1
It’s Under Control
®
T2-B
70-210035-18 V1.0
Universal System Controller
It’s Under Control
®
Operation Guide
Universal System Controller
T2-B
2
Copyright © 2008
Remote Technologies Incorporated
All rights reserved.
3
It’s Under Control
®
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including
interference that may cause undesired operation.
MMURTI1000
IC (Canada): 3166-RTI1000
117 612 914
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI
website at: www.rticorp.com/declaration
FEDERAL COMMUNICATIONS COMMISSION NOTICE
Universal System Controller
T2-B
4
For environmental reasons, your T2-B Universal System
Controller uses “environmentally sound” Lithium-ion
rechargeable batteries. These batteries do not contain any
poisonous heavy metals that can damage the environment.
In the interest of recycling, please do not dispose of these batteries in the
household waste at the end of their useful life. Instead, dispose of them at
an appropriate collection site.
SAFETY SUGGESTIONS
Read Instructions. Read all safety and operating instructions before
operating the unit.
Retain Instructions. Keep the safety and operating instructions for future
reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating
instructions.
Follow Instructions. Follow operating instructions and instructions for use.
Heat. Keep the unit away from heat sources such as radiators, heat
registers, stoves, etc., including ampliers that produce heat.
Do Not Open Battery Compartment. This device contains Lithium-Ion
or Lithium-Polymer batteries. Batteries should only be replaced by an
authorized service center or trained installer.
Power Sources. Connect the unit only to a power supply of the type
described in the operating instructions, or as marked on the unit.
Power Cord Protection. Route power supply cords so that they are not
likely to be walked on or pinched by items placed on or against them,
paying particular attention to the cord plugs at power receptacles and at the
point at which they exit from the unit.
Water and Moisture. Do not use the unit near water—for example, near a
sink, in a wet basement, near a swimming pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled
into the enclosure through openings.
Servicing. Do not attempt any service beyond that described in the
operating instructions. Refer all other service needs to qualied service
personnel.
Damage Requiring Service. The unit should be serviced by qualied
service personnel when:
The power supply cord or the plug has been damaged.
Objects have fallen or liquid has been spilled into the unit.
The unit has been exposed to rain.
The unit does not appear to operate normally or exhibits a marked
change in performance.
The unit has been dropped or the enclosure has been damaged.
BATTERY DISPOSAL
Li-ion
5
It’s Under Control
®
WARNING!
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THE UNIT TO RAIN OR MOISTURE.
Universal System Controller
T2-B
6
Remote Technologies Incorporated warrants its products for a period of
one (1) year (90 days only for included battery packs) from the date of
purchase from Remote Technologies Incorporated or an authorized Remote
Technologies Incorporated distributor.
This warranty may be enforced by the original purchaser and subsequent
owners during the warranty period, so long as the original dated sales receipt
or other proof of warranty coverage is presented when warranty service is
required.
Except as specied below, this warranty covers all defects in material and
workmanship in this product. The following are not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Remote Technologies
Incorporated.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence or
experience of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modied or
removed.
Remote Technologies Incorporated is not liable for any damages caused by its
products or for its failure of its products to perform, including any lost prots,
lost savings, incidental damages, or consequential damages.
Remote Technologies Incorporated is not liable for damages based upon
inconvenience, loss of use of the product, loss of time, interrupted operation,
commercial loss, any claim made by a third party or made by you for a third
party.
Remote Technologies Incorporated’s liability for any defective product is
limited to repair or replacement of the product, at our option.
If your T2-B Universal System Controller needs service, please contact
Remote Technologies Incorporated by telephone, fax or E-mail for return
information. Please do not return products to Remote Technologies
Incorporated without return authorization.
All rights are reserved. No part of this document may be photocopied,
reproduced, or translated without the prior written notice of Remote
Technologies Incorporated.
The information contained in this document is subject to change without
notice. Remote Technologies Incorporated shall not be liable for errors or
omissions contained herein or for consequential damages in connection with
the furnishing, performance, or use of this guide.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
Other brands and their products are trademarks or registered trademarks of
their respective holders.
T2-B, Integration Designer, and the RTI logo are registered trademarks of
Remote Technologies Incorporated.
LIMITED WARRANTY AND DISCLAIMER
7
It’s Under Control
®
Federal Communications Commission Notice ............... 3
Battery Disposal .......................................................... 4
Safety Suggestions ...................................................... 4
Limited Warranty and Disclaimer ............................... 6
Table of Contents ........................................................ 7
Chapter 1 - Welcome ................................................... 9
Compatibility ............................................................ 9
Software Requirements ..............................................9
Unpacking and Inspection ........................................ 10
Product Contents .................................................... 10
Chapter 2 - Introduction ............................................ 11
Features ................................................................ 11
Important Notes ..................................................... 11
Cleaning ................................................................ 12
Battery and Docking Station ..................................... 12
Getting Started ...................................................... 13
Remote Reference ................................................... 14
Docking Station Reference ....................................... 16
Chapter 3 - Operation ................................................ 17
Programming the T2-B ............................................ 17
The Touchscreen Display .......................................... 17
The Main Menu ........................................................ 17
The Control Panel Page ............................................ 18
Adjust Contrast ................................................... 18
Beeper ................................................................19
Time Out ............................................................ 19
Tilt Switch........................................................... 19
Light Sensor .........................................................20
Backlight Level ..................................................... 20
Change Passcode ................................................. 21
Clear All ............................................................. 22
Chapter 4 - Specications .......................................... 23
Chapter 5 - Troubleshooting ...................................... 25
Chapter 6 - Service and Support ................................ 27
Index ........................................................................ 29
TABLE OF CONTENTS
Universal System Controller
T2-B
8
9
It’s Under Control
®
CHAPTER 1 | WELCOME
Thank you for purchasing the T2-B Universal System Controller.
The T2-B combines the power and exibility of a graphic LCD touchscreen
with an ergonomic design that permits effortless one-handed operation. This
design overcomes the need for a compromise between form and function.
Sleek and perfectly balanced, the T2-B takes complete control of the home
theater, replacing all other remotes. It features an intuitive, easy to read
LCD that can display custom buttons, text, graphics, symbols, icons, and
scrolling lists. In addition to the backlit display, a variety of “hard” keypad
buttons allow easy access to frequently used functions.
Programming is easy and convenient thanks to the Windows® based
Integration Designer™ software. Because RTI’s remote control products are
sold only through professional installers/programmers, and never directly to
consumers, it is our philosophy to not incorporate programming capability
directly into our products. Instead, we are committed to providing our
dealers with the hardware and software tools that allow them to create
re-usable programming databases and templates in the most efcient and
reliable way possible.
The T2-B is capable of both infrared and radio frequency output. Optional
RF receivers are available for transmission through walls and cabinets. The
RF receivers connect to an RTI control system for the ultimate in control
reliability and exibility. RTI control systems provide many advanced
features such as IR routing, local macro execution, power sensing, and RS232 control.
COMPATIBILITY
The T2-B and Integration Designer™ software are compatible with infrared
(IR) commands with carrier frequencies between 15KhZ and 460KhZ, as
well as those commands that do not use a carrier. This covers virtually all
of the remotes that exist to date.
SOFTWARE REQUIREMENTS
The recommended minimum system requirements needed to run the
Integration Designer™ software are as follows:
Windows 2000®, Windows XP® or later version.
A free USB port.
At least 256 Megabytes of RAM.
At least 250 Megabytes of free disk storage.
Screen resolution of 800x600 with 16-bit color.
Optional printer for printing reports.
Universal System Controller
T2-B
10
CHAPTER 1 | WELCOME
UNPACKING AND INSPECTION
After unpacking your new T2-B Universal System Controller, save all of the
packing materials in case you ever have to ship the unit.
Thoroughly inspect the T2-B and packing materials for signs of damage.
Report any damage to the carrier immediately. Report any equipment
malfunctions to Remote Technologies Incorporated or an authorized
Remote Technologies Incorporated distributor.
PRODUCT CONTENTS
Contents within the box include the following items:
One (1) T2-B Universal System Controller
One (1) Docking station
One (1) Universal power supply for docking station
One (1) Operation guide
11
It’s Under Control
®
CHAPTER 2 | INTRODUCTION
FEATURES
The T2-B provides superior quality and reliability as well as these features:
Comfortable ergonomic design permits effortless, one-handed
operation.
Easy-to-read LCD to display custom buttons, text, graphics and scrolling
lists.
Digital matrix touchscreen never needs calibration.
Tilt switch can automatically turn on the backlight when picked up.
Extremely bright, backlit display and keypad.
Three-way rocker switch for scrolling list navigation.
Intuitive layout of keypad buttons for commonly used functions
Transmits IR and RF (or both - on a single button press!).
Optional RF receiver allows you to transmit through walls, cabinets, etc.
System includes a Lithium-Ion battery and docking station.
Extremely wide IR transmitting frequency range.
Optional ‘Voltage’ and ‘Video’ sensing modules to monitor power status
of equipment when used with certain RTI processors.
Optional interface for RS-232 controlled equipment when used with
certain RTI processors.
Non-volatile Flash memory stores your system conguration even when
power is not present.
Field upgradable rmware.
USB Programming.
IMPORTANT NOTES
Please read these important notes about the T2-B:
The T2-B should be placed in an area where it is around normal room
temperature (between 60° F to 90° F). If the temperature is too hot,
the display appears dim. If the temperature is too cold, the display
appears dark and may respond slowly.
Do not use sharp objects on the touchscreen. It is designed to operate
with a touch of your nger.
Do not let the T2-B get wet. It should not be handled with wet hands or
placed in an area where it could get wet.
Do not subject the T2-B to smoke, dust, or vibrations. The display may
be damaged from excessive shock or vibration.
Only use the power supply that is provided with the T2-B. Using the
wrong type of power supply may result in damage to the battery or
electronic components.
Do not disassemble the unit. Service of the T2-B should be performed
by authorized personnel only.
Universal System Controller
T2-B
12
CHAPTER 2 | INTRODUCTION
CLEANING
Occasional cleaning may be required, depending on use. It is
recommended that you create a “Clean” button somewhere on the Home
page of the T2-B. This button should link to a page that does not contain
commands or macros that could be inadvertently executed while cleaning
the unit. The “Clean” page could contain a text message or graphic of your
choosing such as:
To clean your T2-B, lightly dampen a lint-free cloth with a glass cleaner or
mild detergent, and wipe the touchscreen, keypad and outer surfaces.
BATTERY AND DOCKING STATION
The T2-B uses a Lithium-Ion rechargeable battery. This battery does
not exhibit any type of “Memory Effect” from being charged too often.
Since the T2-B can safely be charged after each use, a docking station is
included for convenience. If left out of the docking station, the T2-B will
remain in sleep mode for 1 – 2 months before shutting down. At that point
the battery must be recharged.
The T2-B Docking Station can be placed on a at surface such as a shelf or
table, or it can be mounted to a wall using the mounting holes on the back
of the unit.
If the T2-B battery capacity is reduced to approximately one hour of
remaining run-time, a low battery icon will appear in the upper left corner
of the display:
At this point the T2-B must be placed into the docking station to recharge
the battery.
The docking station LED illuminates red to indicate a charge in progress.
The LED will illuminate blue when the battery in the unit is fully charged
13
It’s Under Control
®
or does not need to be charged. A fully discharged battery will take
approximately 2-4 hours to completely re-charge.
GETTING STARTED
NOTE: The following steps for initial installation including removing the
battery door should be performed by an authorized service center or
trained installer only.
Start by inserting the battery connector into the mating plug on the T2-B.
Make sure the connector is oriented properly before attempting to insert
it. Next, turn the unit on by sliding the power switch into the “ON” position
(toward the battery).
The T2-B is turned-on by touching any area of the display or any keypad
button. If the tilt sensor is enabled, picking up the unit will also turn it on.
During normal use the T2-B turns-on instantly from its sleep mode.
POWER
SWITCH
Universal System Controller
T2-B
14
CHAPTER 2 | INTRODUCTION
FRONT
REMOTE REFERENCE
LIGHT
SENSOR
HOME PAGE
BUTTON
IR TRANSMISSION
WINDOW
KEYPAD
BUTTONS
3-WAY ROCKER
SWITCH
BACKLIGHT
BUTTON
FRAME SCROLL
BUTTONS
TOUCHSCREEN
DISPLAY
15
It’s Under Control
®
BACK
AUDIO
SPEAKER
USB
PROGRAMMING
PORT
DOCKING STATION
CONTACTS
POWER
SWITCH
LITHIUM-ION
BATTERY PACK
Universal System Controller
T2-B
16
CHAPTER 2 | INTRODUCTION
TOP
BACK
DOCKING STATION REFERENCE
CHARGE
CONTACTS
CHARGE LED
POWER JACKWIRE GUIDE
WALL MOUNT
HOLES
2-1/2 in.
(63 mm)
17
It’s Under Control
®
CHAPTER 3 | OPERATION
PROGRAMMING THE T2-B
The T2-B is programmed using Integration Designer™ software, RTI
dealers can download the software from:
www.rticorp.com/dealers
A PC running Windows® 2000 or higher with a USB port is required. The
required USB cable is included with the RTI IR-PRO dealer kit.
THE TOUCHSCREEN DISPLAY
The touchscreen display is organized as a series of pages and frames.
A page can consist of up to 12 frames of information having one frame
displayed on the screen at a time.
Normally each frame on a page contains objects (buttons, text, graphics,
and symbols) that are related in some way. For instance, they may all
display information necessary for controlling a particular VCR.
THE MAIN MENU
By default, the remote has one Main Menu page; all other pages are
considered submenus. Any page can contain a button that will display any
other page when selected.
Normally the Main Menu page is used to display the names of the
submenus (e.g., the equipment being controlled). The submenus may
consist of one or more pages. The remote will support 63 pages plus the
Main Menu page; each page can consist of up to 12 frames.
A representation of a programmed Main Menu page is shown below.
Pressing the Main Menu key at any time will return you to the Main Menu
page (unless a different page is assigned using Integration Designer™
software).
Universal System Controller
T2-B
18
CHAPTER 3 | OPERATION
THE CONTROL PANEL PAGE
The Control Panel page can be displayed by pressing and holding the
backlight key for at least 3 seconds.
You can also access the Control Panel page by assigning a “Control Panel”
page link to a button using Integration Designer™ software.
The Control Panel consists of the following two frames:
To change frames, press the frame Left or frame Right
buttons on the bottom of the touchscreen.
To return to your Main Menu, press the Main Menu key.
ADJUST CONTRAST
This button displays a window that allows you to adjust the LCD contrast.
Press the Left Arrow or Right Arrow keypad buttons to adjust. Press the OK
button in the window to close.
19
It’s Under Control
®
BEEPER
This button displays a window that allows you to turn the audible beep On
or Off. The beeper provides feedback that a button was pressed. Press the
OK button in the window to close.
TIME OUT
This button displays a window that allows you to adjust the amount of time
the unit stays awake after the last button press. The time is variable from
1 second to 60 seconds (default is 10 seconds). Press the arrows to the
left or right of the Time Out setting to adjust the time. Press the OK button
in the window to close. During Sleep mode, the remote uses virtually no
battery power.
TILT SWITCH
This button displays a window that allows you to adjust the settings for the
built in tilt switch, which is a device that turns the remote on when tilted
past a 45 degree angle.
On means the tilt switch is active and will turn on display and backlight
when picked up.
Off means the tilt switch is inactive.
Press the OK button in the window to close.
Universal System Controller
T2-B
20
CHAPTER 3 | OPERATION
LIGHT SENSE
This button displays a window that allows you to enable or disable the front
panel ambient light sensor.
On means the Light Sensor is enabled. This will cause the backlight
brightness to dim or brighten in response to changes in the ambient room
light.
Off means the Light Sensor is disabled.
Press the OK button in the window to close.
BACKLIGHT LEVEL - Light Sensor Disabled
This button displays a window that allows you to adjust the backlight
brightness for the T2-B. If the light sensor is disabled, there is only one
backlight level to adjust. Press the left arrow or right arrow buttons in the
window to adjust. Press the OK button in the window when nished.
BACKLIGHT LEVEL - Light Sensor Enabled
If the light sensor is enabled, there are two backlight levels to adjust. The
backlight brightness will automatically change between the two levels,
depending upon the ambient lighting conditions. Press the left arrow or
right arrow buttons in the window to adjust. Press the OK button in the
window when nished.
21
It’s Under Control
®
CHANGE PASSCODE
This button displays a window that allows you to set the passcode that is
used to limit access to the Clear All function on the control panel page, as
well as the Button Lockout function that is available on all buttons.
When you press the Change Passcode button, the screen will prompt you
to enter the old passcode using the hard keys, then press the Enter key on
the keypad.
(The default code is 0000).
Now enter a new four-digit passcode, then press Enter.
You will be prompted to enter the new four-digit passcode again for
conrmation, then press Enter.
When new code is entered successfully, the Code Changed window will pop
up to let you know you have changed the passcode.
Do not forget the passcode!
Universal System Controller
T2-B
22
CHAPTER 3 | OPERATION
CLEAR ALL
This button displays a window that will allow you to erase the current
program in the remote. When the button is pressed, you will be prompted
to enter the current passcode. If the proper code is entered, the entire
program in the remote will be erased.
WARNING!
This will erase the complete program in the remote with
no way to restore it, except by reloading the program
from the Integration Designer™ software!
If you inadvertently press the CLEAR ALL button, simply press the ENTER
button without entering the passcode and you will be returned to the
Control Panel page.
23
It’s Under Control
®
Power 3.6 VDC, 1200 mAh Lithium-Ion Battery Pack
Power Management Automatic On/Off (tilt switch)
Infrared Control
Range
30 feet (9.1 meters) @ 60 degrees
Infrared Frequency
Transmission Range
15 kHz - 460 khz
Radio Frequency
Control Range
Up to 100 feet (30.5 meters)
with optional System Interfaces/Processors
Radio Frequency
Carrier
433 MHz
Operating
Temperature
+32° F to +122° F (0° C to +50° C)
Operating Humidity 5% to 95% Non-condensing
Touchscreen Display High-contrast STN LCD Digital Matrix
64 x 128 pixels
(touchscreen never needs calibrating)
Display Size (H x W) 2.4 in x 1.3 in (61 mm x 33 mm)
Backlights White LED (display), Blue/Red/White LED
(keypad)
Nominal Run Time
on Full Charge
6 hours minimum, continuous use
(10 to 15 days on average use)
Standby Time on
Full Charge
30 days
Battery Charge Time 3 to 4 hours
Total System
Memory
256 K Flash (non-volatile) memory
Device Capability Total number of devices is limited only by memory
Macro Capability Unlimited steps in a single macro
Total number of macros is limited only by memory
Macro capability on every button
Communications USB programming port
Dimensions
(L x W x D)
9.75 in (248 mm) x 2.5 in (64 mm) x 1.0 in
(25 mm)
Enclosure High-impact molded ABS plastic
Weight 8.5 oz. (243 g) with battery pack
Warranty One Year (Parts & Labor) / 90 days on battery
CHAPTER 4 | SPECIFICATIONS
All specications subject to change without notice.
Universal System Controller
T2-B
24
25
It’s Under Control
®
CHAPTER 5 | TROUBLESHOOTING
If you are having problems with your T2-B Universal System Controller,
please read the information below before contacting technical support.
If you continue to have problems, see Chapter 6 for more information on
contacting RTI technical support.
DISPLAY IS DIM, BLANK OR UNREADABLE
Make sure the battery pack connector is attached properly and the
battery is charged.
Try adjusting the contrast or backlight level from the Control Panel
page (Refer to Chapter 3 for more details). By nature, the contrast of
an LCD screen changes with temperature, so if the remote is cold the
display will be dark and will return to normal as it warms.
USB COMMUNICATIONS PROBLEMS
Verify that your PC is running Windows® 2000 or higher.
Verify that the T2-B USB driver was installed the rst time the T2-B
was connected to your PC.
Verify that the T2-B is present in the Device Manager within the
Windows® Control Panel.
Make sure you are using the programming cable that was supplied by
RTI and that both ends are connected securely.
Make sure the PC detects the presence of the T2-B. If it doesn’t,
unplug the USB cable, wait for about ten seconds, and plug it in again.
If the download fails after some data has been transferred, try re-
sending the program.
IR CODE PROBLEMS
If you are using an IR repeater system, make sure it is working
correctly with the original OEM remote. If not, you will need to
troubleshoot the IR repeater system.
If you are still having problems, try adjusting the IR code “Minimum
Repeats” value in the Integration™ Designer programming software.
If the IR code is executed inside a macro that contains multiple IR
codes, try inserting a small time delay before the problem code. If
there already is a delay, try increasing it.
Universal System Controller
T2-B
26
27
It’s Under Control
®
For news about the latest updates, new product information, and new
accessories, please visit our web site at:
www.rticorp.com
CONTACTING RTI
For general info, you can contact RTI at:
Tel. (952) 253-3100
Fax (952) 253-3131
info@rticorp.com
RTI TECHNICAL SUPPORT
At RTI, customer service and satisfaction is an utmost priority. If you are
encountering any problems or have a question about your RTI product,
please contact RTI Technical Support for assistance.
RTI provides technical support by telephone, fax or e-mail. For the highest
quality service, please have the following information ready, or provide it in
your fax or e-mail.
Your Name
Company Name
Telephone Number
E-mail Address
Product model and serial number (if applicable)
If you are having a problem with hardware, please note the equipment in
your system, a description of the problem, and any troubleshooting you
have already tried.
If you are having a problem with software, please note what version you
have installed, the operating system on your PC, a description of the
problem, and any troubleshooting you have already tried.
If you are calling about a software or programming question or problem,
please be at you computer when you place your call. This will considerably
speed up the troubleshooting process.
For technical support or assistance with your T2-B, software, or
accessories, contact RTI at:
(952) 253-3137
support@rticorp.com
www.rticorp.com
For questions regarding service or repair of your T2-B, contact RTI at:
(952) 253-3136
service@rticorp.com
www.rticorp.com
Please do not return products to RTI without return authorization.
CHAPTER 6 | SERVICE AND SUPPORT
Universal System Controller
T2-B
28
CHAPTER 6 | SERVICE AND SUPPORT
Shipment of T2-B for Service
RTI will pay all labor and material expenses for all repairs covered by this
product’s warranty. If necessary repairs are not covered by warranty, or if
a unit is examined which is not in need of repair, you may be charged for
the repairs or examination.
If it is necessary to ship the T2-B Universal System Controller for service:
Please pack it securely (we suggest that it be insured).
Do not include accessories such as power cords or manuals unless
instructed to do so.
You must pay any shipping charges incurred in getting your T2-B Universal
System Controller to RTI. RTI will pay reasonable return shipping charges
via a carrier of our choice to any destination within the United States if the
repairs are covered under warranty.
A copy of the original dated sales receipt must be provided whenever
warranty service is required. You will need this receipt to establish the date
of purchase.
29
It’s Under Control
®
INDEX
Battery ...................................................................................... 12
Disposal .................................................................................... 4
Cleaning ..................................................................................... 12
Compatibility ................................................................................ 9
Contents ...................................................................................... 7
Docking Station ........................................................................... 12
Docking Station Reference ......................................................... 16
Features ..................................................................................... 11
Federal Communications Commission Notice ..................................... 3
Getting Started ........................................................................... 13
Important Notes .......................................................................... 11
Introduction ................................................................................ 11
Remote Reference .................................................................... 14
Limited Warranty and Disclaimer .................................................... 6
Operation ................................................................................... 17
Product Contents ......................................................................... 10
Programming the T2-B ................................................................. 17
Safety Suggestions ........................................................................ 4
Service and Support .................................................................... 27
Contacting RTI ......................................................................... 27
RTI Technical Support ............................................................... 27
Shipment of T2-B for Service ........................................................ 28
Software Requirements .................................................................. 9
Specications .............................................................................. 23
Touchscreen Displays ................................................................... 17
Adjust Contrast ....................................................................... 18
Backlight Level ......................................................................... 20
Beeper .................................................................................... 19
Change Passcode ...................................................................... 21
Clear All ................................................................................... 22
Control Panel Page .................................................................... 18
Light Sensor ............................................................................ 20
Main Menu ................................................................................ 17
Tilt Switch ............................................................................... 19
Time Out ................................................................................. 19
Troubleshooting ........................................................................... 25
Display Problems ...................................................................... 25
IR Code Problems ..................................................................... 25
USB Communications Problems .................................................. 25
Unpacking and Inspection ............................................................. 10
Universal System Controller
T2-B
30
Remote Technologies Incorporated
5775 12th Avenue East, Suite 180
Shakopee, MN 55379
Tel: 952-253-3100
Fax: 952-523-3131
www.rticorp.com
© 2008 Remote Technologies Inc. All rights reserved. Printed in Taiwan.
It’s Under Control
®
Loading...
