RTX HT7144 User Manual

RTX7143 Quickguide

Contents

PART OVERVIEW: 3

CONNECTIONG THE HEADSET TO PC: 4

BLUETOOTH: 4

WEARING THE HEADSET: 5

Adjusting the headband: 5

Positioning the microphone: 5

Rotating the bendable boom arm: 5

HOOK-SWITCH CONTROLER: 6

OPERATING THE HEADSET: 6

HOW TO MUTE THE HEADSET: 6

Answer/Hang-up calls: 7

Auto hook off: 7

Play/Pause audio: 8

USING THE HEADSET WITH A MOBILE DEVICE: 9

PAIRING WITH MOBILE DEVICE: 9

SWITCHING BETWEEN PC AND MOBILE DEVICE: 9

USING THE HEADSET WITH MOBILE DEVICE: 9

Receiving a call on the mobile device when connected to PC: 9

CARE AND SAFTY: 10

Thank you for purchasing the RTX7143 headset.

In this quick guide, you will nd all necessary information regarding your new RTX7143 headset.

PART OVERVIEW:

Headband

Microphone

USB connector

Speaker

Hook-Switch

3

CONNECTIONG THE HEADSET TO PC:

- Plug-in the USB connector into the PC.

- When the headset is connected for the rst time a pop-up message will be shown in the taskbar,

telling you that the headset is connected. You are now ready to use the headset.

- When the headset is ready to use the will turn

NOTE: If you are using win7 you need to set the RTX7143 as default device in Windows control
panel - Sound settings. This only have to be done once.

BLUETOOTH:

The headset has built-in Bluetooth, for pairing with a mobile device. If the headset is not paired with a

mobile device the will be turned off. If it is paired with a mobile device the will turn red

For Bluetooth pairing and use see page 9.

4
