1
GEBRUIKSAANWIJZING
MODE D’EMPLOI
OPERATING INSTRUCTIONS
WARMTE RECUPERATOR TYPE INSERT
RECUPERATEUR DE CHALEUR TYPE INSERT
HEATING APPLIANCE INSERT TYPE
MODEL SORDO 60 475.6311.100
SORDO 70 475.7311.100
SORDO 80 475.8311.100
SORDO 80 Flatline 475.8209.100
www.saeyheating.com
xxx.xxx.xxx
2
READ THESE OPERATING INSTRUCTIONS CAREFULLY BEFORE USING THE
APPLIANCE
OPERATING INSTRUCTIONS
INSERT STOVE TYPE WOOD CASSETTE
MODEL Sordo 60 – 70 – 80 and 80 flatline
Page
INDEX 2
1. GENERAL 3
2. TECHNICAL CHARACTERISTICS 4
3. FUEL: WOOD 5
4. DE FLUE 5
5. COMBUSTION AIR 6
6. INSTALLATION 6
7. INITIAL USE AND DIAGRAM 7
8. COMBUSTION PRINCIPLE 9
9. CLEANING 12
10. MAINTENANCE 13
11. TROUBLESHOOTING 15
12. GUARANTEE 16
3
1 GENERAL:
Dear user,
In purchasing this Saey insert stove you have chosen for a reputable stove. We wish you
many happy hours of cosy heating!
To get the best ecological performance and highest output from this appliance please
follow these installation and operating instructions.
The guarantee will cease to apply if the stove is damaged as a result of a failure to
follow the installation and operating instructions. The appliance must not be modified
without the manufacturer’s permission.
Only original spares made by the manufacturer should be used to repair this appliance.
If the stove is of the inset type, the prevailing laws and local architectural and fire
prevention regulations must be followed.
4
2. TECHNICAL CHARACTERISTICS:
Model
Sordo 60 Sordo 70 Sordo 80
Sordo 80
flatline
Nominal capacity kW
7,4 8,53 10,3 9,4
Maximal capacity kW
10,2 10,82 12,25 11,1
Output under nominal capacity %
64,5 63,2 59,8 60,4
Flue gas temperature under nominal
capacity °C
294 310 331 316
Flue draught under nominal capacity Pa
12 12 12 12
Average CO2 at 13% O2 Vol %
6,8 6,59 7,01 6,81
Average CO at 13% O2 Vol %
0,33 0,37 0,42 0,4
Air consumption under nominal capacity m³
34 39 47 43
Safety distances from front cm
100 100 100 100
Insert stove dimensions:
Height mm
530 600 670 800
Width mm
600 700 800 550
Depth mm
410 430 450 450
Combustion air connector Ø mm
150 180 200 200
Weight of insert stove kg
83 118 136 122
Fuel
wood wood wood wood
Consumption under nominal capacity kg
2,46 2,9 3,7 3,34
Consumption under maximum capacity kg
3,33 3,55 4,4 3,94
Maximum fuel moisture %
20 20 20 20
Maximum length of log cm
40 50 50 60
5
3. FUEL: WOOD
This stove burns wood only. The best results are obtained with dry wood. Logs sawn to size,
cleaved and stored in a well-ventilated place (at least 1 year, preferably 2), give the best
results because:
- they produce considerably more heat than damp or green wood
- they produce much less smoke than damp or green wood
- they deposit less soot on the sides of the stove, the flue and window than damp or
green wood
Solid wood dries out at the rate of 1 cm per year. It is therefore important to cleave the wood
to shorten the drying time.
When a stove is completely filled with wood it gives off more heat for a longer period. In
general, the harder the wood the better it burns.
Never use waste, chippings, wood shavings and sawdust, tree bark or waste from chipboard,
laminated wood or surface-treated wood.
Do not cut the firewood too small. Very thin pieces of wood burn for only a very short period
and are only suitable for lighting the stove. Allow large pieces with the normal dimension of
about 25 cm to burn naturally. Large logs must be chopped small.
ONLY DRY WOOD PREVENTS EMISSIONS OF HAZARDOUS
SUBSTANCES WHEN BURNING!
PLEASE NOTE! The stove is not a waste incinerator. The environment legislation expressly
forbids the burning of waste in household fires. Not only is it environmentally unfriendly to use
a solid fuel stove incorrectly to burn household waste, chemically treated wood waste or waste
paper, or to use it as a private waste incineration plant, but it is also in breach of the emission
laws and liable to punishment.
The appliance is not suitable for burning liquid fuels.
Besides creating high and unchecked air pollution, harmful combustion products and
combustion residues also have a negative effect on the working and operating life of the stove
and flue. This results in all kinds of defects and rapid wear, which may require expensive
remediation and even replacement of the stove.
The burning of unsuitable fuels can lead to a house fire of the type not covered by your fire
insurance.
4. THE FLUE
Before connecting the stove to the flue check that the dimensions and quality of the flue
satisfy local regulations. The dimensions will need to be calculated.
The flue must be cleaned every year and cleaned in accordance with local regulations.
6
What should I do in the event of a chimney fire?
We advise the following steps in the case of a chimney fire:
1. Close the air supply
2. Inform the fire brigade.
3. Allow access to the cleaning hatches (e.g. cellar and loft).
4. Remove all combustibles from the flue.
5. When next using the stove have the flue and stove checked by an expert.
6. This expert should also trace the cause of the chimney fire and take steps to prevent it
in future.
Please note: ·If you set the stove to maximum output for ten minutes once a day this will help
burn off tar deposits. This reduces the risk of a chimney fire, and at the same
time helps keep the window clean.
5. COMBUSTION AIR
As opposed to a normal fire, an SAEY insert stove uses little combustion air. For most homes
the air coming in through the cracks and gaps of doors and windows is sufficient. However, in
some well-insulated homes this air supply may not be sufficient. In such cases it will suffice to
place a ventilation grille in the outside wall, as close as possible to the appliance.
Under no circumstances should you allow air to come in from rooms or cellars
containing volatile or inflammable substances.
Saey insert stoves can only be used when the door of the insert stove is closed. For the air
consumption of your particular insert stove see the table in point 2.
Take account of other heating appliances or air outlet installations in the same area or on the
same combustion air connection.
If needs be the combustion air connection should be calculated, or a separate supply of
combustion air installed outside.
If 15 minutes after lighting the fire there is still a backdraft of flue gasses due to weather
conditions (e.g. fog, storm,…) stop lighting the fire until the weather improves.
Tip:
be sure to take account of extractors which might be connected in the vicinity of the
stove. These create underpressure, which can lead to disruptions in the supply of combustion
air. The combustion gas which escapes is lethal and can damage the health of the people
living in your home.
6. INSTALLATION
When using cement inside or outside the chimney wait 7 days before using the stove, to allow
the cement to dry out and prevent cracking during the drying process.
The stove can give off quite a lot of smoke when used for the first time. These are not
combustion gasses but smoke from the high heat-resistant paint which dries and bakes in.
This smoke is not toxic but nonetheless it is recommendable to ventilate the room (for about
20 minutes). It is not recommended to touch the paint during this period.
7
All local regulations, including national and European standards, must be followed when
installing the appliance.
Only an appliance connected by an accredited installer guarantees compliance with the
architectural and fire prevention regulations. These rules must be followed to ensure the
correct and safe operation of the stove.
The flue is extremely important in connecting the stove. Be sure to consult authorised
specialists about the connection to ensure compliance with the respective regional building
regulations.
Bear the following in mind:
• The appliance can only be used when the door is closed. The doors of the insert
stove must also be closed when the appliance is not in use.
• There must be an adequate supply of fresh air when the appliance is in use.
Fire safety measures relating to combustible or temperature sensitive floor coverings:
• A fire-resistant, non-combustible covering (e.g. marble, tiles, special heat-resistant
insulation, etc.) must be fitted under and around the insert stove. This must be of
sufficient thickness.
• No combustibles or temperature sensitive objects must be stored under the
appliance (e.g. firewood).
Bear the following in mind as regards the diameter of the flue pipe:
• Do not narrow the diameter of the flue pipe. The flue pipe must be a perfect fit for the
flue.
• If the flue draught is too big you will need to incorporate a draught regulator.
• The stove tube must not be smaller than the diameter of the flue; this impedes the
upward pressure of the flue gasses.
• Flue connections to the various combustion points must not be opposite each other or
at the same point, to prevent combustion gasses from not being discharged. Any two
smoke outlet pipe connections must be at least 30 cm apart.
• The flue must not have too many connections – this restricts upwards pressure.
Consult your flue specialist!
• The flue must not supply empty air. Pay attention to closed flue hatches and cleaning
hatches in the cellar or loft!
• The flue pipe must be safely connected to the connector pipe.
• The safety distances from combustibles or temperature sensitive objects given in the
table of technical details must be applied.
7. INITIAL USE AND DIAGRAM
It is important that you run your store in, in the same way you would a car - in WITH DUE
CARE and PROGRESSIVELY! On your first days you should burn 1 to 2 kg of wood. A low
flame and appropriate level of heat will allow stresses in the steel to dissipate and will allow
the entire installation to dry out.
Even after the appliance has been burning for a while it is best to avoid keeping fires lit for too
long, or at too high an intensity.
The small gain is heat is not worth the risk of damaging your appliance.
8
DIAGRAM
Sordo 60 – 70 – 80 and 80 flatline
Fig. 1
A. : Cold air inlet (convection)
B. : Hot air outlet (convection)
C. : Combustion air regulator
D. : Catch
OPENING AND CLOSING THE DOOR
Place the handled supplied in the opening of the catch (D).
Pull the catch towards you to open the door and push it away from you to close it.
The edges of the stove can become extremely hot. We recommend that you use heat
resistant gloves.
Fig. 3
D
9
8. COMBUSTION PRINCIPLE
This stove was developed for semi-slow burning. Loaded fully with wood and operating on a
slow burn the stove will burn through the night with sufficient embers left over the next day to
relight the fire.
It is also possible to set the stove to a very slow burn (no flames).
We do not recommend this for the following reasons:
a) it causes insufficient burning which pollutes the air extremely heavily and unnecessarily
b) this inadequate burning gives rise to extra smoke which deposits tar on the sides of the
stove, the flue and the window when condensing. An accumulation of tar is not only
unsightly but requires regular cleaning of the flue to prevent a chimney fire.
If you are burning damp or green wood the combustion air regulator must be sufficiently open
to obtain a good flame (see next page).
HEAT EMISSION:
the stove gives off two types of heat:
a) heat emission by radiance.
Heat radiates in a straight line from a hot surface. Besides the fire, the main sources of
heat radiation are the hot ashes and the vermiculite sides covering the stove. This radiation
is sent out into the room via the window and heats the immediate environment of the stove.
b) heat emission by convection.
Heat convection occurs when air in contact with a hot surface rises.
Cold air enters the stove via the air inlet (A). This air passes over the bottom of the stove,
then via the back to the ceiling of the combustion chamber before exiting via the hot air
outlet (B).
10
SETTINGS
Combustion air regulator (C)
This controls the amount of air needed for combustion and therefore the heat produced.
It is located on the top right-hand side of the door (see figs 1 and 2).
Open: slide to the right
Close: slide to the left
The greater the supply, the more air is allowed into the stove, the more heat the stove
produces, and the more wood is consumed.
The more the supply of air is restricted, the less heat the stove produces, and the less
wood the stove consumes.
The regulator is at the top of the door, to create an "air-wash" system over the entire
surface of the window. This helps keep the window cleaner for longer.
Fig. 4
LIGHTING
"TOP-DOWN" BURNING
The highest output is achieved by means of "top-down" burning. To achieve this,
do not fill the stove in the traditional way.
- Traditional way: what is meant here is laying down paper first, then kindling and finally
large logs. With this method the load is, however, limited when lighting the fire.
- "TOP-DOWN" burning: this is done by loading the large logs first, then the smaller
pieces, and the paper on top.
In this case combustion takes place from the top down and is known as "TOP-DOWN"
burning.
COLD START
1. Open the combustion air inlet fully (C).
2. Open the door.
3. Place the large logs carefully on the bottom.
4. Cover it with smaller logs, and on top of this lay firelighters or paper and finally kindling.
5. Light the fire and close the door.
6. Leave the combustion air inlet fully open until the wood is burning and the ashes glow.
7. Choose an appropriate burning regime and pick a setting.
C
11
RELOADING
1. Open the air inlet fully (C)
2. Open the door carefully.
3. Use the poker to spread the glowing logs over the bottom.
4. Place new logs on the embers.
5. Close the door and allow the fire to resume.
6. Select a setting.
PLEASE NOTE!
It is recommendable to load no higher than the vermiculite walls, or to load no more wood
than the normal quantity given in table 2.
POSSIBLE SETTINGS
The stove has a higher output when the door is closed. In this way it produces heat in
completely safety by radiation and convection.
We can choose from 3 possible settings.
A. Very high convection and radiation heat emission.
High wood consumption.
Open the primary air inlet completely to obtain a keen and fast flame. This setting should
be used only to light the fire. Once the stove is hot, select another position (see B or C).
B. Very high convection and radiation heat, moderate wood consumption with minimum
pollution and maximum output. Gradually close the air regulator to maintain a good flame
without burning intensely. At this setting a fully loaded appliance should be able to burn
all night and still give off good convection heat. Using extremely dry wood and an
appropriate flue draught, the window will stay clean for longer.
C. Average convection and radiation heat - low wood consumption. Close the air regulator
until the flame almost extinguishes. In this way the stove will burn all night (depending on
the flue draught) but the window will become dirty because combustion is not complete.
The choice of setting depends on the choice of capacity and the flue draught. The flue draught
can also be dependent on weather conditions.
To remind you, the more open the air regulator, the greater the radiation but with less heat
convection, and, more particularly, greater wood consumption. For maximum heat and output
choose setting "B".
9. CLEANING
12
It is recommended to clean the stove when it is cold.
WINDOW
In most cases the window "Air wash" system and the vermiculite covering on the walls help
keep the window clean for longer.
However, if the window becomes dirty, you should:
1) open the door
2) use a spray or cleaning gel on the inside of the window. Apply with care because most of
these products are caustic.
3) allow to penetrate
4) wipe away the tar using a damp cloth, then polish with paper or a cloth. Pressing the
damp cloth in the ashes first may help remove some of the more stubborn deposits. The
ashes have a ‘scouring effect’.
NEVER USE CAUSTIC PRODUCTS WHEN CLEANING THE APPLIANCE
REMOVING THE ASHES
The stove must be cleaned on a regular basis.
This can be done using the shovel provided, which works as a shovel or scraper if turned
around. Please note, leaving a bed of ashes on the bottom (± 1 cm) improves combustion Æ
combustion in the ashes.
1. Open the door.
2. Use the poker supplied to push glowing embers to one side for later use to relight the fire.
3. Push ashes to the other side.
4. Remove the ashes from the stove (with the shovel)
5. Spread the glowing embers evenly over the bottom of the stove.
6. Place new logs on the glowing embers.
PAINTED FRONT
Dust the remaining ashes from the painted parts using a soft hand brush or cotton cloth.
Never wash the stove with water!
10. MAINTENANCE
RESPRAY
The appliance can be resprayed with a heat resistant paint, which is available at your point of
sale. Do not use any other type of paint. Only respray the appliance when it is cold. Before
spraying be sure to cover all parts of the stove that do not need to be sprayed (window and
fireplace, for example), and to degrease any parts to be resprayed. Carefully follow the
instructions on the spray can.
13
CLEANING THE FLUE
The flue must be swept every year. To do this the smoke damper must be removed from the
appliance. To remove the smoke damper follow the instructions below with care.
How to remove the smoke damper
1) After opening the door you can remove baffle plate D. To do this, place your hand on
catch C and push the back of the catch upwards. Catch C at the back will now have
come free from smoke damper E and you can move it towards you. The catch can
now be removed from the smoke damper. See photos 1 to 5.
Please note:
Catch C for the smoke damper has a front ( A ) and back ( B ). Remember these
directions when reassembling. Baffle plate D also has a front ( A ) and back ( B ) which
you will also need to bear in mind.
2) You can now remove baffle plate D by raising the left-hand side and lowering the righthand side, so that the right-hand side can be turned to the front and the plate removed.
See photos 6 to 9.
3) Smoke damper F is removed by sliding it to the back and pulling down. See photo 10.
4) To reassemble the whole work in reverse order. Be sure when reassembling that you
first mount the smoke damper operating shaft F (photo 12) in the guide hole G (photo
6) before placing the grooves of smoke damper E over the fixings. Now shift smoke
damper E to the front to prevent it from dropping.
14
15
BROKEN WINDOW
The pyroceramic window is solidly made and will not crack through heat. However, it can be
broken through a lack of care. Read and apply the tips below to avoid damage.
1. Never allow logs to protrude from the front or the front log will break the window.
2. When filling the stove with logs, make sure than none can roll into the window.
3. Do not press unnecessarily hard when cleaning the window.
4. When using for the first time check the window tension (new appliance and on initial
use after the summer). There should be a little play in the window - if not, remove any
stress before using the appliance for the first time.
If your window does break, consult your installer.
REPLACEMENT OF A BROKEN WINDOW (for the installer)
1. Remove the broken glass from the door.
2. Lift the replacement window and place it in the top rim of the door, the bottom edge of the
window falls into the bottom rim of the door.
3. Push the window from top to bottom against the door seal.
In some cases it may be necessary to completely replace the seal.
16
11. TROUBLESHOOTING
Abnormal operation is usually the result of incorrect usage.
If you are of the opinion that something is not working as it should, check the following.
If you are unable to resolve the problem, then contact your installer.
Symptom Possible cause Remedy
The stove smokes 1. wood is damp or too green 1. use dry wood
2. flue draught insufficient
and requires cleaning
2. clean flue
Warm-up time abnormally
long
1. wood is too damp to too
green
1. use dry wood
2. flue requires cleaning 2. clean flue
Fire goes out overnight 1. insufficient wood in the
stove
1. load more wood
2. wood too soft (e.g. pine) 2. use hard wood
3. poor door seal 3. replace seal
4. wrong air inlet regulation 4. depends on flue draught
The stove goes out 1. wood damp or green 1. burn dry wood
2. stove not up to
temperature
2. allow stove to come to
temperature before closing
primary air inlet
Window gets dirty 1 lack of flame 1. progressively and slowly
open the primary air inlet to
maintain a slow flame
2. wood is damp or green 2. use dry wood
BEWARE! CHILDREN PLAYING!
Stoves get hot! Particularly the top plate, the protective housing and the
glass.
Do not light the stove until you are sure that there are no
children playing nearby.
The safety measures cannot cover all eventualities.
KEEP YOUNG CHILDREN AWAY FROM THE STOVE!
17
12. GUARANTEE
Your Saey appliance has a 2-year guarantee on all manufacturing faults from the date of
purchase, provided it is used in compliance with the operating instructions. Your receipt or bill,
stating the date of purchase is your proof of guarantee.
This guarantee is confined to the repair or replacement of any part found to be defective
through normal use.
This guarantee does not apply to defects resulting from poor installation, improper use,
modification of the appliance, dismantling of the appliance, wear or lack of maintenance.
All queries of your guarantee to made via your point of sale.
SAEY
Home & Garden NV.
Industrielaan 4
B – 8501 KORTRIJK - Heule
Belgium
www.saeyheating.com
Loading...
