Rotem SuperGuard, Piguard 80 Installation Manual And User's Manual

SuperGuard and Piguard 80

Installation Manual and User Guide

110085

WARRANTY & LIMITATION OF LIABILITY

1. ROTEM warrants that the product shall be free of defects in materials or workmanship and will conform to the technical sp ecification for a period of 1 (one) year from the date of initial installation on site (the "warranty period").

2. Load cells are not covered by ROTEM’s warrant y.

3. ROTEM warrants that dur ing said warran ty period, an y item/items or part /parts of equipment f ound defective with respect to materials or workmanship or which do not conform to the technical specification shall be repaired or replaced (at ROTEM's sole discretion), free of charge.

4. During the warranty period, in the event of an alleged defect, authorized resellers in relevant regions should be notified as soon as possible f rom the date of noticing the s aid def ect, but n o longer th an thirty (30) days from such a dis covery. T he report shall includ e (1) a short des cription of the def ects noticed (2) type of card / component and its matching serial number.

5. ROTEM's sole liability under this warranty is the repair or replacement of the defective item of

product.

CONDITIONS AND LIMITATIONS

1. ROTEM will not be responsible f or any labor costs or expenses associat ed with replacem ent of

defective items or other parts of the product or repair.

2. This warranty shall not cov er: (i) product or part th erein which has be en modified (witho ut prior

written approval of ROT EM), or (ii) pr oduct or part ther ein which has not handled or installed b y an authorized reseller of ROTEM or (iii) product or part therein which has either handled or installed no t in strict accor dance with ROTEM's instruc tions, (iv) products which were used for function other than agriculture industry.

3. This warranty will not apply in the follo wing cases: (i) if all components of the product are not

originally supplied by ROTEM (ii) the defect is the result of an act of nature, lighting strikes, electrical power surge or interruption of electricity (iii) the defect is the result of accident, misuse, abuse, alteration, neglect, improper or unauthorized maintenance or repair.

ROTEM warns and alerts all users that the Product is inherently complex and may not be completely free of err ors . RO T EM' s pr oduc ts ar e d es ig ned and manufactured to p rovi de re li ab le operation. Strict tests and q ualit y contro l proced ures ar e appli ed to e very produc t. H owever, t he possibility that something may fail beyond our control exists. Since these products are designed to operate climate control and other systems in confined livestock environments, where failure m ay cause severe dam age, the user s hould provide adequate back up and alarm systems. These are to operate critical systems even in case of a ROTEM system failure. Neglecting to provide suc h a bac k up will b e r egard ed a s the us er’s wil lingn es s to ac cept the r isk of loss, injury and financial damage.

In no event will ROTEM be liable to a user or a ny third party for any direc t, indirect, special, consequential or incidental damages, including but not limited to any damage or injury to business earnings, lost pr ofits or goodwil l, persona l injur y, costs of delay, an y failur e of deliver y, costs of lost or dam aged data or doc um entation, los t or dam aged produc ts or go ods, los t sa les, lost orders, lost income.

Except for the above expre ss warranty, ROTEM makes no other warrant ies, expr ess or implied, relating to the products. ROTEM disclaims and excludes the implied warranties of merchantability and f itness for a particular purpos e. No person is authorized t o make an y other warranty or representati on concerning the perform ance of the products other than as provided by ROTEM.

Software Version: 1.04 Document Version: 2.2

TABLE OF CONTENTS

1 Front Matter .................................................................................................. 5

1.1 Introduction ........................................................................................................................ 5

1.2 Conventions ....................................................................................................................... 5

1.3 Contact Information........................................................................................................... 5

1.4 Document Information ...................................................................................................... 5

2 Precautions ................................................................................................... 6

2.1 Grounding .......................................................................................................................... 6

2.2 Filtering ............................................................................................................................... 6

2.3 Checking the Battery Level .............................................................................................. 6

3 Introduction .................................................................................................. 7

3.1 Components ....................................................................................................................... 7

3.2 General Description........................................................................................................... 7

3.2.1 SuperGuard .................................................................................................................... 7

3.2.2 Piguard ........................................................................................................................... 7

3.3 Features .............................................................................................................................. 7

3.3.1 SuperGuard .................................................................................................................... 7

3.3.2 Piguard ........................................................................................................................... 8

4 Getting Started ............................................................................................. 9

4.1 10 Step Installation Guide ................................................................................................. 9

4.2 SuperGuard Keyboard .................................................................................................... 10

4.3 SuperGuard Main Screen ................................................................................................ 11

4.4 Hotkeys ............................................................................................................................. 12

5 SuperGuard Setup...................................................................................... 14

6 CONTROL ................................................................................................... 16

6.1 Temp Curve ...................................................................................................................... 16

6.2 Min. Max. Level ................................................................................................................ 16

6.3 Humidity ........................................................................................................................... 18

6.4 Static Pressure ................................................................................................................. 19

6.5 System Parameters ......................................................................................................... 20

6.6 Control Mode .................................................................................................................... 22

7 DEVICE ........................................................................................................ 23

7.1 Vent Levels ....................................................................................................................... 23

7.2 Var. Fan Levels ................................................................................................................ 25

7.3 Curtain Levels .................................................................................................................. 25

7.4 Circulation Fan ................................................................................................................. 26

7.5 Cool Pad ........................................................................................................................... 27

7.6 Foggers ............................................................................................................................. 28

7.7 Light .................................................................................................................................. 28

7.8 Feed .................................................................................................................................. 28

7.9 Extra System .................................................................................................................... 29

7.10 Time Clocks ...................................................................................................................... 29

7.11 Variable Heat .................................................................................................................... 30

8 MANAGEMENT ........................................................................................... 31

8.1 Animal Inventory .............................................................................................................. 31

8.2 Day & Group ..................................................................................................................... 31

8.3 Alarm Setting ................................................................................................................... 32

8.4 Alarm Reset ...................................................................................................................... 33

8.5 Version .............................................................................................................................. 33

8.6 Read From Plug ............................................................................................................... 33

8.7 Write To Plug .................................................................................................................... 35

9 HISTORY ..................................................................................................... 36

9.1 Temperature ..................................................................................................................... 36

9.2 Humidity ........................................................................................................................... 36

9.3 Water ................................................................................................................................. 36

9.4 Feed .................................................................................................................................. 37

9.5 Mortality ............................................................................................................................ 37

9.6 Heater ................................................................................................................................ 37

9.7 Alarm ................................................................................................................................. 38

9.8 Event ................................................................................................................................. 39

10 CALIBRATION ............................................................................................ 40

10.1 Temperature ..................................................................................................................... 40

10.2 Humidity ........................................................................................................................... 40

10.3 Pressure ........................................................................................................................... 40

10.4 Water & Feed .................................................................................................................... 40

11 INSTALLATION ........................................................................................... 41

11.1 Relay Layout .................................................................................................................... 41

11.2 Sensors Layout ................................................................................................................ 42

11.3 Digital Input ...................................................................................................................... 42

11.4 Analog Output .................................................................................................................. 42

11.5 Variable Speed Fan.......................................................................................................... 43

11.6 Sensor Definition ............................................................................................................. 43

11.7 Curtain Setup ................................................................................................................... 44

12 PIGUARD ..................................................................................................... 45

12.1 Cold Start .......................................................................................................................... 45

12.2 Set Unit Number ............................................................................................................... 45

12.3 Main Menu ........................................................................................................................ 45

12.4 Calibration ........................................................................................................................ 45

12.5 Test.................................................................................................................................... 46

12.6 Technical Specifications ................................................................................................. 46

12.7 Piguard Installation Guide .............................................................................................. 47

12.7.1 Sensors and Shielded Wiring ....................................................................................... 47

12.7.2 Installation and Electrical Connections ......................................................................... 47

12.8 Mechanical Installation Guide ........................................................................................ 48

12.9 Environmental Protection ............................................................................................... 48

12.10 Metal Sheet Assembly Diagram ..................................................................................... 49

12.11 SuperGuard/Piguard Network Connection ................................................................... 50

12.12 Piguard Wiring Diagram 1 ............................................................................................... 51

12.13 Communication Wiring Diagram .................................................................................... 52

1 FRONT MATTER

This section includes information on the manual and general information.

1.1 Introduction

Rotem manuals provide easy-to-use information regarding the installation, operation, long/short term planning and parts listing (this manual may not deal with all of the above subjects). The table of contents is an outline of the relevant information in this manual.

Read this manual before operating your Rotem product. Using this equipment for any other purpose or in a way not within the operating recommendations specified in this manual will void the warranty and may cause personal injury.

If you have any questions or comments regarding your product, please contact your local Rotem dealer.

1.2 Conventions

NOTE: Notes provide important details regarding specific procedures.

CAUTION Cautions alert you to potential damage to the controller if the procedures are not

followed carefully.

WARNING! Warnings alert you to potentially hazardous situations which, if not avoided

could result in death or personal injury.

NOTE: Notes contain important "tips" and additional information you should know.

1.3 Contact Information

Rotem Control and Management

Email:

www.rotem.com

support@rotem.com

1.4 Document Information

Revision History

Revision Level / Date Para. Affected Description

2.1/ January 2011 preliminary material

2.2 / September 2011 12.12 Removed potentiometer from graphic

No part of this publication may be reproduced, stored in an automated data file or made public in any form or by any means, whether electronic, mechanical, by photocopying, recording or in any other manner without prior written permission of the publisher. Rotem will not accept responsibility for damage resulting from the use of this manual. Rotem also reserves the right to make changes and improvements to its products and/or the associated documentation without prior notice.

5 SuperGuard and Piguard 80 | 1.04

2 1BPRECAUTIONS

2.1 16BGrounding

CAUTION Always connect temperature and sensor shields to earth ground. Avoid mixing high

voltage wiring with sensor and low voltage wiring.

CAUTION Keep the controller as far as possible from heavy contactor boxes and other sources

of electrical interference.

CAUTION Do not connect communication wire shields, which go from one hous e to another at

both ends. Connect them at one end only. Conn ection at both ends can cause ground loop currents to flow, which reduce reliability.

CAUTION The COM connection for communications is not the shield wire. The COM, RX and

TX wires must connect to each other at all controllers.

2.2 17BFiltering

CAUTION If this installation includes a power inverter to drive variable speed fans, install an

EMI filter in front of the inverter, according to the specifications provided by the inverter manufacturer. Refer to the inverter documentation.

2.3 18BChecking the Battery Level

CAUTION Check the battery once a year. The output must be 2.7 volts (minimum). Au thori zed

personnel only must replace the battery if the output is below the minimum required level or every five years.

SuperGuard and Piguard 80 | 1.04 6

3 INTRODUCTION

This manual prov ides easy-to-use information for installation, operation, long/short term planning and parts listing. The table of contents is an outline of the relevant information in this manual.

Read this manual before operating your Rotem Controller. If you have any questions or comments regarding your controller please contact your local Rotem

dealer.

3.1 Components

• SuperGuard

• Piguard

• Extension Box (optional)

• MUX 485 Communication (optional)

3.2 General Description

3.2.1 SuperGuard

SuperGuard provides you maximum capability with minimal complexity in programming and controlling up to 10 Piguard units.

SuperGuard is the ultimate pig house controller. Equipped with an easy programming interface, it provides programmable outputs for all major features and a 4x20 character LCD that provides display feedback on the programming and device status.

The SuperGuard com municates with Piguard units to access history, collect events and alarms for each and all relevant data up to 100 days.

3.2.2 Piguard

Piguard is Rotem’s latest advance in environmental controllers specially designed for the pig house industry.

The user-friendly has high performance and quick response time. Piguard features accurate temperature and humidity sensors, secure transmission of data even in noisy environments and the added convenience of eight output relays as well as four analog outputs.

Each Piguard can operate independently, in case of SuperGuard malfunction or loss of power.

NOTE: Using an inter nal batter y when the Piguard is operating “alone”, there is no history collec t ion or

possibility to change parameters.

3.3 Features

The following sections detail the SuperGuard and Piguard features.

3.3.1 SuperGuard

• Easy programming

• LCD - 4x20 characters

• Positioning scrollbar

7 SuperGuard and Piguard 80 | 1.04

• Swift device and feature selection

• Data plug

• Large numeric keypad

• Communication with up to ten Piguard uni ts

• Extensive history of events and alarms

• Data collection

• Real time visual outlook

• Alarm system for every Piguard unit

• Multi language support

• PC communication

3.3.2 85BPiguard

• Easy programming

• Programmable outputs

• Alarm system

• Large display

• Up to 3 temperature sensors

• Up to 8 heavy duty relays (1 HP)

• On/Off/Auto override switches

• Static pressure control (optional)

• 4 Analog output (0 - 10 volts)

• Variable speed fan output with bypass

• Water, feed, and humidity control

• Automatic calibration of curtains

SuperGuard and Piguard 80 | 1.04 8

4 GETTING STARTED

The following sections explain the basic concepts in using the SuperGuard and Piguard controllers.

4.1 10 Step Installation Guide

This is a quick 10 step guide that explains basic concepts needed for a proper system installation:

1. Hardware Installati on: Read all technical specs and use the wiring diagrams, from page 46 in this manual, to install all hardware.

2. Piguard Cold Start: Plug in the controller and hold its three keys simultaneously for a few seconds until a CLD sign will appear. This action erases the memory completely and loads the default definitions.

3. Piguard Unit Number: Press the two arrow keys together until the number sign (no.) blinks. Select the unit number with the up and down arrows and press Select.

4. Super Guard Cold Start: Plug in the controller and hold the delete key (DEL) for a few seconds until a Cold Start sign will appear. This action erases the memory completely and loads the default definitions.

5. Super Guard Setup (Room #0): Follow the instructions on page 14.

NOTE: Before making any changes make sure you are changing the correct room by checking the

room number on the upper right side of the screen.

6. Super Guard Installation: Follow the instructions from page 41. If you have more than one room, don’t forget to change room number.

7. Super Guard Calibration: Calibrate your equipment on each room using the service menu.

8. Super Guard Control: Follow the instructions from page 16 regarding the control parameters for each room.

9. Super Guard Device: Follow the instructions from page 23 regarding the device settings for each room.

10. Super Guard Management: Follow the instructions from page 31 regarding live stock and

alarm management for each room.

The History menu is for viewing purposes only.

9 SuperGuard and Piguard 80 | 1.04

F A

4.2 23BSuperGuard Keyboard

Keyboard Functions

A Menu Toggles the menu function

B Room

C Arrows

D Round Arrows

E Enter The enter key is a confirmation key.

F Numeric Pad

G Delete The 'Delete' key erases typing mistakes.

The room key is used to switch between rooms. Press the room key and press a number to reach the desired room.

Use the arrows to scroll a short press in any direction moves one notch.

The Round Arrows key is used to scroll between options (Yes/No, On/Off and '-').

The Number keys are selected when a numeric choice is done and when numbers should be selected. Moreover, those keys are used for Hot Keys purposes.

SuperGuard and Piguard 80 | 1.04 10

N/A

No com. 1 2 3 4 5 6 7 8 9 10

4.3 SuperGuard Main Screen

TEMP RH% TRGT RH%T OUT ROOM #01 DAY Hr. LEVEL

NOTE: The main screen shows basic information regarding rooms controlled by the SuperGuard,

depending on what equipment is plugged in. Other parameters like static pressure (PRESS), outside temperature (OUT), level, message and offset are also shown on the main screen when they are plugged in. Parameters are shown according to priority. There is a square in level line indicating tunnel level.

CAUTION In case of an alarm, a blinking message appears on any one of the main screens in

addition to the siren. Pressing "0" on the main screen, when the alarm message is on, directs you to the room with the alarm. Resetting the alarm is possible, but it only stops the siren and not the screen message. Only by fixing the problem will the message stop.

Current room temperature Current room humidity Target temperature Target humidity Outside Temp. Room number Growth day Time Current ventilation level.

Pressing the zero on the numeric pad, while the alarm is activated will open the room status screen.

O.K

Alarm

• An empty square indicates that the SuperGaurd identifies the houses correctly.

• A filled square indicates an alarm is on.

• A dotted square indicates that there is no communication with the Piguard.

NOTE: Once communication is off there is no history accumulation in the SuperGuard.

• A dotted lined square indicates N/A (not available).

11 SuperGuard and Piguard 80 | 1.04

Room Number

4.4 25BHotkeys

To reach the Hotkeys screens, press the Hotkey number while viewing the main screen. The room number is located on the upper right side of the Hot screen. To view the status of deferent rooms, first enter the desired room using the room key and pressing the room number. Then press the desired screen Hotkey number.

Hot key 1: Main Screen Hot key 2: Temperature Screen

The temperature Hot screen shows important information regarding the status of temperature sensors attached to the SuperGaurd. The average temperature (defined in table 6.6 check this) is displayed on the upper left side and shows the average of temperature sensors T1 through T3. Table 6.2 enables the user to set the temperature sensor T3 as 'OUT' and therefore T3 presents the outside temperature. On the right side, you can see the temperature for entering tunnel ventilation mode.

T1 24.4 #01 T2 25.1 AVG 22.9 T3 22.5 TUN. 23.3 OUT 22.5

Hot key 3: Targets Screen This screen shows all of the target levels, selected for any of the controller's functions.

TARGETS #01 TEMP 22.5 PRESS 0.01 MIN LEVEL 5 ON 60 MAX LEVEL 15 OFF 240

Hot key 4: Curtain Position screen This screen shows the curtain opening position in percent. If for example curtain 3 shows 40%, it is 40%

open.

CURTAIN POSITION #01 CURT.1 50 CURT.2 CL CURT.3 40 CURT.4 -TUNNEL OP INLET --

Hot key 5: Curtain Steps This screen shows the number of steps for each curtain.

CURTAIN STEPS #01 CURT.1 12 CURT.2 -CURT.3 14 CURT.3 -TUNNEL -- INLET --

Hot key 6: System Status This screen shows if humidity treatment is ON/OFF, if the cycle is ON/OFF and how many seconds left

for the current cycle.

SuperGuard and Piguard 80 | 1.04 12

TEMPERATURE ROOM #1

SYSTEM STATUS #01 HUMIDITY TREAT. ON/OFF CYCLE STATUS ON/OFF CYCLE LEFT 29

Hot key 7: Variable Fans This screen shows the speed percentage of each variable fan.

VARIABLE FANS #01 FAN 1 30% FAN 3 n/a FAN 2 40% FAN 4 n/a

Hot key 8: Variable Heat This screen shows the percent of each variable heat.

VARIABLE HEAT #01 HEAT 1 70% HEAT 2 n/a

Hot key 9: Relay Status

RELAY STATUS #01 R1- R2- R3- R4-

R5- R6- R7- R8- EXTENSION RELAYS '9'

This option shows active relays; pressing 9 again opens the extension box's relay activity. Hot key Round Arrow key – History Temp. This option shows a summary of temperature according to temperature room. This screen consists of

the following columns;

• Day number ('Day' column)

• Minimum value measured on that day ('Min' column)

• Average value calculated on the measured temperatures through the whole day ('Avg' column)

• Maximum value measured on that day ('Max' column)

DAY MIN AVG MAX 23 21.4 23.5 24.5 24 21.8 24.6 24.7

13 SuperGuard and Piguard 80 | 1.04

5 4BSUPERGUARD SETUP

To reach the SuperGuard Setup screen:

1. Go to Room key.

2. Press '0' and "Enter" from any of the main screens.

The SuperGuard setup is a procedure for customizing the SuperGuard and Piguard units to match the system.

SuperGuard ===COMM.=== Farm-Center# 1 PC.Baudrate 4800 Total Rooms 5 =Language= Language ►English ===UNITS=== Temp. ►F Press ►IN.W.C Other Units IMPER =OUT TEMP.= From Room ►1 ===TIME=== Time(hh:mm) ►12:06 =PASSWORD= Full Access 0 Read Only ► 0

Parameters are explained in the table on the following page.

SuperGuard identity (Max-32). Define the SuperGuard's unit

SUPERGUARD

BAUD RATE

SuperGuard and Piguard 80 | 1.04 14

number. If only one SuperGuard exists, the unit number is 1. Otherwise, the unit numbers are sequential (1, 2, 3,…).

Select communication baud rate with the PC.

TOTAL ROOMS

Set the number of Piguards connected to the Super Guard (maximum of 10). Make sure you define the Piguards' numbers in the following order without sk ippin g dig its; meaning: 1,2,3,4... If not set this way, the SuperGuard does not detect any Piguards. After defining the number of Piguard controllers, the SuperGuard begins a search to find the controllers defined.

LANGUAGE TEMPERATURE

UNIT PRESSURE

Select language. Select between Celsius and Fahrenheit. Select between: Milibar, IN.W.C, Pascal, CM.W.C, MM.W.C.

Select between meter and imperial. This parameter cntrols the

OTHER UNIT

speed and rain flow. Units for speed are meter/h or mile/h and for rain millimeter/h or inch/h.

TIME PASSWORD

Set clock time. Set password to protect data.

NOTE: The last six parameters are general for all of the Piguards.

15 SuperGuard and Piguard 80 | 1.04

TEMP CURVE #01

70.0

66.0

90.0

50.0

95.0

69.0

64.0

85.0

50.0

95.0

..10

6 5BCONTROL

6.1 26BTemp Curve

# Day Target

1 1 74.0 70.0 99.0 70 99.0 2 14 72.0 68.0 99.0 50.0 99.0

5 98 68.0 62.0 80.0 50.0 90.0

Piguard provides separate temperature curves for growth day, target temperature, heat temperature, tunnel temperature and low/high alarm temperatures. The controller creates a curve for each one and uses it as reference. At midnight, the program goes to the next day on the next row programmed. There are up to 10 programmable rows, but the controller maintains the previous day’s settings for any empty line; therefore it is not necessary to fill the entire table.

Limits:

Heat

Tunnel Lo w Alarm High

Alarm

Day 0 - 999 Target 0 - 40° C Alarm low 0 - 40° C (without floating point) Alarm high 0 - 40° C (without floating point)

6.2 27BMin. Max. Level

Day Min Max 1 1 21 14 3 30 98 9 30

By Day

Soft Minimum By Day

Day Min Cold Min Warm Max 1 1 11 25 14 3 13 30 98 9 19 30

SuperGuard and Piguard 80 | 1.04 16

Soft Minimum By Time

By Time

1 1 10

The Minimum/Maximum Level menu sets the current absolute minimum and maximum ventilation levels available. You have four minimum maximum level choices:

1. Min/Max by Growth Day

2. Min/Max by Time of Day

3. + 4 Soft Min/Max by Day or Time .

From Time Min Cold Min Warm Max 8:00 1 7 25 20:00 3 5 23

From Time Min Max 8:00 1 21 20:00 3 21

The third option provides the following: in extreme cold weather the minimum level ventilation might be decreased. For that, the user utilizes the Soft Min level that operates according to outside or inside temperature.

For example:

Target temperature = 74° F Growth day = 1

Min Max Levels

Day Min Cold Min Warm Max

System parameters -> Min/Max Level control - DSFT (Soft Min by days) Soft Min temp - Out (Control by outside temperature) Soft Min Band - 4° F (Differential below heat temperature)

17 SuperGuard and Piguard 80 | 1.04

TARGET TEMP

74°F

HEAT TEMP 70°F

SOFT TEMP 66°F

Curve between min warm

& min cold levels

Min Warm Levels

Min Cold Levels

HUMIDITY #01

Band (%)

If the inside temperature is above 70° F (heat temperature) the controller operates according to the Min Warm levels.

If the inside temperature is below 66° F (Soft Temp) the controller works according to Min Cold levels. When the temperature is between 70° F and 66° F the controller creates a curve between the Min Cold and Min Warm levels. For example, at 68° F the controller operates in level 5.

Important:

• When using Soft Min according to inside temperature there is a curve between min warm and

min cold, while decreasing levels. When temperature increases the level remains at the lowest level reached, until reaching the heat temperature.

• When using Soft Min according to outside temperature there is a curve between min warm

and min cold while decreasing and increasing levels.

• To select the type of minimum/maximum go to system parameters and change the level control

(see page check this).

6.3 28BHumidity

Target

0 Delay (minute) Duration (sec)

Below Heat

SuperGuard and Piguard 80 | 1.04 18

• Target: Set the humidity level to this target.

STATIC PRESSURE #01

Out temp low 5

Press. (high t) 0.12

Pressure Temp

Tunnel Pressure Static Pressure

• Delay: Delay time before humidity treatment. During the delay time the controller checks whether the humidity is above the target.

• Duration: Humidity treatment duration time.

• Band: Band zone to balance the treatment.

• Below Heat: Select if you wish to initiate humidity treatment below heater temperature.

6.4 Static Pressure

• Out Temp low: Set outside low temperature

definition for low pressure target.

• Press (Low T): Static pressure target for the

Press. (low t) 0.08 Out temp high 35

Tunnel press. 0.08 Low alarm 0.05 High alarm 0.15 Band 0.04 Wind delay (s) 10 Pre open (s) 5 Alarm MINIMUM level 0

outside low temperature (see graph below, point 1).

• Out Temp High: Set outside high temperature

definition for high pressure target.

• Press (High T): Static pressure target for outside

high temperature (see graph below, point 2).

• Tunnel Pressure: Static pressure target during

tunnel ventilation mode.

• Low Alarm: If static pressure drops below set

point alarm will be active.

• High Alarm: If static pressure rises above set

point alarm will be active.

• Band: Set band zone to balance the system.

• Wind Delay: Static pressure is affected by wind.

This parameter ensures that an alarm is given enough time to measure a stable change in pressure and not an incidental one, that may have been caused by a wind gust.

• Pre Open: Time setting for curtains to open before fans activate. This is to make sure the curtains are open before fan activity.

• Alarm Minimum Level: From what level you wish to activate low static pressure alarm.

High Alarm

Low Alarm

19 SuperGuard and Piguard 80 | 1.04

==TEMP==

to enforce low temperature minimum

6.5 30BSystem Parameters

• Offset: Use this parameter to raise or lower the offset target temperature for any purpose.

Default: 0.0

• Band: This refers to the target temperature zone range; also known as the Happy Zone.

Default: 1.0

• Cool Factor (%): The minimum correction towards target Happy Zone during each increase ventilations dela y (patie nc e factor). If the temperature does not improve by this amount, the controller increases by one level.

Default: 10%

• Cold Above TRG: Temp change to be considered as quick drop In degrees, to reduce a level to reach above target temp (degrees).

Default: 3.0

• Cold Below TRG: Temp change to be considered as quick drop in degrees, to reduce a level to reach below target temp (degrees).

Default: 1.0

==HEATER==

• Heat Band: Set the Happy Zone for the heaters on/off.

Default: 1.0

• Heat Lamp Diff: Differential from target temperature to initiate heat lamps.

Default: 0.0

• Heat Offset: Use this parameter to raise or lower the offset heat temperature for any purpose.

Default: 0.0

==MIN MAX==

• Curve: If Yes: Min Max table curve between the days.

Default: NO - Will work according to previous line until current day.

• Level Control: Four options for the Min Max table method: by days, soft minimum by days, by time, soft minimum by time.

Default: Day

• Soft Min Temp: Choose whether to use the current inside temperature or the outside temperature to determine when to use the soft minimum.

Default: OUT

• Soft Temp Band: Diff below heat temperature to set tem per ature at which

SYSTEM PARAMETERS =====TEMP===== Offset ► 0.0 Band 1.0

Cool Factor 10% Cold Above TRG 3.0 Cold Below TRG 1.0 ====HEATER==== Heat Band 1.0 Heat Lamp Diff 0.0 Heat Offset 0.0 ====MIN MAX==== Curve NO Level Control Day Soft Min Temp OUT Soft Temp Band 10.0 ====PRESSURE==== Press Control NO ====LEVELS==== Inc Delay (s) 180 Dec Delay (s) 120 ====TUNNEL====

Tun Level 0 Dif Below, Exit 2.0 T.Out Dif, Exit 18.0 Exit Delay (m) 5 ===CURTAINS=== Calib Steps 99 ==COOL PAD== From Level 0 Temp Band 1.0 Humidity Band% 2.0 ===FOGGERS=== From Level 0 Temp Band 1.0 Humidity Band% 2.0 ===VAR. FAN=== Freeze Protect NO Min Fan 1 Spd% 30 Min Fan 2 Spd% 30 Min Fan 3 Spd% 30 Min Fan 4 Spd% 30

SuperGuard and Piguard 80 | 1.04 20

ventilation le ve l.

Default: 10.0

==PRESSURE==

• Press Control (Yes / No): If a pressure control should be done in Min Vent mode by the inlet and in Tunnel mode by tunnel curtain, select Yes. Otherwise, select No.

Default: No.

==LEVELS==

• Inc Delay Time: This is the standard m inim um delay bef or e increasi ng ve nti lat ion le vels.

Default: 120 (sec)

• Dec Delay Time: This is the standard minimum delay before decreasing ventilation levels.

Default: 180 (sec)

==TUNNEL==

Tunnel Level: Switchin g into and out of tunnel ventil ati on is a major change in ventilation. For

• 1 tunnel ventilation, enter the first tunnel level here. If set on 0 there is no tunnel level.

Default: 0

• Dif Below, Exit: This parameter sets amount below the tunnel entry temperature at which to exit tunnel ventilation. Tunnel temperatures are determined by the sensors specified in Temperature Definition. Entry and exit is also controlled by these sensors. The controller can not exit tunnel until the tunnel temperature is this much less than the tunnel entry temperature. It must be a positive number.

Default: 2.0

• T.Out Dif, Exit: Set the relative temperature for the outside sensor at which to exit tunnel. The controller can not exit tunnel until the outside temperature is less than tunnel temperature plus this differential. This number can be positive or negative. To eliminate the effect of this parameter on tunnel exit, enter a large positive number such as 90.0.

Default: 0.0

• Exit Delay (m): Delay time after satisfying tunnel exit conditions.

Default: 5 (minutes)

==CURTAINS==

• Calibration Steps: To ensure accurate positioning of the curtains, the controller can periodically calibrate the curtain position. This parameter sets the maximum number of curtain movements or stages between calibrations. Calibration consists of forcing the curtain to the nearest limit, 0% or 100% with adequate overtime to ensure reaching the limit switch. Then the curtain returns to its proper position. In the event several curtains require calibration, they calibrate one at a time to reduce the amount of restriction to normal ventilation. The stage counter resets automatically each time the curtains reach a limit point to prevent excessive calibration.

Default: 99

==COOL PAD==

• From Level: From what ventilation level to begin cool pad operation. 0 is no operation.

Default: 0

• Temp Band: On/Off differential or Happy Zone with respect to temperature for the ‘Cool #’ and ‘Cool Pad #

’ relays. These normally control the water pump for the cool cells.

Default: 1.0

• Humidity Band: On/off differential or Happy Zone with respect to inside humidity for the ‘Cool #’ and ‘Cool Pad #

’ relays.

Default: 2.0

==FOGGER==

• From Level: From what ventilation level to begin fogger operation. 0 is no operation.

Default: 0

• Temp Band: See cool pad above.

Default: 1.0

21 SuperGuard and Piguard 80 | 1.04

CONTROL MODE #01

Set Mode ►Normal

• Humidity Band: See cool pad above.

Default: 2.0

==VAR. FAN==

• Freeze Pro te ct : A general protection for the variable speed fan motor. When the variable speed fan starts from zero speed, the freeze protection runs it at 100% for 5 seconds.

Default: No

• Min Motor1,2,3,4 Spd: Safety speed fan operation delay. This is the Fan minimum speed to begin operation.

Default: 30.

6.6 31BControl M ode

Empty

In this screen, set the Control mode; choose between Normal mode and Empty mode.

EMPTY MODE

Empty mode is applied when there is an empty house. When Empty mode is selected:

• All alarms are disabled.

• A flashing massage appear while displaying temperature.

• "E" In Piguard and "Empty House" in SuperGuard.

Setting controller to Normal or Empty mode inserts an event to History/Event table.

SuperGuard and Piguard 80 | 1.04 22

VENT LEVELS #01

01 30

240

02 40

220

7 DEVICE

7.1 Vent Levels

# 12345678 On Off Diff

The SuperGuard provides up to 30 programmable ventilati on le vels. The us ual way to program them is to start the first level with the least amount of air to be used.

The full circles represent continuous fan operation. The half full circle represents cycle operations according to the on/off time set for each stage. A dot represents no operation at all. The following table is an example of a proper ventilation setting. Note that tunnel is not noticeable on the current table and is set according to the system parameter- 1

tunnel level.

23 SuperGuard and Piguard 80 | 1.04

Lev Tunnel Fans On Off Diff

1 2 3 4 5 6 7 8 1 2 3 52 548 0.0 4 70 530 0.0 5 90 510 0.0 6 30 270 0.0 7 40 260 0.0 8 52 248 0.0 9 70 230 0.0 10 90 210 0.0 11 120 180 0.0 12 160 140 0.0 13 225 75 0.0

30 570 0.0 40 560 0.0

14 300 0.0 15 100 200 0.0 16 70 230 0.0 17 90 210 0.0 18 120 180 0.0 19 160 140 0.0 20 225 75 0.0 21 0 0 0.0 22 0 0 1.0 23 0 0 2.0 24 0 0 3.0 25 0 0 4.0 26 0 0 5.0 27 28 29 30

SuperGuard and Piguard 80 | 1.04 24

Curtain Level Example

1 2 3 4 Tunnel

Inlet

18 0 0 0 0

CURTAIN (%) #01

Crt. 1

Crt. 2

Crt. 3

Crt. 4

Tun.

inlet

0 0 0 0 0 0

0 0 0 0 15

7.2 Var. Fan Levels

SPEED (%) #01 # Fan 1 Fan 2 Fan 3 Fan 4

…

set on 30% it will operate up to 30% of the maximum.

cycle operation. The fan will operate at 100% at on time. If set on 20%, the fan will operate at 20% of the full power during off time in the cycle and increases to

100% during the on time.

The percentage for a full circle represents the fan operation percentage form the maximum. If

The percentage for a half full circle represents the fan operation percentage in off mode during

7.3 Curta in Levels

…30 0 0 0 0 0 15

Level

Levels 1 thru 17

Curtain (% Open)

. . .

19 0 0 0 0 45

25 SuperGuard and Piguard 80 | 1.04

20 0 0 0 0

70 21 0 0 0 0

100

23 0 0 0 0

100 24..30

0 0 0 0 0

To Time

00:00

22 0 0 0 0 100

Set the curtain levels to correspond with the ventilation levels. Some producers will want to open the tunnel curtain prior to the actual tunnel. This is a convenient method to control pressure in retrofit houses which may not have sufficient side inlets for the number of fans required in side ventilation.

You can also run the tunnel curtain under pressure control. In that event, the percent open settings become minimum settings. Then, once the side vents are at 100%, if pressure requires, the controller opens the tunnel curtain to maintain the pressure setting.

7.4 35BCir culation Fan

CIRCULATION FAN #01 Sensors Dif

From Time

From Level To Level

The circulation fans will mix the air inside the house and control temperature differentials between different parts of the house.

• Sensors Dif: The circulation fans start if the difference between temperatures in different parts of the house is higher than the set differential. The sensors that participate in this differential can be divided in to 3 groups:

o If no sensors are set for circulation fans in temp definition, the currently defined sensors

control this operation. If for example the house is in tunnel mode, the tunnel sensors control the circulation fans. If the difference is higher than 3 (as in the example above) between two sensors the circulation fans begin to operate.

o If one sensor is defined for the circulation fans, the difference between this sensor and the

average controls the circulation fans.

o If more than one sensor is defined for the circulation fans, when the difference increases

between any two sensors, the circulation fans begin operation.

• From Time: When the application starts.

• To Time: When the application stops.

• From Level: From what level to operate this application.

• To Level: Up to what level operate this application.

3.0 00:00

1 10

SuperGuard and Piguard 80 | 1.04 26

If any of the above four definitions is set to 0, the circulation fan operates at any time or level according to the differential.

Cool Pad #01

From

To Diff

%RH

Off

1 2 08:00

20:00

3.0

Band

Stop

Activate

RH%

(Diff)

Stop

Temp

Band

7.5 Cool Pad

The cooling table provides settings for the evaporative cool pad system. There are up to five fragments enabling precise control over this system. Several fragments can be

selected for the same day.

10:00

• From: (HH:MM) Start time.

• To: (HH:MM) End time.

• Diff: Differentiation from target temperature to activate cooling. When the temperature rises to

the difference above the target, the cooling process begins. When the temperature goes back to the target, the cooling process stops.

• %RH: As long as the humidity + Band are below this level the cooling operates. Cooling stops only at humidity level + band (see figure below).

• On/Off: (sec) On/Off cycle by seconds.

• Band: The cooling table has its own ‘happy zone’ for temperature and humidity that can be set

at the system parameters under the cooling section. The cooling system turns on the amount above specified in the column ‘Diff’ and turns off when the temperature drops the amount specified in the band.

18:00

5.0

Activate

Temp.

27 SuperGuard and Piguard 80 | 1.04

Foggers #01

LIGHT

Day

From

FEED

Day

From

7.6 37BFoggers

# From To Diff %RH On Off 1 2 08:00

10:00

The Foggers' table provides settings for the fogger system. There are up to five fragments allowing precise control over this system. Several fragments can be selected for the same day.

• From: (HH:MM) Start time.

• To: (HH:MM) End time.

• Diff: Differentiation from the target temperature to activate foggers. When the temperature

rises to the difference above target, the fogger's process begins. When the temperature goes back to target, fogger's process stops.

• %RH: As long as the humidity + Band are below this level the foggers operate. Foggers stop only at humidity level + band.

• On/Off: (sec) On/Off cycle by seconds.

20:00 18:00

3.0

5.0

85 75

30 60

90 60

7.7 38BLight

1 5

Set the on/off times according to growth day, there are up to five programmable lines.

14:0010: 00

12:00 16:00

7.8 39BFeed

5 10

Set the time period that feeding takes place. There are up to five programmable lines.

10:00 14:00

12:00 16:00

SuperGuard and Piguard 80 | 1.04 28

EXTRA SYSTEM #01

7.9 Extra System

# From To From T. To T. on off 1

10:00

14:00

Any relay can be set as an extra system. There are up to three functions (relays) available to program as extra systems.

The extra systems’ relays activate according to the settings in this table and regardless of the conditions, or other devices.

• From: (HH:MM) Start time.

• To: (HH:MM) End time.

• To/From Temperature (From T./To T.): The temperature range for extra system activity.

• On/Off: (sec) On/off cycle by seconds.

12:00 16:00

240 60

20 30

50 60

This table consists of up to five programs.

7.10 Time Clocks

TIME CLOCKS #01 # From To on off

1 2 10:00

14:00

This is a simple device definition table with operation time and cycle. There are up to five functions (relays) available to program as time clocks.

12:00 16:00

50 60

29 SuperGuard and Piguard 80 | 1.04

7.11 42BVariable Heat

VARIABLE HEAT #01 Heat1 Heat2 Ht Diff 0.0 0.0 Band 10.0 10.0

Min(%) Max(%) End Day

• Heat Diff: Differential from heat temperature to initiate variable heaters.

Default: 0.0

• Band: Temperature range in which the variable heater operates in the power range between minimum and 100%. For example: the heater temperature is 80° F, the temp diff is -1 and the temp band is 2. At 79° F the heater operates at minimum power according to minimum heat. At 77° F and down the heater operates at 100% and between 79° F and 77 °F there is a power band between minimum and 100%.

Default: 0.0

• Minimum Heat: Minimum heaters operation for safety measures. This parameter refers to both Var. Heat 1 and Var. Heat 2.

Default: 30%

• Maximum Heat: Maximum heaters operation for safety measures. This parameter refers to both Var. Heat 1 and Var. Heat 2.

Default: 100%

• End Day: Set the last growth day for the Variable Heaters operation.

Default: 0

30 100 0

SuperGuard and Piguard 80 | 1.04 30

ANIMAL INVENTORY #01

Add Mortality

DAY & GROUP #01

8 MANAGEMENT

8.1 Animal Inventory

Animal Placed Animal Update

This table provides an update for animal inventory.

• Add Mortality: Insert the number of dead animals.

• Animals Placed: Insert the number of placed animals.

• Animal Update: Update number of animals.

In case the wrong figures are accidentally entered, it is possible to correct them by entering negative figures.

1000 998

8.2 Day & Group

Growth Day New Group Group No.

Day and Group keeps monitor the growth of groups

2 Yes/No 4

• Growth Day: Set the growth day. This parameter can also help determine the animals’ age.

• New Group: To start a new group, select YES under new group fragment and the controller

automatically increases the group number by one and set growth day to 1.

NOTE: When starting a new group, history is deleted!!!

• Group No.: You can manually change the group number.

31 SuperGuard and Piguard 80 | 1.04

ALARM SETTIN G

Hi. Alarm Diff 18.0

Comp.

8.3 45BAlarm Setting

Alarm Delay (sec): Represents the number of seconds between

failure detection and the alarm operation.

NOTE: If the problem is solved before the delay time ends, no

alarm is recorded in the history log.

==SENSOR ALAR M== Low/High: High and low temperature ranges beyond which alar m

is activated. ==HIGH TEMP== Out Compensation: This parameter is added to the high

temperature alarm when outside temperatures are high, for example noon in desert countries. The parameter’s purpose is to ensure that you won't get an alarm just because it's a hot day. The emergency temperature has no compensation, so the compensation feature only works when temperatures do not exceed the emergency temperature.

Example: Outdoor+comp. >Alarm then Alarm=Outdoor+Comp. For example: IF the pre set compensation is 2° F, the outside

temperature is 75° F and alarm is set to 76° F, the controller adds the outside temperature to the comp, and the alarm rises to 77. (75+2=77)

Alarm Delay ► 60 =SENSOR ALARM= Low Alarm Diff 18.0

====HIGH TEMP==== Out Compensate 0.0 Emergency Temp 35 =====LOW TEMP===== Var Fan Stop NO ======WATER======= Min Water/hour 0 Max Water/hour 0 =======FEED======= Min Feed/hour 0 Max Feed/hour 0

Emerg.

Alarm

Target

Emergency Temp.: The temperature beyond which the controller goes into emergency mode and an alarm is activated.

==LOW TEMP== Variable Speed Stop (Yes/No): When in low temperature alarm, decide whether to keep variable

speed in minimum operation or totally shut down the function. ==WATER & FEED== Min/Max Water/Hour: A quantity of water per hour, above which alarm activates.

===Aux. Alarm=== Aux Relate f() NONE

Out temp. Compensation.

SuperGuard and Piguard 80 | 1.04 32

ALARM RESET #01

CONTROLLER

Min/Max Feed/Hour: A quantity of feed per hour, above which alarm activates. ==AUX. ALARM== When assigning a related function, alarm occurs if the associated digital input fails to follow the relay.

Digital input must be active when its associated relay is on. If there is no related function the alarm turns on when the digital input is active.

8.4 Alarm Reset

This function resets the alarms.

Alarm Reset ►NO

NOTE: To reset the alarm press Enter and use the Round Arrows key to change from NO to YES.

8.5 Version

Use this window to check the controller's software version.

Piguard SuperGuard

Use the arrow keas to switch between controllers and press select to view the software version.

8.6 Read From Plug

There are two types of data plugs, Regular and Gold. The Gold Data Plug can store up to eight different settings. By naming each setting differently you can easily write/read data from the plug to the controller and vice versa.

Read from Plug?

NO◄ YES

33 SuperGuard and Piguard 80 | 1.04

SELECT SETTING #1

DATA ON THE PLUG

Gold Data Plug

Room No.1 Room No.2 <NO SETTING>

…8.

Name: Room No. 1 Ver.: 1.00r01 OK ENTER, Abort MENU

Use the arrow keys to shift from NO to YES and press Enter to read from the data plug. Before loading the setting, you can view setting name and software version for this setting. Press Enter

to load the data on the controller. To cancel reading from this setting, press MENU.

READING FROM PLUG

PLEASE WAIT

SuperGuard and Piguard 80 | 1.04 34

ENTER SETTING NAME

Gold data plug

SELECT SETTING #1

…8.

8.7 Write To Plug

Write to Plug? NO◄ YES

Use the arrow keys to shift from NO to YES and press Enter to write over the data plug. You can name your current configuration by using the arrow keys. On the Gold Data Plug, select NO SETTING to create a new setting or overwrite an existing one.

Name: Room No. 1 To Change ARROWS OK ENTER, Abort MENU

Room No.1 Room No.2 <NO SETTING>

Press Enter to load data to the plug.

35 SuperGuard and Piguard 80 | 1.04

TEMPERATURE #01

HUMIDITY #01

WATER #01

9 8BHISTORY

The history section maintains a memory of activity of the last 100 days and 100 events or alarms.

9.1 50BTemperature

AVG

78.6

77.0

DAY 1 2 . 100

MIN

76.0

75.0

9.2 51BHumidity

DAY 1 2 . 100

MIN

55.0

AVG.

60.0

MAX

80.0

MAX

67.0

66.0

Sensors: Data collection for minimum, maximum and average in temperature and humidity for the last 100 days.

9.3 52BWater

DAY 1 2 . 100

DAILY

0.0

• Day: Growth day.

• Daily: Daily consumption.

• %Change: % Change from previous day.

% N/A N/A

SuperGuard and Piguard 80 | 1.04 36

FEED #01

MORTALITY #01

DAY

DAILY

TOTAL

HEATER ROOM #01

DAY

Heat 1

Heat 2

9.4 Feed

DAY 1 2 3 . 100

DAILY

0.0

• Day: Growth day

• Daily: Daily consumption

• %Change: % Change from previous day

% N/A N/A

N/A

9.5 Mortality

N/A 2 . 100

• Day: Growth day.

• Daily: Daily mortality.

• Total: Mortality total since growth day one.

9.6 Heater

1 2 100

01:05 00:42

00:00 00:00

The history heater shows the amount of HH:MM the heater was on that day.

37 SuperGuard and Piguard 80 | 1.04

ALARM #01

MESSAGE

TIME

DAY

9.7 56BAlarm

The following is an example of an Icon status that indicates activation of alarms.

There are 21 different possible alarm messages:

Press. Fail High Temp

NOT ACTIVE AN ALARM THAT WAS RESET ACTIVE

1. Ana. In Fail - analog input failure

2. High Temp - high temperature alarm

3. Low Temp – low temperature alarm

4. Hum.Sen Fail- humidity sensor failure

5. Lost Comm- lost communication

6. W. Overflow- water over flow

7. F. Overflow- feed over flow

8. Sn. 1 Fail – Sensor #1 failure.

9. Sn. 2 Fail

10. Sn. 3 Fail

11. Sn.1 Def Err- sensor definition error

12. Sn.2Def Err

13. Sn.3 Def Err

14. Sn.1 Out Rng- sensor out of range

15. Sn.2 Out Rng

16. Sn.3 Out Rng

17. Sn. Not Def- sensor not defined

18. Aux Alarm- auxiliary alarm.

19. Press. Fail

20. Low S. Press.

21. High S. Press.

18:50 10:45

18 14

SuperGuard and Piguard 80 | 1.04 38

EVENTS ROOM #1

EVENT

DAY

TIME

9.8 Event

Menu #11

Power up

Besides the menu # event message there are three kinds of events:

1. Power up: How many times the controller was turned on.

2. Reset: How many times the controller was reset.

3. Cold: How many cold starts were performed.

4. Menu #: Which menu number has been changed.

The events table is similar to the alarms table but without icons. For example: In the table above “menu #11” means that there was a change of settings in CONTROL menu 1, Temp Curve table.

2 4

18:53 14:42

39 SuperGuard and Piguard 80 | 1.04

TEMP. CALIB. #01

Temp-1(Factor)► 0.0

Humid.(factor)► 0.0

PRESS. CALIB. #01

Water/feed #01

10 9BCALIBRATION

10.1 58BTemperature

Temp-2(Factor) 0.0 Temp-3(Factor) 0.0 Temp-4(Factor) n/a

The temperature sensor is a sensor with a deviation of 0.1. If needed, calibrate the temperature sensor by using a very accurate reference instrument and enter the

offset number for each sensor in the Temp factor line. Use the up and down arrow keys to select sensors.

10.2 59BHumidity

HUM. CALIB. #01

If needed, calibrate the humidity sensor by using a very accurate reference instrument and enter the offset number in the Humidity factor line.

10.3 60BPressure

Value A/D

Press ENTER to calib

10.4 61BWater & Feed

Water per pulse 0.1 Feed per pulse 1.0

The water and feed system operates on a pulse counting method. Enter the amount of feed/water per pulse.

SuperGuard and Piguard 80 | 1.04 40

RELAY LAYOUT #01

Heater 1

11 INSTALLATION

CAUTION Always connect temperature and sensor shields to earth ground.

Avoid mixing high voltage wiring with sensor and low voltage wiring. Keep the controller as far as possible from heavy contactor boxes and other sources of electrical interference.

11.1 Relay Layout

1 FUNCTION

Heater 2

Each relay can be defined to any of the following functions:

• None

• Heater 1-2

• Heat lamp 1-2

• Fan 1-8

• Cool Pad

• Foggers

• Curt. 1-4 open

• Curt. 1-4 close

• Tunnel open

• Tunnel close

• Inlet open

• Inlet close

• Light

• Feed

• Circulation

• Extra system 1-3

• Timer 1-5

41 SuperGuard and Piguard 80 | 1.04

ANALOG INPUT #01

OPTIONS

Temp-1

IN / NONE

DIGITAL INPUT #01

OPTIONS

Input-1

Water

None / Water / Feed / Aux. Alarm

# FUNCTION 0% 100%

11.2 63BSensors Layout

Temp-2 Temp-3 Temp-4 Humidity

The Sensor Layout accommodates up to- 4 temperature sensors and one humidity sensor. 3 can be defined for use inside the house and up to one can be used out of the house. Just mark "IN" for a temperature sensor connected in the house and OUT for a temp. sensor outside of the house.

NOTE: Only sensor number 4 can be 'Out'.

NONE NONE OUT YES

IN / NONE IN / NONE NO / YES/OUT NO / YES

11.3 64BDigital Input

Input-2

Feed

Input-3

There are three digital inputs and a selection between Water, Feed, Aux. Alarm or None.

• AUX . ALAR M: Once operating function, a digital input is sent to make sure that it is actually on, and if not the alarm starts.

None

11.4 65B Analog Output

2 89BANALOG OU TPUT #01

1 Var. Heat 1 0.0 10.0 2 Var. Heat 2 0.0 10.0

3 Var. Fan 3 4 Var. Fan 4

Use the Round Arrows key to run through the list of outputs and press enter to select an output.

SuperGuard and Piguard 80 | 1.04 42

FUNCTION 1 2 3 4

11.5 Variable Speed Fan

3 VAR. SPEED FAN #01

FUNCTION 1 VAR. Fan 1 ► YES 2 VAR. Fan 2 YES

To define a speed fan select Yes. This table will fill out according to the number of triacs in your system (0-2).

11.6 Sens or Definition

Average + - + Tunnel + - - -

Heater 1 + - - Heater 2 - + - + Heat Lamp 1 - + - Heat Lamp 2 - - - + Curtain 1 + + - Cool cell - - - Ex. System 1 - - - Tun. Curt - - - + Var. Heat 1 - - + -

Select the temperature sensors 1 - 4 to use for each function using the Round Arrows key to apply and remove check marks.

You will see only the devices defined in the relay layout and variable heat.

NOTE: Average: The average definition refers to the average temperature, according to the sensor

defined. An empty line defined for a certain sensor, indicates that the sensor will operate according to the average temperature definition.

43 SuperGuard and Piguard 80 | 1.04

11.7 68BCurtain Setup

CURTAIN SETUP #01 CURTAIN OPEN CLS Curtain1► 60 60 Curtain2 60 60 Curtain3 60 60 Curtain4 60 60 Tunnel 60 60 Inlet 60 60

Curtain Setup tells the controller how fast your curtains and side inlets move. It needs this information to properly calculate automatic inlet advance as well as inlet and curtain positions.

SuperGuard and Piguard 80 | 1.04 44

12 PIGUARD

12.1 Cold Start

To execute a Cold Start, disconnect the power, reconnect the power while pressing the thre e Pig uard buttons simultaneously about three seconds.

When this screen appears the controller preformed a Cold Start:

C L d

Cold Start erases all data and history from the memory and load factory defaults!!!

12.2 Set U nit Number

Press the two arrow key simultaneously until NO. is blinking. Set the unit number with the up and down arrows and press Select.

12.3 Mai n M enu

Once the Piguard is activated the main screen appears showing the room’s inside average temperature. Pressing SELECT for two seconds allows the user to vie w the main screen’s information.

• trg: The target temperature for the room (can be changed from the Piguard itself only if a curve was not defined.

• rH: Humidity in room

• rH.t: Target humidity

• day: Growth day for the room

The display alternates between the name and the figure.

12.4 Calibration

Temperature sensors are very accurate and most likely will not require calibration. However, if calibration is required it is done as follows:

• Temperature sensor calibration

o Use an accurate thermometer reference. o Plac e it near the tem per atu r e sensor. o Make sure that the inside temperature is stable. o Calibrate the temperature sensor immediately after reading.

• Calibration procedure

1. To get to the calibration menu press Select and the Up arrow keys simultaneously for two

seconds.

2. The display alternates between the sensor number and the temperature measured.

3. Use the arrow key to change the temperature.

4. Press Select to move through the sensors and the arrows to change temperatures

NOTE: Calibration of humidity sensor is done exactly the same way; the only difference is that instead

of measuring temperature, the humidity is measured by an external humidity sensor.

45 SuperGuard and Piguard 80 | 1.04

Mains Voltage

Single phase115/230 VAC

Main Fuse

315 mA

Secondary Fuse

1 A

Maximum Power Consumption

10 VA

Available Power for Peripheral Equipm ent

3 Temperature Sensors

RTS-2 (Thermistor)

5 Analog Outputs

20 MA, 0 to 10V

1 Humidity Sensor Input

0 to 3 V

2 Analog Inputs

0 to 5 V

3 Digital Inputs

Dry contact 5V/2mAmp

8 N.O. Power Relays

2 HP 30 Amps 250 Vac

Dimensions (L x W x H cm)

92.5 x 7 3x 36

Operating Temperature Range

0º to + 50º C

Storage Temperature Range

-10º to + 70º C

Indoor Applications

12.5 73BTest

The Test function enables the installer to check system. It is used mostly during the installa tion process.

To get to the Test menu, press Select and Down arrow keys simultaneously for about two seconds. The display alternates between the name of the I/O and an ON/OFF sign. Pressing the arrow keys allows switc hing between on and off.

• rL.1-7: Relays 1 to 7

• SPd: Variable speed (check minimum to full capacity using the arrow keys)

• AO1-4: Analog outputs 1 to 4

• t1, t2: Temperature sensors with the A/D counts blinking on the screen

• Hu: humidity sensor A/D counts

• Ai1-2: Analog inputs 1 to 2

• Prs: Pressure A/D counts

• DG1-3: Digital inputs 1 to 3

12.6 74BTechnical Specifications

Power Supply

Analog Inputs

Digital Inputs

Relays Outputs

Housing

Ambient Climate

CAUTION The equipment is designed for use in indoor applications o n ly!

SuperGuard and Piguard 80 | 1.04 46

12.7 Piguard Installation Guide

12.7.1 Sensors and S hielde d Wiring

CAUTION Always connect temperature and sensor shields to earth ground.

Avoid mixing high voltage wiring with sensor and low voltage wiring. Keep the controller as far as possible from heavy contactor boxes and other sources of electrical interference.

• For long shielded wires, connect the shield to ground at one end only.

• From the ground terminal, run a heavy wire directly to the ground rod. It is acceptable, if

necessary, to run the heavy ground wire to the electrical service grounding system rather than directly to the ground rod.

CAUTION Do not use light wires for these ground connections. They must carry heavy

lightning currents, sometimes exceeding thousands of amperes. Certainly, do not use the shielding of sensor and low voltage wiring for this purpose.

• Ensure that all ground connections go to a single local point. When lightning strikes, grounds a meter or two apart will be at significantly different voltages. If you have several electronic boxes with individual grounds, connect all these together to a single point (If Possible), preferably to the surge protector ground. This should continue to the ground rod or the electrical service. In particular, avoid grounding any controls remotely through shield wiring.

• Do not use shields to create a path for lightning. For long shield wires, such as building to building runs, connect the shield to ground at one end only, to reduce the chance of conducting lightning from one building to another.

• When splicing sensors to longer wires, ensure that the splice is waterproof. Use adhesive lined heat shrink (marine grade) to make waterproof connections.

• Use a good compression connector for splicing. This is better than soldering. Do not simply twist wires together and then cover with electrical tape.

• Keep sensor wiring separate from other power distribution and high voltage wiring. Ensure that lightning on other wiring will not transfer to the sensors.

• Install outside temperature sensors so that the sun will not cause false readings, and so that exhaust air from the building will not affec t the sensor.

12.7.2 Installati on a nd Elect rical Connections

• Install computerized electronic controls at least one meter (three feet) away from interference sources such as high voltage wiring to motors, variable speed, light dimmers, relays.

• Install electronic controls in a separate ventilated control room that is protected from extreme temperatures and dirty environments. Place the controls so that the operators can conveniently use the control and read indicators and displays.

• Give your installation a professiona l appe ar ance, w it h all wir ing in condu it or neatl y instal le d. Keep low voltage wires separate from high voltage wires.

• Use shielded wiring for low level signals. For buried wiring (building to building runs) use high grade jell filled cables that are impervious to moisture.

• Seal cable entry points and control boxes to prevent contamination and corrosion. If you use silicon sealant with acetic acid cure, keep the control open and ventilated until cured. Otherwise, the acetic acid will attack the metal parts, including circuitry.

• Drill cable entry holes on the bottom of the box only.

47 SuperGuard and Piguard 80 | 1.04

Recycle raw materials instead of disposing as waste. The controller, accessories

12.8 76BMechanical Installation Guide

WARNING! The Piguard must be installed by an authorized electrician. Power must be

disconnected to avoid electrical shock and damage.

• To avoid exposing the Piguard to harmful gases or high humidity, it is recommended to install it in the service room.

• Installation Category (Over voltage Category) II

CAUTION The power supply to the controller should be protected by 10 Amps circuit breaker

All electrical connections must co m p ly with National Electrical code (NEC)

1. Open the enclosure lid by unfastening the four screws.

2. Using the provided bag of screws and plastic caps, drill holes in the three designated areas

inside the Piguard. Place caps on the screws once mounting is complete.

3. Drill holes at bottom of the box and place cable holders.

4. Place the required cables through the cable holders at the bottom of the unit. Connect the

wires according to the wiring diagrams.

5. Make sure that you use wires large enough for the load of the variable speed.

6. To connect temperature and humidity sensors use shielded two or four conductor #18-#24

gauge cables. Connect the shields to the Ground metal strip. Do not connect the shields to more than one point, or you may induce ground loop currents.

7. Close the Piguard enclosure lid carefully and tightly. Use RTV silicon or equivalent sealant to

seal the cable holders.

8. After installation is completed, operate the Piguard for a few hours and re- check for proper

operation.

12.9 77BEnvironmental Protection

and packaging should be sorted for environmental-friendly recycling. The plastic components are labeled for categorized recycling.

SuperGuard and Piguard 80 | 1.04 48

12.10 Metal Sheet Assembly Diagram

Figure 1: Metal Sheet Assembly Diagram

Instructions

1. Drill holes in the three designated areas located in the back of the controller.

2. Mount the controller using the three screws provided in the small plastic bag.

3. Place the provided plastic caps on the screws.

49 SuperGuard and Piguard 80 | 1.04

12.11 79BSuperGuard/Piguard Network Connection

SuperGuard and Piguard 80 | 1.04 50

12.12 Piguard Wiring Diagra m 1

Analog Output, Power, Potentiometer, Relays, Variable speed, RHS-2

51 SuperGuard and Piguard 80 | 1.04

12.13 81BCommunication Wiring Diagram

SuperGuard and Piguard 80 | 1.04 52

Rotem SuperGuard, Piguard 80 Installation Manual And User's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1 FRONT MATTER

1.1 Introduction

1.2 Conventions

1.3 Contact Information

1.4 Document Information

3 INTRODUCTION

3.1 Components

3.2 General Description

3.2.1 SuperGuard

3.2.2 Piguard

3.3 Features

3.3.1 SuperGuard

4 GETTING STARTED

4.1 10 Step Installation Guide

4.3 SuperGuard Main Screen

6.4 Static Pressure

7 DEVICE

7.1 Vent Levels

7.2 Var. Fan Levels

7.3 Curta in Levels

7.5 Cool Pad

7.9 Extra System

7.10 Time Clocks

8 MANAGEMENT

8.1 Animal Inventory

8.2 Day & Group

8.4 Alarm Reset

8.5 Version

8.6 Read From Plug

8.7 Write To Plug

9.4 Feed

9.5 Mortality

9.6 Heater

9.8 Event

11 INSTALLATION

11.1 Relay Layout

1 FUNCTION

11.5 Variable Speed Fan

3 VAR. SPEED FAN #01

11.6 Sens or Definition

12 PIGUARD

12.1 Cold Start

12.2 Set U nit Number

12.3 Mai n M enu

12.4 Calibration

12.7 Piguard Installation Guide

12.7.1 Sensors and S hielde d Wiring

12.7.2 Installati on a nd Elect rical Connections

12.10 Metal Sheet Assembly Diagram

12.12 Piguard Wiring Diagra m 1
