Russell Hobbs RHSLDW1 User Manual

Slimline Dishwasher

Instruction Manual

Please read these instructions carefully and keep

Model Number: RHSLDW1

For Customer Services, Spare Parts & Manufacturer’s

Saturday: 9am – 1pm

them for future reference

Warranty Information, please call 01204 664 084

Opening times: Monday – Friday 9am – 5pm

Contents

Components ............................................................................................................. 4

Control Panel ............................................................................................................ 5

Technical Specification ........................................................................................... 6

EC declaration of conformity ................................................................................... 6

Safety Information .................................................................................................... 6

Recycling ................................................................................................................ 6

Safety information ................................................................................................... 7

When installing your machine ................................................................................. 7

Daily Use ................................................................................................................ 7

Items not suitable for dishwashing .......................................................................... 8

Installing the machine .............................................................................................. 8

Positioning the machine .......................................................................................... 8

Water Connection ................................................................................................... 9

Water inlet hose ...................................................................................................... 9

Water outlet hose.................................................................................................... 9

Electrical Connection ............................................................................................ 10

Before using the machine ..................................................................................... 11

Water .................................................................................................................... 11

Filling with salt ................................ ................................ ................................ ...... 11

Testing Strip ......................................................................................................... 12

Adjusting salt consumption ................................................................................... 13

Detergent Use ...................................................................................................... 14

Filling the detergent compartment ........................................................................ 14

Combined Detergents ........................................................................................... 15

Rinse Aid .............................................................................................................. 15

Loading your dishwasher ...................................................................................... 16

Dish rack ............................................................................................................... 16

Top basket height adjustment ............................................................................... 16

Examples of loading ............................................................................................. 17

Lower Basket ................................................................................................................................. 17

Upper Basket ................................................................................................................................. 17

Incorrect Loads .............................................................................................................................. 17

Standard Loading ................................................................................................... 18

Capacity ................................................................................................................ 18

Programme Options .............................................................................................. 19

Using the machine ................................................................................................. 20

Switching on the machine ..................................................................................... 20

Selecting a programme ......................................................................................... 20

Monitoring your wash cycle .................................................................................. 20

Changing a programme ........................................................................................ 20

Resetting during a cycle ....................................................................................... 20

Switching the machine off ..................................................................................... 21

Important information ............................................................................................ 21

Maintenance and cleaning ..................................................................................... 22

Oil and lime accumulation ..................................................................................... 22

Machine door seal ................................................................................................ 22

Cleaning the machine ........................................................................................... 22

Filters .................................................................................................................... 22

Spray arms ........................................................................................................... 23

Hose filter ............................................................................................................. 23

Programme monitor light is on and Start/Pause light is flashing ........................... 24

The programme won’t start ................................................................ ................... 24

‘Wash/Dry’ and ‘End’ keep flashing ...................................................................... 24

Control lamps illuminated after cycle has finished ................................................ 25

Detergent residues are left in the detergent compartment .................................... 25

Water will not drain ............................................................................................... 25

The machine stops during cycle ........................................................................... 25

Unexpected noise ................................................................................................. 25

Dishes are still dirty ............................................................................................... 25

White stains present ............................................................................................. 25

Dishes won’t dry ................................................................................................... 26

Rust stains are present on dishes ........................................................................ 26

1. Worktop

6. Filters

7. Rating Plate

12.Upper Basket Track Latch

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-4-

Components

2. Upper Basket

3. Upper Spray Arm

4. Lower Basket

5. Lower Spray Arm

8. Control Panel

9. Detergent and rinse aid dispenser

10.Cutlery Basket

11.Salt Dispenser

1

2 3 4

5

6

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-5-

1. Power on/off
When the power on/off button is pressed, the light on the Start/Pause button
will illuminate.

2. Door Handle
The door handle is used to open/close the door.

3. Start/Pause Button
Once you press the Start/Pause button, the programme you selected with the
selector button will start running and the indicator lamp ‘wash/dry’ will
illuminate. If the programme is paused, the LED light will flash repeatedly.

4. Programme selector knob
With the programme selector knob, you can select your desired programme
by turning clockwise and anti-clockwise.

5. Status indicator
You can monitor the current status of your programme by using the indicator
light shown above (5). There are two progression states, ‘wash/dry’ and ‘End’.

6. Low salt indicator
If the low salt indicator light is illuminated, ensure to replenish the salt supply
in your dishwasher.

Control Panel

Capacity

10 Place Settings

Height

845mm

Width

450mm

Depth

598mm

Net Weight

40 Kg

Electricity Input

220 - 240 V, 50 Hz

Total Power

1900 W

Heating Powee

1800 W

Pump Power

100 W

Drain Pump Power

30 W

Water Supply

Pressure

0,03MPa (0,3 bar) - 1MPa (10)

Current

10A

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-6-

Technical Specification

EC declaration of conformity

All stages related to the machine are executed in accordance with the safety rules
provided in all relevant directive of the European Community.
2004/108/EC, 2006/95/EC, IEC 436/DIN 44990, EN50242

Safety Information

Recycling

- Certain components and the packaging of your machine have been produced
from recyclable materials.

- Plastic parts are marked with international abbreviations.

- Cardboard parts have been produced from recycled paper and they should be
disposed of into relevant disposal area.

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-7-

Safety information

- When you receive your machine, check for damage to the packaging and unit.

- Never start a machine that is damaged. Contact 01204 664 084 for advice if
your machine is received in a damaged state.

When installing your machine

- Ensure you choose a suitable, safe and level place to install your machine.

- This machine should always be installed by a qualified engineer.

- Only original spare parts should be used with this machine.

- Before installing, ensure the machine is unplugged.

- All electrical values must match the values indicated on the rating plate.

- Ensure the machine does not stand on the electricity supply cable.

- Never use an extension cable or multiple power point cable when using the
appliance.

- Before using the machine, run a full cycle with the machine empty.

Daily Use

- This machine is for domestic use only. Commercial use of the washer will void
the manufacturer’s warranty.

- Do not overload the machine. Only place dishwasher safe items in the
machine.

- Only use detergents and rinse aids specifically designed for dishwashers. Use
of other detergents will void the manufacturer’s warranty.

- Do not drink water out of the machine.

- Do not use chemical dissolving agents such as solvents – this may cause an
explosion.

- Check that plastic items are heat resistant before placing them in the
machine.

- Do not overfill the machine – this can cause damage.

- Do not open the door while it is in operation. The machine will stop but there
is still a risk of burning.

- Do not leave the dishwasher door open. This could lead to injury.

- Always place knives and other sharp object face down in the dishwasher to
minimise risk of injury.

- This machine is not designed to be used by children and should only be used
by capable individuals.

- Ensure the appliance is only used by persons with sufficient capabilities,
experience and knowledge. The instructions in this manual should be followed
at all times.

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-8-

- Children should not use this machine as this may result in injury.

Items not suitable for dishwashing

- Do not allow cigarette ashes, candle remains, polish, chemical substances to

enter the dishwasher.

- Cutlery with bone, ivory or nacre coated handles, glued items or items soiled

with abrasive chemicals.

- Plastic items that are not heat resistant.

- Aluminium and silver objects – these may discolour.

- Some delicate glass types, porcelains with printed patterns as they fade even

after the first wash.

- Crystal items should not be put in the dishwasher as these will lose

transparency over time.

- Adhered cutlery that is not heat resistant.

- Lead crystal glasses.

- Cutting boards.

- Items manufactured with synthetic fibre.

- Absorbent items such as sponges and kitchen cloths.

Installing the machine

Positioning the machine

When determining the place to put your machine, ensure there is sufficient room to
fully open the dishwasher door.

Do not install the machine where the room temperature is likely to drop below 0°C.

Before positioning, remove the machine from its packaging taking care to follow
warning instructions attached.

Position the machine close to a water tap or drain.

When moving the machine ensure you do not grip the door or panel.

Ensure there is sufficient room around the machine to allow it to be moved for
cleaning purposes.

For Customer Services, Spare Parts & Manufacturer's Warranty Information please call 01204 664 084

-9-

Ensure that the water inlet hose does not become compressed while positioning the
machine. Also, make sure that the machine does not stand on the electrical cable.

Ensure the machine is level when placed on the surface. Adjust the feet by twisting
clockwise to raise the height of the machine, and anti-clockwise to reduce the height
of the machine. Failure to ensure the machine is level may result in the door not
closing properly.

Water Connection

Ensure the machine is connected to a clean, cold running water supply.

Water inlet hose

Only use the water inlet hose supplied with this machine. Do not re­use old inlet hoses. Connect the water inlet hose directly to the water
inlet tap. The pressure supplied by the tap should be a minimum of

0.03Mpa and a maximum of 1Mpa. If the water pressure is above
1Mpa, a pressure release valve should be fitted. After the connection
is made, the tap should be turned on fully and checked for water
tightness. For the safety of your machine, make sure you always turn
off the water after each cycle.

Note: Aquastop water spouts are used in some models. In case of
using aqua stop, a dangerous tension exists. Do not cut an
Aquastop water spout. Do not allow an aqua stop spout to become
twisted.

Water outlet hose

The water drain hose can be connected either directly to the water
drain hole or to the sink outlet spigot. Using a special bent pipe, the
water can be drained directly into the sink via hooking the pipe over

the edge of the sink. This connection should be a minimum of 50cm
and at a maximum of 110 cm from the floor plane. If a drain hose longer than 4m is
used dishes may remain dirty and warranty will
be void.
