Rti RP-4 User Manual

RP-4

Control Processor

Quick Reference Guide

The RP-4 Control Processor is a powerful central controller that is designed for reliable control of audio/
video and other electronic systems. It combines an integrated 433MHz RF receiver, four assignable IR ports,
relays, support for the RTiPanel App (ver 1.2 or higher) and more — all in a small, cost-effective package.
The RP-4 is the perfect control processor for single room installations such as home theaters, media centers,
and bedrooms.

The RP-4 provides superior quality and reliability as well as these features:

• Stores all system commands and macros for reliable control.

• Integrated 433MHz RF receiver.

• Four infrared ports with routing and output adjustment.

• Supports RTiPanel App for one-way control via smart phones and tablets.

• Two voltage sense inputs for reliable, predictable control of devices.

• Two programmable relay outputs.

• Works with all RTI 433MHz wireless interfaces.

• RF signal reception LED.

• USB and Ethernet programming.

Touchscreen Control Panel

Connection Options

Status Lights

Antenna

IR Output Adjustment Controls

Reset Button

Power

Supply

STATUS NETLINK RF LINK

RESET

POWER USB

USB

+12VDC

POWER / SENSE RELAYS

+12VDC

GROUND

SENSE IN 1

SENSE IN 2

CONTACT A

Relays (2)

Ground

Sense Inputs (2)

Sense Inputs: +3-24VDC
Relays: +30VDC, 5A max

CONTACT B

CONTACT A

CONTACT B

ETHERNET PORT 1 PORT 2 PORT 3 PORT 4

Ethernet Network (LAN)

IR OUTPUT LEVEL

Remote Control Processor

Model RP-4

IR Output Options

RTI Remote Control

Amplied IR Connecting Block

More than two emitters per port

requires an amplied IR connecting

block.

Direct to IR Port

Single or Dual
IR Emitters

MOUNTING INSTRUCTIONS

The RP-4 should be located on a secure, at surface, or mounted to a wall, shelf, or

cabinet using the enclosed mounting bracket.

IMPORTANT NOTE: When mounting the RP-4, be certain to choose a safe location
(e.g. away from electrical wires, junction boxes, wet locations, etc.)

MOUNTING BRACKET INSTALLATION:

DRYWALL

1. Level the RP-4 mounting bracket in the desired location on the wall and mark the

fastener holes with a pencil.

2. Using a 3/16” (5mm) sized drill bit, drill holes through the drywall in marked

locations.

3. Insert the drywall anchors (included) into the holes and tap until they are ush

with wall.

4. Align mounting bracket with drywall anchors and screw (using supplied #6-32

screws) bracket to wall.

NON-DRYWALL (EX. Wood Panelling)

1. Level the RP-4 mounting bracket in the desired location and mark the fastener

holes with a pencil.

2. Pre-drill holes into surface in marked locations. (NOTE: The drill bit size will need
to be adjusted depending upon the screw and wall material used).

3. Align mounting bracket with holes and screw bracket to the wall using athead

screws.

MOUNTING RP-4 ON BRACKET

1. Aligning the RP-4 channel locks (located on the backside of the RP-4) over the
mounting bracket channel lock clips (located on the front of the mounting plate).

2. Slide the RP-4 down until the channel lock clips lock into place.

RP-4 Mounting Bracket

Channel Lock

Clips (4)

Fastener Holes (4)
