RVS Systems RVS-115-W User Manual

Instruction Manual

Backup Sensor System (Waterproof)

RVS-115-W

Rear View Safety, Inc. © 2018

System Description............................3

Safety Information............................4

Before Beginning Installation . . . . . . . . . . . . . . . . . . . . . . . 5

Cable Connection Diagram ...................... 6

Display Diagram.............................7

TABLE OF CONTENTS

Sensor System Diagram ..........................8

Waterproof Control Module Diagram . . . . . . . . . . . . . . . . . . . 9

Sensor Detecting Angles........................ 10

Sensor Specications.......................... 11

Waterproof Control Module Specications. . . . . . . . . . . . . . . . 11

Warranty........................... 12

Disclaimer......................... 13

2

Rear View Safety

This high-quality sensor system is the complete package that works
independently of other systems and comes with everything needed for
installation. This Backup Sensor System provides drivers with a detection
range of 8 feet.

The system comes with 4 sensors which mount on the rear bumper and a
small LED display console. The console noties the driver of the distance
between their vehicle and the vehicle or objects behind them.

SYSTEM DESCRIPTION

When objects behind the vehicle become closer the audio “beeps” become
faster and quicker. The sensors, control module, and cables are waterproof
which allow for installation either inside or outside the vehicle.

Reverse With Condence ™

3

SAFETY BASICS

If you have questions about this product, contact:

Rear View Safety

1797 Atlantic Avenue

Brooklyn, NY 11233

Tel: [phone]

IN NO EVENT SHALL SELLER OR MANUFACTURER BE

4

LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF

ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM

ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.

Rear View Safety

Before drilling please check that no cable or wiring is on the other side
of the wall. Please clamp all wires securely to reduce the possibility of
them being damaged while vehicle is in use. Keep all cables away from
hot or moving parts and electrical noisy components.

We recommend doing a benchmark test before installation

to insure that all components are working properly.

BEFORE YOU BEGIN

PLEASE READ THE ENTIRE MANUAL AND FOLLOW THE INSTRUCTIONS AND
WARNINGS CAREFULLY. FAILURE TO DO SO CAN CAUSE SERIOUS DAMAGE
AND/OR INJURY, INCLUDING LOSS OF LIFE. BE SURE TO OBEY ALL APPLI
CABLE LOCAL TRAFFIC AND MOTOR VEHICLE REGULATIONS AS IT PERTAINS

TO THIS PRODUCT. IMPROPER INSTALLATION WILL VOID

MANUFACTURER’S WARRANTY.

Reverse With Condence ™

5

Cable Connection Diagram

Installation Overview

1) Drill four holes for the four (4) waterproof sensors at equal
distance in the rear bumper:

21.5 mm when not using grommet

25.00 mm when using grommet

2) Mount sensors using the included grommets (Optional)

3) Connect the sensors to the Sensor Harness Cable

4) Connect Sensor Harness Cable to Control Module

CABLE CONNECTION

5) Connect LED Display to Power Harness Cable

6) Connect Power Harness to the LED Display

7) Connect Power Harness to Power Source

Sensor input connections distance:

Power harness cable length : 48 ft.
Sensors “1” and “2” : 25 ft.
Sensors “3” and “4” : 13 ft.

6

Rear View Safety

Display Diagram

Bracket

Left Sensor Alarm

Safety Zone

Caution Zone

Danger Zone

Right
Sensor
Alarm

Detection Distance

Volume Settings

Off
Low

High

Volume Switch

DISPLAY SETTINGS

Flip Numerical Display - Display installed on the Dashboard

Mirror Numerical Display – Display installed on TOP of Rear Windshield

Normal Numerical Display – Display installed on TOP of Windshield

Display Switch

DISPLAY DIAGRAM

VOLUME SETTINGS

--- High

-- Low

- Off

High sound is aprox. 80 db at 10 cm
Low sound is aprox. 60 db at 10 cm

Reverse With Condence ™

7

Sensor System Diagram

Sensor Visual and Audible Warnings

Distance from

Warning

Zone

Danger

Zone

Sensor & Obstacle

Unit: In. Unit: Ft.

0" < D < 8" 0' < D < 0.6'

8" ≤ D ≤ 11" 0.6' < D < 0.9'

11" ≤ D ≤ 19" 0.9' < D < 1.5'

RADAR DETECTION RANGE

19" ≤ D ≤ 27" 1.5' < D < 2.2'

Caution

Zone

Safety

Zone

27" ≤ D ≤ 35" 2.2' < D < 2.9'

35" ≤ D ≤ 43" 2.9' < D < 3.5'

43" ≤ D ≤ 70" 3.5' < D < 5.8'

70" ≤ D ≤ 78" 5.8' < D < 6.5'

78" ≤ D ≤ 98" 6.5' < D < 8.1'

Sound Information Visual Information

Sound

Code

Bi… Yes Yes

Bi… Yes Yes

Bi.Bi. Yes Yes

Bi..Bi Yes Yes

Bi...Bi Yes Yes

Bi….Bi Yes Yes

Bi…..Bi Yes No

No Sound No No

No Sound No No

S2, S3 S1, S4 LED Bar Display

Digits

Digits

Digits

Digits

Digits

Digits

Digits

Digits

P

8

Outside

98" ≤ D 8.1' < D

No Sound No No

Rear View Safety

-

Waterproof Control Module Diagram

WATERPROOF CONTROL MODULE

Sensor

Harness

Connector

Reverse With Condence ™

Power

Harness

Connector

9

Sensor Detecting Angles

Horizontal Angle (50°)

180

160

120

80

40

SENSOR DETECTING ANGLES

80 40 0 40 80 cm

Vertical Angle (59°)

80

40

0

-40

10

-80

20

50

80 120

Rear View Safety

160

Sensor Specications

Sensor Type: Analog Sensor
Sensor Quantity:  Sensors
Sensor Frequency:  kHz +/- kHz

Static Capacitance: ± 15%pF

Input Voltage max.:  Vp-p {at KHz)
Decay Time: <1.2ms
Decay Parameter : 20±3 (Admissible parameter)
Echo Sensitivity: > mV
Horizontal Angle: 50°
Vertical Angle: 59°

Detection Range: 0.22mm (0.08ft) – 2.5m (8ft)

Working Voltage: 10.0 ~ 28.0 VDC

Rated Current (ECU): 60mA max

Wiring Harness: Vehicle Spec. T-Piece

Working Temperature -°C ~ +°C

Storage Temperature -°C ~ +°C

Waterproof Control Module Specications

Normal Voltage 12 VDC

Operating Voltage 1.0 ~ 28 VDC

Rated Current 60 mA

Operating Frequency 40 +/- 1 kHz

Housing Material ABS

Housing Color Black

Working Temperature -°C ~ °C

SPECIFICATIONS

Storage Temperature -°C ~ °C

Waterproof Rating IP

Reverse With Condence ™

11

ONE YEAR WARRANTY

REAR VIEW SAFETY, INC. WARRANTS THIS PRODUCT AGAINST MATERIAL DEFECTS FOR A
PERIOD OF ONE YEAR FROM DATE OF PURCHASE. WE RESERVE THE RIGHT TO REPAIR OR
REPLACE ANY SUCH DEFECTIVE UNIT AT OUR SOLE DISCRETION. REAR VIEW SAFETY, INC.
IS NOT RESPONSIBLE FOR A DEFECT IN THE SYSTEM AS A RESULT OF MISUSE, IMPROPER
INSTALLATION, DAMAGE OR MISHANDLING OF THE ELECTRONIC COMPONENTS. REAR VIEW

SAFETY, INC. IS NOT RESPONSIBLE FOR CONSEQUENTIAL DAMAGES OF ANY KIND.

THIS WARRANTY IS VOID IF: DEFECTS IN MATERIALS OR WORKMANSHIP OR DAMAGES

RESULT FROM REPAIRS OR ALTERATIONS WHICH HAVE BEEN MADE OR ATTEMPTED BY
OTHERS OR THE UNAUTHORIZED USE OF NONCONFORMING PARTS; THE DAMAGE IS DUE
TO NORMAL WEAR AND TEAR, THIS DAMAGE IS DUE TO ABUSE, IMPROPER MAINTENANCE,
NEGLECT OR ACCIDENT; OR THE DAMAGE IS DUE TO USE OF THE REAR VIEW SAFETY, INC.

SYSTEM AFTER PARTIAL FAILURE OR USE WITH IMPROPER ACCESSORIES.

WARRANTY

WARRANTY PERFORMANCE

DURING THE ABOVE WARRANTY PERIOD, SHOULD YOUR REAR VIEW SAFETY PRODUCT
EXHIBIT A DEFECT IN MATERIAL OR WORKMANSHIP, SUCH DEFECT WILL BE REPAIRED WHEN
THE COMPLETE REAR VIEW SAFETY, INC. PRODUCT IS RETURNED, POSTAGE PREPAID AND

INSURED, TO REAR VIEW SAFETY, INC. OTHER THAN THE POSTAGE AND INSURANCE

REQUIREMENT, NO CHARGE WILL BE MADE FOR REPAIRS COVERED BY THIS WARRANTY.

WARRANTY DISCLAIMERS

NO WARRANTY, ORAL OR WRITTEN, EXPRESSED OR IMPLIED, OTHER THE ABOVE WARRANTY
IS MADE WITH REGARD TO THIS REAR VIEW SAFETY, INC. REAR VIEW SAFETY, INC. DISCLAIMS
ANY IMPLIED WARRANTY OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR USE OR

PURPOSE AND ALL OTHER WARRANTIES IN NO EVENT SHALL REAR VIEW SAFETY. INC.

LIABLE FOR ANY INCIDENTAL, SPECIAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES OR FOR

ANY COSTS, ATTORNEY FEES, EXPENSES, LOSSES OR DELAYS ALLEGED TO BE AS A

CONSEQUENCE OF ANY DAMAGE TO, FAILURE OF, OR DEFECT IN ANY PRODUCT INCLUDING,

BUT NOT LIMITED TO, ANY CLAIMS FOR LOSS OF PROFITS.

12

Rear View Safety

DISCLAIMER

REAR VIEW SAFETY AND/OR ITS AFFILIATES DOES NOT GUARANTEE OR PROMISE THAT THE
USER OF OUR SYSTEMS WILL NOT BE IN/PART OF AN ACCIDENT OR OTHERWISE NOT COLLIDE
WITH AN OBJECT AND/OR PERSON. OUR SYSTEMS ARE NOT A SUBSTITUTE FOR CAREFUL
AND CAUTIOUS DRIVING OR FOR THE CONSISTENT ADHERENCE TO ALL APPLICABLE TRAFFIC
LAWS AND MOTOR VEHICLE SAFETY REGULATIONS. THE REAR VIEW SAFETY PRODUCTS ARE

NOT A SUBSTITUTE FOR REARVIEW MIRRORS OR FOR ANY OTHER MOTOR VEHICLE
EQUIPMENT MANDATED BY LAW. OUR CAMERA SYSTEMS HAVE A LIMITED FIELD OF VISION
AND DO NOT PROVIDE A COMPREHENSIVE VIEW OF THE REAR OR SIDE AREA OF THE VEHICLE.
ALWAYS MAKE SURE TO LOOK AROUND YOUR VEHICLE AND USE YOUR MIRRORS TO CONFIRM

REARWARD CLEARANCE AND THAT YOUR VEHICLE CAN MANEUVER SAFELY. REAR VIEW

SAFETY AND/OR ITS AFFILIATES SHALL HAVE NO RESPONSIBILITY OR LIABILITY
FOR DAMAGE AND/OR INJURY RESULTING FROM ACCIDENTS OCCURRING WITH VEHICLES
HAVING SOME OF REAR VIEW SAFETY PRODUCTS INSTALLED AND REAR VIEW SAFETY AND/
OR ITS AFFILIATES, THE MANUFACTURER, DISTRIBUTOR AND SELLER SHALL NOT BE LIABLE
FOR ANY INJURY, LOSS OR DAMAGE, INCIDENTAL OR CONSEQUENTIAL, ARISING OUT OF THE
USE OR INTENDED USE OF THE PRODUCT. IN NO EVENT SHALL REAR VIEW SAFETY AND/OR
ITS AFFILIATES HAVE ANY LIABILITY FOR ANY LOSSES WHETHER DIRECT OR INDIRECT, IN

CONTRACT, TORT OR OTHERWISE INCURRED IN CONNECTION WITH THE SYSTEMS,

INCLUDING BUT NOT LIMITED TO DAMAGED PROPERTY, PERSONAL INJURY AND/OR LOSS OF

LIFE. NEITHER SHALL REAR VIEW SAFETY AND/OR ITS AFFILIATES HAVE ANY

RESPONSIBILITY FOR ANY DECISION, ACTION OR INACTION TAKEN BY ANY PERSON IN

RELIANCE ON REAR VIEW SAFETY SYSTEMS, OR FOR ANY DELAYS, INACCURACIES AND/OR

ERRORS IN CONNECTION WITH OUR SYSTEMS FUNCTIONS.

DISCLAIMER

Reverse With Condence ™

13

If you have any questions

about this product, contact:

Rear View Safety, Inc.

1797 Atlantic Avenue

Brooklyn, NY 11233

800.764.1028
