Sagem MY300C User Manual

ENGLISH

You have just purchased a SAGEM phone, we congratulate you; it is recommended that you read this handbook carefully in order to use your phone efficiently and in the best conditions. Your phone can be used internationally in the various networks (GSM 900 MHz and DCS 1800 MHz) depending on the roaming arrangements with your operator. This phone is approved to meet European standards.

SAGEM is a trademark of Sagem Communication SAFRAN Group. T9® Text Input is a trademark of ©Tegic Communications Inc. Java™ and all Java™ based trademarks and logos are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries. The WAP navigator and some message softwares (i-mode) are under licence Openwave. The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares. Wellphone™ and SmartCom™ are registered trademarks owned by SmartCom SARL France.

Description............................................................................. 7

Installing the SIM card and the battery .................................... 10

Idle screen............................................................................ 11

Quick start............................................................................ 12

Information on the SIM card.....................................................12

Getting started .........................................................................13

Switching ON/OFF ...................................................................13

Network....................................................................................14

First call....................................................................................14

Receiving a call........................................................................15

Using your phone................................................................ 16

Improving antenna performance ..............................................16

Increase the battery life of your phone.....................................16

Charging the battery ................................................................16

Phonebook........................................................................... 18

Using the phonebook ............................................................... 18

Storing a new contact ..............................................................18

Calling a contact ......................................................................19

Contact options........................................................................19

Mailing lists ..............................................................................21

Messages ............................................................................. 22

Creating a text message..........................................................22

Saving the message ................................................................23

Sending the message ..............................................................23

Receiving messages................................................................ 24

Messages menu....................................................................... 24

Camera ................................................................................. 28

Taking and saving a photo....................................................... 28

4 Contents

Multimedia ............................................................................ 30

Pictures....................................................................................30

Sounds .................................................................................... 31

Videos...................................................................................... 31

WAP.......................................................................................32

The WAP Menu ....................................................................... 32

WAP Logging on......................................................................33

Downloading objects................................................................ 33

WAP Logging off......................................................................33

GPRS ...................................................................................... 33

Games...................................................................................34

Applications .........................................................................35

Applications .............................................................................35

Alarm ....................................................................................... 35

Timer........................................................................................35

Calculator.................................................................................35

ToDo........................................................................................36

Services................................................................................... 37

Calendar................................................................................38

Calendar menu ........................................................................38

Settings................................................................................. 39

Phone ...................................................................................... 39

Display.....................................................................................41

Messaging ............................................................................... 42

Calls......................................................................................... 43

Networks..................................................................................45

Security....................................................................................45

Browser.................................................................................... 47

Camera.................................................................................... 47

Leds......................................................................................... 47

Connectivity ............................................................................. 48

Help ......................................................................................... 48

Contents

Technical features ............................................................... 49

Conformance Document..................................................... 50

Care and safety information............................................... 51

SAR..........................................................................................51

Advice for limiting exposure to radiofrequency (RF) fields....... 52

Safety.......................................................................................52

Environment.............................................................................54

End User Licence Agreement (EULA), for the software ..55

Java™................................................................................... 62

Warranty............................................................................... 67

Troubleshooting .................................................................. 72

Customer care ..................................................................... 75

Index .....................................................................................76

6 Contents

Description

Red key

Short press: Switch on -

: Switch off

Long press

In a call context: Reject a call - hang up In menus: Return to idle screen

Green key

Short press: Activate/Deactivate hands-free mode

WARNING:

( near to your ear, or you may suffer hearing loss) In call context: Call - receiving a call

Right programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in

the tab (*)

Left programmable key:

In idle screen: Access to certain functions (shortcuts) In menus: Access to the selection shown on screen in

the tab (*) The navigator allows you:

- to navigate in the various functions pressing the

- to confirm your selection pressing the central part

In idle screen, pressing the navigator displays the main menus icons. Pressing the navigator followed by one of the nine keys of the keypad, you can display a menu directly.

When composing a message:

Short press: upper case/lower case Long press (ABC mode, T9 mode, 123 mode)

do not use the phone in hands-free mode

relevant part (

)

(

S, T, X, W

)

: switches from one input mode to another

8 Description

When composing a message:

Long press: modifies the T9 mode language. Short press: displays the symbol table

In idle screen: Long press In call reception mode: Short press: stops ring tone In ring tone setting mode: Short press:

Activate/deactivate ring tone A long press on the key 1 calls voicemail (if the number

has been stored in A long press on the keys 2 to 9 directly displays the

2 to 9

phonebook

(*) In this manual, when a function is chosen by pressing on this

key, square brackets are used (e.g.: [

: Silent mode.

Settings/Calls/Voicemail

Save

]).

menu)

Description

Installing the SIM card and the battery

WARNING

Depending on the model, network configuration and associated subscription cards, certain functions may not be available. Your phone is identified by its IMEI number. Write this number down, and do not keep it with your phone, because you may be asked for it in the event of your phone being stolen, in order to prevent it from being used, even with a different SIM card. In order to display the IMEI on your phone's screen, type: *#06#.

10 Description

Switch off your phone and disconnect the charger.

The SIM card is inserted beneath the phone’s battery.

Slide the SIM card, with cut corner

as shown on the phone, into the card holder with fold face down.

Place the battery by first inserting

the upper section into the opening. Replace the back cover, making it

slide.

Idle screen

The idle screen may contain the following information:

1 - The title bar icons:

Battery (if it flashes red, the battery must be charged immediately)

Silent mode (the ringtone is off)

Only emergency call is possible

Signal strength level (between 0 and 5 bars)

Message received (read your message)

Red: GPRS unavailable

Black: GPRS connection Flashing: GPRS connection on hand

WAP connection

2 - Date and time 3 - Network provider 4 - Thumbnail centred on bottom line:

The main « Menu » thumbnail shows that the menus can be accessed by pressing the navigator. The following information may also be displayed: « New message from » or « 1 missed call from caller unknown. Press the green key » (incoming call failed). It can be deleted by pressing briefly.

Idle screen

Quick start

Information on the SIM card

To use your phone, you need a card called SIM card. It contains personal information that you can modify:

- Secret codes (PIN(s): Personal Identification Numbers), these

codes allow you to protect access to your SIM card and phone

- Phonebook

- Messages

- How special services work.

WARNING

This card must be handled and stored with care in order not to be damaged. If you should lose your SIM card, contact your network provider immediately. Please keep your SIM card out of reach of young children.

12 Quick start

Getting started

When you switch on your phone for the first time, follow instructions displayed on the screen. If access to the SIM card is protected, the device prompts you to enter the PIN number: Enter the code card was issued. These digits do not appear on the screen for security reasons. If there are contacts saved in your SIM card, you are invited, if you wish, to copy them in the phone contacts memory.

Warning

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code provided by

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator to obtain a new card.

between 4 and 8 digits given to you when the SIM

your operator, and validate.

Switching ON/OFF

When your phone is off, a short press on will turn it ON. When the phone is ON, if your are browsing inside the menus, a short press on will come back to the idle screen. When you are in the idle screen, a long press on will switch OFF the phone.

Quick start

Network

From now on the phone hunts for a network on which it can make calls. If it finds one, it displays the name of the network on the screen. You are then ready to send or receive a call.

If the network’s name appears, calls are possible on your operator's network. If the letter possible on a roaming network provider. If the letter emergency services are accessible (ambulance, police, fire brigade). If the network icon flashes, the phone is in permanent search mode. There is no network available. The signal strength indicator received allows you to display the quality of reception. If it indicates less than three bars, search for better reception in order to call in good conditions.

and a network name are displayed, calls are

is displayed without any network name, only the

First call

Dial the number you want to ring. Press . During the call, the call in progress icon flashes on screen and tones may indicate the establishment of the call. While a call is connecting, the phone icon is flashing. You can adjust the sound level (volume) using the navigator upwards or downwards.

14 Quick start

At the end of the conversation press to hang up.

International call

Press 0 (hold down) to display « + », then dial the country code without waiting for the dial tone, then the number of the called party.

Emergency services

Depending on the operators you can obtain the emergency service with or without SIM card. It is enough to be in an area served by a network. To obtain the international emergency service, dial press .

112

then

Receiving a call

When you receive a call, the number of your caller is displayed when it is presented by the network. Press to answer, and speak. To refuse the call, press . To stop the ring tone or the vibrate, without refusing the call, press .

Hands-free mode

To change to hands-free mode during a call, make a short press on the green key then press [ amplified mode.

WARNING:

in this mode do not bring the phone up to your ear.

All the numbers corresponding to incoming and outgoing calls are logged in the list of recent calls.

When on a call, pressing [ different functions: switching to hands-free mode, switching to mute mode, displaying menus, displaying the phonebook.

Mute ON

Pressing [ temporarily when you want that your correspondent does not listen.

Yes

] to confirm activation of the

Options

] allows you to have access to

] allows you to switch off the microphone

Quick start

Using your phone

Improving antenna performance

The antenna is integrated in your phone, under the back cover at the top. Avoid putting your fingers on this area when the phone is switched ON. If your fingers obstruct the antenna, the phone may have to operate with a higher power level than usual; decreasing its efficiency quickly. It could also affect the quality of your communications.

Increase the battery life of your phone

- Don't press the keys when not necessary: each keypress

activates the backlight, and uses much power.

- Don't obstruct the antenna with your fingers.

Charging the battery

16 Using your phone

Your phone is powered by a rechargeable battery. A new battery must be charged for 4 hours at least before being used for the first time. It reaches its optimum capacity after a few cycles of use.

When your battery has been discharged, the empty battery icon flashes. In this case recharge your battery for at least 15 minutes before making any calls in order not to be cut off quickly.

To recharge the battery:

Connect the charger to a socket. Plug the end of the cable into the side connector of the phone. The phone is then charging up. The battery icon scrolls up and down to indicate that it is charging. When the battery is fully charged, the charging stops on its own. Disconnect the cable. When charging, the battery may warm up, this is normal.

WARNING

There is danger of explosion if the battery is placed in an incorrectly way or if it is exposed to fire. Do not short circuit it. The battery does not have any part that you can change. Do not try to open the battery casing. Use only the appropriate chargers and batteries as shown in the phone manufacturer's catalogue. The use of other types of chargers or batteries may be dangerous or invalidate the warranty. Used batteries must be disposed of in the appropriate places. We advise you to take the battery out if you plan not to use the phone for extended periods. You are strongly advised not to connect your phone to the charger if it doesn’t contain a battery. The charger is a safety step-down transformer, it is forbidden to modify, alter or replace it by another component (power supply plug, etc). If the battery has entirely discharged, the phone cannot start. Plug the phone to the charger. The phone will switch on after a few minutes of charge. You can use the phone again when the

Start

option is displayed on the screen.

Using your phone

Phonebook

Using the phonebook

Enter the

Phonebook

already get some (otherwise, go to When a contact is selected, an icon is displayed in the title bar:

contact stored in the SIM card

contact stored in the phone

contact stored in the Fixed Dialling. See

Fixed dialling

activation. You can search for a contact quiclky by typing the first letters (up to three). You can display it by pressing

menu, the contacts list is displayed if you

Storing a new contact

- Select [

Options

contact

- Enter the last name and press OK.

- Enter the number and press

Note:

memory (email, address, ringtone, photo, etc.).

- Press [

18 Phonebook

], then select

you can fill other fields if you store the contact in the phone

Save

] to store it.

Storing a new contact

Security

Menu for more details about this

Add phone contact

OK.

PIN2 number

Add SIM

and

Calling a contact

Several ways:

- Select a contact. Press to start the call.

- Select a contact, press OK, his number is displayed, press [

to start the call.

- Direct call from the idle screen (only for the contacts stored in the

SIM card memory): type the number with which the contact was saved then (example : 21 ) or the number then , the number is displayed, confirm.

Call

]

Contact options

To display the various options, select a contact and press [

Call

It allows you to call the contact selected.

Modifying a contact

Modify what you want and validate then select modifications completed.

Sending a message

To send a SMS or a MMS to a contact (see chapter

Sending by message

To send a contact details by message (see chapter

Copy to mobile/Copy to SIM

This allows you to copy your phonebook contacts from one memory to the other. Only the name and the first phone number will be copied.

My numbers

You can create the entries corresponding to your own numbers in order to consult them when necessary. Select validate.

My numbers

and validate. Enter the different details and

Options

Save

once the

Messages

Phonebook

Memory

Select

SIM

Telephone

memory capacity is shared between the phonebook and various other features. If you lack memory, check if you can free some space.

SIM

: available memory only for contacts.

and validate.

: the screen displays the amount of memory used. The

Delete

It allows you to delete the contact(s) selected or all the contacts.

Copy SIM Æ phone/Copy phone Æ SIM

This allows you to copy all the SIM contacts to the phone memory or all the phone contacts to the SIM card.

Synchronize

You can synchronize your phonebook with your archives stored in your operator's network depending on the options offered by your operator with a GSM or GPRS connection from your phone. You can also synchronize your phonebook with your archives stored in your computer. You have only to configure your USB connection in your phone (see chapter

Connectivity

Add to mailing list

This menu allows you to add a contact to a mailing list.

Settings

List choice

phonebook (SIM, Phone, SIM and Phone) displayed when the phone switches on.

Sorting

in the phonebook (by name or first name).

20 Phonebook

: This menu allows you to select the default

: This menu allows you to select the way to sort contacts

Mailing lists

A mailing list allows you to group contacts: this list can be used to send messages easily to all the list contacts (only contacts stored in the phone memory).

- In the phonebook, select the

navigator rightwards.

Options

- Press [

- Select

- Enter a name and press OK.

- Then, on a list press [

you want to add a contact in the list.

Add mailing list

Options

Mailing Lists

]. Select

Add contact

tab pressing the

each time

Phonebook

Messages

From this menu, you are able to send SMS and MMS. MMS is a Multimedia Message Service, which allows you to enclose photos, audio files, and others rich contents to your messages; these messages can even be composed of several slides. MMS are differently charged to SMS are. Please contact your network provider to get more information on their cost and the service availability.

Creating a text message

- Select

Messages/Create Message

- Type your text. The T9 mode is applied by default.

The language used is the one selected on the display of the phone (if the language selected is not compatible with the Easy Message T9®, the English language will be automatically selected). The Easy Message T9® mode helps you to easily write your messages.

Using T9 Mode

The same sequence of keys pressed can correspond to several words, existing on the dictionary. If the word that appears is not the word you expected, press the navigator upwards to scroll through the words corresponding to this key sequence. Once you agree on the word proposed on the screen, press the navigator rightwards to validate it or on the and inserts a space after the word), and go on writing the next word.

22 Messages

Press once the key corresponding to the letter chosen and compose the word by continuing to press the keys corresponding to the various letters without paying attention to the display: the word is highlighted.

key (which validates

If the word you are expected is not proposed, please add characters until you get the message the word displayed suits you or modify this word before adding it in the dictionary. If you do not want to use pressing (long press). The press on one key several times to make the letter wanted appear (for example: press twice the

Upper case/Lower case/Figures

A short press on switches the text to upper case, lower case.

Punctuation characters

Punctuation characters are obtained by pressing the 1 key (except

123

mode), or with the help of

in by briefly pressing ).

Accented characters

Accented characters are generated automatically in T9 mode. In ABC mode accented characters are available by pressing the key supporting the non-accented character repeatedly.

Add a word

T9 mode

key to display B).

? Press

, you can switch to ABC mode

ABC mode

allows you to type letters:

Insert symbol

Yes

and validate if

mode (fast access

Saving the message

- Select

Save

or if you want to send it several times. It is saved in the menu. or

- Select

in the

if you do not want to send the message immediately

Save as Template

Templates

to use it again as a template. It is saved

menu.

Drafts

Sending the message

- Once the text entered, press the navigator or press [

Add recipient

select

- Enter the receiver’s number or take it in your phonebook pressing

Options

[

You alson can select a contacts list in your phonebook.

] then selecting

Contacts

Options

] and

Messages

Receiving messages

When you receive a message, the phone plays the ring tone that you selected, and a message icon comes on the screen of your phone. The LED located on the flap is flashing. If you do not read the messages, this icon remains displayed on the screen. When it flashes, the memory is full. Receiving icons, backgrounds or tunes can take several seconds. An icon is flashing when the download of your message is in progress. Note that you have two different possibilities for receiving MMS: automatically or manually; if « manual mode » is activated, then you will receive only a notification in your Inbox, meaning that a MMS is available on the MMS Server; select Retrieve in the options when you want to retrieve the MMS from the network. For more details about automatic and retrieval modes, see « Options » on page 26.

Messages menu

Inbox

Messages are listed in chronological order, the latest one being displayed first. The quantity of Not Read and Not Retrieved messages is shown. Not Retrieved and Not Read messages are shown in bold.

Drafts

When you store a composed message, it is stored among the drafts. Select a message and press [ Send, Details, Delete, Modify. If you select a message and press If you want to send it, select

Send

24 Messages

Options

Modify

]. The options are: Read,

, you can modify it.

then press [

Options

] and select

Sentbox

The

Sentbox

activated the option (see page 26). Too many messages saved will quickly fill up the available memory and no further messages will be received. For each message, its characteristics (shown with an icon) and the time (or date) of sending are displayed on the screen. Select a message and press Choose one of the options given: Read, Modify, Forward, Delete, Delete all.

menu is used to store all your sent messages if you

Store sent messages

in the

Options

Outbox

This menu displays the messages that have not been sent. You can therefore send them again.

Call Voice Mail

This function allows you to call your voicemail. This number depends on the operator.

Tem pla tes

When composing a message, if you selected the option, the template is saved in this menu. The same options as for the drafts are available for the templates.

Save as template

Messages

Options

Choose one of the options given: SMS or MMS. The SMS sending options are: store sent messages, acknowledgment, period of validity (during that period, the network provider will try to send the message), message format, message centre number. The MMS options are:

Store sent messages

this function deactivated, in order to avoid a full memory.

Retrieval mode

more convenient to choose the manual retrieval mode which gives you the retrieve later option.

Priority

: selection of a priority to send a message.

Request delivery report

sending a message.

Period of validity

to send the message.

Advanced settings

Send delivery report

message.

MMS ignore

in your phone.

MMS server

parameters of a new MMS provider.

Display Bcc Sender visibility

number on the receiver’s phone screen, with that message.

: it is highly recommended that you keep

: if you are in a poor coverage area, it may be

: request of a delivery report when

: during that period, the network provider will try

: sending a delivery report when receiving a

: if you want to deactivate the reception of any MMS

: to select another MMS provider, or set the

: if you want to activate/deactivate this display.

: you choose to display or not your phone

Local info.

This menu is used to activate reception of information broadcast by the network. You can choose whether you want to receive this information or not (please contact your network provider).

26 Messages

Mailing list

This menu displays the mailing lists created in the phonebook. To display the different options, press [

Add mailing list Modify name

Add contact Properties

number of contacts.

Delete

: allows you to create a new mailing list.

: allows you to modify the mailing list name.

: allows you to add a contact to the mailing list.

: allows you to see the type of mailing list and the

: allows you to delete the mailing list.

Options

Memory

You may know the memory available for saving messages. Choose one of the options given: SMS or MMS. The SMS screen displays the memory available either on the SIM card or on the phone. The MMS screen displays how much memory is used in Kbytes.

Messages

Camera

This menu allows you to take photos and use them for different purposes. For instance, you can send them to another phone or an Internet address, store them, use them as wallpapers or screen savers.

Taking and saving a photo

Select the

Camera

phone display and position your subject. Move your phone to position your photo. The three text lines on the left of the screen indicate:

- the number of photos that you can take with the photo and the

format quality selected,

- the current format selected (

- the current quality selected (

Settings before taking a photo

Zoom

: To activate zoom, use the navigator upwards or downwards.

Note: if the zoom selected does not match with the storing format,

the photo is automatically saved in an appropriate format

Other settings

Activate timer

delay.

Effects Exposure

Click sound

photo.

Photo quality

Photo format

saved.

28 Camera

menu. The camera is now on. Look into your

Photo format Photo quality

(pressing [

Options

: to take a photo with a 5, 10 or 15 second time

: to select an effect.

: to select luminosity.

: to select the sound you will hear when taking a

: to select the photo quality.

: to select the resolution in which your photo will be

]):

option below),

option below).

Taking a photo

- Press OK, the photo is taken and stays on the phone display.

Warning:

if you press [

screen and lose the photo you have just taken.

- Press OK if you want to send the photo immediately by MMS.

Save

- Press

different options are displayed:

Send by message:

•

New…

: allows you to take a new photo.

•

Editor

: various options to modify a photo.

Zoom: allows you to magnify certain parts of your photo. Adjustment: allows you to improve contrast. Emboss: allows you to modify a photo with an embossed grey

tint.

Negative: allows you to change a photo into negative. Grey Scale: allows you to change color into black and white. Contrast: allows you to increase or decrease the contrast of

your photo.

Sharpen: allows you to sharpen a photo. Blur: allows you to add blur to a photo. Sepia: allows you to change colors into sepia. Shape: allows you to shape a photo. Brightness: allows you to increase or decrease the brightness

of a photo. Solarize: allows you to increase or decrease the solarize of a photo. Saturation: allows you to increase or decrease the color saturation.

Rename

•

Add to contact

•

saved in the phonebook.

Use as

: allows you to select the photo as a wallpaper or

•

screensaver.

Note:

using the camera during a call may disturb the call quality.

Back

], you will go back to the previous

to save your photo, a progress bar animates then

allows you to send the photo by MMS.

: allows you to modify the name of a photo.

: allows you to assign a photo to a contact

Camera

Multimedia

The

Multimedia

objects recorded in your phone and the downloaded objects (photos, videos, ringtones, etc.).

Pictures

To display a picture, select it and press OK. To display others, press To display the different options, press [

View

Send by message

you may not send any copyrighted picture).

Add to contact

in the phonebook.

Use as

saver.

Rename Delete

Editor

New photo Details

Memory

30 Multimedia

menu contains the directories of all the multimedia

or T.

Options

: allows you to display the picture.

: allows you to delete a picture.

: (see chapter

: allows you to send a picture by MMS (NB:

: allows you to assign a picture to a contact saved

: allows you to use the picture as a wallpaper or screen

: allows you to rename a picture.

Camera

: allows you to take a new picture.

: properties of the picture selected.

: memory size used by the pictures.

Sounds

To listen to a sound, select it and press OK. To listen to others, press To display the different options, press [

Listen

: allows you to listen to the sound.

Send by message Add to contact:

in the phonebook.

Ring tone Rename

: allows you to rename a sound.

Delete

: allows you to delete a sound.

New sound Details

: properties of the sound selected.

Memory

: memory size used by the sounds.

or T.

Options

: allows you to send a sound by MMS.

allows you to assign a sound to a contact saved

: allows you to add a sound to the ring tones list.

: allows you to record a new sound.

Videos

This menu gives you access to the videos you have downloaded.

Multimedia

WAP

WAP (Wireless Application Protocol): a protocol that translates the Internet language into WML and HTML languages that can be read by a phone. The WAP function allows you to log onto certain Internet sites. You can log onto sites that allow you to download tunes, icons or animated screensavers to your phone.

The WAP Menu

The WAP navigator is under licence:

The WAP navigator and the softwares included are the exclusive property of Openwave. For this reason, it is forbidden to modify, translate, disassemble or even decompile all or part of these softwares.

Go to URL

Browser settings:

Note:

icons.

32 WAP

: this menu allows you to input an Internet address

directly.

Bookmarks

sites). A bookmark stored in the list can be modified, sent or deleted. You can receive bookmarks and add them to this list.

Connection time out

call is automatically disconnected if you have forgotten to log off from a service.

Profiles

configuration settings or to configure others providers’settings.

: allows to store bookmarks (addresses of Internet

: is used to choose the time after which the

: allows you to select or modify your provider’s

see chapter

Idle screen

for information on @ and GPRS

WAP Logging on

The connection to a WAP service on the GPRS network is not cut if an incoming call is received. You can answer the call. If you are logging onto the GSM or GPRS network, the @ symbol flashes, the metering of the cost of the call starts as soon as it stops flashing.

Downloading objects

Some WAP sites allow you to download ringtones, icons, animated screensavers or games. Once downloaded, they are stored in your phone's memory. You can then save them in your phone (same operation as used for downloading using messages).

WAP Logging off

To log off, press . The logoff happens automatically after a few seconds of inactivity if you forget to log off. This period is defined by the linger time setting.

GPRS

A flashing icon indicates that the phone is logging onto a GPRS network. A non-flashing icon indicates that the GPRS network is available; if the icon is dark, it indicates that the phone is logged onto the GPRS network. This icon is not displayed if the GPRS network is not available or if the SIM card inserted in your phone does not include the GPRS service. It may also disappear when accessing WAP services if the connection uses the GSM network instead of the GPRS network.

WAP

Games

Your phone contains one or several games, depending on model. You can download more. You are the owner of a SAGEM mobile phone which gives you the ability to download applications and games to be executed on your phone thanks to the built-in Java™ engine. However, receiving applications from everywhere implies some basic knowledge of the possible effects of such download. We advise you to download certified games or applications from your operator sites or from www.planetsagem.com By default, the connection URL of your operator or of PlanetSagem is configured in your phone.

If no connection URL is configured, by selecting the configure new profiles which allow you to download games or applications. When you select a game or an application, the

Settings/Connection

to configure a profile which only be used by the game or application to connect to the network (to exchange scores for example) but is not used to download new games or applications.

34 Games

More Games

menu, you display the WAP function to

menu (displayed with [

Select

] key) allows you

Applications

(See chapter

Alarm

This menu allows you to set and activate the alarm.

The alarm works even when the phone is switched off.

Timer

This menu is used to set and activate the timer.

Calculator

This menu allows you to use your phone as a calculator. Use the following keys to make calculations:

The following keys are used for:

- : Equals or convert

If no calculations are being run, pressing [ the value in the

Converter

This menu allows you to convert one currency to another. Enter a value and press the navigator upwards to convert from one currency to another, or downwards to convert back. Pressing [

Applications

Games

)

The alarm icon appears on the idle screen.

Upwards

: Add,

lefwards

Rapid exchange

If the Rapid exchange is activated, the converter will work in the idle screen by entering the desired numbers and pressing the navigator to convert.

downwards

: Divide.

: Decimal point.

converter

Options

] allows you to use the following options:

: Delete

directly.

: Subtract,

Convert

rightwards

: Multiply,

] allows you to use

Exchange rate

Enter the exchange rate corresponding to the chosen currency.

Currency

Enter the two types of currency to be converted.

Goto Calculator

This option allows you to use immediately the value converted in the calculator.

ToD o

This menu allows you to add ToDo’s, access category-based Todo management and delete all the ToDo’s.

If there are not any ToDo, you directly access to the options below.

Add Written ToDo/Add Vocal ToDo

the text or voice type. Fill in the different items. Save the ToDo.

Calendar

This menu gives you access to your diary and get to a day, week, month or specific date. It lets you add events, access the global actions for all the events and manage them by event category.

Calendar menu

This menu lets you add events, manage events by category, see the available memory and delete all the events.

Add Written Event/Add Vocal Event

of the text or voice type. Fill in the different items. Save the event.

Delete

: allows you to schedule the deletion of events that took

place more than one day, week or month ago.

Memory

: allows you to view the memory capacity used by the

different functions of your diary.

Delete all

: allows you to delete all the events from your diary.

Settings

Phone

Silent mode

This menu allows you to switch to Silent mode. Silent mode can also be accessed via the idle screen by holding down the key.

When the phone is in silent mode, this relevant icon appears on the idle screen. In this mode, the ring tone will not function, except for the alarm clock.

Ring tones

This menu allows you to allocate a ring tone to different functions.

Vibrate

This menu allows you to activate the vibrate mode for calls.

Languages

This menu allows you to choose your phone's display language. Select your language and validate. If you select to your SIM card.

Beeps

This menu allows you to activate a beep for the battery, the keypad or the network.

Automatic

, the language used will be the one relative

Settings

Date/Time

Set Date/Time

This menu allows you to set the date and time of your phone.

Note:

if you have selected the AM/PM time format (see below) you

also have to select it when setting time.

Time format (depending on model)

This menu allows you to select the time format (24 hours or AM/PM).

Automatic update

This menu allows you to choose manual or automatic updating of date and time (after switch off of your phone or when going abroad for instance) (service depending on the operator). Please select Automatic, Manual or On demand and press [

Display

This menu allows you to select the date and time display. In the list that appears, select the desired display type between: Analog, Digital, None and validate.

Time zone

This menu allows you to change time in relation to the GMT time. Choose the time of the country desired by calculating the time from the GMT time.

Daylight savings

This menu allows you to set your phone to the summer/winter time. Select 1 h, 2 h season, and validate.

Summer time

Winter time

Select

depending on the

Shortcuts

(Function available depending on model). With this menu, you can allocate to the or key order to directly access to the function from the idle screen. You can also allocate to the navigator keys the direct access to a menu from the idle screen.

40 Settings

a function in

Active flap

If you select

Note:

in this menu (

Activate

closing the flap always hangs up, whatever the selection made

, calls are answered by opening the flap.

Activate

Deactivate

Display

This menu allows you to customize your screen by choosing a different presentation.

Wall pap er

This menu allows you to display the background picture you want on your phone.

- No wallpaper: select

- Several wallpapers in a random way: select

- A specific wallpaper: select

• Press [

selected, or

• Press the navigator: the picture is displayed. Press [

select it as your phone wallpaper or press the navigator upwards or downwards to display others.

Skins

This menu allows you to select the background picture when displaying menus.

Operator logo

This menu allows you to display your operator's logo on the idle screen (depending on model).

None

Select

Preloaded

] on the wallpaper name, the wallpaper is

Random

Select

] to

Settings

Screensaver

This menu allows you to display an animation when the phone is in standby mode.

- No screensaver: select

- Several wallpapers in a random way: select

- A specific screensaver: select

• Press [

Select

selected; or

• Press the navigator: the picture is displayed. Press [

select it as your phone screensaver or press the navigator upwards or downwards to display others.

Normal screen

] on the screensaver name, the screensaver is

Preloaded

Slide Show

Select

] to

Energy saving

Backlight

Screen only

Full backlight

Note:

be automatically turned off to save battery life.

: only the screen is lit up.

: both the screen and the keypad are lit up.

in any case, after a certain time of inactivity, the backlight will

Contacts

This menu allows you to select the way to sort contacts in the phonebook (by name or first name) and the filter applied on the contacts list display (SIM contacts, phone memory or both).

Contrast

This menu is used to adjust screen contrast. Adjust the contrast using the navigator.

Messaging

This menu allows you to select various options for sending and receiving messages (see page 26).

42 Settings

Calls

The

Calls

menu allows you to manage all the calls functions (call

forward, displaying numbers, call waiting, voicemail number, etc.).

Call divert

Depending on your subscription, this service allows you to forward incoming calls to a different number or to the voice mailbox. Choose the type of forwarding you want from the options available.

Counters

This menu allows you:

- to consult the duration of the last voice calls.

- to control the cost of your calls (*).

Display numbers

This menu allows you to modify the status of the display number function. Select one of the options given: Anonymous mode, My number, Callers’ number.

Anonymous mode

You have the ability to mask your number on the phone of the person you are calling.

Preset

: network default mode.

Yes

: you choose to active anonymous mode and then not to

display your number.

: you choose not to activate anonymous mode and then to

display your number.

(*) WARNING - Depending on how the networks and associated

subscription cards are configured, some functions may be unavailable.

Settings

Call waiting

(Operator-dependent service). During a call, you may be informed that a caller is trying to reach you: you hear a special tone. The caller's identity is displayed on the screen (name or number).

activate, deactivate, or status

You can order to check if it is active or not. During a call, if a second caller tries to contact you, the screen displays the call warning.

of the call waiting service in

Auto redial

This menu allows you to call back a caller you have not managed to reach. You can set the redial function to inactive, on request or systematic. If you choose automatically if his number is busy. If you choose automatically if his number is busy. You can also deactivate the Automatic redial service by selecting

Inactive

On request

, your phone will offer to redial your caller

Systematic

, your phone redials your caller

Blacklist

The blacklist is used to limit failures on automatic calls (calls generated by the automatic redial function or by applications: data, fax for example). When several automatic calls failed with a number (number busy or unknown), this number is put in the blacklist and no automatic call will be done with this number any more until you delete it from the blacklist.

Note

: this function does not apply to the calls performed manually.

Voicemail

This function is used to record your voicemail access number.

44 Settings

New number

After an incoming or outgoing call with a number not stored in the phonebook, this option allows you to activate or deactivate a request to store the number in the phonebook.

Networks

This menu allows you to configure network preferences.

Selection

Choose networks accessible in the area in which your are located. Choose Choose GPRS network: always, or only when needed (when launching a data connection).

to activate (automatically or manually) one of the

Preferred

to view all the pre-registered networks.

GPRS

to select the way you want to be attached on the

Security

This menu allows you to configure your phone's security settings.

PIN number

This menu allows you to activate and modify your phone's PIN. To modify the PIN, select Enter old PIN and validate. Enter new PIN twice and validate. To activate or deactivate the PIN, select the [

Select

Enter PIN and validate.

Activate

Select

PIN2 number

You have a second PIN number to allow you to access certain functions (*). Proceed as above in order to modify PIN number 2 of your phone.

(*) These functions may or may not be available depending on

your SIM card.

Settings

Deactivate

Modify PIN code

and validate.

and [

Select

Control PIN

menu and

Phone code

The Phone code menu allows you to activate the phone code so that it is requested and checked whenever the phone is switched on if a different SIM card is used. This code is automatically linked to the SIM card installed when the phone is activated, for example to protect the phone if stolen.

Check

and [

Select

Deactivate

and validate.

Modify

and validate.

Select Enter 0000 (the factory code, by default) and validate. Select

Activate

To modify the phone code, select Enter old phone code and validate. Enter new phone code and validate. Enter phone code again to confirm it and validate.

Confidentiality

This menu allows the activation or deactivation of automatic delet ion, after power off/on, of outgoing calls, messages stored or organizer events.

Activate

Deactivate

Select

and validate.

Operator

This menu allows you to modify the call barring. Access to this service depends on your type of subscription.

Call barring

This menu allows you to block the sending or receiving of certain calls. Before you can use this service, a password will be provided by your operator when you take out your subscription. Access to this service depends on your subscription type. To activate call barring:

- Select incoming or outgoing calls.

- Select the call type on which you want to activate call barring.

46 Settings

- Select:

• either

All

If roaming

• or

roaming is available, only incoming calls will be blocked.

- Select Activation and enter password.

, if you are away from your home country and if

Fixed dialling

This menu allows you to restrict the outgoing calls. The availability of this menu depends on your SIM. Enter PIN2 number and validate. Select

Activate

Deactivate

Proceed as for any other phonebook. When activating this function, only the numbers stored in the phonebook can be called. This phonebook is linked to the SIM card, and its size depends on the card's capacity.

and validate.

Browser

This menu allows you to set various parameters needed for WAP connection (see chapter

WAP

Camera

This menu allows you to set the camera features of your phone.

Timer duration

10 or 15 second time delay.

Click sound:

hear when taking a photo.

Photo format:

which your photo will be saved.

Photo quality

: this menu enables you to take a photo with a 5,

This menu allows you to select the sound you will

This menu allows you to choose the format in

: This menu allows you to select the photo quality.

Leds

This menu allows you to select the type of flashing of the LED located on the flap. Select the function then the type of flashing.

Settings

Connectivity

Headset

This menu allows you to configure the options of the phone with a pedestrian kit.

SyncML

Two selections:

Network (OTA)

organizer or your ToDos with your archives stored in your operator's network depending on the options offered by your operator with a GSM or GPRS connection from your phone.

Local

your ToDos with your archives stored in your computer. Use the Wellphone software and configure your USB connection in your phone.

: you can synchronize your phonebook, your

: you can synchronize your phonebook, your organizer or

Help

This menu allows you to activate or deactivate the display of the help in the phone.

48 Settings

Technical features

Weight: 79 g Size: 79.2 x 43.5 x 21.7 mm Original battery: Li-ion Battery life calls/standby: up to 3 h 30/250 h (these values are theoretical ones and given for information only) Multimedia objects supported:

- Audio formats: iMelody, Midi, wave, AMR, AAC (depending on

model)

- Graphic formats: bmp, wbmp, png, gif, animated gif, jpeg

Size of memory available for messages: 250 kB Size of memory available for the phonenook and the multimedia objects: 300 kB Maximum size of each message:

- SMS: < 160 characters

- MMS: < 300 kB for outgoing messages, 100 kB for incoming

messages (depends on the phone configuration and on the operator reservations)

Using temperature: from - 10 °C to + 55 °C

Technical features

Conformance Document

50 Conformance Document

Care and safety information

SAR

THIS MODEL MEETS INTERNATIONAL GUIDELINES FOR EXPOSURE TO RADIO WAVES

Your mobile device is a radio transmitter and receiver. It is designed not to exceed the limits for exposure to radio waves recommended by international guidelines. These guidelines were developed by the independent scientific organization ICNIRP and include safety margins designed to assure the protection of all persons, regardless of age and health. The guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2 W/kg and the highest SAR value for this device when tested at the ear was

1.27 W/kg (*). As mobile devices offer a range of functions, they can

be used in other positions, such as on the body as described in this user guide (**). As SAR is measured utilizing the devices highest transmitting power the actual SAR of this device while operating is typically below that indicated above. This is due to automatic changes to the power level of the device to ensure it only uses the minimum level required to reach the network. The World Health Organization has stated that present scientific information does not indicate the need for any special precautions for the use of mobile devices. They note that if you want to reduce your exposure then you can do so by limiting the length of calls or using a 'hands-free' device to keep the mobile phone away from the head and body. Additional Information can be found on the websites of the World Health Organization (http://www.who.int/emf

(*) The tests are carried out in accordance with international

guidelines for testing.

(**) Please see the

worn operation, page 54.

Care and safety information

Distance of operation

section about body

Advice for limiting exposure to radiofrequency (RF) fields

For individuals concerned about limiting their exposure to RF fields, the World Health Organization (WHO) provides the following advice: Precautionary measures: Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If individuals are concerned, they might choose to limit their own or their children’s’ RF exposure by limiting the length of calls, or using "hands-free" devices to keep mobile phones away from the head and body. Further information on this subject can be obtained from the WHO home page http://www.who.int/peh-emf June 2000.

WHO Fact sheet 193:

Safety

Never attempt to disassemble your phone. You alone are responsible for how you use your phone and any consequences of its use. As a general rule, always switch off your phone wherever the use of a phone is prohibited. Use of your phone is subject to safety measures designed to protect users and their environment. Do not use your phone in damp areas (bathroom, swimming pool…). Protect it from liquids and other moisture. Do not expose your phone to extreme temperatures lower than 10°C an higher than + 55°C. The physicochemical processes created by chargers impose temperature limits when charging the battery. Your phone automatically protects the batteries in extreme temperatures. Do not leave your phone within the reach of small children (certain removable parts may be accidentally ingested).

52 Care and safety information

Electrical safety

Only use the chargers listed in the manufacturer’s catalogue. Using any other charger may be dangerous; it would also invalidate your warranty. Line voltage must be exactly the one indicated on the charger’s serial plate.

Aircraft safety

When travelling by plane, you will need to switch your phone off when so instructed by the cabin crew or the warning signs. Using a mobile phone may be dangerous to the operation of the aircraft and may disrupt the phone network. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations.

Explosive materials

Please comply with warning signs at petrol station asking you to switch your phone off. You will need to comply with radio equipment usage restrictions in places such as chemical plants, fuel depots and at any location where blasting operations are under way.

Electronic equipment

To avoid the risk of demagnetisation, do not let electronic devices close to your phone for a long time.

Electronic medical equipment

Your phone is a radio transmitter which may interfere with electronic medical equipment or implants, such as hearing aids, pacemakers, insulin pumps, etc. It is recommended that a minimum separation of 15 cm be maintained between the phone and an implant. Your doctor or the manufacturers of such equipment will be able to give you any advice you may need in this area.

Hospitals

Always make sure that your phone is switched off in hospitals when so instructed by warning signs or by medical staff.

Road safety

Do not use your phone when driving. In order to give your full attention to driving, stop and park safely before making a call. You must comply with any current legislation.

Care and safety information

Distance of operation

This phone model has been tested and meets radiofrequency exposure guidelines when used as follows:

against the ear

as you would a wireline telephone,

body worn

accessory that contains no metal and positions the phone a minimum of 1.5 cm form your body. Use of other accessories may not ensure compliance with radiofrequency exposure guidelines. If you do not use a body worn accessory and are not holding the phone at the ear, position the phone a minimum of 1.5 cm from your body,

data operation

minimum of 1.5 cm from your body for the whole duration of the data transmission.

Accessories

We advise you the use of SAGEM brand accessories for an optimal operating of your phone and of your accessories.

: place or receive a phone call and hold the phone

: when transmitting, place the phone in a carry

: when using a data feature, position the phone a

Environment

Packaging

To facilitate the recycling of packaging materials, please obey the sorting rules instituted locally for this type of waste.

Batteries

Spent batteries must be deposited at the designated collection points.

The product

The crossed-out waste bin mark affixed to the product (including its accessories) means that it belongs to the family of electrical and electronic equipment. To promote the recycling and recovery of waste electrical and electronic equipment (WEEE) and at the same time safeguard the environment, European regulations require you to obey the sorting rules instituted locally for this type of waste.

54 Care and safety information

End User Licence Agreement (EULA), for the software

CONTEXT AND ACCEPTATION OF THE AGREEMENT

You have acquired a Mobile Phone device ("DEVICE"), manufactured by Sagem Communication (SAGEM), that includes software either developed by SAGEM itself or licensed third party Software suppliers ("SOFTWARE COMPANIES") to SAGEM with the rights to sub-license it to the purchaser of the device. Those installed software products whatever their company of origin, and wherever the name of the company of origin is indicated of not in the DEVICE documentation, as well as associated media, printed materials, and "online" or electronic documentation ("SOFTWARE") are protected by international intellectual property laws and treaties. The SOFTWARE is licensed, not sold. All rights reserved. IF YOU DO NOT AGREE TO THIS END USER LICENSE AGREEMENT ("EULA"), DO NOT USE THE DEVICE OR COPY THE SOFTWARE. INSTEAD, PROMPTLY CONTACT SAGEM FOR INSTRUCTIONS ON RETURN OF THE UNUSED DEVICE(S) FOR A REFUND.

BUT NOT LIMITED TO USE ON THE DEVICE, WILL CONSTI TUTE YOUR AGREEMENT TO THIS EULA (OR RATIFICATION OF ANY PREVIOUS CONSENT)

SOFTWARE includes software already installed on the DEVICE ("DEVICE Software") and Software contained on the CD-ROM disk ("Companion CD"), if any is supplied with the product.

GRANT OF SOFTWARE LICENCE

This EULA grants you the following licence:

DEVICE Software

on the DEVICE. All or certain portions of the DEVICE Software may be inoperable if you do not have and maintain a service account with an appropriate Mobile Operator, or if the Mobile Operator's network facilities are not operating or configured to operate with the DEVICE software.

End User Licence Agreement (EULA), for the software

ANY USE OF THE SOFTWARE, INCLUDING

. You may use the DEVICE Software as installed

COMPANION CD

personal computer is included with your DEVICE. You may install and use the software component(s) contained in the Companion CD only in accordance with the terms of the printed or online end user license agreement(s) provided with such component(s). In the absence of an end user license agreement for particular component(s) of the Companion CD, you may install and use only one (1) copy of such component(s) on the DEVICE or a single computer with which you use the DEVICE.

Security Updates

management technology. If SOFTWARE does contain digital rights management technology, content providers are using the digital rights management technology ("DRM") contained in the SOFTWARE to protect the integrity of their content ("Secure Content") so that their intellectual property, including copyright, in such content is not misappropriated. Owners of such Secure Content ("Secure Content Owners") may, from time to time, request manufacturers or SOFTWARE SUPPLIERS to provide security related updates to the DRM components of the SOFTWARE ("Security Updates") that may affect your ability to copy, display and/or play Secure Content through the SOFTWARE or third party applications that utilise the DRM. You therefore agree that, if you elect to download a licence from the Internet which enables your use of Secure Content, Suppliers may, in conjunction with such licence, also download onto your DEVICE such Security Updates that a Secure Content Owner has requested that SOFTWARE SUPPLIERS distribute. SAGEM and SOFTWARE SUPPLIERS will not retrieve any personally identifiable information, or any other information, from your DEVICE by downloading such Security Updates.

DESCRIPTION OF OTHER RIGHTS AND LIMITATIONS COPYRIGHT

SOFTWARE (including but not limited to any images, photographs, animations, video, audio, music, text and "applets," incorporated into the SOFTWARE), the accompanying printed materials, and any copies of the SOFTWARE, are owned by SAGEM or the

56 End User Licence Agreement (EULA), for the software

. If any is supplied, additional software for your

. The SOFTWARE may include digital rights

. All title and intellectual property rights in and to the

SOFTWARE SUPPLIERS. You may not copy the printed materials accompanying the SOFTWARE. All title and intellectual property rights in and to the content which may be accessed through use of the SOFTWARE is the property of the respective content owner and may be protected by applicable copyright or other intellectual property laws and treaties. This EULA grants you no rights to use such content. All rights not specifically granted under this EULA are reserved by SAGEM and the SOFTWARE SUPPLIERS

Limitations on Reverse Engineering, Decompilation and Disassembly

disassemble the SOFTWARE, except and only to the extent that such activity is expressly permitted by applicable law notwithstanding this limitation.

Single DEVICE

as a single integrated product. The DEVICE Software installed in the memory of the DEVICE may only be used as part of the DEVICE.

Single EULA

versions of this EULA, such as multiple translations and/or multiple media versions (e.g., in the user documentation and in the software). Even if you receive multiple versions of the EULA, you are licensed to use only one (1) copy of the DEVICE Software.

Software Transfer

rights under this EULA with regard to the DEVICE Software or Companion CD, except as permitted by the applicable Mobile Operator. In the event that the Mobile Operator permits such transfer, you may permanently transfer all of your rights under this EULA only as part of a sale or transfer of the DEVICE, provided you retain no copies, you transfer all of the SOFTWARE (including all component parts, the media and printed materials, any upgrades , this EULA and, if applicable, the Certificate(s) of Authenticity), and the recipient agrees to the terms of this EULA. If the SOFTWARE is an upgrade, any transfer must include all prior versions of the SOFTWARE.

Software Rental

. You may not reverse engineer, decompile, or

. The DEVICE Software is licensed with the DEVICE

. The package for the DEVICE may contain multiple

. You may not permanently transfer any of your

. You may not rent or lease the SOFTWARE.

End User Licence Agreement (EULA), for the software

Speech/Handwriting Recognition

speech and/or handwriting recognition component(s), you should understand that speech and handwriting recognition are inherently statistical processes; that recognition errors are inherent in the processes; and that errors can occur in the component's recognition of your handwriting or speech, and the final conversion into text.. Neither SAGEM nor its suppliers shall be liable for any damages arising out of errors in the speech and handwriting recognition processes.

NOTICE REGARDING THE MPEG-4 VISUAL STANDARD

SOFTWARE may include MPEG-4 visual decoding technology. MPEG LA, L.L.C. requires the following notice: USE OF THIS SOFTWARE IN ANY MANNER THAT COMPLIES WITH THE MPEG-4 VISUAL STANDARD IS PROHIBITED, EXCEPT FOR USE DIRECTLY RELATED TO (A) DATA OR INFORMATION (i) GENERATED BY AND OBTAINED WITHOUT CHARGE FROM A CONSUMER NOT THEREBY ENGAGED IN A BUSINESS ENTERPRISE, AND (ii) FOR PERSONAL USE ONLY; AND (B) OTHER USES SPECIFICALLY AND SEPARATELY LICENSED BY MPEG LA, L.L.C. If you have questions regarding this Notice, please contact MPEG LA, L.L.C., 250 Steele Street, Suite 300, Denver, Colorado 80206; Telephone 303 331.1880; FAX 303 331.1879

Termination

terminate this EULA if you fail to comply with the terms and conditions of this EULA. In such event, you must destroy all copies of the SOFTWARE and all of its component parts.

Consent to Use of Data

may collect and use technical information gathered in any manner as part of product support services related to the SOFTWARE. SOFTWARE SUPPLIERS may use this information solely to improve their products or to provide customised services or technologies to you. SOFTWARE SUPPLIERS may disclose this information to others, but not in a form that personally identifies you.

58 End User Licence Agreement (EULA), for the software

. Without prejudice to any other rights, SAGEM may

. If the SOFTWARE includes

. The

. You agree that SOFTWARE SUPPLIERS

Internet Gaming/Update Features

and you choose to utilise, the Internet gaming or update features within the SOFTWARE, it is necessary to use certain computer system, hardware, and software information to implement the features. By using these features, you explicitly authorise SOFTWARE SUPPLIERS to use this information solely to improve their products or to provide customised services or technologies to you. SOFTWARE SUPPLIERS may disclose this information to others, but not in a form that personally identifies you.

Internet-Based Services Components

contain components that enable and facilitate the use of certain Internet-based services. You acknowledge and agree that SOFTWARE SUPPLIERS may automatically check the version of the SOFTWARE and/or its components that you are utilising and may provide upgrades or supplements to the SOFTWARE that may be automatically downloaded to your Device.

Links to Third Party Sites

the ability to link to third party sites through the use of the SOFTWARE. The third party sites are not under the control of SAGEM. Neither SAGEM nor its affiliates are responsible for (i) the contents of any third party sites, any links contained in third party sites, or any changes or updates to third party sites, or (ii) webcasting or any other form of transmission received from any third party sites. If the SOFTWARE provides links to third party sites, those links are provided to you only as a convenience, and the inclusion of any link does not imply an endorsement of the third party site by SAGEM or its affiliates.

Additional Software/Services

SAGEM to provide or make available to you SOFTWARE updates, supplements, add-on components, or Internet-based services components of the SOFTWARE after the date you obtain your initial copy of the SOFTWARE ("Supplemental Components"). If SAGEM provides or makes available to you Supplemental Components and no other EULA terms are provided along with the Supplemental Components, then the terms of this EULA shall apply.

. If the SOFTWARE provides,

. The SOFTWARE may

. The SOFTWARE may provide you with

. The SOFTWARE may permit

End User Licence Agreement (EULA), for the software

SAGEM reserves the right to discontinue any Internet-based services provided to you or made available to you through the use of the SOFTWARE.

EXPORT RESTRICTIONS

subject to U.S. export jurisdiction. You agree to comply with all applicable international and national laws that apply to the SOFTWARE, including the U.S. Export Administration Regulations, as well as end-user, end-use and destination restrictions issued by U.S. and other governments.

UPGRADES AND RECOVERY MEDIA

DEVICE Software

SAGEM separate from the DEVICE on media such as a ROM chip, CD ROM disk(s) or via web download or other means, and is labelled "For Upgrade Purposes Only", you may install one copy of such DEVICE Software onto the DEVICE as a replacement copy for the existing DEVICE Software and use it in accordance with this EULA, including any additional EULA terms accompanying the upgrade DEVICE Software.

COMPANION CD

provided by SAGEM separate from the DEVICE on CD ROM disk(s) or via web download or other means, and labelled "For Upgrade Purposes Only" , you may (i) install and use one copy of such component(s) on the computer(s) you use to exchange data with the DEVICE as a replacement copy for the existing Companion CD component(s).

RESPONSIBILITIES SUPPORT AND INFORMATION

concerning this EULA, or if you desire to contact SAGEM ]for any other reason, please refer to the address provided in the documentation for the DEVICE.

60 End User Licence Agreement (EULA), for the software

. You acknowledge that SOFTWARE is

. If the DEVICE Software is provided by

. If any Companion CD component(s) is

Should you have any questions

NO LIABILITY FOR CERTAIN DAMAGES

PROHIBITED BY LAW, SAGEM SHALL HAVE NO LIABILITY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING FROM OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THE SOFTWARE. THIS LIMITATION SHALL APPLY EVEN IF ANY REMEDY FAILS OF ITS ESSENTIAL PURPOSE. FOR APPLICABLE LIMITED WARRANTIES AND SPECIAL PROVISIONS PERTAINING TO YOUR PARTICULAR JURISDICTION, PLEASE REFER TO YOUR WARRANTY BOOKLET INCLUDED WITH THIS PACKAGE OR PROVIDED WITH THE SOFTWARE PRINTED MATERIALS.

. EXCEPT AS

End User Licence Agreement (EULA), for the software

Java™

When running a Java™ application, you may be prompted to grant access to protected features. These features are protected because using them could incur you cost, or involve your personal data. In case of doubt, don't hesitate to refuse access by selecting the "No" button! The security configuration menu is an expert feature! You must know exactly what you are doing before attempting to change security parameters of a MIDlet. Misunderstanding changes may render MIDlet non functional and/or lead to higher risks for your private data or impact your airtime consumption. Any changes in the security configuration are done under your responsibility. In no case shall Sagem Communication and/or your network provider be liable for any damages deriving from or arising out of such changes in the security configuration. You must be aware that applications downloaded to your phone could cause the phone to perform actions for which you will be billed, like making calls and sending SMS. Depending on your operator's billing policy, you may also be charged to download the application because of airtime consumption.

Security considerations

Java™ MIDP technology is an efficient way to provide powerful applications in mobile phones. All these MIDP 2.0 features cannot be simply exposed to any MIDlet installed in the handset: a careful access control system is implemented in the device to protect your private data and airtime consumption. Access controls are gathered in 9 security groups:

- Network access

- Auto invocation

- Phone call

- Local connectivity

- Messaging receive

62 Java™

- Messaging sending

- Read User data

- Write User data

- Multimedia recording

Each of these security groups has one among 5 possible authorizations levels (listed from the more restrictive to the more permissive):

- Never: The security group completely prevents access to the

protected features.

- Per use: Each time MIDlet tries to use protected feature, user is

prompted to grant access.

- Per session: First time a MIDlet uses a protected function, user is

prompted to grant access like in "Per use" authorization but access is granted until the MIDlet terminates.

- Single confirmation: The first time in the whole MIDlet life a MIDlet

uses a protected feature, user is prompted to grant access. It remains valid until the MIDlet is removed from the handset.

- Always: The security group unconditionally grants access to

protected features.

A MIDlet has a security status which is either "uncertified", or else "certified". An "uncertified" status means that the source of the MIDlet could not be verified by the mobile phone at installation time. As far as the phone knows, the MIDlet could have been written by anyone. A "certified" status means that the MIDlet was digitally signed by a known party, whose name is displayed by the mobile phone. Security permissions are different for "uncertified" or "certified" MIDlets.

Security configuration menu

When a MIDlet is installed in the mobile phone, default security authorizations are applied. This default security configuration may be altered through the "Settings/Security" menu of an installed MIDlet. Once in the "Security" menu, the security status of the MIDlet is displayed.

Java™

If you do not want to enter the security menu, simply select "Back" button. You can proceed by selecting " The menu displayed allows you to increase or decrease permissions currently applied to the current MIDlet for each of the security groups. When you set a more permissive authorization to a security group than the current value, mobile phone asks you to confirm your increased risk exposure. The maximum risk exposure increase is limited by the security status.

What is Java™?

Business applications and games are easily downloadable by the end-user on a Java™ featured handset. Your mobile phone is a MIDP 2.0 compliant Java™ platform which implements WMA (SMS support) and MMAPI (Multimedia support) options, providing an exciting environment to run highly graphical, networked and intuitive MIDP applications.

What is a MIDlet?

A Java™ application or a game designed to run in a mobile phone is named a MIDlet (MIDP applet). A MIDlet is usually made of 2 files:

- The JAD file

- The JAR file

JAD file stands for describing the content of a JAR file. JAR file stands for themselves (program, images, sound). A kilo-bytes large.

Note

: In rare circumstances, MIDlet vendors may provide no JAD file

and the MIDlet is the JAR file alone. In such a case it is your only responsibility to evaluate the risk to download the JAR file without possibility of consulting the JAD file.

64 Java™

ava™ Application Descriptor. It is a small file

ava™ Archive. It refers to the application data

" button.

JAR file may be up to 200

Downloading a MIDlet (Java™ game or application)

MIDlets are easily downloaded in the mobile phone through the Games or Applications menus or through the WAP browser. In almost all cases, you will first receive a JAD file which will be displayed on the screen. When you select a JAD file, your mobile phone downloads it, displays data contained and prompts you to acknowledge the JAR file download. The popup displays information below:

- Name of the MIDlet, Version, Size, Name, Security status, URL.

If you do not want to download the main data (JAR file), you shall refuse to acknowledge further airtime consumption by selecting "Cancel". If you agree on the MIDlet installation, just select installed with security levels set to default values associated with its security status. Before downloading an application, such a message may appear: "Your handset cannot identify the application, please be sure of the source of the application before installing the application".

Trademarks

Java™ and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

Disclaimer

Some downloaded items may contain data or may induce actions which may cause malfunctioning of your mobile phone or loss or corruption of data or abnormal increase of your airtime consumption. You expressly acknowledge that the download of any applications including Java™ applications or games is done under your exclusive responsibility. In no event shall Sagem Communication, your network service provider or their affiliates be liable for any lost profits or costs of procurement of substitute goods or services, loss of profits, interruptions of business, loss of data or for any special, indirect, incidental, economic, or consequential damages arising under contract, tort, negligence, or other theory of liability relating to

. The MIDlet is

Java™

the download of any application by any means, including Java™ applications or games in SAGEM devices. You expressly acknowledge that any applications including Java™ applications or games are provided strictly «as is». Sagem Communication and/or your network service provider extend no warranty whatsoever thereto. Sagem Communication and/or your network service provider disclaim any express, implied or statutory warranty of merchantability, fitness of any applications including Java™ applications or games for a specific purpose, satisfactory quality, security or otherwise.

66 Java™

Warranty

You must always use your phone for the purpose for which it was designed, under normal operating conditions. Sagem Communication declines all responsibility for any use outside of the scope of its designed purpose and for any consequences of this use. The software program developed by SAGEM remains the exclusive property of Sagem Communication. It is therefore highly prohibited to modify, translate, de-compile or disassemble this software program or any part thereof.

Usage precautions

Your phone allows you to download ring tones, icons and animated screensavers. Some of these items may contain data that may cause malfunctions of your phone or data losses (virus for example). For this reason, Sagem Communication rejects all responsibility concerning (1) the reception of downloaded data or losses of the said data, (2) the impact on the operation of the phone and (3) damages resulting from receiving the said downloaded data or loss of said data. In addition, Sagem Communication states that a failure caused by receiving downloaded data that do not comply with the specifications set by Sagem Communication is excluded from the warranty. Consequently, the diagnosis and repair of a phone infected by the said downloaded data will be at the expense of the customer. Any content that you download to your phone may be protected by copyright belonging to third parties and consequently you may not have the right to use this content or its use may be restricted. Consequently it is up to you to ensure that you have permission, such as under the terms of a license agreement, to use any content that you download. Furthermore, Sagem Communication does not guarantee the accuracy nor the quality of any content that you download. You alone are responsible for the content that you download to your mobile phone and how you use it. Sagem Communication cannot be held responsible for this content nor for its use.

Warranty

It is your responsibility to ensure compliance, at your own expense, with the laws and regulations applicable in the country where you use your phone.

Warranty conditions

Whenever you wish to make use of the warranty, please contact your vendor and present him with the purchasing paperwork that he gave you. If a fault occurs, he will advise you.

The new phone (excluding consumables), including new accessories bundled with the phone, are guaranteed by Sagem Communication, parts and labour (apart from travel) against any manufacturing fault for a period of twelve (12) months with effect from the sale of the phone to the customer, on presentation of the paperwork stating the purchase date of the phone. Phones that have been repaired or replaced as standard during the warranty period stated above are guaranteed (parts and labour) until the later of these two dates: Expiry of the guarantee period of twelve (12) months stated above or three (3) months with effect from the date of support provided by Sagem Communication. Your legal rights under the terms of applicable national law as well as your rights in relation to your retailer, as set out in the sales contract, remain applicable and are not in any way affected by this guarantee. In any disputes, the phone is covered by the legal warranty against the consequences of faults or hidden defects in compliance with articles 1641 and subsequent of the French civil code.

All faulty phones under warranty will be replaced or repaired free of charge at Sagem Communication's option (with the exclusion of repair of any other damage), once it has been specified that the work required for the application of the warranty will be done in a workshop and that the return costs (transport and insurance) of the phone to the address to be indicated to it by the Sagem Communication after-sales service, whose phone number will appear on the delivery note, will be charged to the customer.

68 Warranty

Subject to essential legal provisions, Sagem Communication does not accept any warranty, explicit or implicit, other than the warranty provided expressly in this chapter, nor shall Sagem Communication accept responsibility for any immaterial and/or indirect damages (such as loss of orders, loss of profit or any other financial or commercial damage) under the warranty or not.

The acceptance of a phone under warranty demands that a purchase document that is legible and without modi-fication, stating vendor's name and address, date and place of purchase, type of phone and IMEI, are attached to the warranty, and that the information on the phone identification label is legible and that this label or any other seal has not been tampered with. The warranty applies in normal conditions of use. Prior to sending the phone for repair, it is the customer's responsibility to backup at his expense the customized data stored in the phone (phonebook, settings, wallpapers). A list of backup facilities can be provided by Sagem Communication on request. The responsibility of Sagem Communication cannot be invoked if damage occurs to customer files, programs or data. The information or operating elements and the contents of files will not be re-installed in any case in the event of loss. Sagem Communication may decide, at its option, to repair the phone with new or reconditioned parts, replace the phone with a new phone or, in any dispute, a phone in good working condition. During its work Sagem Communication reserves the facility to make, where necessary, any technical modifications to the phone where these modifications doe not adversely affect its initial purpose. Faulty parts to be replaced during a repair under warranty will become the property of Sagem Communication. The phone repair and standstill time during the warranty period may not lead to an extension of the warranty period as stated in article 1 above, provided no other vital provisions have been agreed. The application of the warranty is subject to the full payment of the sums due for the phone when the request for support is made.

Warranty

The following are excluded from the warranty: Breakdowns or malfunctions due to non-compliance with the installation and use instructions, to an external cause of the phone (shock, lightning, fire, vandalism, malice, water damage of any type, contact with various liquids or any harmful agent, unsuitable electric current...), to modifications of the phone made without the written consent of Sagem Communication, to a servicing fault, as described in the documentation supplied with the phone, to lack of supervision or care, to poor environmental conditions of the phone (especially temperature and hygrometry, effects of variations in electric voltage, interference from the mains network or earth) or even due to a repair, a call-out (opening or trying to open the phone) or to servicing done by personnel not approved by Sagem Communication. Damage resulting from inadequate packaging and/or poor packing of the phone sent back to Sagem Communication. Normal wear and tear of the phone and accessories. Communication problems linked with a poor environment, especially: Problems accessing and/or logging onto the Internet, such as breakdowns of the access network, the failure of the subscriber's or his correspondent's line, transmission fault (poor geographic coverage by radio transmitters, interference, disturbance, fai-lure or poor quality of phone lines...), a fault inherent to the local network (cabling, file server, user phone) and/or transmission network fault (interference, disturbance, failure or poor quality of the network...). Change of parameters of the cellular network made after the phone was sold. Supply of new software versions. Current servicing work: delivery of consumables, installation or replacement of these consumables... Call-outs for phone or software modified or added without the written consent of Sagem Communication. Faults or disruptions resulting from the use of products or accessories not compatible with the phone. Phones returned to Sagem Communication without having complied with the return procedure specific to the phone cove-red by this warranty.

70 Warranty

The opening or closing of a SIM operator key and call-outs resulting in the non-operation of the phone resulting from the opening or closing of SIM operator key done without the agreement of the original operator.

In the cases of warranty exclusion and of expiry of the warranty period, Sagem Communication shall draw up an estimate to be given to the customer for acceptance before any call-out. The repair and carriage costs (there and back) given in the accepted estimate will be charged to the customer. These provisions are valid unless a special written agreement has been made with the customer. If one of the provisions turns out to infringe a legally essential rule that consumers could have the benefit of under the national legislation, this provision will not be applied, but all other provisions will remain valid.

Warranty

Troubleshooting

The phone won’t start and/or won’t take a charge

The battery has completely lost its charge. Connect the phone to the charger for between 5 and 30 minutes. The phone will only switch on after it has been charging for a few minutes. You may use the phone again when the Start option is displayed on the screen. If the phone still won't start after 30 minutes’ charging, contact customer service.

SIM not present

Check if the SIM card is present and properly positioned / inserted. Check the condition of the SIM card. If damaged, please go back to the operator's shop for advice. Contact your after-sales service if the message persists.

Incorrect PIN code

An incorrect PIN code has been entered. Be careful! Three incorrect PIN codes will block the SIM Card.

SIM BLOCKED

If a wrong PIN number is entered three times in succession, your SIM card is blocked. You must then:

- Enter the PUK (Personal Unblocking Key) code provided by your

operator, and validate.

- Enter your PIN number and validate.

- Enter your PIN number again and validate.

After 5 or 10 failed attempts (depending on the type of SIM card), the SIM card is definitely locked. You must then contact your operator to obtain a new card.

72 Troubleshooting

SIM LOCKED

In certain cases, the handset can only be used with some types of SIM cards. This message means that the SIM card you are using does not fit with the phone. Take the SIM card out, and switch it back on. If the message need to check its compatibility next to the place where you bought it. If not, please contact your after-sales service.

No call connection

Check that the number you have dialled is correct. If the letter E is displayed on the top right corner of the screen, without any network name displayed, only emergency services can be called. Check the status of your credit. Check that the SIM Card you are using offers the service you are requesting; check if its validity has not expired. Check and deactivate the outgoing calls restriction when necessary. The network could be saturated. Try later. If the problem persists, please contact your Technical Helpdesk.

No receiving calls

Try to make a call in order to check that the phone and the network are operational. Check and deactivate the permanent call forwarding (permanent call forwarding icon displayed on the screen). Check and deactivate the incoming calls restriction when necessary. If the problem persists, please contact your Technical Helpdesk.

Quality reception when calling

Avoid placing your fingers on the top of the phone, where the aerial is integrated: the phone will have to use full strength to establish a quality transmission.

Impossible to send message

Check that the message centre number is correctly entered. To do so, please select the menu then

Msg centre n°

your network provider to get this number.

SIM not present

and check the number entered. Please contact

appears on the screen, you will

Messages

, select

Options/SMS

Troubleshooting

No voicemail

Check that your subscription does offer this service. Program the call to be forwarded to voicemail using the information provided by the operator. Try to make a call to check that phone and network are operational. Check if the voicemail number is properly configured. To do so, go to the

Settings/Calls

number. Otherwise, enter your operator’s voicemail number.

Operator name does not appear on screen

Go into the until the operator appears, select it and validate. If the Operator logo is present (depending on model), activate the

Settings/Display/Operator logo

display (

How can I increase the efficiency of my phone?

Activate the eco mode (see

74 Troubleshooting

Settings

menu, select

Voicemail

Networks

Settings/Display/Energy saving

and check the

, then

Selection

. Wait

Customer care

Austria Belgium France Germany Greece Hungary Ireland Italy Netherlands Poland Romania Russia South Africa Spain Switzerland United Kingdom

Customer Care e-mail address:

Web sites:

Customer care

01 36 02 77 16 64 02 62 77 016 0 892 701 799 (0,34 €/mn) 01805 843 850 0800 44 14 20 38 06 1 7774 839 0 160 58 355 800 800 485 020 65 45 724 0801 801 101 0800 89 45 21 495 258 54 33 011 369 7870 91 375 3376 02 25 67 53 99 0870 24 05 613

support.mobiles@sagem.com

www.sagem.com/mobiles www.planetsagem.com www.sagem-online.com

Index

28, 47

Contacts Contrast

Converter Currencies

Customer care

35 43

Date / Time Display

Energy saving

Fixed dialling

Games

Getting started

GPRS

44 43

Hands-free mode

Help

Icon

Idle screen

Input modes

21 19

Accessories Activating your phone 12 Active flip Alarm Anonymous mode

Backlight Battery

Charging the battery Installing the battery 10

Beeps

Calculator Calendar Call barring Calls

Automatic redial Call divert Call waiting Counters

Display number Camera Confidentiality Contact

Call

Delete

Mailing list

Modify

76 Index

18, 29, 30, 31

13, 42

42 35 36 75

40 41

34 13 33

15 48

11 11 23

Languages Local information

Memory Messages

Create message Drafts Inbox Outbox Receiving messages 24 Sentbox Templates

MMS

Navigator Network Networks

Operator Operator logo

Phone code Phonebook

Memory New contact

Using the phonebook Photo PIN number PIN2 number

Index

Ring tones

Safety information

Screensaver Security

Shortcut keys

Silent mode

SIM card

SMS Sounds

T9 Timer ToDo

Troubleshooting 72, 73, 74

USB

Vibrate Videos Voice mail Voicemail

Wallpaper WAP

Downloading objects WAP logging off WAP logging on

Warranty

22, 29

28, 47

25 25

14 45

46 41

19 18 18

45 45

51 42 45 40 39

10, 12

22 31

22 35 36

20, 38

39 31 25 44

32, 33

33 33 33 67



PC software, available as an option:

To exchange data between your mobile phone and your PC:

Pictures, Sounds, Video, SMS, MMS, Contacts, Calendar…

Using the 3G, EDGE or GPRS networks according to your mobile

To connect to Internet easily

phone capacities and your subscription

Bluetooth® (*)

IRDA (*)

USB (*)

For more information or to buy WellPhone

www.wellphone.com

(*) See chapter

links with your phone.

Settings/Connectivity

to know the compatible

Mobile Communication Business Group

Le Ponant de Paris - 27, rue Leblanc - 75512 PARIS CEDEX 15 - FRANCE

www.sagem.com/mobiles

Capital 300 272 000 € - 480 108 158 RCS PARIS

Société Anonyme

05/2007

Sagem MY300C User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

Description

Idle screen

Quick start

Using your phone

Phonebook

Messages

Camera

Multimedia

Games

Applications

Calendar

Settings

Technical features

Conformance Document

Care and safety information

End User Licence Agreement (EULA), for the software

Java™

Warranty

Troubleshooting

Customer care

Index
