Rugged Science PONS vX-Series User Manual

1.0.0 Edition 19 Mar 14 All

information is subject to change without notice.

Technical Support and Product Information www.RuggedScience.com Rugged Science Corporate Headquarters 53 Loveton Circle, Suite 203, Sparks, Maryland 21152 United States of America Toll-Free: 1.855.769.9747 Email: sales@ruggedscience.com For further support information, refer to the Technical Support and Professional Services appendix. To comment on Rugged Science documentation, refer to the Rugged Science web site at www.RuggedScience.com. © 2014 Rugged Science, LLC. All rights reserved.

Record of Revision

Version Date Page Description Remark

V1.00 March 10, 2014 All Preliminary Release

©Rugged Science PONS vX-series User Manual

This manual is intended to be used as a practical and informative guide only and is subject to change without prior notice. It does not represent commitment from Rugged Science,

LLC. Rugged Science shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

This document contains proprietary information protected by copyright. All rights are reserved. No part of this document may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer. Company/product names mentioned

herein are used for identication

Disclaimer

Declaration of Conformity

Ordering Information

Optional Accessories

Part Number Description

PONS-8610

Intel

® 3rd

Gen Quad Core™ i7/i5/i3 Fanless Embedded System with 6

Gigabit Ports (4 PoE+) & 1 PCIe x16 Expansion Slot

PONS-8620

Intel

® 3rd

Gen Quad Core™ i7/i5/i3 Fanless Embedded System with 6

Gigabit Ports (4 PoE+) & 1 PCI Expansion Slot

Part Number Description

M340S-W28M1

Rugged Science DDR3 4GB 1333/1066MHz RAM, -40°C ~ +85°C

KVR1333D3S9/8G Kingston

DDR3 8GB PC1333 RAM

KVR1333D3S9/4G Kingston

DDR3 4GB PC1333 RAM

PWA-120WM4P 120W, 24V, 90VAC to 264VAC power adapter SCSI-20P-100 20-pin SCSI Cable, 1M TMB-SCSI-20P Terminal Board with One 20-pin SCSI Connector and DIN-Rail

Mounting

WiFi Module Intel MiniPCIe WiFi Module with Antenna

Table of Contents

iv iv

Declaimer Declaration of Conformity Copyright and Trademarks iv

FCC iv

Order Information Optional Accessories v

General Introduction 1

1.1 Overview 1

1.2 Product Specificatio 2

1.2.1 Specifications of Vecow PONS v8610

2 3

1.2.2 Specifications of Vecow PONS v8620

1.3 Supported CPU List

1.4 Mechanical Dimension

Getting to Know Your PONS vX-Series 6

2.1 Packing List 6

2.2 Front Panel I/O Functions 6

2.2.1 Audio Jacks 6

2.2.2 Dual USB 3.0 7

2.2.3 Dual USB 2.0 7

2.2.4 10/100/1000 Mbps Ethernet Ports 8

2.2.5 Dual Display Port 9

2.2.6 DVI-D/HDMI Connector 9

2.2.7 VGA Connector 10

2.2.8 PWR and HDD LED Indicators 11

2.2.9 CFast Card 11

2.2.10 Power Button 12

2.2.11 Reset Tact Switch 12

2.3 Rear Panel I/O Functions 13

2.3.1 DC-In 6~36V Mini DIN or Power Terminal Block 13

2.3.2 Remote Power On/Off Switch 13

2.3.3 Serial Port COM2 14

2.3.4 Serial Port COM1, COM3 & COM4 15

2.3.5 Isolated 8 DI / 8 DO 16

2.3.6 PoE, Power over Ethernet Ports 18

2.4 Main Board Expansion Connectors 19

2.4.1 J4 Miscellaneous Pin Header 21

2.4.2 CN15, CN20, J2 LVDS 22

2.4.3 CN7, CN8 SATA3 & CN11 SATA Power Connector 25

2.4.4

CN10 SATA-II Connector J3 SATA DOM Power Connector 27

2.4.5 J1 Internal USB Dual Port 29

2.4.6 CN17, CN22 Mini-PCIe, mSATA Connectors 30

2.4.7 CN13 GPIO 32

2.4.8 FAN1 33

2.4.9 CN30 PCIe x16 34

2.4.10 Battery 36

2.5 Main Board Jumper Setting 37

2.5.1 JP2 LVDS Backlight Power Selection 39

2.5.2 JP4(A) CMOS Clear Jumper Setting 40

2.5.3 JP4(B) ME Clear Jumper Setting 41

2.5.4 JP3 AT/ATX Power Mode Jumper Setting 42

2.5.5 JP1 PCIe Bifurcation Jumper Setting 43

System Setup 44

44 45 47 48 50

3.1 Install DDR3 / DDR3L SODIMM Modules

3.2 Install HDD

3.3 Install MiniPCIe Cards

3.4 Install SATA DOM

3.5 Install PCI or PCIe Card

3.5 Mount Your PONS vX-Series

BIOS and Driver 54

4.1 BIOS Settings 54

4.1.1 Main Menu 55

4.1.2 Advanced Function 55

4.1.3 Chipset Function 60

4.1.4 Boot Function 61

4.2 Operating System 61

4.3 Driver Installation 62

4.3.1 Chipset Driver Installation 62

4.3.2 Intel HD 4000 Graphics Driver Installation 63

4.3.3 Network Device Driver Installation 63

4.3.4 Audio Driver Installation 64

4.3.5 USB 3.0 Driver Installation 64

4.3.6 Storage Support Software Installation 65

4.3.7 Intel AMT Function Support 65

Appendix A : Isolating DIO Guide 66

Appendix B : GPIO & WDT Function 68

68 68 68

A. Entry MB PnP Mode B. Located on Logical Device 7 C. Access the Super I/O Register D. Access the PONS vX-Series GPIO Port

E.WDT ON/OFF and Timer-Counter setting 69

Product Introduction

General Introduction

Based on 3rd Gen Intel® Quad-Core™ i7 Processor (6M Cache, up to 3.30 GHz), PONS vX series integrates 2 GbE LAN, 4 GigE PoE+ ports, and one PCIe x16 expandable slot. With maximum dual channel 16GB ram, DVI-D/HDMI and VGA triple display, two 2.5” SATA 6Gp/s HDD/SSD, one SATA 3Gp/s SSD/HDD supports SATA DOM, one of 2 miniPCI-express supports SIM card for WiFi, 3G/GPRS, and still keep outstanding thermal design for -25oC to +70oC industrial operating temperature range.

PONS vX series provides 2 fully integrated Gigabit Ethernet interfaces for either 1000 Mb/s or 10/100 Mb/ s operation rates by each and jumbo frames up to 9018 bytes. Enabling accurate time synchronization, wake-up function, and boot up through the extensible firmware interface (PXE), PONS vX series integrates fully power

management function to optimize voltage efciency.

Empowering 4 GigE IEEE 802.3at PoE+ ports, PONS vX series is the ideal option for GigE cameras required efficient power supply and long distance connection. Improving network traffic load-balancing by optimized parallel and pipelined architectures, the 2 gigabit Ethernet controllers of the PONS vX series enables smooth network traffic loading for the most demanding occasions. PONS vX series is designed for machine vision, intelligent automation, intelligent manufacturing system, automation networking communication, IOT (Internet of Things), and process control applications.

1.1 Overview

Product Introduction

©Rugged Science PONS vX-series User Manual

1.2 Product Specication

System

Processor 3rd Generation Intel® Quad Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz)

Chipset Intel

QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB, Two 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 Isolated DIO 8 DI, 8 DO, 5V~24V Input (Optional)

LED Power / Suspend, HDD, CFast and and WDT LEDs

GPIO 16 GPIO

Expansion

PCIe 1 Slot for PCIe x16 Expansion Card

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, Optional with mSATA

1 miniPCIe Socket: PCIe + USB, Optional with mSATA

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000, Triple Independent Display Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mS ATA 2 SATA II 3Gbps (Optional) Storage Expansion CFast Slot, External Hot-Swap, Push In/Out Ejector

Audio

Audio Codec Realtek® ALC892, 5.1 Channel HD Audio

Audio Interface Line-In, Line-Out, Mic-In, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel

82574L Gigabit LAN

Power over Ethernet

LAN3 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel® 82574L with Power On/Off Control LAN4 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

LAN5 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

LAN6 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Random: 0.5Grms @5~500 Hz according to IEC68-2-64

Sinusoidal: 0.5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 20 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS, EN50155 & EN50121-3-2

1.2.1 Specifications of Rugged Science PONS v8610

Product Introduction

1.2.2 Specifications of Rugged Science PONS v8620

System

Processor 3rd Generation Intel® Quad Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz)

Chipset Intel

QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB, Two 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 Isolated DIO 8 DI, 8 DO, 5V~24V Input (Optional)

LED Power / Suspend, HDD, CFast and and WDT LEDs

GPIO 16 GPIO

Expansion

PCI 1 Slot for PCI Expansion Card

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, Optional with mSATA

1 miniPCIe Socket: PCIe + USB, Optional with mSATA

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000, Triple Independent Display Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mS ATA 2 SATA II 3Gbps (Optional) Storage Expansion CFast Slot, External Hot-Swap, Push In/Out Ejector

Audio

Audio Codec Realtek® ALC892, 5.1 Channel HD Audio

Audio Interface Line-In, Line-Out, Mic-In, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel

82574L Gigabit LAN

Power over Ethernet

LAN3 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel® 82574L with Power On/Off Control LAN4 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

LAN5 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

LAN6 Gigabit IEEE 802.3at (25.5W / 48V) PoE Ports by Intel

82574L with Power On/Off Control

Power

Other

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Random: 0.5Grms @5~500 Hz according to IEC68-2-64

Sinusoidal: 0.5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 20 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS, EN50155 & EN50121-3-2

Product Introduction

©Rugged Science PONS vX-series User Manual

1.3 Supported CPU List

Rugged Science PONS vX series accepts 3rd generation Intel® i7/i5/i3 processors via a rPGA988B CPU socket. The following processors have been tested by Rugged Science, LLC for compatibility with PONS vX series . Instead of i7-3610QE, i5-3610ME and i3-3120ME, You may also select other processor according to your consideration of application and performance.

Series Max. TDP iAMT Embedded

i7 3840QM 45W

√

3820QM 45W

√

3740QM 45W

√

3720QM 45W

√

3632QM 35W 3630QM 45W 3612QM 35W

3610QE 45W

√

3610QM 45W 3540M 35W

√

3520M 35W

√

i5 3610ME 35W

√

3380M 35W

√

3360M 35W

√

3340M 35W

√

3320M 35W

√

3230M 35W 3210M 35W

i3 3130M* 35W

3120ME 35W O

3120M* 35W 3110M* 35W

The processors with

"O"

are listed in Intel® Embedded

Roadmap and with a 7-year life cycle support (from 2011 to 2017). The processors with "*" the maximum operation

temperature is 55OC.

Product Introduction

1.4 Mechanical Dimension

Figure 1.1 PONS v8610 & PONS v8620 Dimension

Unit: mm (inch)

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

Getting to Know Your PONS vX

2.1 Packing List

2.2.1 Audio Jacks

The PONS vX series offers stereo audio connector of MIC , Line_In and Line_Out. The audio chip controller is by

ALC892 which is compliant with the Intel® Azalia standard. To utilize the audio function in Windows, you need to install corresponding drivers for both Intel QM77 chipset and Realtek ALC892 codec. Please refer to Section 4 for information of driver installation.

2.2 Front Panel I/O Functions

Item Description Qty

PONS vX fanless controller (According to the configuration you order, the PONS vX may contain HDD and DDR3 SO-DIMM. Please verify these items if necessary.)

2 Accessory box, which contains

•

Rugged Science Drivers & Utilities DVD

• Wall-mounting bracket

• M4 screws for wall-mounting bracket

• 4-pin pluggable terminal block

1 2 4 2

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

2.2.2 Dual USB 3.0

The PONS vX series comes with 2 USB 3.0 hosts on the front panel and 2 hosts on the rear panel. These USB 3.0 ports allow data transfers

up to 5 Gb/s. The controller supports SuperSpeed (SS), high-speed (HS), full-speed (FS) and los-speed (LS) traffic on the

bus.

2.2.3 Dual USB 2.0

The PONS vX series comes with 2 USB 2.0 hosts on the

front panel. The USB interface supports Plug and Play, which enables you to connect or disconnect a device whenever you want, without turning off the system. The hosts can be used for an external flash disk or hard drive for storing large amounts of data. You can also use these USB hosts to connect to a keyboard or a mouse. The following diagram shows the pinouts for USB1 and USB2 port.

Pin Number 1 2 3 4

USB1 +5V USB1- USB1+ GND USB2 +5V USB2- USB2+ GND

1 2 3 4

CFast

Reset DVI-D

VGA

LAN2 LAN1

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.2.4 10/100/1000 Mbps Ethernet Ports

The 10/100/1000 Mbps Ethernet LAN ports 1 and 2 use 8-pin RJ-45 connector. LAN1 is equipped with Intel 82579LM for AMT function. LAN2 is equipped with Intel 82574L. Using suitable RJ-45 cable, you can connect PONS vX

series system to a computer, or to any other piece of equipment that has an Ethernet connection, for example, a hub or a switch. Moreover, both of them have Wake-on-LAN and Preboot Execution Environment capabilities. The following diagram shows the pinouts for LAN1 and LAN2 port.

Pin No. 10 / 100 Mbps 1000 Mbps

1 E_TX+ MDI0_P 2 E_TX- MDI0_N 3 E_RX+ MDI1_P 4 ---- MDI2_P 5 ----- MDI2_N 6 E_RX- MDI1_N 7 ----- MDI3_P 8 ------ MDI3_N

The Ethernet ports use standard RJ-45 jack connectors with LED indicators on the front side to show Active/ Link status and Speed status. The LED indicators on the right bottom corners glow a solid green color when the cable is properly connected to a 100 Mbps Ethernet network. The LED indicator on the left bottom corner will flash on and off when Ethernet packets are being transmitted or received. The LED indicators on the right bottom corners glow a solid orange color when the cable is properly connected to a 1000 Mbps Ethernet network. The LED indicator on the left bottom corner will flash on and off when Ethernet packets are being transmitted or received.

1 8

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

Location 10 Mbps 100 Mbps 1000 Mbps

Right Bottom

LED

off Solid Green Solid

Orange

Left Bottom

LED

Flash Yellow Flash Yellow Flash Yellow

2.2.5 Dual Display Port

Each digital port is capable of driving resolutions up to 2560x1600 at 60 Hz through Display Port.

2.2.6 DVI-D/HDMI Connector

The DVI-D connector on the front panel supports both DVI and HDMI operation mode. This connector can either output DVI signals or HDMI signal. The DVI output mode supports up to 1920x1200 resolutions and HDMI output mode supports up to 1920x1200 resolutions. The DVI or HDMI mode is automatically selected according to the display device connected. You shall need a DVI-D to HDMI cable when connecting to a HDMI display device.

CFast

Reset DVI-D

VGA

LAN2 LAN1

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.2.7 VGA Connector

The PONS vX series comes with a DB15 female connector on

the front panel to connect a VGA monitor. To ensure that the monitor image remains clear, be sure to tighten the monitor cable after connecting it to the PONS vX series . The VGA output mode supports up to 1920x1200 resolutions. The pin assignments of the VGA connector are shown below.

No.

Description

1 Red Color Signal 2 Green Color Signal 3 Blue Color Signal 4 NC 5 Ground 6 VGA Detect 7 Ground 8 Ground

9 VCC 10 Ground 11 NC 12 DDC-DATA 13 H-Sync. 14 V-Sync. 15 DDC-CLK

5 10 15

1 6

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

2.2.8 PWR and HDD LED Indicators

Yellow-HDD LED: A hard disk / CFast LED. If the LED is on, it indicates that the system’s storage is functional. If it is off, it indicates that the system’s storage is not functional. If it is flashing, it indicates data access activities.Green-Power LED: If the LED is solid green, it indicates that the system is powered on.

2.2.9 CFast Card

The PONS vX series system comes with a CFast socket on the front panel for Type-I / Type-II Compact Flash card. It is implemented by a SATA II Port from QM77 PCH. Be sure to disconnect the power source and unscrew the CFast socket cover before installing a CFast card. The PONS v8600-PoE does not support the CFast hot swap and PnP (Plug and Play) functions. It is necessary to remove power source first before inserting or removing the CFast card. The following table shows the pinouts for CFast port:

Pin No. Description Pin No. Description Pin No. Description

S1 GND PC2 GND PC10 NC

S2 SATA_TX_P2 PC3 NC PC11 NC S3 SATA_TX_N2 PC4 NC PC12 NC S4 GND PC5 NC PC13 +3.3V S5 SATA_RX_N2 PC6 NC PC14 +3.3V S6 SATA_RX_P2 PC7 GND PC15 GND S7 GND PC8 NC PC16 GND PC1 NC PC9 CFAST_LED_NPC17 NC

CFast

Reset DVI-D

VGA

LAN2 LAN1

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

It is a hardware reset switch. Use this switch to reset the system without turning off the power. Momentarily pressing the switch will activate a reset.

2.2.10 Power Button

The power button is a non-latched switch with dual color LED (Blue/Orange) for indication S0, S3 and S5 status. Power button dual-color LED indicator:

Status LED Display System Situation S0 Solid Blue System working S3, S5 Solid Orange Suspend to RAM, System off with

standby power

To turn on the PONS vX series, pr

ess the power

button

and

the blue LED is lighted up. To turn off the PONS vX series, you can either issue a shutdown command in OS, or just simply press the power button.

In case of system halts, you can press and hold the power button for 4 seconds to compulsorily shut down the system.Please note that a 4 seconds interval is kept by the system between two on/off operations (i.e. once turning off the system, you shall wait for 4 seconds to initiate another power-on operation).

2.2.11 Reset Tact Switch

CFast

Reset DVI-D

VGA

LAN2 LAN1

CFast

Reset DVI-D

VGA

LAN2 LAN1

Getting to Know Your PONS vX

2.3 Rear Panel I/O Functions

2.3.1 DC-In 6~36V Mini DIN or Power Terminal Block

The PONS vX series offers 6 to 36 VDC power input with the terminal block. If the power is supplied properly, the Power LED will light up a solid green.

80V power surge protection is design in in LTC4356. Grounding and write routing help limit the effects of noise due to EMI. Run the ground connection from the ground screw to the grounding surface prior to connecting the power.

See the gure shown below for the location of the earth

ground on the terminal block power connector. Connect the earth ground wire to an appropriate grounded metal surface.

2.3.2 Remote Power On/Off Switch

It is a 2-pin power-on or power-off switch through Phoenix Contact terminal block. You could turn on or off the system power by using this contact. This terminal block support dual function of soft power-on / power-off (instant off or delay 4 second), and suspend mode.

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.3.3 Serial Port COM2

Serial port 2 can be congured for RS-232, RS-422, or

RS-485 with auto flow control communication. Serial Port 2 default setting is RS-232, if you want to use RS-

422 or RS-485, you can nd the setting in BIOS.

BIOS Setting Function

COM2

RS-232 RS-422 (5-wire) RS-422 (9-wire) RS-485

RS-485 w/z auto-ow control

The pin assignments are shown in the following table:

Serial Port

Pin No.

RS-232 RS-422

(5-Wire)

RS-422 (9-Wire)

RS-485 (3-Wire)

1 DCD TXD- TXD- DATA2 RXD TXD+ TXD+ DATA+ 3 TXD RXD+ RXD+ ----------4 DTR RXD- RXD- ----------5 GND GND GND GND 6 DSR ----------- RTS- ----------7 RTS ----------- RTS+ ----------8 CTS ----------- CTS+ ----------9 RI ----------- CTS- -----------

Getting to Know Your PONS vX

2.3.4 Serial Port COM1, COM3 & COM4

COM1, COM3 and COM4 are RS-232 only and provideup to 115200 bps baud rates. The pin assignments are shown in the following table:

BIOS Setting Pin No. Function

COM1, COM3, COM4

1 DCD 2 RXD 3 TXD 4 DTR 5 GND 6 DSR 7 RTS 8 CTS 9 RI

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.3.5 Isolated 8 DI / 8 DO

The PONS vX series offers an 16-bit DIO ( 8-DI / 8-DO) connector. Each bit of DI and DO equipped with a photo-coupler for isolated protection. A power buffer device TPD2007F

integrated in 8-DO circuit for

motors, solenoids, and lamp drivers applications.

Pin No. Denition Mapping to SIO GPIO

Function 1 INPUT0 SIO_GPI50 2 INPUT 1 SIO_GPI51 3 INPUT 2 SIO_GPI52 4 INPUT 3 SIO_GPI53 5 INPUT 4 SIO_GPI54 6 INPUT 5 SIO_GPI55 7 INPUT 6 SIO_GPI56 8 INPUT 7 SIO_GPI57 9 DI_COM 10 GND 11 OUTPUT0 SIO_GPO20 12 OUTPUT 1 SIO_GPO21 13 OUTPUT 2 SIO_GPO22 14 OUTPUT 3 SIO_GPO23 15 OUTPUT 4 SIO_GPO24 16 OUTPUT 5 SIO_GPO25 17 OUTPUT 6 SIO_GPO26 18 OUTPUT 7 SIO_GPO27 19 N.C. 20 External 24VDC Input

Getting to Know Your PONS vX

GPI SINK Mode

olated GPI input circuit in SINK mode (NPN) is

illustrated as follows.

GPI SOURCE Mode

Digital GPI input signal circuit in SOURCE mode (PNP) is illustrated as follow:

GPO SINK Mode:

Digital GPO output circuit in SINK mode (NPN)

illustrated below.

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.3.6 PoE, Power over Ethernet Ports

PONS vX

series is equipped with 4 IEEE 802.3at PoE+

ports for

transmitting power as much as 25.5W /

48V per port

and 1000BASE-T gigabit data signals

over standard Ethernet CAT-5/CAT-6 cable.

Every PoE port applies one Intel® 82574L Gigabit Ethernet controller and independent PCI express interface to connect with multi-core processor for network and data transmit optimization.

Only when PoE port starts to supply power to power devices , the dedicated LED will be light on.

Getting to Know Your PONS vX

Figure 2.3.1 Internal Connectors and Jumpers

2.4 Main Board Expansion Connectors

The figure below is the top view of the PONS vX series

main board. It shows the location of the connectors.

CN13

CN12

CN18

CN17

CN19

CN30

BIOS

CN22

CN7 CN10

CN8

CN11

FAN1

BATTERY

CN15

CN20

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

The figure below is the bottom view of the PONS vX series main board.

AT35

AT1

QM77

CPU Socket

Super I/O

TPM

Getting to Know Your PONS vX

2.4.1 J4 Miscellaneous Pin Header

These pin headers can be used as a backup for the following functions: hard drive LED indicator, reset button, power LED indicator, and power-on/off button. The front and top panel already provides access to these functions. The following table shows the pinouts for Miscellaneous port:

J4 Miscellaneous Pin Header

Group Pin No. Description HDD LED 1 HDLED

3 HD_LED_N

Reset Button 5 FP_RST_BTN_N

7 GND

Power LED 2 PWRLED

4 PWROK_100MS_N

Power Button 6 FP_PWR_BTN_N

8 GND

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

The PONS vX series supports dual-channel 24-bit LVDS panel up to 1366x768 pixels resolution.

Pin No.

Denition

CN15 Channel A CN20 Channel B 1 LDDC_CLK LDDC_CLK 2 LDDC_DATA LDDC_DATA 3 PANEL_VDD

(+3.3V or +5V by jumper)

PANEL_VDD

(+3.3V or +5V by jumper) 4 LA_ DATA0_P LB_ DATA0_P 5 LA_ DATA3_P LB_ DATA3_P 6 LA_ DATA0_N LB_ DATA0_N 7 LA_ DATA3_N LB_ DATA3_N 8 PANEL_VDD

(+3.3V or +5V by jumper)

PANEL_VDD

(+3.3V or +5V by jumper) 9 GND GND

2.4.2 CN15, CN20, J2 LVDS

CN15

CN20

Getting to Know Your PONS vX

Pin No.

Denition

CN15 Channel A CN20 Channel B 10 LA_ DATA1_P LB_ DATA1_P 11 LA_ CLKP LB_ CLKP 12 LA_ DATA1_N LB_ DATA1_N 13 LA_ CLKN LB_ CLKN 14 GND GND 15 GND GND 16 PANEL_BACKLIGHT

(+12V)

PANEL_BACKLIGHT

(+12V) 17 LA_ DATA2_P LB_ DATA2_P 18 PANEL_BACKLIGHT

(+12V)

PANEL_BACKLIGHT

(+12V) 19 LA_ DATA2_N LB_ DATA2_N 20 GND GND

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

The LCD inverter is connected to J2 via a JST 7-pin,

2.5mm connector to provide +5V/+12V power to the LCD display.

Pin No. Denition 1 +5V 2 +12V 3 +12V 4 LBKLT_CTL 5 GND 6 GND 7 LBKLT_EN

Getting to Know Your PONS vX

The PONS vX series features 2 high performance Serial ATA III interfaces that ease cabling to hard drives or SSD with thin and short cables while application need larger storage capacity.

Pin No. Denition 1 GND 2 TXP 3 TXN 4 GND 5 RXN 6 RXP 7 GND

2.4.3 CN7, CN8 SATA3 & CN11 SATA Power Connector

CN7

CN8

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

The PONS vX series is also equipped one SATA power connector. It supplies 5V (2A max.) and 12V (1A max) current to the hard drive or SSD.

CN11 SATA HDD Power Connections

Pin No. Denition 1 +12V 2 GND 3 GND 4 +5V

CN11

Getting to Know Your PONS vX

2.4.4

CN10 SATA-II Connector J3 SATA DOM Power

Connector

The PONS vX series features one SATA-II interface while applications need SATA DOM.

Pin No. Denition 1 GND 2 TXP 3 TXN 4 GND 5 RXN 6 RXP 7 GND

CN10

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

The PONS vX series is also equipped one SATA DOM power connector. It supplies 5V (0.5A max.) current to the SATA DOM.

J3 SATA DOM Power Connections

Pin No. Denition 1 +5V 2 GND

Getting to Know Your PONS vX

2.4.5 J1 Internal USB Dual Port

The PONS vX series’ main board provides up to two USB plug-and-play ports for Dongle Key or LCD touch Panel using. The USB interface supports 480 Mbps transfer rate which complies with high speed USB specification Rev. 2.0, and fuse protection. The USB interface is accessed through one 1x6-pin JST 2.0mm connector. You will need an adapter cable if you use a standard USB connector. The adapter cable has a 1x6-pin connector on one end and a USB connector on the other.

Pin No. Denition Pin No. Denition 1 USB_VCC 2 USBD23 USBD2+ 4 USBD35 USBD3+ 6 GND

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.4.6 CN17, CN22 Mini-PCIe, mSATA Connectors

Both mSATA and Mini PCI-E share the same formfactor and similar electrical pinout assignments on their connectors. There was no clear mechanism to distinguish if a mSATA drive or a Mini PCI-E device is plugged into the socket until recently that SATA-IO

issued an ECN change (ECN #045) to re-dene pin 43

on mSATA connector as “no connect” instead of “return current path” ( or GND).

When an mSATA drive is inserted, its pin 43 is “no connect”, and the respective pin on the socket is being pulled-up to logic 1. When a Mini PCI-E device is inserted, its pin 43 forces the respective pin on the socket to ground, or logic 0.

CN17

CN22

Getting to Know Your PONS vX

PONS vX series is using Pin 43 status designed for switching between mSATA drive and mini PCI-e device.

Status Mini PCI-e card mSATA drive

Pin 43 Logic 0 Logic 1

CN22 Mini-PCIe Connector Pin Out

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

51 Reserved 52 +3.3Vaux 33 PETp0 34 GND

49 Reserved 50 GND 31 PETn0 32 SMB_DATA 47 Reserved 48 +1.5V 29 GND 30 SMB_CLK 45 Reserved 46 Reserved 27 GND 28 +1.5V 43 Status 44 Reserved 25 PERp0 26 GND 41 +3.3Vaux 42 Reserved 23 PERn0 24 +3.3Vaux 39 +3.3Vaux 40 GND 21 GND 22 PERST# 37 GND 38 USB_D+ 19 Reserved 20 reserved 35 GND 36 USB_D- 17 Reserved 18 GND

Mechanical Key 15 GND 16 Reserved 7 CLKREQ# 8 Reserved 13 REFCLK+ 14 Reserved 5 Reserved 6 1.5V 11 REFCLK- 12 Reserved 3 Reserved 4 GND 9 GND 10 Reserved 1 WAKE# 2 3.3Vaux

CN17 Mini-PCIe Connector Pin Out

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

51 Reserved 52 +3.3Vaux 33 PETp0 34 GND 49 Reserved 50 GND 31 PETn0 32 SMB_DATA 47 Reserved 48 +1.5V 29 GND 30 SMB_CLK 45 Reserved 46 Reserved 27 GND 28 +1.5V 43 Status 44 Reserved 25 PERp0 26 GND 41 +3.3Vaux 42 Reserved 23 PERn0 24 +3.3Vaux 39 +3.3Vaux 40 GND 21 GND 22 PERST# 37 GND 38 USB_D+ 19 Reserved 20 reserved 35 GND 36 USB_D- 17 Reserved 18 GND

Mechanical Key 15 GND 16 UIM_VPP 7 CLKREQ# 8 UIM_PWR 13 REFCLK+ 14 UIM_RST 5 Reserved 6 1.5V 11 REFCLK- 12 UIM_CLK 3 Reserved 4 GND 9 GND 10 UIM_DATA 1 WAKE# 2 3.3Vaux

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.4.7 CN13 GPIO

The PONS vX series offers 16 programmable I/O within TTL 5V tolerance. If the GPIO is logic high, it indicates that the mapping SIO

GPIO pin is logic high level. If the GPIO is logic low, it indicates that the mapping SIO GPIO pin is logic low level.

Pin No. Description Pin No. Description 1 GND 14 GND 2 SIO_GP17 15 SIO_GP67 3 SIO_GP16 16 SIO_GP66 4 SIO_GP15 17 SIO_GP65 5 SIO_GP14 18 SIO_GP64 6 GND 19 GND 7 SIO_GP13 20 SIO_GP63 8 SIO_GP12 21 SIO_GP62 9 SIO_GP11 22 SIO_GP61 10 SIO_GP10 23 SIO_GP60 11 GND 24 GND 12 SMB_DATA 25 +5V 13 SMB_CLK 26 +5V

CN13

Getting to Know Your PONS vX

2.4.8 FAN1

FAN power connector supports for higher thermal requirement.

Pin Out Function 1 GND 2 +12V (1.5A max) 3 Fan-speed sense

FAN1

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

CN30 Pin out

Pin Out

Function Pin

Out

Function Pin

Out

Function Pin

Out

Function

A1 Reserved A2 +12V A43 PEG_RX6P A44 PEG_RX6N A3 +12V A4 GND A45 GND A46 GND

A5 CLK_

PEGC_P

A6 CLK_

PEGC_N

A47 PEG_RX7P A48 PEG_RX7N

A7 Reserved A8 CLKREQ_

PEGA#

A49 GND A50 Reserved

A9 +3.3V A10 +3.3V A51 GND A52 PEG_RX8P A11 PLTRST_

SUMIT#

A12 GND A53 PEG_

RX8N

A54 GND

A13 CLK_

PEGA_P

A14 CLK_

PEGA_N

A55 GND A56 PEG_RX9P

A15 GND A16 PEG_RX0P A57 PEG_

RX9N

A58 GND

A17 PEG_

RX0N

A18 GND A59 GND A60 PEG_RX10P

2.4.9 CN30 PCIe x16

CN30

Getting to Know Your PONS vX

Pin Out

Function Pin

Out

Function Pin

Out

Function Pin

Out

Function

A19 CLKREQ_

PEGB#

A20 GND A61 PEG_

RX10N

A62 GND

A21 PEG_

RX1P

A22 PEG_

RX1N

A63 GND A64 PEG_RX11P

A23 GND A24 GND

A65 PEG_

RX11N

A66 GND

A25 PEG_

RX2P

A26 PEG_

RX2N

A67 GND A68 PEG_RX12P

A27 GND A28 GND

A69 PEG_

RX12N

A70 GND

A29 PEG_

RX3P

A30 PEG_

RX3N

A71 GND A72 PEG_RX13P

A31 GND A32 CLK_

PEGB_P

A73 PEG_

RX13N

A74 GND

A33 CLK_

PEGB_N

A34 GND

A75 GND A76 PEG_RX14P

A35 PEG_

RX4P

A36 PEG_

RX4N

A77 PEG_

RX14N

A78 GND

A37 GND A38 GND

A79 GND A80 PEG_RX15P

A39 PEG_

RX5P

A40 PEG_

RX5N

A81 PEG_

RX15N

A82 GND

A41 GND A42 GND

Pin Out

Function Pin

Out

Function Pin

Out

Function Pin

Out

Function

B1 +12V B2 +12V B41 PEG_TX6P B42 PEG_

TX6N B3 +12V B4 GND B43 GND B44 GND B5 SMB_CLK_

MAIN

B6 SMB_

DAT_ MAIN

B45 PEG_TX7P B46 PEG_

TX7N

B7 GND B8 +3.3V B47 GND B48 Reserved B9 Reserved B10 +3.3V_SB B49 GND B50 PEG_

TX8P B11 PCIE_WAKE# B12 Reserved B51 PEG_TX8N B52 GND B13 GND B14 PEG_

TX0P

B53 GND B54 PEG_

TX9P B15 PEG_TX0N B16 GND B55 PEG_TX9N B56 GND B17 Reserved B18 GND B57 GND B58 PEG_

TX10P B19 PEG_TX1P B20 PEG_

TX1N

B59 PEG_

TX10N

B60 GND

B21 GND B22 GND B61 GND B62 PEG_

TX11P B23 PEG_TX2P B24 PEG_

TX2N

B63 PEG_

TX11N

B64 GND

B25 GND B26 GND B65 GND B66 PEG_

TX12P B27 PEG_TX3P B28 PEG_

TX3N

B67 PEG_

TX12N

B68 GND

B29 GND B30 Reserved B69 GND B70 PEG_

TX13P B31 Reserved B32 GND B71 PEG_

TX13N

B72 GND

B33 PEG_TX4P B34 PEG_

TX4N

B73 GND B74 PEG_

TX14P B35 GND B36 GND B75 PEG_

TX14N

B76 GND

B37 PEG_TX5P B38 PEG_

TX5N

B77 GND B78 PEG_

TX15P B39 GND B40 GND B79 PEG_

TX15N

B80 GND

B81 Reserved B82 Reserved

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.4.10 Battery

The PONS vX series' real-time clock is powered by a lithium battery. The battery is Panasonic BR2032 190mAh lithium battery.

BATTERY

Getting to Know Your PONS vX

2.5 Main Board Jumper Setting

The figure below is the top view of the PONS vX series main board which is the main board used in the

ONS vX series sy

stem. It shows the location of the

jumpers.

JP1

JP3

JP4

JP2

You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper, you connect the pins with the clip. To “open” a jumper, you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2 and 3. In this

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

case you would connect either pins 1 and 2, or 2 and 3.

Getting to Know Your PONS vX

2.5.1 JP2 LVDS Backlight Power Selection

JP2

JP1 provides LVDS voltage selection function, closing Pin 1, 2 is for 3.3V LVDS power input; closing Pin 2, 3 is for 5V LVDS power input.

Setting Description 1-2 +3.3V (Default) 2-3 +5V

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.5.2 JP4(A) CMOS Clear Jumper Setting

Setting Description 1-3 Normal (Default) 3-5 Clear CMOS

JP4

Getting to Know Your PONS vX

2.5.3 JP4(B) ME Clear Jumper Setting

Setting Description 2-4 Normal (Default) 4-6 Clear ME

JP4

Getting to Know Your PONS vX

©Rugged Science PONS vX-series User Manual

2.5.4 JP3 AT/ATX Power Mode Jumper Setting

The PONS vX series main board contains a jumper that can switch

the AT/ATX Power Setting. Normally this jumper should be set with Pin 4 and Pin 6 in ATX power mode. And power on the system by the 2-pin terminal block at the top panel. If you set it with Pin 2 and Pin 4 in AT power mode. It will send the power button signal to power on the system automatically

Setting Description 1-2 AT Mode 2-3 ATX Mode (Default)

JP3

Getting to Know Your PONS vX

2.5.5 JP1 PCIe Bifurcation Jumper Setting

JP1

CFG [ 6 : 5 ]

PCIe Port bifurcation Straps 11 : (Default) x16 - Device 1 functions 1 and 2 disabled 10 : x8, x8 - Device 1 functions 1 enabled ; function 2 disabled 01 : Reserved - (device 1 functions 1 disabled ; function 2 enabled) 00 : x8, x4, x4 - Device 1 functions 1 and 2 enabled

JP1 PCIe Bifurcation (2-4) (1-3) x16 (Default) (2-4) (3-5) x8, x8 (4-6) (1-3) Reserved (4-6) (3-5) x8, x4, x4

System Setup

©Rugged Science PONS vX-Series User Manual

System Setup

3.1 Install DDR3 / DDR3L SODIMM Modules

Remove the “back panel” and you can see a SATA cable and DDR3 SODIMM socket exposed.

Step2.

Put the PONS vX series

upside down on a 

surface. First, to loose the front panel screw and the rear panel screw by bare hands, and use a Philips screwdriver to loose 4 M3

at-head

scre

ws on

the “back

panel”.

Step1.

System Setup

As it’s firmly contacted with socket connectors, press it down until the clamps of the socket snap into the latching position of SODIMM module.

Tile the SODIMM module and insert it to the SODIMM socket.

Step3.

3.2 Install HDD

Remove the “back panel” and you can see a SATA cable and DDR3 SODIMM socket exposed.

Step2.

Put the PONS vX series

upside down on a at

surface. First, to loose the front panel screw and the rear panel screw by bare hands, and use a Philips screwdriver to loose 4 M3

at-head screws on the “back

panel”.

Step1.

System Setup

Find the M3 screws (8pieces) in the accessory box. And prepare one SSD or HDD by your own.

Step3.

Place the HDD into the bracket and gently push it down to make it contact with thermal pad. Use a Philips screwdriver to fix the HDD with four M3 screws.

Step4.

Pull out the SATA cable inside the chassis and connect it to HDD.

Step5.

System Setup

3.3 Install MiniPCIe Cards

There are 2 Mini-PCIe sockets on the main board. Choose one of Mini-PCIe socket to put your mini-PCIe card in.

Step2.

Put the PONS vX series

upside down on a at

surface. First, to loose the front panel screw and the rear panel screw by bare hands, and use a Philips screwdriver to loose 4 M3

lat-head screws on the “back

panel”.

Step1.

Using 2 BH-M2.5X6 screws to lock your mini-PCIe card

rmly. Then you can re-screw

the back panel as the first step.

Step3.

System Setup

3.4 Install SATA DOM

Preparing your SATA DOM

and nding a SATA DOM

connectors on the main board.

Step2.

Put the PONS vX series

upside down on a at

surface. First, to loose the front panel screw and the rear panel screw by bare hands, and use a Philips screwdriver to loose 4 M3

lat-head scre

ws on the “back

panel”.

Step1.

System Setup

Selecting one of the SATA DOM connector and plug in your SATA DOM.Then you can re-screw the back panel

as the rst step.

Step3.

System Setup

3.5 Install PCI or PCIe Card

Put the PONS vX series

upside down on a at

surface. First, to loose the front panel screw and the rear panel screw by bare hands, and use a Philips screwdriver to loose 4 M3

lat-head scre

ws on the “back

panel”.

Step1.

There is one PCI/PCIe socket on the main board.

Step2.

Remove the PCI/PCIe dummpy bracket.

Step3.

System Setup

Insert the PCIe/PCI card right on the socket.Then you can re-screw the back panel as

the rst step.

Step4.

System Setup

Find your wall-mounts brackets (2 pieces)in the accessory box.

Step2.

Fix two wall-mount brackets to the chassis with four M4 screws using a Philips screwdriver.

Step3.

3.5 Mount Your PONS vX series

PONS vX series is shipped with wall-mount brackets. You can mount your PONS vX series on the wall by following the steps listed below.

Put the PONS vX series

upside down on a at

surface. Use a Philips screwdriver to loose screw on the back side.

Step1.

System Setup

Installation Method 1

Installation Method 2

BIOS and Driver

4.1 BIOS Settings

The board uses UEFI BIOS that is use Serial Peripheral Interface (SPI) Flash. The SPI Flash contains the BIOS

Setup program, POST, the PCI auto-conguration utility,

LAN, EEPROM information, and Serial port support. The BIOS setup program is accessed by pressing the <Del> key after the Power-On Self-Test (POST) memory test begins and before the operating system boot begins. The menu bar is shown below.

Figure 4.1: BIOS Menu Bar

BIOS and Driver

4.1.1 Main Menu

Figure 4.2: BIOS Main Screen

System Time / Date : Press “TAB” key to switch sub-items of value .Then press “ +” key or “-“ key number key for modify value.

4.1.2 Advanced Function

Figure 4.3: ACPI Setting Setup Screen

Enable ACPI Auto Conguration: This system support ACPI function as auto process. You should Enable / Disable that depend as your O.S.

BIOS and Driver

Figure 4.4: Trusted Computing Setup Screen

Security Device Support : Enables or Disables BIOS support for security device. O.S. will now show Security Device. TCG EFT protocol and INT1A interface will not be available.

Current Status Information :

Show as below option

SUPPORT TURNED OFF SUPPORT TURNED ON

Figure 4.5: Trusted Computing Setup Screen

Intel Virtualization Technology : For Virtualization Application or platform usage, when enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology,

BIOS and Driver

Figure 4.6: SATA Conguration Setup Screen

SATA Controller(s) :

Enables or Disables integrate SATA controller for Storage device use.

SATA Mode Selection :

Determines how the SATA transfer mode for operate. Here have three option for choice [IDE] / [AHCI] / [RAID]. For the RAID mode operate, please see appendix E. for detail information.

Serial Port 0~5 :

This system offers six SATA port for connection SATA device.

Advanced->IT8783F Super IO Conguration->Serial Port 1

Figure 4.7: Serial Port 1Setup Screen

Serial Port :

Enable or Disable Serial Port .

BIOS and Driver

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11;

Advanced->IT8783F Super IO Conguration->Serial Port 2

Figure 4.8: Serial Port 2 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11;

Interface Mode:

Here have 4 option : RS-232 Mode RS-422 Mode RS-485 Mode

BIOS and Driver

Advanced->IT8783F Super IO Conguration->Serial Port 3

Figure 4.9: Serial Port 3 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11; IO=2F0h; IRQ=6; IO=2E0h; IRQ=7;

Advanced->IT8783F Super IO Conguration->Serial Port 4

Figure 4.10: Serial Port 4 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

BIOS and Driver

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11; IO=2F0h; IRQ=6; IO=2E0h; IRQ=7;

4.1.3 Chipset Function

Phoenix SecureCore(tm) Setup Utility

Main Advanced Chipset Boot Security Save & Exit

WOL conguration

Chipset->PCH-IO Conguration->Wake on LAN

Figure 4.11: Network Setup Screen

PCH LAN Controller : Enable or Disable Serial Port .

Wake on LAN : Enable or Disable integrated LAN to wake the system.

This function also can active by O.S.

Power Loss Conguration

Chipset->PCH-IO Conguration->Restore AC Power Loss

Figure 4.12: Power Loss Setu Screen

BIOS and Driver

PCH LAN Controller :

[Power Off ] : When plug-in the power source , system will keep on SB mode. [Power On ] : When plug-in the power source , system will auto booting . [Last State ] : When plug-in the power source , system will keep on last power status.

4.1.4 Boot Function

Boot Option

Chipset->PCH-IO Conguration->Wake on LAN

Figure 4.13 Boot Setup Screen

Boot option : When you press “Enter” , you can select which device you would like to boot.

4.2 Operating System

Linux :

Ubuntu 10.04LTS or Above Fedora 13 or Above And another Linux kernel 2.6.33 and RHL6.0

(* The Linux kernel of RHL , please check RadHat website rst

)

Windows :

Windows XP Windows 7 Home/Professional/MediaCenter/ Windows 8 ( Do not support RT version) Windows Server 2008 R2 Windows Server 2012

BIOS and Driver

4.3 Driver Installation

After you setup all hardware and rmware device, you should

install the correspond Software driver then active O.S process. When you start to install the driver , please make sure you have administrator ID for system authenticate.

Please follow below sequence for driver install

1. Intel Chipset

2. Intel HD 4000 Graphics

3. Network Device – Include 85574L and 82579LM

4. Audio Driver

5. USB 3.0 support

6. Storage: Include “ACHI” driver and Intel Rapid Storage Software.

7. AMT function of Intel ME(Management Engine)

Find the driver install le

• Windows 7 64bit version :

The Chipset driver location is : [CD]:\Win7\64bit\

ChipsetDriver\

Step1.

4.3.1 Chipset Driver Installation

This device software installs all components of ECS-7000 platform chipset to the system target system. After install this software, please ensure that as following features function properly:

1. PCIe / PCI . ISAPNP services cong.

2. IDE/ACHI storage interface Support

3. USB Support

4. Identification of Intel Chipset Components in the Device Manager.

Install instruction:

Execute and install the files which matches your operation system. Instruction windows will pop-up when you start to setup the driver, please follow it and complete the setup processes.

Step2.

Step3.

Once you completed the Intel Chipset Driver setup, please reboot your system , all update function will be active on next time into Windows.

BIOS and Driver

Find the driver install le

• Windows 7 64bit version :

The Graphics driver location is : [CD]:\Win7\64bit\ VGADriver\

Step1.

4.3.2 Intel HD 4000 Graphics Driver Installation

This driver will install following features or function properly:

- Display serive

- High denition Audio support

Install instruction:

Execute and install the files. Instruction windows will pop-up when you start to setup the driver, please follow it and complete the setup processes.

Step2.

Step3.

Once you completed the HD Graphics Driver Driver setup, please reboot your system , all update function will be active on next time into Windows.

Find the driver install le

• Windows 7 64bit version :

The network driver location is : [CD]:\Win7\64bit\LanDriver\

Step1.

4.3.3 Network Device Driver Installation

This driver will install following features or function properly:

- LAN 1 : Intel 82579LM network device

- LAN 2~ LAN 6 : Intel 82574L network device.

( Please ensure your LAN port number)

Install instruction:

Execute and install the files. Instruction windows will pop-up when you start to setup the driver, please follow it and complete the setup processes.

Step2.

BIOS and Driver

Step3.

Once you finish the LAN device Driver setup , the LAN connection will loss for a while and then restart automatically.

Step4.

If you need active AMT function as well , please refer to the section of “AMT driver install”.

Find the driver install le

The Audio driver location is : [CD]:\Win7\64bit\Audio\

Step1.

4.3.4 Audio Driver Installation

This driver will install Realtek High definition device software and Utility.

Execute the install le and start to install it.

Step2.

Step3.

Once you finish the Audio device Driver setup ,please reboot your system , all update function will be active on next time into Windows.

Find the driver install le

USB 3.0 driver location is : [CD]:\Win7\64bit\USB3.0

Step1.

4.3.5 USB 3.0 Driver Installation

This driver will install USB 3.0 device support software.

Execute the install le and start to install it.

Step2.

Step3.

Once you nish the USB3.0 device Driver setup ,please reboot your system , all update function will be active on next time into Windows.

BIOS and Driver

Find the driver install le

Intel Rapid software location is : [CD]:\Win7\64bit\Storage

Step1.

4.3.6 Storage Support Software Installation

Installing the Intel Rapid software This driver will install following features or function properly:

Execute the install le and start to install it.

Step2.

Step3.

Once you nish the Rapid software setup ,please reboot your system , all update function will be active on next time into Windows.

This function only use on AHCI mode.

- Software panel for SATA device Utilities for RAID volume creating.

CAUTION!

4.3.7 Intel AMT Function Support

This driver will install following features or function properly:

- Intel ME (Management Engine) support

- Intel AMT software panel

- SOL(Serial on LAN) device driver .

Find the driver install le

The Chipset driver location is : [CD]:\Win7\64bit\LanDriver\ME

Step1.

Execute the install le and start to install it.

Step2.

Step3.

Once you nish the AMT function setup ,please reboot your system , all update function will be active on next time into Windows.

Appendix A

Description:

Initialize hardware and resources, and get number of functional borads.

Syntax:

I16 _mnet104_open ()

Argument:

Name Type Description N/C

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other Please reference to the Appendix error table.

Description:

Get the local DI value.

Syntax:

I16 _mnet104_read_port( U16 Offset, U8 *Val )

Argument:

Name Type Description Offset U16 Pointer the access DI port address Val [output] U8 * Return the value of local input interface.

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other Please reference to the Appendix error table.

Description:

Get the local DI value.

Syntax:

I16 _mnet104_write_port( U16 Offset, U8 Val )

Appendix A : Isolated DIO Guide

Appendix A

Argument:

Name Type Description Offset U16 Pointer the access DI port address Val U8 Write the value of local input interface.

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other Please reference to the Appendix error table.

Appendix B 68

The GPIO& WDT are using internal Super IO function.

However, you must entry super I/O conguration mode to set

it. The output port is set as GPIO 1 on CN13 , reg. index = 0x60 The input port is set as GPIO 4 on CN12 , reg. index = 0x62.

Super I/O special address port = 0x2E

Super I/O special data port = 0x2F

GPIO Logical device is 0x07

//write twice 0x87 value.

outportb(Super I/O special address port, 0x87); outportb(Super I/O special address port, 0x01); outportb(Super I/O special address port, 0x55); outportb(Super I/O special address port, 0x55);

//write 0x07 on Reg [0x07] , this setup must follow Step A. that can be workable.

outportb(Super I/O special address port, 0x07); outportb(Super I/O special data port, 0x07);

Base control for write Super I/O register.

outportb(special address port, Register Index.); outportb(special data port, update_value);

Base control for read Super I/O register

outportb(special address port, Register Index.); inportb(special data port); //It will return a BYTE value.

Please refer to source code for set_data() and get_data() function.

Write data to GPO(output) port

set_data( Register Index , update_value);

example : unsigned char data = 0x82; set_data( 0xE5 , data); //Set bit 7 & bit 1 of GPO output port as High level ,another bit is Low

A. Entry MB PnP Mode

B. Located on Logical Device 7

C. Access the Super I/O Register

D. Access the PONS vX Series GPIO Port

ppendix B : GPIO & WDT Function

Appendix B

Please refer to source code for set_data() and get_data() function.

Read data to GPI(input) port

get_data( Register Index ) //It will return a BYTE value. example : unsigned char data get_data( 0xF1 , data); //Get GPI(input) port status on input_data variable.

Refer to GPIO setting of Step A and B. , located Logical 0x08 for WDT function.

Reg [0x30] is WatchDog ON/OFF control.

WatchDog On : set_data( 0x30 , 0x01); WatchDog Off : set_data( 0x30 , 0x00);

Reg [0xF0] is WatchDog timer - counterON/OFF control.

WatchDog counter start : set_data( 0xF0 , 0x02); WatchDog counter start : set_data( 0xF0 , 0x00);

Reg [0xF1] is WatchDog time-out value, "Reading" this register returns the current value in the Watch Dog Counter, not the Watch Dog Timer Time-out value.

WatchDog time-out value : set_data( 0xF1 , );

E.WDT ON/OFF and Timer-Counter setting

Rugged Science PONS vX-Series User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
