IrDA (depending on
model)
Serial Speed
Car kit
Headset
SyncML (depending
on model)
Phonebook
Settings
Sounds
Display
Camera
Languages
Contacts
Calls
Security
Networks
Shortcuts
Date/Time
WAP settings
Help
Your phone package - Accessories
When you open the box, check that all items are present:
1 - Phone
2 - Charger
3 - Battery
4 - User guide
1
Accessories
We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories. You
can also find (as an option) or order the following accessories:
- Pedestrian kit
- Bluetooth pedestrian kit (depending on model)
- Additional battery
- Additional charger
- USB cable (with associated drivers) to connect your phone to a PC
- Cigar lighter charger
- Wellphone CD (depending on model)
Note:
The front and back covers are not interchangeable.
For more information: www.planetsagem.com
Your phone package - Accessories 7
and www.sagem.com/mobiles.
2
4
3
Description
Hold down: Switch on/off
In a call context: Reject a call - hang up
In menus: Return to initial screen
press: Activate/Deactivate hands-free mode (
Short
not bring the phone up to your ear (at least 3.9 inches (10 cm))
In call context: Call - receiving a call
Right programmable key:
In initial screen:
In menus: Access to the selection shown on screen in the tab (*)
Left programmable key:
In initial screen:
In menus: Access to the selection shown on screen in the tab (*)
The four-directional navigation stick allows you to:
- Move the cursor on the screen by pushing the stick toward the
corresponding direction
- Confirm your selection by pressing the stick
- In initial screen: depending on model, long press leftwards/rightwards:
access to Phonebook
Press briefly and [OK]: activate or deactivate keypad locking
When composing a message:
Short press: switches from one input mode to another (T9, ABC, 123)
Long press: upper case/lower case
Hold down
In call reception mode: Short press stops ring tone
In ring tone setting mode: Activate / deactivate ring tone
Zoom mode (see
2 to 9
A long press on the keys 2 to 9 directly displays the phonebook.
(*) In this manual, when a function is chosen by pressing on this key, square brackets are
used (e.g.: [
Access to certain functions (shortcuts)
Access to certain functions (shortcuts)
: In initial screen: Silent mode
Messages
and
Save
]).
WAP
menus)
8 Description
WARNING:
in this mode do
Short press: access to photo viewfinder
A second short press takes the photo
(depending on model)
Camera
Mirror
IrDA (Infrared)
(depending on model)
Description 9
Navigation principles
These basic principles bring a great intuitiveness to your phone.
Vali date
by pressing the key or the navigation stick.
Cancel
by pressing the key.
The thumbnails at the bottom of the screen refer to the
In the menus, a title bar reminds you of the previous level.
From the home page, pressing the navigation stick displays the icons of the main menus.
When pressing the navigation stick followed by a figure, you can display a menu directly. For instance, pressing the navigation
stick then
8
displays the Phonebook.
The
key is used to go from a menu to a sub-menu.
The key is used to go from a sub-menu to a menu.
The key (press briefly) is used to go back to the initial screen (current function is abandoned).
In some menus there is a
10 Navigation principles
Help
menu ( icon) which informs you on the various functions of the sub-menus.
keys.
Initial screen
The initial screen may contain the following information:
1 - The title bar icons:
2 - Date and time, in digital or analog mode
3 - Network provider
4 - Thumbnail centred on bottom line:
The main "Menu" thumbnail shows that the menu can be accessed by pressing the navigation stick. The following information
may also be displayed: "1 message received" or "1 call".
It can be deleted by pressing key briefly.
Initial screen 11
Battery
Calls forwarded
Call (establishing the call)
Call (hands free)
Message (reception of a message, message memory full)
FAX communication
DATA communication
Silent mode
Message in answering machine
WAP (@) communication
GPRS
Home zone
Roaming
Only emergency call is possible
Keypad locking
Protected WAP logon
Protected WAP logon icon with certificate
Signal strength level (5 bars).
Activating your phone
Information on the SIM card
To use your phone, you need a card called SIM card. It contains personal
information that you can modify:
- Secret codes (PIN(s): Personal Identification Numbers), these codes allow
you to protect access to your SIM card and phone
- Phonebook
- Messages
- How special services work.
Your phone is compatible with the SIM 3V cards.
WARNING
This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact
your network provider or your SMC (Services Marketing Company) immediately.
Please keep your SIM card out of reach of young children.
12 Activating your phone
First use: installing the SIM card and the battery
123
Slide the SIM card, with cut corner as shown on the phone, into the card holder
1
with fold face down.
Place the battery by positioning first the top of it, as shown on the battery.
Place the back cover, clicking in first the upper part then the lower.
2
3
Removing the back cover
Proceed as follows to remove the back cover (in case of replacement of the battery or the SIM card, for instance):
- Turn the phone back. Press on the centre part at the level of the notch (1) and lift the cover (2).
Activating your phone 13
Getting started
You are now ready to use your phone for the first time.
Switch on the phone by pressing the key. A short display appears.
When you switch on your phone for the first time, you must configure it with various settings that will remain by default until
you choose to modify them (depending on model).
After entering your PIN code and the date and time, make your choice for the following settings: time zone, daylight savings,
skin, wallpaper, screensaver, ring tone, volume, vibrate and voicemail number.
If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.
PIN number
This is your SIM's secret code.
If access to the SIM card is protected, the device prompts you to enter the PIN number:
Enter the code
for security reasons.
Press [
If your phone indicates that the SIM is missing, press the key to switch off your phone and check that the SIM card is
correctly installed.
14 Activating your phone
between 4 and 8 digits given to you when the SIM card was issued. These digits do not appear on the screen
OK
] or the navigation stick to validate.
WARNING
If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:
- Enter the PUK (Personal Unblocking Key) code provided by your operator, and validate.
- Enter your PIN number and validate.
- Enter your PIN number again and validate.
After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then
contact your operator or your SMC to obtain a new card.
Setting time and date
When you use your phone for the first time, you need to set the date and time.
In due course, when the battery is completely discharged, or if it has been removed, you will be prompted systematically to
confirm date and time.
Setting the date:
Set the date by entering it directly in numerical form or by using the navigation stick to increase or decrease the default values.
Use the navigation stick to access the next (or last) data input field.
Once the date is correct, press the key to validate.
Setting the time:
Same procedure as for setting the date.
Network
From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on
the screen. You are then ready to send or receive a call.
If the network icon appears, calls are possible on your operator's network.
If the letter R and a network name are displayed, calls are possible on the network of a different operator.
If the letter E is displayed without any network name, only the emergency services are accessible (ambulance, police,
fire brigade).
If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength
indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better
reception in order to call in good conditions.
First call
Dial the number of your correspondent.
Press the key.
During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call.
Once communication has been established, the call icon stops flashing.
You can adjust the sound level (volume) using the
At the end of the conversation press the key to hang up.
Activating your phone 15
navigation stick.
Calling voicemail
In the initial screen, press and hold down the 1key.
International call
Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the
called party.
Emergency services
Depending on the operators you can obtain the emergency service with or without SIM card or when the keypad is
locked. It is enough to be in an area served by a network.
To obtain the international emergency service, dial
112
then press the key.
Receiving a call
When you receive a call, the number of your correspondent is displayed when it is presented by the network.
Press the key or the key to answer, and speak.
To refuse the call, press the key or the key.
To stop the ring tone or the vibrate, without refusing the call, press the key.
Hands-free mode
To change to hands-free mode during a call, make a short press on the key then press [
of the amplified mode.
WARNING:
in this mode do not bring the phone up to your ear.
All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.
When a call is on hand, pressing [
holding a call, switching to mute mode, ending the call, displaying menus.
Pressing [
Mute ON
you want to speak to other people.
] allows you to switch off the sound temporar ily when you do not want that your correspondent listens when
Options
] allows you to have access to different functions: switching to hands-free mode,
Yes
] to confirm activation
Switching off
Press the key (long press).
The end message is displayed. The phone switches off.
16 Activating your phone
Using your phone
Freeing the antenna
The antenna is integrated in your phone, under the back cover at the top.
Avoid putting your fingers on this area when the phone is switched ON.
If your fingers obstruct the antenna, the phone may have to operate with a higher
power level than usual; decreasing its efficiency quickly. It could also affect the
quality of your communications.
Non ionising radiation
To obtain maximum satisfaction from your phone, use it in a vertical position.
Your personal safety can only be improved by doing so.
Increase the efficiency of your phone
- Don't press the keys when not necessary: each keypress activates the backlight, and uses much power.
- Don't obstruct the antenna with your fingers.
Using your phone 17
Charging the battery
Your phone is powered by a rechargeable battery. A new battery must be
charged for 4 hours at least before being used for the first time. It reaches its
optimum capacity after a few cycles of use.
When your battery has been discharged, the phone displays the state (empty
battery icon flashes). In this case recharge your battery for at least 15 minutes
before making any calls in order not to be cut off in the middle of a call.
To recharge the battery:
Connect the charger to a socket.
Plug the end of the cable into the side connector of the phone.
The phone is then charging up. The battery icon is scrolling up and down to
indicate that it is charging. When the battery is fully charged, the charging stops
on its own. Disconnect the cable.
When charging, the battery may warm up, this phenomenon is normal.
WARNING
There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire.
Do not short circuit it.
The battery does not have any part that you can change.
Do not try to open the battery casing.
Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue.
The use of other types of chargers or batteries may be dangerous or invalidate the warranty.
Used batteries must be disposed of in the appropriate places.
We advise you to take the battery out if you plan not to use the phone for extended periods.
You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery.
The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power
supply plug, etc).
If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on
after a few minutes of charge. You can use the phone again when the Start option is displayed on the screen.
18 Using your phone
Phonebook
Using the phonebook
Enter the
Phonebook
When a contact is selected, an icon is displayed in the title bar:
contact stored in the SIM card
contact stored in the phone
contact stored in the Fixed Dialling. See
activation.
You can search for a contact quiclky by typing the first letters (up to three). You can display it by pressing OK.
menu, the contacts list is displayed if you already get some (otherwise, go to
PIN2 number
and
Fixed dialling
in
Security
Storing a new contact
- Display the Phonebook, press [
- Enter the last name and press the navigator.
- Enter the number and press the navigator (
Note:
you can fill other fields if you store the contact in the phone memory (email, address, ringtone, photo, etc.).
- Press [
Save
] to store it.
Options
] then select
OK
).
Add phone contact
or
Add SIM contact
Calling a contact
Several ways:
- Select a contact. Press to start the call.
- Select a contact, press OK, his number is displayed, press [
- Direct call from the idle screen (only for the contacts stored in the SIM card memory): type the number with which the
contact was saved then
Phonebook 19
∗
(example : 21∗) or the number then #, the number is displayed, confirm.
Call
] to start the call.
Storing a new contact
Menu for more details about this
.
).
Contact options
To display the various options, select a contact and press [
Modifying a contact
Modify what you want and validate then select
Sending a message
To send a SMS or a MMS to a contact (see chapter
Sending by
To send a contact details by MMS, SMS, IrDA (depending on model) or Bluetooth (depending on model) (see chapters
Messages
and
Connectivity
).
Copy to SIM/Copy to mobile
This allows you to copy your phonebook contacts from one memory to the other. Only the name and the first phone number
will be copied.
My numbers
You can create the entries corresponding to your own numbers in order to consult them when necessary.
Select
My numbers
and validate. Enter the different details and validate.
Mailing lists
A mailing list allows you to send a same message to several recipients at the same time.
Mailing Lists
- Select
- Select the list type (SMS or MMS) and press the navigation stick.
- Enter a name and press the navigation stick.
- Then, on a list press [
20 Phonebook
and press the navigation stick. The phone asks you to confirm the creation of a new list.
Options
]. Select
Add contact
Options
].
Save
once the modifications completed.
Messages
).
each time you want to add a contact in the list.
Memory
Select
SIM
or
Telephone
Telephone: the screen displays the amount of memory used. The memory capacity is shared between the phonebook and
various other features. If you lack memory, check if you can free some space.
SIM: available memory only for contacts.
and validate.
Delete/Delete all
This allows you to delet the contact selected or all the contacts.
Set as my card/Business card
The details of a contact stored in the phone memory can be saved in a business card.
- Select a contact and press [
- Select
Set as my card
SMS, MMS or IrDA (depending on model).
Options
and [OK]. The details are saved as
].
Business card
. Then you can read it, modify it or send it by
Synchronize (depending on model)
You can synchronize your phonebook with your archives stored in your operator’s network depending on the options offered
by your operator.
The local synchronisation with your computer is only computer originated, from Wellphone software; you have only to activate
infrared, Bluetooth, or configure your USB connection in your phone.
Contacts synchronisation with a computer (depending on model)
Install Wellphone, software provided on CD (depending on model), and click on DIRECTSYNC: you can synchronise your
contacts stored in the phone memory with those of your Lotus Notes™ or Microsoft Outlook™ bases
.
List choice
This menu allows you to select the default phonebook (phone, SIM and Phone or SIM) displayed when the phone switches on.
Phonebook 21
Messages
From this menu, you are able to send SMS and MMS. MMS is a Multimedia Message Service, which allows you to enclose
audio files, images and others rich contents to your messages; these messages can even be composed of several slides.
MMS are differently invoiced than SMS are. Please contact your network provider to get more information on their cost.
This menu has been compiled in collaboration with magic4™.
Compose SMS
On the
Messages
The language used is the one selected on the display of the phone (if the language selected is not compatible with the Easy
Message T9™, the English language will be automatically selected).
When typing a text, a counter showing the number of characters deducted is displayed at the top of the screen (depending
on model). This counter is not displayed if an icon or sound is inserted into the SMS.
When the text has been entered, [
-
Send
-
ABC mode
123 mode
-
-
T9 mode
-
Save
Save as Template
-
-
Cancel
-
Activate/Deactivate Zoom
Activate/Deactivate Silent
-
-
Formatting
-
Insert
22 Messages
menu, please select the
is used to send the message by entering the correspondent's number or selecting it in the phonebook
(see page 24)
(see page 24)
(see page 23)
is used to save a draft in memory
to insert an image or sound into your message (see page 24).
: allows you to keep as a template a message in order to use it again.
is used to delete all text entered and quit
is used to enrich a text
is used to modify size of characters
is used to activate or not the keypad beep when typing the text
Compose
menu and validate. Choose the
Options
] is used to access the functions offered:
SMS
option.
The Easy Message T9™ mode helps you to easily write your short messages.
Using T9 Mode
Press once the key corresponding to the letter chosen and compose the word by continuing to press the keys corresponding
to the various letters without paying attention to the display: the word is highlighted.
If you agree on the word proposed on the screen, press the
the next word.
However, the same sequence of keys pressed can correspond to several words, existing on the dictionary. If the word that
appears is not the word you expected, press the navigation stick to scroll through the words corresponding to this key
sequence.
Once you agree on the word proposed on the screen, press the
writing the next word.
If the word you are expected is not proposed, please add characters until you get the message
validate if the word displayed suits you or modify this word before adding it in the dictionary.
Messages 23
0
key to validate it (the 0key inserts a space), and go on writing
0
key to validate it (the 0key inserts a space), and go on
Add a word
? Press
Yes
and
Input modes
When composing a message:
key:
-
Deletes last letter
-
key:
Message options
-
key (long press):
Zoom mode (changes size of
characters)
key (short press):
-
Access to symbol table
key (long press):
-
Upper case
Punctuation characters
Punctuation characters are obtained thanks to key1 (except in
briefly pressing the key).
Accented characters
Accented characters are generated automatically in T9 mode.
In ABC mode accented characters are available by pressing the key supporting the non-accented character in succession.
In the input screen, the key is used to access other input modes. The mode
in which you type the text is displayed at the right top of the screen. A short press
of the key switches from one mode to another.
ABC mode
The
a particular character, please press the corresponding key several times: the
characters will scroll down on your screen.
Mode 123
Insert mode
Images and sounds can be of two types: pre-defined or customized. Pre-defined
images and sounds are smaller, especially suited to exchanging messages.
Upper case
A long press of the key will display the next letter in upper case ( icon).
is used to write words that do not exist in the dictionary. To get
is used to add numbers.
is used to add symbols, animations, call group icons and tunes.
123
mode), or with the help of
Insert
mode (fast access by
Compose MMS
On the
Messages
When the text has been entered, [
-
Insert
ABC mode
-
-
123 mode
-
T9 mode
Cancel
-
-
Slide…
-
Preview
24 Messages
menu, please choose the
to insert multimedia objects such as images, animations, sounds and videos into your message.
(see page 24)
(see page 24)
(see page 23)
is used to delete all text entered and quit
to compose a slideshow of the multimedia objects.
to see a presentation of the multimedia objects.
Compose
Options
menu and validate. Select the
] is used to access the functions offered:
MMS
option.
Saving the message
Select
Save
. It is saved in the
Select
Save as Template
Sending the message
- Once the text entered, press the navigation stick or press [
- Enter the receiver’s number (or take it in your phonebook pressing
You can enter an e-mail address.
Note:
It is possible that the voice message format (.amr) is not supported by some PC. See your PC provider.
WARNING:
some message sendings may fail if the message content is too big.
In the recipient screen, before typing the recipient’s number, the following options are available:
-
Editor
: this option allows you to modify the text before sending the message.
Contacts
-
-
-
Once the number typed, other options are available.
: to access the phonebook.
ABC/123
: to type either letters or figures.
Add mailing list
Drafts
menu.
. It is saved in the
: this option allows you to select a mailing list to which the message is sent (see chapter
Templates
menu.
Options
] and select
Send
Contacts
.
) and press the navigation stick.
Phonebook
).
Receiving messages
When you receive a message, the phone plays the ring tone that you selected, and the message icon comes on the
screen of your phone.
If you do not read the messages, this icon remains displayed on the screen. When it flashes, the memory is full.
Receiving icons, backgrounds or tunes can take several seconds. An icon is blinking when the download of your message is
in progress.
Note that you have two different possibilities for receiving MMS: automatically or manually; if « manual mode » is activated,
then you will receive only a notification in your Inbox, meaning that a MMS is available on the MMS Server; select Retrieve
in the options when you want to retrieve the MMS from the server.
For more details about automatic and retrieval modes, see « Options » on page 27.
Please contact your network provider to get more information on icons, backgrounds or tunes downloading.
Received messages are stored in the SIM card or in the phone until you choose to delete them.
Messages 25
Inbox
On the
Messages
Each message shows the presence of any attachments, the time and date the message was received and its size.
Messages are listed in chronological order, the latest one being displayed first.
The quantity of Not Read and Not Retrieved messages is shown. Not Retrieved and Not Read messages are shown in bold.
Select a message and press the navigation stick. Choose one of the options given.
Enclosures (pictures or sounds), which you receive, can be extracted in order to be used later on (stored…).
You can consult them in the corresponding menus (WAP bookmarks in
menu, please choose the
Inbox
menu and [
Select
].
WAP
, ring tones in
Sounds
, wallpapers in
Display
Outbox
This menu displays the messages that have not been sent. You can therefore send them again.
Sentbox
The
Sentbox
menu (see page 27).
Too many messages saved will quickly fill up the available memory and no further messages will be received.
For each message, its characteristics (shown with an icon) and the time (or date) of sending are displayed on the screen.
Select a message and press the navigation stick.
Choose one of the options given: Read, Modify, Forward, Delete, Delete all.
menu is used to store all your sent messages if you activated the option
Store sent messages
in the
Options
Drafts
When you store a composed message, it is stored among the drafts.
On the
Messages
Select a message and press [
If you select a message and press the navigation stick, you can modify it.
If you want to send it, select
menu, please choose the
Options
Modify
Drafts
]. The options are: Delete, Read, Modify, Details.
then press [
menu and press the navigation stick.
Options
] and select
Send
.
Templates
When composing a message, if you selected the
The same options as for the drafts are available for the templates.
26 Messages
Save as Template
option, the template is saved in this menu.
).
Options
Several sending options are offered.
On the
Messages
Choose one of the options given: SMS or MMS.
The SMS sending options are: message centre number, store sent message, acknowledgment, period of validity (during that
period, the network provider will try to send the message), message format.
The MMS options are:
Store sent messages
-
-
Retrieval mode
gives you the retrieve later option.
Priority
-
-
Request delivery report
-
Period af validity
Advanced settings
-
Send delivery report
MMS ignore
-
-
MMS server
-
Display Bcc
Sender visibility
-
-
Maximal Size
menu, please choose
: (it is highly recommended that you keep this function deactivated, in order to avoid a full memory),
: if you are in a poor coverage area, it may be more convenient to choose the manual retrieval mode which
: selection of a priority to send a message.
: if you want to deactivate the reception of any MMS in your phone.
: to select another MMS provider, or set the parameters of a new MMS provider.
: if you want to activate/deactivate this display.
: request of a delivery report when sending a message.
: during that period, the network provider will try to send the message.
: sending a delivery report when receiving a message.
: you choose to display or not your phone number on the receiver’s phone screen, with that message.
: if you want to activate/deactivate the option of maximum size supported for the MMS.
Options
and [
Select
].
Memory
You may know the memory available for saving messages.
On the
Messages
Choose one of the options given: SMS or MMS.
The SMS screen displays the memory available either on the SIM card or on the phone.
The MMS screen displays how much memory is used in Kbytes.
menu, please select the
Memory
option and [
Select
].
Local information
This menu is used to activate reception of local information broadcast by the network.
You can choose whether you want to receive this information or not (please contact your network provider).
On the
Messages
menu, please select the
Messages 27
Local info.
menu and [
Select
].
Calling Voice Mail
This function allows you to call your voicemail.
On the
Messages
This number depends on the operator.
menu, please select the
Call Voice Mail
option and [
Select
].
Mailing list
This menu displays the mailing lists created in the phonebook.
To display the different options, press [
Add mailing list
-
-
Modify name
-
Add contact
Properties
-
-
Delete
-
Send message
28 Messages
: allows you to create a new mailing list.
: allows you to modify the mailing list name.
: allows you to add a contact to the mailing list.
: allows you to see the type of mailing list and the number of contacts.
: allows you to delete the mailing list.
: allows you to compose and send a message to the contacts of the mailing list.
Options
].
Camera
This menu allows you to take photos and use them for different purposes. For instance, you can send them to
another phone or an Internet address, store them, use them as wallpapers or screen savers…
Taking and saving a photo
Settings before taking a photo
You can set the timer, the click sound, the photo format and quality in the
In the screen when taking the photo:
- To activate zoom, use the navigation stick upwards or downwards.
- To set the luminosity, move the navigation stick leftwards:
: cloudy, : very sunny, : low luminosity, : in case of neon or halogen lighting, : to avoid backlighting.
To select an effect (sepia, negative or black and white), move the navigation stick rightwards.
Other settings
-
-
-
-
-
Taking and/or sending a picture
- Press the navigation stick, the photo is taken and stays on the phone display.
Warning:
- Press the navigation stick if you want to send the photo immediately.
- Press [
If there is not enough memory to save the photo, a warning message appears, prompting you to confirm whether you want
to go on.
Once taken, the photo appears on the phone display. The name is made up with a number.
Note:
Camera 29
(pressing [
Options
Activate timer
Timer duration
Click sound
Photo format
Photo quality
: to take a photo with a 5, 10 or 15 second time delay.
: to select the timer delay
: to select the sound you will hear when taking a photo.
: to select the format in which your photo will be saved
: to select the photo quality.
if you press [
Save
] to save your photo and display the different options (see next page).
using the camera during a call may disturb the call quality.
]):
Back
], you will go back to the previous screen and lose the photo you have just taken.
Settings/Camera
menu.
Loading...
