Rugged Science Cortex vX series User Manual

Rev1.0.3 11/13/2013

All information is subject to change without notice from Rugged Science.

Technical Support and Product Information www.RuggedScience.com

Rugged Science Corporate Headquarters 53 Loveton Circle, Suite 203, Sparks, Maryland 21152 United States of America

Toll-Free: 1.855.769.9747 Email: sales@ruggedscience.com

For further support information, refer to the Technical Support and Professional Services appendix. To comment on Rugged Science documentation, refer to the Rugged Science web site at www.RuggedScience.com. © 2014 Rugged Science, LLC. All rights reserved.

Record of Revision

Version Date Page Description Remark

V1.00 March 05, 2013 All Perliminary Release V1.01 March 07, 2013 P8 CPU List V1.02 Oct 04, 2013 V, 2, 3, 12, 13

Models Added

V1.03 Nov 13, 2013 V, 4, 15, 29, 62-64

Models Added

iv

©

Rugged Science - Cortex vx-Series Embedded System User Manual

T

his manual is intended to be used as a practical and informative guide only and is subject to change without prior notice. Rugged Science shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use.

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC

The product(s) described in this manual complies with all applicable European Union (CE) directives if it has a CE marking. For computer systems to remain CE compliant, only CE-compliant parts may be used. Maintaining CE compliance also requires proper cable and cabling techniques.

CE

This document contains proprietary information protected by copyright. All rights are reserved. No part of this document may be reproduced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer. Company/product names mentioned herein are used for identication

Disclaimer

Declaration of Conformity

Copyright and Trademarks

v

Order Information

Optional Accessories

Part Number Description

v7090S

9 GbE LAN Fanless Embedded Controller, 2 HDD, Isolated DIO, SUMIT (A, B), iAMT 8.0

v7090

9 GbE LAN Fanless Embedded Controller, 2 HDD, Isolated DIO, iAMT 8.0

v7460F

6 GbE LAN - 6 Copper & 2 Fiber ST Sockets Fanless Embedded Controller, 2

HDD

v7060S

6 GbE LAN Fanless Embedded Controller, 2 HDD, Isolated DIO, SUMIT (A, B), iAMT 8.0

v7060D

6 GbE LAN Fanless Embedded Controller, 2 HDD, Isolated DIO, iAMT 8.0

v7062

6 GbE LAN Fanless Embedded Controller, 2 Front Panel Access Removable HDD with Key Lock, iAMT 8.0

v7060

6 GbE LAN Fanless Embedded Controller, 2 HDD, iAMT 8.0

v7040

4 GbE LAN Fanless Embedded Controller, 2 HDD, iAMT 8.0

v7022

2 GbE LAN Fanless Embedded Controller, 2 Front Panel Access Removable HDD with Key Lock

v7020

2 GbE LAN Fanless Embedded Controller, 2 HDD

Part Number Description

RS-M340S-W28M1 DDR3 4GB 1333/1066MHz RAM, Wide Temperature -40°C ~ +85°C RS-KVR1333D3S9

Kingston® DDR3 4GB PC1333 RAM

RSPWA-120WM4P

120W, 24V, 90VAC to 264VAC power adapter

RS-SCSI-20P-100

20-pin SCSI Cable, 1M

RS-TMB-SCSI-20P

Terminal Board with One 20-pin SCSI Connector and DIN-Rail Mounting

vi

Table of Contents

iv iv

Declaimer Declaration of Conformity Copyright and Trademarks iv

FCC iv

iv

v

CE

Order Information Optional Accessories v

General Introduction 1

1.1 Overview 1

1.2 Product Specication 2

2 3 4 5 6 7 8 9

10

1.2.1 Specifications of Cortex v7090S

1.2.2 Specifications of Cortex v7090

1.2.3 Specifications of Cortex v7460F

1.2.4 Specifications of Cortex v7060S

1.2.5 Specifications of Cortex v7060D

1.2.6 Specifications of Cortex v7062

1.2.7 Specifications of Cortex v7060

1.2.8 Specifications of Cortex v7040

1.2.9 Specifications of Cortex v7022

1.2.10 Specifications of Cortex v7020

11

1.3 Supported CPU List 12

1.4 Mechanical Dimension 13

Getting to Know Your Cortex vX 22

2.1 Packing List 22

2.2 Front Panel I/O Functions 22

2.2.1 Audio Jacks 22

2.2.2 Dual USB 3.0 23

2.2.3 Dual USB 2.0 23 24 25 25 26 27 27 28 28

2.2.4 10/100/1000 Mbps Ethernet Ports

2.2.5 Dual Display Port

2.2.6 DVI-D/HDMI Connector

2.2.7 VGA Connector

2.2.8 PWR and HDD LED Indicators

2.2.9 CFast Card

2.2.10 Power Button

2.2.11 Reset Tact Switch

2.2.12 SFP on Cortex v7460F

29

2.3 Rear Panel I/O Functions 30

2.3.1 DC-In 6~36V Mini DIN or Power Terminal Block 30

2.3.2 Remote Power On/Off Switch 30

2.3.3 Isolated 8 DI / 8 DO 31

2.3.4 Serial Port COM2 33

2.3.5 Serial Port COM1/COM3 / COM4 33

2.4 Main Board Expansion Connectors 35

2.4.1 J1 Miscellaneous Pin Header 37

2.4.2 CN23, CN25, J4 LVDS 37

2.4.2 CN23, CN25, J4 LVDS 38

2.4.3 CN17, CN20 SATA3 & CN21 SATA Power Connector 40

2.4.4

CN13 SATA-II Connector J3 SATA DOM Power Connector 42

2.4.5 J2 Internal USB Dual Port 44

G

2.4.6 CN8, CN14 Mini-PCIe, mSATA Connectors 45

2.4.7 CN16 GPIO 47

2.4.8 FAN1 48

2.4.9 CN27, CN28 SUMIT 49

2.4.10 Battery 50

2.5 Main Board Jumper Setting 51

2.5.1 JP3 LVDS Backlight Power Selection 52

2.5.2 JP2(A) CMOS Clear Jumper Setting 53

2.5.3 JP2(B) ME Clear Jumper Setting 54

2.5.4 JP1 AT/ATX Power Mode Jumper Setting 55

System Setup 56

3.1 Install DDR3 / DDR3L SODIMM Modules 56

3.2 Install HDD 57

3.3 Install MiniPCIe Cards 59

3.4 Install SATA DOM 60

3.5 Install the SFP Module and SC cable 62

3.5.1 Hardware Installation 62

63

64

3.5.2 Software Installation

3.6 Remove the SFP Module and SC cable

3.6 Mounting Your Cortex vX

65

BIOS and Driver 67

4.1 BIOS Settings 67

4.1.1 Main Menu 68

4.1.2 Advanced Function 68

4.1.3 Chipset Function 73

4.1.4 Boot Function 74

4.2 Operating System 74

4.3 Driver Installation 75

4.3.1 Chipset Driver Installation 75

4.3.2 Intel HD 4000 Graphics Driver Installation 76

4.3.3 Network Device Driver Installation 76

4.3.4 Audio Driver Installation 77

4.3.5 USB 3.0 Driver Installation 77

4.3.6 Storage Support Software Installation 78

4.3.7 Intel AMT Function Support 78

Appendix A : Isolating DIO Guide 79

Appendix B : GPIO & WDT Function 81

81 81 81 81

A. Entry MB PnP Mode B. Located on Logical Device 7 C. Access the Super I/O Register D. Start to Access the Cortex vX GPIO Port E. WDT ON/OFF and Timer-Counter setting

82

1

Product Introduction

General Introduction

The Cortex vX-series supports 3rd Gen Intel® Core™ series processor (6M Cache, up to 3.30 GHz), DDR3L and DDR3 maximum dual channel 16GB ram, 3 independent display (DP, DVI-D, and VGA), isolated DIO, maximum 9 GbE LANs, CFast, two 2.5” SATA 6Gp/s HDD/ SSD trays, 4 COM, 4 USB 3.0 ports, JST connector, and 2 mini PCI-express. Additionally, overvoltage protection,

watchdog timer, and a Trusted Platform Module further expand the functionality of the Cortex Embedded Computer.

The Cortex is powered by a cutting-edge 3rd Gen Intel® Quad-Core™i7 Processor (6M Cache, up to 3.3 GHz). Ivy

Bridge increases power efficiency by as much as 25% and also integrates Intel's® HD 4000 graphics. An

extremely low thermal design power of 35W ensures enhanced reliability, safety and shock resistance for fanless operating environments.

Wi

th up to 9 GbE LANs, The Cortex vX-series provides

stable and speedy Ethernet at 9.6 kb/s to 1 Gb/s data transmission speeds while also supporting Ethernet Control Automation Technology (EtherCAT).

1

1.1 Overview

2

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

1.2 Product Specication

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB, 2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 Isolated DIO 8 DI, 8 DO

LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, 1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps, 1 SATA II 3Gbps - Support Horizontal Type SATA DOM

mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN7 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN8 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN9 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

1.2.1 Specifications of Cortex v7090S

3

Product Introduction

1.2.2 Specifications of Rugged Science Cortex v7090

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB, 2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, 1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps, 1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN7 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN8 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN9 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

4

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket

1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support Fiber SPF 1000Base SFP Port Based On Intel® I350 Chipset Fiber SPF 1000Base SFP Port Based On Intel® I350 Chipset

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64

Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

1.2.3 Specifications of Rugged Science Cortex v7460F

5

Product Introduction

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 Isolated DIO 8 DI, 8 DO

LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket

1 miniPCIe Socket: PCIe + USB SUMIT A, B 2 SUMIT Slots

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max.,

LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64

Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

1.2.4 Specifications of Rugged Science Cortex v7060S

6

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

1.2.5 Specifications of Rugged Science Cortex v7060D

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 Isolated DIO 8 DI, 8 DO

LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, 1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max.,

LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps, 1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

7

Product Introduction

1.2.6 Specifications of Rugged Science Cortex v7062

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, 1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps, 1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

8

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

1.2.7 Specifications of Rugged Science Cortex v7060

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket, 1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max.,

LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps, 1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN5 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN6 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

9

Product Introduction

1.2.8 Specifications of Rugged Science Cortex v7040

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket

1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN3 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support LAN4 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

10

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

1.2.9 Specifications of Rugged Science Cortex v7022

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket

1 miniPCIe Socket: PCIe + USB

JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max., LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

11

Product Introduction

1.2.10 Specifications of Rugged Science Cortex v7020

System

Processor 3rd Generation Intel® Core™ i7/i5/i3 Ivy Bridge Processors (6M Cache, up to 3.30 GHz) Chipset Intel® QM77 BIOS AMI SIO IT8783F Memory DDR3 1066/1333/1600 MHz, DDR3L 1066/1333 MHz, Max. 16GB

2 204-pin SO-DIMM Sockets

I/O Ports

Serial Interface 3 COM RS-232, 1 COM RS-232 / 485 / 422 USB 4 USB 3.0, 2 USB 2.0, 2 Internal USB 2.0 LED Power, SDD and CFast LEDs

GPIO 16 GPIO

Expansion

Mini PCIe 1 miniPCIe Socket: PCIe + USB + SIM Card Socket

1 miniPCIe Socket: PCIe + USB JST Connector 1 Internal 6-pin (Internal USB 2.0)

Graphics

Chipset Intel® GMA HD 4000 Display Memory Shared Memory, Up to 1.7GB Interface DB-15 VGA / 1920 x 1200 Max., DVI-D / 1920 x 1200 Max.,

Display Port 1 / 2560 x 1600 Max., Display Port 2 / 1920 x 1200 Max.,

LVDS / Dual Channel 24-bit / 1920 x 1200 Max.

Storage

SATA 2 SATA III 6Gbps

1 SATA II 3Gbps - Support Horizontal Type SATA DOM mSATA 2 SATA II 3Gbps Storage Expansion CFast Slot Push In / Out Ejector

Audio

Audio Codec Realtek ALC892, 5.1 Channel HD Audio

Audio Interface Line-in, Line-out, Mic-in, Front Audio Header

Ethernet

LAN1 Intel® 82579LM Gigabit LAN, Wake on LAN, PXE Support LAN2 Intel® 82574L Gigabit LAN, Wake on LAN, PXE Support

Power

Power Input 1 Mini DIN, One 3-pin Terminal Block for DC-IN : V+, V-, Frame Ground Power Input Voltage DC-IN 6 ~ 36V Power Adapter AC to DC +24V / 5A 120W Max. (Optional) Protection On-board LT4356 for Power Input High Voltage Surge Protection

Other

Trusted Platform Module (TPM) Inneon SLB9635, LPC interface (Optional) Watchdog Timer Reset: 1 to 255 sec / min Per Step HW Monitor Temperature / Voltages Auto Throttling Control When CPU Overheats

Mechanical

Chasis Construction Aluminum Housing Size (W x D x H) 260mm x 175mm x 79mm (10.2" x 6.9" x 3.1") Weight 2.8 Kg (6 lb) Mounting Wall-mount by Mounting Bracket

Environmental

Operating Temperature -25°C to 70°C (-13°F to 157°F) Storage Temperature -40°C to 85°C (-40°F to 185°F)

Humidity 10% to 95% Humidity, Non-condensing

Relative Humidity 95% at 70°C Vibration Rational: 5Grms @5~500 Hz according to IEC68-2-64 Shock Operating, 50 Grms, Half-sine 11 ms Duration (w / SSD, According to IEC60068-2-27) EMC CE, FCC, RoHS

12

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

1.3 Supported CPU List

Rugged Science Cortex vX accepts 3rd generation Intel® i7/i5/i3 processors via a rPGA988B CPU socket. The following processors have been tested by

Rugged Science for the compatibility with Rugged Science Cortex vX. Instead of i7- 3610QE, i5-3610ME

and i3-3120ME, you may also select other processors according to your specifications of application and performance.

Series Max. TDP iAMT Embedded

i7 3840QM 45W √

3820QM 45W √ 3740QM 45W √ 3720QM 45W √ 3632QM 35W 3630QM 45W 3612QM 35W

3610QE 45W √ O

3540M 35W √ 3520M 35W √

i5 3610ME 35W √ O

3380M 35W √ 3360M 35W √ 3340M 35W √ 3320M 35W √ 3230M 35W 3210M 35W

i3 3130M* 35W

3120ME 35W O

3120M* 35W 3110M* 35W

The processors with

"O"

ar

e listed in Intel® Embedded Roadmap for 7-year life cycle support (from 2011 to 2017). The processors with "*" the maximum operation

temperature is 55C.

13

Product Introduction

1.4 Mechanical Dimension

Figure 1.1 Cortex v7090S

14

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

Figure 1.2 Cotex v7090

15

Product Introduction

Figure 1.3 Cortex v7460F

16

Product Introduction

©Rugged Science Cortex vX Embedded System Series User Manual

Figure 1.4 Cortex v7060S

17

Product Introduction

Figure 1.5 Cortex v7062

18

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

Figure 1.6 Cortex v7060

19

Getting to Know Your Cortex vX

Figure 1.7 Cortex v7040

20

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

Figure 1.8 Cortex v7022

21

Getting to Know Your Cortex vX

Figure 1.9 Cortex v7020

22

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

Getting to Know Your Cortex vX

2.1 Packing List

2

2.2.1 Audio Jacks

The Cortex vXseries offers stereo audio connectors of MIC , Line_In and Line_Out. The audio chip controller is ALC892 which is compliant with the Intel® Azalia standard. To utilize the audio function in Windows, you need to install corresponding drivers for both Intel QM77 chipset and Realtek ALC892 codec. Please refer to Section 4 for information of driver installation.

2.2 Front Panel I/O Functions

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

Item Description Qty

1

Cortex vX Series fanless controller (According to the configuration you order, the Cortex vX series may contain HDD

and DDR3 SO-DIMM. Please verify these items if necessary.)

1

2 Accessory box, which contains

•

Rugged Science Drivers & Utilities DVD

• Wall-mounting bracket

• M4 screws for wall-mounting bracket

• 4-pin pluggable terminal block

1 2 4 2

23

Getting to Know Your Cortex vX

2.2.2 Dual USB 3.0

The Cortex vX series comes with 2 USB 3.0 hosts on the front panel. These USB 3.0 ports allow data transfers up to 5 Gb/s. The controller supports SuperSpeed (SS), high-speed (HS), full-speed (FS) and low-speed (LS) traffic on the bus.

2.2.3 Dual USB 2.0

The C

ortex vX series comes with 2 USB 2.0 hosts on the

front panel. The USB interface supports Plug and Play, which enables you to connect or disconnect a device whenever you want, without turning off the system. The hosts can be used for an external flash disk or hard drive for storing large amounts of data. You can also use these USB hosts to connect to a keyboard or a mouse. The following diagram shows the pinouts for USB1 and USB2 port.

Pin Number 1 2 3 4

USB1 +5V USB1- USB1+ GND USB2 +5V USB2- USB2+ GND

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

1 2 3 4

24

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.2.4 10/100/1000 Mbps Ethernet Ports

Th

e 10/100/1000 Mbps Ethernet LAN ports 1 and 2 use 8-pin RJ-45 connector. LAN1 is equipped with Intel 82579LM for AMT function. LAN2 is equipped with Intel 82574L. Using suitable RJ-45 cable, you can connect a Cortex vX system to a computer, or to any other piece of equipment that has an Ethernet connection. Both have Wake-on-LAN and Preboot Execution Environment capabilities. The following diagram shows the pinouts for LAN1 and LAN2 port.

Pin No. 10 / 100 Mbps 1000 Mbps

1 E_TX+ MDI0_P 2 E_TX- MDI0_N 3 E_RX+ MDI1_P 4 ---- MDI2_P 5 ----- MDI2_N 6 E_RX- MDI1_N 7 ----- MDI3_P 8 ------ MDI3_N

T

he Ethernet ports use standard RJ-45 jack connectors with LED indicators on the front side to show Active/Link status and Speed status. The LED indicators on the right bottom corners glow a solid green color when the cable is properly connected to a 100 Mbps Ethernet network. The LED indicator on the left bottom corner will ash on and o when Ethernet packets are being transmitted or received. The LED indicators on the right bottom corners glow a solid orange color when the cable is properly connected to a 1000 Mbps Ethernet network. The LED indicator on the left bottom corner will ash on and o when Ethernet packets are being transmitted or received.

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

1 8

25

Getting to Know Your Cortex vX

Location 10 Mbps 100 Mbps 1000 Mbps

Right Bottom

LED

o Solid Green Solid Orange

Left Bottom

LED

Flash Yellow Flash Yellow Flash Yellow

2.2.5 Dual Display Port

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

Each digital display

port is capable of driving resolutions up to 2560x1600 at 60 Hz through Display Port.

2.2.6 DVI-D/HDMI Connector

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

The DVI-D connector on the front panel supports both DVI and HDMI operation mode. This connector can either output DVI signals or HDMI signal. The DVI output mode supports up to 1920x1200 resolutions and HDMI output mode supports up to 1920x1200 resolutions. The DVI or HDMI mode is automatically selected according to the display device connected. You shall need a DVI-D to HDMI cable when connecting to a HDMI display device.

26

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.2.7 VGA Connector

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

Th

e Cortex vX series comes with a DB15 female connector on the front panel to connect a VGA monitor. To ensure that the monitor image remains clear, be sure to tighten the monitor cable after connecting it to the Cortex vX series . The VGA output mode supports up to 1920x1200 resolution. The pin assignments of the VGA connector are shown below.

Pin No. Description

1 Red Color Signal 2 Green Color Signal 3 Blue Color Signal 4 NC 5 Ground 6 VGA Detect 7 Ground 8 Ground

9 VCC 10 Ground 11 NC 12 DDC-DATA 13 H-Sync. 14 V-Sync. 15 DDC-CLK

5 10 15

1 6

11

27

Getting to Know Your Cortex vX

2.2.8 PWR and HDD LED Indicators

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

Yellow-HDD LED: A hard disk / CFast LED. If the LED is on, it indicates that the system’s storage is functional. If it is o, it indicates that the system’s storage is not functional. If it is ashing, it indicates data access activities.

Green-Power LED: If the LED is solid green, it indicates that the system is powered on.

2.2.9 CFast Card

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

The C

ortex vXseries system comes with a CFast socket on

the front panel for Type-I / Type-II Compact Flash card. It is implemented by a SATA II Port from QM77 PCH. Be sure to disconnect the power source and unscrew the CFast socket cover before installing a CFast card. The Cortex vXseries does not support the CFast hot swap and PnP (Plug and Play) functions. It is necessary to remove power source first before inserting or removing the CFast card. The following table shows the pinouts for CFast port:

Pin No. Description Pin No. Description Pin No.

Description

S1 GND PC2 GND PC10 NC S2 SATA_TX_P2 PC3 NC PC11 NC

S3 SATA_TX_N2 PC4 NC PC12 NC S4 GND PC5 NC PC13 +3.3V S5 SATA_RX_N2 PC6 NC PC14 +3.3V S6 SATA_RX_P2 PC7 GND PC15 GND S7 GND PC8 NC PC16 GND PC1 NC PC9

CFAST_LED_N

PC17 NC

28

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

It is a hardware reset switch. Use this switch to reset the system without turning off the power. Momentarily pressing the switch will activate a reset.

2.2.10 Power Button

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

The power button is a non-latched switch with dual color LED (Blue/Orange) for indication S0, S3 and S5 status. Power button dual-color LED indicator:

Status LED Display System Situation S0 Solid Blue System working S3, S5 Solid Orange Suspend to RAM, System off with

standby power

To turn on the Co

rtex vX series, press the power button and the blue LED lights up. To turn off the Cortex vXseries, you can either issue a shutdown command in the OS, or just simply press the power button. In case of system halts, you can press and hold the power button for 4 seconds to compul

sorily shut down the system. Please note that a 4 seconds interval is kept by the system between two on/off operations (i.e. once turning off the system, you must wait for 4 seconds to initiate another power-on operation).

2.2.11 Reset Tact Switch

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

29

Getting to Know Your Cortex vX

The SFP modules are input/output devices that plug into a Gigabit Ethernet (GE) port, linking the port with a 1000BASE-X ber-optic network.

The SFP Modules are hot-swappable input/output (I/ O) devices that plug into the sockets, which connect the module port to a fiber-optic cable.

You can use any comb

ination of SFP modules. Each port must match the wavelength specifications on the other end of the cable and the cable must not exceed the stipulated cable length for reliable communications.

2.2.12 SFP on Cortex v7460F

CFast

Reset HDD

PWR

DVI-D

VGA

2

1

LAN2 LAN1

30

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.3 Rear Panel I/O Functions

2.3.1 DC-In 6~36V Mini DIN or Power Terminal Block

LAN4 LAN6

LAN3 LAN5

COM2

COM4

COM1

COM3

Isolated DIO

+

Power Switch

On / Off

(+)

Th

e Cortex vX series offers 6 to 36 VDC power input with the terminal block. If the power is supplied properly, the Power LED will light up a solid green.

80

V power surge protection is designed in with LTC4356. Grounding and wire routing help limit the effects of noise due to EMI. Run the ground connection from the ground screw to the grounding surface prior to connecting the power.

See the figure shown below for the location of the earth ground on the terminal block power connector. Connect the earth ground wire to an appropriate grounded metal surface.

2.3.2 Remote Power On/O Switch

LAN4 LAN6

LAN3 LAN5

COM2

COM4

COM1

COM3

Isolated DIO

+

Power Switch

On / Off

(+)

2-pin power-on or power-off switch through Phoenix Contact terminal block. You can

turn on or off the system power by using this contact. This terminal block support dual function of soft power-on / power-off (instant off or delay 4 second), and suspend mode.

DC 6-36V

31

Getting to Know Your Cortex vX

2.3.3 Isolated 8 DI / 8 DO

LAN4 LAN6

LAN3 LAN5

COM2

COM4

COM1

COM3

Isolated DIO

+

Power Switch

On / Off

(+)

The

Cortex vX series offers a 16-bit DIO ( 8-DI / 8-DO) connector. Each bit of DI and DO is equipped with a photo-coupler for isolated protection. A power buffer device (TPD2007F) is integrated in the 8-DO circuit for motors, solenoids, and lamp drivers applications.

Pin No. Denition Mapping to SIO GPIO

Function 1 INPUT0 SIO_GPI50 2 INPUT 1 SIO_GPI51 3 INPUT 2 SIO_GPI52 4 INPUT 3 SIO_GPI53 5 INPUT 4 SIO_GPI54 6 INPUT 5 SIO_GPI55 7 INPUT 6 SIO_GPI56 8 INPUT 7 SIO_GPI57 9 DI_COM 10 GND 11 OUTPUT0 SIO_GPO20 12 OUTPUT 1 SIO_GPO21 13 OUTPUT 2 SIO_GPO22 14 OUTPUT 3 SIO_GPO23 15 OUTPUT 4 SIO_GPO24 16 OUTPUT 5 SIO_GPO25 17 OUTPUT 6 SIO_GPO26 18 OUTPUT 7 SIO_GPO27 19 N.C. 20 External 24VDC Input

32

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

GPI SINK Mode

Isolated GPI input circuit in SINK mode (NPN) is illustrated as follows.

GPI SOURCE Mode

Digital GPI input signal circuit in SOURCE mode (PNP) is illustrated as follow:

GPO SINK Mode:

Digital GPO output circuit in SINK mode (NPN) is illustrated below.

33

Getting to Know Your Cortex vX

2.3.4 Serial Port COM2

LAN4 LAN6

LAN3 LAN5

COM2

COM4

COM1

COM3

Isolated DIO

+

Power Switch

On / Off

(+)

Serial port 2 can b

e configured for RS-232, RS-422, or RS485 with auto flow control communication. Serial Port 2 default setting is RS-232. To use RS-422 or RS- 485, you can change the setting in BIOS.

BIOS Setting Function

COM2

RS-232 RS-422 (5-wire) RS-422 (9-wire) RS-485 RS-485 w/z auto-ow control

The pin assignments are shown in the following table:

Serial Port

Pin No. RS-232 RS-422

(5-Wire)

RS-422 (9-Wire)

RS-485 (3-Wire)

2

1 DCD TXD- TXD- DATA 2 RXD TXD+ TXD+ DATA+ 3 TXD RXD+ RXD+ ----------4 DTR RXD- RXD- ----------5 GND GND GND GND 6 DSR ----------- RTS- ----------7 RTS ----------- RTS+ ----------8 CTS ----------- CTS+ ----------9 RI ----------- CTS- -----------

2.3.5 Serial Port COM1/COM3 / COM4

LAN4 LAN6

LAN3 LAN5

COM2

COM4

COM1

COM3

Isolated DIO

+

Power Switch

On / Off

(+)

34

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

COM1, COM3 and COM4 are RS-232 only and provide up to 115200 bps baud rates. The pin assignments are shown in the following table:

BIOS Setting Pin No. Function

COM1, 3, 4

1 DCD 2 RXD 3 TXD 4 DTR 5 GND 6 DSR 7 RTS 8 CTS 9 RI

35

Getting to Know Your Cortex vX

Figure 2.3.1 Internal Connectors and Jumpers

2.4 Main Board Expansion Connectors

Th

e figure below is the top view of the Cortex vX

series main board. It shows the location of the connectors.

36

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

The figure below is the bottom view of the Cortex vXseries main board.

37

Getting to Know Your Cortex vX

2.4.1 J1 Miscellaneous Pin Header

These pin headers can be used as a backup for the following functions: hard drive LED indicator, reset button, power LED indicator, and power-on/o button. The front and top panel already provides access to these functions. The following table shows the pinouts for Miscellaneous port

J5 Miscellaneous Pin Header

Group Pin No. Description HDD LED 1 HDLED

3 HD_LED_N

Reset Button 5 FP_RST_BTN_N

7 GND Power 2 PWRLED LED 4 PWROK_100MS_N Power Button 6 FP_PWR_BTN_N

8 GND

2.4.2 CN23, CN25, J4 LVDS

These pin headers can be used as a backup for the following functions: hard drive LED indicator, reset button, power LED indicator, and power-on/o button. The front and top panel already provides access to these functions. The following table shows the pinouts for Miscellaneous port:

J1 Miscellaneous Pin Header

Group Pin No. Description HDD LED 1 HDLED

3 HD_LED_N Reset Button 5 FP_RST_BTN_N

7 GND Power LED 2 PWRLED

4 PWROK_100MS_N Power Button 6 FP_PWR_BTN_N

8 GND

38

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

The Cortex vX series supports dual-channel 24-bit LVDS panels

up to 1366x768 pixels resolution.

Pin No.

Denition

CN23 Channel A CN25 Channel B 1 LDDC_CLK LDDC_CLK 2 LDDC_DATA LDDC_DATA 3 PANEL_VDD

(+3.3V or +5V by jumper)

PANEL_VDD

(+3.3V or +5V by jumper) 4 LA_ DATA0_P LB_ DATA0_P 5 LA_ DATA3_P LB_ DATA3_P 6 LA_ DATA0_N LB_ DATA0_N 7 LA_ DATA3_N LB_ DATA3_N 8 PANEL_VDD

(+3.3V or +5V by jumper)

PANEL_VDD

(+3.3V or +5V by jumper) 9 GND GND 10 LA_ DATA1_P LB_ DATA1_P 11 LA_ CLKP LB_ CLKP 12 LA_ DATA1_N LB_ DATA1_N 13 LA_ CLKN LB_ CLKN

2.4.2 CN23, CN25, J4 LVDS

39

Getting to Know Your Cortex vX

Pin No.

Denition

CN23 Channel A CN25 Channel B 14 GND GND 15 GND GND 16 PANEL_BACKLIGHT

(+12V)

PANEL_BACKLIGHT

(+12V) 17 LA_ DATA2_P LB_ DATA2_P 18 PANEL_BACKLIGHT

(+12V)

PANEL_BACKLIGHT

(+12V) 19 LA_ DATA2_N LB_ DATA2_N 20 GND GND

The LCD inverter is connected to J4 via a JST 7-pin, 2.5mm connector to provide +5V/+12V power to the LCD display.

Pin No. Denition 1 +5V 2 +12V 3 +12V 4 LBKLT_CTL 5 GND 6 GND 7 LBKLT_EN

40

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

The Cortex vX

series features 2 high performance Serial ATA III interfaces, wich allow for efficient cabling to hard drives or SSDs with thin and short cables for applications which need larger storage capacity.

Pin No. Denition 1 GND 2 TXP 3 TXN 4 GND 5 RXN 6 RXP 7 GND

2.4.3 CN17, CN20 SATA3 & CN21 SATA Power Connector

41

Getting to Know Your Cortex vX

The Cortex vX series is also equipped with one SATA power connector. It supplies 5V (2A max.) and 12V (1A max) current to the hard drive or SSD.

CN21 SATA HDD Power Connections

Pin No. Denition 1 +12V 2 GND 3 GND 4 +5V

42

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.4.4

CN13 SATA-II Connector J3 SATA DOM Power Connector

The Cortex vX series features one SATA-II interface for applications which require a SATA DOM.

Pin No. Denition 1 GND 2 TXP 3 TXN 4 GND 5 RXN 6 RXP 7 GND

43

Getting to Know Your Cortex vX

The

Cortex vXseries is also equipped with one SATA DOM power connector. It supplies 5V (0.5A max.current) to the SATA DOM.

J3 SATA DOM Power Connections

Pin No. Denition 1 +5V 2 GND

44

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.4.5 J2 Internal USB Dual Port

Th

e Cortex vX series’ main board provides up to two USB plug-and-play ports for a Dongle Key or an LCD touch Panel. The USB interface supports 480 Mbps transfer rate, which complies with high speed USB specification Rev. 2.0, and fuse protection. The USB interface is accessed through one 1x6-pin JST 2.0mm connector. You will need an adapter cable if you use a standard USB connector. The adapter cable has a 1x6pin connector on one end and a USB connector on the other.

Pin No. Denition Pin No. Denition 1 USB_VCC 2 USBD23 USBD2+ 4 USBD35 USBD3+ 6 GND

45

Getting to Know Your Cortex vX

2.4.6 CN8, CN14 Mini-PCIe, mSATA Connectors

Both

mSATA and Mini PCI-E share the same form-factor and similar electrical pinout assignments on their connectors. There was no clear mechanism to distinguish if a mSATA drive or a Mini PCI-E device is plugged into the socket until recently. The SATA-IO issued an ECN change (ECN #045) to re-define pin 43 on mSATA connector as “no connect” instead of “return current path” ( or GND).

When an mSATA drive is inserted, its pin 43 is “no connect”, and the respective pin on the socket is being pulled-up to logic 1. When a Mini PCI-E device is inserted, its pin 43 forces the respective pin on the socket to ground, or logic 0.

Cortex vX series is

using the Pin 43 status for

switching between a mSATA drive and mini PCI-e device.

Status Mini PCI-e card mSATA drive

Pin 43 Logic 0 Logic 1

46

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

CN8 Mini-PCIe Connector Pin Out

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal

Name 51 Reserved 52 +3.3Vaux 33 PETp0 34 GND 49 Reserved 50 GND 31 PETn0 32 SMB_DATA 47 Reserved 48 +1.5V 29 GND 30 SMB_CLK 45 Reserved 46 Reserved 27 GND 28 +1.5V 43 Status 44 Reserved 25 PERp0 26 GND 41 +3.3Vaux 42 Reserved 23 PERn0 24 +3.3Vaux 39 +3.3Vaux 40 GND 21 GND 22 PERST# 37 GND 38 USB_D+ 19 Reserved 20 reserved 35 GND 36 USB_D- 17 Reserved 18 GND

Mechanical Key 15 GND 16 Reserved 7 CLKREQ# 8 Reserved 13 REFCLK+ 14 Reserved 5 Reserved 6 1.5V 11 REFCLK- 12 Reserved 3 Reserved 4 GND 9 GND 10 Reserved 1 WAKE# 2 3.3Vaux

CN14 Mini-PCIe Connector Pin Out

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal Name

Pin No.

Signal

Name 51 Reserved 52 +3.3Vaux 33 PETp0 34 GND 49 Reserved 50 GND 31 PETn0 32 SMB_DATA 47 Reserved 48 +1.5V 29 GND 30 SMB_CLK 45 Reserved 46 Reserved 27 GND 28 +1.5V 43 Status 44 Reserved 25 PERp0 26 GND 41 +3.3Vaux 42 Reserved 23 PERn0 24 +3.3Vaux 39 +3.3Vaux 40 GND 21 GND 22 PERST# 37 GND 38 USB_D+ 19 Reserved 20 reserved 35 GND 36 USB_D- 17 Reserved 18 GND

Mechanical Key 15 GND 16 UIM_VPP 7 CLKREQ# 8 UIM_PWR 13 REFCLK+ 14 UIM_RST 5 Reserved 6 1.5V 11 REFCLK- 12 UIM_CLK 3 Reserved 4 GND 9 GND 10 UIM_DATA 1 WAKE# 2 3.3Vaux

47

Getting to Know Your Cortex vX

2.4.7 CN16 GPIO

The Cortex vX

series offers 16 programmable I/O within TTL 5V tolerance. If the GPIO is logic high, it indicates that the mapping SIO GPIO pin is at a logic high level. If the GPIO is logic low, it indicates that the mapping SIO GPIO pin is at a logic low level.

Pin No. Description Pin No. Description 1 GND 14 GND 2 SIO_GP17 15 SIO_GP67 3 SIO_GP16 16 SIO_GP66 4 SIO_GP15 17 SIO_GP65 5 SIO_GP14 18 SIO_GP64 6 GND 19 GND 7 SIO_GP13 20 SIO_GP63 8 SIO_GP12 21 SIO_GP62 9 SIO_GP11 22 SIO_GP61 10 SIO_GP10 23 SIO_GP60 11 GND 24 GND 12 SMB_DATA 25 +5V 13 SMB_CLK 26 +5V

48

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

2.4.8 FAN1

A FAN power connector is available f

or higher

thermal requirements if necessary.

Pin Out Function 1 GND 2 +12V (1.5A max) 3 Fan-speed sense

49

Getting to Know Your Cortex vX

CN28 Pin out

Pin Out

Function Pin

Out

Function Pin

Out

Function Pin

Out

Function

1 +5V_AUX 2 +12V 27 +5V 28 LPC_AD2 3 +3.3V 4 SMB_DATA 29 USB_1+ 30 LPC_AD3 5 +3.3V 6 XMB_CLK 31 USB_1- 32 LPC_FRAME# 7 Reserved 8 Reserved 33 +5V 34 SERIRQ# 9 Reserved 10 SPI_MISO 35 USB_0+ 36 Reserved 11 USB_OC# 12 SPI_MOSI 37 USB_0- 38 CLK_33MHz 13 Reserved 14 SPI_CLK 39 GND 40 GND 15 +5V 16 SPI_CS10 41 A_PET_P0 42 A_PER_P0 17 USB_3+ 18 SPI_CS1# 43 A_PET_N0 44 A_PER_N0 19 USB_3- 20 Reserved 45 GND 46 APRSNT#/A_

PE_CLKREQ# 21 +5V 22 LPC_DRQ1# 47 PERST# 48 A_CLKP 23 USB_2+ 24 LPC_AD0 49 WAKE# 50 A_CLKN 25 USB_2- 26 LPC_AD1 51 +5V 52 GND

2.4.9 CN27, CN28 SUMIT

50

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

CN27 Pin Out

Pin Out

Function Pin

Out

Function Pin

Out

Function Pin

Out

Function

1 GND 2 GND 27 C_PET_P2 28 C_PER_P2 3 B_PET_P0 4 B_PER_P0 29 C_PET_N2 30 C_PER_N2 5 B_PET_N0 6 B_PER_N0 31 GND 32 GND 7 GND 8 GND 33 C_PET_P3 34 C_PER_P3 9 C_CLKP 10 B_CLKP 35 C_PET_N3 36 C_PER_N3 11 C_CLKN 12 B_CLKN 37 GND 38 GND 13 CPRSNT#/C_

PE_CLKREQ#

14 GND 39 PERST# 40 WAKE#

15 C_PET_P0 16 C_PER_P0 41 Reserved 42 Reserved 17 C_PET_N0 18 C_PER_N0 43 +5V 44 Reserved 19 GND 20 GND 45 +5V 46 +3.3V 21 C_PET_P1 22 C_PER_P1 47 +5V 48 +3.3V 23 C_PET_N1 24 C_PER_N1 49 +5V 50 +3.3V 25 GND 26 GND 51 +5V 52 +5V_AUX

2.4.10 Battery

The Cortex vX series’ real-time clock is powered by a lithium battery. The battery is a Panasonic BR2032 190mAh lithium battery. Replacing the lithium battery on your own is NOT recommended. If the battery needs to be changed, please contact the Rugged Science RMA service team.

51

Getting to Know Your Cortex vX

2.5 Main Board Jumper Setting

Th

e figure below is the top view of the Cortex vX

series main board. It shows the location of all jumpers.

52

Getting to Know Your Cortex vX

©Rugged Science Cortex vX Embedded System Series User Manual

You may configure your card to match the needs of your application by setting jumpers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them. To “close” a jumper, you connect the pins with the clip. To “open” a jumper, you remove the clip. Sometimes a jumper will have three pins, labeled 1, 2 and 3. In this case you would connect either pins 1 and 2, or 2 and 3.

2.5.1 JP3 LVDS Backlight Power Selection

53

Getting to Know Your Cortex vX

JP1 provides LVDS voltage selection function, closing Pin 1, 2 is for 3.3V LVDS power input; closing Pin 2, 3 is for 5V LVDS power input.

Setting Description 1-2 +3.3V (Default) 2-3 +5V

2.5.2 JP2(A) CMOS Clear Jumper Setting

Setting Description 1-3 Normal (Default) 3-5 Clear CMOS

54

Getting to Know Your Cortex vX

2.5.3 JP2(B) ME Clear Jumper Setting

Setting Description 2-4 Normal (Default) 4-6 Clear ME

55

Getting to Know Your Cortex vX

2.5.4 JP1 AT/ATX Power Mode Jumper Setting

Th

e Cortex vX main board contains a jumper that can switch the AT/ATX Power Setting. Normally this jumper should be set with Pin 4 and Pin 6 in ATX power mode. Power on the system with the 2-pin terminal block at the top panel. If you set it with Pin 2 and Pin 4 in AT power mode, it will send the power button signal to power on the system automatically

Setting Description 1-2 AT Mode 2-3 ATX Mode (Default)

56

System Setup

3.1 Install DDR3 / DDR3L SODIMM Modules

3

Remove the “Pet-Door” and you can see a SATA cable and DDR3 SODIMM socket exposed.

Step2.

Put the Cortex vX series upside down on a flat surface. You can see the “Pet-Door” exposed. Use a Philips screwdriver to loose

n the M3 flat-head screw on the “PetDoor”.

Step1.

57

System Setup

It's firmly contacted with socket connectors - press it down until the clamps of the socket snap into the latching position of SODIMM module.

Tile the SODIMM module and insert it to the SODIMM socket.

Step3.

3.2 Install HDD

Put the Cortex vX

series upside down on a flat surface. You can see the “Pet-Door” exposed. Use a Philips screwdriver to loosen the M3 flat-head screw on the “PetDoor”.

Step1.

Remove the “Pet-Door” and you can see a SATA cable and DDR3 SODIMM socket exposed.

Step2.

58

System Setup

Find the HDD bracket on the back of the “Pet-Door”, (consists of 4 M3 screws and

HDD

thermal pad in the

accessory box.)

Step3.

Place the HDD into the bracket and gently push it down to m

ake it contact with thermal pad. Use a Philips screwdriver to tighten the HDD with M3 screws. Please note that the HDD must be placed in the proper orientation as below.

Step4.

Pull out the SATA cable inside t

he chassis and

connect it to the HDD.

Step5.

SATA Connector of HDD

59

System Setup

Tilt the HDD assembly a

nd inser t the lip of the HDD bracket to the bottom cover. Once it’s firmly wedged, push it down and tighten it using a M3 flathead screw.

Step 6.

3.3 Install MiniPCIe Cards

Use a screwdriver to loosen

9 screws on the “Back Panel”. Find the BH-M2.5X6 (4 pieces) screw pack in the accessory box.

Step1.

There are 2 Mini-PCIe s

ockets on the main board. Choose either Mini-PCIe socket to put your mini-PCIe card

into.

Step2.

60

System Setup

Use 2 BH-M2.5X6 screws to lock your mini-PCIe card firmly. Then you can rescrew the back

panel from

the first step.

Step3.

3.4 Install SATA DOM

Use a screwdriver to loosen 9 screws on the “Back Panel”.

Step1.

Prepare your SATA DOM and find the 3 SATA DOM

connectors on the main board.

Step2.

61

System Setup

Select one of the SATA DOM connectors and plu

g in

your SATA DOM.

Step3.

62

System Setup

3.5 Install the SFP Module and SC cable

Please make sure the swing latch of the SFP Module is in on the bottom before you insert it to the SFP socket.

Step1.

Correct Wrong

Step2.

Push the Fiber module into the socket till it locks to the socket rmly. Repeat Step 2 if you are inserting a second SFP module. Do not remove the SFP module plugs until you are ready to install the cables.

Step3.

Inserting the SC cable into Fiber module to complete installation.

Complete

3.5.1 Hardware Installation

63

System Setup

3.5.2 Software Installation

Step1.

If hardware installed correctly

, 2 i350 LAN devices will be listed on

Windows network, as shown in the graphic below:

P

lease make sure the SC cable connects to the Fiber Module firmly, if it is

not, Windwos cannot detect the connection.

CAUTION!

64

System Setup

3.6 Remove the SFP Module and SC cable

Step1.

Loose

n the swing latch to un-lock the Fiber Module and SC cable connection.

Step2.

Remove the SC cable.

Step3.

Remove the Fiber Module.

65

System Setup

Find your wall-mounts brackets (2 pieces)in the accessory box.

Step2.

Fix two wall-mount brackets to the chassis with four M4 screws using a Philips screwdriver.

Step3.

3.6 Mounting Your Cortex vX

The Cortex vX i

s shipped with wall-mount brackets. You can mount your Cortex vXseries on the wall by following the steps listed below.

Step1.

Put the Cortex vX

series upside down on a flat surface. Use a Philips screwdriver to loosen screws on the back side.

66

System Setup

Installation Method 2

Installation Method 1

67

BIOS and Driver

4.1 BIOS Settings

The

Cortex main board uses UEFI BIOS via Serial Peripheral Interface (SPI) Flash. The SPI Flash contains the BIOS Setup program, POST, the PCI auto-configuration utility, LAN, EEPROM information, and Serial port support. The BIOS setup program is accessed by pressing the <Delete> key after the Power-On Self-Test (POST) memory test begins, and before the operating system boot begins. The menu bar is shown below.

Figure 4.1: BIOS Menu Bar

4

68

BIOS and Driver

4.1.1 Main Menu

Figure 4.2: BIOS Main Screen

System Time / Date : Press “TAB” key to switch sub-items of value .Then press “ +” key or “-“ key number key for modify value.

4.1.2 Advanced Function

Figure 4.3: ACPI Setting Setup Screen

Enable ACPI Auto Configuration: This system supports ACPI functionality as an

auto process. You should Enable / Disable that dependent on your O.S. requirements.

69

BIOS and Driver

Figure 4.4: Trusted Computing Setup Screen

S

ecurity Device Support : Enables or Disables BIOS support for security

devices. If enabled, the O.S. will show Security Device. TCG EFT protocol and INT1A interface will not be available.

Current Status Information :

Show as below option

SUPPORT TURNED OFF SUPPORT TURNED ON

Figure 4.5: Trusted Computing Setup Screen

I

ntel Virtualization Technology : Used for a Virtualization Application or

platform usage. When enabled, a VMM can utilize the additional hardware capabilities provided by Vanderpool Technology,

70

BIOS and Driver

Figure 4.6: SATA Conguration Setup Screen

SATA Controller(s) : 0988261051

Enables or Disables integrated

SATA controller for Storage device use.

SATA Mode Selection :

D

etermines the SATA transfer mode for operation. Three options are available: [IDE] / [AHCI] / [RAID]. For the RAID mode operation, please see appendix E. for detailed information.

Serial Port 0~5 :

This system offers six SATA ports

for connection to SATA devices.

Advanced->IT8783F Super IO Configuration->Serial Port 1

Figure 4.7: Serial Port 1Setup Screen

Serial Port :

Enable or Disable Serial Port .

71

BIOS and Driver

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11;

Advanced->IT8783F Super IO Configuration->Serial Port 2

Figure 4.8: Serial Port 2 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11;

Interface Mode:

Here have 4 option : RS-232 Mode RS-422 Mode RS-485 Mode

72

BIOS and Driver

Advanced->IT8783F Super IO Configuration->Serial Port 3

Figure 4.9: Serial Port 3 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11; IO=2F0h; IRQ=6; IO=2E0h; IRQ=7;

Advanced->IT8783F Super IO Configuration->Serial Port 4

Figure 4.10: Serial Port 4 Setup Screen

Serial Port :

Enable or Disable Serial Port .

Device Setting:

Current IO address and interrupt resource of Serial Port.

73

BIOS and Driver

Change Settings :

Select another device setting . Here have 4 option : IO=3F8h; IRQ=4; IO=2F8h; IRQ=3; IO=3E8h; IRQ=10; IO=2E8h; IRQ=11; IO=2F0h; IRQ=6; IO=2E0h; IRQ=7;

4.1.3 Chipset Function

Phoenix SecureCore(tm) Setup Utility

Main Advanced Chipset Boot Security Save & Exit

WOL configuration

Chipset->PCH-IO Conguration->Wake on LAN

Figure 4.11: Network Setup Screen

PCH LAN Controller : Enable or Disable Serial Port .

Wake on LAN : Enable or Disable integrated LAN to wake the system.

This function can also be acti

vated by your O.S.

Power Loss Configuration

Chipset->PCH-IO Conguration->Restore AC Power Loss

Figure 4.12: Power Loss Setup Screen

74

BIOS and Driver

PCH LAN Controller :

[Power Off ] : When plug-in to the power source , system will keep in SB mode. [Power On ] : When plug-in to the power source , system will auto boot. [Last State ] : When plug-in to the power source , system will keep on the last power status.

4.1.4 Boot Function

Boot Option

Chipset->PCH-IO Conguration->Wake on LAN

Figure 4.13 Boot Setup Screen

Boot option : When you press “Enter” , you can select which device you would like to boot.

4.2 Operating System

Linux :

Ubuntu 10.04LTS or Above Fedora 13 or Above And

other Linux kernel 2.6.33 and RHL6.0

(* The Linux kernel of RHL , please check Red Hat website first )

Windows :

Windows XP Windows 7 Home/Professional/MediaCenter/ Windows 8 ( Do not support RT version) Windows Server 2008 R2 Windows Server 2012

75

BIOS and Driver

4.3 Driver Installation

After you setu

p all hardware and firmware devices, you should install the corresponding software driver for your specific O.S process. When you start to install the driver, please make sure you have an administrator ID for system authentication. Please follow below sequence for driver install

1. Intel Chipset

2. Intel HD 4000 Graphics

3. Network Device – Include 85574L and 82579LM

4. Audio Driver

5. USB 3.0 support

6. Storage: Include “ACHI” driver and Intel Rapid Storage Software.

7. AMT function of Intel ME(Management Engine)

Find the driver installation file

• Windows 7 64bit version :

The Chipset driver location is : [CD]:\Win7\64bit\ChipsetDriver\

Step1.

4.3.1 Chipset Driver Installation

T

his device software installs all components of the Cortex platform chipset to the target system. After installing this software, please ensure that the following features function properly:

1. PCIe / PCI . ISAPNP services cong.

2. IDE/ACHI storage interface Support

3. USB Support

4. Identification of Intel Chipset Components in the Device

Manager.

Installation instruction:

Ex

ecute and install the files which match your operating system. Instruction windows will pop-up when you start to setup the driver. Please follow instructions and complete the setup process.

Step2.

Step3.

O

nce you completed the Intel Chipset Driver setup, please reboot your system , all update function will be active on the next start up of Windows.

76

BIOS and Driver

Find the driver installation file

• Windows 7 64bit version :

The Graphics driver location is : [CD]:\Win7\64bit\VGADriver\

Step1.

4.3.2 Intel HD 4000 Graphics Driver Installation

This driver will install the

following features:

- Display services

- High definition Audio support

Install

ation instructions:

Execute and install the files. Instruction windows will pop-up when you start to setup the driver, please follow it and complete the setup processes.

Step2.

Step3.

Once you complete the HD Graphics Driver setup, please reboot your

system. All updated functions will be active on the next Windows startup.

Find the driver install le

• Windows 7 64bit version :

The network driver location is : [CD]:\Win7\64bit\LanDriver\

Step1.

4.3.3 Network Device Driver Installation

This driver will install the

following features:

- LAN 1 : Intel 82579LM network device

- LAN 2~ LAN 6 : Intel 82574L network device.

( Please double check your LAN port number)

Install

ation instruction:

Execute and install the files. Instruction windows will pop-up when you start to setup the driver, please follow it and complete the setup processes.

Step2.

77

BIOS and Driver

Step3.

Once you finish the LAN device Driver setup , the LAN connection will

show a

loss temporarily, and then restart automatically.

Step4.

If you need active AMT function as well , please refer to the section for “AMT driver install”.

Find the driver install le

The Audio driver location is : [CD]:\Win7\64bit\Audio\

Step1.

4.3.4 Audio Driver Installation

This driver will install the Realtek High definition device software and Utility.

Execute the installation file

to begin driver installation.

Step2.

Step3.

Once you finish the Audio device Driver setup, please reboot your system. All updated functions will be active next Windows startup.

Find the driver installation file

USB 3.0 driver location is : [CD]:\Win7\64bit\USB3.0

Step1.

4.3.5 USB 3.0 Driver Installation

This driver will install USB 3.0 device support software.

Execute the installation

file to begin

Step2.

Step3.

On

ce you finish the USB3.0 device Driver setup ,please reboot your

system. All updated functions will be active on next Windows startup.

78

BIOS and Driver

Find the driver install le

Intel Rapid software location is : [CD]:\Win7\64bit\Storage

Step1.

4.3.6 Storage Support Software Installation

Installing the Intel Rapid software This driver will install following features:

Execute the install le and start to install it.

Step2.

Step3.

Once you finish the Rapid software

setup ,please reboot your system ,

all update function will be active on next Windows startup.

Use this driver only on AHCI mode.

- Software panel for SATA device

- Utilities for RAID volume creation.

CAUTION!

4.3.7 Intel AMT Function Support

This driver will install the

following features:

- Intel ME (Management Engine) support

- Intel AMT software panel

- SOL(Serial on LAN) device driver .

Find the driver install le

The Chipset driver location is : [CD]:\Win7\64bit\LanDriver\ME

Step1.

Execute the install le and start to install it.

Step2.

Step3.

O

nce you finish the AMT function setup ,please reboot your system. All updated function will be active on next Windows startup.

Appendix A

79

ppendix A : Isolated DIO Guide

A

Description:

Initialize hardware and resources, a

nd get number

of functional boards.

Syntax:

I16 _mnet104_open ()

Argument:

Name Type Description N/C

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other

Please reference the Appendix error table.

Description:

Get the local DI value.

Syntax:

I16 _mnet104_read_port( U16 Oset, U8 *Val )

Argument:

Name Type Description Oset U16

Pointer to the accessed DI port address

Val [output] U8 * Return the value of local input interface.

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other

Please reference the Appendix error table.

Description:

Get the local DI value.

Syntax:

I16 _mnet104_write_port( U16 Oset, U8 Val )

Argument:

80

Appendix A

Name Type Description Oset U16 Pointer the access DI port address Val U8 Write the value of local input interface.

Return:

Return Value Description ERR_NoError The function nished execution successfully. Other Please reference to the Appendix error table.

Appendix B

81

The GPIO& WDT are using internal Super IO functions. However, you must enter super I/O configuration mode to set it. The output port is set as GPIO 1 on CN13 , reg. index = 0x60 The input port is set as GPIO 4 on CN12 , reg. index = 0x62.

Super I/O special address port = 0x2E

Super I/O special data port = 0x2F

GPIO Logical device is 0x07

//write twice 0x87 value.

outportb(Super I/O special address port, 0x87); outportb(Super I/O special address port, 0x01); outportb(Super I/O special address port, 0x55); outportb(Super I/O special address port, 0x55);

//write 0x07 on Reg [0x07] , this setup must follow Step A. that can be workable.

outportb(Super I/O special address port, 0x07); outportb(Super I/O special data port, 0x07);

Base control for write Super I/O register.

outportb(special address port, Register Index.); outportb(special data port, update_value);

Base control for read Super I/O register

outportb(special address port, Register Index.); inportb(special data port); //It will return a BYTE value.

Please refer to source code for set_data() and get_data() function.

Write data to GPO(output) port

set_data( Register Index , update_value);

example : unsigned char data = 0x82; set_data( 0xE5 , data); //Set bit 7 & bit 1 of GPO output port as High level ,another bit is Low

ppendix B : GPIO & WDT Function

A

A. Entry MB PnP Mode

B. Located on Logical Device 7

C. Access the Super I/O Register

D. Start to Access the Cortex GPIO Port

82

Appendix B

Please refer to source code for set_data() and get_data() function.

Read data to GPI(input) port

get_data( Register Index ) //It will return a BYTE value. example : unsigned char data get_data( 0xF1 , data); //Get GPI(input) port status on input_data variable.

Refer to GPIO setting of Step A and B. , located Logical 0x08 for WDT function.

Reg [0x30] is WatchDog ON/OFF control.

WatchDog On : set_data( 0x30 , 0x01); WatchDog O : set_data( 0x30 , 0x00);

Reg [0xF0] is WatchDog timer - counterON/OFF control.

WatchDog counter start : set_data( 0xF0 , 0x02); WatchDog counter start : set_data( 0xF0 , 0x00);

Reg [0xF1] is WatchDog time-out value, "Reading" this register returns the current value in the Watch Dog Counter, not the Watch Dog Timer Time-out value..

WatchDog time-out value : set_data( 0xF1 , );

E. WDT ON/OFF and Timer-Counter setting

Rugged Science Cortex vX series User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
