SAC AE0584PRO User Manual

Page 1

①

②

③

This product d istri butes 1 way HDM I signal from STB, D VD, Blu Ray pl ayers or PS3 etc . to 4 way HDMI si gnal to connect to project or, DLP, LCD o r other HD di splays simult aneously.

Box Conten t

1. Safe ty Notes:

1). In order t o avoid fire, elect ricity shock or p roduct damage, please keep the pr oduct away fro m rain, dam p, any other liquid, and pressure .

2). All parts should keep a way from shaki ng sharply, n o collision, knocking, or fa lling down to avoid damage.

3). When you unplug t he power adapter, p lease hold the p lug, but not the line.

4). Please power off w hen it's

not in use and unplug the

power adapter if does not use t his splitter for l ong time.

5). Do not open the housi ng or modify the m odule.

6). Worki ng power is 5V/1 A. Please check the powe r adapter paramete rs before you change it.

7). Please keep the user manual f or futur e refer ence.

2.Installa tion Requirement

HDTV or other di splay wit h HDMI port

HDMI video source, such as, DVD, PS3 , STB, PC, etc.

26AWG HDMI cable or better

3. Installa tion Steps

HDMI display HDMI display HDMI display HDMI display

HDMI video source

DC5V/1A

Please connect the devices accor ding to t he above image, and operate

as followi ng steps:

①. Connect the HDMI vi deo source output port t o the splitter

input port by HDMI cable.

②. Connect the splitter output por t to HDMI displ ay by HDMI

cable,

③. Adjust the HDM I display i nput signal channel as HDMI ④. Power on t he converter.

4. Features

1) HDMI splitter funct ion

Connect all the devi ces according t o Installati on steps, th is device work s as HDMI splitter, it can d istri bute 1 HDMI source to 4 HDMI di splays simult aneously.

2) HDMI splitter + extende r

If you want to extend th e signal longer, pl ease make sure to use longer standard HDMI cabl e (refer to HDM I

cable's specification, 26AW G can extend 30M), th e Max dis tance this device suppor ted is 30me ters fo r input and 25meter s for output. If there's n o image shown when HDMI cable i s 15meters o r longer, please adjust t he switc h on the splitter.

Output Output

Input

Output Output

④

4Kx2K 1x4 HDMI Spli tter

DC 5V/1A power adapt er

User Manual

www.sacelectronics.co.uk

AE0584PRO

Max. Data rate

10.2Gbps

HDMI Input

HDCP Compliance

HDMI Resolution support

480i@60Hz、480p@60Hz、 576i@50Hz、576p@50Hz、 720p@50/60Hz、1080i@50/60Hz、 1080p@50/60Hz、1080p@24Hz 3D、 720p@50/60Hz 3D, 4K X 2K

Yes

HDMI graphic resolution support

640x480@60Hz、800x600@60Hz、 1024x768@60Hz、 1280x720@60Hz、 1280x768@60Hz、1280x960@60Hz、 1280x1024@60Hz、1360x768@60Hz、 1366x768@60Hz、1400x1050@60Hz、 1440x900@60Hz、1600x900@60Hz、 1680x1050@60Hz、 1920x1080@60Hz

Color format support

24-bits /Deep col or 30 bits / Deep color 36-bit s

4) CEC support

To realize this f unction, both th e input and output device m ust support CEC (refe r to the device m anufacture r's specifi cation) After connection, every remo te control of t he connected devices can control al l of the connecte d devices.

5) 4K*2K s

upport

This splitter can support t he resolut ion up to 4K *2K., when both the input and output devices support 4 K*2K, th e output resolutio n can reach 4K*2 K.

Output

≤

25meters

≤

Input

30me ters

3) 3D support

If HDMI video sourc e and all the HDM I displays support 3 D signal, thi s splitter can detect the E DID automa tically and support 3D output.

Input is HDMI 3D si gnal

3D display

Note: To reach 4 K*2K, all c onnected HDMI cables must

be shorter tha n 5 meters.

5. Trouble shooting

Q: No imag e output A: 1) Please check and make sur e all the connect ion is

correct and workin g status L ED is blue.

2) Please check the i nput and output HDMI cable and make sure they are w ell connected.

3) Please make sure t he HDMI video sour ce device output channel is HD

MI.

4) Please make sure t he HDMI displ ay input channel is HDMI.

5) Please adjust th e EXTENDER swit ch according to the length of HDMI cables.

6) Please change the i nput or output HDMI cable .

7) Please unplug and p lug the pow er adapter and re-power t he splitter.

6. Specifications

Item

noitpircseD

Features

HDMI Splitter

Distri bute 1 HDMI s ource t o 4

HDMI displays simu ltaneously

Extend HDMI signal up to 30

HDMI Extender meters for input and 25 me ters

for output

HDMI Resolution

U p to 4K X 2K and support ful l

3D foma t

With energy-saving technology, power consumption is a

s low as

Energy-Sav ing

Power supply mode

Power adaptor 5V

/1A

Power

Voltage Consumption

DC 5V <5W

Disclaimer

The product name and brand name may be registered trademark of rela ted manufacturers.TM and ® may be omitted on the user manual. T he pictures on the user manual are just for reference,and there may be some slight difference with the real products.

We reserve the rights to make changes without further notice to a product or system described herein to improve reliability, function or design.

TMDS signal 0. 5 ~1. 5Vpp(T

MDS) DDC signal 5Vp-p(TTL)

The length fo r HDMI cable

<=30m(AWG26 standard HDMI cable)

HDCP Compliance

Yes

HDMI Resolution support

480i@60Hz、480p@60Hz、 576i@50Hz、576p@50Hz、 720p@50/60Hz、1080i@50/60Hz、 1080p@50/60Hz、1080p@24Hz 3D

、

720p@50/60Hz 3D, 4K X 2K

Color format support

24-bits /Deep col or 30 bits / Deep color 36-bit s

HDMI Output

Max. Data rate

10.2Gbps

Protection Type

ESD protectio n

1a Socketed discharge Level 3 1b Air discharge Level 3 Executive standard：IEC61000-4-2

Operating Environment

Oper a tio n Temperature Sto r a g e Temperature

Relative Humidity (non-condensing)

-10 ~55℃

-20 ~70℃

0 ~95%

Dimension (L×W×H)

156mm×79mm×17mm

Material Color Weight

Aluminum alloy

Black

205g

Product

Reliability

(MTBF)

>30000 hours

DDC signal 5V p-p(TTL)

The length fo r HDMI cable

<=25m(AWG26 standard HDMI cable)

TMDS signal 0. 5 ~1.5Vp-p(TMDS )

HDMI graphic resolution support

HDMI Output
