Runco VX-2IX User Manual

OWNER’S OPERATING MANUAL

VX-2ix

Digital Light ProcessingTM Projector

and DHD Controller

TWO YEAR LIMITED WARRANTY

For Projectors, Video Processors and Controllers

Congratulations on your purchase of a Runco video product and welcome to the Runco family! We believe Runco produces
“The World’s Finest Home Theater Products.” With proper installation, setup and care, you should enjoy many years of
unparalleled video performance.

This is a LIMITED WARRANTY as defined in the Magnuson-Moss Warranty Act. Please read it carefully and retain it with your
other important documents.

WHAT IS COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:

SERVICE LABOR: Runco will pay for service labor by a Runco Authorized Service Center when needed as a result of
manufacturing defect for a period of two (2) years from the effective date of delivery to the end user (excluding the lamp).

PARTS (not including the lamp): Runco will provide new or rebuilt replacement parts for the parts that fail due to defects in
materials or workmanship for a period of two (2) years from the effective date of delivery to the end user. Such replacement
parts are then subsequently warranted for the remaining portion (if any) of the original warranty period.

PROJECTOR LAMP: Runco will pay for service labor by a Runco Authorized Service Center when needed as a result of a
manufacturing defect for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to
the end user. In addition, Runco will provide a new or rebuilt replacement lamp for the lamp that fails due to defects in materials
or workmanship for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to the
end user. Such replacement lamps are then subsequently warranted for the remaining portion (if any) of the original warranty
period.

WHAT IS NOT COVERED UNDER THE TERMS OF THIS LIMITED WARRANTY:

This Limited Warranty only covers failure due to defects in materials and workmanship that occur during normal use and does
not cover normal maintenance. This Limited Warranty does not cover cabinets or any appearance items; failure resulting from
accident, misuse, abuse, neglect, mishandling, misapplication, faulty or improper installation or setup adjustments; improper
maintenance, alteration, improper use of any input signal; damage due to lightning or power line surges, spikes and
brownouts; damage that occurs during shipping or transit; or damage that is attributed to acts of God. In the case of remote
control units, damage resulting from leaking, old, damaged or improper batteries is also excluded from coverage under this
Limited Warranty.

CAUTION: THIS LIMITED WARRANTY ONLY COVERS RUNCO PRODUCTS PURCHASED FROM RUNCO AUTHORIZED
DEALERS. ALL OTHER PRODUCTS ARE SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS WARRANTY.
MOREOVER, DAMAGE RESULTING DIRECTLY OR INDIRECTLY FROM IMPROPER INSTALLATION OR SETUP IS
SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS LIMITED WARRANTY. IT IS IMPERATIVE THAT INSTALLATION
AND SETUP WORK BE PERFORMED ONLY BY AN AUTHORIZED RUNCO DEALER TO PROTECT YOUR RIGHTS UNDER
THIS WARRANTY. THIS WILL ALSO ENSURE THAT YOU ENJOY THE FINE PERFORMANCE OF WHICH YOUR RUNCO
PRODUCT IS CAPABLE WHEN INSTALLED AND CALIBRATED BY RUNCO AUTHORIZED PERSONNEL.

RIGHTS, LIMITS AND EXCLUSIONS:

Runco limits its obligations under any implied warranties under state laws to a period not to exceed the warranty period. There
are no express warranties. Runco also excludes any obligation on its part for incidental or consequential damages related to
the failure of this product to function properly. Some states do not allow limitations on how long an implied warranty lasts, and
some states do not allow the exclusion or limitation of incidental or consequential damages. So the above limitations or
exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from
state to state.

Runco VX-2ix Owner’s Operating Manual iii

EFFECTIVE WARRANTY DATE:

This warranty begins on the effective date of delivery to the end user. For your convenience, keep the original bill of sale as
evidence of the purchase date.

IMPORTANT – WARRANTY REGISTRATION:

Please fill out and mail your warranty registration card. It is imperative that Runco knows how to reach you promptly if we
should discover a safety problem or product update for which you must be notified.

CONTACT A RUNCO AUTHORIZED SERVICE CENTER TO OBTAIN SERVICE:

Repairs made under the terms of this Limited Warranty covering your Runco video product will be performed at the location of
the product, during usual working hours, providing location of product is within normal operating distance from a Runco
Authorized Service Center. In some instances it may be necessary for the product to be returned to the Runco factory for
repairs. If, solely in Runco’s judgment, location of product to be repaired is beyond normal operating distance of the closest
Runco Authorized Service Center, or the repair requires the unit be returned to the Runco factory, it is the owner’s
responsibility to arrange for shipment of the product for repair. These arrangements must be made through the selling Runco
Dealer. If this is not possible, contact Runco directly for a Return Authorization number and shipping instructions. Runco will
return product transportation prepaid in the United States, unless no product defect is discovered. In that instance, shipping
costs will be the responsibility of the owner.

COPYRIGHT AND TRADEMARKS:

© Copyright 2006 Runco International. This document contains proprietary information protected by copyright, trademark and
other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any mechanical,
electronic or other means, in any form, without prior written permission of the manufacturer.

Reflection, Enhanced GEN3, DHD, Vivix, Virtual Cinema, CineWide, AutoScope, O-Path, CinOptx, LiveLink, CSMS, SuperOnyx
and VirtualWide are trademarks of Runco International.

THX and the THX logo are trademarks of THX Ltd. which may be registered in some jurisdictions. All rights reserved.

All other trademarks and registered trademarks used in this document are the property of their respective owners.

Runco International products are manufactured under one or more of the following patents: US. Patent 6755540 and Other
Patents Pending.

iv Runco VX-2ix Owner’s Operating Manual

ADDITIONAL INFORMATION:

To locate the name and address of the nearest Runco Authorized Service Center, or for additional information about this
Limited Warranty, please call or write:

RUNCO INTERNATIONAL, INC.

Attn: Customer Service Department

2900 Faber Street

Union City, CA 94587

Ph: [phone]

Fax: [phone]

Toll Free: (800) 23-RUNCO

RUNCO VIDEO-PRODUCT INFORMATION

RETAIN THIS INFORMATION FOR YOUR RECORDS

_________________________________________________________ ________________________________________

Model Purchased Date

____________________________________________________________________________________________________________

Serial Number

____________________________________________________________________________________________________________

Runco Authorized Dealer Name

____________________________________________________________________________________________________________

Address

____________________________________________ __________________ ________________________

City State/Province Postal Code

____________________________________________ _______________________________________________________

Phone Fax

Runco VX-2ix Owner’s Operating Manual v

Safety Precautions

Thank you for your purchase of this quality Runco video projector! It has been designed to provide you with the quality of video
that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the
menus and operation.

WARNING

CAUTION

RISK OFELECTRIC SHOCK

DO NOTOPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

CAUTION:

SERVICE PERSONNEL.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

This symbol is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock.

This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the
literature accompanying the appliance.

4. Do not use this equipment near water, outdoors or otherwise exposed to the elements.

5. Clean only with a dry cloth.

6. Do not block any ventilation openings.

7. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.

8. Do not defeat the safety feature of the polarized or grounding type plug. A polarized type plug has two blades with one
wider than the other. A grounding type plug has two blades and a third grounding prong. The third prong is provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for the replacement of the obsolete
outlet.

9. The 12V trigger only outputs DC 12V signal for triggering. Do not connect to any other power input or output. This could
cause damage to this unit.

10. Only use accessories specified by Runco International.

11. Keep the packing material in case the equipment should ever need to be shipped.

12. Unplug this projector during lightning storms or when it will not be used for an extended period of time.

13. The lamp becomes extremely hot during operation. Allow the projector to cool down for approximately 45 minutes prior to
removing the lamp assembly for replacement. Do not operate lamps beyond the rated lamp life. Excessive operation of
lamps beyond rated life could cause them to explode in rare occasions.

14. Refer all servicing to qualified service personnel. Servicing is required when the projector has been damaged in any way,
objects have fallen or spilled into the projector, the projector has been exposed to rain or moisture, does not operate
normally, or has been dropped.

vi Runco VX-2ix Owner’s Operating Manual

1Table of Contents

TWO YEAR LIMITED WARRANTY ................................................................................. iii

Safety Precautions ......................................................................................................... vi

1. Introduction ...............................................................................................................1

About This Manual .......................................................................................................1

Target Audience .....................................................................................................1

If You Have Comments About This Manual.............................................................1

Textual and Graphic Conventions ...........................................................................1

Using This Manual ........................................................................................................2

Description, Features and Benefits ...............................................................................3

Key Features and Benefits ......................................................................................4

Parts List ................................................................................................................4

2. Controls and Functions ............................................................................................ 5

VX-2ix at a Glance ........................................................................................................5

VX-2ix Rear Panel ........................................................................................................6

VX-2ix Remote Control .................................................................................................9

3. Installation ...............................................................................................................13

Remote Control ..........................................................................................................13

Notes on Batteries ................................................................................................ 13

Notes on Remote Control Operation .....................................................................13

Quick Setup ...............................................................................................................14

Installation Considerations ..........................................................................................15

Installation Type .................................................................................................... 15

Ambient Light .......................................................................................................15

Throw Distance.....................................................................................................16

Vertical and Horizontal Position............................................................................. 17

Vertical and Horizontal Lens Shift..........................................................................17

Folded Optics .......................................................................................................19

Other Considerations ............................................................................................ 19

Installing the Optional CineWide Lens .........................................................................19

Runco VX-2ix Owner’s Operating Manual vii

Table of Contents

Mounting the VX-2ix ...................................................................................................20

Floor Mounting (Upright) ....................................................................................... 20

Ceiling Mounting (Inverted)....................................................................................20

Adjusting the Projection Angle ..............................................................................20

Connections to the VX-2ix ..........................................................................................21

Connector Panel Access.......................................................................................21

Connecting the VX-2ix to Source Components .....................................................21

RS-232 Controller Connection ..............................................................................25

Connecting 12-Volt Trigger Outputs to External Theater Equipment......................25

Connecting to AC Power ......................................................................................26

4. Operation .................................................................................................................27

Turning on the Power ................................................................................................. 27

Adjusting the Picture Orientation ................................................................................27

Lens Adjustments ...................................................................................................... 28

Focus ..................................................................................................................28

Zoom ...................................................................................................................28

Shift .....................................................................................................................28

Using the On-Screen Menus ......................................................................................28

Main Menu ...........................................................................................................30

Input Source......................................................................................................... 30

Aspect Ratio.........................................................................................................30

Picture .................................................................................................................33

Input Position........................................................................................................36

ISF Presets ...........................................................................................................37

Information ........................................................................................................... 37

Calibration ............................................................................................................38

Service ................................................................................................................40

5. Maintenance and Troubleshooting ........................................................................ 45

Lamp Replacement ....................................................................................................45

Lens Replacement .....................................................................................................45

Troubleshooting Tips ..................................................................................................49

6. Serial Communications ..........................................................................................51

RS-232 Connection and Port Configuration ...............................................................51

Serial Command Syntax .............................................................................................51

7. Specifications ..........................................................................................................57

VX-2ix Specifications ..................................................................................................57

VX-2ix Dimensions .....................................................................................................60

viii Runco VX-2ix Owner’s Operating Manual

Table of Contents

APPENDIX A. VX-2ix Color Gamut Adjustment ........................................................A-1

Required Hardware and Software ............................................................................ A-2

Serial Connections and Equipment Setup ................................................................ A-2

Serial Command Syntax ........................................................................................... A-3

Adjusting the Gamut ................................................................................................. A-4

Runco VX-2ix Owner’s Operating Manual ix

Table of Contents

Notes:

x Runco VX-2ix Owner’s Operating Manual

1List of Figures

2-1. VX-2ix Front/Bottom/Side View ....................................................................................5

2-2. VX-2ix Rear Panel.........................................................................................................6

2-3. VX-2ix Remote Control .................................................................................................9

3-1. Estimating Throw Distance .........................................................................................16

3-2. Projector Placement ...................................................................................................17

3-3. Vertical Lens Shift (Example Only) ...............................................................................18

3-4. Horizontal Lens Shift (Example Only)...........................................................................18

3-5. Folded Optics.............................................................................................................19

3-6. DVI Source Connections ............................................................................................ 21

3-7. Digital (DTV) RGB Connections...................................................................................22

3-8. Analog RGB Connections...........................................................................................23

3-9. Composite, S-Video and Component Video Connections...........................................24

3-10. RS-232 Control System Connection.........................................................................25

3-11. Connecting the 12-Volt Trigger Output to the AutoScope Lens Motor ......................25

3-12. Connecting a 12-Volt Trigger Output to Other Equipment.........................................26

4-1. VX-2ix OSD Menu Structure .......................................................................................29

4-2. Typical PLUGE Pattern for Adjusting Brightness .........................................................33

4-3. Typical Gray Bar Pattern for Adjusting Contrast .......................................................... 34

4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................35

4-5. Typical Test Pattern for Adjusting Sharpness..............................................................36

7-1. VX-2ix Dimensions .....................................................................................................60

A-1. CIE 1931 Chromaticity Diagram ............................................................................... A-1

A-2. Equipment Setup for Color Gamut Adjustment......................................................... A-2

A-3. VX-2ix Secondary RS-232 Port ................................................................................ A-3

Runco VX-2ix Owner’s Operating Manual xi

List of Figures

Notes:

xii Runco VX-2ix Owner’s Operating Manual

1. Introduction

This Owner’s Manual describes how to install, set up and operate the Runco VX-2ix DLP
Projector. Throughout this manual, the Runco VX-2ix DLP Projector is referred to simply
as the “VX-2ix.”

most out of the VX-2ix.

Runco has made every effort to ensure that this manual is accurate as of the date it was
printed. However, because of ongoing product improvements and customer feedback, it
may require updating from time to time. You can always find the latest version of this and
other Runco product manuals on-line, at www.runco.com.

Runco welcomes your comments about this manual. Send them to [e-mail].

Text Conventions: The following conventions are used in this manual, in order to clarify
the information and instructions provided:

• Remote and built-in keypad button identifiers are set in upper-case bold type; for
example, “Press EXIT to return to the previous menu.”

• Computer input (commands you type) and output (responses that appear on-screen) is
shown in monospace (fixed-width) type; for example: “To change the aspect ratio to
Letterbox, type LETTERBOX <Enter>.”

• All keys with functional names are initial-capped, set in bold type and enclosed in angle
brackets. These keys are the following: <Enter>, <Spacebar>, <Control>, <Esc>
and <Tab>.

• <Enter> indicates that you may press either the RETURN or ENTER key on your
keyboard if it has both keys.

1.1 About This Manual

Target AudienceRunco has prepared this manual to help home theater installers and end users get the

If You Have Comments About This Manual...

Textual and Graphic Conventions

In addition to these conventions, underlining, boldface and/or italics are occasionally used
to highlight important information, as in this example:

A carriage return must be used after each command or string.

Note

Runco VX-2ix Owner’s Operating Manual 1

Introduction

Graphic Conventions: These symbols appear in numerous places throughout the
manual, to emphasize points that you must keep in mind to avoid problems with your
equipment or injury:

1.2

Using This Manual

Tip

certain features.

NOTES emphasize text with unusual importance or special

TIPS highlight time-saving short cuts and helpful guidelines for using

Note

significance. They also provide supplemental information.

CAUTIONS alert users that a given action or omitted action can

Caution

degrade performance or cause a malfunction.

WARNINGS appear when a given action or omitted action can result

WARNING

in damage to the equipment, or possible non-fatal injury to the user.

DANGER appears when a given action can cause severe injury or

DANGER!

death.

Use the following table to locate the specific information you need in this manual.

If you need... ... Turn to page:

Information about obtaining service iv

General information about the VX-2ix DLP Projec­tor

Installation instructions 13

First-time configuration instructions 27

Advanced configuration instructions 38

Troubleshooting tips 49

VX-2ix DLP Projector specifications 57

3

2 Runco VX-2ix Owner’s Operating Manual

Introduction

Runco steps into the future once again with the Video Xtreme™ VX-2ix Digital Light
Processing (DLP™) Projector, one of the world’s first THX
theater projectors.

Note

The VX-2ix optical light engine utilizes three, 16:9 SuperOnyx™ Digital Micromirror
Device™ (DMD™) chips featuring 1280 x 720, high-definition resolution and 12-degree
mirror tilt for unsurpassed black level performance. Unlike previous, single-chip DLP
implementations, no color wheel is used. This reduces mechanical complexity and
compromises to color spectrum purity. The impressive brightness inherent in 3-chip
systems is further bolstered by the improved contrast capabilities of the VX-2ix light
engine design, offering the best of both worlds.

The VX-2ix is equipped with an embedded, all-digital signal processor/controller featuring
advanced Vivix II™ video processing, superb scaling and aspect ratio control. The VX-2ix
is enhanced further by significant horizontal and vertical lens shift capability for maximum
installation flexibility.

The VX-2ix produces an impressive 2500 ANSI lumens of light output (CSMS™ light
output of 52.1 ft-Lamberts). The VX-2ix’s 16:9 native aspect ratio DMD array makes it
ideal for widescreen viewing, while its 3-chip, 1280 x 720 native resolution produces crisp,
crystal clear high-definition images with richly saturated colors, deep black levels and
natural, highly refined detail.

THX recommends the use of 720p source material for optimal
performance with this product.

®

Certified, high-definition home

1.3 Description, Features and Benefits

This advanced design provides pure digital connections from input to light engine for
absolutely stellar pictures. In addition, Runco’s multiple aspect ratio control includes its
unique VirtualWide™ mode for viewing standard video formats in widescreen without loss
of image quality.

For uncompromising widescreen reproduction of movies originally filmed in the “scope”
(2.35:1) format, the VX-2ix can be equipped with Runco’s patent-pending CineWide™
technology, a combination of software, electronics and high-quality anamorphic optics.
CineWide maintains constant vertical height on the screen just as in a movie theater.
When a viewer transitions from 1.78:1 (16:9) program material to 2.35:1, the image simply
gets wider while full height is maintained. Also available with the VX-2ix is CineWide with
AutoScope™, an enhanced, remote-controlled motorized version of CineWide.

Note

Discrete IR and RS-232 control make custom installation seamless, while discrete source
and aspect ratio selection accommodate any automation control system.

CineWide requires the use of a 2.35:1 or similar aspect ratio superwide
format screen.

Runco VX-2ix Owner’s Operating Manual 3

Introduction

Key Features and Benefits The VX-2ix offers these key features and benefits:

Parts List Your VX-2ix is shipped with the following items. If any items are missing or damaged,

➤

• Native Resolution: 1280 x 720 (16:9 Native Aspect Ratio)

• Three-chip Digital Light Processing (DLP™) system

• Two DVI Inputs with High-bandwidth Digital Content Protection (HDCP)

• HDTV Compatible

•CinOptx™ Proteus lens options for stunning sharpness and throw distance flexibility

➤

please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.

• VX-2ix DLP Projector

• Remote Control Unit and two (2), AAA-size batteries

• DVI Cable, 16.4 feet (5.0 meters)

• AC Power Cord

• 3.0-mm, Ball-Point Hex Driver

• (1) Warranty information and registration card

• Runco VX-2ix Owner’s Operating Manual (this document)

Optional Accessories:

• CineWide™ technology (fixed, secondary anamorphic lens)

• CineWide™ with AutoScope™ system (secondary anamorphic lens and motorized
mount)

• Ceiling mount kit

• LiveLink™ DVI Cabling System

4 Runco VX-2ix Owner’s Operating Manual

2. Controls and Functions

Figure 2-1 shows the key VX-2ix components.

1

23

455

6

2.1 VX-2ix at a Glance

Figure 2-1. VX-2ix Front/Bottom/Side View

1. INTAKE VENT

2. LENS

3. RUNCO LOGO
The logo can be rotated to match the projector orientation: inverted (ceiling-mounted)
or upright. To rotate the logo, grip it at the sides, pull it away from the projector and
rotate it 180 degrees.

4. EXHAUST VENT

5. CABLE OPENINGS
Pass cables through these openings.

6. IR SENSOR

Runco VX-2ix Owner’s Operating Manual 5

Controls and Functions

2.2

VX-2ix Rear Panel

RUNCO INTERNATIONAL

UNION CITY, CA

VX-2i DIGITAL PROJECTOR

MADE IN USA

Figure 2-2 shows the VX-2ix rear panel.

1237 864 5

INPUTS

R
Pr

G

R

Y

Pr

DVI 1

DVI 1

(LAMP COVER)

INPUTS

B

G
Y

Pb

B

Pb

DVI 2

DVI 2

HV

HD1

HV

HD2

Pb

Pb

COMPONENT VIDEO

HD1

HD2

Pr

Pr Y

TRIGGERS

1

1

COMPONENT VIDEO

VIDEO

Y

VIDEO

TRIGGERS

3

2

2

ENTER MENU

IR

3

IR

S-VIDEO 1

S-VIDEO 1

S-VIDEO 2

S-VIDEO 2

RS-232

CONTROL

ENTERMENU

CONTROL

RS-232

STANDBY / POWER

OFF / ON

ON / OFF

AC IN 110-240V 60HZ

POWER / STANDBY

AC IN 110-240V 60HZ

Figure 2-2. VX-2ix Rear Panel

9 10 11 151412 16 1713 1918 20

1. DVI 1 / DVI 2 (Digital)
Two, HDCP-compliant digital video inputs for connecting a DVD player or HD tuner
with a DVI or HDMI output.

2. COMPONENT VIDEO (RCA connectors)
Standard Definition (480i/576i) Component (YPrPb) input. This is the input for
component video from sources such as DVD players.

For best results, do not run your DVD player in progressive mode.

Tip

3. HD1 / HD2 (Analog BNC connectors)
Two inputs (five BNCs per input) for connecting either RGB or component
high-definition television signals. The VX-2ix automatically detects the signal format:
RGB(HV) or YPrPb, 480p, 720p, 480i, 576i or 1080i.

4. COMPOSITE VIDEO INPUT
Standard composite video input for connecting a VCR, laser disc player or other
composite video source.

6 Runco VX-2ix Owner’s Operating Manual

5. 12-VOLT (750 mA) TRIGGER OUTPUTS
Connection for up to three (3), 12-volt trigger-controlled devices. These can be
retractable screens, screen masks or the Runco CineWide with AutoScope system.

6. S-VIDEO 1 / S-VIDEO 2
Two, standard S-Video inputs for connecting a DVD player, satellite receiver or Super
VHS (S-VHS) VCR.

7. IR
Wired input from an external remote control or infrared receiver. It is a 3.5-mm, mini
phono jack, wired as follows:
Ring = +5V
Tip = IR Input
Sleeve = Ground

Controls and Functions

Note

to the wired IR input, the IR sensors on the projector are disabled.

8. RS-232 CONTROL PORT
A female, 9-pin D-sub connector for interfacing with a PC or home theater
automation/control system.

9. VACUUM FLUORESCENT DISPLAY
Can be used instead of the On-Screen Display (OSD). Displays currently-selected
menu or – if no menu is selected – the current source, signal format (NTSC or PAL),
input resolution and aspect ratio.

10. UP BUTTON
Use to direct-select aspect ratios or move the menu cursor up in the On-Screen
Display. When no menus are present on-screen, the UP button toggles you through

When an external remote control or infrared receiver is connected

aspect ratios in the following order:
Anamorphic - Standard (4:3) - Letterbox - VirtualWide - Cinema - Virtualwide 2.35

(Virtualwide 2.35 is available only on CineWide-equipped projectors. For more
information about aspect ratios, refer to

Table 4-1.)

11. LEFT BUTTON
Used to direct-select inputs or move the menu cursor left in the On Screen Display.
When no menu is present on-screen, the LEFT button toggles you through the
different sources, in this order:
DVI 2 - DVI 1 - HD/RGB2 - HD/RGB1 - Component SD - S-Video 2 - S-Video 1 ­Composite

12. DOWN BUTTON
Use to direct-select aspect ratios or move the menu cursor down in the On-Screen
Display. When no menu is present on-screen, this button toggles you through the
different aspect ratios, in this order:
Virtualwide 2.35 - Cinema - VirtualWide - Letterbox - Standard (4:3) - Anamorphic

13. ENTER BUTTON
When an item is highlighted on the On-Screen Display, the ENTER button selects the
item.

Runco VX-2ix Owner’s Operating Manual 7

Controls and Functions

14. RIGHT BUTTON
Used to direct-select inputs or move the menu cursor right in the On Screen Display.
When no menus are present on-screen, the RIGHT button toggles you through the
different sources, in this order:
Composite - S-Video 1 - S-Video 2 - Component SD - HD/RGB 1 - HD/RGB 2 - DVI 1

- DVI

2

15. MENU BUTTON
Pressing the MENU button brings up the main menu. Also, if you are in an adjustment
mode or function, pressing MENU brings the menu back one level.

16. IR SENSOR
Receives the IR commands from the remote.

17. POWER BUTTON
Press once to turn on the VX-2ix. Press it again to put it into Standby mode. For a
discrete on or off command, you can use the direct access buttons on the remote
control.

18. POWER INPUT (100 to 240 VAC)
Connect the VX-2ix to power here.

19. MAIN POWER SWITCH
Disconnects or applies power to the VX-2ix.

20. POWER/STANDBY LED

8 Runco VX-2ix Owner’s Operating Manual

Controls and Functions

Figure 2-3 shows the VX-2ix remote control, and the paragraphs that follow describe its
functionality.

2

1

3

4

6

5

8

7

10

11

9

12

2.3 VX-2ix Remote Control

13

Figure 2-3. VX-2ix Remote Control

Runco VX-2ix Owner’s Operating Manual 9

Controls and Functions

1. IR OUTPUT INDICATOR
Lights when a button is pressed to indicate that an IR signal is being transmitted.

2. ON / OFF
Press to turn the projector on or off.

3. ENTER
Press to select a highlighted menu item or confirm a changed setting.

4. Cursor Buttons ( , , , )
Use these buttons to select items or settings, adjust settings or switch display
patterns.

When no menus are present on-screen, the UP and DOWN buttons toggle through
the available aspect ratios, in this order:
UP Button = Anamorphic - Standard (4:3) - Letterbox - VirtualWide - Cinema ­Virtualwide 2.35
DOWN Button = Virtualwide 2.35 - Cinema - VirtualWide - Letterbox - Standard (4:3)

- Anamorphic

Virtualwide 2.35 is available only on CineWide-equipped projectors.

Note

For more information about aspect ratios, refer to

Table 4-1.

Likewise, the LEFT and RIGHT buttons toggle through the different source inputs, in
this order:
LEFT Button = DVI 2 - DVI 1 - HD/RGB2 - HD/RGB 1 - Component SD - S-Video 2 ­S-Video 1 - Composite
RIGHT Button = Composite - S-Video 1 - S-Video 2 - Component SD - HD/RGB 1 ­HD/RGB 2 - DVI 1 - DVI 2

5. LIGHT
Press to illuminate the buttons. (Not available on all models.)

6. MENU
Press this button to access the OSD controls, or to exit the current menu and return
to the previous one.

7. VIDEO (1)
Press to select Composite video input as the source or to enter the numeric
character

“1.”

8. COMP (Component) (2)
Press to select Component SD (480i/576i) video input as the source or to enter the
numeric character “2.”

10 Runco VX-2ix Owner’s Operating Manual

9. Aspect Ratio Selection Buttons
Use the red buttons to select an aspect ratio directly or to enter numeric characters,
as follows:

ANA (Anamorphic) (3)

For viewing 16:9 DVDs or HDTV programs in their native aspect ratio.

4X3 (Standard 4:3) (6)

Scales the input signal to fit 4:3 display mode in the center of the screen.

LETBOX (Letterbox) (9)

For viewing LaserDisc movies or non-anamorphic DVDs on a 4:3 screen.

V-WIDE (VirtualWide)

Enlarges a 4:3 image horizontally in a NON-linear fashion to fit 16:9 full screen display.

CINEMA
For viewing 2.35:1 source material.

SVC (CineWide-equipped projectors only)

Selects the Virtualwide 2.35 aspect ratio, used for viewing 16:9 source material on a

2.35:1 screen.

10. S-VID 1 (4) / S-VID 2 (5) (S-Video)
Press to select an S-Video input or to enter the numeric character “4” or “5.”

Controls and Functions

11. HD 1 (7) / HD 2 (8)
Press to select a HD (RGBHV or YPbPr component) input or to enter the numeric
character “7” or “8.”

12. DVI 1 / DVI 2 (0)
Press to select a Digital Video input. Press DVI2 to enter the numeric character “0.”

13. Memory Preset Buttons:

ISF™ NT (Night)

Press to recall settings for the current input from the “ISF Night” memory preset.

ISF DAY

Press to recall settings for the current input from the “ISF Day” memory preset.

CUST 1

Press to recall settings for the current input from the “Custom 1” memory preset.

CUST 2

Press to recall settings for the current input from the “Custom 2” memory preset.

Runco VX-2ix Owner’s Operating Manual 11

Controls and Functions

Notes:

12 Runco VX-2ix Owner’s Operating Manual

3. Installation

To install batteries in the remote control,
press up on the battery cover retainer clip
and lift off the cover. Install the two AAA
batteries with the correct polarity and then
replace the cover.

• Do not mix an old battery with a new one or different types of batteries.

• If you will not use the remote control for a long time, remove the batteries to avoid

damage from battery leakage.

• Make sure that there is nothing obstructing the infrared beam between the remote

control and the IR receiver on the projector.

• If the effective range of the remote control decreases, or it stops working, replace the

batteries with new ones.

• The remote control may fail to operate if the infrared remote sensor is exposed to bright

sunlight or fluorescent lighting.

• Ambient conditions may possibly impede the operation of the remote control. If this

happens, point the remote control at the projector, and repeat the operation.

• The Ø icon appears on the screen when a button for an unavailable function is pressed.

3.1 Remote Control

Notes on Batteries• Make sure that the battery polarities are correct when installing the batteries.

Notes on Remote Control Operation

Runco VX-2ix Owner’s Operating Manual 13

Installation

3.2

Quick Setup

Table 3-1 gives a quick overview of the VX-2ix installation process. The sections following
this one provide detailed instructions.

Installation should be performed by a qualified custom video

Note

installation specialist.

Table 3-1. Installation Overview

Step Procedure

1 Choose a location for the projector 15

Install CineWide (secondary anamorphic) lens (optional) 19

2

3 Connect signal sources to the projector 21

4 Connect external controller to RS-232 port (optional) 25

5 Connect AutoScope lens motor or other home theater

equipment to 12-volt trigger outputs (optional)

6 Apply power to the projector 26, 27

For Details, Refer to

page...

25

7 For rear-screen and/or ceiling-mount installations, select

the proper picture orientation

8 Lens adjustments: projected image size (zoom), position

(shift) and focus

9 Projector calibration: adjust the following for each input,

starting with Component SD; save settings when finished:

• Aspect ratio

• Brightness

• Contrast

• Color level

• Tint

• Input position

27

17, 28

30 through 37

14 Runco VX-2ix Owner’s Operating Manual

Installation

Proper installation of your projector will ensure the quality of your display. Whether you are
installing a projector temporarily or permanently, you should take the following into
account to ensure your projector performs optimally.

inverted mount.

Table 3-2 compares these various installation methods.

Table 3-2. Projector Installation Options

Advantages Considerations

Front Screen, Floor Mount Installation

• Easy to set up

• Can be moved or changed quickly

• Easy to access

Front Screen, Inverted Mount (ceiling) Installation

• Does not take up audience space

• Projector is unobtrusive

• Projector cannot be accidentally moved

Rear Screen, Floor Mount Installation

• Projector is completely hidden

• Projector is easily accessed

• Usually good ambient light rejection

• Shares floor space with audience

• Installation is more permanent

• Projector access is more difficult

• Requires separate room

• Installation cost is usually higher

3.3 Installation Considerations

Installation TypeChoose the installation type that best suits your needs: front or rear screen, floor mount or

Rear Screen, Inverted Mount (ceiling) Installation

• Projector is completely hidden

• Usually good ambient light rejection

Rear Screen, Floor Mount with Mirror

• Projector is completely hidden

• Usually good ambient light rejection

• Requires less space behind screen than
other rear screen installations

• Requires separate room

• Installation cost is usually higher

• Requires separate room

• Installation cost is usually higher

images will be noticeably reduced if light directly strikes the screen, such as when a shaft
of light from a window or floodlight falls on the image. Images may then appear washed
out and less vibrant.

Ambient LightIn general, minimize or eliminate light sources directed at the screen. Contrast ratio in your

Runco VX-2ix Owner’s Operating Manual 15

Installation

Throw Distance Throw distance is the distance measured from the front of the projector to the screen.

➤

This is an important calculation in any projector installation as it determines whether or not
you have enough room to install your projector with a desired screen size and if your
image will be the right size for your screen.

You can quickly estimate the throw distance by taking the width of the screen and
multiplying it by the lens throw ratio; see

Figure 3-1. The result of this calculation tells you
roughly how far back the projector should be positioned from the screen in order to
project a focused image large enough to fill the screen.

Estimating Throw Distance

Throw Distance (TD) = Screen Width (w) x Lens Throw Ratio

Screen width (w)

TD

Figure 3-1. Estimating Throw Distance

Table 3-3 lists the available lens options for the VX-2ix and their associated throw ratios.

Table 3-3. VX-2ix Lens Options and Throw Ratios

Lens Option

(Note 2)

Proteus A

Proteus B

Proteus C

Proteus D

Proteus E

Proteus F

Notes:

Throw Range in

Throw Ratio

with Primary

Lens Only

0.64 (Fixed)

1.22 - 1.44 117.12 138.24

1.45 - 1.76 139.20 168.96

1.82 - 2.39 174.72 229.44 1.39 - 1.77 176.39 224.61

2.42 - 3.57 232.32 342.72 1.84 - 2.64 233.50 335.02

3.63 - 5.72 348.48 549.12 2.75 - 4.26 348.98 540.59

inches, with

96x54-inch (1.78:1)

Screen

Minimum Maximum Minimum Maximum

For rear-screen installa-

tions only. Contact

Runco Technical Support

for more information.

Throw Ratio

with Primary

Lens and

Anamorphic

Lens

Throw Range in

inches, with

126.9x54-inch (2.35:1)
Screen

Not Applicable

(Note 2)

1. Throw distance does not affect image quality, provided these ranges are taken into account.

2. Only the Proteus D, E and F lenses can be used with the optional CineWide (secondary
anamorphic) lens. Doing so affects the throw distances as shown here.

16 Runco VX-2ix Owner’s Operating Manual

Installation

Proper placement of the projector relative to the screen will yield a rectangular,
perfectly-centered image that completely fills the screen.

Ideally, the projector should be positioned perpendicular to the screen and in such a way
that the lens center and screen center are aligned with each other, as shown in

Ceiling Installation

Height

Projection Distance

Lens Center

x

Screen Lens Center

Ceiling

Figure 3-2.

Floor Installation

Lens Center

x

Height

Screen

Lens Center

Vertical and Horizontal Position

Projection Distance

Floor

Figure 3-2. Projector Placement

If it is not possible to align the projector and screen as shown in Figure 3-2, you can use
the lens shift controls to center the image on the screen. Lens shift is generally expressed
as a percentage of the screen height or width, as shown in

Figure 3-3 and Figure 3-4.

Vertical Lens Shift: The VX-2ix zoom lenses (Proteus B through F) provide up to 80% of
downward vertical lens shift. For example, with a 96 x 54-inch (16:9) screen, you can shift
the image up to 43.20 inches (1.10

meters) below the screen center. (Upward vertical lens
shift is not possible. Vertical lens shift is not possible in either direction with the Proteus A
lens.)

Horizontal Lens Shift: The VX-2ix zoom lenses (Proteus B through F) allow up to 10% of
horizontal lens shift in either direction (left or right). For example, with a 96 x 54-inch (16:9)
screen, you can shift the image up to 9.60 inches (24.38 cm) left or right of the screen
center. (Horizontal lens shift is not possible with the Proteus A lens.)

1. With no vertical or horizontal lens shift, the lens center and

Note

screen center are aligned with each other.

2. Vertical shift limits are percentages of the screen height.
Horizontal shift limits are percentages of the screen width.

Vertical and Horizontal Lens Shift

3. Vertical lens shift figures apply to ceiling mount
configurations. For floor installations (where the projector is

upright), reverse the up/down vertical offset percentages.

Runco VX-2ix Owner’s Operating Manual 17

Installation

Base plate

to lens center =

approx. 5-6" (depending

on the amount of lens shift)

Screen Center

0%

50% Height

Lens Shift

(0.5 x H)

100% Height

Lens Shift

(1.0 x H)

150% Height

Lens Shift

(1.5 x H)

Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular

lens or projector is used in this example.

Figure 3-3. Vertical Lens Shift (Example Only)

150% Width Lens Shift

(1.5 x W)

100% Width Lens Shift

(1.0 x W)

50% Width Lens Shift

(0.5 x W)

Screen Center

0%

Screen Width (W)

Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular

lens or projector is used in this example.

Figure 3-4. Horizontal Lens Shift (Example Only)

18 Runco VX-2ix Owner’s Operating Manual

used to fold the optical path, as shown in
mirror must be accurately set. If you are considering this type of installation, contact your
dealer for assistance.

Figure 3-5. Folded Optics

• Keep the ambient temperature constant and below 35°C (95°F). Keep the projector
away from heating and/or air conditioning vents. Changes in temperature may cause
drifts in the projector circuitry, which may affect performance.

• Keep the projector away from devices that radiate electromagnetic energy such as
motors and transformers. Common sources of these include slide projectors,
speakers, power amplifiers and elevators.

Figure 3-5. The position of the projector and

Installation

Folded OpticsIn rear screen applications where space behind the projector is limited, a mirror may be

Other ConsiderationsOther considerations and tips that can help improve your installation:

If you are installing a VX-2ix with the optional CineWide or CineWide with AutoScope
system, install the secondary anamorphic lens in accordance with the instructions
provided with the lens installation kit.

3.4 Installing the Optional CineWide Lens

Runco VX-2ix Owner’s Operating Manual 19

Installation

3.5

Mounting the VX-2ix

Floor Mounting (Upright) In typical front and rear screen installations, the projector can be mounted to a secure and

Ceiling Mounting

(Inverted)

Adjusting the Projection

Angle

There are several methods for mounting the projector. Depending on your chosen
installation, one method may be more suitable than another.

➤

level surface such as a table or cart. Carts are useful when moving a projector during a
presentation or from site to site. If possible, lock the wheels when it’s in position to prevent
it from being moved during a presentation.

For fixed installations, and for those that want the projector out of sight or have a limited

➤

space for projector and audience, you can invert the VX-2ix and suspend it from the
ceiling using a specially-designed ceiling mount fixture.

Note

The projector can also be inverted and placed in an enclosure above and behind the
viewing area. Install four feet on the inside bottom surface of the enclosure on which the
projector can rest. A variety of materials can be used for this purpose (for example, rubber
crutch tips or turntable feet).

If the screen is significantly higher or lower than the projector, you can also tilt the

➤

projector at a slight angle. In a ceiling installation, you do this by adjusting the ceiling
mount.

Use only the Runco-approved ceiling mount kit designed for your
projector. Install the mount kit according to the instructions
provided with it.

If you do this, you may need to shift the image using the on-screen display (OSD) controls,
to compensate. For detailed instructions, refer to
page 28.

Using the On-Screen Menus on

20 Runco VX-2ix Owner’s Operating Manual

Installation

Proceed as follows to connect the VX-2ix to your video sources, external controller(s) – if
present – and AC power.

When connecting your equipment:

• Turn off all equipment before making any connections.

• Use the correct signal cables for each source.

• Ensure that the cables are securely connected. Tighten the thumbscrews on
connectors that have them.

Connect your video sources to the VX-2ix as shown and described in the sections that
follow.

DVI Connections: See Figure 3-6.

Use the DVI inputs whenever possible. This ensures the highest

Tip

video quality because the signal is carried in the digital domain
throughout the entire signal path, from source component output
into the projector.

INPUTS

INPUTS

B

Pb

B

Pb

DVI 2

HV

HV

DVI 2

HD1

HD1

HD2

HD2

Pr

Pb

Pb

Pr Y

COMPONENT VIDEO

123

1

COMPONENT VIDEO

Y

VIDEO

TRIGGERS

VIDEO

2

TRIGGERS

3

S-VIDEO 1

S-VIDEO 2

S-VIDEO 1

S-VIDEO 2

IR

IR

RS-232

CONTROL

CONTROL

RS-232

R
Pr

R

Pr

DVI 1

DVI 1

G
Y

G
Y

3.6 Connections to the VX-2ix

Connector Panel AccessTo access the connector panel, pull firmly on the cable access cover to open it.

Connecting the VX-2ix to Source Components

Figure 3-6. DVI Source Connections

Runco VX-2ix Owner’s Operating Manual 21

DVI Source

(DVD Player or

HD Tuner with

HDMI or DVI out)

Installation

Digital (DTV) RGB or Component Video Connections: See Figure 3-7.

INPUTS

Pb

B

DVI 2

INPUTS

B

Pb

HV

HV

DVI 2

HD1

HD1

HD2

HD2

Pr

Pb

Pb

Pr Y

COMPONENT VIDEO

123

1

COMPONENT VIDEO

Y

VIDEO

TRIGGERS

VIDEO

TRIGGERS

2

S-VIDEO 1

S-VIDEO 2

R

Pr

R
Pr

DVI 1

DVI 1

G
Y

G
Y

Red/Pr Green/Y Blue/Pb Horiz Vert

3

S-VIDEO 1

S-VIDEO 2

IR

IR

RS-232

CONTROL

CONTROL

RS-232

DTV or Progressive

Component (YPbPr)

Source

Figure 3-7. Digital (DTV) RGB Connections

22 Runco VX-2ix Owner’s Operating Manual

Analog (Computer) RGB Connections: See Figure 3-8.

INPUTS

INPUTS

R
Pr

G

R
Pr

DVI 1

DVI 1

Y

Red Green Blue Horiz Vert

B

G
Y

B

Pb

DVI 2

Pb

DVI 2

HV

HD1

HD1

HD2

HD2

HV

Pb

Pb

Pr Y

COMPONENT VIDEO

TRIGGERS

TRIGGERS

1

23

12

COMPONENT VIDEO

Pr

VIDEO

Y

VIDEO

3

S-VIDEO 1

S-VIDEO 2

S-VIDEO 1

S-VIDEO 2

IR

IR

RS-232

CONTROL

CONTROL

RS-232

Installation

Personal Computer

Figure 3-8. Analog RGB Connections

Runco VX-2ix Owner’s Operating Manual 23

Installation

Composite/S-Video/Component Video Connections: See Figure 3-9.

INPUTS

INPUTS

R

Y

Pr

DVI 1

DVI 1

G
Y

R
Pr

B

G

B

Pb

DVI 2

Pb

HV

DVI 2

HV

HD1

HD1

HD2

HD2

Pr

Pb

Pb

Pr Y

COMPONENT VIDEO

12

COMPONENT VIDEO

Y

VIDEO

1

VIDEO

TRIGGERS

23

TRIGGERS

3

S-VIDEO 1

S-VIDEO 2

S-VIDEO 1

S-VIDEO 2

IR

IR

RS-232

CONTROL

CONTROL

RS-232

DVD Player, VCR,
Satellite Receiver,
Laser Disc etc.

Figure 3-9. Composite, S-Video and Component Video Connections

24 Runco VX-2ix Owner’s Operating Manual

Installation

Use a standard, 9-pin RS-232 cable to connect a PC or home theater control/automation
system (if present) to the RS-232 CONTROL port on the VX-2ix; see

Figure 3-10.

For more information about using this connection, refer to Serial Communications on
page 51.

1

345

2

6

89

7

2 Transmit Data
3 Receive Data
5 Ground

Pr

Pb

Pb

Pr Y

COMPONENT VIDEO

1

12

COMPONENT VIDEO

Y

VIDEO

VIDEO

TRIGGERS

23

TRIGGERS

S-VIDEO 1

S-VIDEO 2

3

S-VIDEO 1

S-VIDEO 2

IR

IR

RS-232

CONTROL

CONTROL

RS-232

(none of the other pins are used)

to Automation/

Control System

or PC

RS-232 Controller Connection

Figure 3-10. RS-232 Control System Connection

If your VX-2ix is equipped with a CineWide with AutoScope system, use the cable
supplied with the AutoScope Lens Motor to connect the motor to a 12-Volt trigger output
as shown in

to AutoScope

Lens Motor

Figure 3-11.

Pb Pr Y

Video

TRIGGERS

2

1

S-Video 1

RS-232 OutComponent Video

S-Video 2

IR

3

RS-232 Control

3.5-mm
mini plug

Figure 3-11. Connecting the 12-Volt Trigger Output to the AutoScope Lens Motor

Connecting 12-Volt Trigger Outputs to External Theater Equipment

Runco VX-2ix Owner’s Operating Manual 25

Installation

If your home theater contains a retractable screen, screen mask or other 12-Volt
trigger-activated equipment, connect it to a 12-Volt trigger output as shown in

Figure

3-12.

TRIGGERS

2

1

IR

3

Video

S-Video 1

S-Video 2

RS-232 OutComponent Video

RS-232 Control

Pb Pr Y

3.5-mm
mini plug

to 12-Volt

trigger-activated

equipment

Sleeve = Ground

Tip = +12V

Figure 3-12. Connecting a 12-Volt Trigger Output to Other Equipment

Connecting to AC Power Plug the female end of the power cord into the AC receptacle on the rear of the VX-2ix

➤

(AC 100V ~ 240V). Then, connect the other end to your AC power source.

AutoScope Lens Motor: With AutoScope-equipped projectors, an additional power
cord is provided for the lens motor. Plug the female end of the AC power cord into the AC
input on the rear of the lens motor assembly. Connect the other end to a 110

VAC power

source.

The input voltage to the AutoScope lens motor must be between

Caution

100 and 120 VAC. Do not connect the AutoScope lens motor
to a 200-240

VAC power source!

26 Runco VX-2ix Owner’s Operating Manual

4. Operation

1. Turn on your source components.

2. Turn on the main power switch on the projector.

3. If this is an AutoScope-equipped projector, turn on the main power switch at the rear

of the AutoScope lens motor. The lens motor power switch is located next to the AC
input.

4. Press the ON button on the remote control – or the POWER button on the VX-2ix

rear panel – to turn on the projector. The vacuum fluorescent display on the VX-2ix
rear panel briefly displays “Starting Display.”

5. When the projector is ready for use, the fluorescent display indicates the active

source, signal format (NTSC or PAL), input resolution and aspect ratio; for example:

Input

Current Source Format

Resolution

Component SD NTSC 480i
Anamorphic VX-2

Aspect

Ratio

4.1 Turning on the Power

By default, the VX-2ix is configured for a “floor/front” installation, in which the projector is
installed upright and in front of the screen. If it is installed behind the screen and/or
mounted on a ceiling, you must change the picture orientation. To do this:

1. Press MENU and enter the Service Menu passcode.

2. Select Service from the Main Menu.

3. Select Display Device from the Service Menu.

4. Select Installation from the Display Device menu.

5. Choose Floor/Rear, Ceiling/Front or Ceiling/Rear, to match the installation method.

You must enter a passcode to access the Service menu.

Note

Runco VX-2ix Owner’s Operating Manual 27

4.2 Adjusting the Picture Orientation

Operation

4.3

Lens Adjustments

Focus To focus the projected image, use the cursor buttons to highlight “In” or “Out.” Then,

Zoom To make the picture smaller (zoom out), use the cursor buttons to highlight the minus sign

Shift To change the projected image position, use the cursor buttons to highlight “Left,”

4.4

Using the On-Screen Menus

To access the motorized lens controls, select Display Device from the Service Menu, then
select Lens from the Display Device menu. The Lens menu gives you a great deal of
control over the picture size, position and focus:

➤

press and hold the ENTER button.

➤

(-). Then, press and hold the ENTER button.

To enlarge the picture (zoom in), use the cursor buttons to highlight the plus sign (+).
Then, press and hold the ENTER button.

➤

“Right,” “Up” or “Down.” Then, press and hold the ENTER button to shift the image in that
direction.

Press the MENU button on either the remote control or the rear panel to display the Main
Menu.

To select a menu item, use the and buttons on either the remote control or the rear
panel to highlight it. Press ENTER to confirm your selection.

The VX-2ix OSD menus are arranged hierarchically, as shown in Figure 4-1.

28 Runco VX-2ix Owner’s Operating Manual

Operation

Input Source

Aspect Ratio


Input Position

ISF Presets

Information

(read-only)

Service

Composite
S-Video 1
S-Video 2
Component SD
HD/RGB 1
HD/RGB 2
DVI 1
DVI 2
Anamorphic
Standard 4:3
Letterbox
VirtualWide
Cinema
Virtualwide 2.35
Brightness
Contrast
Color
Tint
Sharpness
Left/Right
Up/Down
Width
Height
Overscan
Recall ISF Night
Recall ISF Day
Recall/Save Custom 1
Recall/Save Custom 2
Reset Custom 1 & 2 to Factory Default
Serial Number
Hardware
Firmware
Date

Test Video

Input Names Rename, Restore or Save

Remote Control

Display Device

HD Format

Triggers 1 / 2 / 3 / Save

Miscellaneous

Resolution

System Reset
Restore Saved Settings

Note: Virtualwide 2.35 is
available only on VX-2ix
projectors equipped with the
CineWide option (secondary
anamorphic lens).

Grey Bars 1
Grey Bars 2
Color Bars 1
Color Bars 2

Primary
Secondary

Installation

Lens

Diagnostics

HD/RGB 1
HD/RGB 2
ADC Bandwidth Auto, 75 MHz, 150 MHz or 300 MHz
YPbPr Input Resolution Auto, 480i/p, 576i/p, 720p or 1080i

Language (currently, English only)
Menu Mode
Timeout
Side Bar Color
Film Mode (SD src. only)
800x600 ... 1400x1050

480i ... 720p ... 1080i

Calibration

Picture Orientation
Lamp Hours (View/Reset)
Focus
Zoom
Shift
Red Only
Green Only
Blue Only
75 IRE Color Bars
100 IRE Color Bars
Horiz. Grey Ramp
Vert. Grey Ramp
Checkerboard
Alignment Grid

Auto, RGB or YUV

Gain

ISF Night - Display Color

ISF Night - Input Image

ISF Night - Input Color

ISF Day - Display Color

ISF Day - Input Image

ISF Day - Input Color

Save ISF Settings Back / Confirm

Output Shift

Splash Configure

OSD Position

Offset
Gamma
Lamp Power
Color Temp
Brightness
Contrast
Color
Tint
Sharpness
Gain
Offset
Chroma Delay
Phase
Noise Filter
Gain
Offset
Gamma
Lamp Power
Color Temp
Brightness
Contrast
Color
Tint
Sharpness
Gain
Offset
Chroma Delay
Phase
Noise Filter

Left/Right
Up/Down
Width
Height
Save
Owner Name
ISF Calibrated
ISF Other

Figure 4-1. VX-2ix OSD Menu Structure

Runco VX-2ix Owner’s Operating Manual 29

Operation

Runco Video

Input Source

Aspect Ratio


Input Position

ISF Presets

Information

Calibration

Service

Input Source

> Composite

S-Video 1

S-Video 2

Component SD

HD/RGB 1

HD/RGB 2

DVI 1

DVI 2

Main Menu The Main Menu is the starting point for accessing all projector functions.

➤

(The Calibration and Service menus are hidden and not accessible until you enter a
passcode.)

Input Source From the Main Menu, select Input Source to choose a video signal source.

➤

The active source is indicated by an arrow (>) to its left; in the example at left, Composite
is the active source.

Aspect Ratio

Anamorphic

7

Standard 4:3



Letterbox



VirtualWide



Cinema



Virtualwide 2.35



Aspect Ratio To change the aspect ratio (size and shape) of the projected image, select Aspect Ratio

➤

from the Main Menu and press ENTER. Select the appropriate aspect ratio for the type of
program material being viewed; refer to

Table 4-1.

The currently-selected aspect ratio is indicated by a “7” to its left; in the example at left,
Anamorphic is selected.

The aspect ratio selection is automatically saved for each input and

Note

resolution.

30 Runco VX-2ix Owner’s Operating Manual

Table 4-1. Aspect Ratio Settings

Remote

Aspect Ratio

Control

Key

Anamorphic ANA Select Anamorphic to view 16:9

16:9 Image on

16:9 Screen

4:3 Image on

16:9 Screen

Standard 4:3 4X3 Standard 4:3 scales the input

Active Image

Area (4:3)

Description

DVDs and HDTV programs in
their native aspect ratio. 4:3
images are stretched
horizontally to fit a 16:9 screen.

signal to fit in the center of the
16:9 screen. 4:3 is the aspect
ratio used by computer
monitors, standard television
programming and most VHS
video cassettes.

Operation

Letterbox LET

BOX

Letterbox Image on

16:9 Screen

In Letterbox mode, the image is
stretched vertically; the top and
bottom portions are “blanked
off.” Letterbox is best suited for
viewing LaserDisc movies or
non-anamorphic DVDs on a 4:3
screen.

VirtualWide V-WIDE VirtualWide scales a 4:3 image

NON-linearly (more on the sides
than in the center) to fit a 16:9
screen.

Runco VX-2ix Owner’s Operating Manual 31

Operation

Table 4-1. Aspect Ratio Settings (continued)

Remote

Aspect Ratio

Cinema CINEMA Select Cinema to view 2.35

Control

Key

2.35:1 Image on
16:9 Screen

(without CineWide)

2.35:1 Image on

2.35:1 Screen

(with CineWide)

Description

source material in its native
aspect ratio.

With a 16:9 screen and a
non-CineWide projector (no
anamorphic lens), the upper and
lower portions of the screen are
masked, but the geometry of the
active image area is unchanged.

With a 2.35:1 screen and a
CineWide-equipped projector,
the VX-2ix vertically stretches
the 2.35 image so that the active
image area fills the 16:9 chip
surface, eliminating the black
bars. The secondary
anamorphic lens then stretches
the image back to 2.35:1.

Virtualwide 2.35 SVC A 16:9 image is scaled

NON-linearly (more on the sides

16:9 Image on

16:9 Image on

2.35:1 Screen

2.35:1 Screen

than in the center) to fit a 2.35:1
screen.

Virtualwide 2.35 is available only
on CineWide-equipped VX-2ix
projectors.

16:9 Image on

2.35:1 Screen with
VirtualWide 2.35

32 Runco VX-2ix Owner’s Operating Manual

Operation

A

Picture Use the controls in the Picture Menu to calibrate your VX-2ix for optimum picture quality.

The VX-2ix has been designed to incorporate setup and calibration standards established
by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted,
industry-recognized standards for optimal video performance and has implemented a
training program for technicians and installers to use these standards to obtain optimal
picture quality from Runco video display devices. Accordingly, Runco recommends that
setup and calibration be performed by an ISF certified installation technician.

All signal types require separate processing. Therefore, you need to calibrate each input
separately.

When you change a picture quality setting, save the change to a

Note

preset afterwards. Otherwise, the change will be lost when a
different input is selected. (Picture quality settings are saved for
each input separately.) For information about saving settings, refer
to

ISF Presets on page 37.

Although it may be possible to obtain satisfactory picture quality using the naked eye and
regular program material, Runco recommends using the following calibration tools for best
results:

• External test pattern source – Ovation Multimedia, Digital Video Essentials or AVIA test
DVD or equivalent.

• A blue filter (provided with many test DVDs), for color level and tint adjustments.

Connect your test pattern source to the input that you are calibrating and proceed as
follows. Perform the adjustments in the order listed here.


Brightness

Contrast

Color

Tint

Sharpness

Brightness: On your external test pattern source, select a PLUGE pattern. (PLUGE is an

acronym for “Picture Line-Up Generation Equipment.”)

Figure 4-2 shows a typical PLUGE

pattern.

Below Black

bove Black

Figure 4-2. Typical PLUGE Pattern for Adjusting Brightness

Runco VX-2ix Owner’s Operating Manual 33

Operation

PLUGE patterns vary but generally consist of some combination of black, white and gray
areas against a black background. The example above includes two vertical bars and four
shaded boxes.

Select Brightness from the Picture menu and press ENTER. Adjust the brightness so that:

• The darkest black bars disappear into the background.

• The dark gray areas are barely visible.

• The lighter gray areas are clearly visible.

• The white areas are a comfortable level of true white.

• The image contains only black, gray and white (no color).

Contrast: On your external test pattern source, select a stepped, gray-bar pattern like the
one shown in

Figure 4-3.

Figure 4-3. Typical Gray Bar Pattern for Adjusting Contrast

Select Contrast and press ENTER. Adjust the contrast to a point just below which the
white rectangle starts to increase in size.

Brightness and contrast controls are interactive. A change to one

Note

may require a subtle change to the other in order to achieve the
optimum setting.

34 Runco VX-2ix Owner’s Operating Manual

Color Saturation: On your external test pattern source, select a color bar pattern like the
one shown in

Figure 4-4.

Operation

gray

Figure 4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint

Select Color and press ENTER. While looking at the color bar pattern through a blue filter,
adjust the color saturation level until the outermost (gray and blue) color bars appear to be
a single shade of blue:

gray

yellow

yellow

cyan

cyan

green

green

magenta

magenta

red

red

blue

blue

Tint: Tint or “hue” is essentially the ratio of red to green in the color portion of the image.
When tint is decreased, the image appears redder; when it is increased the image
appears greener. To set the tint, select Tint and press ENTER. While looking at the color
bar pattern through a blue filter, adjust the tint level until the cyan and magenta color bars
(on either side of the green bar) appear to be a single shade of blue.

Note

Runco VX-2ix Owner’s Operating Manual 35

Like the brightness and contrast controls, the color and tint controls
are interactive. A change to one may require a subtle change to the
other in order to achieve the optimum setting.

Operation

Sharpness: “Sharpness” is the amount of high-frequency detail in the image. To adjust
sharpness, select Sharpness from the Picture menu and press ENTER. On your external
test pattern source, select a pattern like the one shown in

Figure 4-5. Adjust as needed,
looking for white edges around the transitions from black to gray and differently-sized lines
in the “sweep” patterns at the top and bottom. Lower the sharpness setting to eliminate
them.

Left/Right

Up/Down

Width

Height

Overscan

Figure 4-5. Typical Test Pattern for Adjusting Sharpness

Input Position Use the controls in the Input Position Menu to fine-tune the aspect ratio and image

➤

position for the current source.

Input Position

The input position settings are automatically saved for each input

Note

and resolution.

Left/Right: Select Left/Right from the Input Position menu to shift the projected image
horizontally. Use the right or up cursor button to shift the image to the right; use the left or
down button to shift it to the left.

Up/Down: Select Up/Down from the Input Position menu to shift the projected image
vertically. Use the right or up cursor button to shift the image upward; use the left or down
button to shift it downward.

Width: Select Width from the Input Position menu to change the projected image width.
Use the right or up cursor button to increase the width; use the left or down button to
decrease it.

Height: Select Height from the Input Position menu to change the projected image
height. Use the right or up cursor button to increase the height; use the left or down
button to decrease it.

36 Runco VX-2ix Owner’s Operating Manual

Overscan: Image Overscan pushes the outside edge of the active picture area of the
video signal out beyond the edge of the display area.

Some television programs are produced based on the assumption that older television
sets may not display the outer edges of the broadcast picture area. Overscan effectively
trims away these inactive, outer edges and enlarges the remaining portion of the image to
fill the display area.

Select from 1% to 10% of Overscan, as desired.

For HDTV, DVDs and other video sources, Overscan is generally not necessary or
desirable.

recall at a later time. You can create up to four presets per input and resolution. Use the
ISF Presets menu to recall saved image presets, or to save image settings in the
“Custom
a “

You should save changes to any of the following settings to a preset; otherwise they will
be lost when a new input source or resolution is selected:

• Brightness

•Contrast

• Color saturation

•Tint

• Sharpness

1” or “Custom 2” memory location. The currently-selected preset is indicated by

7” to its left; in the example shown here, ISF Night is selected.

ISF PresetsFor each input, the VX-2ix lets you save image quality settings as presets that you can

ISF Presets

ISF Night

7

ISF Day



Custom 1 Save



Custom 2 Save



Factory Default

Operation

To reset the Custom 1 and Custom 2 image presets to their factory defaults, select
Factory Default and press ENTER.

projector: its serial number, the installed hardware and firmware versions and the firmware
version build date. Should you ever need to contact Runco Technical Support, this
information will help them answer your questions or resolve product performance issues.

InformationSelect Information from the Main Menu to see information that uniquely identifies your

Information

Serial Number

Hardware 0

Firmware 0002.012A

Date Mar 29 2006

Runco VX-2ix Owner’s Operating Manual 37

Operation

Calibration

ISF Night

Display Color

Input Image

Input Color

ISF Day

Display Color

Input Image

Input Color

Save ISF Settings

Output Shift

Splash Configure

OSD Position

Calibration Use the Calibration menu to perform advanced picture quality adjustments. This menu

➤

should be used by ISF-certified technicians only.

You must enter a passcode to access the Calibration menu.

Note

To recall the ISF Night or ISF Day settings, select “ISF Night” or “ISF Day” from the ISF
Presets menu (

ISF Night - Display Color: Use the Display Color settings to adjust the color balance at
the projector output. These settings are saved independently for each input.

•Gain: Use the Gain controls to correct color imbalances in the bright areas of the

image. A good way to do this is to use a test pattern consisting mostly of solid white
areas, such as an 80 IRE “window” pattern. If the white areas contain traces of red,
green or blue, decrease the Gain for that color.

•Offset: Use the Offset controls in the White Balance sub-menu to correct color

imbalances in the dark areas of the image. A good way to do this is to use a test
pattern consisting mostly of dark gray areas, such as a 30 IRE “window” pattern. If the
gray areas contain traces of red, green or blue, decrease the Offset for that color.

• Gamma: “Gamma” is a global setting that determines how gray shades are displayed

between minimum input (black) and maximum input (white) for all signals. A good
gamma setting helps to optimize blacks and whites while ensuring smooth transitions
for the “in-between” values utilized in other grays. Unlike “Brightness” and “Contrast”
controls, the overall tone of your images can be lightened or darkened without
changing the extremes and all images will be more vibrant while still showing good
detail in dark areas.

page 37).

In all but the most unusual situations, the appropriate “Color Temp” selection (see
below) will produce accurate colors and a satisfying contrast level. However, it is
sometimes necessary to adjust the red, blue and green gamma curves individually. To
do this, select Gamma from the Display Color sub-menu and use the left- and
right-arrow buttons to manipulate the on-screen slidebars.

•Lamp Power: Select Lamp Power from the Display Color Menu to adjust the lamp

output level. You can choose to run the lamp as bright as possible (“1”; this is the
default setting) or you can choose the lower setting (“0”). Generally, lower lamp output
can prolong the life of the lamp, but decreases brightness.

• Color Temp: Select Color Temp from the Display Color menu to adjust the color

temperature. The default setting is appropriate for most situations. Higher settings
produce a “bluer” picture.

ISF Night - Input Image: The Input Image controls are similar to those in the Picture
menu, but are accessible only by entering the Calibration menu passcode. This makes it
possible to restore the picture quality settings to what they were when the projector was
installed, simply by recalling the “ISF Night” preset.

38 Runco VX-2ix Owner’s Operating Manual

ISF Night - Input Color: The Input Color controls are similar to those in the Display Color
menu (see above), but adjust the color balance of the incoming signal. These settings are
also saved independently for each input.

• Gain/Offset: Refer to ISF Night - Display Color, above.

•Chroma Delay: use the Chroma Delay control to correct a mis-aligned image from a

Composite, S-Video or Component video source. Chroma delay in an image causes
color shifts to occur to the left of the vertical edge transitions, producing artificial
shadows or a “halo” effect. If necessary, adjust this setting to eliminate them.

•Phase: Adjust the phase if the image (usually from an RGB source) shows shimmer or
“noise.” Pixel phase adjusts the phase of the pixel sampling clock relative to the
incoming signal. The effect of this control is similar to that of a tracking control on a
VCR.

For best results, use a good test pattern such as a smooth gray consisting of a clear
pattern of black and white pixels, or a similar “half on, half off” graphic image. (You may
notice that you can stabilize the image at more than one point. Use either setting in this
case.)

• Noise Filter: To apply noise filtering to the input signal, select Noise Filter from the
Input Color menu. The Noise Filter is useful for clearing up noisy images from 480i
video sources.

Operation

Use the left- or right-arrow buttons to select the desired amount of noise reduction,
keeping in mind that higher settings (which reduce high frequencies) may also “soften”
the image.

ISF Day - Display Color: Refer to ISF Night - Display Color.

ISF Day - Input Image: Refer to ISF Night - Input Image.

ISF Day - Input Color: Refer to ISF Night - Input Color.

Save ISF Settings: Whenever you make a change to the ISF settings, you should always

save it. Select Save ISF Settings from the ISF Calibration menu to do this. In the event you
ever have to perform a

System Reset, you can restore the saved ISF settings by selecting
Restore Saved Settings in the Service menu. (System Reset and Restore Saved Settings
are described on page 43.)

Output Shift: The controls in the Output Shift menu are similar to those in the Input
Position menu, except that they change the characteristics of the output signal. These
settings are saved independently for each aspect ratio.

Splash Configure: Use the Splash Configure menu to customize the appearance of the
start-up message that appears on the vacuum fluorescent display upon power-up. You
can have the VX-2ix display the owner’s name, your name, the phrase “ISF Calibrated”
and/or any other string, up to 20 characters in length.

Use the up or down cursor button to select a character. Use the right and left cursor
buttons to change the cursor position. Press MENU when you have finished entering text.
Then, check the “Splash Enable” box to have the VX-2ix display the information you enter
here when it is turned on.

OSD Position: Select OSD Position, press ENTER and use the arrow buttons to change
the size and position of the OSD controls.

Runco VX-2ix Owner’s Operating Manual 39

Operation

Service Use the Service menu to access advanced projector configuration settings. This menu

Service

Test Video

Input Names

Remote Control

Display Device

HD Format

Triggers

Miscellaneous

Resolution

System Reset

Restore Saved Settings

Input Names

Restore

Composite Composite

S-Video 1 S-Video 1

S-Video 2 S-Video 2

Component SD Component SD

HD/RGB 1 HD/RGB 1

HD/RGB 2 HD/RGB 2

DVI 1 DVI 1

DVI 2 DVI 2

Save

➤

should be used by ISF-certified technicians only.

You must enter a passcode to access the Service menu.

Note

Test Video: Select Test Video from the Service Menu to access the internal test patterns
on the VX-2ix. Four patterns are available, consisting of white/gray or colored bars.

Press MENU to exit test pattern mode.

Input Names: You can give each VX-2ix input a descriptive name. For example, you may
want to change the default input name to the type of source component connected to it:
“VCR,” “DVD,” “Laptop” et cetera. Composite, S-Video and Component SD input names
can be up to 12 characters long; the others can be up to eight characters long.

To edit an input name, select Input Names from the Service menu. Press or to select
an input and press ENTER. Use the or buttons to change a character; press or

to select a character to change. When you have finished editing the input name, press

MENU.

To restore the default input name, press repeatedly to highlight that input name in the
“Restore” column. Then, press ENTER.

To save input names so that they can be restored after a System Reset (described on
page 43), press repeatedly to highlight “Save.” Then, press ENTER.

Note

The button takes you from top to bottom in the left column, then
from top to bottom in the right column. To highlight “Save,” scroll
through both columns.

40 Runco VX-2ix Owner’s Operating Manual

Remote Control: The Remote Control menu shows you the primary and secondary
infrared (IR) codes to which the VX-2ix will respond. By default, both are set to 17. You
can change these codes if either:

• Another device in the theater (a DVD player, for example) is responding to commands

from the VX-2ix remote control in ways that are unpredictable or undesirable.

• You have multiple VX-2ix projectors and want to control them independently, as

opposed to broadcasting commands from a single remote to all of them. In this
scenario, you can use multiple remotes programmed to use different IR codes. Or, you
can use a single remote and change the IR code as needed to address a specific
projector.

Operation

Tip

Use the rear-panel keypad to change a projector IR code. Then,
change the code sent by the remote to match as described below.

Do not change the “Type” setting in this menu.

Note

When you change a remote code on the VX-2ix, you must re-program your remote control
to send that same code. To do this:

1. Using a straightened paper clip or similar object, press and hold the

CODE button on the remote control for approximately three
seconds, or until the red LED on the remote lights solid red.

2. Enter a new two-digit code between 00 and 31 inclusive. Include a

leading zero for single-digit codes; for example, enter 9 as “09.”

3. The LED turns off to confirm the code change. If you enter an invalid code, the LED

flashes for three or four seconds. Try again, entering a valid code.

Display Device: The options in the Display Device menu allow you to change the picture
orientation, reset the lamp timer, perform lens adjustments and access additional test
patterns.

• Installation: Select Installation from the Display Device menu to change the picture

orientation to suit the method of installation (Floor Front, Floor Rear, Ceiling Front or
Ceiling Rear).

This menu page also displays the number of hours that the lamp has been in service,
and lets you reset the counter (which is recommended after you replace the lamp; refer
to

Lamp Replacement on page 45).

•Lens: Select Lens from the Display Device menu to access the motorized lens

controls. Refer to

• Diagnostics: Select Diagnostics from the Service menu to access additional test

patterns for calibration or measurement purposes:

• Select Red, Green or Blue to display only the selected color (simulating a filter of
that color).

• Select 75 or 100 to display color bars (75 IRE or 100 IRE).

• Select Horz or Vert to display a horizontal or vertical gray ramp.

• Select Checks to display a 15-segment checkerboard pattern.

• Select Align to display a white grid against a black background (useful for verifying
proper image or screen alignment).

Runco VX-2ix Owner’s Operating Manual 41

Lens Adjustments on page 28.

Operation

HD Format

HD/RGB 1 Auto

HD/RGB 2 Auto

ADC Bandwidth Auto

YPbPr Input Resolution

HD Format: If the characteristics of the incoming signal on the HD1 or HD2 inputs are

known, select HD Format from the Service menu and set them as described below. Doing
so can reduce the time it takes the VX-2ix to switch from HD to 480i signals or vice versa.

This is generally not necessary unless the VX-2ix – for whatever reason – has difficulty
determining the color space (RGB or YUV), bandwidth or resolution of the incoming HD
signal. In most situations, the Auto settings work well.

• HD/RGB 1 and HD/RGB 2 (Color Space): Select Auto, RGB or YUV.

• ADC Bandwidth: Select Auto, 75 MHz, 150 MHz or 300 MHz.

• YPbPr Input Resolution: Select Auto or specify the input resolution, if known: 480i,

480p, 576i, 576p, 720p or 1080i.

Triggers: Select Triggers from the Service menu to configure the 12-volt trigger outputs.
You can assign one or more trigger outputs to each aspect ratio. Those triggers are then
activated by selecting that aspect ratio.

If your projector is equipped with the Runco CineWide with AutoScope system, assign at
least one trigger output (the same one to which the lens motor is connected) to the
Cinema and Virtualwide 2.35 aspect ratios.

To save the trigger settings so that they can be restored after a System Reset (described
below), press

repeatedly to highlight “Save.” Then, press ENTER.

Miscellaneous: Select Miscellaneous from the Service menu to set the following options:

• Language: Select Language from the Miscellaneous menu and press the up- or

down-arrows to select the OSD Language (English, French, Spanish or German).

•Menu Mode: This is the manner in which the OSD menus appear and disappear when
you press MENU. Choose one of the following:

0 = No transition; menus abruptly appear and disappear.
1 = Menus fade in and out.
2 = “Checkerboard” dissolve; menus appear and disappear in sections.
3 = “Window shade” effect; menus are drawn on a diagonal from top left to bottom
right, and retract in the opposite direction.

• Timeout - Short/Long: These settings control how long the OSD menus stay on
screen. Select a time-out period of from 2 to 60 seconds.

• Side Bar Color: This controls the color of the inactive image area. The range is from

-100 (black) to 100 (white).

The inactive image area is on either side of the active image area when using the
Standard 4:3 aspect ratio, and above and below the active image area when using the
Letterbox aspect ratio.

• Film Mode: Enable Film Mode to smooth out moving images from interlaced,
standard-definition (SD) sources. In most cases, the VX-2ix detects the proper
“pull-down” rate and vertical frequency. However, if your source is jittery and/or tearing
you may wish to enable Film Mode to ensure stable processing for that source.

Resolution: The VX-2ix defaults to an output resolution of 720p. When using the VX-2ix
with a computer or certain HD sources, you may want to force it to use a different output
resolution. If so, select Resolution from the Service menu and choose one. Then, press
ENTER to confirm.

42 Runco VX-2ix Owner’s Operating Manual

System Reset: To reset ALL projector and controller settings (including image settings)
back to their factory defaults, choose System Reset from the Service menu.

A confirmation message appears, reminding you to save your settings before you perform
the reset, so that you can restore them afterwards. If you have done this, select Confirm to
continue with the reset. Otherwise, click Back to cancel.

Operation

Caution

perform a System Reset, save ALL settings, including “Custom” ISF
Presets (

page 37), ISF Day/Night presets (page 39), Output Shift
settings (page 39), Input Names (page 40) and Trigger settings
(page 42).

Restore Saved Settings: Following a System Reset, select Restore Saved Settings to
apply all previously-saved settings to the projector.

This action is not undoable. Proceed with caution! Before you

Runco VX-2ix Owner’s Operating Manual 43

Operation

Notes:

44 Runco VX-2ix Owner’s Operating Manual

5. Maintenance and Troubleshooting

The lamp should be replaced when it reaches the end of its life (typically 2000 hours), or
sooner if a noticeable degradation in brightness occurs. Contact your Runco dealer to
obtain a replacement lamp.

1. Turn off the projector and unplug the power cord. Allow the projector to cool down for
approximately 45 minutes prior to removing the lamp assembly for replacement.

2. Loosen the four rear Lamp Cover
screws and remove the cover.

3. Remove the two lamp assembly mounting screws.

4. Grasp the lamp assembly handle and pull gently, removing the lamp module from the
projector housing.

5. Install the new lamp module.

6. Replace the lamp cover and re-tighten all screws.

7. Reset the Lamp Hour counter. To do this, select Service from the Main Menu, then
Display Device, then Installation. Use the cursor buttons to highlight Reset under
“Lamp

Hours” and press ENTER.

REMOVE THESE SCREWS

5.1 Lamp Replacement

If you need to remove the lens – either to replace it or to prepare the projector for
shipment – proceed as follows:

Note

1. Power down the projector and wait five minutes to allow the lamp to cool.

2. Remove the secondary anamorphic lens, if present.

Runco VX-2ix Owner’s Operating Manual 45

Only trained, authorized Runco dealers should attempt to
remove or replace a lens. Please read this procedure
carefully before doing so.

Lens replacement is normally performed at the Runco factory. Field
replacement of lenses is generally only required if the projector is
re-installed in a new location or the lens has been damaged.

5.2 Lens Replacement

Maintenance and Troubleshooting

3. Loosen the captive Phillips screw from the
bottom of the front lens decorative bezel.

4. Slide the bezel upward to remove it.

5. Remove the foam shield around the front of the lens.

6. Using the red-handled, 3-mm hex driver
provided with the projector, loosen the
three, captive Allen screws on the outer
ring of the lens assembly.

7. Gently pull the lens assembly straight out,
just far enough to separate the motor
socket connector (on the lens) from the
lens mount flange (inside the projector).
Then, carefully rotate the lens assembly 90
degrees counter-clockwise (in order to
clear the Projector chassis with the Motor
Assembly) and remove it.

46 Runco VX-2ix Owner’s Operating Manual

Note that the lens mount flange has a
female socket connector for the lens motor
on the right side of the flange.

Note that the lens assembly motor has a
male socket connector.

Maintenance and Troubleshooting

8. Hold the replacement lens assembly with
the motor facing upward. Carefully insert
the back of the lens assembly into the hole
in the lens flange.

DO NOT PUSH THE LENS ASSEMBLY
ALL THE WAY IN. Only push the lens
assembly in far enough so that the front of
the lens motor is clearly behind the
projector chassis cover.

9. Carefully rotate the lens assembly 90
degrees clockwise until the motor socket
connector is aligned with the connector on
the flange. Then, gently push the lens
assembly in until it is seated flush against
the flange and the connectors have seated.

10. Secure the lens assembly to the projector flange with the three Allen screws that you
loosened in Step

6.

Runco VX-2ix Owner’s Operating Manual 47

Maintenance and Troubleshooting

11. Replace the foam lens shield.

12. Reattach the front lens bezel by sliding the
top down onto the two retaining dowels.

13. Tighten the Phillips screw on the bottom of
the bezel to secure it.

48 Runco VX-2ix Owner’s Operating Manual

Maintenance and Troubleshooting

Table 5-1 provides some general guidelines for troubleshooting problems you may
encounter with the VX-2ix. If you encounter an issue not described here, please contact
Runco Technical Support.

Table 5-1. Troubleshooting Chart

Symptom Possible Cause(s) Solution

The projector does not turn
on after initial installation. The
power LED lights red after you
press the power button.

The projector is on, but there
is no video image on-screen.

A projected image from a
DVD is split or otherwise
scrambled.

Image is too bright and/or
lacks definition in the bright
areas of the image.

Image appears “washed out”
and/or dark areas appear too
bright.

• The VX-2ix is not plugged
in or the AC outlet is not
active.

• Incorrect source selection.

• Source component is not
turned on.

• DVD player is set to
progressive scan mode.

• Contrast is set too high. • Lower the contrast setting.

• Brightness is set too high. • Lower the brightness

• Ensure that the VX-2ix is
plugged in and that the AC
outlet is active.

• Select the correct source.

• Turn on the source.

• Turn off progressive scan
on the DVD player.

• Connect the DVD player to
the HD/RGB 1 or
HD/RGB

setting.

2 input.

5.3 Troubleshooting Tips

Colors in the image are
swapped; for example, reds
appear blue or vice versa.

Image geometry is incorrect. • Incorrect aspect ratio

The projector will not turn
back on after it was powered
down, or the image disap­pears during operation.

•The Red/Pr, Green/Y or
Blue/Pb outputs from the
source are connected to
the wrong inputs on the
VX-2ix.

selection.

• The projector will not turn
on for two minutes after
power-down, to protect
the lamp.

• The lamp has failed.

• Ensure that the source
outputs are connected to
the correct VX-2ix input.

• Select the aspect ratio that
best matches the source
image and screen size
(refer to

• Wait two minutes until the
LED at the front of the
VX-2ix turns red.

Table 4-1).

Runco VX-2ix Owner’s Operating Manual 49

Maintenance and Troubleshooting

Notes:

50 Runco VX-2ix Owner’s Operating Manual

6. Serial Communications

To interface the VX-2ix with a home theater automation/control system or a PC running
terminal emulation software, connect it to your control system or PC as shown in
3-10.

Configure the RS-232 controller or PC serial port as follows: no parity, 8 data bits, 1 stop
bit and no flow control. Set the baud rate to 19200, to match that of the VX-2ix RS-232
port.

Serial commands to the VX-2ix take the following form:

• Commands are not case-sensitive.

• For a single command that takes no parameters, type the command followed by a
carriage return; for example, to set the aspect ratio to Letterbox, type

LETTERBOX

• For a single command that takes a parameter, type the command, a space or a
comma and the desired value followed by a carriage return; for example, to set the
brightness to -10, type BRIGHTNESS

BRIGHTNESS,-10

• You can also send a string of multiple commands on a single line, separated by
commas. For example, COMPOSITE,BRIGHTNESS
switches to the Composite video input, sets the brightness to 100 and sets the aspect
ratio to Anamorphic. Command strings can be up to 255 characters long.

Note

<Enter>.

-10 <Enter> or

<Enter>.

100,ANAMORPHIC <Enter>

Avoid combining the ON or POWER 1 commands with other commands
on a single line. After sending ON or POWER 1, allow at least 15
seconds for the projector to power up. Once it does, it will accept and
properly execute multiple serial commands.

Figure

6.1 RS-232 Connection and Port Configuration

6.2 Serial Command Syntax

Table 6-1 lists the RS-232 command set. The “Parameter (min/max)” column shows the
valid parameter ranges, or “NA” for commands that take no parameters.

When you enter a valid command, the VX-2ix executes it and acknowledges it with a plus
sign on the command line (+ >). When you enter an invalid command – one that is
misspelled or followed by values outside the valid range for that command – the VX-2ix
ignores it and returns a minus sign (- >).

Table 6-1. Serial Commands

Command

OFF NA NA Turns projector off

ON NA NA Turns projector on

POWER 0/1 NA Turns projector on and off

POWER? NA NA Returns power status

Runco VX-2ix Owner’s Operating Manual 51

Parameter

(min/max)

Value

Stored?

Power On/Off Commands

Description

Serial Communications

Table 6-1. Serial Commands (continued)

Command

COMPONENT NA YES Selects the Component input

COMPOSITE NA YES Selects the Composite video input

DVI1 NA YES Selects the DVI 1 input

DVI2 NA YES Selects the DVI 2 input

HD1 NA YES Selects the RGB HD 1 input

HD2 NA YES Selects the RGB HD 2 input

INPUT? NA NA Returns active input

SVIDEO1 NA YES Selects the S-Video 1 input

SVIDEO2 NA YES Selects the S-Video 2 input

ANAMORPHIC NA YES Selects the Anamorphic aspect ratio

ASPECT? NA NA Returns current aspect ratio

ASPECTIN? NA NA Returns the input source aspect ratio

Parameter

(min/max)

Value

Stored?

Input Selection Commands

Aspect Ratio Commands

Description

ASPECTOUT? NA NA Returns output screen size

CINEMA NA YES Selects the Cinema aspect ratio

LETTERBOX NA YES Selects the Letterbox aspect ratio

OUT169 NA YES Sets the output screen to 1.78:1 (16:9)

OUT235 NA YES Sets the output screen to 2.35:1

STANDARD NA YES Selects the Standard (4:3) aspect ratio

VIRTUALWIDE NA YES Selects the VirtualWide aspect ratio

VIRTUAL235 NA YES Selects the Virtualwide 2.35 aspect ratio

52 Runco VX-2ix Owner’s Operating Manual

Table 6-1. Serial Commands (continued)

Serial Communications

Command

BRIGHTNESS -100/100 YES Sets a value for brightness

BRIGHTNESS? NA NA Returns brightness setting value

CHROMADELAY -12/12 YES Sets a value for input color chroma delay

CHROMADELAY? NA NA Returns input color chroma delay setting

COLOR -100/100 YES Sets a value for color

COLOR? NA NA Returns color setting value

CONTRAST -100/100 YES Sets a value for contrast

CONTRAST? NA NA Returns contrast setting value

FILMMODE 0/1 YES Sets Film Mode off (0) or on (1)

FILMMODE? NA NA Returns Film Mode setting (0 = off; 1 = on)

FILTER 0/15 YES Sets a value for input color noise filter

FILTER? NA NA Returns input color noise filter setting

PHASE 0/3 YES Adjusts phase

Parameter

(min/max)

Value

Stored?

Picture Adjust Commands

Description

PHASE? NA NA Returns phase setting value

SHARPNESS -6/6 YES Sets a value for sharpness

SHARPNESS? NA NA Returns sharpness setting value

TINT -100/100 YES Sets a value for tint

TINT? NA NA Returns tint setting value

Image Preset Commands

CUSTOM1 NA YES Loads “Custom 1” image preset

CUSTOM2 NA YES Loads “Custom 2” image preset

DAY NA YES Loads “ISF Day” image preset

NIGHT NA YES Loads “ISF Night” image preset

PRESET? NA NA Returns currently-selected preset

(ISF Day, ISF Night, Custom 1 or Custom 2)

Runco VX-2ix Owner’s Operating Manual 53

Serial Communications

Table 6-1. Serial Commands (continued)

Command

IHEIGHT -100/100 YES Sets the value for input height

IHEIGHT? NA NA Returns input height value

IHPOS -100/100 YES Sets a value for horizontal input position

IHPOS? NA NA Returns input horizontal position value

IVPOS -100/100 YES Sets a value for vertical input position

IVPOS? NA NA Returns input vertical position value

IWIDTH -100/100 YES Sets the value for input width

IWIDTH? NA NA Returns input horizontal width value

OVERSCAN 0/10 YES Sets the overscan percentage

OVERSCAN? NA NA Returns overscan percentage

OHEIGHT -100/100 YES Sets the value for output height

OHEIGHT? NA NA Returns output height value

Parameter

(min/max)

Value

Stored?

Input Position Commands

Output Shift Commands

Description

OHPOS -100/100 YES Sets the value for output horizontal position

OHPOS? NA NA Returns output horizontal position value

OVPOS -100/100 YES Sets the value for output vertical position

OVPOS? NA NA Returns output vertical position value

OWIDTH -100/100 YES Sets the value for output width

OWIDTH? NA NA Returns output horizontal width value

54 Runco VX-2ix Owner’s Operating Manual

Table 6-1. Serial Commands (continued)

Serial Communications

Command

BKGND -100/100 YES Sets the background color for letterbox or

BKGND? NA NA Returns background setting value

DATE? NA NA Returns product manufacture date

HDINPUTRES NA YES Sets YPbPr input resolution and refresh

HWVER? NA NA Returns hardware version number

INRES? NA NA Returns input resolution

LENS1 0 or 4 YES Set primary lens configuration:

Parameter

(min/max)

Value

Stored?

Miscellaneous Commands

4:3 aspect ratio (-100 = black; 100 = white)

rate for HD1/HD2, as follows:
0 = 480i
1 = 480p
2 = 576i
3 = 576p
4 = 720p / 60 Hz
5 = 1080i / 60 Hz
6 = 720p / 50 Hz
7 = 1080i / 25 Hz
Any other value = Auto

0 = No anamorphic lens present
4 = Anamorphic lens present

Description

LENS1? NA NA Returns Lens 1 configuration

LENS2 0 or 8 YES Set anamorphic lens type:

0 = Fixed CineWide
8 = CineWide with AutoScope

LENS2? NA NA Returns Lens 2 configuration

OUTRES 0/5 YES Sets output resolution, as follows:

0 = 480i
1 = 576i
2 = 480p
3 = 576p
4 = 720p
5 = 1080i

OUTRES? NA NA Returns output resolution

SWVER? NA NA Returns software version number

TRIGGER 1/3 YES Assigns trigger to currently-selected aspect

ratio

Runco VX-2ix Owner’s Operating Manual 55

Serial Communications

Notes:

56 Runco VX-2ix Owner’s Operating Manual

7. Specifications

Table 7-1 lists the VX-2ix specifications.

Table 7-1. VX-2ix Specifications

Projector Type: Digital Light Processing (DLP), 3-chip, 16:9 DMD

Native Resolution: 1280 x 720 (16:9)

Aspect Ratios: 4:3, Letterbox, 16:9 Anamorphic, VirtualWide, Cinema,

VirtualWide 2.35

Video Standards: NTSC, PAL

DTV Compatibility: 480p, 720p, 1080i

THX recommends the use of 720p source material for optimal
performance with this product.

Scan Frequency: Horizontal: 15 - 100 kHz

Vertical: 28 - 78 Hz

Picture Size (16:9 Screen): Recommended Width: 72 - 120 in.

Maximum Width: 250 in.

Throw Distance
(Factor x Screen Width):

Horizontal and Vertical
Offset:

Refer to Table 3-3

Proteus A lens:
None

7.1 VX-2ix Specifications

All other lenses:
Horizontal – 10% of screen width left or right of center
Vertical (when ceiling-mounted) –

80% of screen height below center;
0% of screen height above center

Vertical (when floor-mounted) –

0% of screen height below center;
80% of screen height above center

Runco VX-2ix Owner’s Operating Manual 57

Specifications

Table 7-1. VX-2ix Specifications (continued)

Brightness and Contrast: Cinema Standards Measurement System (CSMS)

Specifications

- Brightness: 52.1 foot-Lamberts (fL)

- Contrast Ratio: 271:1

These measurements are taken from the projector in a controlled,
home theater environment. All measurements are made to
ANSI/NAPM IT7.228-1997 specifications using the Photo Research
PR-650 SpectraColorimeter and Minolta LS-100 Luminance Meter,
Video Essentials test DVD and a 1.3 gain, 72-inch wide screen. The
projector is calibrated to a color temperature of 6,500K and has a
minimum of 150 hours of usage.
The foot-Lambert (fL) is the unit of measurement used in commercial
movie theaters to express image brightness at the screen surface. The
Society of Motion Picture and Television Engineers (SMPTE) specifies
16 fL as the target image brightness for film-based projectors using an
open gate (without film in the projector). More importantly, today
SMPTE specifies 12 fL as the target image brightness in Digital
Cinema theaters. The foot-Lambert measurement is dependent on
screen size, screen gain and projector light output.

Home Theater Calibration Specifications

- Light Output: 1227 ANSI Lumens

- Contrast Ratio: 271:1

These specifications are obtained by calibrating the projector as
described above for CSMS measurements.

Industry-Standard Specifications

- Light Output: 2500 ANSI Lumens

- Contrast Ratio: 3100:1

These are typical projector brightness and contrast specifications
found in most companies’ sales literature. Runco includes these
measurements in its literature to allow for direct comparison with other
manufacturers’ projectors. These measurements are typically taken at
9,000K to 13,000K to get expected performance data when the
projector is used in professional, commercial and industrial displays.

Lamp: 275 Watts

Estimated Lamp Life: 2000 hours

Inputs: (1) Composite; (2) S-Video; (1) Component; (2) HD-R (Pr), G

(Y), B (Pb), H, V; (2) DVI w/HDCP

Control Options: - Built-in keypad

- Discrete infrared remote

- Serial commands via RS-232

Trigger Outputs: (3) +12 VDC, each rated at 750 mA and thermal

fuse-protected

Bandwidth: 150 Mega Samples/Second (MSPS)

Power Requirements: 100 to 240 VAC (auto-sensing), 50/60 Hz, 610 Watts

Operating Environment: 41°F to 95°F (5°C to 35°C), 0% to 90% humidity

(non-condensing)

Dimensions: See Figure 7-1

Weight (without lens): 84 lbs. (38.10 kg)

Regulatory Approvals: Complies with FCC, CE C-Tick

58 Runco VX-2ix Owner’s Operating Manual

Table 7-1. VX-2ix Specifications (continued)

Limited Warranty: Projector: Two (2) years parts and labor from the date of

delivery to the end user.
Lamp: 1000 hours or six (6) months, whichever comes first.

Specifications are subject to change without notice.

Specifications

Runco VX-2ix Owner’s Operating Manual 59

Specifications

7.2

VX-2ix Dimensions

Figure 7-1 shows the VX-2ix dimensions.

R 10.680

21.190

15.857

12.123

1.500

9.245

.750

8.389

0

.500

25.737

.134

all dimensions are in inches

Figure 7-1. VX-2ix Dimensions

1.305

1.685

4.335

19.505

1.330

1.620

0

0

9.934

14.671

1.500

23.990

Ø 1.140

60 Runco VX-2ix Owner’s Operating Manual

Appendix A. VX-2ix Color Gamut Adjustment

Note

procedure!

For most applications, the Display Color controls in the Calibration menu are adequate for
producing accurate and realistic colors from a variety of sources.

In rare cases, though, you may need more precise control over the VX-2ix display color
gamut (range). For example, you may require a unique color gamut for a given projector or
application. In such cases, you can access the VX-2ix’s color gamut controls via serial
commands. This enables you to define the precise hue of each primary color component
(white, red, green and blue) used to generate the millions of colors produced in displays.
You do this by specifying x and y coordinates for each primary color component.

The x and y coordinates for each color define its location on the standard CIE chromaticity

Only ISF-trained and -certified technicians should attempt this

graph, shown in

Figure A-1. (CIE stands for “Commission Internationale de l’Éclairage”
(International Commission on Illumination), the organization responsible for color
measurement and management standards.)

1.0

y

0.9

0.8

0.7

0.6

0.5

0.4

0.3

0.2

0.1

0.0

0.00.1 0.20.30.40.50.60.70.80.91.0

D93

D65

10000

8000

D50

6667

5714

5000

4444

4000

3636

3333

3077

2857

2677

2500

2353

2222

2105

2000

x

Figure A-1. CIE 1931 Chromaticity Diagram

Changing either or both of these numbers changes the hue of the color and relocates the
“triangle” for possible colors. For example, changing the x/y coordinates for red moves the
color closer to either orange or violet, which in turn affects all displayed colors having a red
component.

Runco VX-2ix Owner’s Operating Manual A-1

VX-2ix Color Gamut Adjustment

A.1 Required Hardware and Software

A.2 Serial Connections and Equipment Setup

To perform these adjustments, you need the following:

• Laptop or desktop PC with a DB-9 serial port.

• A straight-through (not null-modem) serial cable (DB-9 female to DB-9 male).

• A DB-9 female-to-3.5mm phono plug adapter.

• Terminal emulation software – HyperTerminal or equivalent.

• Color analyzer – Sencore ColorPro 5000 software and ColorPro III sensor, or
equivalent.

Most computer-based color analyzers – like the Sencore product used

Note

here as an example – also require a serial connection for the color
sensor. In order to use them for this procedure, your PC must have either
two available RS-232 COM ports, or one COM port and one Universal
Serial Bus (USB) port.

If you are using a stand-alone color analyzer, this is not an issue.

Connect your PC to the projector and color sensor as shown in Figure A-2.

3.5-mm phono plug

Screen

to D-Sub 9-pin

(not included)

6 - 12 in.

Color Sensor

USB or COM2

COM1

Figure A-2. Equipment Setup for Color Gamut Adjustment

1. Connect a straight-through serial cable to the computer’s serial port.

2. Connect the other end of the serial cable to a 9-pin-to-3.5mm phono plug adapter.

3. Connect the 3.5-mm phono plug to the secondary RS-232 port on the rear of the

projector. This port is not labeled, but is to the right of and slightly below the primary
RS-232 port; see Figure A-3.

A-2 Runco VX-2ix Owner’s Operating Manual

Figure A-3. VX-2ix Secondary RS-232 Port

4. Connect the color sensor to any available COM or USB port.

5. Launch HyperTerminal. Open a connection using these parameters: 19200 baud,
8

data bits, no parity,1 stop bit and no flow control.

6. Press <Enter>. The VX-2ix responds with “+>” to indicate that it is ready to accept
commands.

7. Start your color analyzer. Position the sensor approximately 6 to 12 inches from the
screen, facing it at a slight angle (upward or to one side) so that the color of the
screen is included in the calibration.

VX-2ix Color Gamut Adjustment

Table A-1 lists the serial command set for color gamut adjustments. The “Parameter
(min/max)” column shows the valid parameter ranges, or “NA” for commands that take no
parameters.

When you enter a valid command, the VX-2ix executes it and acknowledges it with a plus
sign on the command line (+ >). When you enter an invalid command – one that is
misspelled or followed by values outside the valid range for that command – the VX-2ix
ignores it and returns a minus sign (- >).

Table A-1. Serial Commands for Gamut Adjustment

Command

GAMUT WHITE NA NA

GAMUT RED NA NA

Parameter

(min/max)

Value

Stored?

Description

Displays white field on screen for
measuring x and y coordinates;
shows current x and y
coordinates for white on the
command line.

Displays red field on screen for
measuring x and y coordinates;
shows current x and y
coordinates for red on the
command line.

A.3 Serial Command Syntax

Runco VX-2ix Owner’s Operating Manual A-3

VX-2ix Color Gamut Adjustment

Table A-1. Serial Commands for Gamut Adjustment (continued)

Command

GAMUT GREEN NA NA

GAMUT BLUE NA NA

GAMUT SET WHITE [x] [y] x = 0.0 / 0.8

GAMUT SET RED [x] [y] x = 0.0 / 0.8

GAMUT SET GREEN [x] [y] x = 0.0 / 0.8

GAMUT SET BLUE [x] [y] x = 0.0 / 0.8

GAMUT OFF NA NA

Parameter

(min/max)

y = 0.0 / 0.9

y = 0.0 / 0.9

y = 0.0 / 0.9

y = 0.0 / 0.9

Stored?

YES Sets x and y coordinates for white.

YES Sets x and y coordinates for red.

YES Sets x and y coordinates for green.

YES Sets x and y coordinates for blue.

Value

Description

Displays green field on screen for
measuring x and y coordinates;
shows current x and y
coordinates for green on the
command line.

Displays blue field on screen for
measuring x and y coordinates;
shows current x and y
coordinates for blue on the
command line.

Applies new gamut setting (if
changed) and goes back to
normal picture.

A.4 Adjusting the Gamut

1. In HyperTerminal, type gamut white and press <Enter>. The VX-2ix displays a

white field on the screen and the current x and y coordinates for white on the
command line.

2. Using the color analyzer, measure the x and y coordinates for about 15 seconds.
Make a note of the results.

3. In HyperTerminal, use the gamut set white command to change the x and y
coordinates to the values you obtained in Step 2. For example, if the readings were
x=0.284 and y=0.294, type gamut set white 0.284 0.294 and press
<Enter>.

4. To confirm the change, repeat Step 1. The displayed x and y values should match
what you just entered.

5. Type gamut red and press <Enter>. The VX-2ix displays a red field on the screen
and the current x and y coordinates for red on the command line.

6. Repeat Step 2.

7. In HyperTerminal, use the gamut set red command to change the x and y
coordinates to the values you obtained in Step 6.

8. To confirm the change, repeat Step 5. The displayed x and y values should match
what you just entered.

A-4 Runco VX-2ix Owner’s Operating Manual

9. Type gamut green and press <Enter>. The VX-2ix displays a green field on the

screen and the current x and y coordinates for green on the command line.

10. Repeat Step 2.

11. In HyperTerminal, use the gamut set green command to change the x and y

coordinates to the values you obtained in Step 10.

12. To confirm the change, repeat Step 9. The displayed x and y values should match
what you just entered.

13. Type gamut blue and press <Enter>. The VX-2ix displays a blue field on the
screen and the current x and y coordinates for blue on the command line.

14. Repeat Step 2.

15. In HyperTerminal, use the gamut set blue command to change the x and y
coordinates to the values you obtained in Step 14.

16. To confirm the change, repeat Step 13. The displayed x and y values should match
what you just entered.

17. Type gamut off and press <Enter>. The VX-2ix stores the new x and y
coordinates and returns to normal operation.

VX-2ix Color Gamut Adjustment

When you have completed the gamut adjustments, proceed with the Display Color
adjustments; refer to

Calibration on page 38.

Runco VX-2ix Owner’s Operating Manual A-5

VX-2ix Color Gamut Adjustment

Notes:

A-6 Runco VX-2ix Owner’s Operating Manual

SERIAL NUMBER

RUMA-011155

rev 09-27-06 v2.2

Runco International • 2900 Faber Street • Union City, CA 94587 • Ph [phone] / (800) 23RUNCO / Fax [phone]

www.runco.com
