Royal Prestige Maxtractor User Manual

CARE AND USE MANUAL

B77.JM3.HYCITE.1-131107M

CONTENTS

Important Safeguards

Safety Warning

Parts

How to Assemble

How to Operate

Tips on Operation

Tips on Ingredient

Ingredients Preparation

How to Disassemble and Clean

How to Clean Silicone Parts

How to Use the Cleaning Tool

Troubleshooting Q&A

Speci cations

Read all Instructions Before Use

IMPORTANT SAFEGUARDS SAFETY WARNING

When using electrical appliances, basic safety precautions should always be followed

1. Read all instructions.

2. To protect against risk of electrical shock do not immerse motor base in water or other liquid.

3. Close supervision is necessary when any appliance is used by or near children.

4. Unplug from outlet when not in use before putting on or taking o parts, and before cleaning.

5. Avoid contacting moving parts.

6. Do not operate any appliance with a damaged cord or plug, or after the appliance malfunctions or damaged in any manner. Return appliance to the customer support for examination and/or repair.

7. The use of attachments not recommended or sold by the manufacturer may cause  re, electric shock or injury.

8. Do not use outdoors.

9. Do not let cord hang over edge of table or counter.

10. Always make sure the hopper is closed securely in place before motor is turned on. Do not open the hopper while maXtractor

11. Be sure to turn switch to OFF position after each use of your maXtractor stops completely before disassembling.

12. Do not put  ngers or other objects into the hopper during operation. If food becomes lodged, use pusher or another piece of fruit or vegetable to push it down. When this method does not work, turn the motor o and disassemble maXtractor

13. Do not use the appliance if the rotation wiper is damaged.

14. Do not operate without the pulp container in place.

15. Do not alter or modify the appliance in anyway.

16. Do not use the appliance for anything other than its intended purpose as described in the manual.

17. The appliance should be used for limited period of time.

™

is in operation.

™

. Make sure the motor

™

to remove the remaining food.

Unplug the power cord when not in use.

Do not keep or operate the appliance near infants or toddlers;

*It may injure them.

Do not use the appliance on an uneven surface;

* It may cause a malfunction if the appliance tips over.

Do not put  ngers or other objects into the hopper while it is in operation;

*It may cause injury.

Do not put the

maXtractor

™

parts in the dishwasher or extremely hot water;

*The parts may wear faster.

Do not use any hazardous chemicals to clean the appliance;

* It may change the color of the appliance or result in a  re.

• This appliance is for household use only. Please follow the instructions in the manual carefully. (The appliance cannot be covered under the manufacturer’s warranty if the product is used in a way not intended by the manufacturer or commercially.)

• Save the instruction manual for future reference.

• If the appliance is given as a gift, please include the manual with the product.

The following precautions are provided to ensure the safety of the user. Please carefully read through the precautions and exercise care when using the appliance.

Warning: This label warns of the risk of death or severe injuries. Caution: This label warns of the risk of injuries or appliance damage.

Prohibited

Do not disa ssemble Must take a ction

Do not repair, disassemble the base, or customize the appliance;

* The appliance may not operate properly causing  re, electric shock, or injury.

Do not spray water or  ammable sprays near the appliance;

* It may cause an explosion or electrical shock.

PARTS

1. Hopper

4. Smart Cap

Detachable

* The prod ucts illustr ated/photogra phed in this book let may vary sl ightly from the ac tual produc t.

Pusher

Align

Align the dots ● and slide the pusher in.

2. Juicing Bowl

3. Pulp Container

7. Rotation Wiper

10. Pusher

11. Cleaning Brush

5. Base

STEP 1

Top-set Assembly

Align the red dots ● on each part and

6. Juice Container

assemble in the order shown. Once assembled, turn the hopper clockwise to close.

9. UltraSqueezer™8. Strainer

STEP 2

Top-set and base assembly

Assemble the entire top-set onto the

▼

is aligned

on the

base ensuring the arrow symbol hopper is aligned with the arrow symbol

on the base. Turn the top-set clockwise ensuring the arrow symbol with the arrow symbol

HOW TO ASSEMBLE

Top-set Assembly

STEP 1

Check Before Operating

Note |

• Wash the parts before  rst use.

• Ensure that the compression silicone and silicone ring are assembled properly.

Firmly insert the compression silicone into the slot below the pulp spout.

The MaXtractor™ may leak if not assembled properly.

Assemble the strainer into the rotation wiper, then place this assembly into the juicing bowl ensuring the red dot the strainer is aligned with the red dot on the juicing bowl.

●

STEP 2

TIP

Place the UltraSqueezer™ into the strainer.

Turn and press down on it until it clicks into place.

Note |

The UltraSqueezer™ needs to be locked in place in order to close the hopper.

Place the hopper onto the juicing bowl

aligning the red dot with the red dot

●

Turn clockwise to close, aligning the red

●

on the hopper with the close mark

dot

●

on the hopper

●

on the juicing bowl.

Top-set and Base Assembly

For easy assembly hold the hopper and turn clockwise as shown in the illustration.

Place the top-set on top of the base. Align the arrow ▼ on the hopper with the arrow slightly turn the top-set clockwise, until the hopper arrow is aligned with the arrow (close)

(open) on the base then

Open/Close mark on the top-set.

Note |

MaXtractor™ will not operate if parts are not assembled properly.

Place the pulp container under the

pulp spout and place the juice container under the juice spout as shown in the illustration.

Open

Detachable

HOW TO OPERATE

STEP 1

Note |

STEP 2

Note |

If the ingredients become jammed in the UltraSqueezer™ and the hopper does not open, press the OFF button. Then press and hold the REVERSE button until the ingredients become dislodged. Repeat REVERSE - OFF - FORWARD as often as needed to achieve the desired result.

After preparing the ingredients, plug the power cord into a wall outlet.

• Do not touch the power cord with wet hands. It may cause electrical shock,

short-circuit, or  re.

• Check the safety of the wall outlet.

Press the FORWARD button to operate.

• Forward: Pulls down and slowly masticates the ingredients.

• Reverse: Pushes the ingredients back up to dislodge them.

If the maXtractor™ stops during operation:

Switch the button to OFF position then press and hold the REVERSE button until the ingredients become dislodged.

Repeat REVERSE - OFF - FORWARD as needed.

1 3

FORWARD : Pulls down the food OFF : Stops the operation REVERSE : Pushes the food back up

STEP 3

Note |

Tip |

STEP 4

Tip |

Note |

Insert the prepared ingredients one piece at a time.

• Fibrous leafy vegetables (celery, kale, etc.): » Separate each stem. Cut the outer stems that are thick and tough to 4 inches long or

less.

» Bundle up the leafy vegetables as inserting into the maXtractor™. Alternate between

leafy parts and stems.

• Before extracting, remove hard seeds or pits in ingredients.

• When juicing frozen fruits with small seeds, ensure that even the seeds are completely

thawed.

• Insert the ingredients one piece at a time.

• Align the dots ● and slide the pusher in.

• After inserting ingredients, use the pusher when it is necessary. Too much use of the

pusher may a ect the juice quality.

» Intermittently use the pusher for soft ingredients like tomatoes and apples. Constant

use of pusher for soft ingredients may a ect the juice quality.

Use the smart cap to make mixed juices, stop juice from dripping, or rinse between di erent juices.

Smart cap

• Juicing with the smart cap closed creates various mixed juice creations when

di erent fruits and vegetables, milk, banana, beans etc. are selected.

• After juicing, close the smart cap to stop the juice from dripping, especially when

disassembling the juicing bowl o the base.

• When making di erent juices quickly rinse away any leftover  avors by running a

glass of water in the maXtractor™ with the smart cap closed.

• Leave the smart cap open when juicing ingredients that create excessive foam

during extraction, (e.g. apples, celery).

• Pay close attention when operating with the smart cap closed. Juice may over ow

if the juice collected in the juicing bowl exceeds its capacity marked on the bowl.

Note |

OFF OFFREVERSE FORWARD

• REVERSE: Pushes the ingredients back up to dislodge them.

The REVERSE button only works while holding down the switch.

• Switch OFF ensuring that the maXtractor™ comes to a complete stop. Then press REVERSE. Hold the REVERSE button for 2-3 seconds and release. Repeat as needed.

Let the maXtractor™ stop completely before using the REVERSE button to prevent malfunction.

• If the maXtractor™ does not work after these steps, disassemble and clean the parts before operating the maXtractor™ again.

▶▶▶

STEP 5

Note |

After juice and pulp are completely extracted, switch the unit OFF.

• If the remaining ingredients in the juicing bowl have not been extracted completely, the hopper may not open easily. After each extraction, run the maXtractor™ for an

additional 30 seconds to let the maXtractor™ extract the remaining pulp.

• When the hopper is stuck, press the REVERSE - OFF - FORWARD button in this order; switching back and forth 2 or 3 times to dislodge the ingredients. Then place hands on top of the hopper and  rmly press down while simultaneously turning it counter clockwise to open.

» Depending on the ingredients, pour water down the hopper to rinse out the interior

of the juicing bowl and then attempt to remove it.

TIPS ON OPERATION TIPS ON INGREDIENTS

1. Operating the maXtractor™ without ingredients can cause damage to the UltraSqueezer™.

2. Do not continuously operate the maXtractor™ for more than 30 minutes.

This can damage the motor from overheating. After continuous use, let the maXtractor™ rest for 30 minutes to cool down before starting another session.

3. Do not put  ngers or other objects into the hopper. Always use provided pusher when needed.

If other objects are inserted into the hopper during operation, such materials can get stuck and damage the maXtractor™ parts and/or cause injury.

4. Do not put dried or hard ingredients like whole grains, fruits with hard seeds or ice into the maXtractor™.

These may damage the parts (e.g. juicing bowl, UltraSqueezer™, and strainer).

• Beans or grains can be used if soaked overnight or boiled.

• Fruits with pits and hard seeds must be pitted before juicing (e.g. nectarines, peaches, mangoes and cherries).

• When using frozen fruits with small seeds such as grapes, completely thaw before inserting them into the maXtractor™.

5. Do not use ingredients containing excessive amounts of vegetable oil or animal fat. Do not use the maXtractor™ to extract vegetable oil from ingredients.

If vegetable/animal oil gets on the UltraSqueezer™, it may reduce performance and even damage the part.

6. Do not reinsert the extracted pulp into the maXtractor™. This can cause the unit to stop or cause the hopper not to open.

7. After juicing ingredients with seeds like grapes, thoroughly clean all the crevices on the bottom of the UltraSqueezer™.

MaXtractor™ damage due to owner negligence or from not following the instructions of this manual will void the warranty.

DO NOT

Hard seeds

Hard or inedible skins

Frozen fruits or ice

Vegetable/ animal oil

Others

put the following ingredients into the maXtractor™:

Peach, nectarines, apricot, plum, mango, etc.

Remove hard seeds from the ingredients before juicing.

Pineapple, melon, mango, orange, etc.

Peel the skin from the ingredients before juicing.

Frozen strawberry, blueberry, raspberry, etc.

Completely thaw frozen fruits before juicing. Do not use ice.

Sesame seed, butter, margarine, etc.

Do not extract ingredients containing vegetable or animal oil. This can reduce performance and even damage the maXtractor™.

Coconut, sugarcane, whole grains, etc.

Do not extract ingredients with no water content.

Experience the best quality juice by understanding each ingredient’s characteristics and knowing the optimal way of handling them.

The Slow MaXtractor™ is an innovative product that uses a patented slow-speed masticating technology to e ciently extract the juice from ingredients. The maXtractor™ is designed to obtain the best result

from ingredients with  rm composition and with high water content.

For best result, each ingredient should be prepared and extracted

depending on its characteristics and properties.

INGREDIENTS PREPARATION

Before Operating:

Juice Yield:

Soft fruits and vegetables

PREPARATION TIPS:

• Cut 1-4 wedges.

EXTRACTION TIPS:

• Slowly insert the ingredients, one piece at a time.

• Use the pusher to push the ingredients down the hopper. (The pusher also helps prevent juice from spraying out of the hopper when extracting ingredients with high water content)

• Leave the smart cap open when juicing ingredients that create excessive foam during extraction.

(Foam can accumulate if operated with the smart cap closed).

• It is recommended that the extracted juice be consumed within 48 hours after extracting. Depending on the density of the ingredients, the extracted juice can gradually show layers over time.

• If there is an excessive amount of foam, use a mesh strainer to separate it from the juice.

• When an ingredient is being masticated by the UltraSqueezer™, the squeezed ingredient may splash juice through the hopper. Use the pusher to block out the juice splash when juicing.

• Before Operating: If the maXtractor™ is jammed or if the hopper does not open, press the REVERSE button and hold until the ingredient becomes dislodged. Repeat REVERSE-OFF-FORWARD as needed.

• Continue operating the maXtractor™ until all the ingredients in the juicing bowl are extracted. The hopper may not open easily if there is a lot of pulp remaining in the maXtractor™.

• Every ingredient yields di erent amounts of juice.

• For the optimal extraction and maximum juice yield, cut the ingredients following the guidelines given in this section.

• Insert ingredients slowly monitoring how they are extracted.

The juice yield may vary depending on the juicing speed.

(e.g. oranges, tomatoes):

| (E.g. apples, oranges & tomatoes)

1-4 wedges

- Peel the skin o oranges, and for tomatoes and apples, take out the stem.

- If the ingredients are larger than the hopper, cut the ingredients into pieces that will fit into it.

- Fruits with seeds must be pitted before extraction. Cut to 1-4 wedges then slowly insert the ingredients down the hopper.

How to Use the Smart Cap:

Adjusting the amount of pulp in

• Juicing with the smart cap closed allows mixed juice creations with di erent fruits, vegetables and liquids.

• After juicing, close the smart cap to block excess juice from dripping, especially when disassembling the juicing bowl o the base.

• When making di erent juices, quickly rinse away any leftover  avors by running a glass of water in the maXtractor™ with the smart cap closed.

• Leave the smart cap open when juicing ingredients that create excessive foam during extraction (e.g. apples, celery).

• Pay close attention when operating the maXtractor™ with the smart cap closed. Juice may over ow if the amount collected in the bowl exceeds its capacity marked.

• Depending on the ingredient, you may get extra pulp when juicing continuously.

• To reduce the amount of pulp, disassemble the top-set and wash frequently.

the juice:

Hard fruits and vegetables

6 inch

Hard fruits and vegetables may put excess strain onto the motor and cause it to stall.

PREPARATION TIPS:

• Slice the ingredients 1 inch thick or cut 1 inch wide and 2-6 inches long.

• Soak hard ingredients like carrots and ginger in cold water prior to juicing.

EXTRACTION TIPS:

• Slowly insert the ingredients, one at a time.

• Pace the juicing speed ensuring each ingredient is thoroughly extracted.

• To maximize the juice yield, juice with ingredients with high water content.

(e.g. carrots, potato, beets & spinach):

1/2 - 1 inch

1 inch

Soak in cold water prior to juicing and cut to appropriate sizes.

To increase the juice yield, juice fruits and vegetables with high water content.

+ 18 hidden pages

Royal Prestige Maxtractor User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
