Ryobi CFP180L Operator's Manual

OPERATOR’S MANUAL

CORDLESS FLUORESCENT LIGHT

CFP180L

Your Fluorescent Light has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation
and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

WARNING: To reduce the risk of injury, the user must read and understand the operator's manual before using

this product.

Thank you for buying a Ryobi product.

SAVE THIS MANUAL FOR FUTURE REFERENCE

BATTERIES AND CHARGERS
SOLD SEPARATELY

GENERAL SAFETY RULES

Use only with recommended battery pack (ABP1801/
ABP1802) and charger (ACR1800) (both sold separately).

CAUTION!

Read and follow all Safety Rules and Operating Instruc­tions before first use of this product.

READ ALL INSTRUCTIONS

n KNOW YOUR FLUORESCENT LIGHT.
Read operator’s manual carefully. Learn its applications

and limitations as well as the specific potential hazards
related to this fluorescent light.

n REMOVE BATTERY PACK FROM FLUORESCENT

LIGHT BEFORE REPLACING BULB OR PERFORM­ING ANY ROUTINE MAINTENANCE OR CLEANING.

n DO NOT DISASSEMBLE YOUR LIGHT.
n DO NOT PLACE FLUORESCENT LIGHT OR BATTERY

PACK NEAR FIRE OR HEAT.

They may explode. Also,
n DO NOT dispose of a worn out battery pack by inciner-

ating. Do not incinerate the battery, even if it is severely
damaged or completely worn out. The battery may ex­plode in fire.

n DO NOT STORE YOUR FLUORESCENT LIGHT IN A

DAMP OR WET LOCATION. ALSO, DO NOT STORE
IN LOCATIONS WHERE THE TEMPERATURE MAY
REACH OR EXCEED 40°C (104°F).

For example, outside sheds, vehicles or metal buildings

in the summer.

n DO NOT PERMIT CHILDREN TO USE FLUORESCENT

LIGHT UNSUPERVISED.

It is not a toy. The temperature of the bulb can become

hot after being on for an extended period of time. This
hot temperature may cause burn injury if touched.

n KEEP WORK AREA CLEAN.
Cluttered areas and benches invite accidents.

n AVOID DANGEROUS ENVIRONMENT.
n KEEP LIGHT DRY, CLEAN AND FREE FROM OIL AND

GREASE.

Always use a clean cloth when cleaning. Never use brake

fluids, gasoline, petroleum-based products or any strong
solvent to clean your light.

n CHECK DAMAGED PARTS.
Before further use of this light, a part that is damaged

should be carefully checked to determine that it will op­erate properly and perform its intended function. Do not
use fluorescent light if it does not function properly.

n SAVE THESE INSTRUCTIONS.

Review them frequently and use them to instruct others

who may use this light. If you loan someone this light,
loan them these instructions also.

SAFETY RULES FOR FLUORESCENT LIGHT

WARNING

Do not operate fluorescent light or charger near flam­mable liquids or in gaseous or explosive atmosphere.
Internal sparks may ignite fumes.

WARNING

Lens and bulb become hot during use.

n During or immediately after use, don’t lay fluorescent light

flat on lens surface.

n Handle fluorescent light with care around any flammable

surface.

n If bulb has been lit, let fluorescent light cool for several

minutes before changing bulb.

n Do not use or permit use of fluorescent light in bed or

sleeping bags. A burn injury could result.

TO INSTALL/REMOVE BATTERY PACK (NOT
INCLUDED)

n Begin with a fully charged battery pack.
n TO INSTALL: Align raised ribs on battery pack with

grooves on bottom of uorescent light, then install
battery pack to uorescent light as shown in gure 1.

Make sure the latch on battery pack snaps in place

and battery pack is secured to uorescent light before
beginning operation.

OPERATION

n TO REMOVE: Depress latch located on front of battery

pack (1) to remove battery pack.

Pull on battery pack (2) to remove from uorescent

light.

WARNING

During the change of lamp.

2

OPERATION

CAUTION

When placing battery pack in your fluorescent light, be
sure raised ribs on battery pack aligns with groove inside
light handle and latches snap in place properly. Improper
assembly of battery pack can cause damage to internal
components.

SWITCH

See Figure 2.

To turn your light on and off, depress switch trigger.

HANGING / STORAGE FEATURE

See Figure 2.

On top of the housing is a hook in which you can use to
hang the light up. This is a good feature for storing light
when not in use and also to keep light out of the reach of
children. To use, simply lift up on hook.

TUBE REPLACEMENT

See Figure 3.

TO REMOVE: DEPRESS

LATCH TO RELEASE

BATTERY PACK

TO RAISE

BATTERY PACK

(NOT INCLUDED)

GROOVES

Fig. 1

HANGER

TO

LOWER

WARNING

During the change of lamp the battery has to be not
contacted with the luminaire.

Use only with above listed fluorescent tube, other type of
fluorescent tubes will result in a risk of electric shock.

TO REPLACE FLUORESCENT TUBE

n Remove battery pack from uorescent light.
n Remove screw to release lens cover. Remove lens cover

by pulling forward and lifting from the housing.

n To remove old uorescent tube from spring, gently

grasp the lower edge of the rubber cushion and sides of
bulb. Carefully work tube in a side-to-side motion while
easing tube forward and up until tube is free from the
spring. Do not pull uorescent tube straight out from its
center, as this increases chance of breakage. Remove
rubber cushion from old uorescent tube and place on
top of new tube, rounded edge facing outward.

n Insert new uorescent tube in spring by aligning prongs

on tube with holes in tube socket area. Gently push
down on base of new tube until fully engaged. Do not
force tube into place.

n Replace lens cover by sliding lower edge into housing.

Align screw holes at top. With a screwdriver, tighten
screw.

n Replace battery pack.

PULL LENS COVER

FORWARD TO REMOVE

SCREW

LENS COVER

FLUORESCENT TUBE

(9W U-TYPE TUBE)

SWITCH

TRIGGER

Fig. 2

RUBBER

CUSHION

FLUORESCENT TUBE

SOCKET AREA

Fig. 3

WARNING

Do not attempt to disassemble the battery pack. Fire or
injury may result.

3

RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.

GUARANTEE

RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.

A.B.N. 98 002 277 509

SYDNEY: 359-361 Horsley Road, Milperra, N.S.W. 2214.

Contact during normal business hours.

RYOBI NEW ZEALAND PTY. LTD.

AUCKLAND: 27 Clemow Drive, Mt Wellington, N.Z.

Contact during normal business hours.

Subject to the guarantee condition below, this Ryobi tool
(hereinafter called “the product”) is guaranteed by Ryobi
(hereinafter called “the Company”) to be free from
defects in material or workmanship for a period of 24
months from the date of original purchase covering
both parts and labour. Under the terms of this
guarantee, the repair or replacement of any part shall
be the opinion of the Company or its authorised agent.
Should service become necessary during the warranty
period, the owner should contact the RYOBI HELPLINE
1300 361 505 or contact the retailer from whom the
product was purchased.
In order to obtain guarantee service, the owner must
present the sales docket and Guarantee Certificate
to confirm date of purchase. This product is sold by the
dealer or agent as principal and the dealer has no
authority from the Company to give any additional
guarantee on the Company’s behalf except as herein
contained or herein referred to.

Guarantee Conditions
This guarantee only applies provided that the Product
has been used in accordance with the manufacturer’s
recommendations under normal use and reasonable
care (in the opinion of the Company) and such

guarantee does not cover damage, malfunction or
failure resulting from misuse, neglect, abuse, or used
for a purpose for which it was not designed or is not
suited and no repairs, alterations or modifications
have been attempted by other than an Authorised
Service Agent. This guarantee will not apply if the tool is
damaged by accident or if repairs arise from normal
wear and tear.
The Company accepts no additional liability pursuant to
this guarantee for the costs of travelling or
transportation of the Product or parts to and from the
service dealer or agent - such costs are not included in
this guarantee.
Certain legislation, including the Trade Practices Act,
1974 (as amended) and other state and territorial laws
give rights to the buyer and impose liability on the seller in
certain circumstances. Nothing herein shall have the effect
of excluding, restricting or modifying any condition,
guarantee, right or liability imposed, to the extent only
that such exclusion, restriction or modification
would render any term herein void.

BRISBANE : All enquiries Tel : [phone]
TOWNSVILLE: All enquiries Tel : [phone]
MELBOURNE: 960 Stud Road, Rowville,Vic. 3178

Tel : [phone]

HOBART: All enquiries Tel : [phone]
ADELAIDE: All enquiries Tel : [phone]
PERTH: 33-35 Sorbonne Cres. Canning Vale, W.A. 6155

Address Of Dealer

Present This Form With Your Purchase Docket When Guarantee Service Is Required.

Tel: [phone] - Fax: [phone] - www.ryobi.com.au

Tel: [phone] - Free Call: 0800 279 624 - Fax: [phone] - www.ryobi.co.nz

For your record and to assist in establishing date of purchase (necessary for in-guarantee service)

please keep your purchase docket and this form completed with the following particulars.

This Guarantee Form Should Be Retained By The Customer At All Times

Date Model No Serial No

Tel : [phone]
