R&S
®
NGL200
Power Supply
Getting Started
Getting Started
Version 02
1178872002
(;ÜåD2)
This manual describes the following R&S®NGL200 models and options:
●
R&S®NGL201 1 Channel PSU 60W (3638.3376.02)
●
R&S®NGL202 2 Channel PSU 120W (3638.3376.03)
●
R&S®NGL-K102 Option Wireless LAN (3652.6362.02)
●
R&S®NGL-B105 Option GPIB Interface (3652.6356.02)
●
R&S®NGL-K106 Option Battery Simulation (3652.6255.02)
●
R&S®NGL-K103 Option Digital I/O (3652.6385.02)
The contents of this manual correspond to firmware version 1.00 or higher.
The software contained in this product uses several valuable open source software packages. For information, see the "Open Source Acknowledgment" document, which is available for download from the
R&S NGL200 product page at www.rohde-schwarz.com/product/ngl200 > " Downloads > Firmware ".
Rohde & Schwarz would like to thank the open source community for their valuable contribution to embedded computing.
© 2018 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Fax: +49 89 41 29 12 164
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1178.8720.02 | Version 02 | R&S®NGL200
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®NGL200 is indicated as R&S NGL200.
1171.1307.52 - 05
1
Safety Instructions
Instrucciones de seguridad
Sicherheitshinweise
Consignes de sécurité
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric shock, fire,
personal injury or instrument damage.
● Do not open the instrument casing.
● Read and observe the "Basic Safety Instructions" delivered as printed brochure with
the instrument.
● Read and observe the safety instructions in the following sections.
Note that the data sheet may specify additional operating conditions.
● Keep the "Basic Safety Instructions" and the product documentation in a safe place
and pass them on to the subsequent users.
Riesgo de lesiones y daños en el instrumento
El instrumento se debe usar de manera adecuada para prevenir descargas eléctricas,
incendios, lesiones o daños materiales.
● No abrir la carcasa del instrumento.
● Lea y cumpla las "Instrucciones de seguridad elementales" suministradas con el
instrumento como folleto impreso.
● Lea y cumpla las instrucciones de seguridad incluidas en las siguientes secciones.
Se debe tener en cuenta que las especificaciones técnicas pueden contener
condiciones adicionales para su uso.
● Guarde bien las instrucciones de seguridad elementales, así como la
documentación del producto, y entréguelas a usuarios posteriores.
1171.1307.52 - 05
2
Gefahr von Verletzungen und Schäden am Gerät
Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen Schlag, Brand,
Verletzungen von Personen oder Geräteschäden zu verhindern.
● Öffnen Sie das Gerätegehäuse nicht.
● Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise", die als
gedruckte Broschüre dem Gerät beiliegen.
● Lesen und beachten Sie die Sicherheitshinweise in den folgenden Abschnitten;
möglicherweise enthält das Datenblatt weitere Hinweise zu speziellen
Betriebsbedingungen.
● Bewahren Sie die "Grundlegenden Sicherheitshinweise" und die
Produktdokumentation gut auf und geben Sie diese an weitere Benutzer des
Produkts weiter.
Risque de blessures et d'endommagement de l'appareil
L'appareil doit être utilisé conformément aux prescriptions afin d'éviter les
électrocutions, incendies, dommages corporels et matériels.
● N'ouvrez pas le boîtier de l'appareil.
● Lisez et respectez les "consignes de sécurité fondamentales" fournies avec
l’appareil sous forme de brochure imprimée.
● Lisez et respectez les instructions de sécurité dans les sections suivantes. Il ne faut
pas oublier que la fiche technique peut indiquer des conditions d’exploitation
supplémentaires.
● Gardez les consignes de sécurité fondamentales et la documentation produit dans
un lieu sûr et transmettez ces documents aux autres utilisateurs.
1171.0500.22-06.00
Customer Support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz equipment, contact one of our Customer
Support Centers. A team of highly qualified engineers provides telephone support and will
work with you to find a solution to your query on any aspect of the operation, programming
or applications of Rohde & Schwarz equipment.
Up-to-date information and upgrades
To keep your instrument up-to-date and to be informed about new application notes related
to your instrument, please send an e-mail to the Customer Support Center stating your
instrument and your wish.
We will take care that you will get the right information.
Europe, Africa, Middle East
Phone +49 89 4129 12345
customersupport@rohde-schwarz.com
North America
Phone 1-888-TEST-RSA (1-888-837-8772)
customer.support@rsa.rohde-schwarz.com
Latin America
Phone +1-410-910-7988
customersupport.la@rohde-schwarz.com
Asia/Pacific
Phone +65 65 13 04 88
customersupport.asia@rohde-schwarz.com
China
Phone +86-800-810-8228 /
+86-400-650-5896
customersupport.china@rohde-schwarz.com
Contents
R&S®NGL200
3Getting Started 1178.8720.02 ─ 02
Contents
1 Documentation Overview......................................................5
1.1 Manuals and Instrument Help..............................................................5
1.2 Data Sheet............................................................................................. 6
1.3 Release Notes and Open Source Acknowledgment..........................6
2 Conventions Used in the Documentation........................... 7
2.1 Typographical Conventions.................................................................7
2.2 Conventions for Procedure Descriptions...........................................7
2.3 Notes on Screenshots.......................................................................... 8
2.4 Other Conventions................................................................................8
3 Welcome to R&S NGL200..................................................... 9
4 Putting into Operation.........................................................10
4.1 Safety................................................................................................... 11
4.2 Intended Operation............................................................................. 13
4.3 Unpacking and Checking the Instrument......................................... 14
4.4 Setting Up the Instrument.................................................................. 15
4.4.1 Bench Operation................................................................................... 15
4.4.2 Rack Mounting...................................................................................... 16
5 Instrument Tour................................................................... 17
5.1 Overview of Controls..........................................................................17
5.1.1 Front Panel........................................................................................... 17
5.1.2 Rear Panel............................................................................................ 19
5.2 Switching On the Instrument............................................................. 21
6 Trying Out the Instrument...................................................23
6.1 Setting the Output Voltage and Current............................................23
Contents
R&S®NGL200
4Getting Started 1178.8720.02 ─ 02
6.2 Activating the Channels Output........................................................ 23
7 Maintenance......................................................................... 25
Index..................................................................................... 26
Documentation Overview
R&S®NGL200
5Getting Started 1178.8720.02 ─ 02
1 Documentation Overview
This section provides an overview of the R&S NGL200 user documentation.
1.1 Manuals and Instrument Help
You find the manuals on the product page at:
www.rohde-schwarz.com/product/ngl200
Getting started manual
Introduces the R&S NGL200 and describes how to set up the product. A printed
English version is included in the delivery.
User manual
Contains the description of all instrument modes and functions. It also provides
an introduction to remote control, a complete description of the remote control
commands with programming examples, and information on maintenance and
instrument interfaces. Includes the contents of the getting started manual.
The online version of the user manual provides the complete contents for immediate display on the internet.
Basic safety instructions
Contains safety instructions, operating conditions and further important information. The printed document is delivered with the instrument.
Service manual
Describes the performance test for checking the rated specifications, module
replacement and repair, firmware update, troubleshooting and fault elimination,
and contains mechanical drawings and spare part lists. The service manual is
available for registered users on the global Rohde & Schwarz information system
(GLORIS, https://gloris.rohde-schwarz.com).
Manuals and Instrument Help
Documentation Overview
R&S®NGL200
6Getting Started 1178.8720.02 ─ 02
1.2 Data Sheet
The data sheet contains the technical specifications of the R&S NGL200. It also
lists the options with their order numbers and optional accessories.
See www.rohde-schwarz.com/brochure-datasheet/ngl200
1.3 Release Notes and Open Source Acknowledgment
The release notes list new features, improvements and known issues of the current firmware version, and describe the firmware installation. The open source
acknowledgment document provides verbatim license texts of the used open
source software.
See www.rohde-schwarz.com/firmware/ngl200. The open source acknowledg-
ment document can also be read directly on the instrument.
Release Notes and Open Source Acknowledgment
Conventions Used in the Documentation
R&S®NGL200
7Getting Started 1178.8720.02 ─ 02
2 Conventions Used in the Documentation
2.1 Typographical Conventions
The following text markers are used throughout this documentation:
Convention Description
"Graphical user interface
elements"
All names of graphical user interface elements on the screen,
such as dialog boxes, menus, options, buttons, and softkeys are
enclosed by quotation marks.
[Keys] Key and knob names are enclosed by square brackets.
File names, commands,
program code
File names, commands, coding samples and screen output are
distinguished by their font.
Input Input to be entered by the user is displayed in italics.
Links Links that you can click are displayed in blue font.
"References" References to other parts of the documentation are enclosed by
quotation marks.
2.2 Conventions for Procedure Descriptions
When operating the instrument, several alternative methods may be available to
perform the same task. In this case, the procedure using the touchscreen is
described. Any elements that can be activated by touching can also be clicked
using an additionally connected mouse. The alternative procedure using the keys
on the instrument or the on-screen keyboard is only described if it deviates from
the standard operating procedures.
The term "select" may refer to any of the described methods, i.e. using a finger on
the touchscreen, a mouse pointer in the display, or a key on the instrument or on
a keyboard.
Conventions for Procedure Descriptions
Conventions Used in the Documentation
R&S®NGL200
8Getting Started 1178.8720.02 ─ 02
2.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions
and possible interdependencies between parameters. The shown values may not
represent realistic usage scenarios.
The screenshots usually show a fully equipped product, that is: with all options
installed. Thus, some functions shown in the screenshots may not be available in
your particular product configuration.
2.4 Other Conventions
Remote commands may include abbreviations to simplify input. In the description
of such commands, all parts that have to be entered are written in capital letters.
Additional text in lowercase characters is for information only.
Other Conventions
Welcome to R&S NGL200
R&S®NGL200
9Getting Started 1178.8720.02 ─ 02
3 Welcome to R&S NGL200
The one or two-channel power supply series are based on a classical transformer
concept with linear regulators. This concept allows the instrument to achieve
highest accuracy and lowest residual ripple.
The R&S NGL200 power supply series feature galvanically isolated, floating overload and short-circuit proof outputs. The outputs can be connected in parallel and
serial to get higher voltages, thus making high currents available.
Multi-purpose protection functions are available for each channel which you can
set separately, such as overcurrent protection (OCP), overvoltage protection
(OVP) and overpower protection (OPP). If such a limit is reached, the affected
output channel is automatically turned off and an indicator icon (
, , ) blinks
on the display. In the case of two-channel power supply, NGL202, the overcurrent
protection can be linked to the other channel. In this case, the linked channel is
turned off when the other channel reaches a limit.
Additionally, the R&S NGL200 is protected with overtemperature protection
(OCP). This safey feature protects the R&S NGL200 from getting overheated,
when activated, the channel outputs are turned off.
The Arbitrary function allows a freely definable voltage and current sequences
with a timeframe as short as 10 ms. It allows you to vary the voltage or current
limit during a test sequence, for example to simulate different charging conditions
of a battery. With Ramp function, the R&S NGL200 provides the operating condition to simulate the continuous rise of the supply voltage within a defined timeframe of 10 ms to 10 s.
All R&S NGL200 power supply series are equipped with a color LCD display (800
x 480 pixels). The R&S NGL200 comes with a USB and LAN (LXI) interface.
Equipped with a wireless LAN (WLAN) option, you can establish a network connection wirelessly .
The digital I/O interfaces installed at the rear panel is activated with an option, it
provides a set of 4-bit digital interfaces that can be individually used as trigger
inputs or outputs.
The user manual contains description of the functionalities that the instrument
provides. The latest version is available for download at the product homepage
(http://www.rohde-schwarz.com/product/ngl200).
Putting into Operation
R&S®NGL200
10Getting Started 1178.8720.02 ─ 02
4 Putting into Operation
This chapter describes the steps to set up the R&S NGL200 for the first time.
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric
shock, fire, personal injury, or damage.
●
Do not open the instrument casing
●
Read and observe the "Basic Safety Instructions" delivered as a printed
brochure with the instrument. Note that the basic safety instructions also
contain information on operating conditions that prevent damage to the
instrument
In addition, read and observe the safety instructions in the following sections.
Notice that the data sheet may specify additional operating conditions.
Risk of radio interference
This instrument is compliant with Class A of CISPR 32. In a residential environment, this instrument may cause radio interference.
Putting into Operation
R&S®NGL200
11Getting Started 1178.8720.02 ─ 02
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instrument and the connected devices. Ensure the following operating conditions
before you switch on the instrument:
●
The instrument is dry and shows no sign of condensation
●
The instrument is positioned as described in Chapter 4.4.1, "Bench
Operation", on page 15
●
The ambient temperature does not exceed the range specified in the
data sheet
●
Signal levels at the input connectors are all within the specified ranges
●
Signal outputs are correctly connected and not overloaded
EMI impact on measurement results
Electromagnetic interference (EMI) may affect the measurement results.
To suppress the generated EMI:
●
Use suitable shielded cables of high quality, for example, LAN cables
●
Note the EMC classification in the data sheet
● Safety.............................................................................................................. 11
● Intended Operation......................................................................................... 13
● Unpacking and Checking the Instrument........................................................ 14
● Setting Up the Instrument............................................................................... 15
4.1 Safety
This instrument was built in compliance with DIN EN 61010-1 (VDE 0411 part 1),
safety regulations for electrical instruments, control units and Iaboratory equipment.
It has been tested and shipped from the plant in safe condition. It is also in compliance with the regulations of the European standard EN 61010-1 and the international standard IEC 61010-1.
Safety
Putting into Operation
R&S®NGL200
12Getting Started 1178.8720.02 ─ 02
To maintain this condition and ensure safe operation, you must observe all
instructions and warnings given in this user manual. Casing, chassis and all measuring ports are connected to a protective earth conductor. The instrument is
designed in compliance with the regulations of protection class I.
For safety reasons, the instrument may only be operated with authorized safety
sockets. The power cord must be plugged in before signal circuits may be connected.
Never use the product if the power cable is damaged. Check regularly if the
power cables are in perfect condition. Choose suitable protective measures and
installation types to ensure that the power cord cannot be damaged and that no
harm is caused by tripping hazards or from electric shock, for instance.
Risk of electric shock
It is prohibited to disconnect the earthed protective connection inside or outside of the instrument!
If it is assumed that a safe operation is no longer possible, the instrument must be
shut down and secured against any unintended operation.
Safe operation can no longer be assumed as follows:
●
Instrument shows visible damage
●
Instrument includes loose parts
●
Instrument no longer functions properly
– After an extended period of storage under unfavorable conditions (e.g. out-
doors or in damp rooms)
– After rough handling during transport (e.g. packaging that does not meet
the minimum requirements by post office, railway or forwarding agency)
Exceeding the low voltage protection
Use insulated wires and not bare wires for the terminal connection.
It is assumed that only qualified and trained personnel service the power
supplies and the connected loads.
Safety
Putting into Operation
R&S®NGL200
13Getting Started 1178.8720.02 ─ 02
Prior to switching on the product, it must be ensured that the nominal voltage setting on the product matches the nominal voltage of the AC supply network. If it is
necessary to set a different voltage, the power fuse of the product may have to be
changed accordingly.
4.2 Intended Operation
The instrument is intended only for use by personnel familiar with the potential
risks of measuring electrical quantities.
For safety reasons, the instrument may only be connected to properly installed
wall outlets. Separating the ground is prohibited.
The power plug must be inserted before signal circuits may be connected.
Use only the power cord included in the delivery package. See "Delivery
package" on page 15.
Before each measurement, measuring cables must be inspected for damage and replaced if necessary. Damaged or worn components can damage
the instrument or cause injury.
The product may be operated only under the operating conditions and in the positions specified by the manufacturer, without the product's ventilation being
obstructed. If the manufacturer’s specifications are not observed, this can result
in electric shock, fire and / or serious personal injury, and in some cases, death.
Applicable local or national safety regulations and rules for the prevention of accidents must be observed in all work performed.
The instrument is designed for use in the following sectors: Industrial, residential,
business and commercial areas and small businesses.
The instrument is designed for indoor use only. Before each measurement, you
need to verify at a known source if the instrument functions properly.
To disconnect from the mains, unplug the IEC socket on the back panel.
See Table 4-1 for the general data on the instrument specification. For more infor-
mation, see the instrument datasheet (PN: 5216.1057.12).
Intended Operation
Putting into Operation
R&S®NGL200
14Getting Started 1178.8720.02 ─ 02
Table 4-1: General data on instrument specification
General data
Mains nominal voltage AC 100 / 115 / 230 V (±10 %) 50 Hz to 60 Hz
Maximum input power 400 W
Mains fuses IEC 60127-2 / 5 T4.0H 250 V
Operating temperature range +5 °C to +40 °C
Storage temperature range -20 °C to +70 °C
Humidity Non-condensing 5 % to 80 %
Display 5 " (Resolution 800 x 480, WVGA)
Input Method Capacitive touch input
Rack mount capability R&S HZN96 rack adapter 2U (P/N: 3638.7813.02)
Dimensions (W x H x D) 222 mm x 97 mm x 436 mm (8.74 in x 3.82 in x 17.17 in)
Weight R&S NGL201 7.1 kg (15.65 lb)
R&S NGL202 7.3 kg (16.09 lb)
4.3 Unpacking and Checking the Instrument
Unpack the R&S NGL200 carefully and check the content of the package.
●
Check the equipment for completeness using the delivery note and package
contents list for the various items.
●
Check the instrument for any damage and loose parts. If there is any damage,
immediately contact the carrier who delivered the instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or shipped at a later date, you can use the material to protect the control
elements and connectors.
Unpacking and Checking the Instrument
Putting into Operation
R&S®NGL200
15Getting Started 1178.8720.02 ─ 02
Risk of damage during transportation and shipment
Insufficient protection against mechanical and electrostatic effects during
transportation and shipment can damage the instrument.
●
Always ensure that sufficient mechanical and electrostatic protection are
provided
●
When shipping an instrument, the original packaging should be used. If
you do not have the original packaging, use sufficient padding to prevent the instrument from moving around inside the box. Pack the instrument in antistatic wrap to protect it from electrostatic charging
●
Secure the instrument to prevent any movement and other mechanical
effects during transportation
Delivery package
The package contents contain the following items:
●
R&S NGL200 power
●
Four power cables
●
One printed Getting Started manual
●
One document folder containing a printed Basic Safety Instructions
4.4 Setting Up the Instrument
The R&S NGL200 is designed for benchtop and rackmount.
4.4.1 Bench Operation
On a benchtop, the R&S NGL200 can either lie flat or stand on its feet. As shown
in Figure 4-1, feet on the bottom can be folded out to set the instrument in an
inclined position.
Setting Up the Instrument
Putting into Operation
R&S®NGL200
16Getting Started 1178.8720.02 ─ 02
Figure 4-1: Operating positions
Positioning of instrument
The instrument must be positioned in a manner that allows the user to disconnect the unit from the mains at any time and without restrictions.
4.4.2 Rack Mounting
The instrument can be installed in a 19 " rack-mount using a rack adapter kit.
Ambient temperature
Place the R&S NGL200 in an area where the ambient temperature is within
+5 °C to +40 °C. The R&S NGL200 is fan-cooled and must be installed with
sufficient space along the sides to ensure free flow of air.
Setting Up the Instrument
Instrument Tour
R&S®NGL200
17Getting Started 1178.8720.02 ─ 02
5 Instrument Tour
This chapter provides an overview of all the controls available in the
R&S NGL200 models and steps to switch on the instrument for the first time.
● Overview of Controls.......................................................................................17
● Switching On the Instrument...........................................................................21
5.1 Overview of Controls
5.1.1 Front Panel
The front panel of the R&S NGL200 is as shown in Figure 5-1. The function keys
and navigation controls are located beside the display. The various connectors
are located right of the display.
The R&S NGL200 has one output channel for NGL201 model and two output
channels for NGL202 model .
Figure 5-1: Front panel of R&S NGL200
1 = Display with touch screen
2 = Menu control keys
3 = Navigation keys
4 = Output and channels keys
Overview of Controls
Instrument Tour
R&S®NGL200
18Getting Started 1178.8720.02 ─ 02
5 = Output terminals (one channel with sense NGL201, two channels NGL202)
6 = USB connector
7 = Power key
Display (1)
The display is a color LCD screen. Depending on the instrument model, up to two
channels are shown on the display. The respective measurement settings and
functions are displayed in the individual channel display area. There is a status
bar in the device level and channel level, showing the device operating mode and
respective channel settings of the instrument.
For a detailed description on-screen layout, see section "Display Overview" in the
User Manual.
Menu control keys (2)
The menu control keys allow you to navigate to the home window, main menu
window and user button key in the instrument.
For a detailed description on navigation keys, see section "Menu Controls" in the
User Manual.
Navigation keys (3)
The navigation keys are used for menu navigation and value adjustment in the
instrument.
For a detailed description on navigation, see section "Navigation Controls" in the
User Manual.
Output and channel keys (4)
Depending on the instrument type, up to two output channels are available to
source or sink power to and from the output terminals.
Each channel is capable to source 0 V to 6 V with a current of 6 A or 6 V to 20 V
with a current of 3 A. In sink mode, each channel can consume 0 A to 3 A at an
input voltage of 0 V to 20 V.
Output terminals (5)
Both instrument models are equipped with 4 terminals. The R&S NGL201 provides both the output plus the sense connectors at the front panel while the R&S
NGL202 provides only output terminals for both channels.
Overview of Controls
Instrument Tour
R&S®NGL200
19Getting Started 1178.8720.02 ─ 02
USB connector (6)
The USB connector is a Type-A connector. You can connect a USB flash drive to
this connector to perform a firmware update, store logging data or screen shots.
Power key (7)
The [Power] key switches the instrument on and off.
5.1.2 Rear Panel
Figure 5-2 shows the rear panel of the R&S NGL200 with its connectors.
Figure 5-2: Rear panel of R&S NGL200
8 = AC inlet with fuse holder and voltage selector
9 = Channel 1 rear panel connector
10 = Channel 2 rear panel connector (NGL202 model)
11 = USB connector (Device)
12 = USB connector (Host)
13 = Ethernet (LAN) connector
14 = Cover for optional IEEE 488 (GPIB) Interface
15 = Digital I/O connector
AC inlet with fuse holder and voltage selector (8)
Main supply cord
Do not use detachable mains supply cord with inadequate rating.
Overview of Controls
Instrument Tour
R&S®NGL200
20Getting Started 1178.8720.02 ─ 02
For safety reasons, the instrument can only be operated with authorized safety
sockets.
The power cable must be plugged in before signal circuits can be connected.
Never use the product if the power cable is damaged. See Chapter 5.2, "Switch-
ing On the Instrument", on page 21 for more information.
The built-in voltage selector selects the mains voltage between 100 V, 115 V and
230 V. All voltage settings are using the same fuse rating.
Channel connectors (9, 10)
Output Terminals
Either the output terminals at the front panel or those at the back panel can
be used. Using both terminals at the same time can cause instrument malfunction.
DVM pins on the channel connector are only available in the NGM types
power supply.
The channel connectors contain both output ("F+", "F-") and sense ("S+", "S-")
connections. Connector for "Ch 2" is only available in the R&S NGL202 model.
USB connectors (11, 12)
The USB host connector (Type-A) can be used for mass storage devices like the
USB connector at the front panel.
The USB device connector is a Type-B connector for remote control operation.
Ethernet connector (13)
This connector is used for establishing remote control via SCPI.
See section "Ethernet Setup" in the user manual for more information on the connection setup.
Overview of Controls
Instrument Tour
R&S®NGL200
21Getting Started 1178.8720.02 ─ 02
Option GPIB interface (14)
An IEEE488 GPIB interface can be ordered (NGL-B105). This interface is not
user installable.
Digital I/O connector (15)
The Digital I/O connector is a terminal block for external input or output.
The Digital Trigger I/O option (NGL-K103) must be installed for this function to be
available in the instrument.
5.2 Switching On the Instrument
Before switching on the instrument, check if the value on the voltage selector corresponds to the mains voltage (100 V, 115 V or 230 V). Switch it on, if necessary.
Fuse rating
The R&S NGL200 is using the same fuse ratings for all main voltages.
To change power fuse:
1. Peel off the yellow label sticker on the AC inlet.
2. Release the latch of the fuse holder which is located directly below the socket
and pull it out.
3. Pull out the removable part of the fuse holder.
4. Turn this part until correct voltage label (100, 115 or 230) is displayed in the
window of the holder.
5. Return the fuse holder to its position in the panel.
To switch on instrument:
1. Connect the power cable to the AC power connector on the rear panel of the
R&S NGL200.
2. Connect the power cable to the socket outlet.
3. Press [Power] key on the front panel.
Switching On the Instrument
Instrument Tour
R&S®NGL200
22Getting Started 1178.8720.02 ─ 02
The instrument performs a system check, boots the operating system, and
starts the R&S NGL200 firmware.
By default, all output channels are turned off when the instrument is switched on
to prevent connected loads from being damaged unintentionally.
To switch off instrument:
1. Press [Power] key.
All current settings are saved to internal memory and the firmware shutdown.
2. Disconnect the AC power cable from the AC power supply.
Switching On the Instrument
Trying Out the Instrument
R&S®NGL200
23Getting Started 1178.8720.02 ─ 02
6 Trying Out the Instrument
This chapter describes some basic functions that you can perform with the
R&S NGL200.
Source and sink current
The R&S NGL200 series are 2 quadrant power supplies which may both
source and sink current. This function needs no separate configuration or
mode switching. As soon as the voltage across the output terminal exceeds
the set voltage, current flows into the instrument. This is an intended feature
and it is safe.
On the display, sink mode is shown as negative current.
6.1 Setting the Output Voltage and Current
1. Press [Home] key.
The R&S NGL200 displays the home window.
2. Select voltage or current parameter in the home window
The R&S NGL200 displays an on-screen keypad to set the value.
3. Enter the required value.
4. Confirm value with the unit key (for voltage - V or mV, for current A or mA).
6.2 Activating the Channels Output
The output voltages can be switched on or off regardless of the operating mode
the instrument is in.
To switch on or off channel output.
1. Select desired channel key ([Ch1] or [Ch2]) on the front panel.
2. Press [Output] key.
Activating the Channels Output
Trying Out the Instrument
R&S®NGL200
24Getting Started 1178.8720.02 ─ 02
The R&S NGL200 output the set voltage level on the selected output channel
terminal.
Depending on the mode which the channels are operated in, the followings are
observed:
