RVS Systems RVS-6139Q, RVS-812613-NM, RVS-770616-NM, RVS-062710 User Manual

Download
1
What’s in the Box?
System connects to four (4) cameras
• 1 x 9" TFT LCD Digital Quad View Color Monitor
• 1 x Universal Mount with Adhesive Pad
• 1 x Power Harness with 4 Camera Inputs
• 1 x Remote Control
Table of Contents
Safety Information ..................................................................................5-7
Wiring Camera & Monitor.................................................................10-11
Camera Specifications..............................................................................21
3
Introduction
Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.
Congratulations on purchasing a Rear View Backup Camera
System! With this manual you will be able to properly install and
operate the unit.
The Backup Camera System is intended to be installed as a
supplement aid to your standard rear view mirror that already
exists in your vehicle. The Backup Camera System should not be
used as a substitute for the standard rear view mirror or for any
other mirror that exists in your vehicle.
In some jurisdictions, it is unlawful for a person to drive a
motor vehicle equipped with a TV viewer or screen located for-
ward of the back of the driver’s seat or in any location that is
visible, directly or indirectly, to the driver while operating the ve-
hicle.
4
Rear View Safety
Safety Information
Please read the entire manual and follow the instructions and warnings carefully. Failure to do so can cause serious damage and/or injury, including loss of life. Be sure to obey all applica­ble local traffic and motor vehicle regulations as it pertains to this product. Improper installation will void manufacturer’s
warranty.
USAGE
• The Rear View Camera System
is designed to help the driver safely detect people and/or objects helping to avoid damage or injury. However, you the driver, must use it properly. Use of this system is not a substitute for safe, proper or legal driving.
• Never back up while looking
at the monitor alone. You should always check behind and around the vehicle when backing up, in the same way as you would if the vehicle did not have the Rear View
Reverse With Confidence
™
Camera System. If you back up while looking only at the monitor, you may cause damage or injury. Always back up slowly.
• The Rear View Camera Sys-
tem is not intended for use during exstensive back-up maneuvers or backing into cross traffic or pedestrian walkways.
• Please, always remember,
the area displayed by the Rear View Camera System is limited. It does not display the entire panorama that is behind you.
5
Safety Information
INSTALLATION
•
Electric shock or product malfunction may occur if this product is installed incorrectly.
• Use this product within
the voltage range specified. Failure to do so can cause electronic shock or product malfunction.
• Take special care when
cleaning the monitor.
• Make sure to firmly affix the
product before use.
• If smoke or a burning smell
is detected, disconnect the system immediately.
• Where the power cable may
touch a metal case, cover the cable with a friction tape. A short circuit or disconnected wire may cause a fire.
• While installing the RVS
System be careful with the wire positioning in order to avoid wire damage.
• The RVS System should only
be used when the vehicle is in reverse.
• Do not watch movies or
operate the monitor while driving; as it may cause an accident.
• Do not install the monitor
where it may obstruct drivers view or obstruct an air bag device.
• Dropping the unit may cause
possible mechanical failure.
6
Rear View Safety
Safety Information
If you have questions about this product, contact:
Customer Service:
Rear View Safety
1797 Atlantic Avenue
Brooklyn, NY 11233 Tel: 1.800.764.1028
IN NO EVENT SHALL SELLER OR MANUFACTURER BE
LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
Reverse With Confidence
™
7
Before Beginning Installation
Before Beginning Installation
Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components.
We recommend doing a benchmark test before installation to insure that all components are working properly.
Step 1: Choose the monitor and camera locations.
Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm) hole should be drilled for passing camera cable through vehicles walls. Install split grommets where applicable.
Step 3: Once all cables and wiring have been properly routed, perform a system function test by temporarily connecting the system. If the system seems to not be operating properly see troubleshooting (page 17).
8
Rear View Safety
Installation Guide
Camera Installation
1. Attach camera bracket close to rear marker lights, centered on vehicle.
2. Camera: Drill a 20mm (0.8in) diameter hole into vehicle body near the camera and bracket. Insert camera cable into vehicle (be careful not to kink cable) and fit grommet into hole. Apply sealant around grommet to increase resistance to water penetration. Connect camera to the camera extension cable which runs inside the vehicle.
3. Feed as much cable as possible into vehicle & clamp securely. This reduces the pos-
sibility of cable being hooked or snagged. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather ele­ments.
4. Attach camera to bracket using screws provided and adjust the angle.
Wiring Camera
5. The power harness on this unit has 4 camera ports (BLUE-BACKUP, YELLOW-LEFT,
BROWN-RIGHT, and BLACK-FRONT.)
6. Each camera should be connected to its corresponding port. All that is needed for
the system to work is to connect the POWER (red) to 12V and the GROUND (black).
7. The camera and monitor can always be activated by manually pushing the power
button on monitor. This is in addition to utilizing the positive triggers.
8. As you may have noticed, there are also 3 multi-colored wires (blue, brown, yellow).
These are trigger wires, and when they are energized (12V) they will turn on their cor­responding channel. The Blue wire will also turn on gridlines and sound.
9. The camera system can be wired to be powered “ON” the entire time the vehicle is on.
This is typical in RV and some commercial applications.
Reverse With Confidence
™
9
Installation Guide
Monitor
1. To Attach the Pedestal mount to the dashboard or to the headliner use self-tapping screws and/or the adhesive pad.
2. Attach monitor to mount, and adjust mounting angle to allow optimum driver viewing comfort. (see figure 1.1 on page 11)
F Infrared technology built
into camera IRs are activated automatically according to the lighting conditions.
F When using the postive trig-
ger functions (blue, yellow & white wires) each trigger function needs to work on a seperate 12V+ source i.e. the Yellow and White wires can be wired to a turn signal circuit etc.
F Grid lines function can be
turned on/off by manually from menu. (See page 13)
Note: If connecting power
directly to battery, the camera
is always ON and therefore can
drain battery. Therefore it is
recommended to connect
power to an ignition switched
accessory power source.
10
Rear View Safety
Installing the Monitor
Figure 1.1
Reverse With Confidence
Figure 1.4
™
11
Installation Diagram
33ft Extension Cable 33ft Extension Cable 66ft Extension Cable 66ft Extension Cable
3
2
4
5
1
FUSE
Monitor cable
Camera
1. Red (power+)
2. Yellow (Left)
3. Brown (Right)
4. Blue (Back)
5. Black (Ground)
12
Camera
Camera
Camera
Rear View Safety
Monitor Operation
CAMERA
SELECTION
ROTATE
(Back/Exit
when in Menu
Mode)
• To turn on the monitor, press “POWER” button
• To get to the menu, press “MENU” and use arrows to choose your settings
• To display options press “MENU”
• To adjust brightness, press “MENU”. Use arrows to choose desired camera and press
“MENU” to select. Once selected, use arrows to set the brightness
• To adjust contrast press “MENU”. Use arrows to choose desired camera and press “MENU” to select. Once selected, use arrows to set the brightness
• To adjust saturation press “MENU”. Use arrows to choose desired camera and press “MENU” to select. Once selected, use arrows to set the brightness
• To set distance grid lines press “MENU” to select. Once selected, use arrows to choose off or on and press “MENU”
• To set auto power press “MENU” to select. Once selected, use arrows to choose off or on and press “MENU”.
• To reset press “MENU” to select. Once selected, use arrows to choose yes or no and press “MENU”.
• To return to previous press “REV” when in menu
• To rotate screen press “REV”
• To adjust the volume press “UP” and “DOWN” buttons
• To toggle between cameras/display modes press "V1/V2" Choose from Single/Dual/
Triple/Quad/H Mode/POP
“-” DOWN
MENU/
SELECTION BUTTON
“+” UP
POWER ON / OFF
Reverse With Confidence
™
13
Splitting & Splicing
1. Red (-12-24V)
2. Green (video back)
3. Blue (trigger back)
4. Brown (trigger right)
5. Yellow (trigger left)
6. White (audio)
7. Light blue (video front)
8. Gray (video right)
9. Pink (12V)
10. Purple (Audio out)
11. Black (GND)
12. Green (Video out)
13. Orange (left)
14
Rear View Safety
Positioning
Reverse With Confidence
™
15
Power Harness
Red (power+)
Yellow (Left)
Brown (Right)
Blue (Back)
Black (Ground)
FUSE
Monitor cable
DESCRIPTIONS
Blue - Back
Brown - Right
Yellow - Left
Red - Power 12V+
Black - Ground 12V-
16
Rear View Safety
Troubleshooting
Monitor Displays Blue Screen & Displays No Signal
• Do a hard reset, unplug all
cables and power cables and leave them out for 1 minute and then re-connect them.
• Check to ensure that the con-
nection to the camera is tight.
• Verify camera cable is plugged
into port labeled Backup Camera
• Verify that the blue positive
trigger on power harness is
put to power 12v+.
If the problem still persists, ver­ify that alternate ports work. If alternate ports do not work, re­move Blue Trigger wire from 12V+ and select alternate chan­nels.
Monitor Will Not Power-Up (no backlight on power button)
• Check fuse
• Check 12v+ to monitor
• Check ground connection
No Image On Screen
• Verify camera is on correct
camera input
• Verify cable is connected to
monitor
• Verify camera is connected to
cable
• Connect known working
camera and cable to monitor.
• Verify Blue trigger is receiving
power
Audio on Camera
• Verify chosen camera has audio
• Verify volume setting
• Confirm that the Blue audio
trigger is connected to 12v+
Reverse With Confidence
™
17
Monitor Dimensions
9”
Menu/
Selection
Button
Camera
Selection
Rotation
(Exit in
Down Up
Menu
Mode)
Power On/Off
6”
power
video select down/up
menu
mirror/ normal
18
Rear View Safety
Monitor Specifications
TFT LCD Digital Monitor
Screen Size 9”
Dot Resolution 800
H x 3 (RGB) x 480V
Display Format 16:9 / 500:1
Display Brightness 400cd/m
2
Viewing Angle U:50° / D:60° / R:70°
Video Input
channel
4
Video Source 1Vp-p, 75Ω
Power Supply
Power Consumption
Operating Temperature
Video System
Overall Dimensions
Weight
DC 12V OR
5W
-30°C ~ +80° C
Auto NTSC/PAL
9”L x 6”H x 1”D
400G
Impact Rating 5G
Dot Pitch 0.192
H x 0.1805V
Sync System Internal
Reverse With Confidence
™
24V (+/-10%)
19
Warranty
One Year Warranty
Rear View Safety, Inc. warrants this product against material defects for a period of one year from date of purchase. We reserve the right to repair or replace any such defective unit at our sole discretion. Rear View Safety, Inc. is not responsible for a defect in the system as a result of misuse, improper installation, damage or mishandling of the electronic components. Rear View Safety, Inc. is not responsible for consequential damages of any kind.
This warranty is void if: defects in materials or workmanship or damages result from repairs or alterations which have been made or attempted by others or the unautho­rized use of nonconforming parts; the damage is due to normal wear and tear, this damage is due to abuse, improper maintenance, neglect or accident; or the damage is due to use of the Rear View Safety, Inc. system after partial failure or use with im­proper accessories.
Warranty Performance
DURING THE ABOVE WARRANTY PERIOD, SHOULD YOUR Rear View Safety PRODUCT EXHIBIT A DEFECT IN MATERIAL OR WORKMANSHIP, SUCH DEFECT WILL BE REPAIRED WHEN THE COMPLETE Rear View Safety, INC. PRODUCT IS RETURNED, POSTAGE PREPAID AND INSURED, TO Rear View Safety, INC. OTHER THAN THE POSTAGE AND INSURANCE REQUIREMENT, NO CHARGE WILL BE MADE FOR REPAIRS COVERED BY THIS WARRANTY.
Warranty Disclaimers
NO WARRANTY, ORAL OR WRITTEN, EXPRESSED OR IMPLIED, OTHER THE ABOVE WARRANTY IS MADE WITH REGARD TO THIS Rear View Safety, INC. Rear View Safety, INC. DISCLAIMS ANY IMPLIED WARRANTY OR MERCHANT­ABILITY OR FITNESS FOR A PARTICULAR USE OR PURPOSE AND ALL OTHER WARRANTIES IN NO EVENT SHALL Rear View Safety. INC. LIABLE FOR ANY IN­CIDENTAL, SPECIAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES OR FOR ANY COSTS, ATTORNEY FEES, EXPENSES, LOSSES OR DELAYS ALLEGED TO BE AS A CONSEQUENCE OF ANY DAMAGE TO, FAILURE OF, OR DEFECT IN ANY PROD­UCT INCLUDING, BUT NOT LIMITED TO, ANY CLAIMS FOR LOSS OF PROFITS.
20
Rear View Safety
Disclaimer
Rear View Safety and/or its affiliates does not guarantee or promise that the user of our systems will not be in/part of an accident or otherwise not collide with an object and/or person. Our systems are not a substitute for careful and cautious driving or for the consistent adherence to all applicable traffic laws and motor vehicle safety regulations. The Rear View Safety products are not a substitute for rearview mirrors or for any other motor vehicle equipment mandated by law. Our camera systems have a limited field of vision and do not provide a comprehensive view of the rear or side area of the vehicle. Always make sure to look around your vehicle and use your mirrors to confirm rearward clearance and that your vehicle can maneuver safely. Rear View Safety and/or its affiliates shall have no responsi­bility or liability for damage and/or injury resulting from accidents occurring with vehicles having some of Rear View Safety products installed and Rear View Safety and/or its affiliates, the manufacturer, distributor and seller shall not be liable for any injury, loss or damage, incidental or consequential, arising out of the use or intended use of the product. In no event shall Rear View Safety
and/or its affiliates have any liability for any losses (whether direct or indirect, in contract, tort or otherwise) incurred in connection with the systems, including but not limited to damaged property, personal injury and/or loss of life. Neither shall Rear View Safety and/or its affiliates have any responsibility for any decision, action or inaction taken by any person in reliance on Rear View Safety systems, or for any delays, inaccuracies and/or errors in connection with our systems functions.
Reverse With Confidence
™
21
If you have any questions
about this product, contact:
Rear View Safety, Inc.
1797 Atlantic Avenue
Brooklyn, NY 11233
800.764.1028
BETTER CAMERAS. BETTER SERVICE.
IT’S OUR GUARANTEE.
