Runco SC-35d, SC-30d User Manual

Download

I NSTALLATION/OPERATION MANUAL

SC-30d and SC-35d

Active 3D Home Theater Projector and

DC-300 Dimension Digital Controller

RuncoCare™ Standard Two Year Limited

Warranty

Congratulations on your purchase of a Runco® product! With proper installation, setup and care, you should enjoy many years of unparalleled video performance.

This Limited Warranty is provided free of charge by Runco International, LLC (“Runco”) with the purchase of a covered Runco product. This Limited Warranty is applicable to all Runco projectors, processors, LCD display and plasma display products, with the exception of the following models: XP-103DHD, SC-1 and SC-1a covered Runco products occurring on or after June 1, 2011.

. This Limited Warranty applies to purchases of

RuncoCare™ Limited Warranty Coverage

Runco warrants its products to be free from defects in material and workmanship during the warranty period provided below. If a product proves to be defective in material or workmanship during the warranty period, Runco will repair the product, replace the product with a substantially similar new or like-new product, or refund a prorated share of the purchase price (calculated based on the remainder of the warranty period and the then-current, most-recent MSRP replacement of the product is determined by Runco to not be feasible.

Length of RuncoCare™ Warranty Period

Runco products are warranted for two (2) years from the date of shipment from Runco. Lamps are warranted six (6) months from the date of shipment or 1000 hours of use, whichever comes first. A replacement lamp is warranted for the remaining portion (if any) of the original warranty period or ninety (90) days from the date it was shipped to you, whichever is longer. All other accessories, which include but are not limited to cables, remotes, carrying cases, lens cap and other peripherals sold with the Runco product, are warranted for ninety (90) days from the date of shipment.

RuncoCare™ Eligibility

This Limited Warranty is valid only in the country where the Product was originally purchased and for the buyer who originally purchased the covered product from the authorized Runco dealer or distributor. This warranty is not transferable; it is not valid for any subsequent buyer (if any). You may be required to provide proof of purchase in order to receive warranty services.

PRE

IMINAR

of a similar product), if repair or

1. Runco may update this list of products excluded from this warranty from time to time at Runco’s sole discretion, but updates will not apply on a retroactive basis.

2. MSRP is defined as the most recent product price listed on Runco’s price list.

Runco SC-30d/SC-35d Installation/Operation Manual iii

RuncoCare™ Standard Claim Procedure

• In the event of a product defect, please follow the claim procedure provided below: A. Register your product if you have not yet done so. Visit http://www.runco.com/support/product-registration/ to

register the product. B. Contact your original authorized dealer or distributor who sold the product. C. The dealer/distributor will contact Runco Technical Support via email at support@runco.com or via phone at 1-800-

23-RUNCO (1-800-237-8626).

• The dealer/distributor will provide to Runco proof of purchase, serial number, product model number, description of the problem and any troubleshooting steps already attempted.

• Runco’s technical support staff will attempt to assist the dealer/distributor in troubleshooting any technical issues that might be causing the product to malfunction. If Runco is unable to resolve the problem through troubleshooting, a Return Material Authorization (RMA) number will be issued for the exchange of the defective product if it is determined that the claim is covered by the warranty. Once an RMA has been created, RMA status is available at serviceorders@runco.com.

• If an RMA is issued, the dealer or customer will need to return the defective product to the Runco repair depot location specified by the Runco technical support representative. The dealer or customer will need to properly package the defective product in a suitable shipping container consisting of the product only, and not include any accessories (e.g., cables, remotes, carrying cases, lens, lens cap and other peripherals). Boxes may be purchased from a Runco technical support representative.

• The dealer or customer is responsible for paying freight charges and insurance to ship the defective product to the Runco repair depot location. If there are any shipping damages, the dealer or customer will need to address and resolve any shipping damage claims directly with the shipping company.

• Runco will not accept a returned product unless an RMA has been issued by Runco.

• For in-warranty repairs, Runco will pay freight charges to return the repaired/replacement product to the dealer/distributor from the Runco repair depot. For select countries or geographies Runco will ship via an economy express service. Return delivery time and availability may vary based on origin and destination, and Runco is unable to deliver to PO Box and FPO Box addresses.

• Note: in the 48 contiguous United States, other options for on-site service or advance exchange for the product may apply, if you purchased the Runco PremierCare™ Service Plan.

IMINAR

What to Include with Your Return

1. Return only the defective product with the lamp (if applicable).

2. Runco will not be responsible for returning or replacing any accessories (e.g., cables, remotes, carrying cases, lens, lens

cap and other peripherals sold with the Runco product) that are returned with the defective product.

3. Repaired or replacement products will be shipped with a lamp (if applicable) but without any accessories.

RuncoCare™ Warranty Exclusions

This Limited Warranty does not include and is limited by the following:

1. Products not purchased from an authorized Runco dealer

2. Rental costs incurred by the customer in the event of product defect or failure

3. Any product with a defaced, modified, or removed serial number

PRE

iv Runco SC-30d/SC-35d Installation/Operation Manual

4. Damage, deterioration, or malfunction resulting from:

A. Accident, abuse, misuse, neglect, improper ventilation, fire, water, disaster, lightning, or other acts of nature, smoke

exposure (cigarette or otherwise), unauthorized product modification (including use of an unauthorized mount), or

failure to follow instructions supplied with the product B. Repair or attempted repair by anyone not authorized by Runco C. Any damage to the product due to shipment D. Removal or installation of the product E. Causes external to the product, such as electric power fluctuations or failure F. Use of supplies or parts (including lamps) that are not purchased from Runco or do not meet Runco’s specifications G. Normal wear and tear H. Expected lamp degradation and normal decrease in lamp output over a period of time or as the lamp is consumed I. Customer caused defects, including but not limited to, scratched/defaced/altered plastics J. Failure to follow maintenance procedures as outlined in the product’s user guide where a schedule is specified for

regular cleaning of the product K. Opening the product and/or tampering with internal circuitry L. Products lost, stolen or discarded M. Any damage or dissatisfaction associated with latent images, “burnin,” or any other damage determined by Runco to

be the result of customer use patterns N. Any other cause, which does not relate to a product defect in material or workmanship

5. Removal, installation, and set-up service charges are excluded from the warranty.

6. Black uniformity issues or other LCD issues associated with usage outside the Runco recommended guidelines and specifications for the product.

7. Bright or dark sub pixels that are characteristic of LCD technology and considered by Runco to be acceptable and within Runco’s manufacturing specifications.

Specifically, it is not uncommon for one or more sub pixels to become bright or dark during or after the manufacturing process. A bright sub pixel is one that remains in the on position, and a dark sub pixel is one that appears black or off. The sub pixels are usually hard to see and will not detract from the display quality or usability at normal viewing distance. The following are Runco’s criteria for identifying bright or dark sub pixels that would be considered unacceptable: a) the number of bright or dark sub pixels; b) the location of the bright or dark sub pixels; c) the color of the bright sub pixels; and d) the Runco model size. If sub pixels have been identified as unacceptable by Runco the LCD will be deemed faulty and will be replaced if reported within the warranty period.

PRE

IMINAR

Other Terms and Conditions

1. If the defective product is not properly packaged and is damaged in transit during its return to Runco, you may be invoiced for either the repair costs, if repairable, or the MSRP of a replacement product and shipping costs incurred by Runco.

2. The repaired or replaced product will assume the remainder of your original product’s warranty term or 90 days from the date the repaired or replaced product is shipped, whichever is longer.

3. If a replacement product is sent, the replacement becomes the property of the customer and the defective product becomes the property of Runco.

Runco SC-30d/SC-35d Installation/Operation Manual v

RuncoCare™ Extended Service Options

Runco offers extended and expanded service plans. For information on additional product protection, please ask your authorized Runco dealer, email serviceorders@runco.com or call (toll free) (800) 23RUNCO (800-237-8626).

Exclusion of Implied Warranties

RUNCO PROVIDES NO WARRANTIES, EXPRESS OR IMPLIED, EXCEPT THOSE EXPRESSLY PROVIDED IN THIS DOCUMENT. RUNCO EXPRESSLY DISCLAIMS AND EXCLUDES ALL OTHER WARRANTIES, INCLUDING THE IMPLIED WARRANTIES OF TITLE, NONINFRINGEMENT, MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Limitation of Liability; Exclusion of Damages

RUNCO’S MAXIMUM AGGREGATE LIABILITY IS LIMITED TO THE COST OF REPAIR, REPLACEMENT OR REFUND OF THE PRODUCT.

RUNCO WILL NOT BE LIABLE FOR DAMAGE TO OTHER PROPERTY OR FOR DAMAGES BASED UPON INCONVENIENCE, LOSS OF USE OF THE PRODUCT, LOSS OF TIME, LOSS OF PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL OR FINANCIAL LOSS, EVEN IF RUNCO IS AWARE OF THE POSSIBILITY OF SUCH DAMAGES AND EVEN IF A REMEDY HAS FAILED OF ITS ESSENTIAL PURPOSE.

RUNCO WILL NOT BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, INDIRECT, EXEMPLARY, SPECIAL, PUNITIVE OR ANY OTHER TYPE OF DAMAGES, WHETHER THE CLAIM IS BASED ON CONTRACT, TORT, PRODUCT LIABILITY, NEGLIGENCE, STRICT LIABILITY OR ANY OTHER LEGAL OR EQUITABLE THEORY.

RUNCO WILL NOT BE LIABLE FOR ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY.

IMINAR

Effect of Local Law

This Limited Warranty gives you specific legal rights, and you may have other rights, which vary from locality to locality. Some localities do not allow limitations on implied warranties and/or do not allow the exclusion of incidental or consequential damages, so the above limitations and exclusions may not apply to you.

PRE

© Copyright 2012 Runco International, LLC (“Runco”). This document contains proprietary information protected by copyright, trademark and other intellectual property laws. All rights are reserved. No part of this manual may be reproduced by any mechanical, electronic or other means, in any form, without prior written permission of Runco.

The trademarks reproduced in this Runco Owner’s Manual and used on the Runco Products are either owned by Runco or are licensed by Runco. You may not reproduce or use the trademarks without the prior written consent of Runco.

Runco Products are manufactured under one or more of the following patents: US. Patent 6755540 and Other Patents Pending.

vi Runco SC-30d/SC-35d Installation/Operation Manual

Important Safety Instructions

Thank you for your purchase of this quality Runco video product! For the best performance, please read this manual carefully as it is your guide through the menus and operation.

WARNING

CAUTION

RISK OFELECTRIC SHOCK

DO NOTOPEN

TO REDUCE THE RISK OF ELECTRIC SHOCK

DO NOT REMOVE COVER (OR BACK)

NO USER SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED

1. Read these instructions.

2. Keep these instructions.

3. Heed all warnings.

4. Follow all instructions.

5. Do not use this apparatus near water.

6. Clean only with a dry cloth.

CAUTION:

SERVICE PERSONNEL.

This symbol is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.

This symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.

7. Do not block any of the ventilation openings. Install in accordance with the manufacturer’s instructions.

8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. When the provided plug does not fit into your outlet, consult an electrician for the replacement of the obsolete outlet.

10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles and the point where they exit from the apparatus.

11. Only use the attachments/accessories specified by the manufacturer.

12. Use only with a cart, stand, tripod, bracket or table specified by the manufacturer or sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for long periods of time.

14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15. The +12V trigger only outputs 12Vdc signal for triggering. Do not connect to any other power input or output. This could cause damage to this unit.

16. Keep the packing material in case the equipment should ever need to be shipped.

17. The lamp becomes extremely hot during operation. Allow the projector to cool down for approximately 45 minutes prior to removing the lamp assembly for replacement.

18. Do not operate lamps beyond the rated lamp life. Excessive operation of lamps beyond rated life could cause them to explode in rare occasions.

PRE

IMINAR

19. Never look directly into the lens when the lamp is on.

Runco SC-30d/SC-35d Installation/Operation Manual vii

IMPORTANT HEALTH AND SAFETY INFORMATION FOR 3D VIEWING:

Please read and make sure you understand the following safety information before using the product for viewing 3D content. Provide this information to the end users of this product and ensure that they understand it.

WARNING

It is widely recognized that stereographic display devices can cause discomfort, including, without limitation, dizziness, nausea, headaches, eye fatigue and eye-strain, in some individuals. The 3D effect and experience will vary by individual, depending on a variety of factors, including his or her health and vision. Runco recommends that users take regular breaks when watching 3D video or playing games using stereoscopic displays. Discontinue use if any discomfort occurs. Parents of young children should ensure their children avoid extensive exposure to electronic stereographic entertainment.

The quality and appropriateness of the 3D screen materials onto which the image is projected and the quality of the 3D content being displayed both have a significant and noticeable impact on the overall 3D experience. A properly-calibrated projection system, including glasses and an optimized third-party screen, displaying high-quality 3D content is the best formula for immersive and comfortable 3D experiences in the home. Please refer to the remainder of this manual for proper projector installation and usage instructions.

The glasses that accompany this product are not safe to use as sunglasses, protective eyewear or any use outdoors or other than only in conjunction with the proper operation of the Runco product with which they are sold. It is common to dim the lights in a home theater. Using 3D glasses and the immersive imagery of stereoscopic imagery can increase the risk of tripping or falling the dark. Special care should be taken.

IMINAR

Do not tilt your head while using the 3D glasses.

PRE

viii Runco SC-30d/SC-35d Installation/Operation Manual

Compliance Information

DECLARATION OF CONFORMITY:

Manufacturer’s Name: Runco International, LLC

Manufacturer’s Address: 1195 NW Compton Drive, Beaverton, OR 97006-1992

hereby declares that the Products’ Model Numbers:

SC-30d, SC-30d/CineWide, SC-30d/CineWide with AutoScope, SC-35d, SC-35d/CineWide and SC-35d/CineWide with AutoScope

conform with the provisions of:

Council Directive 2004/108/EC on Electromagnetic Compatibility;

EN 55022 “Limits and methods of measurements of radio interference characteristics of information technology equipment” 1998;

EN 55024 “Limits and methods of measurements of immunity characteristics of information technology equipment” 1998;

Including:

• EN 61000-4-2 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 2: Electrostatic discharge immunity test”

• EN 61000-4-3 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 3: Radiated, Radio-Frequency, Electromagnetic Field Immunity Test”

• EN 61000-4-4 “Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 4: Electrical fast transient/burst immunity test”

• EN 61000-4-5 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 5: Surge immunity test"

• EN 61000-4-6 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 6: Conducted disturbances induced by radio-frequency fields immunity test"

• EN 61000-4-8 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 8: Conducted disturbances induced by power frequency magnetic fields immunity test"

• EN 61000-4-11 "Electromagnetic compatibility (EMC) Part 4: Testing and measurement techniques Section 11: Voltage dips, short interruptions and voltage variations immunity tests"

PRE

IMINAR

And:

• EN 61000-3-2 "Electromagnetic compatibility (EMC) Part 3, Section 2: Limits for harmonic current emissions (equipment input current up to and including 16 A per phase)" 2000;

• EN 61000-3-3 "Electromagnetic compatibility (EMC) Part 3, Section 3: Limitations of voltage changes, voltage fluctuations and flicker in public low-voltage supply systems, for equipment with rated current up to and including 16 A and not subject to conditional connection" 1995;

Council Directive 2006/95/EC and amended by M1 and C1 on Low Voltage Equipment Safety;

EN 60950 “Safety of information technology equipment, including electrical business equipment”

The Technical Construction file required by this Directive is maintained at the corporate headquarters of Runco International, LLC, located at 1195 NW Compton Drive, Beaverton, OR 97006-1992.

Date of Declaration: September 2012

Runco SC-30d/SC-35d Installation/Operation Manual ix

FCC PART 15:

NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

INDUSTRY CANADA (ICES-003):

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.

PRODUCT DISPOSAL:

IMINAR

The Product contains small amounts of tin, lead and/or mercury. Disposal of these materials may be regulated due to environmental considerations.

IMPORTANT RECYCLE INSTRUCTIONS

Lamp(s) inside this product contain mercury. This product may contain other electronic waste that can be hazardous if not disposed of properly. Recycle or dispose in accordance with local, state, or federal Laws.

PRE

For more information, contact the Electronic Industries Alliance at WWW.EIAE.ORG.

For lamp specific disposal information check WWW.LAMPRECYCLE.ORG.

DISPOSAL OF OLD ELECTRICAL AND ELECTRONIC EQUIPMENT (Applicable throughout the European Union and other European countries with separate collection programs)

This symbol found on your product or on its packaging, indicates that this product should not be treated as household waste when you wish to dispose of it. Instead, it should be handed over to an applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences to the environment and human health, which could otherwise be caused by inappropriate disposal of this product. The recycling of materials will help to conserve natural resources. This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal.

x Runco SC-30d/SC-35d Installation/Operation Manual

1Table of Contents

RuncoCare™ Standard Two Year Limited Warranty ................................................... iii

Important Safety Instructions ....................................................................................... vii

Compliance Information ................................................................................................ ix

1. Introduction ............................................................................................................... 1

About This Manual .......................................................................................................1

Target Audience .....................................................................................................1

If You Have Comments About This Manual.............................................................1

Textual and Graphic Conventions ...........................................................................1

Using This Manual ........................................................................................................ 2

Description, Features and Benefits ...............................................................................3

Key Features and Benefits ......................................................................................4

Parts List ................................................................................................................4

2. System Overview ....................................................................................................... 5

Projector ......................................................................................................................6

SC-30d/SC-35d Rear Panel .........................................................................................7

DC-300 Dimension Digital Controller ............................................................................ 9

Front Panel Layout..................................................................................................9

Rear Panel Layout ................................................................................................11

SC-30d/SC-35d Remote Control Unit ........................................................................ 13

SC-30d/SC-35d Active 3D Emitter ............................................................................. 17

IMINAR

PRE

3. Installation ...............................................................................................................19

Remote Control ..........................................................................................................19

Notes on Batteries ................................................................................................ 19

Notes on Remote Control Operation .....................................................................19

Quick Setup ...............................................................................................................20

Runco SC-30d/SC-35d Installation/Operation Manual xi

Table of Contents

Installation Considerations ..........................................................................................21

Pre-Wiring for 3D: Run Dual HDMI Cables ............................................................21

Installation Type .................................................................................................... 21

Ambient Light .......................................................................................................21

Throw Distance.....................................................................................................22

Vertical and Horizontal Position............................................................................. 24

Vertical and Horizontal Lens Shift..........................................................................24

Folded Optics .......................................................................................................26

Audio/Video Synchronization Issues...................................................................... 27

Other Considerations ............................................................................................ 28

Installing the Primary Projection Lens .........................................................................28

Installing the Optional CineWide Lens Mount ..............................................................30

Installing the AutoScope Lens Motor (SC-30d/SC-35d/

CineWide with AutoScope) ...................................................................................30

Installing the Fixed CineWide Base Plate............................................................... 33

Mounting the SC-30d/SC-35d ...................................................................................34

Floor Mounting (Upright) ....................................................................................... 34

Ceiling Mounting (Inverted)....................................................................................34

Installing the Projector in an Enclosure..................................................................34

Adjusting the Projection Angle ..............................................................................34

Mounting the Dimension Digital Controller ..................................................................35

System Interconnections ............................................................................................36

Connector Panel Access.......................................................................................36

Connecting the Dimension Digital Controller to the Projector.................................36

PRE

Connecting an Audio Processor or Secondary Display Device to the

Dimension Digital Controller (Optional) ..................................................................38

Additional Connections to the Dimension Digital Controller (Optional)....................39

IMINAR

Connecting Source Components to the Dimension Digital Controller ....................43

Connecting the Active 3D Emitter to the Dimension Digital Controller....................49

Connecting to AC Power ......................................................................................49

Turning on the Power ................................................................................................. 50

xii Runco SC-30d/SC-35d Installation/Operation Manual

Table of Contents

Primary Lens Adjustments: Focus, Zoom and Position ............................................... 51

Focus ...................................................................................................................51

Zoom....................................................................................................................51

Vertical and Horizontal Lens Shift..........................................................................51

Adjusting the Picture Orientation ................................................................................52

Adjusting the Image Geometry ...................................................................................53

Installing and Adjusting the CineWide Anamorphic Lens .............................................55

Cylindrical Anamorphic Lens Installation and Adjustment ......................................55

4. Operation .................................................................................................................61

Using the On-Screen Menus ......................................................................................61

Main Menu............................................................................................................63

Input Source......................................................................................................... 63

Aspect Ratio......................................................................................................... 64

Screen..................................................................................................................66

Picture..................................................................................................................67

Input Position........................................................................................................72

Memory Presets .................................................................................................. 74

3D Processing ......................................................................................................75

Sleep Timer ..........................................................................................................76

Information ...........................................................................................................76

Calibration ............................................................................................................77

Service ................................................................................................................. 85

Using the 3D Glasses .................................................................................................98

Key Features.........................................................................................................98

PRE

Functional Overview.............................................................................................. 98

Charging the Battery.............................................................................................99

Turning On the Glasses ......................................................................................100

IMINAR

Auto Power-Off................................................................................................... 100

5. Maintenance and Troubleshooting ......................................................................101

Lamp Replacement ..................................................................................................101

Troubleshooting Tips ................................................................................................102

Runco SC-30d/SC-35d Installation/Operation Manual xiii

Table of Contents

6. External Control ....................................................................................................105

Serial or TCP/IP Communications ............................................................................105

RS-232 Connection and Port Configuration ........................................................105

Using Telnet........................................................................................................105

Command Format ..............................................................................................106

Response Format ...............................................................................................106

Command and Response Examples ...................................................................107

Serial Command List...........................................................................................107

Using Discrete IR Codes ..........................................................................................122

IR Command Protocol ........................................................................................122

IR Command List (Standard Mode) ..................................................................... 123

IR Command List (Extended Mode) ....................................................................126

Using HDMI CEC Messages .....................................................................................127

CEC Command List............................................................................................ 127

7. Specifications ........................................................................................................ 129

SC-30d/SC-35d Projector Specifications .................................................................129

Dimension Digital Controller Specifications ...............................................................132

Supported Timings ...................................................................................................134

SC-30d/SC-35d Dimensions ....................................................................................138

IMINAR

PRE

xiv Runco SC-30d/SC-35d Installation/Operation Manual

1List of Figures

2-1. SC-30d/SC-35d Active 3D Projection System Block Diagram ......................................5

2-2. SC-30d/SC-35d Front/Bottom/Side/Top Views............................................................ 6

2-3. SC-30d/SC-35d Rear Panel .........................................................................................7

2-4. Dimension Digital Controller Front Panel .......................................................................9

2-5. DC-300 Dimension Digital Controller Rear Panel.........................................................11

2-6. Dimension Digital Controller Remote Control Unit for SC-30d/SC-35d ....................... 13

3-1. Estimating Throw Distance .........................................................................................22

3-2. Projector Placement ...................................................................................................24

3-3. Vertical Lens Shift (EXAMPLE ONLY) ..........................................................................24

3-4. Horizontal Lens Shift (EXAMPLE ONLY)......................................................................25

3-5. Folded Optics.............................................................................................................26

3-6. SC-30d/SC-35d/CineWide with AutoScope Motor Assembly – Exploded View ..........30

3-7. Installing the Ceiling Mount Adapters/Projector Stands...............................................31

3-8. AutoScope Lens Motor Installation ............................................................................. 32

3-9. Projector with Cylindrical Lens Base Plate and Ceiling Mounting Rails -

Exploded View ...........................................................................................................33

3-10. Mounting Angle Ranges (Front-to-Back and Side-to-Side)........................................ 34

3-11. Attaching the Rack Mounting Hardware ...................................................................35

3-12. RS-232 Connection from the Dimension Digital Controller to the Projector ...............36

3-13. Connecting the Dimension Digital Controller to the Projector ....................................37

3-14. Audio Processor Connection to Dimension Digital Controller ....................................38

IMINAR

PRE

3-15. RS-232 Control System Connection to Dimension Digital Controller .........................39

3-16. Connecting 12-volt Trigger Outputs..........................................................................40

3-17. External IR Receiver Connection...............................................................................41

3-18. Ethernet Network Connection to Dimension Digital Controller ...................................42

3-19. DisplayPort Source Connection ................................................................................ 43

3-20. HDMI Source Connections .......................................................................................44

3-21. Component Video Source Connections.................................................................... 45

3-22. RGBHV Source Connections....................................................................................46

3-23. SCART RGBS Source Connections..........................................................................47

3-24. Composite Video Source Connections ..................................................................... 48

3-25. Active 3D Emitter Connection ...................................................................................49

3-26. Vertical and Horizontal Lens Shift Adjustments .........................................................51

3-27. Keystone and Pincushion Distortion .........................................................................53

Runco SC-30d/SC-35d Installation/Operation Manual xv

List of Figures

3-28. Image Alignment Controls ........................................................................................54

3-29. Cylindrical Anamorphic Lens Mounting Assembly - Exploded View...........................55

3-30. Attaching the Anamorphic Lens to the Lens Ring ..................................................... 56

4-1. SC-30d/SC-35d OSD Menu Structure .......................................................................61

4-2. Typical PLUGE Pattern for Adjusting Brightness .........................................................68

4-3. Typical Gray Bar Pattern for Adjusting Contrast .......................................................... 68

4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint................................69

4-5. Typical Test Pattern for Adjusting Sharpness..............................................................71

4-6. Overscan Modes ........................................................................................................73

4-7. CIE 1931 Chromaticity Diagram .................................................................................78

6-1. NEC Protocol Message Format ................................................................................ 122

7-1. SC-30d/SC-35d Dimensions ....................................................................................138

IMINAR

PRE

xvi Runco SC-30d/SC-35d Installation/Operation Manual

Introduction

1. Introduction

This Owner’s Manual describes how to install, set up and operate the Runco SC-30d/SC-35d Active 3D Projection System.

Throughout this manual, the Runco SC-30d/SC-35d Active 3D Projection System is referred to as the “SC-30d/SC-35d.”

out of the SC-30d/SC-35d.

Runco has made every effort to ensure that this manual is accurate as of the date it was printed. However, because of ongoing product improvements and customer feedback, it may require updating from time to time. You can always find the latest version of this and other Runco product manuals on-line, at www.Runco.com.

Runco welcomes your comments about this manual. Send them to support@Runco.com.

Text Conventions: The following conventions are used in this manual, in order to clarify the information and instructions provided:

• Remote and built-in keypad button identifiers are set in upper-case bold type; for example, “Press EXIT to return to the previous menu.”

• Computer input (commands you type) and output (responses that appear on-screen) is shown in monospace (fixed-width) type; for example: “To change the aspect ratio to Letterbox, type (ASP = 2) <Enter>.”

• All keys with functional names are initial-capped, set in bold type and enclosed in angle brackets. These keys are the following: <Enter>, <Spacebar>, <Control>, <Esc> and <Tab>.

• <Enter> indicates that you may press either the RETURN or ENTER key on your keyboard if it has both keys.

In addition to these conventions, underlining, boldface and/or italics are occasionally used to highlight important information, as in this example:

PRE

IMINAR

1.1 About This Manual

Target AudienceRunco has prepared this manual to help installation personnel and end users get the most

If You Have Comments About This Manual...

Textual and Graphic Conventions

Note

Runco SC-30d/SC-35d Installation/Operation Manual 1

A carriage return must be used after each command or string.

Introduction

Graphic Conventions: These symbols appear in numerous places throughout the manual, to emphasize points that you must keep in mind to avoid problems with your equipment or injury:

TIPS highlight time-saving short cuts and helpful guidelines for using

Tip

certain features.

1.2

Using This Manual

Note

Caution

NOTES emphasize text with unusual importance or special significance. They also provide supplemental information.

CAUTIONS alert users that a given action or omitted action can degrade performance or cause a malfunction.

WARNING

DANGER!

Use the following table to locate the specific information you need in this manual.

WARNINGS appear when a given action or omitted action can result in damage to the equipment, or possible non-fatal injury to the user.

DANGER appears when a given action can cause severe injury or death.

IMINAR

If you need... ... Turn to page:

Information about obtaining service iv

General information about the SC-30d/SC-35d Active 3D Projection System

Installation instructions 19

PRE

First-time configuration instructions 51

Advanced configuration instructions 77

Troubleshooting tips 102

Specifications for the SC-30d/SC-35d Active 3D Projection System

129

2 Runco SC-30d/SC-35d Installation/Operation Manual

Introduction

Offering the best in high-end luxury projection, the new Signature Cinema™ SC-30d/SC-35d Active 3D Projection System expands Runco’s most prestigious line of custom-built personal cinema projectors.

In concert with the prowess of the Signature Cinema Series, the SC-30d/SC-35d offers exceptional performance with a state-of-the-art product that enables an extraordinary cinematic experience that surpasses even the most renowned public theaters. This is because the product and room are custom-built with the finest components to exactly match an owner’s specifications. The SC-30d/SC-35d utilizes a Runco-patented technology to enable the use of digital cinema lenses in a proprietary optical system and provides an unparalleled range of brightness and features for creating immersive entertainment experiences.

The SC-35d boasts 3,500 ANSI lumens of brightness (uncalibrated), and when calibrated to Runco’s CSMS™ standards delivers a dazzling 87 Foot-Lamberts (fL) of brightness.These benefits combine into a brilliant image that provides a spectacular color gamut and contrast, as well as unmatched color brightness, even on the largest screen sizes. For home theater environments that may not require the SC-35d’s light output capability, the SC-30d provides an impressive 1,950 ANSI Lumens (before calibration) of light output and enhanced contrast. In all other respects, the two projectors are identical.

The SC-30d/SC-35d ships with Runco’s new Dimension Digital Controller™ (DC-300), which has been engineered to enhance 3D performance. This 2U outboard controller provides a level of flexibility and control not commonly found in integrated processors, and provides the Runco installer with a full suite of calibration tools necessary to achieve a perfect picture in any viewing environment.

The SC-30d/SC-35d comes with three pairs of active 3D glasses and relies on frame sequential 3D technology to ensure that users can enjoy 2D and 3D content on the same screen, with full 1080p HD resolution delivered to both eyes.

IMINAR

1.3 Description, Features and Benefits

The SC-30d/SC-35d features Runco’s revolutionary Personal Color Equalizer™ (PCE), which allows color adjustment that includes those exactly defined by the cinematographer and the color preferences of each individual viewer for each source.

In addition to Runco's proprietary Personal Color Equalizer, the SC-30d/SC-35d can also be paired with Runco’s legendary CineWide™ technology. Through an ingenious combination of software, electronics and precision anamorphic optics, CineWide provides uncompromised widescreen reproduction of movies originally filmed in the “scope” 2.35:1 format. It maintains constant vertical height on the screen just as in a movie theater. When a viewer transitions from 1.78:1 (16:9) program material to superwide 2.35:1, the image simply gets wider while full screen height is maintained, eliminating useless black bars on the top and bottom of the screen. Also available with the SC-30d/SC-35d is CineWide with AutoScope™, an enhanced, remote-controlled motorized version of CineWide.

CineWide requires the use of a 2.35:1 (or similar aspect ratio),

Note

Rounding out this projector’s impressive feature set are discrete input source, aspect ratio and power on/off control (via serial commands or IR codes), for seamless integration with automation control systems.

“superwide” format screen.

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 3

Introduction

➤

Key Features and Benefits The SC-30d/SC-35d offers these key features and benefits:

• Native Resolution: 1920 x 1080 (16:9 Native Aspect Ratio)

• Three-chip Digital Light Processing (DLP™) system

• DisplayPort 1.1a Input (on Dimension Digital Controller) with High-bandwidth Digital Content Protection (HDCP)

• Eight (8) HDMI Inputs (on Dimension Digital Controller) with HDCP, 3D and Deep Color

•CinOptx™ Triton™ (SC-30d) or Telesto™ (SC-35d) digital cinema lenses for the best optical performance available in front projection

• Bundled with two years of Runco PremierCare™ service program providing on-site calibration and two years of ongoing support from Runco

Parts List Your SC-30d/SC-35d is shipped with the following items. If any items are missing or

damaged, please contact your Runco dealer or Runco Customer Service at (800) 23RUNCO.

• SC-30d/SC-35d Active 3D Projection System:

• Projection Unit

• Dimension Digital Controller unit

• Remote Control Unit and batteries

• AC Power Cords (2)

• RJ-11 Telephone Cable, 50 feet (15.24 meters)

• Serial Port Adapter, RJ-11 Female to DB-9 Male

• Active 3D Emitter and projector interface cable, 3.28 feet (1.0 meters)

• Active 3D Glasses (3 pairs)

• 3/16” Long-length Hex Wrench (for lens adjustments)

• HDMI-to-HDMI Cables (2), sold separately (refer to Optional Accessories, below)

• Rack-mount hardware for the Dimension Digital Controller

• Runco SC-30d/SC-35d Quick Setup Guide

IMINAR

Optional Accessories:

PRE

• Secondary anamorphic lens and lens mount

• Replacement Lamp (part number 997-5268-00)

• Ceiling mount kit (part number 956-0074-00)

• HDMI-to-HDMI Cable, length specified at time of order:

• 16.4 feet (5.0 meters) (part number 903-1010-00)

• 24.6 feet (7.5 meters) (part number 903-1011-00)

• 32.8 feet (10.0 meters) (part number 903-1012-00)

• 49.2 feet (15.0 meters) (part number 903-1013-00)

• 65.6 feet (20.0 meters) (part number 903-1014-00)

4 Runco SC-30d/SC-35d Installation/Operation Manual

2. System Overview

A SC-30d/SC-35d Active 3D Projection System consists of the following components:

• The projector (equipped with dual digital video inputs) with optional anamorphic lens and lens transport assembly.

• The DC-300 Dimension Digital Controller™ unit that provides “left-eye” and “right-eye“ video signals and the on-screen display (OSD) menu to the projector. In addition, the Dimension Digital Controller controls the projector in response to user input via its infrared (IR) remote control unit or front-panel keypad, an external control system or HDMI Consumer Electronics Control (CEC) messages.

• An Active 3D Emitter that receives a left/right synchronization signal from the Dimension Digital Controller and transmits it to the Active 3D Glasses worn by the viewers. This signal precisely controls when left and right fields are visible through the glasses.

Figure 2-1 shows how these components connect to and interact with each other. The following sections describe each one in detail.

System Overview

Remote

Video

Sources

Figure 2-1. SC-30d/SC-35d Active 3D Projection System Block Diagram

Control

HDMI, DisplayPort,

Component, SCART,

RGB, Composite

HDMI Audio Out

DC-300

Dimension Digital Controller

Primary

Video

Scaler

Primary Video

(Left)

IMINAR

RS-232

Secondary

Video

Scaler

Primary Video/CEC (Control)

Secondary Video

PRE

2D/3D Video

Decoder/

Multiplexer

Secondary Video

(Right)

L/R Stereo Sync

Projector

Optical Engine

Trigger

Active 3D

Emitter

Anamorphic

Lens

Active 3D

Glasses

Runco SC-30d/SC-35d Installation/Operation Manual 5

System Overview

2.1

Projector

A SC-30d/SC-35d Active 3D Projection System can display both traditional 2D and stereoscopic 3D video content.

An active 3D presentation requires a specialized video signal source configuration and content to be displayed correctly. Images from a stereo 3D video source consist of a series of images (called frames or fields) that alternate quickly between two slightly different view points, corresponding to a viewer’s left and right eyes.

When these frames are displayed fast enough and viewed with special stereo glasses synchronized to the left/right changes, the resulting image appears with the same depth and perspective that is sensed in the real world.

Figure 2-2 shows the key SC-30d/SC-35d components.

IMINAR

PRE

3 4

Figure 2-2. SC-30d/SC-35d Front/Bottom/Side/Top Views

6 Runco SC-30d/SC-35d Installation/Operation Manual

1. PROJECTION LENS

The inside of the lens barrel is threaded to accommodate a standard, 72-mm lens filter. For example, with a smaller screen you can install a neutral-density filter to reduce the overall light output.

2. VERTICAL LENS SHIFT CONTROL

To access the vertical lens shift control, insert the included 5.0-mm Hex wrench into this opening and turn it as needed to shift the lens in the desired direction (refer to Primary Lens Adjustments: Focus, Zoom and Position on page 51).

3. RUNCO LOGO

The logo can be rotated to match the projector orientation: inverted (ceiling-mounted) or upright. To rotate the logo, grip it at the sides, pull it away from the projector and rotate it 180 degrees.

4. EXHAUST VENT

Warm air exits the projector through this vent. Ensure that it is not blocked.

5. HORIZONTAL LENS SHIFT CONTROL

To access the horizontal lens shift control, insert the included 5.0-mm Hex wrench into this opening and turn it as needed to shift the lens in the desired direction (refer to Adjusting the Focus, Zoom and Position of the Primary Lenses on page 54).

6. INTAKE VENT

Internal fans draw cool air into the projector through this vent.

7. CEILING MOUNTING HOLES

Use these to attach the ceiling bracket (if needed) to the projector.

8. CABLE OPENING

Pass cables through this opening.

IMINAR

System Overview

Figure 2-3 shows the SC-30d/SC-35d rear panel.

PRE

RS232

1 2 3 4 65 7

PRIMARY

SECONDARY

2.2 SC-30d/SC-35d Rear Panel

SECONDARY

Figure 2-3. SC-30d/SC-35d Rear Panel

Runco SC-30d/SC-35d Installation/Operation Manual 7

System Overview

1. RS232 (Control) A female, 9-pin D-sub connector that provides a serial communication link to the Dimension Digital Controller, via its Pri. Display Control output (see Figure 2-5).

2. 3D LED Lights green when the projector is displaying 3D content.

3. PRIMARY VIDEO INPUT Connect the HDMI Out To Primary Display connector from the Dimension Digital Controller to this input (see Figure 2-5).

4. PRIMARY SOURCE LED Lights amber when the projector detects a valid primary video signal from the Dimension Digital Controller.

5. SECONDARY VIDEO INPUT Connect the HDMI Out To Sec. Display connector from the Dimension Digital Controller to this input (see Figure 2-5).

6. SECONDARY SOURCE LED Lights amber when the projector detects a valid secondary video signal from the Dimension Digital Controller.

7. POWER INPUT (100 to 240 VAC) Connect the SC-30d/SC-35d to power here.

IMINAR

PRE

8 Runco SC-30d/SC-35d Installation/Operation Manual

System Overview

The Dimension Digital Controller provides “left-eye” and “right-eye” video signals and the OSD menu to the projector. It controls the other system components in response to user input via the following interfaces:

• Front-panel keypad

• IR remote control unit

• HDMI CEC messages

• Serial commands via RS-232 or TCP/IP

•Ethernet

panel; the paragraphs that follow describe them.

SC-30d/SC-35d

HDMI 1

16:9/1 1080i/60

standby

91011

IMINAR

2.3 DC-300 Dimension Digital Controller

Front Panel LayoutFigure 2-4 shows the controls and indicators on the Dimension Digital Controller front

Figure 2-4. Dimension Digital Controller Front Panel

1. RUNCO ICON Lights blue to indicate that the controller is on or powering up.

2. IR SENSOR Receives IR commands from the remote control.

3. VACUUM FLUORESCENT DISPLAY Can be used instead of the On-Screen Display (OSD). Displays currently-selected menu or – if no menu is selected – the connected display device model, current source, input resolution and aspect ratio/screen.

4. ON/STANDBY BUTTON Press once to toggle from standby mode to on mode. Press it again to return to standby mode. For a discrete on or off command, you can use the direct access buttons on the remote control.

5. LEFT BUTTON Used to direct-select inputs or move the menu cursor left in the OSD. When no menu is present on-screen, the LEFT button toggles through the different sources, in this order: DisplayPort - HDMI 8 - HDMI 7 - HDMI 6 - HDMI 5 - HDMI 4 - HDMI 3 - HDMI 2 HDMI 1 - SCART - HD 2 - HD 1 - Component - Composite 3 - Composite 2 Composite 1

PRE

654 87

Runco SC-30d/SC-35d Installation/Operation Manual 9

System Overview

6. DOWN BUTTON Use to direct-select aspect ratios or move the menu cursor down in the OSD. When no menu is present on-screen, this button toggles through aspect ratios in the following order: 16:9 - 4:3 - Letterbox - VirtualWide - Cinema - Virtual Cinema - Native

7. RIGHT BUTTON Used to direct-select inputs or move the menu cursor right in the OSD. When no menus are present on-screen, the RIGHT button toggles through the different sources, in this order: Composite 1 - Composite 2 - Composite 3 - Component - HD 1 - HD 2 - SCART HDMI 1 - HDMI 2 - HDMI 3 - HDMI 4 - HDMI 5 - HDMI 6 - HDMI 7 - HDMI 8 DisplayPort

8. MENU BUTTON Press the MENU button to bring up the main menu, or to exit the current menu and return to the previous one.

9. UP BUTTON Use to direct-select aspect ratios or move the menu cursor up in the OSD. When no menus are present on-screen, the UP button toggles through aspect ratios in the following order: Native - Virtual Cinema - Cinema - VirtualWide - Letterbox - 4:3 - 16:9

10. ENTER BUTTON When an item is highlighted on the OSD, the ENTER button selects the item.

11. STANDBY LED Lights amber when the Dimension Digital Controller is in standby mode; otherwise it is off.

IMINAR

PRE

10 Runco SC-30d/SC-35d Installation/Operation Manual

System Overview

Compone

HD2

Rear Panel LayoutFigure 2-5 shows the rear connector panel on the Dimension Digital Controller.

1 2

3D SYNC

DisplayPort

HD2

TRIGGERS

123

Component / SCART

13 181714

Video 1

Video 2

deo

Video 3

deo

USB

HDMI 2 HDMI 4 HDMI 6 HDMI 8

Figure 2-5. DC-300 Dimension Digital Controller Rear Panel

1. MAIN POWER SWITCH Disconnects or applies power to the Dimension Digital Controller.

2. 3D Sync Out A 3-pin, VESA standard mini-DIN connector for connecting the Runco Active 3D Emitter to the Dimension Digital Controller (see Figure 3-25).

IMINAR

3. TRIGGERS Connection for up to three (3), 12-volt trigger-controlled devices such as retractable

screens or screen masks. Output current is limited to 250 milliamperes (mA).

RS-232

To Accessory Box

Pri. Display Control Sec. Display Control

Ethernet

HDMI Out

To Sec. Display

HDMI Out

Audio Only

96 754

RS-232

PC / Control

HDMI Out

To Pri. Display

1916

4. USB A standard, USB Series “B” connection to a personal computer, for performing software upgrades and other service procedures.

5. RS-232 (To Accessory Box) Reserved for future use.

PRE

6. Pri. Display Control Connect this to the RS-232 input on the projector.

7. Sec. Display Control Not used.

8. IR Wired input from a Niles- or Xantech-compatible, infrared (IR) repeater system. It is a

3.5-mm, mini phono jack, wired as follows: Ring = No connection Tip = IR Input Sleeve = Ground

9. RS-232 (PC / Control) A female, 9-pin D-sub connector for interfacing with a PC or automation/control system.

10. POWER INPUT (100 to 240 VAC) Connect the Dimension Digital Controller to power here.

Runco SC-30d/SC-35d Installation/Operation Manual 11

System Overview

11. DisplayPort DisplayPort 1.1a and DisplayPort-HDCP 1.1 compliant, SD/HD input for connecting SDTV, EDTV or HDTV component video sources.

12. HD1 / HD2 In (15-pin VGA) Two inputs for connecting standard-definition (SD = 480i/576i), enhanced-definition (ED = 480p/576p) or high-definition (HD = 720p/1080i/1080p) component video sources, or RGBHV sources such as personal computers.

13. Component / SCART In (3 x RCA connectors) SD/HD input for connecting SDTV, EDTV or HDTV component video sources. Also provides RGB input for SCART RGBS sources.

14. Video 1 / Video 2 / Video 3 In Standard, composite video inputs for connecting a VCR, camcorder or other composite video source. The Video 1 input also provides composite sync input for SCART RGBS sources.

15. HDMI 1 ... HDMI 8 In (Digital) Eight (8), HDCP-compliant digital video inputs for connecting HDMI or DVI sources.

16. Ethernet A female RJ-45 connector for wired network communications.

17. HDMI Out (Audio Only) Connect this output to an audio control system to pass through HDMI audio.

Note

IMINAR

18. HDMI Out (To Secondary Display)

19. HDMI Out (To Primary Display)

Connect this to the SECONDARY video input on the projector.

Connect this to the PRIMARY video input on the projector.

PRE

The Dimension Digital Controller does not transmit HDMI CEC control messages from the “HDMI Audio Out” connector.

12 Runco SC-30d/SC-35d Installation/Operation Manual

System Overview

Figure 2-6 shows the SC-30d/SC-35d remote control, and the paragraphs that follow describe its functionality.

Note

The SC-30d/SC-35d remote control unit supports an “extended” key code mode that allows certain buttons to perform alternate functions. The following list identifies those buttons that have both standard- and extended-mode functions.

For more information, refer to Remote Control on page 87 and IR Command List (Extended Mode) on page 126.

IMINAR

2.4 SC-30d/SC-35d Remote Control Unit

PRE

Figure 2-6. Dimension Digital Controller Remote Control Unit for SC-30d/SC-35d

Runco SC-30d/SC-35d Installation/Operation Manual 13

System Overview

1. IR OUTPUT INDICATOR Lights when a button is pressed to indicate that an IR signal is being transmitted.

2. OFF (Standard) / Sleep Timer = 30 Minutes (Extended) Press to turn off the Dimension Digital Controller and projector. In extended mode, press to set the Sleep Timer to 30 minutes.

3. ON (Standard) / Sleep Timer = Off (Extended) Press to turn on the Dimension Digital Controller and projector. In extended mode, press to disable the Sleep Timer.

4. Aspect Ratio Selection Buttons Use these buttons to select an aspect ratio directly, as follows:

16:9 (Standard) / Sleep Timer = 60 Minutes (Extended)

For viewing 16:9 DVDs or HDTV programs in their native aspect ratio. In extended mode, press to set the Sleep Timer to 60 minutes.

4:3 (Standard) / Sleep Timer = 90 Minutes (Extended)

Scales the input signal to fit 4:3 display mode in the center of the screen. In extended mode, press to set the Sleep Timer to 90 minutes.

LETBOX (Letterbox - Standard) / Sleep Timer = 2 Hours (Extended)

For viewing non-anamorphic (“full-screen”) DVDs on a 16:9 screen. In extended mode, press to set the Sleep Timer to 2 hours.

V-WIDE (VirtualWide - Standard) / Sleep Timer = 4 Hours (Extended)

Enlarges a 4:3 image horizontally in a non-linear fashion to fit 16:9 full screen display. In extended mode, press to set the Sleep Timer to 4 hours.

CINEMA (Standard) / Video 1 Input (Extended) For viewing 2.35:1 source material. In extended mode, press to select the Video 1 (Composite 1) input.

V-CINE (Standard) / Component Input (Extended)

Selects the Virtual Cinema aspect ratio, used for viewing 16:9 source material on a

2.35:1 screen. In extended mode, press to select the Component input.

IMINAR

PRE

NATIVE (Standard) / HD 1 Input (Extended)

Displays the source signal in its native resolution, centered in the display area. In extended mode, press to select the HD 1 input.

14 Runco SC-30d/SC-35d Installation/Operation Manual

5. Numeric Buttons (Standard) Use these buttons to enter numeric characters (0 ... 9), such as when changing remote control codes (refer to Remote Control on page 87).

Numeric Buttons (Extended)

In extended mode, press a numbered button to select a video source, as follows:

Remote Control Button Source Assignment in Extended Key Code Mode

System Overview

6. SCREEN 1 (Standard) / Video 3 Input (Extended) SCREEN 2

Use these buttons to select a screen profile. For more information, refer to Screen on page 66.

In extended mode, press SCREEN 1 to select the Video 3 (Composite 3) input.

7. Memory Preset Buttons:

HD 2

HDMI 1

HDMI 2

HDMI 3

HDMI 4

HDMI 5

HDMI 6

HDMI 7

HDMI 8

DisplayPort

IMINAR

ISF NIGHT (Standard) / SCART (Extended)

Press to recall settings for the current input from the “ISF Night” memory preset. In extended mode, press to select the SCART input.

ISF DAY (Standard) / Video 2 (Extended)

Press to recall settings for the current input from the “ISF Day” memory preset. In extended mode, press to select the Video 2 (Composite 2) input.

CUST 1 (Standard) / 3D Mode = Off (Extended)

Press to recall settings for the current input from the “Custom 1” memory preset. In extended mode, press to set the 3D Mode to Off (for 2D content).

CUST 2 (Standard) / Aspect Ratio = Auto Cinema (Extended)

Press to recall settings for the current input from the “Custom 2” memory preset. In extended mode, press to set the Aspect Ratio to Auto Cinema.

8. EXIT Press this button to exit the current menu and return to the previous one.

Runco SC-30d/SC-35d Installation/Operation Manual 15

PRE

System Overview

9. MENU Press this button to access the OSD controls, or to exit the current menu and return to the previous one.

10. Cursor Buttons (, , , ) Use these buttons to select items or settings, adjust settings or switch display patterns.

When no menu is present on-screen, the UP and DOWN buttons toggle through the available aspect ratios, in this order:

UP Button = Native - Virtual Cinema - Cinema - VirtualWide - Letterbox - 4:3 - 16:9 DOWN Button = 16:9 - 4:3 - Letterbox - VirtualWide - Cinema - Virtual Cinema -

Native

Note

Likewise, the LEFT and RIGHT buttons toggle through the different source inputs, in this order: LEFT Button = DisplayPort - HDMI 8 - HDMI 7 - HDMI 6 - HDMI 5 - HDMI 4 - HDMI 3

- HDMI 2 - HDMI 1 - SCART - HD 2 - HD 1 - Component - Composite 3 Composite 2 - Composite 1 RIGHT Button = Composite 1 - Composite 2 - Composite 3 - Component - HD 1 HD 2 - SCART - HDMI 1 - HDMI 2 - HDMI 3 - HDMI 4 - HDMI 5 - HDMI 6 - HDMI 7 HDMI 8 - DisplayPort

11. ENTER Press to select a highlighted menu item or confirm a changed setting.

12. LIGHT Press to illuminate the buttons.

13. SRC 1, SRC 2 ... SRC 14 Use these buttons to select a video source. You can assign each button to any source you wish. By default, these buttons are assigned as follows:

PRE

IMINAR

Remote Control Button Default Source Assignment

SRC 1 ... SRC 8

For more information about aspect ratios, refer to Table 4-1.

HDMI 1 ... HDMI 8

SRC 9

SRC 10

SRC 11

SRC 12

SRC 13

SRC 14

For instructions on how to change these assignments, refer to SRC 1-7 Keys / SRC 8-14 Keys on page 88.

16 Runco SC-30d/SC-35d Installation/Operation Manual

DisplayPort

Component

HD 1

HD 2

Composite 1

Composite 2

14. 3D Mode Selection Buttons:

3D AUTO Press to set the 3D Mode to Auto.

3D SBS (Side-by-Side) Press to set the 3D Mode to 3D Side-by-Side.

3D TAB (Top-and-Bottom) Press to set the 3D Mode to 3D Top-and-Bottom.

3D FP (Frame Packing) Press to set the 3D Mode to 3D Frame Packing.

System Overview

Note

The Active 3D Emitter, shown below, receives a left/right synchronization signal from the Dimension Digital Controller and transmits it to the Active 3D Glasses worn by the viewers. This signal precisely controls when left and right fields are visible through the glasses.

The Active 3D Emitter has the following functional components:

1. LED Indicators Five (5), multi-colored LEDs indicate modes of operation. During normal operation, all five LEDs are off.

2. Joystick Use this to enable various modes and change settings.

3. USB Port A USB “Micro B“ port for connecting to a PC to perform software upgrades.

4. 3D SYNC IN Connect the 3D SYNC output from the Dimension Digital Controller (see Figure 2-5) to this input, using the supplied cable.

For more information about 3D modes, refer to 3D Mode on page 75.

IMINAR

PRE

2.5 SC-30d/SC-35d Active 3D Emitter

For more information configuring the emitter to work with the 3D glasses, refer to Using the 3D Glasses on page 98.

Runco SC-30d/SC-35d Installation/Operation Manual 17

System Overview

Notes:

IMINAR

PRE

18 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

3. Installation

Note

To install batteries in the remote control:

1. Press down the tab on the cover and pull the cover in the direction of the arrow.

2. Insert the included batteries. Ensure that the polarities correctly match the and markings inside the battery compartment.

3. Insert the lower tab of the cover into the opening, and press down the cover until it clicks in place.

• Do not mix an old battery with a new one or different types of batteries.

• If you will not use the remote control for a long time, remove the batteries to avoid

damage from battery leakage.

• Do not expose batteries to excessive heat such as from sunshine, fire or the like.

• Make sure that there is nothing obstructing the infrared beam between the remote

control and the IR receiver on the Dimension Digital Controller.

• If the effective range of the remote control decreases, or it stops working, replace the

batteries with new ones.

• The remote control may fail to operate if the infrared remote sensor is exposed to bright

sunlight or fluorescent lighting.

• Ambient conditions may possibly impede the operation of the remote control. If this

happens, point the remote control at the Dimension Digital Controller, and repeat the operation.

Installation must be performed by a qualified custom video installation specialist.

IMINAR

PRE

3.1 Remote Control

Notes on Batteries• Make sure that the battery polarities are correct when installing the batteries.

Notes on Remote Control Operation

Runco SC-30d/SC-35d Installation/Operation Manual 19

Installation

3.2

Quick Setup

Table 3-1 gives a quick overview of the SC-30d/SC-35d installation process. The sections following this one provide detailed instructions.

Table 3-1. Installation Overview

Step Procedure

Choose a location for the projector 21

Install primary projection lens 28

Install anamorphic lens mounting assembly (optional) 30, 40

Mount the projector 34

Mount the Dimension Digital Controller 35

Connect the Dimension Digital Controller to the projector 36

Connect other external equipment to Dimension Digital Controller (optional):

• Audio processor or secondary display device

• Control system interface (RS-232)

• 12-volt trigger-activated equipment (retractable screens or screen masking)

• External IR repeater

• Network hub, router or gateway (Ethernet)

For Details, Refer

to page...

IMINAR

Connect signal sources to the Dimension Digital Controller 43

Connect the Active 3D Emitter to the Dimension Digital Controller 49

Connect system components to AC power 49

Apply power to the projector 50

Adjust primary lens: projected image size (zoom), position (shift) and focus

PRE

For rear-screen and/or ceiling-mount installations, select the proper picture orientation

Use Image Alignment controls to fine-tune image geometry 53

Install and adjust secondary anamorphic lens (optional) 55

Display calibration: adjust the following for each Dimension

Digital Controller input and display mode (resolution/frame rate); save settings when finished:

• Aspect ratio • Color level

• Brightness • Tint

• Contrast • Input position

• Color temperature and white balance

Prepare Active 3D Glasses for use and test with 3D source material

24, 51

64 through 83

20 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

Proper installation of your projector will ensure the quality of your display. Whether you are installing a projector temporarily or permanently, you should take the following into account to ensure your projector performs optimally.

It is a common practice in custom audio/video installations to conceal cables by running them through walls.

If you plan to do this with your SC-30d/SC-35d installation, you will need to run three cables from the projector to the Dimension Digital Controller: two (2) HDMI cables and a serial control cable (typically Category 5 or 4-wire telephone cable).

inverted mount. Table 3-2 compares these various installation methods.

Table 3-2. Projector Installation Options

Advantages Considerations

Front Screen, Floor Mount Installation

• Easy to set up

• Can be moved or changed quickly

• Easy to access

Front Screen, Inverted Mount (ceiling) Installation

• Does not take up audience space

• Projector is unobtrusive

• Projector cannot be accidentally moved

• Shares floor space with audience

IMINAR

• Installation is more permanent

• Projector access is more difficult

3.3 Installation Considerations

Pre-Wiring for 3D: Run Dual HDMI Cables

Installation TypeChoose the installation type that best suits your needs: front or rear screen, floor mount or

Rear Screen, Floor Mount Installation

• Projector is completely hidden

• Projector is easily accessed

• Usually good ambient light rejection

Rear Screen, Inverted Mount (ceiling) Installation

• Projector is completely hidden

• Usually good ambient light rejection

• Projector is completely hidden

• Usually good ambient light rejection

• Requires less space behind screen than other rear screen installations

images will be noticeably reduced if light directly strikes the screen, such as when a shaft of light from a window or floodlight falls on the image. Images may then appear washed out and less vibrant.

PRE

Rear Screen, Floor Mount with Mirror

• Requires separate room

• Installation cost is usually higher

• Requires separate room

• Installation cost is usually higher

• Requires separate room

• Installation cost is usually higher

Ambient LightIn general, minimize or eliminate light sources directed at the screen. Contrast ratio in your

Runco SC-30d/SC-35d Installation/Operation Manual 21

Installation

➤

Throw Distance Throw distance is the distance measured from the front of the projector to the screen.

This is an important calculation in any projector installation as it determines whether or not you have enough room to install your projector with a desired screen size and if your image will be the right size for your screen.

You can quickly estimate the throw distance by taking the width of the screen and multiplying it by the lens throw ratio; see Figure 3-1. The result of this calculation tells you roughly how far back the projector should be positioned from the screen in order to project a focused image large enough to fill the screen.

Estimating Throw Distance

Throw Distance (TD) = Screen Width (w) x Lens Throw Ratio

IMINAR

Figure 3-1. Estimating Throw Distance

PRE

Screen width (w)

22 Runco SC-30d/SC-35d Installation/Operation Manual

Table 3-3 lists the available lens options for the SC-30d/SC-35d and their associated throw ratios.

Table 3-3. Lens Options and Throw Ratios

Installation

Lens Option

(Note 2)

Triton A

Triton B

Triton C

Triton D

Triton E

Telesto A

Telesto B

Telesto C

Throw Range in

Throw Ratio

with Primary

Lens Only

SC-30d Lens Options and Throw Ratios

0.96 (Fixed)

1.98 - 2.64 213.84 285.12 1.48 - 1.98 213.12 285.12

2.64 - 3.69 285.12 398.52 1.98 - 2.77 285.12 398.88

3.69 - 5.94 398.52 641.52 2.77 - 4.45 398.88 640.80

5.94 - 9.90 641.52 1069.20 4.45 - 7.20 640.80 1068.48

SC-35d Lens Options and Throw Ratios

0.97 (Fixed)

1.93 - 2.41 208.44 260.28 1.45 - 1.81 208.80 260.64

2.41 - 3.38 260.28 365.04 1.81 - 2.53 260.64 364.32

inches, with

108 x 60.75-inch

(1.78:1) Screen

Minimum Maximum Minimum Maximum

For rear-screen installa-

tions only. Contact

Runco Technical Support

for more information.

For rear-screen installa-

tions only. Contact

Runco Technical Support

for more information.

Throw Ratio

with Primary

Lens and

Anamorphic

Lens

IMINAR

Throw Range in

inches, with

144 x 60.75-inch

(2.35:1) Screen

Not Applicable

(Note 2)

Not Applicable

(Note 2)

Telesto D

Telesto E

Notes:

1. Due to normal manufacturing variances, throw distance can vary by up to +/- 5 percent from these specifications.

2. The Triton A and Telesto A lenses cannot be used with the optional CineWide (secondary anamorphic) lens.

3.38 - 6.03 365.04 651.24 2.53 - 4.52 364.32 650.88

6.03 - 9.65 651.24 1042.20 4.52 - 7.24 650.88 1042.56

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 23

Installation

➤

Vertical and Horizontal

Position

Proper placement of the projector relative to the screen will yield a rectangular, perfectly-centered image that completely fills the screen.

Ideally, the projector should be positioned perpendicular to the screen and in such a way that the lens center is aligned with either the top or bottom edge of the screen area, and centered horizontally. See Figure 3-2.

Ceiling Installation

Height

Floor Installation

Height

Lens Center

Projection Distance

Screen

Lens Center

Ceiling

Lens CenterLens Center

Vertical and Horizontal

Lens Shift

PRE

Figure 3-2. Projector Placement

You can use the lens shift controls to center the image on the screen. Lens shift is generally expressed as a percentage of the screen height or width, as shown in Figure 3-3 and Figure 3-4.

Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example.

IMINAR

Projection Distance

Floor

Screen Center

50% Height

Lens Shift

(0.5 x H)

100% Height

Lens Shift

(1.0 x H)

Figure 3-3. Vertical Lens Shift (EXAMPLE ONLY)

24 Runco SC-30d/SC-35d Installation/Operation Manual

100% Width Lens Shift

(1.0 x W)

50% Width Lens Shift

(0.5 x W)

Screen Width (W)

Installation

Screen Center

Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example.

Figure 3-4. Horizontal Lens Shift (EXAMPLE ONLY)

IMINAR

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 25

Installation

➤

Table 3-4 lists the lens shift limits for each available SC-30d/SC-35d lens, as percentages and absolute measurements with a 108 x 60.75 inch (1.78:1) screen.

Table 3-4. SC-30d/SC-35d Vertical and Horizontal Lens Shift Limits

Telesto A Telesto B Telesto C Telesto D Telesto E

Lens Shift Limits, as Percentages of Screen Height or Width (Note 1)

Vertical

(Note 2)

Horizontal

(Note 1)

Vertical

Horizontal

Notes:

1. Vertical shift limits are percentages of the screen height. Horizontal shift limits are percentages of the screen width.

2. Vertical lens shift figures apply to ceiling mount configurations. For floor installations (where the projector is upright), reverse the up/down vertical offset percentages.

3. Lens shift is not possible in any direction with the Telesto A lens. The vertical position is fixed at 50% down.

Folded Optics In rear-screen applications where space behind the projector is limited, a mirror may be

used to fold the optical path, as shown in Figure 3-5. The position of the projector and mirror must be accurately set. If you are considering this type of installation, contact your

PRE

dealer for assistance.

Down 50% - 100%

Left 44%

Right 44%

Lens Shift Limits in Inches, with a 108-by-60.75 inch (1.78:1) Screen

Down 30.38 - 60.75

Left 47.52

Right 47.52

(Note 3)

IMINAR

0.00

Screen

Mirror

Figure 3-5. Folded Optics

26 Runco SC-30d/SC-35d Installation/Operation Manual

Tip

Installation

For best performance, always use “first-surface” mirrors in your rear-projection installation (as opposed to conventional, “second-surface” mirrors with the reflective surface behind a transparent substrate such as glass or acrylic).

First-surface mirrors provide a strict reflection without the “ghosting” effect seen with a second surface mirror, where a faint secondary reflection could be observed coming from the front surface of the glass.

This is especially critical for 3D viewing; with a conventional second-surface mirror, the resulting image quality may be unacceptable.

Due to its extraordinarily high level of video processing performance, the Dimension Digital Controller may distribute video signals with a perceptible level of audio latency. In order to easily solve this issue, Runco recommends using the Dimension Digital Controller with a high-quality audio receiver that has the ability to effectively synchronize audio and video signals.

Most mainstream audio receiver/switchers have the ability to synchronize the audio and video to the Advanced Television Systems Committee (ATSC) prescribed tolerances. According to the ATSC, the sound program should never lead the video program by more than 15 milliseconds, and should never lag behind the video program by more than 45 milliseconds.

In addition, many video displays and A/V receivers introduce additional latency that needs to be compensated for during the installation.

Table 3-5 shows the amount of possible audio latency given different signal input timings.

Table 3-5. Possible Audio Latency for Various Input Timings

Input Timing Possible Audio Latency (milliseconds)

480i 133

480p 83

576i 160

576p 100

720p/50 100

720p/60 83

PRE

IMINAR

Audio/Video Synchronization Issues

1080i/25 160

1080i/30 133

1080p/24 125

1080p/50 80

1080p/60 67

Runco SC-30d/SC-35d Installation/Operation Manual 27

Installation

➤

Other Considerations Other considerations and tips that can help improve your installation:

• Keep the ambient temperature constant and below 35°C (95°F). Keep the projector away from heating and/or air conditioning vents. Changes in temperature may cause drifts in the projector circuitry, which may affect performance.

• Keep the projector away from devices that radiate electromagnetic energy such as motors and transformers. Common sources of these include slide projectors, speakers, power amplifiers and elevators.

3.4 Installing the Primary Projection Lens

The primary projection lens is shipped separately from the projector. Tto install it, proceed as follows:

1. Carefully remove the projector from the

shipping container and place it on a flat surface.

2. Loosen the Phillips screws at the bottom

and top of the decorative bezel on the front of the projector.

IMINAR

PRE

3. Grasp the bezel by the front, then slide it

forward to remove it.

4. Carefully remove the lens from the shipping container.

5. Remove the rear cap from the lens. This protective cap is only used during shipping to

protect the lens from damage.

28 Runco SC-30d/SC-35d Installation/Operation Manual

6. Hold the lens assembly with the motor facing right (toward the Runco logo). Carefully insert the back of the lens assembly into the hole in the lens flange.

Installation

Caution

7. Secure the lens to the projector using the six (6), 9/64” Hex Mounting Screws (two each at 12 o'clock, 9 o'clock and 6 o'clock).

8. Connect the lens motor to the projector.

Make sure to route the wire harness away from the moving lens stages and Motor Assembly, to prevent unexpected disconnection or lens damage.

IMINAR

PRE

9. Re-install the front bezel that you removed in Steps 2 and 3. Tighten the Phillips screws on the bottom and top of the bezel to secure it.

Runco SC-30d/SC-35d Installation/Operation Manual 29

Installation

➤

3.5

Installing the Optional CineWide Lens Mount

Installing the AutoScope

Lens Motor

(SC-30d/SC-35d/

CineWide with AutoScope)

If you are installing a standard SC-30d/SC-35d (without an anamorphic lens), skip this step and proceed with Mounting the SC-30d/SC-35d (page 34).

If you are installing an SC-30d/SC-35d/CineWide, proceed with Installing the Fixed CineWide Base Plate (page 33).

If you are installing a SC-30d/SC-35d/CineWide with AutoScope, proceed as follows to install the AutoScope lens motor.

Note

Figure 3-6 shows the SC-30d/SC-35d/CineWide with AutoScope motor assembly.

Screw, Phillips Pan-Head,

10-32 x 3/8” (12x)

AutoScope

Lens Motor

1. Do not install the CineWide lens yet, only the fixed CineWide base plate or AutoScope lens motor. You will install the CineWide lens after you install the projector and adjust the primary lens.

2. Some components shipped with your projector may differ slightly from what is shown in these instructions.

CineWide with AutoScope

Ceiling Mount Adapter/ Projector Stand, Right

IMINAR

CineWide with

AutoScope Ceiling Mount Adapter/ Projector Stand, Left

PRE

Figure 3-6. SC-30d/SC-35d/CineWide with AutoScope Motor Assembly – Exploded View

30 Runco SC-30d/SC-35d Installation/Operation Manual

Remove Projector Front Feet:

Place the projector upside down on a blanket or other soft surface. Use a Phillips screwdriver to loosen the screws attaching the two front feet to the projector. Then, remove the feet.

Install Ceiling Mount Adapters/Projector Stands: For ceiling installations, the adapters bring the attachment points for the projector mounting rails (included with the projector ceiling mount kit) from the bottom of the projector up above the AutoScope lens motor housing. For floor installations (where the projector is upright), the adapters allow the projector to lie flat on the mounting surface.

Using eight (8) each of the supplied, Pan-Head Phillips screws, attach the AutoScope Ceiling Mount Adapters/Projector Stands to the projector as shown in Figure 3-7.

Installation

IMINAR

PRE

Figure 3-7. Installing the Ceiling Mount Adapters/Projector Stands

Caution

DO NOT OVER-TIGHTEN THE SCREWS.

Runco SC-30d/SC-35d Installation/Operation Manual 31

Installation

Install Lens Motor: Position the AutoScope Lens Motor as shown in Figure 3-8. Line up the mounting holes on the lens motor housing with those on the underside of the projector. Secure the motor to the projector with the four remaining Pan-Head Phillips screws.

IMINAR

Figure 3-8. AutoScope Lens Motor Installation

After you have installed the AutoScope lens motor, proceed with Mounting the

PRE

SC-30d/SC-35d (page 34).

32 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

To install the fixed CineWide base plate on a SC-30d/SC-35d/CineWide:

1. Place the projector upside down on a blanket or other soft surface.

2. Place the CineWide base plate on the bottom of the projector.

3. If you are mounting the projector on a ceiling: Line up the three holes on the left and right mounting rails (included with the projector ceiling mount kit) with those on the bottom of the projector and CineWide base plate.

4. Secure the CineWide base plate (and ceiling mounting rails, if needed) to the projector with the Pan-Head Phillips screws provided with the CineWide lens base plate. See Figure 3-9.

1. Do not use the mounting screws provided with the ceiling mounting kit. Use only the hardware provided with the CineWide

lens base plate.

2. DO NOT OVER-TIGHTEN THE SCREWS.

Ceiling Mount Rails (part of Ceiling Mount Kit)

IMINAR

Screw, Phillips Pan-Head, 10-32 x 3/8” (8x)

Caution

Installing the Fixed CineWide Base Plate

Anamorphic Lens Base Plate

Figure 3-9. Projector with Cylindrical Lens Base Plate and Ceiling Mounting Rails

- Exploded View

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 33

Installation

➤

3.6 Mounting the SC-30d/SC-35d

Floor Mounting (Upright) In typical front and rear screen installations, the projector can be mounted to a secure and

Ceiling Mounting

(Inverted)

Installing the Projector in

an Enclosure

There are several methods for mounting the projector. Depending on your chosen installation, one method may be more suitable than another.

level surface such as a table or cart. Carts are useful when moving a projector during a presentation or from site to site. If possible, lock the wheels when it’s in position to prevent it from being moved during a presentation.

For fixed installations, and for those that want the projector out of sight or have a limited space for projector and audience, you can invert the SC-30d/SC-35d and suspend it from the ceiling using a specially-designed ceiling mount fixture.

Use only the Runco-approved ceiling mount kit designed for your

Note

For detailed installation instructions, refer to the documentation provided with the ceiling mount kit.

The projector can also be inverted and placed in an enclosure above and behind the viewing area. Install four feet on the inside bottom surface of the enclosure on which the projector can rest. A variety of materials can be used for this purpose (for example, rubber crutch tips or turntable feet).

projector.

IMINAR

Adjusting the Projection

Angle

PRE

If the SC-30d/SC-35d is ceiling-mounted and the screen is significantly lower than the projector, you can tilt the projector at a slight angle by adjusting the ceiling mount.

The projector can be rotated (side-to-side) up to 360 degrees and mounted without it affecting performance. However, to ensure optimal performance of the lamp, limit the front-to-back tilt of the projector to ±20 degrees; see Figure 3-10.

Figure 3-10. Mounting Angle Ranges (Front-to-Back and Side-to-Side)

If you do this, you may need to shift the image using the on-screen display (OSD) controls, to compensate. For detailed instructions, refer to Primary Lens Adjustments: Focus, Zoom and Position on page 51.

± 360º

± 20º

34 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

The Dimension Digital Controller unit can be placed on any flat, stable surface such as a shelf or table, or it can be rack-mounted using the supplied mounting hardware. Place it in a location that provides easy access to the power connectors.

The Dimension Digital Controller unit requires 2U (3.5 inches) or more of vertical rack space.

To mount the Dimension Digital Controller in a standard, 19-inch equipment rack, install the mounting ears on either side of the chassis using the supplied screws; see Figure 3-11. Then, secure the mounting ears to the rack.

IMINAR

3.7 Mounting the Dimension Digital Controller

PRE

Figure 3-11. Attaching the Rack Mounting Hardware

Runco SC-30d/SC-35d Installation/Operation Manual 35

Installation

➤

3.8 System Interconnections

Connector Panel Access To access the connector panel, pull firmly

Connecting the Dimension

Digital Controller to the

Projector

Proceed as follows to connect the SC-30d/SC-35d system components to each other and to AC power.

When connecting your equipment:

• Turn off all equipment before making any connections.

• Use the correct signal cables for each source.

• For best performance and to minimize cable clutter, use high-quality cables that are only as long as necessary to connect two devices. (Don’t use a 20-foot cable when a 6-foot cable will suffice.)

• Route all cables through the opening at the bottom of the projector.

• Ensure that the cables are securely connected. Tighten the thumbscrews on connectors that have them.

on the cable access cover to open it.

Digital Video Connection: Connect the HDMI Out To Pri. Display connector on the Dimension Digital Controller to the PRIMARY input on the projector. Similarly connect the

HDMI Out To Sec. Display connector on the Dimension Digital Controller to SECONDARY input on the projector.

RS-232 Connection: Connect the Pri. Display Control output from the Dimension Digital Controller to the RS232 input on the projector.

IMINAR

Use a standard, modular telephone cable with RJ11 plugs at both ends. On the projector end, use the provided RJ11-to-DB9 adapter. This adapter is wired as shown in Figure 3-12.

PRE

To/From

Dimension

Digital

Controller

1, 5, 6

6-position

RJ-11 Male

Figure 3-12. RS-232 Connection from the Dimension Digital Controller to the Projector

RCV DATA

XMT DATA

SIG GND

NO CONNECTION

XMT DATA

RCV DATA

RS232

1, 4, 6, 7, 8, 9

DB-9 Male

RS232

36 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

deo

HDMI 2

HDMI4HDMI

HDMI

Etherne

RIGGERS

3D SYNC

isplayPor

Note

between the SC-30d/SC-35d projector and the Dimension Digital Controller. However, display control using HDMI CEC control messages is also possible. For more information on this capability, please contact Runco Technical Support.

Figure 3-13 shows how to connect the Dimension Digital Controller to the projector.

Dimension Digital Controller

Pri. Display Control Sec. Display Control

Runco recommends using the RS-232 communication link

ec. Display Contro

HDMI Out

To Sec. Display

HDMI Out

DMI

Ethernet

Audio Only

Audio Onl

HDMI Out

To Pri. Display

DisplayPort

3D SYNC

HD2

TRIGGERS

123

Component / SCART

Component / SCA

Video 2

Video 1

Video 3

HDMI 2 HDMI 4 HDMI 6 HDMI 8

RS232

IMINAR

PRIMARY

SECONDARY

PRIMARY

3D Sync Out

SECONDARY

3D Sync Out

PRE

Figure 3-13. Connecting the Dimension Digital Controller to the Projector

Runco SC-30d/SC-35d Installation/Operation Manual 37

Installation

➤

Bo x

PC / C

RS-23

P 3

Etherne

Connecting an Audio

Processor or Secondary

Display Device to the

Dimension Digital

Controller (Optional)

The Dimension Digital Controller provides a second HDMI output (labeled HDMI Out (Audio Only)) for connection to an audio receiver/switching system or secondary display

device for monitoring purposes. See Figure 3-14.

The Dimension Digital Controller does not transmit HDMI CEC

Note

USB

HDMI 1

RS-23

To Accessory Box

ccessory

HDMI 3

control messages from the “HDMI Audio Out” connector.

ri. Display ControlSec. Display Control

RS-232

Pri. Display Control Sec. Display Control

HDMI 5

HDMI 7

HDMI Out

To Sec. Display

To Sec. Displa

RS-232

ontro

PC / Control

HDMI 2

HDMI 4

HDMI 6

HDMI 8

Ethernet

HDMI Out

Audio Only

HDMI Out

To Pri. Display

IMINAR

PRE

Figure 3-14. Audio Processor Connection to Dimension Digital Controller

Audio Processor/

Switcher

Secondary Display

38 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

l 5

HDMI 7

HDMI

The Dimension Digital Controller provides the following interfaces to external equipment that allow it to control or be controlled by that equipment:

• An RS-232 interface to a PC or control/automation system;

• Three (3), 12-volt trigger outputs;

• An infrared (IR) repeater input;

• An Ethernet network interface for serial command control (via Telnet), firmware updates and maintenance notifications.

The following sections describe how to make these interface connections.

RS-232 Controller Connection: Use a straight-through, 9-pin RS-232 cable to connect a PC or control/automation system (if present) to the RS-232 port on the Dimension Digital Controller; see Figure 3-15.

Pri. Display ControlSec. Display Contro

Pri. Display Control Sec. Display Control

DMI 5

DMI 6

HDMI 7

HDMI 8

Ethernet

therne

HDMI Out

DMI O

To Sec. Display

Sec. Display

HDMI Out

DMI O

Audio Only

Audio Onl

RS-232

PC / Control

HDMI Out

DMI O

To Pri. Display

To Pri. Displ

345

Additional Connections to the Dimension Digital Controller (Optional)

2 Receive Data

to Automation/

Control System

or PC

IMINAR

(none of the other pins are used)

(to ctrl. system)

3 Transmit Data

(from ctrl. system)

5 Ground

Figure 3-15. RS-232 Control System Connection to Dimension Digital Controller

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 39

Installation

deo

DMI1HDMI

RS-2

HD1

HD2

Connecting 12-volt Trigger Outputs to External Equipment: If your SC-30d/SC-35d is equipped with an anamorphic lens, connect the +12V Trigger Input on the lens transport to a 12-volt trigger output on the Dimension Digital Controller; see Figure 3-16.

Similarly connect other 12-volt trigger-activated equipment (such as retractable screens or screen masks) to the other trigger outputs.

AutoScope Lens Motor

Power Switch

3.5-mm mini plug

Retractable Screen or other 12-volt trigger-activated device

IMINAR

PRE

Figure 3-16. Connecting 12-volt Trigger Outputs

AC Input

Sleeve = Ground

Tip = +12V

D SYNC

D SYN

HD1

HD2

TRIGGERS

123

Component / SCART

omponent / SCA

Video 1

Video 2

Video 3

USB

HDMI 1

HDMI 2

To Acces

HDMI

RS-

cces

40 Runco SC-30d/SC-35d Installation/Operation Manual

Connecting an External IR Receiver to the Dimension Digital Controller: If infrared

HDMI

Etherne

signals from the remote control cannot reach the Dimension Digital Controller due to excessive distance or obstructions such as walls or cabinet doors, you can connect an external IR receiver to extend the range of the remote control. See Figure 3-17.

Installation

Remote Control

(3.5-mm, mini

phono plug)

ri. Display Control Sec. Display Control

ri. Display ControlSec. Display Contro

HDMI 7

MI 5

MI 6

HDMI 8

Ethernet

IR Sensor

To Sec. Display

HDMI Ou

HDMI

ec. Displ

DMI Ou

HDMI Out

udio Onl

Audio Only

IR Repeater

RS-232

RS-23

HDMI

HDMI Out

oPri. Disp

To Pri. Display

Figure 3-17. External IR Receiver Connection

IMINAR

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 41

Installation

PC / C

HDMI

Pri. Displa

Audio Only

Ethernet Network Connection: Use a standard, Category 5 network cable with an RJ-45 plug to connect a network hub, router or gateway to the Ethernet port on the Dimension Digital Controller; see Figure 3-18.

ontrol Sec. Display Control

ontrolSec. Display Contro

HDMI 7

HDMI 8

Ethernet

HDMI Out

DMI O

Sec. Displ

To Sec. Display

DMI

HDMI Out Audio Only

RS-232

RS-2

PC / Control

ontr

DMI O

HDMI Out

To Pri. Display

to Ethernet

Hub, Router

or Gateway

Figure 3-18. Ethernet Network Connection to Dimension Digital Controller

IMINAR

PRE

1 Transmit Data + 2 Transmit Data 3 Receive Data + 6 Receive Data -

42 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

Comp

Connect your video sources to the Dimension Digital Controller as shown and described in the sections that follow.

DisplayPort Source Connection: See Figure 3-19.

TRIGGERS

RIGGER

12 3

onent / SCAR

Component / SCART

Video

Video 1

Video 2

deo

Video 3

USB

HDMI 1

HDMI 2

RS-232

RS-23

To Accessory

ccessory

HDMI

HDMI 3

HDMI 4

DisplayPort

3D SYNC

3D SYN

HD1

HD2

Connecting Source Components to the Dimension Digital Controller

Figure 3-19. DisplayPort Source Connection

PRE

IMINAR

Notebook Computer

or Other DisplayPort Source

Runco SC-30d/SC-35d Installation/Operation Manual 43

Installation

deo

PC / C

RS-232

HDMI Source Connections: See Figure 3-20.

Use the HDMI inputs whenever possible. This ensures the highest

Tip

video quality because the signal is carried in the digital domain throughout the entire signal path, from source component output into the projector.

You can also connect computers with DVI output to these inputs.

Note

Refer to Supported Timings on page 134 for a list of compatible input signals.

USB

Video 2

Video 3

HDMI 1

HDMI 2

IMINAR

PRE

HDMI

AV OUT

RS-232

To Accessory Bo

o Accessory B

HDMI 3

HDMI 4

ri. Display Contro

Pri. Display Control Sec. Display Control

HDMI 5

HDMI 6

ec. Display Contro

HDMI 7

HDMI 8

Ethernet

therne

HDMI Out

HDMI

ToSec. Displa

To Sec. Display

HDMI Ou

HDMI Out

Audio Onl

Audio Only

RS-232

ontr

PC / Contro

HDMI

Pri.

To Pri. D

HDMI source

(BD, DVD, DTV Set-Top Box etc.)

Figure 3-20. HDMI Source Connections

44 Runco SC-30d/SC-35d Installation/Operation Manual

Component Video Source Connections: Connect your component video sources to

deo

HDMI 23HDMI

RIGGERS

3D SYNC

isplayPor

the HD1, HD2 and/or Component/SCART inputs as shown in Figure 3-21.

Installation

DisplayPor

3D SYNC

HD1

HD2

TRIGGERS

123

Component / SCART

Video 1

Video 2

Video 3

deo

IMINAR

USB

HDMI 1

HDMI 2

RS-232

To Accessory Box

oAccessory Bo

HDMI 3

HDMI 4

COMPONEN T VIDEO OUT

Y PB PR

PRE

DTV-Set-Top Box

BD/DVD

(DTV-STB)

Figure 3-21. Component Video Source Connections

Runco SC-30d/SC-35d Installation/Operation Manual 45

Installation

deo

RIGGERS

3D SYNC

isplayPor

RGBHV Source Connections: Connect personal computers and/or other RGB sources to the HD1 and/or HD2 inputs as shown in Figure 3-22.

TRIGGERS

123

Component / SCART

Component / SCAR

Video 1

DisplayPor

3D SYNC

HD1

HD2

Computer

IMINAR

RGB Camcorder

Video 2

Video 3

Video

Figure 3-22. RGBHV Source Connections

PRE

46 Runco SC-30d/SC-35d Installation/Operation Manual

SCART RGBS Source Connections: Connect the green, blue and red outputs from

deo

isplayPor

3D SYNC

your SCART source to the Component/SCART input on the Dimension Digital Controller. Connect the sync output from your SCART source to the Video 1 input on the Dimension Digital Controller. See Figure 3-23.

RIGGER

3D SYNC

TRIGGERS

123

Installation

VCR

DVD/DTV STB

Gaming Console

SCART-to-RGBS

adapter

DisplayPor

Green

Component / SCART

Blue

Video 1

Red

Video 2

deo

Video 3

Sync

HD1

HD2

IMINAR

Green

Blue

Red

Sync

PRE

Figure 3-23. SCART RGBS Source Connections

Runco SC-30d/SC-35d Installation/Operation Manual 47

Installation

DMI

RIGGERS

isplayPor

Composite Source Connections: See Figure 3-24.

VCR

Camcorder

IMINAR

Gaming Console

DisplayPor

Composite

3D SYNC

HD1

HD2

TRIGGERS

123

Component / SCART

Video 1

Video 2

Video 3

Composite

USB

HDMI 1

HDMI 2

PRE

Figure 3-24. Composite Video Source Connections

48 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

deo

isplayPor

Connect the 3D SYNC IN port on the emitter to the 3D SYNC connector on the Dimension Digital Controller, as shown in Figure 3-25.

Secure the emitter in the desired location using double-sided tape or

Tip

a similar adhesive material.

Active 3D Emitter

SYNC IN

TRIGGERS

3D SYNC

HD1

RIGGER

123

Component / SCART

Component / SCAR

Video 1

Video 2

USB

Connecting the Active 3D Emitter to the Dimension Digital Controller

IMINAR

DisplayPort

Figure 3-25. Active 3D Emitter Connection

the AC receptacle on the rear of the SC-30d/SC-35d (AC 100V ~ 240V). Then, connect the other end to your AC power source.

PRE

Similarly connect the Dimension Digital Controller to a nearby AC outlet.

AutoScope Lens Motor: With AutoScope-equipped projectors, an additional power cord is provided for the lens motor. Plug the female end of the AC power cord into the AC input on the rear of the lens motor assembly. Connect the other end to a 110 VAC power source.

Video 3

HDMI

HDMI 2

Connecting to AC PowerProjector/Dimension Digital Controller: Plug the female end of one power cord into

Runco SC-30d/SC-35d Installation/Operation Manual 49

Installation

3.9

Turning on the Power

1. Power up your source components.

2. If this is an AutoScope-equipped projector, turn on the main power switch at the rear of the AutoScope lens motor. The lens motor power switch is located next to the AC input (see Figure 3-16).

3. Turn on the main power switch at the rear of the Dimension Digital Controller.

4. Press the ON button on the remote control (or the ON/STANDBY ( ) button on the Dimension Digital Controller front panel) to turn on the system. The vacuum fluorescent display on the Dimension Digital Controller front panel briefly displays “Initializing System,” followed by “Starting SC-30d/SC-35d.”

5. When the display is ready for use, the fluorescent display indicates the active source, input resolution/frame rate and aspect ratio/screen; for example:

Current

Source

SC-30d/SC-35d

HDMI 1

16:9/1 1080i/60

Aspect Ratio/Screen

6. When the projector is turned on, the Active 3D Emitter turns on as well. The LEDs display a red moving pattern while the emitter attempts to acquire a 3D signal and until a signal is found.

IMINAR

1080p/60

Input Resolution/Frame Rate

If the emitter searches for a signal for longer than 60 seconds, a signal is assumed to not be present.

Searching for 3D Sync Signal 3D Sync Signal Found

PRE

7. Upon finding a 3D signal, all LEDs turn blue. Once the LEDs indicate a 3D signal, the 3D glasses can be used to experience 3D. For more information on using the Active 3D Glasses, refer to Using the 3D Glasses on page 98.

50 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

Lens zoom and focus are motorized adjustments that are adjustable using the remote control (Figure 2-6). This allows you to adjust the focus and image size while at the screen for more accurate results.

To access the motorized lens controls:

1. On the Dimension Digital Controller remote control or front panel, press MENU.

2. Select Service from the Main Menu and enter the Service Menu passcode.

You must enter a passcode to access the Service menu.

Note

3. Select Display Device from the Service Menu.

4. Select Configure from the Display Device menu, then select Lens.

The Lens menu controls operate as described below.

press and hold the ENTER button.

(-). Then, press and hold the ENTER button.

To enlarge the picture (zoom in), use the cursor buttons to highlight the plus sign (+). Then, press and hold the ENTER button.

IMINAR

To change the projected image position, use the lens adjustment tool provided with the SC-30d/SC-35d to shift the lens in the desired direction; see Figure 3-26. The vertical lens shift control is at the top of the projector; the horizontal lens shift control is on the side of the projector farthest from the Runco logo.

3.10 Primary Lens Adjustments: Focus, Zoom and Position

FocusTo focus the projected image, use the cursor buttons to highlight “In” or “Out.” Then,

ZoomTo make the picture smaller (zoom out), use the cursor buttons to highlight the minus sign

Vertical and Horizontal Lens Shift

ertical Lens Shift

PRE

Horizontal Lens Shift

Figure 3-26. Vertical and Horizontal Lens Shift Adjustments

Runco SC-30d/SC-35d Installation/Operation Manual 51

Installation

3.11 Adjusting the Picture Orientation

By default, the SC-30d/SC-35d is configured for a “floor/front” installation, in which the projector is installed upright and in front of the screen. If it is installed behind the screen and/or mounted on a ceiling, you must change the picture orientation. To do this:

1. On the Dimension Digital Controller remote control or front panel, press MENU.

2. Select Service from the Main Menu and enter the Service Menu passcode.

Note

3. Select Display Device from the Service Menu.

4. Select Configure from the Display Device menu, then select Installation.

5. Select Orientation, then choose Floor/Rear, Ceiling/Front or Ceiling/Rear, to match the installation method.

You must enter a passcode to access the Service menu.

IMINAR

PRE

52 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

Projector and/or screen placement — among other things — can cause geometric distortion in the projected image.

To correct this, the Dimension Digital Controller provides precise, nine-point control over the projected image geometry. Use these controls as (and only if) needed to re-position the image corners, mid-points and center to eliminate “keystoning” (mis-aligned corners) or “pincushion” distortion (mid-points not aligned with corners). See Figure 3-27.

Horizontal Keystoning

Vertical Keystoning

IMINAR

3.12 Adjusting the Image Geometry

PRE

Pincushion Distortion

Figure 3-27. Keystone and Pincushion Distortion

Runco SC-30d/SC-35d Installation/Operation Manual 53

Installation

“Keystoning” usually occurs when the projector is tilted relative to the screen. “Pincushion” distortion can sometimes occur if the throw distance is very short and/or the projector is equipped with an anamorphic lens.

To correct keystoning or pincushion distortion:

1. On the Dimension Digital Controller remote control or front panel, press MENU.

2. Select Calibration from the Main Menu and enter the Calibration Menu passcode.

You must enter a passcode to access the Calibration menu.

Note

3. Select Image Alignment from the Calibration Menu.

4. Select Corner Alignment to correct a “keystoned” image by adjusting the image corner positions. Select Midpoint Alignment to correct pincushion distortion by adjusting the image edge mid-points. See Figure 3-28.

Use the built-in test pattern when adjusting the image corners or

Tip

midpoints. To access it, check the Test Pattern box in the Corner Alignment or Midpoint Alignment menu.

Top Left (x, y)

IMINAR

Left

Middle (x)

Left/Right

Middle (y)

PRE

Bottom Left (x, y)

Notes:

1. Smaller “x” values move a point to the left; larger values move it to the right.

2. Smaller “y” values move a point up; larger values move it down.

Figure 3-28. Image Alignment Controls

Top/Bottom Middle (x)

Top Middle (y)

Center

(x, y)

Bottom Middle (y)

Top Right (x, y)

Bottom Right (x, y)

Right Middl (x)

54 Runco SC-30d/SC-35d Installation/Operation Manual

Installation

If you are installing an SC-30d/SC-35d/CineWide or SC-30d/SC-35d/CineWide with AutoScope, proceed as follows to install and adjust the secondary anamorphic lens.

Note

The Cylindrical Anamorphic lens mount kit consists of everything shown in Figure 3-29. Some components shipped with your projector may differ slightly from what is shown in these instructions. If any items are missing or damaged, please contact your Runco dealer or Runco Customer Service at (800) 23-RUNCO.

It is extremely important that the primary lens is properly adjusted before you install the anamorphic lens. Ensure that the image from the primary lens is perfectly centered on the screen.

Pitch Adjustment

T-Nut (2x)

Pitch Adjustment Yoke

for Lens

Anamorphic Lens

IMINAR

Set Screw

3.13 Installing and Adjusting the CineWide Anamorphic Lens

Cylindrical Anamorphic Lens Installation and Adjustment

1/4-20

Hex Bolt (2x) and Washer (2x)

PRE

Height/Y-Adjustment

T-Screw and Washer (2x)

Pitch Adjustment

T-Screw and Washer (2x)

Anamorphic Lens

Holder

AutoScope

Carriage Plate (or Fixed CineWide Base Plate)

Yaw/X Adjustment

Lever and Washer(2x)

Figure 3-29. Cylindrical Anamorphic Lens Mounting Assembly - Exploded View

Runco SC-30d/SC-35d Installation/Operation Manual 55

Installation

Attach Lens Mounting Assembly to Lens Motor Carriage Plate:

1. Remove the two Yaw/X Adjustment Levers and Washers (8) from the bottom of the Anamorphic Lens Holder (6).

2. Place the Anamorphic Lens Holder on top of the AutoScope Carriage Plate or Fixed CineWide Base Plate (7). Position the bracket so that the long slot at the bottom of the lens holder is perpendicular to the corresponding slots on the plate.

3. Secure the Anamorphic Lens Holder to the plate using the Hex Bolts/Washers (9) and Yaw/X Adjustment Levers that you removed in Step 1.

4. Use the Height/Y Adjustment T-Screws/Washers (4), Pitch Adjustment T-Screws/Washers (5) and T-Nuts (1) to attach the Pitch Adjustment Yoke and Lens Adapter Ring to the Anamorphic Lens Holder. The Yoke should be as close to the

primary lens as possible.

5. Attach the lens to the Lens Adapter Ring by threading it clockwise.

Lens threads into ring

IMINAR

PRE

Figure 3-30. Attaching the Anamorphic Lens to the Lens Ring

56 Runco SC-30d/SC-35d Installation/Operation Manual

Configure Lens Motor Trigger on Dimension Digital Controller: The anamorphic lens solution for the SC-30d/SC-35d maintains constant image height independent of the aspect ratio, while using the full display resolution of the projector. It accomplishes this by moving the anamorphic lens in front of the primary lens when widescreen material is being viewed. When the viewer transitions back to 16:9 or 4:3 source material, the anamorphic lens moves out of the light path.

Proceed as follows to configure the 12-volt trigger output for proper operation.

1. Project a 2.35:1 aspect ratio test pattern or other image on the screen.

2. On the Dimension Digital Controller remote control or front panel, press MENU.

3. Select Service from the Main Menu and enter the Service Menu passcode.

Installation

You must enter a passcode to access the Service menu for the first

Note

4. Select Tri gg er s from the Service menu.

5. Assign the trigger output to which the lens motor is connected to the Cinema and Virtual Cinema aspect ratios. This enables the lens motor to move the anamorphic lens into position (in front of the primary lens) when either aspect ratio is selected.

6. Select the Cinema aspect ratio to move the anamorphic lens into position, if it isn’t already. To do this, press CINEMA on the Dimension Digital Controller remote control (Figure 2-6), or press or repeatedly with no menus visible on-screen.

7. Proceed as described in the following sections to adjust the anamorphic lens.

Horizontal Position (X) Adjustment:

1. Project a white field on the screen.

2. Loosen the Yaw/X-Adjustment Levers underneath the lens.

3. Slowly move the anamorphic lens into place (from right to left or vice versa) so that there are no shadows on either side of the screen:

time after turning on the system.

IMINAR

PRE

Too Far Left

Correct position

Too Far Right

4. When the horizontal position is properly set, tighten the Yaw/X-Adjustment Levers to secure the lens in place.

Runco SC-30d/SC-35d Installation/Operation Manual 57

Installation

Adjusting the Height (Y): With the white field still on-screen, loosen the Height/Y Adjustment T-Screws on either side of the lens. Then, slowly move the anamorphic lens into place so that there are no shadows on the top or bottom of the screen:

Too Low

Correct position

Too High

When the height is properly set, tighten the Height Adjustment T-Screws to secure the lens in place.

Adjusting the Pitch (Angle): Next, angle the lens to even out any top-to-bottom pincushion distortion. To do this, loosen the Pitch Adjustment T-Screws (directly below the Height/Y Adjustment T-Screws) on either side of the lens to allow it to pivot freely. Then, adjust the anamorphic lens angle so that the projected image is rectangular:

IMINAR

PRE

Incorrect Lens Angle

The anamorphic lens will almost always be angled with respect to the projector; this is normal.

Once the proper lens angle has been set, firmly tighten the Pitch Adjustment T-Screws to secure the lens in place.

Correct Lens Angle

Note

There may be some pincushion distortion even after the lens is properly adjusted, especially at shorter throw distances. If this is the case, Runco recommends that you slightly over-scan the image into the screen frame area to mask the distortion.

58 Runco SC-30d/SC-35d Installation/Operation Manual

Yaw Adjust: Loosen the Yaw/X-Adjustment Levers to allow the lens to pivot freely from side to side. Then, angle the lens to even out any left-to-right pincushion distortion:

Anamorphic Lens (Top View)

Once the proper lens angle has been set, firmly tighten the Yaw/X-Adjustment Levers to secure the lens in place.

Geometry:

1. Unscrew the Anamorphic Lens just enough to allow it to rotate freely.

Installation

2. Grasp the lens by the center ring and rotate the lens until the image is properly anamorphic:

IMINAR

Wrong Position Correct Position

3. When the image geometry appears correct, tighten the Anamorphic Lens Set Screw (3) to secure the lens in place. (When viewed from the front, the rear opening on the anamorphic lens should appear as a tall, narrow oval.)

Focus: Finally, rotate the Focus Ring on the anamorphic lens to fine-tune the optical focus.

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 59

Installation

Notes:

IMINAR

PRE

60 Runco SC-30d/SC-35d Installation/Operation Manual

Operation

4. Operation

To display the Main Menu, press the MENU button on the remote control or Dimension Digital Controller front panel (Figure 2-4).

To select a menu item, use the and buttons on the remote control or Dimension Digital Controller front panel to highlight it. Then, to confirm your selection, press ENTER on the remote control or Dimension Digital Controller front panel.

The SC-30d/SC-35d OSD menus are arranged hierarchically, as shown in Figure 4-1. Some menu options apply only to certain input signal types. For example, Phase and Tracking can only be adjusted for RGB, Component video or SCART signals.

Composite 1 HDMI 1 Composite 2 HDMI 2 Composite 3 HDMI 3

Input Source

Aspect Ratio

Screen


Input Position

Memory Presets

3D Processing

Sleep Timer

Information

Component HDMI 4 HD 1 HDMI 5 HD 2 HDMI 6 SCART HDMI 7 DisplayPort HDMI 8 16:9 4:3 Letterbox VirtualWide Cinema Virtual Cinema Native Auto Cinema

Screen 1 / Screen 2 Brightness

Contrast Color Tint Sharpness Noise Filter Left/Right Up/Down Width Height Overscan Overscan Mode

(Zoom/Crop) Phase

(RGB/Component/SCART signals only) Tracking

(RGB/Component/SCART signals only) Recall ISF Night or ISF Day Recall/Save Custom 1 or Custom 2 Reset Custom 1 and Custom 2 to Factory

Default 3D Mode

(Auto, Off, Side-by-Side, Top-and-Bottom or Frame Packing)

Reverse Eyes (On/Off)

Off, 30 Minutes, 60 Minutes, 90 Minutes, 2 Hours or 4 Hours

Signal System Network Field Service Manufacturing

PRE

Display Color Common Settings

Display Color -

IMINAR

Calibration

Note: Default settings appear in bold type. Settings marked with an asterisk (*) apply to 2D content only.

Projector Settings

Input Image

Input Color

Save ISF Night Save ISF Day

Copy/Paste

Output Shift

Image Alignment

Adjustment Mode Both, Primary or Secondary

Splash Configure

OSD Position Hor. / Ver. 0, 1, 2 ... 100

Gain Offset

Gamma

Color Temp Simple (5500K, 6500K, 7500K or 9300K) Color Gamut* Auto, REC709, SMPTE-C, EBU, Native or PCE

PCE*

Lamp Power (230W or 260W) ConstantContrast*

(SC-30d only) Brightness Contrast Color Tint Sharpness Gain Offset

Chroma Delay

Noise Filter 0, 1, 2 ... 63

Back / Confirm

Memory Preset

Aspect Ratio

Left/Right Up/Down Width Height

Screen Masking

Corner Alignment

Midpoint Alignment

Owner Name ISF Calibrated ISF Other Splash Timer 5, 6, 7 ... 15 Splash Enable On/Off

4.1 Using the On-Screen Menus

-100, -99... 0 ... 99, 100 (Red, Green, Blue)

Mode (Simple / Advanced)

Simple (1.8, 2.0, 2.2, 2.35, 2.5)

Advanced (0 (2.2 gamma curve), 1, 2, 3 ... 20 (custom gamma tables))

Red x, y / Green x, y / Blue x, y / White x, y Yellow x, y / Cyan x, y / Magenta x, y

On / Off

-50, -49 ... 0 ... 49, 50

-32, -31... 0 ... 31, 32 (HD 1, HD 2 and Component inputs only)

0, 1, 2 ... 7 (Composite inputs only)

Copy Settings Paste Settings Copy Settings Paste Settings

-50, -49 ... 0 ... 49, 50

-50, -49, 48 ... 0

0, 1, 2 ... 100 (Top / Bottom / Left / Right / Test Pattern Enable)

Top Left / Top Right / Bottom Left / Bottom Right / Test Pattern Enable

Center / Top Middle / Left Middle / Right Middle / Bottom Middle / Test Pattern Enable

... 59, 60

Figure 4-1. SC-30d/SC-35d OSD Menu Structure

Runco SC-30d/SC-35d Installation/Operation Manual 61

Operation

Service

Color Bars 1 Color Bars 2 Focus

Test Video

Input Names Rename/Restore

Remote Control

Display Device - Configure

Network

Color Space

Triggers 1 / 2 / 3

Miscellaneous

PRE

HDMI

Front Panel Brightness

Auto Power Off

Standby Mode Low Power / Fast Startup System Reset

Grey Bars Full White Primary / Secondary / Dual

Alignment 3D

Remote Code

SRC 1-7 Keys SRC 8-14 Keys Installation -

Picture Orientation

Lens

Display Info. (read-only)

Lamp Hours Reset Yes / No Diagnostics White, Red, Green, Blue, Yellow, Cyan, Magenta Altitude Auto / High Display 3D Settings (n/a)

Internal 3D Settings

24Hz 3D Mode 120 Hz 6:4 or 120 Hz 5:5

IP Configuration

Auto Firmware Upgrade

E-Mail Notification

Remote Network Control On / Off Auto, REC601, REC709,

RGB-PC or RGB-Video

Language

OSD Timer 0 (no timeout) or 5, 6, 7 ... 30 ... 60 sec. OSD Messages On / Off Blank Screen Color Sidebar Color Film Mode

(SD sources only) CUE

(Chroma Upsampling Error)

Sync Threshold

HDMI EDID Extension On / Off (per HDMI and DisplayPort input)

Audio Format

CEC On / Off HPD Toggle Rejection Logo LED 0 (off), 1, 2 ... 31 Standby LED On / Off LCD 0 (off), 1, 2, 3 or 4 Enable On / Off / No Signal Hours 1, 2, 3, 4, ... 23, 24

IMINAR

00000 ... 08209 ... 65535 or 88999 (extended mode)

(select a key, then choose a source to assign to it)

Auto, Floor Front, Ceiling Front, Floor Rear or Ceiling Rear

Focus Zoom Projector Serial Number

Lamp Hours

Sync Delay Test Pattern Enable

DHCP (On / Off), IP Address, Subnet Mask, Default Gateway, Communication Test

Auto Check for New Firmware, Auto Perform Upgrade, Check for New Firmware

E-Mail Address, Error Notification, Error Notification to Runco, Periodic Service Notification, Lamp Life Notification, Customer Information, E-Mail Calibration Data

(Not available on Composite 1, Composite 2 or Composite 3 inputs)

English, Français, Deutsch, Italiano, Español, Svenska, (Simplified Chinese), (Traditional Chinese), Português, (Russian), (Japanese) or (Korean)

Red/Green/Blue = 0, 1, 2, 3 ... 255

On / Off

0, 1, 2 ... 15 (HD 1, HD 2 and Component inputs only)

Combined / HDMI Out (Pri. Display) / HDMI Out (Sec. Display) / HDMI Out (Audio Only)

Auto / On / Off

Figure 4-1. SC-30d/SC-35d OSD Menu Structure (continued)

62 Runco SC-30d/SC-35d Installation/Operation Manual

functions.

(You must enter a passcode to access the Calibration and Service menus.)

Operation

Main MenuThe Main Menu is the starting point for accessing all Dimension Digital Controller

Runco Video

Input Source Aspect Ratio Screen Picture Input Position Memory Presets 3D Processing Sleep Timer Information Calibration Service

Input SourceFrom the Main Menu, select Input Source to choose a video signal source.

The active source is indicated by an arrow (Î) to its left; in this example, Composite is the active source.

IMINAR

PRE

Input Source

Composite 1 Composite 2 Composite 3 Component HD 1 HD 2 SCART HDMI 1 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI 6 HDMI 7 HDMI 8 DisplayPort

Runco SC-30d/SC-35d Installation/Operation Manual 63

Operation

➤

7       

Aspect Ratio To change the aspect ratio (size and shape) of the projected image, select Aspect Ratio

Aspect Ratio

16:9 4:3 Letterbox VirtualWide Cinema Virtual Cinema Native Auto Cinema

from the Main Menu and press ENTER. Select the appropriate aspect ratio for your screen size and the type of program material being viewed; refer to Table 4-1.

The currently-selected aspect ratio is indicated by a “ selected.

Note that some aspect ratios are unavailable and/or not useful with certain types of source material. The optimal setting depends on a number of factors, such as:

• The aspect ratio of the source material, as broadcast or encoded on the playback medium.

• The “display type” (16:9 or 4:3) and output resolution settings at the source component. Most modern DVD/BD players and set-top boxes have such controls.

• Viewer preference (original aspect ratio with “black bars,” or a full-screen presentation with some distortion or cropping).

The aspect ratio selection is automatically saved for each input and

Note

resolution.

7” to its left; in this example, 16:9 is

Table 4-1. Aspect Ratio Settings

Aspect Ratio

IMINAR

16:9 16:9 Select 16:9 to view 16:9 DVDs

PRE

4:3 4:3 Standard 4:3 scales the input

Remote Control

Key

16:9 Image on

16:9 Screen (Display)

4:3 Image, stretched to fill

16:9 Screen (Display)

4:3 Image on

16:9 Screen (Display)

Description

and HDTV programs in their native aspect ratio.

4:3 images are stretched horizontally to fit a 16:9 screen.

signal to fit in the center of the 16:9 screen. 4:3 is the aspect ratio used by computer monitors, standard television programming and most VHS video cassettes.

64 Runco SC-30d/SC-35d Installation/Operation Manual

Table 4-1. Aspect Ratio Settings (continued)

Remote

Aspect Ratio

Control

Key

Description

Operation

Letterbox LET

BOX

4:3 Image on

16:9 Display

(Letterbox aspect ratio)

VirtualWide V-WIDE VirtualWide scales a 4:3 image

4:3 Image on

16:9 Screen (Display)

4:3 Image on

16:9 Screen

with VirtualWide

4:3 Image on

2.35:1 Screen

with VirtualWide

Letterbox mode scales (zooms in on) a 4:3 image linearly (by the same amount on all sides) to fill a 16:9 display. Letterbox is best suited for viewing LaserDisc movies or “full-screen” DVDs on a 16:9 screen.

NON-linearly (more on the sides than in the center) to fit a 16:9 screen.

On a 2.35:1 screen, the image is

IMINAR

centered between black bars on either side.

Cinema CINEMA Select Cinema to view 2.35

source material in its native aspect ratio.

PRE

2.35:1 Image on 16:9 Screen

(Cinema aspect ratio / no CineWide)

2.35:1 Image on

2.35:1 Screen

Cinema aspect ratio / CineWide)

(

Runco SC-30d/SC-35d Installation/Operation Manual 65

With a 16:9 screen and a standard SC-30d/SC-35d (without an anamorphic lens), the upper and lower portions of the screen are masked, but the geometry of the active image area is unchanged.

With a 2.35:1 screen and an anamorphic lens, the Dimension Digital Controller scales the

2.35:1 image so that the active image area fills the 16:9 chip surface, eliminating the black bars. The secondary, anamorphic lens then restores the proper geometry to the

2.35:1 image.

Operation

➤

Table 4-1. Aspect Ratio Settings (continued)

Remote

Aspect Ratio

Virtual Cinema V-CINE A 16:9 image is scaled

Native NATIVE Select Native to display the

Control

Key

16:9 Image on

2.35:1 Screen

16:9 Image on

2.35:1 Screen with Virtual Cinema

1080i HDTV Image

Description

NON-linearly (more on the sides than in the center) to fit a 2.35:1 screen.

source signal in its native resolution, centered in the display area with no re-sizing or overscan.

Screen 1 Screen 2

Screen

This means, for example, that 720p HDTV programs will

IMINAR

Auto Cinema -- Select Auto Cinema to have the Dimension Digital Controller apply

PRE

Screen The Screen Menu allows you to recall multiple sets of stored values for certain controls

(Output Shift, Image Alignment and Screen Masking) that are saved for each aspect ratio. Such settings are also saved “per screen.” To recall the Output Shift and Image Alignment settings associated with “Screen 1” or “Screen 2,” make that selection here.

the Cinema aspect ratio to 2.35:1 source material automatically, when detected. To all other content, Auto Cinema applies the 16:9 aspect ratio.

720p HDTV Image

display with unused pixels on all sides: 320 on the left and right sides and 180 above and below.

With SDTV and EDTV sources, the Dimension Digital Controller scales the image horizontally to achieve a 16:9 aspect ratio.

66 Runco SC-30d/SC-35d Installation/Operation Manual

achieve optimum picture quality.

The Dimension Digital Controller has been designed to incorporate setup and calibration standards established by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted, industry-recognized standards for optimal video performance and has implemented a training program for technicians and installers to use these standards to obtain optimal picture quality from Runco video display devices. Accordingly, Runco recommends that setup and calibration be performed by an ISF certified installation technician.

All signal types require separate processing. Therefore, you need to calibrate each Dimension Digital Controller input separately.

Operation

PictureUse the controls in the Picture Menu to calibrate each Dimension Digital Controller input to


Brightness Contrast Color Tint Sharpness Noise Filter

Note

Although it may be possible to obtain satisfactory picture quality using the naked eye and regular program material, Runco recommends using an external test pattern source (Ovation Multimedia, Digital Video Essentials or AVIA test DVD or equivalent) for best results.

Connect your test pattern source to the input that you are calibrating and proceed as follows. Perform the adjustments in the order listed here.

1. When you change a picture quality setting, save the change to a preset afterwards. Otherwise, the change will be lost when a different input is selected. (Picture quality settings are saved for each input and display mode separately.) For information about saving settings, refer to Memory Presets on page 74.

2. For best results, Runco recommends that you set ConstantContrast (available only on the SC-30d) to Off before adjusting Brightness, Contrast and other image quality settings in this menu (refer to ConstantContrast (SC-30d only) on page 82). After you have completed the initial calibration, set ConstantContrast to On if desired.

IMINAR

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 67

Operation

Brightness: On your external test pattern source, select a PLUGE pattern. (PLUGE is an acronym for “Picture Line-Up Generation Equipment.”) Figure 4-2 shows a typical PLUGE pattern.

Below Black

bove Black

Figure 4-2. Typical PLUGE Pattern for Adjusting Brightness

PLUGE patterns vary but generally consist of some combination of black, white and gray areas against a black background. The example above includes two vertical bars and four shaded boxes.

Select Brightness from the Picture menu and press ENTER. Adjust the brightness so that:

• The darkest black bars disappear into the background.

• The dark gray areas are barely visible.

• The lighter gray areas are clearly visible.

• The white areas are a comfortable level of true white.

• The image contains only black, gray and white (no color).

Contrast: On your external test pattern source, select a stepped, gray-bar pattern like the one shown in Figure 4-3.

IMINAR

PRE

Figure 4-3. Typical Gray Bar Pattern for Adjusting Contrast

Select Contrast and press ENTER. Adjust the contrast to a point just below which the white rectangle starts to increase in size.

Note

Brightness and contrast controls are interactive. A change to one may require a subtle change to the other in order to achieve the optimum setting.

68 Runco SC-30d/SC-35d Installation/Operation Manual

Color Saturation: On your external test pattern source, select a color bar pattern like the one shown in Figure 4-4.

Operation

gray

Figure 4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint

1. Press the MENU button on the remote control or Dimension Digital Controller front panel.

2. Select Service from the Main Menu and press ENTER.

3. Enter the Service menu passcode.

4. Select Display Device from the Service menu and press ENTER.

5. Press ENTER again to select Configure.

6. Select Diagnostics and press ENTER.

7. Select Blue from the Diagnostics menu, then press ENTER to display only the blue color channel.

8. Press EXIT (or MENU) repeatedly to return to the Main Menu.

yellow

cyan

green

magenta

red

blue

IMINAR

PRE

9. Select Picture from the Main Menu and press ENTER.

10.Select Color from the Picture menu and press ENTER.

Runco SC-30d/SC-35d Installation/Operation Manual 69

Operation

11.Adjust the color saturation level until the outermost (gray and blue) color bars appear to be a single shade of blue:

gray

yellow

cyan

green

red

magenta

blue

Tint: Tint or “hue” is essentially the ratio of red to green in the color portion of the image. When tint is decreased, the image appears redder; when it is increased the image appears greener.

To adjust the tint, enable “blue only” display mode in the Diagnostics menu, as you would for adjusting color saturation (refer to the previous section, Color Saturation).

Select Tint from the Picture menu and press ENTER. Adjust the tint level until the cyan and magenta color bars (on either side of the green bar) appear to be a single shade of blue.

Note

IMINAR

Like the brightness and contrast controls, the color and tint controls are interactive. A change to one may require a subtle change to the other in order to achieve the optimum setting.

PRE

70 Runco SC-30d/SC-35d Installation/Operation Manual

Sharpness: “Sharpness” is the amount of high-frequency detail in the image. To adjust sharpness, select Sharpness from the Picture menu and press ENTER. On your external test pattern source, select a pattern like the one shown in Figure 4-5. Adjust as needed, looking for white edges around the transitions from black to gray and differently-sized lines in the “sweep” patterns at the top and bottom. Lower the sharpness setting to eliminate them.

Operation

IMINAR

Figure 4-5. Typical Test Pattern for Adjusting Sharpness

Noise Filter: To apply noise filtering to the input signal, select Noise Filter from the Picture

menu. The Noise Filter is useful for clearing up noisy images from 480i video sources.

Use the left- or right-arrow buttons to select the desired amount of noise reduction, keeping in mind that higher settings (which reduce high frequencies) may also “soften” the image.

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 71

Operation

➤

Input Position

Left/Right Up/Down Width Height Overscan Overscan Mode Phase Tracking

Input Position Use the controls in the Input Position Menu to fine-tune the aspect ratio and image

position for the current source.

The input position settings are automatically saved for each input

Note

Left/Right: Select Left/Right from the Input Position menu to shift the projected image horizontally. Press to shift the image to the right; press to shift it to the left.

Up/Down: Select Up/Down from the Input Position menu to shift the projected image vertically. Press to shift the image upward; press to shift it downward.

and resolution.

Width: Select Width from the Input Position menu to change the projected image width. Press to increase the width; press to decrease it.

Height: Select Height from the Input Position menu to change the projected image height. Press to increase the height; press to decrease it.

Overscan/Overscan Mode: Overscan pushes the outside edge of the active picture area of the video signal out beyond the edge of the display area.

Some television programs are produced based on the assumption that older television sets may not display the outer edges of the broadcast picture area. Overscan effectively trims away these inactive, outer edges and enlarges the remaining portion of the image to fill the display area.

For HDTV, DVDs and other video sources, Overscan is generally not necessary or desirable.

This control defines the amount of overscan applied to the image. The range is from 0 to 20. There are two overscan modes:

•In Crop mode, each increment adds a mask at the top, bottom, left and right edges of the source image equal to 0.5% of the displayed horizontal resolution (1% total). A setting of 10, for example, crops the image 5% on all sides or 10% total.

•In Zoom mode, each increment adds a factor to the scaling of the source image so

PRE

that the vertical and horizontal resolutions are 100% plus 1% increments of the size determined by the aspect ratio function. A setting of 10, for example, zooms in on the image 5% on all sides or 10% total.

IMINAR

Figure 4-6 illustrates the effect of each overscan mode setting.

72 Runco SC-30d/SC-35d Installation/Operation Manual

4:3

16:9

Operation

Off Crop Zoom

= Source Image Area

= Edge Noise

= Screen (16:9)

Figure 4-6. Overscan Modes

Phase (RGB, Component or SCART sources): This control adjusts the phase of the

pixel sampling clock relative to the incoming signal. Adjust the phase when an RGB, Component or SCART image still shows shimmer or “noise” after Tracking has been optimized.

Adjust the Phase after adjusting Tracking (see below).

Tip

IMINAR

For best results, use a good test pattern such as a smooth gray consisting of a clear pattern of black and white pixels, or a similar “half on, half off” graphic image. Adjust the slidebar until the image stabilizes and each pixel is clearly defined. You may notice that you can stabilize the image at more than one point. Use either setting in such cases.

Tracking (RGB, Component or SCART sources): Tracking determines the frequency of the pixel sampling clock, indicated by the number of incoming pixels per line, so that all pixels generated by a particular source are sampled.

PRE

Steady flickering or several soft vertical stripes or bands across the entire image indicates poor pixel tracking. Proper pixel tracking helps ensure that the image quality is consistent across the screen, that aspect ratio is maintained and that pixel phase (see above) can be optimized.

Runco SC-30d/SC-35d Installation/Operation Manual 73

Operation

➤

Memory Presets For each input, the Dimension Digital Controller lets you save image quality settings as

Memory Presets

ISF Night ISF Day Custom 1 Save Reset Custom 2 Save Reset

presets that you can recall at a later time. You can create up to four presets per input and display mode (resolution and frame rate).

The Dimension Digital Controller stores the following display modes in each memory preset:

•480i

•480p

•576i

•576p

• 720p/24 Hz

• 720p/25 Hz

• 720p/30 Hz

• 720p/50 Hz

• 720p/60 Hz

• 1080i/50 Hz

• 1080i/50 Hz (Australia)

• 1080i/60 Hz

• 1080p/24 Hz

• 1080p/25 Hz

• 1080p/30 Hz

• 1080p/50 Hz

• 1080p/60 Hz

IMINAR

Use the Memory Presets menu to recall saved image presets, or to save image settings in the “Custom 1” or “Custom 2” memory location. The currently-selected preset is indicated by a “Î” to its left; in the example shown here, ISF Night is selected.

You should save changes to any of the following settings to a preset; otherwise they will be lost when a new input source or resolution is selected:

PRE

•Brightness

•Contrast

• Color saturation

•Tint

• Sharpness

•Gamma

•Lamp Settings

• Color temperature and white balance

To select a memory preset, press or to highlight it and press ENTER.

To save the settings for the current input and display mode to the Custom 1 or Custom 2 memory preset, select it, press or to highlight Save and press ENTER.

74 Runco SC-30d/SC-35d Installation/Operation Manual

Operation

Note

To reset the Custom 1 or Custom 2 memory preset to its factory-default state, select it, press or to highlight Reset and press ENTER.

formatting and delivery of HDMI 3D content.

3D Mode: Select 3D Mode from the 3D Processing menu to specify how the Dimension Digital Controller processes the “left eye” and “right eye” image components respectively.

•Choose Auto to have the Dimension Digital Controller determine the appropriate 3D mode based on the HDMI vendor-specific InfoFrame data. This is the default setting.

•Choose Off for 2D content.

•Choose Side-by-Side to have the Dimension Digital Controller scale the left and right image halves respectively to fill the screen.

Side-by-Side multiplexing is used with 1080i source material.

To save the settings for the current input and display mode to the ISF Night or ISF Day memory preset, select Save ISF Night or Save ISF Day from the Calibration menu (refer to Save ISF Night/Save ISF Day on page 82).

3D ProcessingSelect 3D Processing from the Main Menu to set the following options related to

3D Processing

3D Mode Reverse Eyes

•Choose Top-and-Bottom to have the Dimension Digital Controller scale the top and bottom image halves respectively to fill the screen.

Top-and-Bottom multiplexing is used with 720p or 1080p source material.

•Choose Frame Packing to have the input FPGA decode frame packed data into left and right eye data.

Reverse Eyes: By default, the Primary and Secondary video scalers in the Dimension Digital Controller are dedicated to “left eye” and “right eye” image processing respectively. To reverse this relationship, choose Reverse Eyes from the 3D Processing menu and set it to On.

PRE

IMINAR

Runco SC-30d/SC-35d Installation/Operation Manual 75

Operation

➤

Off 30 Minutes 60 Minutes 90 Minutes 2Hours 4Hours

Signal System Network Field Service Manufacturing

Sleep Timer Select Sleep Timer from the Main Menu to turn off the SC-30d/SC-35d after a specified

interval. Press or to select Off, 30 Minutes, 60 Minutes, 90 Minutes, 2 Hours or

Sleep Timer

Information Signal / System: Select Information from the Main Menu, then choose either Signal or

Information

4 Hours. Then, press ENTER.

System to display information about the current input signal (resolution, frequency, type et cetera) and installed firmware versions, as well as other information that uniquely identifies your Dimension Digital Controller and display device.

Should you ever need to contact Runco Technical Support, this information will help them answer your questions or resolve product performance issues.

Signal

Input Source HDMI 1 Signal Format 1080p/60 Input Resolution 1920x1080 Vertical Freq 59.94 Hz Horizontal Freq 67.500 kHz Pixel Clock 148.500 MHz Color Space REC709 Sync Type Separate 3D Mode Side-by-Side Memory Preset ISF Night

IMINAR

System

Model DC-300 Display Name SC-30d/SC-35d Output Resolution 1920x1080 Serial Number 00000000 Boot Version 1.0 Firmware Version 1.5 Micro Version 1.2 Input FPGA Version 1.0 Output FPGA Version 1.0

Network

MAC Address 1A:2B:3C:4D:5E:6F IP Address 192.168.0.150 Subnet Mask 255.255.0.0 Default Gateway 192.168.1.1 DHCP Enabled Network Status Connected

PRE

Network: Select Information from the Main Menu, then choose Network to display information about the Ethernet network connection.

To enable network communication via Ethernet, refer to IP Configuration on page 90.

Field Service / Manufacturing: The Field Service and Manufacturing menus are password-protected and intended for use only by Runco service personnel and factory technicians.

76 Runco SC-30d/SC-35d Installation/Operation Manual

should be used by ISF-certified technicians only.

Note

To recall the ISF Night or ISF Day settings, select “ISF Night” or “ISF Day” from the Memory Presets menu (see page 74) or use the corresponding remote control buttons.

Display Color - Common Settings: Use the Display Color - Common Settings menu to adjust the color balance at the Dimension Digital Controller output. These settings are saved independently for each input and display mode.

•Gain: Use the Gain controls to correct color imbalances in the bright areas of the image. A good way to do this is to use a test pattern consisting mostly of solid white areas, such as an 80 IRE “window” pattern. If the white areas contain traces of red (Pr), green (Y) or blue (Pr), decrease the Gain for that color.

•Offset: Use the Offset controls to correct color imbalances in the dark areas of the image. A good way to do this is to use a test pattern consisting mostly of dark gray areas, such as a 30 IRE “window” pattern. If the gray areas contain traces of red (Pr), green (Y) or blue (Pr), decrease the Offset for that color.

• Gamma: Select Gamma from the Display Color - Common Settings menu to choose a de-gamma curve. Used correctly, the Gamma control can improve contrast while maintaining good details for blacks and whites. If excess ambient light washes out the image and it becomes difficult or impossible to see details in dark areas, lower the gamma setting to compensate. This improves contrast while maintaining good details for blacks. Conversely, if the image is washed out and unnatural, with excessive detail in black areas, increase the setting.

• Mode: With the SC-30d/SC-35d, two Gamma adjustment modes are available:

Simple or Advanced. The two modes are mutually exclusive; when you select the Simple mode, the Advanced selection in the Gamma menu is grayed out. Likewise, when you select Advanced, the Simple selection is grayed out.

• Simple: Use the Simple Gamma control to perform gamma correction at the display

according to a simple power law gamma function. The value chosen here corresponds to the power variable in this equation:

You must enter a passcode to access the Calibration menu.

IMINAR

PRE

Operation

CalibrationUse the Calibration menu to perform advanced picture quality adjustments. This menu

Calibration

ISF Settings

Display Color Input Image

Input Color Save ISF Night Save ISF Day Copy/Paste Output Shift Image Alignment Adjustment Mode Splash Configure OSD Position

Output = Input

The Dimension Digital Controller applies this gamma curve to all three primary color channels (red, green and blue).

• Advanced: To select a custom gamma curve, select Mode from the Gamma menu and set it to Advanced. Then, select Advanced from the Gamma menu to select one of up to 20 pre-programmed gamma tables. Custom gamma tables provide the ability to perform complex, non-linear gamma correction on each primary color channel independently of the others.

Runco SC-30d/SC-35d Installation/Operation Manual 77

Power

Operation

• Color Temp: Select Color Temp from the Display Color - Common Settings menu to adjust the color temperature. Color temperature establishes the “color of gray” by adjusting the 75% white point to various color points.

What are “color points?” A “color point” is an x/y coordinate pair that defines a color’s location on the standard CIE chromaticity graph, shown in Figure 4-7. (CIE stands for “Commission Internationale de l’Éclairage” (International Commission on Illumination), the organization responsible for color measurement and management standards.)

1.0

0.9

0.8

0.7

Green

0.6

0.5

0.4

0.3

Cyan

IMINAR

0.2

0.1

Blue

0.0

PRE

0.00.10.20.30.40.50.60.70.80.91.0

Figure 4-7. CIE 1931 Chromaticity Diagram

• Simple: Select Simple mode from the Color Temp menu (with the SC-30d/SC-35d,

this is the only choice) to choose one of five color temperature presets: 3200K, 5500K, 6500K, 7500K and 9300K. The default setting, 6500K, is appropriate for most situations. Higher settings produce a “bluer” picture; lower ones impart a reddish hue to the image.

D93

D65

8000

10000

D50

6667

5714

5000

4000

3333

Yellow

2222

2500

2000

2857

Magenta

Red

78 Runco SC-30d/SC-35d Installation/Operation Manual

Table 4-2 lists the x- and y-coordinates for each color temperature preset in “Simple” mode.

Table 4-2. Color Temperature Presets and Associated Color Points

Operation

Color Temperature Preset

3200K 0.423 0.404

5500K 0.332 0.348

6500K 0.313 0.329

7500K 0.299 0.315

9300K 0.284 0.298

• Color Gamut: Select Color Gamut from the Display Color - Common Settings menu to select a color gamut (range) that may be different from the default color gamut.

Each setting defines the precise hue of each primary (red, green and blue) and secondary (yellow, cyan and magenta) color component used to generate the millions of colors produced in displays. Changing this setting relocates the “triangle” for possible colors (see Figure 4-7). For example, changing the x/y coordinates for red moves the color closer to either orange or violet, which in turn affects all displayed colors having a red component.

Associated x/y Values

IMINAR

Note

• The default setting, Auto, automatically chooses the appropriate color gamut:

• SMPTE C for NTSC, 480i and 480p sources.

• EBU for PAL, SECAM, 576i and 576p sources.

• REC709 for all other sources.

• Select REC709 to use the color gamut defined in ITU-R BT.709-5.

• Select SMPTE-C to use the color gamut defined in SMPTE 170M-1999.

• Select EBU to use the color gamut defined in EBU Tech. 3213-E.

• Select Native to use REC709 for cyan, magenta, and yellow and uncorrected values for red, green, and blue.

• Select PCE to use the Personal Color Equalizer feature of the SC-30d/SC-35d. PCE lets you define a custom color gamut. Refer to the next section, PCE, for instructions on how to do this.

1. The Color Gamut setting only affects 2D content.

2. The Dimension Digital Controller uses the Color Gamut settings for all display modes on a given input.

PRE

Runco SC-30d/SC-35d Installation/Operation Manual 79

Operation

Table 4-3 lists the Color Gamut settings and associated x- and y-coordinates for each primary and secondary color component.

Table 4-3. x/y Color Gamut Values

Color Gamut Settings and Associated x/y Values

Primary

Color

Red 0.640 0.330 0.630 0.340 0.640 0.330

Yellow 0.419 0.505 0.421 0.507 0.418 0.502

Green 0.300 0.600 0.310 0.595 0.290 0.600

Cyan 0.225 0.329 0.231 0.326 0.220 0.329

Blue 0.150 0.060 0.155 0.070 0.150 0.060

Magenta 0.321 0.154 0.314 0.161 0.328 0.158

REC709 SMPTE “C” EBU

xyxyxy

Display Color

RGBW

Red x 0.640

Red y 0.330

Green x 0.300

Green y 0.600

Blue x 0.150

Blue y 0.060

White x 0.313

White y 0.329

7 Auto Color Enable 7 Test Pattern Enable

•PCE: To use the Personal Color Equalizer to define a custom color gamut, choose the “PCE” Color Gamut setting (refer to Color Gamut on page 79). Then, choose PCE from the Display Color - Common Settings menu and press ENTER.

Note

IMINAR

PCE provides the ability to define a custom color gamut in terms of a “white point” and primary (red, green, blue) color points; see Figure 4-7.

• RGBW (Red, Green, Blue, White): To precisely adjust the primary color points and white point associated with the custom color gamut, choose RGBW from the PCE sub-menu. Each control operates only on the color specified. Surrounding colors are linearly interpolated based on their distance from each of these colors.

PRE

1. The PCE setting only affects 2D content.

2. The Dimension Digital Controller uses the PCE settings for all display modes on a given input.

80 Runco SC-30d/SC-35d Installation/Operation Manual

The Auto Color Enable and Te st Pattern Enable checkboxes let you choose what to display on-screen while making these adjustments. These controls work together as follows:

Auto Color Enable

Setting

Off Off When both boxes are unchecked, the input

Off On When only the Test Pattern Enable box is

Test Pattern Enable

Setting

Description

signal (normal picture) appears on the display.

checked, a white “curtain” test pattern appears instead of the input signal.

Operation

On Off When only the Auto Color Enable box is

checked, the input signal appears on the display.

When you select a red, green, blue, yellow, cyan or magenta color point to adjust, the Dimension Digital Controller displays only that color channel. When you select a white point x- or y-value, all colors are visible (normal picture).

On On When both boxes are checked, the

Dimension Digital Controller automatically displays a red, green, blue, yellow, cyan, magenta or white “curtain” test pattern

IMINAR

when you select an x- or y-value for that color point to adjust.

• YCM (Yellow, Cyan, Magenta): To precisely adjust the secondary color points associated with the custom color gamut, choose YCM from the PCE sub-menu. Each control operates only on the color specified. Surrounding colors are linearly interpolated based on their distance from each of these colors.

PRE

Display Color

YCM

Yellow x 0.419

Yellow y 0.505

Cyan x 0.225

Cyan y 0.329

Magenta x 0.321

Magenta y 0.154

7 Auto Color Enable 7 Test Pattern Enable

•Lamp: Select Lamp from the Display Color - Projector Settings menu to adjust the projector lamp brightness.

• Power (230W or 260W): To supply a constant wattage to the lamp, select Power

(230W or 260W) from the Lamp menu to set the lamp power level. You can choose to run the lamp as bright as possible (this is the default setting) or you can choose a lower setting. Generally, lower lamp output prolongs the life of a lamp, but decreases brightness.

Runco SC-30d/SC-35d Installation/Operation Manual 81

Operation

•ConstantContrast (SC-30d only): Select ConstantContrast from the Display Color - Projector Settings menu to enable (On) or disable (Off) ConstantContrast in the optical engine. ConstantContrast uses a dynamic iris that modulates light to the DMD based on the actual content of the video material. Runco recommends that you disable ConstantContrast before adjusting Brightness, Contrast or other image settings.

Note

Input Image: The Input Image controls are functionally similar to those in the Picture menu (refer to page 67), but are accessible only by entering the Calibration menu passcode.

Note

Input Color: The Input Color controls are similar to those in the Display Color menu (see above), but adjust the color balance of the incoming signal. These settings are also saved independently for each input and display mode.

•Gain/Offset (HD1, HD2 and Component/SCART inputs only): These controls operate similarly to those in the Display Color - Common Settings menu (described on page 77), but affect the Y, Pb and Pr signal components rather than the red, green and blue channels.

• Chroma Delay: use the Chroma Delay control to correct a mis-aligned image from a composite video source. Chroma delay in an image causes color shifts to occur to the left of the vertical edge transitions, producing artificial shadows or a “halo” effect. If necessary, adjust this setting to eliminate them.

•Noise Filter: To apply noise filtering to the input signal, select Noise Filter from the Input Color menu. The Noise Filter is useful for clearing up noisy images from 480i video sources.

IMINAR

PRE

Use the left- or right-arrow buttons to select the desired amount of noise reduction, keeping in mind that higher settings (which reduce high frequencies) may also “soften” the image.

ConstantContrast is disabled when the SC-30d is displaying 3D content, regardless of this setting.

The Input Image settings establish the “zero point” for the Picture menu settings, whose values represent offsets from the Input Image settings. For example, if you set Brightness to 10 in this menu, setting Brightness to 10 in the Picture menu results in an actual setting value of 20 (10+10).

Save ISF Night/Save ISF Day: Whenever you make a change to the ISF settings, you should always save it. Select Save ISF Night or Save ISF Day from the Calibration menu to do this.

82 Runco SC-30d/SC-35d Installation/Operation Manual

preset to another. This gives you a convenient starting point for creating a new preset based on an existing one, to make the calibration process less time-consuming.

For example, you can use the Copy/Paste Memory Preset feature to:

• Apply settings from HDMI 1 to HDMI 2, or from HD1 to HD2.

• Calibrate an input for 720p source signals, then use those settings for 1080i sources.

• Duplicate ISF Night settings for a given source and signal format and save them in the Custom 1 memory preset.

Operation

Copy/Paste - Memory Preset: You can copy and paste settings from one memory

Copy/Paste

Memory Preset Aspect Ratio

Memory Preset

Copy Settings Paste Settings

To use this feature, select Copy/Paste from the Calibration menu, then select Memory Preset.

•Memory Preset - Copy Settings: Select Copy Settings from the Copy/Paste Memory Preset menu to place the settings for the current input source, signal format (resolution and frame rate) and memory preset onto a “clipboard,” which is a temporary memory location. When you do, the message “Settings Copied” briefly appears on-screen. The Copy/Paste menu then re-appears, indicating the source of the copied settings.

Note

•Memory Preset - Paste Settings: To apply the settings on the clipboard to a different input source, signal format and/or memory preset, do any or all of the following:

• Switch to another input (for example, from HD1 to HD2).

• Change the output signal format at the source (for example, from 720p/60 to

1080i/60).

• Switch to another Memory Preset (for example, from ISF Night to Custom 1).

Then, select Paste Settings from the Copy/Paste Memory Preset menu. If you want

to keep these new settings, you must save them! (Refer to Save ISF Night/Save ISF Day on page 82 or Memory Presets on page 74.)

Copied settings are not retained after a power cycle.

IMINAR

PRE

those for Output Shift, Image Alignment (refer to page 84) or Screen Masking (refer to page 84) from one aspect ratio or “screen” (refer to Screen on page 66) to another.

To do this, select Copy/Paste from the Calibration menu, then select Aspect Ratio.

•Aspect Ratio - Copy Settings: Select Copy Settings from the Copy/Paste Aspect Ratio menu to place the Output Shift, Image Alignment and Screen Masking settings for the current aspect ratio onto a “clipboard,” which is a temporary memory location. When you do, the message “Settings Copied” briefly appears on-screen. The Copy/Paste menu then re-appears, indicating the source of the copied settings.

Copied From: Input Source HDMI 1 Signal Format 1080p/60

Memory Preset ISF Night

Copy/Paste - Aspect Ratio: You can also copy and paste certain settings, such as

Copy/Paste

Memory Preset Aspect Ratio

Aspect Ratio

Copy Settings Paste Settings

Note

Copied settings are not retained after a power cycle.

Runco SC-30d/SC-35d Installation/Operation Manual 83

Copied From: Aspect Ratio 16:9 Screen Screen 1

Operation

•Aspect Ratio - Paste Settings: To apply the Output Shift, Image Alignment and Screen Masking settings on the clipboard to a different aspect ratio and/or screen, do either of the following:

• Switch to another aspect ratio (for example, from 16:9 to Cinema).

• Switch from Screen 1 to Screen 2 or vice versa.

Then, select Paste Settings from the Copy/Paste Aspect Ratio menu. The new settings are saved automatically.

Output Shift: The Left/Right, Up/Down, Width and Height controls in the Output Shift menu are similar to those in the Input Position menu, except that they change the characteristics of the output signal. These settings are saved independently for each

aspect ratio and screen selection (refer to Screen on page 66).

• Screen Masking: This control adjusts the amount of cropping on each edge of the

output image. This differs from the regular Overscan control in two ways:

• It allows separate adjustments on each edge; and

• It is saved per aspect ratio, per screen (as opposed to per connector, per mode).

This is useful for installations where the aspect ratio of the screen doesn’t exactly match the aspect ratio of the display.

Image Alignment: Use the controls in the Image Alignment menu to ensure proper image geometry; that is, a perfectly rectangular projected image with no keystoning or pincushion. For detailed instructions, refer to Adjusting the Image Geometry on page 53.

Adjustment Mode (during 3D Operation): By default, any command or control message you send using the remote control, front-panel keypad or RS-232 interface is acted upon by both the Primary and Secondary scalers in the Dimension Digital Controller. In some cases — for example, when using the lens controls or aligning the “left eye” or “right eye” output images — you may need to address a command to only the Primary or Secondary scaler. To do this, select Adjustment Mode from the Calibration menu and set it to Primary or Secondary. The Main Menu title changes to “Runco Video (Pri.)” or “Runco Video (Sec.)” when you do this.

PRE

Note

Splash Configure: Use the Splash Configure menu to control the appearance and behavior of the “splash” screen that appears on the display upon power-up.

•Owner Name/ISF Calibrated/ISF Other: You can have the SC-30d/SC-35d display the owner’s name, your name, the phrase “ISF Calibrated” and/or any other string, up to 30 characters in length.

IMINAR

The Secondary OSD menus are only visible during 3D operation. In 2D mode, you will only see the image from the Primary scaler, regardless of this setting. If you want to adjust the Secondary scaler while in 2D mode, you must use the built-in keypad and VFD on the Dimension Digital Controller.

Use the up or down cursor button to select a character. Use the right and left cursor buttons to change the cursor position. Press MENU when you have finished entering text.

• Splash Timer: When you turn on the SC-30d/SC-35d, it projects a welcome screen with the Runco and ISF logos, along with the personalized information you enter as described above. Select Splash Timer from the Splash Configure menu to set the amount of time for which this screen appears. The range is from 5 to 60 seconds, in one-second increments. Press or to set the timer, then press MENU.

84 Runco SC-30d/SC-35d Installation/Operation Manual

Runco SC-35d, SC-30d User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Important Safety Instructions

Compliance Information

1. Introduction

1.1 About This Manual

Target AudienceRunco has prepared this manual to help installation personnel and end users get the most

If You Have Comments About This Manual...

Textual and Graphic Conventions

Using This Manual

1.3 Description, Features and Benefits

Key Features and Benefits The SC-30d/SC-35d offers these key features and benefits:

Parts List Your SC-30d/SC-35d is shipped with the following items. If any items are missing or

• HDMI-to-HDMI Cables (2), sold separately (refer to Optional Accessories, below)

2. System Overview

Figure 2-1. SC-30d/SC-35d Active 3D Projection System Block Diagram

Projector

Figure 2-2. SC-30d/SC-35d Front/Bottom/Side/Top Views

2.2 SC-30d/SC-35d Rear Panel

Figure 2-3. SC-30d/SC-35d Rear Panel

2.3 DC-300 Dimension Digital Controller

Front Panel LayoutFigure 2-4 shows the controls and indicators on the Dimension Digital Controller front

Figure 2-4. Dimension Digital Controller Front Panel

Rear Panel LayoutFigure 2-5 shows the rear connector panel on the Dimension Digital Controller.

Figure 2-5. DC-300 Dimension Digital Controller Rear Panel

2.4 SC-30d/SC-35d Remote Control Unit

Figure 2-6. Dimension Digital Controller Remote Control Unit for SC-30d/SC-35d

2.5 SC-30d/SC-35d Active 3D Emitter

3. Installation

3.1 Remote Control

Notes on Batteries• Make sure that the battery polarities are correct when installing the batteries.

Notes on Remote Control Operation

Quick Setup

Table 3-1. Installation Overview

Table 3-2. Projector Installation Options

3.3 Installation Considerations

Pre-Wiring for 3D: Run Dual HDMI Cables

Installation TypeChoose the installation type that best suits your needs: front or rear screen, floor mount or

Ambient LightIn general, minimize or eliminate light sources directed at the screen. Contrast ratio in your

Throw Distance Throw distance is the distance measured from the front of the projector to the screen.

Figure 3-1. Estimating Throw Distance

Table 3-3. Lens Options and Throw Ratios

Figure 3-2. Projector Placement

Figure 3-3. Vertical Lens Shift (EXAMPLE ONLY)

Figure 3-4. Horizontal Lens Shift (EXAMPLE ONLY)

Table 3-4. SC-30d/SC-35d Vertical and Horizontal Lens Shift Limits

Folded Optics In rear-screen applications where space behind the projector is limited, a mirror may be

Figure 3-5. Folded Optics

Table 3-5. Possible Audio Latency for Various Input Timings

Audio/Video Synchronization Issues

Other Considerations Other considerations and tips that can help improve your installation:

3.4 Installing the Primary Projection Lens

Installing the Optional CineWide Lens Mount

Figure 3-7. Installing the Ceiling Mount Adapters/Projector Stands

Figure 3-8. AutoScope Lens Motor Installation

Installing the Fixed CineWide Base Plate

3.6 Mounting the SC-30d/SC-35d

Floor Mounting (Upright) In typical front and rear screen installations, the projector can be mounted to a secure and

Figure 3-10. Mounting Angle Ranges (Front-to-Back and Side-to-Side)

3.7 Mounting the Dimension Digital Controller

Figure 3-11. Attaching the Rack Mounting Hardware

3.8 System Interconnections

Connector Panel Access To access the connector panel, pull firmly

Figure 3-12. RS-232 Connection from the Dimension Digital Controller to the Projector

Figure 3-13. Connecting the Dimension Digital Controller to the Projector

Figure 3-14. Audio Processor Connection to Dimension Digital Controller

Additional Connections to the Dimension Digital Controller (Optional)

Figure 3-15. RS-232 Control System Connection to Dimension Digital Controller

Figure 3-16. Connecting 12-volt Trigger Outputs

Figure 3-17. External IR Receiver Connection

Figure 3-18. Ethernet Network Connection to Dimension Digital Controller

Connecting Source Components to the Dimension Digital Controller

Figure 3-19. DisplayPort Source Connection

Figure 3-20. HDMI Source Connections

Figure 3-21. Component Video Source Connections

Figure 3-22. RGBHV Source Connections

Figure 3-23. SCART RGBS Source Connections

Figure 3-24. Composite Video Source Connections
