Runco DHD4 Specifications

Runco DHD4 Controller Specifi cations:

Aspect Ratios: 4:3, 16:9, Letterbox, VirtualWide™, Cinema,
Virtual Cinema™, Native

Video Standards: HDMI and DVI with HDCP for digital video, Component and RGB HDTV
(1080p, 1080i, 720p), Component and RGB EDTV (576p, 480p),
Component and Composite SDTV (576i, 480i), RGB SCART with adaptor,
NTSC (M, 4.43), PAL (B, G, H, I, N, M), SECAM (M)

Runco® DHD4™

Controller/processor

Inputs: (4) HDMI 1.4 with CEC and Deep Color; (1) Component/SCART (3 x RCA);
(2) Component/RGBHV (5 x BNC); (3) Composite

Output: (1) HDMI 1.4 with CEC and Deep Color to display; (1) HDMI 1.4 with
Deep Color to second display or audio processor

Display Communication: HDMI via RuncoLink™; RJ11 for serial display control
Communication Control Ports: (1) USB (type B female) for fi rmware upgrade; (1) RS-232 (female DB9)

for serial commands; (1) RS-232 (male DB9) for accessories; (1) 3.5mm
wired IR input for Niles/Xantech-compatible IR systems; Discrete infrared
remote; Front panel vacuum fl uorescent display and keypad

Ethernet Communication: (1) RJ45 (female) for web server, e-mail, auto fi rmware upgrade and Telnet
12V Outputs: (3) 3.5mm programmable, 250mA max each
Power Requirements: 100 – 240V AC (auto-sensing), 50/60 Hz, 35 watts (typical)
Operating Environment: 50°F to 104°F (10°C to 40°C), 0% to 85% humidity (non-condensing),

up to 10,000’ altitude
Dimensions: Width = 17.50 inches (444.5 mm); Depth = 11.19 inches (284.1 mm);

Height (with feet) = 3.75 inches (95.3 mm); Height (without feet) = 3.47
inches (88.14 mm); Weight: 15.4 lbs. (7.0 kg)

Accessory Applications: Runco Firmware Upgrader, Runco BRiC (backup, restore, clone),
CalMAN by SpectraCal for automatic calibration

Regulatory Approvals: cTUVus, FCC class B, CE, RoHS, China RoHS, WEEE, C-Tick, CCC,
local conformances as required

Limited Warranty: (2) Two years parts and labor from the date of shipment from Runco

Speci cations are subject to change without notice. ©Copyright 2010 Runco International Inc. All rights reserved.
