Sagem my3078 User Manual

ENGLISH

MY 3078

251127964_Proposition2.qxd 6/03/02 10:00 Page 1

IN A FEW WORDS ...

Redial last number

Switch on

Press .

Call

Dial the number then press .

Answer

Open the flap or press .

Hang up

Press or close the flap.

Switch off

Press (long press).

✄

MY_3078_EN-00.p65 05/03/02, 16:441

Press twice.

Make a call from a number stored in the directory

By name: enter the first letter of the name, press correspondent, then press to call.

By location in the directory: enter the location number then press

, scroll down the list to find your

to call.

Briefly, the functions

MENUS

With lateral keys:

Enter using

Navigate using and

Games

Accessories

Security

Briefly, the menus

MY_3078_EN-00.p65 05/03/02, 16:442

Controls

Validate using OK Quit or return to the previous

menu using C

Services

Directory

Text messages

Call services

Ringing and beeps

✄

You have just bought a mobile phone and we congratulate you on your choice.

Your phone will allow you to use different international networks depending on the roaming agreements between the operators.

We would like to remind you that this phone is approved to European standards.

To get the most out of using your phone, we recommend that you read this manual carefully and keep it handy for future reference if needed.

WARNING

According to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).

If an incompatible SIM card is inserted, a message will be displayed when switching on your phone. For further information, contact your Operator.

The SAGEM logo and trademark are the property of SAGEM SA. AT is a registered trademark of Hayes Microcomputer products Inc. Hayes is a registered trademark of Hayes Microcomputer Products Inc. T9 Text Input is a registered trademark of ©Tegic Communications Inc. T9 is licensed under one or more of the following U.S. Patents: 5,818,437, 5,953,541, 5,187,480, 5,945,928, 6,011,554 and additional patents are pending worldwide.

Compatibility of your SIM card

Your phone is compatible with SIM 3V cards only.

GLOSSARY

Outgoing call A call made from your phone.

Incoming call A call received by your phone.

SIM card The card containing your subscription

and access rights to services. The detachable part is the micro-SIM.

PIN The personal code linked to your SIM

card.

PIN2 The second personal code linked to

your SIM card to access certain functions (*).

Phone code The phone code is a secret code

intended to protect the phone in case of theft.

IMEI The identification number of your

phone.

SMS Short Message Service: sending and

receipt of text messages, icons, animated screen savers and melodies.

Service Company which manages the network provider or subscription. Operator

MY_3078_EN-00.p65 05/03/02, 16:443

1. Presentation of the phone ..................................... 6

Getting started ....................................................... 9

2.1 Information on the SIM card ................................ 9

2.2 Installing the SIM card and the battery .............. 10

2.3 Charging the battery ......................................... 11

2.4 Switching on/switching off, starting up .............. 12

2.5 Menu access .................................................... 13

2.6 Deleting characters ........................................... 13

3. Initial communication ........................................... 14

3.1 Making a call ..................................................... 14

3.2 Receiving a call ................................................ 15

3.3 Volume control .................................................. 15

3.4 Ending a call ..................................................... 15

4. Menu list .............................................................. 16

How to use the directory ...................................... 19

5.1 Directory display ............................................... 19

5.2 Storing a number .............................................. 19

5.3 Deleting a number ............................................ 20

5.4 Call groups ....................................................... 20

5.5 Sorting .............................................................. 22

5.6 Sending a short message to a stored number .. 22

5.7 Directory space memory ................................... 22

5.8 Displaying personal numbers ........................... 22

5.9 Making a call with a stored number ................... 22

Contents

6. SMS ..................................................................... 24

6.1 Receiving an SMS message ............................. 24

6.2 Editing a message using Easy Message T9 .. 27

6.3 Edited messages .............................................. 29

7. How to use the call related features .................... 30

7.1 Forwarding calls ............................................... 30

7.2 Viewing the list of the last numbers used .......... 31

7.3 Monitoring the duration and cost of calls ........... 31

7.4 Displaying the numbers .................................... 32

7.5 Authorising double call ...................................... 33

7.6 Configuring automatic redial ............................. 33

7.7 Voice mail number ............................................ 33

7.8 Local information distribution ............................ 33

7.9 Replacing the international prefix ...................... 33

7.10 Placing calls on hold ........................................ 33

7.11 Multi-conferencing (*) ...................................... 34

8. How to adjust the ringing tones

and the vibrator ................................................... 35

8.1 Selecting the volume and the type

of ringing tone ................................................... 35

8.2 Call groups ....................................................... 36

8.3 Personalising the ringing tone ........................... 36

8.4 Setting the vibrator ............................................ 36

8.5 Selecting silent mode ........................................ 37

8.6 Setting the beeps .............................................. 37

8.7 Deleting DTMF tones ........................................ 37

MY_3078_EN-00.p65 05/03/02, 16:444

9. How to adjust and customize your phone............ 38

9.1 Customizing your phone ................................... 38

9.2 Selecting the display language ......................... 40

9.3 Select the type of response .............................. 40

9.4 Selecting the network ....................................... 40

9.5 Setting the time and date .................................. 41

9.6 Controlling screen contrast ............................... 41

9.7 Converting currencies....................................... 42

9.8 Active flap ......................................................... 42

10.How to use the security features

of your phone ....................................................... 43

10.1 Changing the PIN number ............................... 43

10.2 Changing the PIN2 number (*) ........................ 44

10.3 Changing the phone code ............................... 44

10.4 Changing the operator password (*) ................ 45

10.5 Limiting incoming calls (*) ................................ 45

10.6 Limiting outgoing calls (*) ................................ 45

10.7 Setting up the pre-set directory (*) ................... 46

10.8 Charge checking (*) ........................................ 46

11. Other functions .................................................... 47

11.1 Calculator ........................................................ 47

11.2 Setting the alarm ............................................. 48

11.3 Setting the timer .............................................. 48

11.4 Data parameters ............................................. 48

12. WAP Function ..................................................... 49

Games ................................................................. 52

13.

Available accessories .......................................... 53

14.

Upkeep ................................................................ 54

15.

Recommendations .............................................. 55

16.

Answers to your questions ........................................ 58

Contents

MY_3078_EN-00.p65 05/03/02, 16:455

Ear phone

High definition graphics screen

Antenna

Indicator light

Programmable key

Lateral key with scrolling arrows

Stop/End call

Correction

Microphone

WARNING!

During a call, mind you do not obstruct the microphone with your hand.

1. Presentation of the phone

MY_3078_EN-01.p65 08/03/02, 10:416

Mobile Internet access key

Programmable key

(depending on model)

Operate/Call

Validate

Battery charging socket

Accessories socket

Function keys

Stop  Reject a call  Hang up

Go  Call a number  Receive a call  Hands-free mode

C Short press: Return to the previous

menu  Delete a character Long press: Exit menu mode  Complete deletion of the entry

OK Validate

- Programmable keys for direct access to the functions that you have selected (depending on model)

- Contextual action

@ - Mobile Internet access key

- Flap activation / deactivation

and Entry and scrolling through the

menus.

- Volume control during conversation

key: lower, key: louder)

(

Alphanumeric keyboard

Made up of 12 keys: 0 to 9, * and #. To obtain a number or letter, hold down the

relevant key until the desired number or letter appears.

Letters with accents are obtained by a long press on accent.

Punctuation marks and special symbols are obtained by a long press on the # key.

after entering the letter with no

Key 1

A long press on key 1 allows you to access the voicemail service (depending on model).

1. Presentation of the phone

MY_3078_EN-01.p65 08/03/02, 10:417

Display

The high definition graphics screen enables you to read messages easily. Various icons inform you about the status of functions.

Battery charge indicator (black if charged, clear if discharged)

Received signal strength indicator (maximum strength: 5 bars) ; the R letter indicates if the network found does not correspond to the subscription

flashes, the phone is

If searching for a network

Call in progress

Permanent call forwarding

Silent mode

1. Presentation of the phone

The three keys located under the screen are allocated to actions described at the bottom of the screen just above the key, each time it is necessary.

For example:

Validate Pressing

Receipt of SMS and presence of SMS not read; Flashing: SMS memory full.

Voice messages present.

validates the current

function.

MY_3078_EN-01.p65 08/03/02, 10:418

2.1 Information on the SIM card

2. Getting started

MY_3078_EN-02.p65 04/03/02, 13:019

To use your phone, you have a small card called a SIM card. In addition to all of the information necessary for the network, this card contains other information that you can modify:

 secret codes (PIN and PIN2 -

Personal Identification Number)  directory  mini-messages  functioning of specific services.

2. Getting started

SIM card

This card must be handled and stored with care in order to avoid excessive stresses or scratches that would damage it. If your SIM card is lost, contact your Operator or Service Provider immediately. Note: Do not leave you SIM card within the reach of small children.

PIN code

This is the personal code for your SIM card. You may be asked to enter this code when the instruction: Pin number ? appears after you switch on your phone.

Enter the code of between 4 and 8 digits given to you by your operator. These digits will not be displayed on the screen for security reasons.

Press # or OK or to validate.

PIN2 code (*)

If one was given to you by your Operator, a second PIN code provides secure access to certain functions.

Warning

If the wrong PIN code is entered three times in a row, the card will be locked. To unlock your card:

- enter **05*

- enter the PUK code (Personal Unlocking Key) provided by your Network Operator and validate,

- enter your PIN code and validate,

- enter your PIN code again and validate.

After 5 or 10 times (depending on SIM card type), the SIM card will be permanently locked. Contact your Operator or your Service Provider to obtain a new card. The same procedure (entering 052) applies when the PIN-2 code is blocked (PUK 2 code).

2. Getting started

2.2 Installing the SIM card and the battery

Switch off your phone and disconnect the charger.

The SIM card is inserted beneath the phones battery.

Turn your phone over. Pull out the lock (1) and remove the battery (2).

Install the card with the gold coloured sections facing towards the phone and the cut-off corner lined up to match the drawing on the phone. Pull the lock to fix the card.

To remove the card, push the lock.

Replace the battery by sliding it (1) and press (2) to lock.

MY_3078_EN-02.p65 04/03/02, 13:0110

2.3 Charging the battery

Your phone is powered by a rechargeable battery. A new battery must be charged for at least 4 hours before it is used for the first time. It will reach its nominal capacity after several usage cycles.

When your battery has run down, the phone displays it and cuts out.

To recharge your battery:

Connect the charger to a wall outlet. Connect the end of the charging cable to

the bottom of your phone.

The phone will start charging. The battery charging indicator indicates the charge. Charging stops by itself.

Unplug the cable.

It is possible that during charging, the battery may heat up slightly; this is normal.

WARNING

There is a risk of explosion if the battery is incorrectly replaced or disposed of in fire.

Do not short-circuit. The battery does not contain any

components that can be changed by you. Do not attempt to open the battery case. Only use the correct chargers and

batteries as shown in the manufacturers catalogue.

Spent batteries must be collected at the appropriate sites.

You are advised to remove the battery if you intend to leave your telephone unused for a long period.

2. Getting started

MY_3078_EN-02.p65 04/03/02, 13:0211

2.4 Switching on/switching off, starting up

To switch on your phone:

Press to switch on your phone. If access to the SIM card is

protected by a secret code, the phone will ask you to enter your PIN code.

Enter the code of between 4 and 8 digits given to you when you were given your SIM card. These digits will not be displayed on the screen for security reasons.

Press # or OK or to validate.

Setting time

The first time you switch on your phone, you will be asked to set the time and date:

Press OK to accept displayed time and date.

2. Getting started

Control of the PIN code

If your phone displays SIM absent, press (long press) to switch off your phone and check that your SIM card is correctly positioned.

Press (Next) to set the following element of time and date.

Press (Cancel) or not to set the time and date.

Later you will be able to change time, thanks to Setting Time and

Date menu.

Searching for a network

The phone then searches for a network on which it can communicate:

If it finds one, the name of the network appears on the screen, and the indicator light flashes green.

You are ready to make or receive a call.

If the R letter and a network name are displayed, calls can be made and the indicator light flashes green.

Network indicator

The indicator of the level of network signal received enables you to visualise the quality of reception. If it shows less than three bars, look for better reception to make your call in good conditions.

MY_3078_EN-02.p65 04/03/02, 13:0212

If the R letter is displayed without any network name, only emergency services will be accessible (police, ambulance, fire brigade).

If the flashes, the phone will keep searching. No network is available.

Switching off

Hold down the key until the end message is displayed.

Release the key. The phone switches off.

2.5 Menu access

The menu functions permit you to verify or modify the various functions of your phone to adapt it to your needs.

Press the scrolling arrows or

to access the menus.

Scroll through the menus using the scrolling arrows then press OK to access the selected menu.

Each time you want to validate an action, press OK.

Direct access to menus

To directly access a menu, press then enter the number of the selected menu.

To abandon an action, press C. To exit the menu mode, press and hold C.

2.6 Deleting characters

You can cancel an entry error:

Press quickly on C to delete the last character.

If you press this key longer, you will delete the previous word.

2. Getting started

MY_3078_EN-02.p65 04/03/02, 13:0213

3. Initial communication

3.1 Making a call

The network is displayed.

Dial the number, including the area code if necessary, by pressing keys on the alphanumeric keypad.

Press .

During the call, flashes on the screen, and tones may signal the establishment of a connection.

When the person you have called answers, speak.

Emergency services

Depending on the operator, you can contact the emergency services with or without a SIM card or when the keyboard is locked. It is sufficient to be in a zone served by a network. To call the international emergency service, dial 112 then press .

Other emergency service numbers may exist, depending on the country.

International call

Press 0 (long press) to display + then dial the country code without waiting for a tone, then the number you require.

MY_3078_EN-03.p65 08/03/02, 10:4314

3.2 Receiving a call

When you receive a call:

Press then speak. or Open flip when in Active flip (default) mode.

The callers number is displayed when it is presented to the network.

All incoming and outgoing call numbers are registered in the list of the last calls.

3.3 Volume control

Increase or decrease the volume during a conversation by pressing the

or keys.

3.4 Ending a call

Press . or Close flip when in Active flip (default) mode. The end of call message appears on the

screen.

3. Initial communication

MY_3078_EN-03.p65 08/03/02, 10:4315

4. Menu list

According to the model of your phone, to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).

4. Menus

Services

Access to specific services offered by the operator
