E-PAK
E-PAK
PERSONAL
PERSONAL
ELECTRONICS
ELECTRONICS
MAGNETIC
MAGNETIC
POUCH
POUCH
www.saddlemen.com
3502-0208
FEATURES OF THE E-PAK:
• The best way to bring your smart-phone, GPS or other personal electronics on your motorcycle - you can easily see the
device’s screen and controls through the pouch's large window.
• Sized to be used with modern smart phones, but can also be used with a variety of GPS units. The pouch can be oriented to
match the screen format of your device.
• Strong magnets keep the weather resistant pouch secured to your metal fuel tank. Each magnet is shielded to prevent
interference with your device's electronics.
• Spacious electronics compartment (5.0-inches wide x 3.5-inches long x 0.75-inches tall) includes a removable plush pad and
foam mat you can trim to custom fit your device to the pouch.
• The large plastic window transfers electrostatic energy so you can operate the touch screen on your device (with a bare finger
or special electrostatic-transmitting gloves).
• Rubberized pouch back protects your bike's paint finish while the long perimeter zipper let's you easily stow or remove your
device from the pouch.
• Double zipper fob entry system lets you easily insert your device and permits power or audio cords to route into the pouch.
READ THESE INSTRUCTIONS THOROUGHLY BEFORE INSTALLATION!
Your attention to these installation instructions and recommendations will permit safe and proper use of this accessory. You must mount this accessory properly and
securely before riding your motorcycle.
seek out a qualified motorcycle technician for assistance. Using or mounting this accessory improperly could result in a loss of control of the motorcycle which could result
in damage to your motorcycle or other personal property, the property of third parties, and/or personal injury to yourself or others, up to and including death.
BE SURE TO THOROUGHLY READ AND CLOSELY FOLLOW THE MOUNTING INSTRUCTIONS THAT ARE INCLUDED WITH THIS ACCESSORY:
• Your Saddlemen accessory pouch must be installed and securely attached to the fuel tank or similar foundation on the motorcycle.
• Install the pouch so it will not shift or move while riding. Make sure the accessory or any related cords will not contact any moving parts of the motorcycle.
• If you do not understand the mounting instructions DO NOT mount the pouch.
• Thoroughly inspect your motorcycle accessories before every ride. Do not use the pouch it has been modified, or if it has deteriorated, loosened, or is beginning to fail.
• Before riding, secure your device inside the pouch and completely close all zippers.
• Continually check the security of your accessory pouch at each stop as you ride. Mounting magnets can shift during operation, so be sure to check it frequently.
• Do not use this accessory if you have any doubts as to whether it is properly mounted to your motorcycle.
• Do not transport or store flammable, or potentially explosive materials in your accessory pouch.
• If your accessory is ever damaged, do not use it until it has been inspected by your local professional motorcycle dealer. Replace the E-PAK immediately if it has damage
that will prevent it from being properly secured to your motorcycle or being able to securely hold its contents.
DO NOT ATTEMPT TO USE THIS ACCESSORY IF:
• You do not understand these installation and use instructions, or if you do not understand any part of the accessory mounting system, or you have any doubts as to the
security of the mounting system.
If you do not understand the Mounting Instructions DO NOT mount the accessory and remove any other items you may have installed on your vehicle. Contact your local
professional motorcycle dealer for assistance, or call the Saddlemen support line at (310) 638-1222.
Remember: Motorcycling can be a dangerous activity. Installation of any accessory can increase your risk if it is not installed properly. You are responsible to install this
accessory so it will not contact any portion of the drive train, suspension or steering, and so that it will in no way interfere with the operation of your motorcycle.
You are responsible for the proper installation of this accessory. If you lack the ability to safely and properly install this accessory,
PADDED MAT & ADJUSTMENT FOAM:
Y our E-P AK is delivered with a padded, vinyl covered mat 2 that is intended
to press your device 1 against the pouch’s clear window 4 permitting
easy viewing and touch-screen control.
Also included is a raw foam strip 3 you can trim or cut to shape in case
you need to hold your device in a particular position within the pouch. The
foam can be trimmed easily with a scissors.
The images in this instruction set may be different than your accessory or motorcycle. Continued on next page...
www.saddlemen.com
17801 SOUTH SUSANA ROAD, RANCHO DOMINGUEZ, CA 90221
11
1
11
22
2
22
33
3
33
44
4
44
(310) 638-1222 1 / 2
(rev2 10-28-2013) 11-400271
TWIN ZIPPER FOBS & CORD ROUTING:
The E-PAK is equipped with a zipper 5 that goes around 75% of the
pouch’s circumference to permit easy installation and removal of your
electronic device.
The E-PAK is slightly oversized so you can connect audio or power cords
6 to your device when it is stowed inside the pack.
You can use the twin zipper fobs 7 to control which direction a power or
audio cord 8 will route from the E-PAK. Once you have your device and
cord in place, close the zipper fobs to secure the pouch.
FUEL TANK SURFACE - IMPORTANT:
Before placing the magnetic E-PAK on your motorcycle’s fuel tank,
make sure no metallic objects are clinging to it’s rubberized mounting
pad. This plush mounting pad is designed to be soft the fuel tank’s
surface and to provide good grip for the pouch. If the fuel tank’s
surface gets dirty you can damage the finish under the E-PAK, so
clean under the pouch frequently. For additional fuel tank surface
protection you can obtain and install the Saddlemen Protective Tape
Kit (#4320-0807).
88
8
88
77
7
77
55
5
55
77
7
77
66
6
66
IMPORTANT:
Failure to mount this accessory properly may it or any related wires or cords to come into contact with the motorcycles’s
moving parts or controls. It is vital that you verify that neither the accessory, nor any related item can touch, or interfere
with, other motorcycle components while the steering or suspension moves through its entire range of motion. Make
sure that the accessory or related item cannot come into contact with the exhaust or any other component of the motorcycle,
as other vehicle components may be damaged by contact with this accessory. It is your responsibility to make sure the
installation of this accessory does not create an unsafe or illegal condition. Inspect the E-PAK more often if you are riding
your motorcycle in wet or rough conditions. Inspect the accessory and related items before and during each ride. A loose
accessory can interfere with the vehicle’s operation and cause an unsafe riding condition.
CARE OF YOUR SADDLEMEN E-PAK:
Your E-PAK requires almost no maintenance, other than periodic cleaning with mild soap and water.
SADDLEMEN LIMITED ONE-YEAR WARRANTY
Saddlemen warrants this product for defects in materials, design or workmanship for a period of one year after retail
purchase. Items that are defective will be repaired or replaced by Saddlemen at its sole discretion. Damage caused by
improper use or improper installation is not a defect; therefore repair or replacement of a damaged accessory will not be
covered under this warranty . This warranty contains other provisions and conditions, so please visit
for more information. Thank you for purchasing your Saddlemen E-PAK. You can count on Saddlemen's quality, innovation, service and style. We want you to be completely satisfied. If you have any comments, or are not satisfied with the
performance of your accessory, please contact your retailer directly, or call the Saddlemen support line at (310) 638-1222.
www.saddlemen.com
www.saddlemen.com
The images in this instruction set may be different than your accessory or motorcycle.
17801 SOUTH SUSANA ROAD, RANCHO DOMINGUEZ, CA 90221
(310) 638-1222 2 / 2
(rev2 10-28-2013) 11-400271
