Professional
Instructions for use
Made in Germany
IMPORTANT SAFEGUARDS
When using your iron, basic safety precautions should
always be followed, including the following:
Read all instructions before using the iron.
1. Use iron only for its intended use.
2. To protect against a risk of electric shock, do not
immerse the iron in water or other liquids.
3. The iron should always be turned to Minimum
(Min) before plugging or unplugging from outlet.
Never yank cord to disconnect from outlet, instead
grasp plug and pull to disconnect.
4. Do not allow cord to touch hot surfaces. Let iron
cool completely before putting away. Loop cord
loosely around iron when storing.
5. Always disconnect iron from electrical outlet when
filling iron with water or emptying and when not in
use.
6. Do not operate iron with a damaged cord or if the
iron has been dropped or damaged. To avoid the
risk of electric shock, do not disassemble the iron,
take it to the nearest authorized Rowenta Appliance
Service Center for examination and repair. Incorrect
reassembly can cause a risk of electric shock when
the iron is used.
7. Close supervision is necessary for any appliance
being used by or near children. Do not leave iron
unattended while connected or on an ironing board.
8. Burns can occur from touching hot metal parts, hot
water or steam. Use caution when you turn a steam
iron upside down – there may be hot water in the
reservoir.
9.
The use of accessory attachments is not recommended
by Rowenta Appliance Company and may result in fire,
electric shock or personal injury.
2
SPECIAL INSTRUCTIONS
1. This is a 1200 watt or 1400 watt appliance (check
rating on iron heel). To avoid a circuit overload, do
not operate another high wattage appliance on the
same circuit.
2. If an extension cord is absolutely necessary, a 12ampere cord should be used. Cords rated for less
amperage may overheat. Care should be taken to
arrange the cord so that it can not be pulled or
tripped over.
3. After the iron has cooled, wrap the cord loosely
around the handle.
4. Your Rowenta appliance is intended for household
use only.
SAVE THESE INSTRUCTIONS
3Professional USA
CDEFG H I
B
A
■ Description:
A Water filling inlet
B Spray nozzle
C Burst of steam button
D Spray button
E Variable steam control
F Indicator light
G Temperature control dial
H Swivelling cord protector
I Supply cord
J Transparent water tank
K Soleplate according to model
– Stainless steel
– Titan Plus
L Water level indicator
Made in Germany
JKL
Features vary by model. Check
packaging or markings on iron
for exact features
4
Set the temperature control dial according
to the type of fabric you are ironing. Check
the fabric’s label for appropiate setting.
d Synthetics (low temperature)
dd Silk/wool (medium temperature)
ddd Cotton/linen (high temperature)
j Please read the instructions for use and the Important Safeguards
carefully.
j Slowly peel the protective cover off the soleplate.
j It is normal for a small amount of smoke to be produced the first
time the iron is used. This will quickly disappear.
BEFORE USE
Filling with water:
Made in Germany
M
a
d
e
in
G
e
rm
a
n
y
5
DE 873 Professional USA
3-WAY AUTO-OFF (NOT ON ALL MODELS)
j If the iron is not moved while it is
switched on, an internal safety switch
will turn it off. It will turn off in 8 minutes
if left vertically or in 30 seconds if left on
its soleplate or tipped over.
j A red flashing light indicates that the
auto-off has been activated. To switch the
iron on again, move the iron or gently
shake it.
Wait until iron is fully reheated before use.
STEAM IRONING
j Ensure the iron is unplugged.
j Slide the variable steam control
completely to the left.
j Hold the appliance upright so that the
water filling inlet is horizontal.
j Fill the iron with tap water to the
maximum level mark (see water usage
for more informations).
Adding water:
j If you need to add water during ironing,
unplug the iron and repeat above steps.
j Ensure iron is fully reheated after filling
(temperature indicator light goes out)
before ironing.
SELECTING THE TEMPERATURE
To avoid damage to clothes from dust or dirt that may collect in the
iron, we recommend that for the first use or after the iron has been
stored for some time that you first iron an old cloth, testing both the
steam and burst of steam feature.
j To remove stubborn wrinkles or press in
a sharp crease, use the burst of steam
button.
j Press the button firmly, a strong burst of
steam penetrates deep into the fabric.
j Leave an interval of at least four seconds
between pressing the burst of steam
button.
j With water in the tank, the burst of steam
button can be used as soon as the steam ironing temperature has
been reached (
● ● ●)
6
To avoid automatic switch off while the iron is heating up, always
keep the iron on its heel. Start at low temperature and graduate to
high temperature. For delicate fabrics we recommend carrying out a
test on an unobtrusive part of the garment (inner seam).
SETTING VARIABLE STEAM CONTROL
Set the variable steam control to required steam volume. Steam can
only be produced when the thermostat is in the red cotton/linen
zone. Allow iron to heat up (light goes out) before activating the
variable steam control. Reduce or set variable steam to min when
ironing at low temperatures to avoid water leakage or spitting.
Iron ready for steam ironing:
Steam is produced as soon as the iron is held
horizontally.
Steam off:
Steam generation can be interrupted by
standing the iron on its heel or sliding the
variable steam control fully to the left.
SPRAY SETTING
j Ensure there is water in the tank.
j Moistening the fabric with the spray will
make wrinkle removal easier.
j Press the spray button down slowly for a
jet or quickly and strongly for a mist.
j Do not spray silk, etc.
BURST OF STEAM
Made in Germany
7
j Unplug the iron. Slide the variable steam control completely to
the left and empty any water left in the tank. Leave the iron to
cool down.
AFTER IRONING
Integrated cord wrap:
j For easy storage, the cord can be wound
loosely around the cord wrap once the
iron has cooled off completely.
j To protect the soleplate always store the
iron on its heel.
WATER TO USE IN ROWENTA IRONS
TAP WATER:
Rowenta irons are designed to be used with REGULAR TAP WATER
(up to 12 grains of hardness). If your water is harder than this,
Rowenta recommends mixing half tap water with half distilled water
which reduces the hardness; or inexpensive spring water.
Never use 100% distilled water since this can cause the iron to
spit and leak.
DRY IRONING
j Sliding the variable steam control fully
to the left, dry ironing can be performed
either with or preferably without water in
the tank.
Made in Germany
j The iron can also be used vertically. This is
especially useful for getting wrinkles out
of hanging clothes, curtains, tapestries,
etc.
j Hold iron vertical, close to but not
touching fabric.
j Hold hem and pull gently downward on
the fabric.
WARNING:
Never iron clothes while they are being worn!
VERTICAL STEAM (NOT ON ALL MODELS)
j Press burst of steam button, a strong burst of steam penetrates
deep into the fabric.
SOFTENED WATER:
There are many types of household water softeners and the water
from many of them is perfectly acceptable for use in an iron.
However, some types of softeners, particularly those that use
chemicals such as salt, can cause the iron to leak or spit during use.
If you experience this type of problem, we recommend that you try
using inexpensive bottled spring water or untreated tap water.
Never use 100% pure distilled water.
Once you have changed water it will take several uses to correct the
problem. Rowenta recommends trying the steam function for the
first time on an old towel or cloth to avoid damaging your clothes.
IRON AND OTHER IMPURITIES:
If your water supply contains large amounts of iron or organic
matter, these minerals can collect inside the iron and eventually
appear as brown stains. If you experience these problems Rowenta
recommends using inexpensive bottled spring water.
Never use
100% pure distilled water.
Vapodur Valve:
The patented Vapodur valve ensures that the opening which allows
the water to drip from the water tank into the steam chamber of
your iron remains unaffected by hard water deposits.
To ensure your iron continues to steam efficiently the valve MUST
be opened and closed a few times. This is done by moving the
variable steam control left to right a few times each time you finish
ironing.
When cold and unplugged, the iron can be cleaned with a damp
cloth and wiped dry. Never use household cleaners or solvents.
CLEANING AND MAINTENANCE
8
Cleaning the Soleplate (depending on model):
j Rowenta stainless steel and Titan Plus soleplates have excellent
non-stick properties and can be simply wiped clean when cold.
j In normal use a draggy coating may build up on the soleplate
(starch, detergent buildup, burnt synthetic fibers). This can be
easily removed by using the Rowenta Soleplate Cleaning Kit or a
quality hot iron soleplate cleaner available at most stores.
j Do not use abrasive household cleaners or abrasive cleaning pads.
j The soleplate of your iron makes ironing easier. To prevent
scratching of the soleplate, do not iron over sharp objects
(zippers, etc.). Do not place the iron on rough surfaces, e.g.
metal iron support, which may scratch the soleplate.
