G277/G577/G577h DECT Quick Reference Guide
G577 G577h G277
Front View
Package Contents:
- G277/577(h) DECT Handset
- Battery
- Belt Clip
- This Reference Guide
- Additional Information Sheet
G277/577 DECT Handset Quick Reference Guide 1
To use the G277/577(h) for the first time:
- Open the battery lid;
- Remove the plastic strip from the
- Close the battery lid;
- Place the G277/577(h) on the charger
Side Views
battery contacts
to fully charge the battery
2 G277/577 DECT Handset Quick Reference Guide
Contacts
Signal Strength
Central Directory
Battery Status
Calls
Ringer Off
Settings
Microphone Muted
Calendar
Keypad Locked
Accessories
Missed Call
Messaging (G577(h))
Voice Mail Present Indication
GETTING STARTED
Press and hold for a few seconds.
When the display of your phone is dark, press any key to activate your phone (phone in Idle
mode).
Press and then (toggle function).
1. Press and then type the number you want to reach. OR
2. Press an then type the number you want to reach (speakerphone call) OR
3. Type the number you want to reach and then or OR
4. Use a speed dial key ( … or ) OR
5. Press soft key or , select the required contact and press soft key ,
, or .
Press or, for speakerphone call, .
Press .
During a call, press and dial the number of the party you want to consult. Press to
toggle between the two parties. Press to transfer the call.
During a call, press “Volume Up” or “Volume Down” on the side of the phone. The default
volume level is 4.
During a call, press ; to de-activate: press again.
Press the soft key . To turn the microphone on again, press the soft key .
Turning the G277/577(h) on and off
Activating your phone
Lock/Unlock your phone
Make a call
Answering an incoming call
End a call
Make an enquiry call
Change the volume
Use the Speaker phone
Mute the microphone during a call
Main Menu Items
Top Line Icons
G277/577 DECT Handset Quick Reference Guide 3
In Idle mode, press , use the navigation keys to select and press the soft key .
1. Press soft key , then enter the text of your message. OR
2. Use the navigation keys to select a stored draft message and press soft key .
Then press soft key , select the type of the message (normal or urgent) and choose the
required destination(s). When “message sent” is given in the display your message has been
sent successfully.
In Idle mode, press soft key , select the contact you want to assign a speed dialling key
and press soft key . Choose and press soft key . Use the navigation keys
to scroll to the appropriate number (2..9) and press soft key .
In Idle mode, press , use the navigation keys to select and press soft key . Use
the navigation keys to select (connectivity) and press soft key . Use the navigation
keys to select (Register) and press soft key .
Enter the requested registration information (contact your System Administrator for this).
Wait for the registration to be completed.
In Idle mode, press to access the main menu. Use the navigation keys to go to the
required menu, menu tab and menu item. Use soft key ( or press ) to select the
chosen menu or menu item/tab. Other soft keys may provide additional options.
To go back one step in the menu or leave altogether, press .
Write and send a text message (G577(h))
Assigning a contact to a speed dialling key
Register the handset
Using the menu
4 G277/577 DECT Handset Quick Reference Guide
1. Contacts
• List of contacts
2. Central Directory
• Select required contact by name
3. Calls
• All Calls
• Answered Calls
• Dialled Calls
• Missed Calls
4. Settings
• General Settings
Silent
Time & Date
Language
(Supported: English, Spanish,
German, French,
Italian, Dutch, Danish, Swedish,
Turkish, Polish,
Norwegian, Greek & Russian)
Shortcuts (for the navigation
keys)
LED Signal
Red LED
Green LED
Yellow LED
Blue LED
Security
Phone Lock
Automatic Key Lock
Change PIN
Proxy Password
Handset Name
Reset Settings
Status
• Sounds Normal & Sounds Silent
Incoming Call
Ring Volume
Ring
External/Internal/Unkn
own
Group Ring
Intercom Ring
Emergency Ring
Arb. Ring
Increasing Ring
Vibrator
Message Notifications
(G577(h))
Notification Volume
Notification
Normal/Urgent/Emerg
ency
Increasing Notification
Vibrator
Alerts
Alert Volume
Alert Melody
Increasing Alert
Vibrator
Feedback
Key Sound
Confirmation Sound
Coverage Warning
Charger Warning
Noise Reduction
• Display
Wallpaper
Startup Screen
Power Save
Charger Backlight
• Calls
Units
Answer Mode
Caller Filter
Emergency Call
Number
Message
SOS Key (G577(h))
Voicemail Number
Silent Charging
Missed Call Time
• Connectivity
Register
Deregister
Select Network
Bluetooth (G577(h))
Enabled/Disabled
Search for Devices
Paired Devices
5. Calendar
• Manage your appointments
6. Accessories
• Alarms
• Calculator
• Stopwatch
7. Messaging (G577(h))
• Drafts
• Inbox
• Sent Messages
• Settings
Menu list
FCC Warning：
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this
device must accept any interference
received, including interference that may cause undesired
operation. Any Changes or modifications not
expressly approved by the party responsible for compliance
could void the user's authority to operate the
equipment.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV technician for
help.
FCC Exposure to Radio Frequency (RF) Signals
For Handset
This is a radio transmitter and receiver. It is designed and
manufactured not to exceed the emission limitsfor
exposure to radio frequency (RF) energy set by the
Federal Communications Commission (FCC) of the
U.S.Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF
energy for the general population. The guidelines are
based on the safety standards previously set by both
U.S. and international standards bodies. These standards
include a substantial safety margin designed to
assure the safety of all persons,regardless of age and
health. This device and its antenna must not be colocated
or operating in conjunction with any other antenna or
transmitter. This product has been shown to be
capable of compliance for localized specific absorption rate
(SAR) for uncontrolled environment/general
population exposure limits specified in ANSI/IEEE Std.
C95.1-1992 and had been tested in accordance with
the measurement procedures specified in FCC/OET
Bulletin 65 Supplement C (2001) and IEEE 1528.
Le présent appareil est conforme aux CNR d'ISEDC
applicables aux appareils radio exempts de
licence.L'exploitation est autorisée aux deux conditions
suivantes :
(1) l'appareil nedoit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
The device has been tested and compliance with SAR
limits, users can obtain Canadian information on RF
exposure and compliance
Le présent appareil est conforme Après examen de ce
matériel aux conformité aux limites DAS et/ou aux
limites d’intensité de champ RF, les utilisateurs peuvent
sur l’exposition aux radiofréquences et la
conformité and compliance d’acquérir
ISEDC Specific Absorption Rate (SAR) information
For Handset
SAR tests are conducted using standard operating
positions accepted by the ISEDC with device transmitting
at its highest certified power level in all tested frequency
bands, although the SAR is determined at the
highest certified power level, the actual SAR level of the
device while operating can be well below the
maximum value. Before a new model device is a available
for sale to the public, it must be tested and
certified to the ISEDC that it does not exceed the exposure
limit established by the ISEDC, tests for each
device are performed in positions and locations as
required by the ISEDC. For body worn operation, this
model device has been tested and meets the ISEDC RF
exposure guidelines when used with an accessory
designated for this product or when used with an
accessory that contains no metal.
ISEDC Radiation Exposure Statement:
For Handset
SAR l’utilisation des règles sma l’emplacement Le matériel
de transmission et fonctionnant dans tous les
essais à la certification, même si la puissance suprême a
décidé le niveau, utilisation spécifique peut être
très en deçà de la valeur de référence maximale.Types de
matériel sont vendus au public un ancien, d’essai
et de certification de l’exposition, limite maximum sma,
chaque document et l’emplacement du matériel
d’essai et conformément au document.Le modèle en
physique, matériel d’essai et conforme aux directives
d’exposition des radiofréquences sma quand une annexe
désigné pour ce produit lors de leur utilisation ou
des pièces de rechange ne contiennent pas de métal.
ISEDC Warning:
This device complies with ISEDC licence-exempt RSS
standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause interference, and
(2) this device must accept any interference, including
interference that may cause undesired operation of
the device.
G277/577 DECT Handset Quick Reference Guide 5
CS03 Warning
This product meets the applicable ISEDC technical specifications. / Le present matériel est
conforme aux specifications techniques applicables d’ISEDC.
The REN is an indication of the maximum number of terminals allowed to be connected to a
telephone interface. The termination on an interface may consist of any combination of
devices subject only to the requirement that the sum of the Ringer Equivalence Numbers of
all the devices does not exceed five. / L’indice d’équivalence de la sonnerie (IES) sert à
indiquer le nombre maximal de terminaux qui peuvent être raccordés à une interface
téléphonique. La terminaison d’une interface peut consister en une combinaison
quelconque de dispositifs, à la seule condition que la somme d’indices d’équivalence de la
sonnerie de tous les dispositifs n’excède pas cinq.
REN: NAN
