RTS TIF 2000 User Manual

USER MANUAL

Model TIF 2000

Digital Hybrid Telephone Line Interface

9350-7674-000 Rev A, 11/2001

1

PROPRIETARY NOTICE

The RTS product information and design disclosed herein were
originated by and are the property of Telex Communications, Inc.
Telex reserves all patent, proprietary design, manufacturing,
reproduction, use and sales rights thereto, and to any article
disclosed therein, except to the extent rights are expressly granted
to others.

COPYRIGHT NOTICE

Copyright © 2001 by Telex Communications, Inc. All rights reserved.
Reproduction in whole or in part without prior written permission
from Telex is prohibited.

WARRANTY INFORMATION

RTS products are warranted by Telex Communications, Inc. to be
free from defects in materials and workmanship for a period of three
years from the date of sale.

CUSTOMER SUPPORT

Technical questions should be directed to:

Customer Service Department
RTS/Telex,
12000 Portland Avenue South
Burnsville, MN 55337 U.S.A.
Telephone: [phone]
Fax: [phone]

RETURN SHIPPING INSTRUCTIONS
PROCEDURE FOR RETURNS

If a repair is necessary, contact the dealer where this unit was
purchased.

If repair through the dealer is not possible, obtain a RETURN
AUTHORIZATION from:

The sole obligation of Telex during the warranty period is to provide,
without charge, parts and labor necessary to remedy covered
defects appearing in products returned prepaid to Telex. This
warranty does not cover any defect, malfunction or failure caused
beyond the control of Telex, including unreasonable or negligent
operation, abuse, accident, failure to follow instructions in the
Service Manual or the User Manual, defective or improper associ­ated equipment, attempts at modification and repair not authorized
by Telex, and shipping damage. Products with their serial numbers
removed or effaced are not covered by this warranty.

To obtain warranty service, follow the procedures entitled “Proce­dure For Returns” and “Shipping to Manufacturer for Repair or
Adjustment”.

This warranty is the sole and exclusive express warranty given with
respect to RTS products. It is the responsibility of the user to
determine before purchase that this product is suitable for the
user’s intended purpose.

ANY AND ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED
WARRANTY OF MERCHANTABILITY ARE LIMITED TO THE
DURATION OF THIS EXPRESS LIMITED WARRANTY.

NEITHER TELEX NOR THE DEALER WHO SELLS RTS PROD­UCTS IS LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES OF ANY KIND.

Customer Service Department
Telex Communications, Inc.
Telephone: [phone]
Fax: [phone]

DO NOT RETURN ANY EQUIPMENT DIRECTLY TO THE
FACTORY WITHOUT FIRST OBTAINING A RETURN AUTHORIZA­TION.

Be prepared to provide the company name, address, phone
number, a person to contact regarding the repair, the type and
quantity of equipment, a description of the problem and the serial
number(s).

SHIPPING TO MANUFACTURER FOR REPAIR OR ADJUSTMENT

All shipments of RTS products should be made via United Parcel
Service or the best available shipper, prepaid. The equipment
should be shipped in the original packing carton; if that is not
available, use any suitable container that is rigid and of adequate
size. If a substitute container is used, the equipment should be
wrapped in paper and surrounded with at least four inches of
excelsior or similar shock-absorbing material. All shipments must be
sent to the following address and must include the Return Authori­zation.

Factory Service Department
Telex Communications, Incorporated
West 1st Street
Blue Earth, MN 56013 U.S.A.

Upon completion of any repair the equipment will be returned via
United Parcel Service or specified shipper collect.

2

Table of Contents

INTRODUCTION .................................................................................................................................... 4

DESCRIPTION ........................................................................................................................................ 4

Front Panel Features ..................................................................................................................................................................4

Rear Panel Features ................................................................................................................................................................... 4

INSTALLATION ...................................................................................................................................... 4

Unpacking .................................................................................................................................................................................... 4

Rear Panel DIP Switch (S201) ................................................................................................................................................... 4

Auto Answer ................................................................................................................................................................. 4

Generate Ring Signal ................................................................................................................................................... 4

Password Required ...................................................................................................................................................... 4

Intercom Port Address ................................................................................................................................................. 4

Full Duplex Method ..................................................................................................................................................... 6

Internal DIP Switch (S202) ........................................................................................................................................................ 6

Ring Count ....................................................................................................................................................................6

DTMF or Pulse Dial Selection .....................................................................................................................................7

Point-to-Point Seize ...................................................................................................................................................... 7

One Touch Dial ............................................................................................................................................................. 7

Fast Seize ....................................................................................................................................................................... 7

DSP Full or Half Duplex Selection ..............................................................................................................................7

Audio Ducking .............................................................................................................................................................. 7

Internal DIP Switch (S203) ........................................................................................................................................................ 7

Rack Mounting ........................................................................................................................................................................... 7

Connections ................................................................................................................................................................................. 7

Intercom ........................................................................................................................................................................ 7

Telephone and Telephone Line .................................................................................................................................... 7

Power Supply ................................................................................................................................................................ 8

Setting Audio Levels ................................................................................................................................................................... 9

Setting audio levels to intercom matrix ......................................................................................................................9

Setting audio levels to telephone line ..........................................................................................................................9

Configuring for Country’s Telephone System.......................................................................................................................... 9

OPERATION ............................................................................................................................................ 9

Operation From A Keypanel ..................................................................................................................................................... 9

Programming a key to use the TIF 2000 .................................................................................................................... 9

Dialing a call ............................................................................................................................................................... 10

Hanging up .................................................................................................................................................................. 10

Re-dialing the last number ........................................................................................................................................ 10

Dialing a speed dial number ...................................................................................................................................... 10

Storing a speed dial number ...................................................................................................................................... 10

Answering a call ......................................................................................................................................................... 10

TIF 2000 System Setup to Receive Calls ................................................................................................................................ 11

Auto Answer Mode ..................................................................................................................................................... 11

Manual Answer Mode ................................................................................................................................................ 11

Using The TIF 2000 From The Telephone .............................................................................................................................. 11

DTMF Codes ............................................................................................................................................................... 12

SPECIFICATIONS ................................................................................................................................ 13

TELEPHONE INTERFACE REQUIREMENTS FORM .................................................................. 14

3

INTRODUCTION

INSTALLATION

This manual describes the installation, programming, and
operating procedures for the RTS Model TIF 2000 Digital
Hybrid Telephone Line Interface. Since TIF 2000 functions
as a keypanel, the user may also need to refer to the
manuals and/or on-line help files for CSedit, ADAMedit, or
ZEUSedit for information on configuring certain features.

Important! Be sure to review any recently added
supplemental information before proceeding.
Supplements are placed at the back of the manual.

DESCRIPTION

The TIF 2000 is a single line digital hybrid telephone line
interface designed to be compatible with ADAM,
ADAM CS, ZEUS, and CS 9000 series intercom systems. It
provides bi-directional communication between the inter­com matrix and a standard DTMF capable telephone line. It
allows the phone to access all crosspoints of the matrix, as
well as dynamic party lines, IFB circuits, and other forms of
communications. The 1U high by ½ wide rack mountable
(via an optional kit) TIF 2000 provides a transparent link to
the telephone system enabling full dial-out capability from
any designated keypanel with keypad. The TIF 2000 has full
dial-in capability giving the caller a keypanel on the system
via commands from the DTMF pad on their telephone.
Since the TIF 2000 appears to the matrix as any other
keypanel would, the only limitation on the number of units
in the system is the same as for other keypanels.

Front Panel Features

Power
Indicator

Seizes &
Drops Line

Line Mode
Indicator

Figure 1 - TIF 2000 Front Panel Features

Audio to Matrix
Level Meter

Audio to Matrix
Level Adjustment

Rear Panel Features

Audio to Telephone Line
Level Meter

Audio to Telephone Line
Level Adjustment

Unpacking

The TIF 2000 shipping box should contain the following
items:

1 TIF 2000 Unit
1 Power Supply
1 IEC Power cord
1 User Manual
1 Software Disk containing country specific
telephone system configuration files.

If anything is missing or damaged, contact the shipper or
T elex immediately.

Rear Panel DIP Switch (S201)

The rear panel DIP switch contains switches to configure
the most often changed options. These include: auto answer
on/off, ring signal on/off, password on/off, intercom port
address, and full duplex method.

Auto Answer

Turning on the auto answer option will set the unit to
answer the phone automatically when it rings. The number
of rings required before it answers is determined by the
setting of internal DIP switch (S202). If auto answer is
turned off, the line will ring until someone at a keypanel
answers the call or until the Select button on the TIF 2000’s
front panel is pressed. To turn on auto answer, place switch
1 in the down position. To turn off auto answer, place switch
1 in the up position.

Generate Ring Signal

Turning on the generate ring signal option sets the unit so
that when the phone line is ringing, keypanels that are
configured to receive ring signals will produce an audible
ring. To turn on the ring signal, place switch 2 in the down
position. To turn off the ring signal, place switch 2 in the up
position.

Passwo rd Required

Turning on the password required option sets the unit so that
when a call is automatically answered, the user must enter a
password via DTMF before the unit will allow communica­tions. The password numeric sequence and length are
determined by the settings of internal DIP switch (S203). To
turn on the password required option, place switch 3 in the
down position. To turn off the password required option,
place switch 3 in the up position.

Intercom Matrix
Connections

Data Present Address &

Configuration

Figure 2 - TIF 2000 Rear Panel Features

Telephone Line
Connections

Power

Intercom Port Address

Switches 4 to 7 determine the address of the unit. The port
address is expressed in binary with switch 4 being the least
significant bit (LSB) and switch 7 being the most significant
bit (MSB). To turn on (set bit to 1), place the desired switch
in the down position. To turn off (set bit to 0), place the
desired switch in the up position. ADAM, ADAM CS, and

4

Table 1- Correspondence between address numbers and intercom port numbers for ADAM, ADAM CS, and Zeus systems
