Page 1
Rumble Tuff
Electric Breast Pump
Instructions & Assembly
for Mighty Tyke
Page 2
Page 3
Congratulations
Congratulations on your new Rumble Tuff
®
Electric Breast Pump! The Rumble Tuff
®
Electric Breast Pump is perfect for
many occasions.
● Collecting breast milk while you're away from your baby
○ for example: when you're at work
● Relieving engorgement
○ for example: when your baby's feeding habits change because they're eating more solids
● Maintaining your milk supply if you have to temporarily stop breast feeding
○ for example: to express unsuitable milk while you are undergoing medical treatment
The Rumble Tuff
®
Electric Breast Pump provides many of the features busy moms love.
● 2 cycles of expressions to mimic baby's nursing patterns.
○ Swift Expression - Fast but shallow swallowing habit
○ Natural Expression - Steady and strong swallowing pattern
● Milk back-ow protection
● Quiet motor for discretion
● Small and lightweight
● 2 power options to t your needs
○ AC/DC Adapter
○ Li-ion battery
Indication for Use
The Rumble Tuff
®
Electric Breast Pump is a single user, electrical powered device used to express milk from the breasts
of lactating women. This device is not intended for hospital use.
English 0
Page 4
English 1
Table of Contents
Congratulations
Indication for Use
Important Safeguards
● DANGER
● CAUTION
● WARNING
Parts Guide
● Electrical Pump Main Unit
● LED Screen Guide
● Expression Collection Combo Kit
How to Assemble the Expression Collection Kit
How to Assemble Electric-pump Diaphragm Kit
How to Assemble Expression Collection Combo Kit
Power Options
● Using your AC/DC Adapter
● Using the Li-Ion Rechargeable Battery
● Install the Battery
Pumping Instructions
LED Light Signal Guide
Cleaning Instructions
● Sanitize Prior to First Use
● Before Each Use
● General Cleaning Instructions
● Tubing Cleaning Instructions
Breastmilk Storage Guidelines
● Important Notes
........................................................................................................................
.....................................................................................................................
..............................................................................................................
.................................................................................................................................
................................................................................................................................
...............................................................................................................................
.............................................................................................................................
..............................................................................................................
......................................................................................................................
.....................................................................................................
......................................................................
......................................................................
...............................................................
.........................................................................................................................
.............................................................................................................
...............................................................................................
........................................................................................................................
...............................................................................................................
............................................................................................................
...............................................................................................................
..............................................................................................................
........................................................................................................................
.........................................................................................................
..........................................................................................................
................................................................................................
.........................................................................................................................
0
0
3
3
3
3
5
6
6
7
8
11
12
14
14
15
16
18
22
23
23
23
23
24
25
25
Page 5
Tips
● Pumping Tips
● Battery Storage
● Breastfeeding Tips
Troubleshooting
● Interruption of Electrical Service
● Radio Frequency Energy
● Decreased Suction
● Pumping Does't Start
● Breastmilk Buildup in the Breastshield Body
● Where to get Replacement Parts
● Where to get Additional Accessories
● What Additional Accessories are Available
Technical Data
● Power Requirements
Warranty
..........................................................................................................................................
.............................................................................................................................
..........................................................................................................................
.......................................................................................................................
.......................................................................................................................
.......................................................................................................
...............................................................................................................
......................................................................................................................
...................................................................................................................
.........................................................................................
......................................................................................................
..................................................................................................
...........................................................................................
.........................................................................................................................
....................................................................................................................
...................................................................................................................................
27
27
28
28
29
29
29
29
30
30
30
30
30
31
31
32
English 2
Page 6
English 3
Important Safeguards
The Rumble Tuff
®
Electric Breast Pump is designed for a single user and should never be
shared or resold; doing so will void the warranty.
READ ALL INSTRUCTIONS BEFORE USING
DANGER: To reduce the risk of electrocution:
● Always unplug this product immediately after using.
● Do not use while bathing.
● Do not place or store this product where it can fall or be pulled into a tub or sink.
● Do not place or drop into water or other liquid.
● Do not reach for an electrical product that has fallen into water. Unplug immediately.
CAUTION:
● Do not use this product for any other purpose than as indicated in the manual.
● Make sure all the parts are assembled correctly before operating.
● Stop using the breast pump immediately if your breasts or nipples experience any discomfort.
● Please wash hands before using this product.
● Keep this product out of reach of babies and children.
● Do not drop or hit the product to avoid damage.
● Do not touch the product with bare hands right after sterilizing by boiling water to avoid scalds and burns.
● Do not over-boil to avoid premature aging of the product materials.
WARNING: To reduce the risk of burns, electrocution, re, or injury to persons:
● This product should never be left unattended when plugged in.
● Close supervision is necessary when this product is used near children or invalids.
● Use this product only for its intended use as described in this manual. Do not use attachments not recommended by
Rumble Tuff
®
.
● Do not operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged,
or if it has been dropped in water.
● Keep the cord away from heated surfaces.
● Do not use while sleeping or drowsy.
● Do not drop or insert any other object into any opening or tubing.
● Do not use outdoors with the AC/DC Adapter or operate where aerosol spray products are being used, or where oxygen is
being administered.
SAVE THESE INSTRUCTIONS
along with your receipt for future reference.
Page 7
Important Safeguards (Continued)
● Make sure the voltage of the AC/DC Adapter is compatible with the power source.
● Plug the AC/DC Adapter into the electrical outlet rst, then plug the Power Cord into your Rumble Tuff
®
Electric Breast
Pump.
● Rumble Tuff has provided an AC/DC Adapter and Li-Ion battery pack with this device. Using any other AC/DC Adapter or
Li-Ion battery pack not approved by the manufacturer voids the warranty.
● If you are infected with Hepatitis A, Hepatitis B, or have HIV (Human Immunodeciency Virus): pumping breast milk does not
reduce or remove the risk of transmitting the virus to your baby through breast milk.
● Wash the Expression Collection Combo Kit parts before each use.
● Do not operate a motor vehicle while using the Rumble Tuff
®
Electric Breast Pump.
● Do not attempt to modify the product.
English 4
Page 8
Parts Guide
Mighty Tyke Breast Pump Main Unit
AC/DC Adapter
Expression Collection Combo Kit
B o t t l e A d a p t e r K i t
Vacuum Tube with Adapter
English 5
Li-Ion
Rechargeable Battery
Extra 5 oz. Collection Bottle
Page 9
● Electric Pump Main Unit
● LED Screen Guide
Vacuum Adjusting Button Vacuum Adjusting Button
Power & Mode Button
* On/Off (press and hold for 2 sec.)
* Mode (press once)
Swift Expression LED Light Natural Expression LED Lght
Battery Cover
Tubing Adapter Inlet AC/DC Adapter Inlet
TOP VIEW BOTTOM VIEW
Parts Guide
English 6
Page 10
● Expression Collection Combo Kit
Parts Guide
English 7
Cap
Diaphragm
Cup with O-Ring
Breastshield Body
One-Way Valve
Bottle Adapter
Collection Bottle
Bottle Base
Silicone Cushion
Electric-pump
Diaphragm Kit
Expression
Collection Kit
Page 11
How to Assemble the Expression Collection Kit
Your Rumble Tuff
®
Electric Breast Pump comes pre-assembled; however, you will need to re-assemble it after each
cleaning. (For cleaning instructions, see page 23) Below is a step-by-step guide for assembling the Expression
Collection Kit:
1. Hold the "horn" of the Breastshield Body in one hand. Make sure the bottle-thread side opening is facing up.
2. With the thumb and forenger of the other hand, hold the tip of the One-Way Valve and place the at circular bottom into the
opening. Be sure not to stretch, bend, or twist the tip of the One-Way Valve. Seal all the edges rmly.
Note: The One-Way Valve tip does not have to align with anything, as long as all the edges are securely sealed.
Flat circular bottom
Tip
English 8
Page 12
How to Assemble the Expression Collection Kit (Continued)
3. With your thumb and forenger, gently seal any openings on the tip of the One-Way Valve and shape into a straight line.
Note: This is critical to the performance of the Pump.
4. Carefully twist on the Bottle Adapter to the Breastshield Body for a secure t.
Note: Be sure not to bump the One-Way Valve when twisting the Breastshield Body & the Bottle Adapter pieces together. If you
bump the One-Way Valve, repeat step 3.
English 9
Page 13
How to Assemble the Expression Collection Kit (Continued)
5. With the Bottle Adapter in one hand, twist on the Collection Bottle for a secure t.
English 10
Page 14
How to Assemble Electric-pump Diaphragm Kit
1. With the Cup in one hand, place the Silicone Diaphragm in the Cup (matching the shape of the Cup). Press around the edges of the
Diaphragm for a secure t. Make sure the Diaphragm is evenly mounted on the Cup and there is no gap in between them.
2. Place the Cap on the Cup & Diaphragm. (Be sure to align the hinge and hinge cover.) Press tightly to seal.
Hinge cover
Hinge
English 11
Page 15
How to Assemble Expression Collection Combo Kit
1. With the O-Ring side down, put the Electric Pump Diaphragm Kit into the top of the Breastshield Body opening. Twist the Electric Pump Diaphragm Kit clockwise into the Breastshield Body until it locks into place.
2. With the Breastshield Body in one hand, place the Silicone Cushion in the Breastshield Body (matching the shape of the horn).
Secure the lip of the Cushion around the edges of the horn.
Note: Your Electric Breast Pump will work with or without the Silicone Cushion. Your comfort depends on your preference.
English 12
Turn
Clockwise
Page 16
How to Assemble Expression Collection Combo Kit (Continued)
3. Take the open-end of Vacuum Tube (the end without the adapter) and connect to the Tubing Connector located on the Cap. Push
together rmly for a tight seal.
Note: Make sure there is no moisture in the tubing.
4. Make sure the Tubing Adapter is properly inserted into the Tubing Adapter Inlet on the Electric Pump Main Unit.
Tubing
Connector
English 13
Page 17
Power Options
1. Plug the AC/DC Adapter into an electrical outlet.
2. Attach the Power Cord to the AC/DC Adapter Inlet on the Electric Pump Main Unit.
Your Electric Breast Pump may be operated under any of the following power supply modes:
Using your AC/DC Adapter:
● Electrical safety can only be achieved when using the AC/DC Adapter which was provided with the Pump. Use of any
another Adapters causes concern for the safety of the product and/or the user and voids the warranty.
English 14
Page 18
Using the Li-Ion Rechargeable Battery:
● Prior to rst use, charge the battery for 24 hours. If necessary, your Electric Breast Pump can be used during this
period with the Power Cord only. For best results, allow the Pump to initially charge uninterrupted for 24 hours.
● After the initial charge, subsequent charges will take approximately 4 hours. Once charged, you should not need to
remove the battery unless replacing or when storing.
● The Li-Ion Rechargeable Battery will charge every time the AC/DC Adapter is plugged in; however, it will not charge
while your Electric Breast Pump is in use.
● The Swift Expression LED and Natural Expression LED ash alternately while the battery is charging.
Note:The Li-Ion Rechargeable Battery used in this device may present a risk of re or chemical burn if mistreated.
Do NOT disassemble the battery. Do NOT place battery near heat source or re. Dispose of used battery properly.
Do NOT dispose of battery in re. For long term storage, keep battery within the following temperature range:
32°F to 77°F (0°C to 25°C). Keep away from children.
Li-Ion Battery Compartment
Li-Ion Battery
English 15
Page 19
1. Open the Battery compartment by sliding the cover to the side by following the arrow. Lift to remove the cover.
2. Use the tab to remove the old battery.
Note: To remove the battery, slide the battery down, away from the side with the Tubing Adapter Inlet. Pull the tab up to remove the
old battery.
Install the Battery: Li-Ion Rechargeable
English 16
Tubing Adapter Inlet
Page 20
3. Insert the new Li-Ion Rechargeable Battery. Make sure the sticker on the battery faces the sticker on the pump's bottom, and the
battery is inserted completely into the compartment.
Note: The pump will not operate on battery power if the battery is inserted incorrectly. When the battery is inserted correctly, it will
slide easily into the battery compartment. Do NOT force.
4. Close the Battery Cover and slide the back in place until locked. Align the arrow to the locked position to ensure the battery cover is
closed.
Note: Make sure the battery is inserted completely into the compartment before pushing the cover closed.
Install the Battery: Li-Ion Rechargeable (Continued)
English 17
Page 21
Pumping Instructions
1. Hold the Expression Collection Combo Kit to your breast so that your nipple is centered inside the Breastshield.
2. Press and hold the Power/Mode Button until the pumping starts.
Note: Make sure to hold the Power/Mode button long enough (approx. 2 sec.) until the pumping starts. If this doesn't work, please
check the Troubleshooting section on page 29.
Power/Mode
English 18
Note: Please check for correct tting of the shield.
Page 22
Pumping Instructions (Continued)
3. The Pump will start in the Swift Expression mode at the lowest suction level. The Swift Expression LED will light up.
4. Adjust the suction to your comfort level while pumping by pressing the buttons or . A beep sound can be heard whenever the
suction level is changed.
Note: The LED light will ash when you have reached the minimum or maximum vacuum settings (There are 8 suction levels).
Vacuum Adjusting
buttons
English 19
Swift Expression LED Light
Page 23
5. If you feel your milk start to let-down, press the Power/Mode Button to switch to the Natural Expression mode.
Note: The pump will turn off if you press and hold the Power/Mode Button for more than 2 seconds.
6. The pump will switch to the Natural Expression mode at the lowest suction level. The Natural Expression LED will light up.
Power/Mode Button
Pumping Instructions (Continued)
Swift Expression mode Natural Expression mode
English 20
Page 24
7. Adjust the suction in the Natural Expression mode to your comfort level while pumping by pressing the Vacuum Adjusting buttons
or .
Note: The LED light will ash when you have reached the minimum or maximum vacuum settings (There are 8 suction levels).
8. When your pumping session is nished, press and hold the Power/Mode Button for more than 2 seconds until the pumping stops.
Note: Make sure to hold the Power/Mode button long enough (approx. 2sec.) until the pumping stops.
Make sure there is no suction on the nipple before removing the Breastshield. If necessary, break the suction by inserting a
nger between the Breastshield and the breast, similar to the way you break away from your baby's suction.
Pumping Instructions (Continued)
Note: If the Rumble Tuff
®
Electric Breast Pump is left on, but unattended for more than 30 minutes, the
Pump will automatically shut-off.
Vacuum Adjusting
buttons
Power/Mode
English 21
Page 25
LED Light Sign Guide
English 22
State Signal
While Pump
is on
Pumping in Swift Expression
Swift Expression LED Natural Expression LED
(White light) (Blue light)
White Light is On
Pumping in Natural Expression
Blue Light is On
Battery is Low (Swift Expression mode)
White Light Flashes
Battery is Low (Natural Expression mode)
Blue Light Flashes
Battery is Empty
Both Blue & White Lights Flash, then turn Off
While Pump
is off
Battery is Charging
Blue & White Lights Flash Alternately
Charging is Completed
Both Blue & White Lights are On
Light is Off Light is On Light is Flashing
Page 26
Cleaning Instructions
Unless otherwise instructed by your healthcare provider, follow these sanitizing and cleaning instructions.
Sanitize Prior to First Use:
Before you use your Rumble Tuff
®
Electric Breast Pump for the first time, disassemble and boil all parts of the
Expression Collection Combo Kit in water for 10 minutes.
● Be sure to use enough water to keep all parts aoat while boiling.
● Do NOT boil Tubing or Tubing Adapter.
● Remove all parts from the water immediately after sterilizing. To avoid scalds and burns, do NOT touch the product
with bare hands right after sterilizing.
● Completely air-dry or towel-dry before reassembling and next use.
Partially dry components may affect the operation of your Electric Breast Pump. Please ensure that all parts are
completely dry before use.
Before Each Use:
● Wash your hands thoroughly with soap and warm water before handling the Expression Collection Combo Kit, the
Electric Breast Pump or any Expression Collection parts or attachments.
● Make sure all parts are clean and dry.
● Ensure the Tubing is free from any liquid. Do NOT operate your Rumble Tuff Electric Breast Pump if any liquid
is visible in the Tubing. (See Tubing Cleaning Instructions on page 24.)
General Cleaning Instructions:
● Set aside the Tubing and Tubing Adapter. Under the normal working conditions of the pump, the diaphragm
prevents the back-ow of milk. Therefore, these items do not need to be washed. In case of nding any liquid or
liquid vapor inside the Tubing, follow the Tubing Cleaning Instructions ( page 24) carefully before use.
● All parts of the Expression Collection Combo Kit may be cleaned in the upper compartment of your dishwasher or
hand washed with dish soap in hot water.
Caution: Take care when cleaning the One-Way Valve. If it gets damaged, your breast pump will not
function properly. To clean the One-Way Valve, rub it gently between your ngers in warm soapy water,
then rinse thoroughly in clean warm water. Do not insert any objects into the One-Way Valve as this
may damage the valve.
English 23
Page 27
Cleaning Instructions (Continued)
● Do NOT use solvents or abrasives.
● Rinse with hot, clean water.
● To clean the Electric Pump Main Unit, wipe it with a damp cloth, using only water or water mixed with a mild soap.
Tubing Cleaning Instructions:
● Wipe the outside of the Tubing with a clean, damp cloth. Avoid getting water or other uids inside the Tubing.
● If liquids are found inside Tubing, rinse the Tubing with clean hot water. Hang to AIR DRY COMPLETELY BEFORE
USING. Do NOT insert any object into Tubing.
Note: Before each use visually inspect the individual components for cracks, chips, tears, discoloration or deterioration;
as they may affect the efciency of the Rumble Tuff
®
Electric Breast Pump. In the event that damage to the
device is observed, please discontinue use until the parts have been replaced.
English 24
Page 28
Breastmilk Storage Guidelines
Check with your healthcare provider or an International Board Certified Lactation Consultant for specific storage
instructions. This information is based on current research and applies to mothers who have healthy, full-term babies
who are storing their milk for home use.
Important Notes:
● STORAGE CONTAINERS: The best option for storing human milk is glass or hard-sided plastic containers with
well-tting tops. When you are freezing your breastmilk, do not ll the container more than 3/4 full to allow for
expansion from freezing. Store milk in the main refrigerator or freezer compartment, away from the door, to avoid
changes in temperature that may compromise the milk.
● RE-WARMING THE FROZEN MILK: Frozen milk can be thawed in the refrigerator overnight or under cool running
water. Gradually increase the temperature of the water to heat the milk to feeding temperature. Be sure to use
thawed milk within 24 hours. Discard any leftovers.
● RE-WARMING THE REFRIGERATED MILK: Refrigerated milk can be warmed by running under warm water for
several minutes. ALWAYS test the temperature of the milk on the inside of your wrist before feeding it to your baby.
The milk should feel warm, not hot.
● WHAT TO DO: Storing milk in 2 to 4 oz amounts may reduce waste. Write the date you expressed your milk on the
container (include your baby's name on the label if your baby is in a daycare setting). Use the oldest milk rst. Throw
away previously frozen milk that is not used within 24 hours.
● WHAT NOT TO DO: Do NOT heat milk directly on the stove. Do NOT thaw in hot or boiling water. Do NOT microwave
milk, as microwaving alters the composition of the milk and may create hot spots that may burn your baby. Do NOT
refreeze thawed milk.
● THAT'S WEIRD: Human milk may separate into a milk layer and a cream layer when it is stored. This is normal.
Gently swirl to redistribute the cream before giving to baby. Sometimes thawed milk may smell or taste soapy. This is
due to a breakdown in the milk fats. The milk is safe and most babies will still drink it.
● IS IT DANGEROUS: Expressed milk can be kept in a common refrigerator at the workplace or day care center. The
US Center for Disease Control (CDC) and the US Occupational Safety and Health Administration (OSHA) agree that
human milk is not among the body uids that require special handling or storage in a separate container.
English 25
Page 29
Breastmilk Storage Guidelines (Continued)
Place Temperature How long Things to know
Refrigerator
39°F or colder ● Up to 72 hours is best.
● Up to 5-8 days is okay for very
clean expressed milk.
Store milk in the back of the main body of
the refrigerator.
Freezer
0°F or colder ● Up to 6 months is best.
● Up to 12 months is okay.
Store milk toward the back of the freezer
where temperature is most constant. Milk
stored at 0°F or colder is safe for longer
durations, but the quality of the milk might
not be as high.
Smaller
cooler with
a blue-ice
pack.
59°F 24 hours Keep ice packs in contact with milk
containers at all times; limit opening
cooler.
Countertop,
table
Room temp
(60°F - 85°F)
● Up to 3-4 hours is best.
● Up to 6-8 hours is okay for very
clean expressed milk.
Containers should be covered and kept
as cool as possible; covering the container
with a clean cool towel may keep milk
cooler. Throw out any leftover milk within
1 to 2 hours after the baby is nished
feeding.
Source: Breastfeeding Made Easier at Home and Work www.womenshealth.gov
Do not refreeze thawed milk. Discard any remaining thawed milk if not used within 24 hours.
English 26
Page 30
Tips
Pumping Tips:
The most important and successful part of pumping is the let-down reex. The let-down reex is when your milk begins
to ow freely.
● Try relaxing with a warm, wet compress on your breasts.
● Drink plenty of uids.
● Avoid outside distractions.
● Visualize yourself happy, well rested and successful at pumping.
● Sometimes a light circular massaging of the breasts prior to and/or during a pumping session will help your let-down
reex start/continue.
● Go to a non-stressful environment.
● Use a comfortable chair that gives lower back support with or without a footstool. After all, you're the one who has to
be comfortable.
Depending on your health and milk production condition, you may be able to achieve more than one let-down in one
pumping session. Most mothers have more than one let-down while breast feeding and don't even notice the change.
To achieve multiple let-downs; which mimics the natural reex found in breast feeding, you can switch back and forth
between the Swift Expression and Natural Expression just by pressing the Power/Mode Button.
Remember that successful pumping is a learned skill. Don't get discouraged, and keep working at it to obtain the best
results. Breastmilk is produced on a supply and demand basis; expressing your breastmilk regularly stimulates and
maintains your milk supply.
If it feels uncomfortable or painful on your breasts while using the Pump, try decreasing the suction level by pressing the
Vacuum Adjusting buttons (-). You may also try pumping with/without the Silicone Cushion. If these tips do not help, turn
the product off and remove the pump from your breasts for a few minutes. If you are still experiencing pain or discomfort,
consult your healthcare professional or an international board certied lactation consultant.
English 27
Page 31
Battery Storage:
● When storing the battery for a short period of time, store within the following temperature range: -4°F to 140°F
(-20°C to 60°C).
● When storing the battery for an extended period of time, store within the following temperature range: 32°F to 77°F
(0°C to 25°C).
Breastfeeding Tips:
● The Rumble Tuff
®
Electric Breast Pump helps you maintain a supply of milk and can help you prepare for planned
events such as "Date Night" or unexpected events such as power outages, medical treatment, or relief from tender
nipples.
Tips (Continued)
English 28
Page 32
Troubleshooting
English 29
Interruption of Electrical
Service
If you experience an interruption of electrical service, due to a power surge or other factors, during
normal operation of your Rumble Tuff
®
Electric Breast Pump, try the following:
● Unplug the AC/DC Adapter cord from the electrical outlet and wait for ve seconds.
● Plug the AC/DC Adapter cord back into the electrical outlet.
● If problem persists, try a different electrical outlet.
Radio Frequency Energy
This equipment generates, uses, and can radiate radio frequency energy. If not installed properly and
used in accordance with the instructions; it may cause harmful interference with other devices in the
vicinity. Try the following:
● Reorient or relocate the device receiving interference.
● Increase the distance between the equipment.
● Connect the equipment into an outlet on a different circuit from that which the other
device(s) are connected.
● Consult the manufacturer or a eld service technician of the device receiving interference
for help.
● There is no guarantee that interference will not occur.
Decreased Suction
If it feels like the suction has decreased, try the following:
● Make sure the Breast Pump is assembled correctly
(see Assembly Instructions pages 8-13).
○ Inspect the One-Way Valve for any tears or pinholes. This component is critical to
achieving proper suction. If damaged, replace the One-Way Valve with one of the spare
valves that is provided with your Rumble Tuff
®
Electric Breast Pump.
● Detach the Tubing and Tubing Adapter from the back of your Electric Breast Pump and place a nger
over the Tubing Adapter Inlet.
○ If you do feel suction, the Electric Pump Base is operating properly.
○ If you do NOT feel suction or feel that the suction has decreased to an unexpected strength; contact
Rumble Tuff Customer Service for warranty service (see Page 32).
Page 33
Additional Accessories:
Parts
● Breastshield Body with Adaptor Ring
● Silicone Cushion (2pcs)
● One-Way Valve(4pcs)
● Bottle, Wide Mouth with Feeding Nipple (2 pcs)
● Storage Bottle only, Wide Mouth with Cap (6 pcs)
● Electric Pump Diaphragm(2pcs)
● Electric Pump Diaphragm Kit
● Manual Pump Diaphragm Kit
● Vaccuum Tube with adapter, for Double Pump
● Vaccuum Tube with adapter, for Single Pump
Parts
● AC/DC 12V Power Adapter, UL
● Bottle Adapter,Wide
● Collection Bottle Combo Kit (2 pcs)
Part Number
PA91500-0101
PA90300-0201
PA90800-0420
PA90400-0201
PA90401-0601
PA91200-0220
PA91300-0101
PA90900-0101
PA90600-0120
PA90700-0120
Part Number
PA902U1-0101
PA900P0-0000
PA91900-0201
.........................
.............................................
................................................
........
.....
................................
.....................................
.....................................
..........
...........
.................................
...................................................
...........................
Troubleshooting (Continued)
English 30
Pumping Doesn't Start
● Make sure the adapter is properly plugged.
● If you are using the battery, make sure the battery is fully charged.
●When battery runs low, Both Blue & White Lights Flash and then turn off automatically.
Breastmilk Buildup in
the Breastshield Body
If breastmilk doesn't appear to be draining fast enough into the Collection Bottle, reduce the suction
setting on your Electric Breast Pump to allow the milk to drain before gradually increasing.
Where to get
Replacement Parts
If you are missing a part or a part was damaged, please contact Rumble Tuff ® customer service by
calling toll-free (855) 228-8388.
You can purchase additional accessories for your Rumble Tuff
®
Electric Breast Pump by the following
methods:
● Email: [email protected]
● Fax: (801) 796-2688
● Toll-Free: (855) 228-8388
Page 34
Technical Data
Power Requirements:
● AC/DC Adapter (included) North American Plug conguration:
Brand: Acute Ideas
Model: GDP12AV-0901300, 100V~240V AC, 50/60 Hz, 0.45A, wall plug type AC/DC Adapter with DC 9V/1.33A output.
● Battery:
Li-Ion Rechargeable battery; 7.4V 850mAh
Brand: Acute Ideas
Model: 18-0740850-RT00, compatible with Nikon EN-EL9
● The power adaptor plug is also served to disconnect the device, not to position the equipment to make it difcult to
operate the disconnection device.
Technical Specications:
VACUUM:
Reex/Swift Expression: -115~-200mmHg (-15.3~-26.6kpa)
Natural Expression: -115~-250mmHg (-15.3~-33.3kpa)
Ambient Temperature range: +10OC to 40OC (50OF to 104OF)
Relative Humidity range: 20% to 80%
Transportation / Storage Environment : –10 to 50˚c / 20 to 90% relative humidity
Key to Box Symbol:
●
Type BF equipment (Breastshield)
●
Consult instructions for use
●
Disposal of Electrical & Electronic Equipment (WEEE)
Made in China
English 31
Page 35
Warranty
Limited Consumer Product Warranty (United States)
This Rumble Tuff
®
Electric Breast Pump is warranted to the original consumer "the purchaser" to be free from defects in
material and workmanship which are not commercially acceptable for the period of one year from the date of purchase
on the pump mechanism and a period of 120 days on all other components. Warranty coverage terminates if you sell or
otherwise transfer this product to another person. This warranty gives you specic legal rights and you may also have
other rights, which vary by location.
RUMBLE TUFF
®
MAKES NO EXPRESS WARRANTY OF ANY KIND REGARDING THIS PRODUCT OTHER THAN
THOSE WARRANTIES SET FORTH HEREIN. ANY IMPLIED WARRANTY, INCLUDING ANY IMPLIED WARRANTY
OF MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FOR A PARTICULAR PURPOSE TO THE
EXTENT PERMITTED BY LAW, SHALL BE LIMITED IN DURATION TO A PERIOD OF 120 DAYS FROM THE DATE
OF PURCHASE BY THE ORIGINAL PURCHASER.
In the event that this product if found by Rumble Tuff
®
to not meet the above limited warranty, as purchaser's sole and
exclusive remedy, Rumble Tuff
®
will repair or at the option of Rumble Tuff
®
, replace this product without charge for such
replacement parts or labor. The purchaser shall bear all expenses related to returning this product to Rumble Tuff
®
. This
warranty does not apply to any part of the product that has been subject to misuse, abuse, or alteration. Only Rumble
Tuff
®
brand replacement parts are recommended for use with Rumble Tuff
®
breastfeeding products. Improper or
incorrectly performed maintenance or repair, or use of non-Rumble Tuff
®
brand replacement parts voids this warranty.
TO THE EXTENT PERMITTED BY LAW, RUMBLE TUFF
®
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO, REPLACEMENT COSTS RESULTING FROM
THE BREACH OF ANY WRITTEN OR IMPLIED WARRANTY.
English 32
Page 36
Warranty (Continued)
If you wish to make a claim under this warranty, you will need the following:
● The entire original Rumble Tuff
®
product
● The original receipt showing date of purchase
● Return Authorization Number (RA#)
● Detailed description of the problem
You, the purchaser, are responsible for all shipping charges.
To obtain an RA# and shipping address: Please contact Rumble Tuff
®
Customer Service Department by;
Toll-free (855) 228-8388, or
E-mail to [email protected], or
In writing to:
Customer Service Department
Rumble Tuff
865 N 1430 W
Orem UT 84057
Items returned without a RA# will not be processed and will be returned to sender (postage due).
English 33
Page 37
75-PA20600-RT01 Ver : A1407
Rumble Tuff
®
is owned and operated by
A Cute Baby, Inc.
865 N 1430 W Orem UT 84057-6402
Tel: (801) 609-8168 Fax: (801) 796-2688
www.rumbletuff.com www.acutebaby.com
Loading...
