WiFi HITCH CAMERA
Product Manual
RVS-83112-WiFi
What’s in the Box?
• Color Waterproof WiFi Hitch Camera with
Magnetic Base and Infra-red Night Vision
• USB Cable for Rechargeable Battery
• Velcro Mounting Pad
2
Table of Contents
What’s in the Box.....................................................2
Features..........................................................4
Specifications......................................................6
Operations...................................................8
WiFi Connection........................................................9
Disclaimer.....................................................10
Warranty......................................................11
3
Please read all of the installation instructions carefully before installing the product.
Improper installation will void manufacturer’s
warranty.
Thank you for purchasing our WiFi Hitch Camera! The
user manual has a detailed description on how to correctly use the WiFi Hitch Camera and provides detailed
product information, including operation, installation
precautions and technical specifications. Please read
the manual carefully before using. We hope you enjoy
this system.
4
Features
• WiFi Connection - View hitch camera on mobile
device!
• Magnetic Camera Mount - Mounts anywhere
with no hardware!
• Rechargeable Battery – Recharge with included
USB cable
• Six Infra-Red Lights - 30ft of Night Vision
• Completely Waterproof Camera with an IP68 Rating
5
Specifications
Camera Specs
Camera High Quality CMOS Sensor
Picture Elements NTSC: 580x492, PAL: 580x540
Viewing Angle 120°
Infra-Red Distance 30ft (6 Infra-Reds)
Usable Illumination 0 Lux (IR On)
Waterproof IP68
Voltage 3.7V
White Balance Automatic
Video Output 1.0 the vp, 75 Ohm-p
Operating Temperature -20°C ~ +70°
6
Battery Specs
Battery Capacity 2100 mAh
Recharge Time 4.5h
Recharge Voltage 5V
Battery Boot Voltage 3.6 - 4.2 V
Max Current Recharge 480 mA
Communications Working Current 260mA
Transmit Power 17DB
Wireless Communication Format WiFi
7
Operations - App Installation
Scan the QR code for your device below.
Apple
Android
8
WiFi Connection
1. First turn on your WiFi Hitch Camera. Your
LED will turn blue.
2. Open Wifi settings on your phone and
connect to WiFi network named "Sonix_***"
3. With the WiFi connected, open the RoadVue
App.
4. You will now be able to see the camera view
on your smartphone!
9
Disclaimer
Rear View Safety and/or its affiliates does not guarantee or promise that the user of our systems will not be
in/part of an accident or otherwise not collide with an
object and/or person. Our systems are not a substitute
for careful and cautious driving or for the consistent
adherence to all applicable traffic laws and motor vehicle safety regulations.
The Rear View Safety products are not a substitute for
rear view mirrors or for any other motor vehicle equipment mandated by law. Our camera systems have a
limited field of vision and do not provide a comprehensive view of the rear or side area of the vehicle. Always
make sure to look around your vehicle and use your
mirrors to confirm rearward clearance and that your
vehicle can maneuver safely. Rear View Safety and/
or its affiliates shall have no responsibility or liability
for damage and/or injury resulting from accidents occurring with vehicles having some of Rear View Safety
10
products installed and Rear View Safety and/or its affiliates, the manufacturer, distributor and seller shall not
be liable for any injury, loss or damage, incidental or
consequential, arising out of the use or intended use of
the product. In no event shall Rear View Safety and/or
its affiliates have any liability for any losses (whether direct or indirect, in contract, tort or otherwise) incurred in connection with the systems, including but
not limited to damaged property, personal injury
and/or loss of life. Neither shall Rear View Safety and/
or its affiliates have any responsibility for any decision,
action or inaction taken by any person in reliance on
Rear View Safety systems, or for any delays, inaccuracies and/or errors in connection with our systems
One Year Warranty
Rear View Safety Inc. warrants this product against
material defects for a period of one year from date of
purchase. We reserve the right to repair or replace any
such defective unit at our sole discretion. Rear View
11
Safety Inc. is not responsible for a defect in the system
as a result of misuse, improper installation, damage or
mis-handling of the electronic components. Rear View
Safety Inc. is not responsible for consequential damages of any kind. This warranty is void if: defects in materials or workmanship or damages result from repairs
or alterations which have been made or attempted by
others or the unauthorized use of nonconforming parts;
the damage is due to normal-ware and tear, this damage is due to abuse, improper maintenance, neglect
or accident: or the damage is do to use of the Rear
View Safety Inc. system after partial failure or use with
improper accessories.
WARRANTY PERFORMANCE
DURING THE ABOVE WARRANTY PERIOD, SHOULD
YOUR REAR VIEW SAFETY PRODUCT EXHIBIT A DEFECT
IN MATERIAL OR WORKMANSHIP, SUCH DEFECT WILL
BE REPAIRED WHEN THE COMPLETE REAR VIEW SAFETY INC. PRODUCT IS RETURNED, POSTAGE PREPAID
12
AND INSURED, TO REAR VIEW SAFETY INC. OTHER
THAN THE POSTAGE AND INSURANCE REQUIREMENT,
NO CHARGE WILL BE MADE FOR REPAIRS COVERED
BY THIS WARRANTY. WARRANTY DISCLAIMERS NO
WARRANTY, ORAL OR WRITTEN, EXPRESSED OR IMPLIED, OTHER THE ABOVE WARRANTY IS MADE WITH
REGARD TO THIS REAR VIEW SAFETY INC. REAR VIEW
SAFETY INC. DISCLAIMS ANY IMPLIED WARRANTY OR
MERCHANT-ABILITY OR FITNESS FOR A PARTICULAR
USE OR PURPOSE AND ALL OTHER WARRANTIES IN
NO EVENT SHALL REAR VIEW SAFETY INC. LIABLE
FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL, OR
PUNITIVE DAMAGES OR FOR ANY COSTS, ATTORNEY
FEES, EXPENSES, LOSSES OR DELAYS ALLEGED TO BE
AS A CONSEQUENCE OF ANY DAMAGE TO, FAILURE OF,
OR DEFECT IN ANY PRODUCT INCLUDING, BUT NOT
LIMITED TO, ANY CLAIMS FOR LOSS OF PROFITS.
13
If you have any questions
about this product, contact:
Rear View Safety, Inc.
1797 Atlantic Avenue
Brooklyn, NY 11233
800.764.1028
BETTER CAMERAS. BETTER SERVICE.
IT’S OUR GUARANTEE.
