RPI Industries VIHD 3 Installation Manual

Operating Manual

VIENNA Hot Display

Operating and Maintenance instructions

Please read this manual carefully before you start to operate your heated display case.
Following these instructions helps you to ensure having a fully functional unit at all times.

Warranty claims can only be forwarded if all instructions are strictly

followed!

Contents

Operation and maintenance

1 Introduction .............................................................................................................. 3

1.1. Welcome .............................................................................................................. 3

1.2. Fundamental Safety Notes ............... ................................................................ 3

1.3. Warranty and Liabilities ............................................................................................ 3

1.4. Symbols and Notes ............................ ................................................................ 4

1.5. Validity .............................................................................................................. 4

2 Purpose of use …….................................................................................................. 5

3 Proper use of the unit …………..……..................................................................... 5

4 Fundamental Safety Notes …………........................................................................ 5

4.1. Obligation of the Operator ................................................................................. 5

4.2. Obligation of the Personnel ................................................................................. 5

4.3. Possible Risk ……………................................................................................... 5

5 Fundamental operating notes .................................................................................. 6

5.1. Switching on the appliance ....................................................................................... 6

5.2. Setting the temperature .......................................................................................... 6

5.3. Lighting .............................................................................................................. 6

6 Functional description ……….. ................................................................................ 7

7 Technical Data …….................................................................................................. 7

8 Cleaning and care ............................................................................................. 8

8.1. General Recommendations ...................................................................................... 8

8.2. Detergents ……….................................................................................................... 8

9 Trouble shooting .......................... ................................................................ 9

10 Dangers .................................................................................................................... 10

11 Maintenance ……...................................................................................................... 10

12 Wiring diagram …………………………………………………………………… 11
13 Declaration of Conformity ………………………………………………………….. 12

OPERATING AND MAINTENANCE

1. Introduction

1.1. Welcome
With the purchase of this new heated display case you have decided on a product that combines the

highest technical demands with practical service comfort. We recommend that you read these
operating and maintenance instructions carefully in order to become familiar with the product quickly.

With the proper treatment you will enjoy this appliance for a long time. Please keep these operating
and maintenance instructions to consult in case any maintenance and repairs are needed.

We wish you successful business and much pleasure with this appliance.

1.2. Fundamental Safety Notes

• Those covers bearing a warning may only be opened by specialists!

• The bottom and back panels are not to be cleaned by water jet.

• Protective covers and devices may not be removed due to risk of injury!

• The control system may only be opened by an expert.

• Due to risk of injury, sharp objects are not to be stored loosely in the heated unit.

• Any glass parts are to be treated with the necessary care in order to avoid injuries resulting from

broken glass.

• Components and operating equipment may only be replaced by original parts.

1.3. Warranty and Liabilities
Fundamentally, our "General terms of sale and delivery“ are valid. These are known to the operator

upon the signing of the contract at the latest. Claims of warranty and liability for damage to persons
and property are not possible, if they result from one or several of the following causes:

• Improper use of the unit.

• Improper assembling, starting up, operating and servicing of the unit.

• Operating the unit with defective safety devices or safety devices which have not been installed

properly and are not in working condition.

• Disregard of the instructions in the operating manual concerning transportation storage,
installation, start-up, operation, maintenance and assembling of the unit.

• Unauthorized mechanical or electrical changes to the unit.

• Insufficient maintenance of wear and tear parts.

• Unauthorized repair.

• Extreme environmental concern, fire, explosions etc.

Valid from: 03/2009 Technical changes reserved Page 2

The installation and any technical modifications are only to be carried

out by specialists! This is especially valid for any electrical installation

and mechanical work.

Any changes are to be authorized by the manufacturer!

1.4. Symbols and Notes

This symbol points to important instructions for the proper use of the unit.

Not paying attention to these instructions can lead to disturbances at the unit or in
the environment!

This symbol means a possible or directly threatening danger to the life and health of
persons and/or a possibly dangerous situation.

Ignoring these instructions may result in dire consequences for your health and/or
can lead to property damages!

Danger of surfaces with a high temperature

The top of the shelves, the glass and s/s columns at the back of the unit may be hot

This symbol points to operation tips and especially useful information.
Helps you to use all functions on your unit optimally.

1.5. Validity

These operating instructions are valid for the models:

Drop-in - Heated Display Case

VIENNA Hot Display - CC

Operation side: closed / hinged doors
Customer side: closed

Drop-in - Heated Display Case

VIENNA Hot Display - OC

- open -

- open -

- open -

Operation side: open
Customer side: closed

Drop-in - Heated Display Case

VIENNA Hot Display - CO

Operation side: closed / hinged doors
Customer side: open

Valid from: 03/2009 Technical changes reserved Page 3
