Ryobi HG500QP User Manual [en, es, fr]
OPERATOR’S MANUAL
MANUEL D’UTILISATION
MANUAL DEL OPERADOR
VARIABLE TEMPERATURE
HEAT GUN
DOUBLE INSULATED
PISTOLET THERMIQUE VARIABLE
DOUBLE ISOLATION
PISTOLA DE AIRE CALIENTE VARIABLE
DOBLE AISLAMIENTO
HG500
ITEM NO. HG500QP
(ARTICLE NO. / ART. NÚM. HG500QP)
This heat gun has been engineered and manufactured to our high standard for dependability, ease of operation and operator safety.
When properly cared for, the heat gun will give you years of rugged, trouble-free performance.
WARNING
To reduce the risk of injury, the user must read and understand the operator’s manual before using this product.
Thank you for buying a Ryobi® product.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Ce pistolet thermique a été conçu et fabriquée conformément
à nos strictes normes de fiabilité, simplicité d’emploi et sécurité
d’utilisation. Correctement entretenue, elle vous donnera des
années de fonctionnement robuste et sans problème.
AVERTISSEMENT
Pour réduire les risques de blessures, l’utilisateur doit lire et
veiller à bien comprendre le manuel d’utilisation avant d’utiliser
ce produit.
Merci d’avoir acheté un produit Ryobi®.
CONSERVER CE MANUEL POUR
FUTURE RÉFÉRENCE
Su pistola de aire calienteha sido diseñado y fabricado de
conformidad con nuestras estrictas normas para brindar
fiabilidad, facilidad de uso y seguridad para el operador. Con el
debido cuidado, el taladro le brindará muchos años de sólido
funcionamiento y sin problema.
ADVERTENCIA
Para reducir el riesgo de lesiones, el usuario debe leer y comprender el manual del operador antes de usar este producto.
Le agradecemos la compra de un producto Ryobi® .
GUARDE ESTE MANUAL PARA
FUTURAS CONSULTAS
TABLE OF CONTENTS
Introduction ..................................................................................................................................................................... 2
Warranty .......................................................................................................................................................................... 2
Important Safety Instructions ....................................................................................................................................... 3-4
Specific Safety Rules .................................................................................................................................................... 4-5
Symbols ........................................................................................................................................................................... 6
Electrical .......................................................................................................................................................................... 7
Features ........................................................................................................................................................................... 8
Assembly ......................................................................................................................................................................... 8
Operation .................................................................................................................................................................... 9-10
Maintenance .................................................................................................................................................................. 11
Figure Numbers (Illustrations) ........................................................................................................................................ 13
Parts Ordering / Service ................................................................................................................................... Back page
INTRODUCTION
This tool has many features for making its use more pleasant and enjoyable. Safety, performance, and dependability have
been given top priority in the design of this product making it easy to maintain and operate.
WARRANTY
RYOBI® POWER TOOL - LIMITED TWO YEAR WARRANTY AND 90 DAY EXCHANGE POLICY
One World Technologies, Inc., warrants its RYOBI® power tools with the following conditions:
90-DAY EXCHANGE POLICY: During the first 90 days after date of purchase, you may either request service under this
warranty or you may exchange any RYOBI® power tool which does not work properly due to defective workmanship or
materials by returning the power tool to the dealer from which it was purchased. To receive a replacement power tool or requested warranty service, you must present proof of purchase and return all original equipment packaged with the original
product. The replacement power tool will be covered by the limited warranty for the balance of the two year period from
the date of the original purchase.
WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI® power
tool for a period of two years from the date of purchase. With the exception of batteries, power tool accessories are warranted for ninety (90) days. Batteries are warranted for two years.
HOW TO GET SERVICE: Just return the power tool, properly packaged and postage prepaid, to an Authorized Service Center. You can obtain the location of the Service Center nearest you by contacting a service representative at
One World Technologies, Inc., P.O. Box 1207, Anderson, SC 29622-1207, by calling 1-800-525-2579 or by logging on to
www.ryobitools.com. When you request warranty service, you must also present proof of purchase documentation, which
includes the date of purchase (for example, a bill of sale). We will repair any faulty workmanship, and either repair or replace
any defective part, at our option. We will do so without any charge to you. We will complete the work in a reasonable time,
but, in any case, within ninety (90) days or less.
WHAT’S NOT COVERED: This warranty applies only to the original purchaser at retail and may not be transferred. This
warranty only covers defects arising under normal usage and does not cover any malfunction, failure or defects resulting
from misuse, abuse, neglect, alteration, modification or repairs by other than Authorized Service Centers. One World Technologies, Inc. makes no warranties, representations or promises as to the quality or performance of its power tools other
than those specifically stated in this warranty.
ADDITIONAL LIMITATIONS: Any implied warranties granted under state law, including warranties of merchantability or
fitness for a particular purpose, are limited to two years from the date of purchase. One World Technologies, Inc. is not
responsible for direct, indirect, or incidental damages, so the above limitations and exclusions may not apply to you. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
2 - English
IMPORTANT SAFETY INSTRUCTIONS
WARNING:
Read and understand all instructions. Failure to follow
all instructions listed below may result in electric shock,
fire and/or serious personal injury.
READ THESE INSTRUCTIONS
WORK AREA
Keep your work area clean and well lit. Cluttered
benches and dark areas invite accidents.
Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gases,
or dust. Power tools create sparks which may ignite the
dust or fumes.
Keep bystanders, children, and visitors away while
operating a power tool. Distractions can cause you to
lose control.
Avoid accidental starting. Be sure switch is off
before plugging in. Carrying tools with your finger on
the switch or plugging in tools that have the switch on
invites accidents.
Remove adjusting keys or wrenches before turning
the tool on. A wrench or a key that is left attached to a
rotating part of the tool may result in personal injury.
Do not overreach. Keep proper footing and balance
at all times. Proper footing and balance enables better
control of the tool in unexpected situations.
Use safety equipment. Always wear eye protection.
Dust mask, nonskid safety shoes, hard hat, or hearing
protection must be used for appropriate conditions.
Do not wear loose clothing or jewelry. Contain long
hair. Loose clothes, jewelry, or long hair can be drawn
into air vents.
Do not use on a ladder or unstable support. Stable
footing on a solid surface enables better control of the
tool in unexpected situations.
ELECTRICAL SAFETY
Double insulated tools are equipped with a polarized
plug (one blade is wider than the other). This plug will
fit in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician to install a
polarized outlet. Do not change the plug in any way.
Double insulation
wire grounded power cord and grounded power supply
system.
Avoid body contact with grounded surfaces such as
pipes, radiators, ranges, and refrigerators. There is an
increased risk of electric shock if your body is grounded.
To reduce the risk of fire or electric shock, do not
expose this product to rain or moisture. Store indoors.
Do not abuse the cord. Never use the cord to carry the
tools or pull the plug from an outlet. Keep cord away
from heat, oil, sharp edges, or moving parts. Replace
damaged cords immediately. Damaged cords increase
the risk of electric shock.
When operating a power tool outside, use an outdoor
extension cord marked “W-A” or “W”. These cords are
rated for outdoor use and reduce the risk of electric shock.
eliminates the need for the three-
PERSONAL SAFETY
Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use tool
while tired or under the influence of drugs, alcohol,
or medication. A moment of inattention while operating
power tools may result in serious personal injury.
Dress properly. Do not wear loose clothing or jewelry.
Contain long hair. Keep your hair, clothing, and gloves
away from moving parts. Loose clothes, jewelry, or long
hair can be caught in moving parts.
TOOL USE AND CARE
Use clamps or other practical way to secure and
support the workpiece to a stable platform. Holding
the work by hand or against your body is unstable and
may lead to loss of control.
Do not force tool. Use the correct tool for your ap-
plication. The correct tool will do the job better and safer
at the rate for which it is designed.
Do not use tool if switch does not turn it on or off. Any
tool that cannot be controlled with the switch is dangerous and must be repaired.
Disconnect the plug from power source before making
any adjustments, changing accessories, or storing the
tool. Such preventive safety measures reduce the risk of
starting the tool accidentally.
Store idle tools out of the reach of children and other
untrained persons. Tools are dangerous in the hands of
untrained users.
Maintain tools with care. Keep cutting tools sharp
and clean. Properly maintained tools with sharp cutting
edges are less likely to bind and are easier to control.
Check for misalignment or binding of moving parts,
breakage of parts, and any other condition that may
affect the tool’s operation. If damaged, have the tool
serviced before using. Many accidents are caused by
poorly maintained tools.
Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one tool, may become hazardous when used
on another tool.
3 - English
IMPORTANT SAFETY INSTRUCTIONS
Keep the tool and its handle dry, clean and free from
oil and grease. Always use a clean cloth when clean-
ing. Never use brake fluids, gasoline, petroleum-based
products, or any strong solvents to clean your tool.
Following this rule will reduce the risk of loss of control
and deterioration of the enclosure plastic.
SERVICE
Tool service must be performed only by qualified
repair personnel. Service or maintenance performed by
unqualified personnel may result in a risk of injury.
SPECIFIC SAFETY RULES
WARNING!
To reduce the risk of injury, user must read instruction
manual.
When servicing a tool, use only identical replacement
parts. Follow instructions in the Maintenance section
of this manual. Use of unauthorized parts or failure to
follow Maintenance Instructions may create a risk of
shock or injury.
The nozzle of the heat gun becomes very hot during
operation and should not be touched until the tool has
cooled. Always hold the tool by the insulated gripping
surface to reduce the risk of serious personal injury.
Heat guns produce very high temperatures and must
be used with caution to prevent combustible material
from igniting. Keep tool in constant motion; do not
stop or dwell in one spot. Following this rule will reduce
the risk of fire or serious personal injury.
Excessive heat can generate fumes which may be
dangerous when inhaled. Wear a dust respirator mask
or dual filter respirator mask when using the heat gun.
Following this rule will reduce the risk of serious personal
injury.
Keep a fully charged fire extinguisher close at hand
for emergency use. Following this rule will reduce the
risk of fire or serious injury.
Do not leave the heat gun unattended while running or
cooling down. Always set tool on a flat, level surface
so nozzle tip is directed upwards, away from supporting surface, while running or cooling down. Following
this rule will reduce the risk of fire or serious injury.
Know your power tool. Read operator’s manual care-
fully. Learn its applications and limitations, as well
as the specific potential hazards related to this tool.
Following this rule will reduce the risk of electric shock,
fire, or serious injury.
Always wear safety glasses. Everyday eyeglasses
have only impact-resistant lenses; they are NOT safety
glasses. Following this rule will reduce the risk of serious
personal injury.
Protect your hearing. Wear hearing protection during
extended periods of operation. Following this rule will
reduce the risk of serious personal injury.
Inspect tool cords periodically and, if damaged, have
repaired at your nearest Authorized Service Center.
Constantly stay aware of cord location. Following this
rule will reduce the risk of electric shock or fire.
Check damaged parts. Before further use of the
tool, a guard or other part that is damaged should
be carefully checked to determine that it will operate
properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts,
breakage of parts, mounting, and any other conditions
that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced
by an authorized service center. Following this rule will
reduce the risk of shock, fire, or serious injury.
Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one
heavy enough to carry the current your product will
draw. A wire gauge size (A.W.G.) of at least 14 is
recommended for an extension cord 50 feet or less
in length. A cord exceeding 100 feet is not recommended. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord. An
undersized cord will cause a drop in line voltage resulting
in loss of power and overheating.
Save these instructions. Refer to them frequently and
use them to instruct others who may use this tool. If you
loan someone this tool, loan them these instructions also.
4 - English
SPECIFIC SAFETY RULES
CALIFORNIA PROPOSITION 65
WARNING:
This product and some fumes and materials created by the use of this product may contain chemicals, including lead,
known to the State of California to cause cancer, birth defects, or other reproductive harm. Wash hands after handling.
Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products and,
• arsenic and chromium from chemically treated lumber.
Your risk from exposure to these chemicals varies, depending on how often you do this type of work. To reduce your
exposure, work in a well-ventilated area and with approved safety equipment, such as dust masks that are specially
designed to filter out microscopic particles.
5 - English
SYMBOLS
The following signal words and meanings are intended to explain the levels of risk associated with this product.
SYMBOL SIGNAL MEANING
DANGER:
WARNING:
CAUTION:
CAUTION:
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME
Safety Alert Indicates a potential personal injury hazard.
Read Operator’s Manual
Indicates an imminently hazardous situation, which, if not avoided, will
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, could
result in death or serious injury.
Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
(Without Safety Alert Symbol) Indicates a situation that may result in
property damage.
DESIGNATION/EXPLANATION
To reduce the risk of injury, user must read and understand
operator’s manual before using this product.
Eye Protection
Wet Conditions Alert Do not expose to rain or use in damp locations.
Hot Surface
V Volts Voltage
A Amperes Current
Hz Hertz Frequency (cycles per second)
min Minutes Time
Alternating Current Type of current
n
o
No Load Speed Rotational speed, at no load
Class II Construction Double-insulated construction
Always wear eye protection with side shields marked to comply
with ANSI Z87.1.
To reduce the risk of injury or damage, avoid contact with any
hot surface.
6 - English
ELECTRICAL
DOUBLE INSULATION
Double insulation is a concept in safety in electric power
tools, which eliminates the need for the usual threewire grounded power cord. All exposed metal parts are
isolated from the internal metal motor components with
protecting insulation. Double insulated tools do not need
to be grounded.
WARNING:
The double insulated system is intended to protect the
user from shock resulting from a break in the tool’s internal insulation. Observe all normal safety precautions
to avoid electrical shock.
NOTE: Servicing of a tool with double insulation requires
extreme care and knowledge of the system and should be
performed only by a qualified service technician. For service,
we suggest you return the tool to your nearest authorized
service center for repair. Always use original factory replacement parts when servicing.
ELECTRICAL CONNECTION
This tool has a precision-built electric motor. It should be
connected to a power supply that is 120 volts, 60 Hz, AC
only (normal household current). Do not operate this tool
on direct current (DC). A substantial voltage drop will cause
a loss of power and the motor will overheat. If your tool does
not operate when plugged into an outlet, double-check the
power supply.
EXTENSION CORDS
When using a power tool at a considerable distance from
a power source, be sure to use an extension cord that has
the capacity to handle the current the tool will draw. An undersized cord will cause a drop in line voltage, resulting in
overheating and loss of power. Use the chart to determine
the minimum wire size required in an extension cord. Only
round jacketed cords listed by Underwriter’s Laboratories
(UL) should be used.
When working outdoors with a tool, use an extension cord
that is designed for outside use. This type of cord is designated with “WA” or “W” on the cord’s jacket.
Before using any extension cord, inspect it for loose or exposed wires and cut or worn insulation.
**Ampere rating (on tool faceplate)
0-2.0 2.1-3.4 3.5-5.0 5.1-7.0 7.1-12.0 12.1-16.0
Cord Length Wire Size (A.W.G.)
25' 16 16 16 16 14 14
50' 16 16 16 14 14 12
100' 16 16 14 12 10 —
**Used on 12 gauge - 20 amp circuit.
NOTE: AWG = American Wire Gauge
WARNING:
Keep the extension cord clear of the working area. Position the cord so that it will not get caught on lumber,
tools or other obstructions while you are working with a
power tool. Failure to do so can result in serious personal
injury.
Check extension cords before each use. If damaged replace immediately. Never use tool with a damaged cord
since touching the damaged area could cause electrical
shock resulting in serious injury.
7 - English
WARNING:
FEATURES
PRODUCT SPECIFICATIONS
Heat Output ........................................................................................................................................................ 200˚F-1050˚F
Input .....................................................................................................................................120 V, 60 Hz, AC only, 11 Amps
Net Weight ....................................................................................................................................................................1.9 lbs.
KNOW YOUR HEAT GUN
See Figure 1, page 12
The safe use of this product requires an understanding of
the information on the product and in this operator’s manual
as well as a knowledge of the project you are attempting.
Before use of this product, familiarize yourself with all
operating features and safety rules.
HANGER
A hanger is located in the support stand of your heat gun.
LED TEMPERATURE DISPLAY
LED lights located on top of the heat gun display the desired
temperature as indicated by the position of the temperature
adjustment dial.
NOSE CONE
The nose cone on your heat gun can be removed for work
in confined spaces.
ASSEMBLY
ON/OFF SWITCH
Your heat gun has a conveniently located on/off slide
switch.
POWER CORD
An extra-long power cord gives you more freedom of movement and placement flexibility when working with your heat
gun.
SUPPORT STAND
Your heat gun has a built-in support stand for ease of use
and convenient cool down.
TEMPERATURE ADJUSTMENT DIAL
The temperature of your heat gun can be adjusted from
200ºF to 1050ºF by rotating the temperature adjustment dial.
UNPACKING
This product has been shipped completely assembled.
Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
WARNING:
Do not use this product if any parts on the Packing List
are already assembled to your product when you unpack
it. Parts on this list are not assembled to the product by
the manufacturer and require customer installation. Use
of a product that may have been improperly assembled
could result in serious personal injury.
Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
Do not discard the packing material until you have care-
fully inspected and satisfactorily operated the tool.
If any parts are damaged or missing, please call
1-800-525-2579 for assistance.
PACKING LIST
Heat Gun
Operator’s Manual
8 - English
WARNING:
If any parts are missing do not operate this tool until
the missing parts are replaced. Use of this product with
damaged or missing parts could result in serious personal injury.
WARNING:
Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such
alteration or modification is misuse and could result in a
hazardous condition leading to possible serious personal
injury.
WARNING:
Do not connect to power supply until assembly is
complete. Failure to comply could result in accidental
starting and possible serious personal injury.
OPERATION
WARNING:
Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is sufficient to inflict serious injury.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
WARNING:
Do not use any attachments or accessories not recommended by the manufacturer of this tool. The use of
attachments or accessories not recommended can result
in serious personal injury.
APPLICATIONS
You may use this tool for the purposes listed below:
Soften paint, caulking and putty for easier removal
Soften adhesives to help remove stickers, floor tiles,
wallpaper, etc.
Heating plastic and metal for bending
Soldering pipe joints
Shrink tubing for electrical work
Shrink plastic film for wrapping or weatherproofing
Loosen rusted nuts, bolts, and fittings
READ THIS INSTRUCTION
WARNING:
Use extreme care when stripping paint. The peelings,
residue, and vapors of paint may contain lead, which
is poisonous. Any pre-1977 paint may contain lead and
paint applied to homes prior to 1950 is likely to contain
lead. Once deposited on surfaces, hand to mouth contact
can result in the ingestion of lead. Exposure to even low
levels of lead can cause irreversible brain and nervous
system damage; young and unborn children are particularly vulnerable. Before beginning any paint removal
process, you should determine whether the paint you are
removing contains lead. This can be done by your local
health department or by a professional who uses a paint
analyzer to check lead content of the paint to be removed.
LEAD-BASED PAINT SHOULD ONLY BE REMOVED BY
A PROFESSIONAL AND SHOULD NOT BE REMOVED
USING A HEAT GUN.
Persons removing paint should follow these guidelines:
Move the workpiece outdoors. If this is not possible, keep
the work area well ventilated. Open the windows and put
an exhaust fan in one of them. Be sure the fan is moving
the air from inside to outside.
Remove or cover any carpets, rugs, furniture, clothing,
cooking utensils, and air ducts.
Place drop cloths in the work area to catch any paint chips
or peelings. Wear protective clothing such as extra work
shirts, overalls, and hats.
Work in one room at a time. Furnishings should be re-
moved or placed in the center of the room and covered.
Work areas should be sealed off from the rest of the
dwelling by sealing doorways with drop cloths.
Children, pregnant or potentially pregnant women, and
nursing mothers should not be present in the work area
until the work is done and all clean up is complete.
Wear a dust respirator mask or a dual filter (dust and
fume) respirator mask which has been approved by the
Occupational Safety and Health Administration (OSHA),
the National Institute of Safety and Health (NIOSH), or
the United States Bureau of Mines. These masks and
replaceable filters are readily available at major hardware
stores. Be sure the mask fits. Beards and facial hair may
keep masks from sealing properly. Change filters often.
DISPOSABLE PAPER MASKS ARE NOT ADEQUATE.
Use caution when operating the heat gun. Keep the heat
gun moving as excessive heat will generate fumes
Keep food and drink out of the work area. Wash hands,
arms and face and rinse mouth before eating or drinking. Do not smoke or chew gum or tobacco in the work
area.
Clean up all removed paint and dust by wet mopping the
floors. Use a wet cloth to clean all walls, sills, and any
other surface where paint or dust is clinging. DO NOT
SWEEP, DRY DUST, OR VACUUM. Use a high phosphate
detergent or trisodium phosphate (TSP) to wash and mop
areas.
At the end of work session, put the paint chips and debris
in a double plastic bag, close it with tape or twist ties,
and dispose of properly.
Remove protective clothing and work shoes in the work
area to avoid carrying dust into the rest of the dwelling.
Wash work clothes separately. Wipe shoes off with a wet
rag that is then washed with the work clothes. Wash hair
and body thoroughly with soap and water.
9 - English
OPERATION
WARNING:
This heat gun generates extremely high temperatures.
Hidden areas such as behind walls, ceilings, floors, soffit
boards, and other panels may contain flammable materials that could be ignited by the heat gun when working
in these locations. Keep tool in constant motion; do not
stop or dwell in one spot as the panel or material behind
it may ignite. The ignition of these materials may not be
readily apparent and could result in property damage and
injury to persons.
SAVE THIS INSTRUCTION
WARNING:
Do not direct hot tip or nozzle toward clothing, hands
or other body parts. Intense heat from tip or nozzle can
cause serious burns or cause clothing to ignite.
SAVE THIS INSTRUCTION
STARTING/STOPPING THE HEAT GUN
See Figure 2, page 12.
The heat gun is started by sliding the on/off switch up to
the ON ( l) position. To stop, slide the switch down to the
OFF (O ) position.
ADJUSTING THE TEMPERATURE
See Figure 3, page 12.
The temperature of the heat gun is controlled by the temperature adjustment dial located at the top of the tool. Turn
the dial to the right to raise the temperature and to the left
to lower the temperature. The LED lights located in front of
the dial indicate the temperature setting selected.
NOTE: The proper amount of heat necessary for a specific
application depends on the distance between the nozzle and
workpiece and the length of time heat is applied. Experiment
with scrap materials and start with the lowest temperature
range. Be cautious when working until the proper combination of heat, distance and time has been determined.
HANDS-FREE OPERATION
See Figure 4, page 12.
The heat gun has a flat bottom surface that acts as a support stand to allow hands-free operation and cooling. Rest
the tool on a flat surface and make sure the cord placement
does not cause the heat gun to tip over.
NOTE: Do not leave heat gun unattended while it is running
or cooling down. Always set on a flat, level surface with
nozzle tip directed upwards, away from supporting surface.
REMOVING THE NOSE CONE
See Figure 5, page 12.
The nose cone helps to limit exposure to the extremely hot
nozzle when the heat gun is in use. However, the nose cone
can be removed to allow use of the heat gun in tight spaces.
NOTE: Always reinstall the nose cone when finished.
To remove:
Unplug the heat gun.
With nozzle pointed away from you, rotate the nose cone
slightly clockwise and remove.
WARNING:
The nozzle of the heat gun is extremely hot during use.
It will stay hot for several minutes, depending on room
temperature. Allow heat gun to cool before attempting to
install or remove the nose cone to avoid possible serious
personal injury.
To reinstall:
Unplug the heat gun.
Slide nose cone over the heat gun nozzle.
Seat the nose cone against the body of the heat gun by
aligning tabs on heat gun body to notches on base of
nose cone.
Rotate the nose cone counterclockwise to secure.
USING THE HANGER
See Figure 6, page 12.
The heat gun has a hanger recessed into the support stand.
To use, simply slide your finger into the opening underneath
the hanger and flip the hanger out and away from the support stand.
10 - English
MAINTENANCE
WARNING:
When servicing, use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
WARNING:
Always wear eye protection with side shields marked to
comply with ANSI Z87.1. Failure to do so could result in
objects being thrown into your eyes resulting in possible
serious injury.
GENERAL MAINTENANCE
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types of
commercial solvents and may be damaged by their use. Use
clean cloths to remove dirt, dust, oil, grease, etc.
WARNING:
Do not at any time let brake fluids, gasoline, petroleumbased products, penetrating oils, etc., come in contact
with plastic parts. Chemicals can damage, weaken or
destroy plastic which may result in serious personal injury.
Electric tools used on fiberglass material, wallboard, spackling
compounds, or plaster are subject to accelerated wear and
possible premature failure because the fiberglass chips and
grindings are highly abrasive to bearings, brushes, commutators, etc. Consequently, we do not recommended using this
tool for extended work on these types of materials. However,
if you do work with any of these materials, it is extremely
important to clean the tool using compressed air.
LUBRICATION
All of the bearings in this tool are lubricated with a sufficient
amount of high grade lubricant for the life of the unit under
normal operating conditions. Therefore, no further lubrication is required.
WARNING:
Always unplug the heat gun before performing any type
of maintenance. Following this rule will reduce the risk
of serious personal injury.
CLEANING THE HEAT GUN
The heat gun and attachments should be kept clean, dry,
and free of oil or grease. Only a mild soap and damp cloth
should be used to clean the heat gun. Do not allow liquid
to enter the tool.
The high temperatures of the heat gun will cause the nozzle
to turn dark over time. This is normal and will not affect its
performance or life.
Ventilation openings must be kept clean and free of foreign
matter. The most effective method of cleaning the vents is
with compressed air. Do not attempt to clean by inserting
pointed objects through the openings.
STORAGE
Always allow the heat gun and nozzle attachments to cool
to room temperature before storing. Store the heat gun out
of reach of children and untrained individuals.
WARNING:
The nozzle of the heat gun will stay hot for several minutes
after use. Always allow heat gun to cool before storage.
Following this rule will reduce the risk of serious personal
injury or property damage.
POWER SUPPLY CORD REPLACEMENT
If replacement of the power supply cord is necessary, this
has to be done by the manufacturer or his agent in order to
avoid a safety hazard.
NOTE: FIGURES (ILLUSTRATIONS) START ON PAGE 13
AFTER FRENCH AND SPANISH LANGUAGE SECTIONS.
11 - English
Loading...
