XCP-40-DB9
Breakout Panel Technical Guide
38110511 Rev C April / 2008
PROPRIETARY NOTICE
SHIPPING TO THE MANUFACTURER
The product information and design disclosed herein were originated by
and are the property of Telex Communications, Inc. Telex reserves all
patent, proprietary design, manufacturing, reproduction, use and sales
rights thereto, and to any article disclosed therein, except to the extent
rights are expressly granted to others.
COPYRIGHT NOTICE
Copyright 2008 by Telex Communications, Inc. All rights reserved.
Reproduction, in whole or in part, without prior written permission from
Telex is prohibited.
WARRANTY NOTICE
See the enclosed warranty card for further details.
CUSTOMER SUPPORT
Te chnical questions should be directed to:
Customer Service Department
RTS/Telex Communications, Inc.
12000 Portland Avenue South
Burnsville, MN 55337 USA
Telephone: 800-392-3497
Fax: 800-323-0498
All shipments of product should be made via UPS Ground, prepaid (you
may request from Factory Service a different shipment method). Any
shipment upgrades will be paid by the customer. The equipment should
be shipped in the original packing carton. If the original carton is not
available, use any suitable container that is rigid and of adequate size. If
a substitute container is used, the equipment should be wrapped in paper
and surrounded with at least four (4) inches of excelsior or similar
shock-absorbing material. All shipments must be sent to the following
address and must include the Proof of Purchase for warranty repair.
Upon completion of any repair the equipment will be returned via
United Parcel Service or specified shipper, collect.
Factory Service Department
Telex Communications, Inc.
8601 East Cornhusker Hwy.
Lincoln, NE 68507 U.S.A.
Attn: Service
This package should include the following:
RETURN SHIPPING INSTRUCTIONS
Customer Service Department
Telex Communications, Inc. (Lincoln, NE)
Telephone: 402-467-5321
Fax: 402-467-3279
Factory Service: 800-553-5992
Please include a note in the box which supplies the company name,
address, phone number, a person to contact regarding the repair , the type
and quantity of equipment, a description of the problem and the serial
number(s).
CHAPTER 1
TelexCommunications, Inc.
Made inU.S.A.
J1 J2 J3 J4 J9 J10
J11
J12 J17 J18
J19 J20
J25 J26 J27 J28 J33 J34
J35
J36
J5 J6 J7 J8 J13 J14
J15
J16
J21
J22 J23 J24 J29
J30
J31
J32
J37 J38 J39
J40
J1
J2 J3
J4
J5
XCP-40-DB9
9000-7515-000
FIGURE 1. XCP-40-DB9
The XCP-40-DB9 breakout panel allows for the expansion
of the ADAM frame at 40+, 80+, and 120+. When using the
40-port DB-9 breakout panel, you must use the SCSI
backcard with the AIO-16 card.
Pin 1 Keypanel Data +
Pin 2 Keypanel Data Pin 3 Gnd
Pin 4 Audio Out +
Pin 5 Audio Out Pin 6 Gnd
Pin 7 Audio In Pin 8 Audio In +
Pin 9 Gnd
9-pin Male D-sub
SCSI Connector - J1, J2, J3, J4, J5
Pin
Number
Port Function
2 Data +
27 Data -
34 1 Audio To Matrix +
9 1 Audio To Matrix 35 1 Audio From Matrix +
10 1 Audio From Matrix -
36 2 Audio To Matrix +
11 2 Audio To Matrix 37 2 Audio From Matrix +
12 2 Audio From Matrix -
3
SCSI Connector - J1, J2, J3, J4, J5
Pin
Number
38 3 Audio To Matrix +
13 3 Audio To Matrix 39 3 Audio From Matrix +
14 3 Audio From Matrix -
40 4 Audio To Matrix +
15 4 Audio To Matrix 41 4 Audio From Matrix +
16 4 Audio From Matrix -
42 5 Audio To Matrix +
17 5 Audio To Matrix 43 5 Audio From Matrix +
18 5 Audio From Matrix -
44 6 Audio To Matrix +
19 6 Audio To Matrix 45 6 Audio From Matrix +
20 6 Audio From Matrix -
Port Function
46 7 Audio To Matrix +
21 7 Audio To Matrix 47 7 Audio From Matrix +
22 7 Audio From Matrix -
48 8 Audio To Matrix +
23 8 Audio To Matrix 49 8 Audio From Matrix +
24 8 Audio From Matrix -
4
Notes
