RTI XP-8v, XP-6s Reference Manual
XP-8v
Advanced Control Processor
Reference Guide
XP-8v Advanced Control Processor
The XP-8v is a high-end remote control processor for automating the operation of electronic systems in homes and
ofce buildings. The combination of a blazing fast MPU, real-time/multitasking operating system, and tremendous
expansion capability, make the XP-8v the perfect solution for large-scale and complex projects.
The XP-8v provides superior quality and reliability as well as these features:
• Powerful 1GHz internal processor.
• 4Gb of non-volatile ash memory.
• One HDMI output for on screen display (OSD) video interface
• Eight multi-purpose I/O ports.
• Eight programmable relay outputs.
• Eight two-way RS-232 ports.
• Eight sense inputs.
• Multi-purpose I/O ports are compatible with industry-standard IR emitters, blasters and repeater systems.
• Multi-purpose I/O ports support all optional RTI power sensing and communications modules.
• All output ports incorporate both short-circuit and overload protection.
• Variable IR output on all ports.
• Front panel controls/display (11 Buttons for front panel control).
• Non-volatile Flash memory stores your system conguration even when power is not present.
• Field upgradeable rmware.
• USB and Ethernet programming.
• Compatible with RTI 433MHz and 2.4GHz Zigbee® RF modules.
• Astronomical clock built in for time-based event programming.
• Designed for rack mount or free standing installations.
Touchscreen Control Panel
GND
INPUT
HIGH OUT
USB
EXPANSION
12VDC,1A
+
INFRARED
RTI COM
VIDEO OUT
ETHERNET
POWER
8
A B
3A @ 30VDC MAX EA. RELAY / 100mA MAX EA. TRIGGER OUTPUT
12VDC
GND
INPUT
HIGH OUT
USB
EXPANSION
12VDC,1A
+
+
INFRARED
RTI COM
VIDEO OUT
ETHERNET
POWER
To
Mute
PDM1
Phone Doorbell Module
Remote Technologies Inc.
www.rticorp.com
Made in Taiwan
PDM1/01
Phone Doorbell Module
PDM-1
S/N Model
117 612 914
P/N 20-210126-14
TO DOORBELLS
TO TEL
#1 #2
PDM-1
Rear - Front
Doorbell
USB
EXPANSION
12VDC,1A
+
RTI COM
VIDEO OUT
ETHERNET
POWER
Installation & Operation
PROGRAMMING THE XP-8v
The XP-8v must be programmed to operate. All programming is done using RTI’s Integration Designer® software and is downloaded using the USB
Programming Port located on front of XP-8v or via Ethernet.
UPDATING FIRMWARE
It is highly recommended that this and all RTI products have the latest rmware installed. The rmware can be found in the Dealer section of the RTI
website (www.rticorp.com). Install the rmware using the USB Programming Port located on the front of XP-8v.
MPIO PORTS - Control via Infrared, Sensing and RS-232 (One-way)
RS-232
1
MULTI-PURPOSE I/O PORTS
INFRARED OUT / SERIAL OUT / POWER SYNC IN
1
42
3
567
234
8
7
5
6
Voltage From
Power Supply
CM-232 Communication Module
(RS-232 One-way)
SENSE INPUTS
VOLTAGE / CLOSURE 3A @ 30VDC MAX EA. RELAY / 100mA MAX EA. TRIGGER OUTPUT
1 42 3 5 6 7 8
A B A B
A B
A B A B
A B
8
A B A B
RELAY / TRIGGER OUTPUTS
1 42 3 5 6 7 8
A B A B
A B
A B A B
A B
IR Connecting Block
Each IR output can drive up to
four emitters directly. More than
four emitters require an amplied
connecting block.
Direct to IR Port
Single or Dual
IR Emitters
IR Emitter
Equipment with switched outlet
or voltage trigger output
INFRARED
12VDC
INPUT
HIGH OUT
GND
+
A B
A B
INFRARED EMITTERS
The multi-purpose I/O ports on the XP-8v are compatible with industry
standard infrared emitters and infrared repeating systems. Each output port is
capable of driving up to four infrared emitters directly. The use of more than
four infrared emitters requires the addition of an amplied connecting block. A
connecting block can be wired up to 1000 feet away from the XP-8v using #22
AWG (minimum) wire.
INFRARED OUTPUT GAIN ADJUSTMENT
The IR output gain can be separately adjusted for each of the eight output
ports. The XP-8v is shipped with the IR gain set to the optimum level for most
equipment, and it should only need to be adjusted if the attached equipment is
not responding reliably. If adjustment is needed, rotate the IR output controls
on the front of the XP-8v clockwise for higher output power, or counterclockwise for lower output power.
NOTE: The IR output feedback LEDs located on the front of the XP-8v will
illuminate when any IR code is delivered out of a port. This includes IR codes
“passing through” from another source, such as an IR receiver.
VPS-1 SENSOR MODULE
The multi-purpose I/O ports on the XP-8v are compatible with RTI power
sensing modules (e.g. VPS-1). Follow the guide included with the modules
for installation instructions, and follow the instructions in the Integration
Designer® software for programming details.
RS-232 COMMUNICATION MODULES (CM-232)
The multi-purpose I/O ports on the XP-8v are compatible with RTI RS-232
communication modules (e.g. CM-232). Follow the guide included with
the modules for installation instructions, and follow the instructions in the
Integration Designer® software for programming details.
RS-232 PORTS
RS-232
1
3
2
4
MULTI-PURPOSE I/O PORTS
INFRARED OUT / SERIAL OUT / POWER SYNC IN
1
42
3
567
8
7
5
6
1 42 3 5 6 7 8
A B A B
8
SENSE INPUTS
VOLTAGE / CLOSURE
A B
A B
A B A B
A B A B
RELAY / TRIGGER OUTPUTS
1 42 3 5 6 7
A B A B
A B
A B A B
A B
A B
Cat-5
Adapter
HVAC
TV
Lighting
SENSE INPUTS / RELAY-TRIGGER OUTPUTS
Sense inputs and relay-trigger modes are congured within Integration
Designer®.
3
4
7
8
Doorbell
SENSE INPUTS
VOLTAGE / CLOSURE 3A @ 30VDC MAX EA. RELAY / 100mA MAX EA. TRIGGER OUTPUT
1 42 3 5 6 7 8
A B A B
A B
A B
A B
+ -
-
+
Receiver
RELAY / TRIGGER OUTPUTS
A B
A B
1 42 3 5 6 7 8
A B
A B A B
A B
A B
A B
A B
A B
+ -
Screen Lift
A B
+
12VDC
+
-
The XP-8v is capable of two-way control using RS-232 communication via eight RJ-45
output ports using standard Cat-5 cable with RJ-45 termination (568B). The XP-8v ships
with eight RJ-45 (female) to DB-9 (male) adapters.
IMPORTANT NOTE: RS-232 communication cabling should be limited to 50 feet (16m)
depending on baud rate.
DB-9 - RJ45 ADAPTOR PINOUT
RJ-45 (XP-8v RS-232 Output)
Pin Signal Signal
Name Description
1 DSR Data Set Ready
2 DCD Carrier Detect
3 DTR Data Terminal Ready
4 GND Signal Ground/Common
5 RXD Receive Data
6 TXD Transmit Data
7 CTS Clear To Send
8 RTS Request To Send
DB-9
Pin Signal Signal
Name Description
1 DCD Carrier Detect
2 RXD Receive Data
3 TXD Transmit Data
4 DTR Data Terminal Ready
5 GND Signal Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 NC Not Connected
SENSE INPUT
Upon sensing contact closure or a voltage (2-24VDC), events can be
automatically triggered such as a macro or command.
Sense contact closure: Connect conductors from the source device
to each side of a sense input (A and B).
Sense voltage trigger: Connect positive lead from voltage source to
Side A of sense input and ground lead to Side B.
RELAYS/TRIGGER OUTPUTS
Relays may be congured as a dry contact closure or a voltage trigger
output (12VDC @100mA). All relays are Normally Open when not
Shades
energized, and may be programmed to behave Normally Closed (as long
as power is applied to the XP-8v).
Contact closure: Connect the A and B contact terminals of a relay
to the device.
Voltage trigger: Connect contact A to the positive lead and connect
Contact B to the ground lead of the device.
