1 About This Document

This document describes the configuration, customization, management, operation, maintenance and troubleshooting
of the RTX8200 Location Gateway in RTX generic mode. For customer, specific modes refer to specific customer
agreements, which describe the software operational deviations from this document.

1.1 Audience

Who should read this guide? First, this guide is intended for networking professionals responsible for designing and
implementing RTX based enterprise networks.
Second, network administrators and IT support personnel that need to install, configure, maintain, and monitor

elements in a “live” SME VoIP network will find this document helpful. Furthermore, anyone who wishes to gain

knowledge on fundamental features in the Beatus system can also benefit from this material.

1.2 When Should I Read This Guide

Read this guide before you install the core network devices of VoIP SME System and when you are ready to setup or
configure SIP server, NAT aware router, advanced VLAN settings, base stations, and Location Gateway’s in a multi cell
setup.
This manual will enable you to set up and connect your RTX8200 Location Gateway in a Multi Cell system.

1.3 Important Assumptions

This document was written with the following assumptions in mind:

• You understand network deployment in general

• You have working knowledge of basic TCP/IP/SIP protocols, Network Address Translation, etc...

• A proper site survey has been performed, and the administrator have access to these plans

1.4 What’s Inside This Guide

We summarize the contents of this document in the table below:

WHERE IS IT?

CONTENT

PURPOSE

CHAPTER 2

TBD

TBD

CHAPTER 3

TBD

TBD

CHAPTER 4

TBD

TBD

CHAPTER 5

TBD

TBD

RTX8200 LOCATION GATEWAY GUIDE 4.6 5 | P a g e
Proprietary and Confidential

1.5 What’s Not in This guide

This guide provides overview on, how-to configure RTX8200 Location Gateway to an RTX Generic System.
It is not intended as a comprehensive reference to all detail and specific steps on how to configure other vendor
specific components/devices needed to make the SME VoIP System functional. For such a reference to vendor
specific devices, please contact the respective vendor for documentation.
Configuration on specific Alarm/Messaging servers are not included in this guide.

1.6 Abbreviations

For this document, the following abbreviations hold:

DHCP: Dynamic Host Configuration Protocol
DNS: Domain Name Server
HTTP(S): Hyper Text Transfer Protocol (Secure)
(T)FTP: (Trivial) File Transfer Protocol
IOS: Internetworking Operating System
PCMA: A-law Pulse Code Modulation
PCMU: mu-law Pulse Code Modulation
PoE: Power over Ethernet
RTP: Real-time Transport Protocol
RPORT: Response Port (Refer to RFC3581 for details)
SIP: Session Initiation Protocol
SME: Small and Medium scale Enterprise
VLAN: Virtual Local Access Network
TOS: Type of Service (policy based routing)
URL: Uniform Resource Locator
UA: User Agent

1.7 References/Related Documentation

RTX8430 Handset_Manual_Operations_v4.6
RTX8630 Handset_Manual_Operations_v4.6
RTX8631_Handset_Manual_Operations_v4.6
RTX8632_Handset_Manual_Operations_v4.6
RTX8633_Handset_Manual_Operations_v4.6
RTX8830_Handset_Manual_Operations_v4.6
How to Deploy SME VOIP System v1.4
Provisioning of SME VoIP System (23)

1.8 Document History

REVISION

AUTHOR

ISSUE DATE

COMMENTS

4.6

HDJ

01-04-2019

Updated to V460 Firmware

RTX8200 LOCATION GATEWAY GUIDE 4.6 6 | P a g e
Proprietary and Confidential

1.9 What is new

What new features have been added.

VERSION

FEATURE

V460

All new product

1.10 Documentation Feedback

We always strive to produce the best and we also value your comments and suggestions about our documentation. If
you have any comments about this guide, please enter them through the Feedback link on the RTX website. We will
use your feedback to improve the documentation.

RTX8200 LOCATION GATEWAY GUIDE 4.6 7 | P a g e
Proprietary and Confidential

2. Introduction – System overview

In a typical DECT telephony system, you have base station, repeaters and handsets, allowing the users to
make/receive calls and messages.
A typical setup could look like this:

Increasing demand for locating equipment, personal or pushing information to specific handset on a specific location,
demands the system to know exactly where the device is located.
This can be done be adding RTX8200 Location gateway devices to the DECT system.
