Owner’s Manual
RT-1080
AM/FM Stereo Tuner
POWER
PTY
TA TP
ANT
AFDISPLAY
ATT
ANT
FM IF
A/B
NARROWFMMONO
AM/FM STEREO TUNER RT-1080
UP
DOWN
12345
67890
AUTO
PRESET
TUNE
BANDMEMORY
TUNING
SCAN
/PRESET
RT-1080 AM/FM Stereo Tuner
Cautions
WARNING: There are no user serviceable parts inside. Refer
all servicing to qualified service personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose the unit to moisture or water. Do not allow foreign
objects to get into the enclosure. If the unit is exposed to moisture,
or a foreign object gets into the enclosure, immediately disconnect the power cord from the wall. Take the unit to a qualified
service person for inspection and necessary repairs.
Read all the instructions before connecting or operating the component.
Keep this manual so you can refer to these safety instructions.
Heed all warnings and safety information in these instructions and on the
product itself. Follow all operating instructions.
Clean the enclosure only with a dry cloth or a vacuum cleaner.
You must allow 10 cm or 4 inches of unobstructed clearance around the
unit. Do not place the unit on a bed, sofa, rug, or similar surface that could
block the ventilation slots. If the component is placed in a bookcase or cabinet,
there must be ventilation of the cabinet to allow proper cooling.
Keep the component away from radiators, heat registers, stoves, or any
other appliance that produces heat.
The unit must be connected to a power supply only of the type and voltage
specified on the rear panel of the unit.
Connect the component to the power outlet only with the supplied power
supply cable or an exact equivalent. Do not modify the supplied cable in
any way. Do not attempt to defeat grounding and/or polarization provisions. Do not use extension cords.
Do not route the power cord where it will be crushed, pinched, bent at
severe angles, exposed to heat, or damaged in any way.
The power cord should be unplugged from the wall outlet if the unit is to be
left unused for a long period of time.
Immediately stop using the component and have it inspected and/or serviced by a qualified service agency if:
• The power supply cord or plug has been damaged.
• Objects have fallen or liquid has been spilled into the unit.
• The unit has been exposed to rain.
• The unit shows signs of improper operation
• The unit has been dropped or damaged in any way
Place the unit on a fixed, level surface strong enough to support its weight.
Do not place it on a moveable cart that could tip over.
NOTE TO CATV SYSTEM INSTALLER: Call the CATV system or antenna
installer’s attention to Article 820-40 of the NEC. This provides guidelines
for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the
pint of cable entry as practical. See installation diagram.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against interference
in a residential installation. This equipment generates and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause interference to radio or TV communications. There
is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception,
which can determined by turning the equipment off and on, try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the unit and the television tuner.
• Connect the unit to an AC power outlet on a different electrical circuit.
• Consult your authorized Rotel retailer for assistance.
2
3
English
1: Controls and Connections
5 6 721
4
3
POWER
8 19
ANTENNA
FM
AB
AM G
ANT
ATT
ANT
A/B
TAPTY TP
FM IF
NARROWFMMONO
AFDISPLAY
AM/FM STEREO TUNER
MODEL NO. RT-1080
POWER CONSUMPTION: 10 W
RT-1080
AM/FM STEREO TUNER RT-1080
DOWN UP
OUTPUTS
LEFT
RIGHT
12V TRIGGER
IN OUT
EXT REM.
IN
12345
67890
AUTO
TUNING
TUNE
/PRESET
PRESET
SCAN
17 1815 1612 14139 10 11
COMPUTER I/O
24222120
BANDMEMORY
WARNING:
SHOCK HAZARD – DO NOT OPEN
AVIS:
RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR
2623 25
ANTENNA
FM
AB
AM G
AM/FM STEREO TUNER
MODEL NO. RT-1080
POWER CONSUMPTION: 10 W
RT-1080
OUTPUTS
LEFT
RIGHT
12V TRIGGER
IN OUT
EXT REM.
IN
COMPUTER I/O
2: Hook-up Illustration
WARNING:
SHOCK HAZARD – DO NOT OPEN
AVIS:
RISQUE DE CHOC ELECTRIQUE–NE PAS OUVRIR
RT-1080 AM/FM Stereo Tuner
3: RR-T92 Remote Control
4
123
DIMMER
I
456
FM IF
NARROW
J
A
7
89
FM
MONO
K
0
ANT
AB
ANT
ATT
AUTO
TUNING
B
MEMORY
FREQUENCY
DIRECT
PRESET
SCAN
TUNE
/PRESET
C
D
DISPLAY
E
AFPTY TATP
F
L
M
N
O
P
Q
G
BAND
H
RR-T92
<
TUN/PRESET
>
R
5
English
Contents
Boxed numbers refer to RT-1080 illustration.
Boxed letters refer to RR-T92 illustration.
1: Controls and Connections 3
2: Hook-up Illustration 3
3: RR-T92 Remote Control 4
About Rotel ...........................................5
Getting Started ...................................... 5
Key Features 6
Unpacking 6
Placement 6
Cables 6
Remote Control ......................................6
Remote Sensor 6
Remote Control Batteries 6
Rear Panel Connections .......................... 6
RCA Outputs 6
AM Loop Antenna 6
FM Antenna 7
AC Input 7
12V TRIGGER Connections 7
EXT REM. IN Jack 7
COMPUTER I/O Interface 7
Basic Operating Controls......................... 7
Power Button 7
Front Panel Display 7
DIMMER Button 7
MEMORY Button 7
Setting Country Mode 8
Basic Tuning Controls ..............................8
BAND Button 8
TUNING Controls 8
NUMERIC Buttons:
Station Presets 8
FREQUENCY DIRECT Button:
Direct Access Tuning 9
AUTO TUNING Button 9
TUNE/PRESET Button 9
PRESET SCAN Button 9
RDS and RBDS Reception ........................ 9
DISPLAY Button 9
PTY Button 10
TP Button 10
TA Button 10
AF Button 10
Additional Tuning Features ....................10
FM MONO Button 10
ANT ATT Button 10
FM IF NARROW Button 10
ANT A/B Button 10
Specifications .......................................11
FM Tuner 11
AM Tuner 11
General 11
About Rotel
A family whose passionate interest in music
led them to manufacture high fidelity components of uncompromising quality founded Rotel
over 40 years ago. Through the years that
passion has remained undiminished and the
family goal of providing exceptional value for
audiophiles and music lovers regardless of their
budget, is shared by all Rotel employees.
The engineers work as a close team, listening to, and fine tuning each new product until
it reaches their exacting musical standards.
They are free to choose components from
around the world in order to make that product the best they can. You are likely to find capacitors from the United Kingdom and Germany, semi conductors from Japan or the United
States, while toroidal power transformers are
manufactured in Rotel’s own factory.
Rotel’s reputation for excellence has been
earned through hundreds of good reviews and
awards from the most respected reviewers in
the industry, who listen to music every day.
Their comments keep the company true to its
goal – the pursuit of equipment that is musical, reliable and affordable.
All of us at Rotel, thank you for buying this
product and hope it will bring you many hours
of enjoyment.
Getting Started
Thank you for purchasing the Rotel RT-1080
AM/FM Stereo Tuner. When used in a highquality music audio system, it will provide years
of musical enjoyment.
The RT-1080 is a full featured, high performance
component. All aspects of the design have been
optimized to retain the full dynamic range and
subtle nuances of your music. Rotel’s Balanced
Design Concept combines advanced circuit
board layout, comprehensive parts evaluation,
and extensive listening tests for superior sound
and long term reliability.
The printed circuits are designed with Symmetrical Circuit Traces so that the precise timing of the music is faithfully preserved. Metal
film resistors and polystyrene or polypropylene
capacitors are used in important signal paths.
All aspects of this design have been examined
to ensure the most faithful music reproduction.
RT-1080 AM/FM Stereo Tuner
6
The main functions of the RT-1080 are easy
to install and use. If you have experience with
other stereo systems, you shouldn’t find anything perplexing. Simply plug in the associated components and enjoy.
Key Features
• Full-function wireless remote control
• User-friendly Fluorescent Display
• AM and FM tuning capabilities
• 30 Station Presets for memorizing your
favorite stations
• Manual frequency and preset tuning, auto-
search tuning, preset scanning, and frequency direct tuning.
• RDS (Radio Data System) capability for
Europe and RBDS (Radio Broadcast Data
Service) capability for the USA.
• Dual selectable FM antenna inputs
• Stereo/mono switching, selectable local/
distance antenna attenuation, selectable
narrow/wide IF band.
• 12 volt trigger connections for remote turn
on/off by Rotel preamplifiers and surround
processors.
• Computer I/O connection for operation of
the unit from a home automation controller or a computer running special software
Unpacking
Carefully remove the RT-1080, the remote
control, and accessories from the shipping
carton. Save the shipping carton and all enclosed packing material for future use. Shipping or moving the unit in anything other than
the original packing material may result in severe damage.
Keep the original sales receipt. It is your best
record of the date of purchase, in the event
warranty service is ever required.
Placement
Like all audio components that handle low-level
signals, the RT-1080 can be affected by its
environment. Avoid placing the RT-1080 on
top of other components.
The RT-1080 generates some heat as part of
its normal operation. There should be 10 cm
(4 inches) of clearance around the chassis,
and reasonable airflow through the installation location, to prevent overheating.
Place the unit on a solid shelf. We recommend
installing the RT-1080 in furniture designed to
house audio components. Such furniture is designed to reduce or suppress vibration which
can adversely affect sound quality. Ask your
authorized Rotel dealer about component furniture and proper installation.
The RT-1080 is supplied with an RR-T92 remote control and must be placed where the
infrared signal from the remote can reach the
front panel Remote Sensor.
Cables
Keep power cords, digital cables, and audio
cables away from each other. This will minimize the chance of the audio signal cables
picking up noise or interference from the power
cords or digital cables. Using high quality,
shielded cables will also help to prevent noise
or interference. If you have any questions see
your authorized Rotel dealer for advice about
the best cable to use with your system.
Remote Control
The RT-1080 includes an RR-T92 remote control that operates many of the features of the
RT-1080.
Remote Sensor
The remote sensor receives infrared signals
from the remote control. Do not cover or block
the sensor. It must be unobstructed or the remote control will not work properly.
The operation of the remote sensor can also
be affected if exposed to bright sunlight or
certain types of lighting (such as halogen lights)
that emit infrared light. In addition remote control functions may not work reliably if the batteries in the RR-AT92 are weak.
NOTE
: To use the remote, aim it at the remote
sensor on the front panel of the RT-1080.
Remote Control Batteries
Two UM-4/AAA size batteries (supplied) must
be installed before the remote control can be
used. To install the batteries, remove the cover
on the back of the RR-AT92. Install the batteries as shown in the illustration in the battery
well. Test the control for proper operation, then
replace the cover. When the batteries become
weak the remote control won’t operate the
RT-1080 consistently. Installing fresh batteries
should eliminate the problem.
NOTE
: Remove the batteries from the remote
if it will not be used for a long period of time.
Do not leave run down batteries in the remote control; they can leak corrosive chemicals which will damage the unit.
Rear Panel Connections
The RT-1080 provides rear panel connections
for audio line level output, two FM antennas,
an AM antenna, computer interface, a remote
IR connection, 12V trigger connections for remote turn-on and AC power input.
NOTE
: Do not plug any system component into
an AC source until system hookup is complete and you are sure that all connections
have been properly made.
RCA Outputs
A pair of line level RCA audio outputs sends
a fixed-level stereo signal from the RT-1080
to your preamplifier, surround processor, or
integrated amplifier. Use a standard RCA au-
left
dio cable to connect the
left
channel tuner input on your system con-
right
troller and the
nel tuner input on your system controller.
output jack to the
AM Loop Antenna
The RT-1080 includes a loop antenna to receive AM radio signals. Remove this antenna
from the box and locate it near the RT-1080.
Connect the 300 ohm twin-conductor wire from
the loop antenna to the pair of screw terminals labeled AM LOOP, attaching one wire
to each terminal. It does not matter which wire
attaches to which terminal, but make sure that
the connections are solid and that the two wires
do not touch.
output jack to the
right
chan-
7
English
You may need to rotate or otherwise reorient
the antenna to find the best position.
NOTE
: To use an outdoor antenna, connect its
300 ohm twin-conductor wire instead of the
loop antenna, only after a professional contractor has installed the antenna system in
accordance with local electrical codes.
FM Antenna
The RT-1080 has two FM antenna connections,
labeled A and B. This permits you to switch
between two different FM antenna systems
using a front panel or remote control switch.
This feature could be useful to switch between
an indoor antenna and an outdoor antenna
system or between a standard FM antenna and
a cable or satellite TV decoder that provides
an FM antenna signal.
NOTE
: The following instructions assume the
use of a standard FM wire antenna supplied
with the unit. To hook up a cable or satellite
TV FM antenna system, see the instructions
supplied with that unit.
The RT-1080 is supplied with a T-shaped indoor FM antenna. Connect the attached coax
F-type plug to one of the FM antenna connectors on the RT-1080. For best reception, unfold the T-shaped antenna. Eyelets at both ends
of the T allow tacking the antenna to a wall,
if desired. Experiment with positioning for best
reception.
NOTE
: To use an outdoor antenna, connect its
75 ohm coax lead wire to the FM connector
instead of the indoor wire antenna, only after a professional contractor has installed the
antenna system in accordance with local electrical codes. In the USA, you will need to use
the supplied F-type converter to connect the
75 ohm coax cable to the antenna input.
AC Input
Your RT-1080 is configured at the factory for
the proper AC line voltage in the country where
you purchased it (115 volts/60Hz in the USA
and 230 volts/50Hz in Europe). The AC line
configuration is noted on a decal on the back
of your unit. Make sure that your unit is configured properly for your AC voltage.
Plug the supplied cord into the AC input receptacle on the back of the unit. Once all other
rear panel connections are completed, plug
the power cord into an AC wall outlet or
switched AC outlet on another component.
12V TRIGGER Connections
The RT-1080 can be activated by a 12 volt
trigger signal from a Rotel preamplifier.
These two connections provide an input to
receive the 12 volt trigger signal from the
preamp and an output to pass through the trigger signal to another component such as a
Rotel power amplifier.
The trigger input accepts any control signal
(AC or DC) ranging from 3 volts to 30 volts.
When a cable is connected to the input and
a trigger signal is present, the tuner is activated.
When the trigger signal is interrupted, the tuner
goes into standby mode. The front panel indicator light remains lit, but the display goes
dark and the unit will not operate.
NOTE
: When using the 12V Trigger feature,
leave the POWER button in the ON position.
EXT REM. IN Jack
This 3.5mm jack receives command codes from
industry-standard infrared receivers (Xantech,
etc.) via hard-wired connections. This feature
could prove useful when the unit is installed
in a cabinet and the front panel sensor is
blocked. Consult your authorized Rotel dealer
for information on external repeaters and the
wiring of a jack to fit the receptacle.
COMPUTER I/O Interface
The unit can be operated from a home automation controller or a computer running audio system control software from third-party
developers. This control is accomplished by
sending the operating codes normally sent by
the RR-T92 remote over a hard-wired network
connection from the computer.
The COMPUTER I/O input provides the necessary connection on the back panel. It accepts standard RJ-45 8-pin modular plugs, such
as those commonly used in 10-BaseT UTP
Ethernet cabling.
For information on the connections, software,
and operating codes for computer control,
contact your authorized Rotel dealer.
Basic Operating Controls
The following explanations will help you get
familiar with the features and controls. When
a function is available on both the front panel
and the remote, a number (see front panel
illustration) and a letter (see remote control
illustration) are shown in the instructions. For
example, to change from the AM to FM band,
you can either press the front panel button
or use the button on the remote. When only
one identifier appears, that control is available only on the front panel or the remote, but
not both.
Power Button
The POWER button is located on the front panel
of the RT-1080 and is not duplicated on the
remote control.
Push the button in to turn the unit on. The LED
above the switch and the display will light up.
Push the button again (returning it to the out
position), to turn the unit off.
NOTE
: If you are using a switched outlet on
another component to power the RT-1080 or
if you are using the 12 volt trigger feature,
leave the POWER switch in the ON position.
Front Panel Display
The fluorescent display in the center of the
RT-1080 provides status information used in
operating the AM/FM receiver (such as station frequency display, band, preset memory,
RDS information, etc.).
DIMMER Button
Available only on the remote control, this button
selects three display brightness settings: NORMAL, DIM, or OFF. When the display is OFF,
pressing any button or control will return it to
the NORMAL mode. Press the button to cycle
through the three settings.
NOTE
: When the tuner is turned off and back
on, the display reverts to its normal setting.
MEMORY Button
The MEMORY button is used to confirm and
memorize various settings in the setup and
operation of the RT-1080, including tuner station presets. Its use is described in detail in
the relevant sections that follow.
RT-1080 AM/FM Stereo Tuner
8
Setting Country Mode
The RT-1080 has two modes (one for the USA
and one for Europe) that configure the unit for
differences in local markets, including FM tuning
intervals, AM tuning intervals, and differences
in the European RDS and United States RBDS
standards. Your unit has been factory configured to the correct mode for the country in which
it was purchased.
To switch to the USA mode, press and
hold the POWER, MEMORY, and 9 buttons
for 5 seconds. The word LOADING will appear in the display and the unit will power up
in the USA configuration.
To switch to the European mode, press
and hold the POWER, MEMORY, and 0 buttons for more than 5 seconds. The word LOADING will appear in the display and the unit
will power up in the European configuration.
Basic Tuning Controls
The RT-1080 features a digital synthesized AM/
FM tuner with RDS or RBDS capability and 30
station presets. The unit offers a wide range
of tuning options. Here is an overview of the
tuning options (more detailed information is
provided in subsequent sections of this manual):
• Manual frequency tuning tunes up or
down to the next station frequency. Set the
TUNE/PRESET mode to TUNE. Turn off
AUTO TUNING. Use the DOWN/UP controls to tune up or down.
• Direct frequency tuning lets you en-
ter the desired station frequency digits. Press
the FREQUENCY DIRECT button on the
remote and enter the digits using the
NUMERIC buttons.
• Automatic frequency search tuning
lets you search up or down to find the next
receivable broadcast signal. Set the TUNE/
PRESET mode to TUNE. Turn on AUTO
TUNING. Use the DOWN/UP controls to
search up or down.
• Memory station preset tuning lets
you directly enter the number of a memorized station preset number. Enter the number of the memorized preset using the NUMERIC buttons.
• Preset scan tuning scans through the
memorized station presets. Press the PRESET SCAN button to begin scanning.
• RDS (Europe) or RBDS (USA) tuning
provides special tuning and search features
based on data codes encoded with the
broadcast signal. See the RDS section of
this manual for detailed information.
BAND Button
The BAND button selects whether the tuner
receives AM or FM broadcast signals. Press
the button to toggle between AM and FM. An
indicator will light at the left portion of the
display to confirm your choice. The currently
tuned station frequency will be shown.
TUNING Controls
A pair of buttons, labeled DOWN/UP on the
front panel and < TUN/PRESET > on the remote, serve as the main tuning controls for the
RT-1080. In the following instructions, we refer to these as DOWN/UP buttons. You can
use either the front panel or remote buttons;
their function is identical.
These controls provides different tuning functions, depending on the mode of operation:
In the FREQUENCY TUNING mode with
AUTO TUNING off, press a DOWN/UP
button to manually jump to the next frequency,
regardless of whether or not a station is broadcasting on that frequency.
SET button and AUTO TUNING button sections
for details on changing the tuning modes.
In the FREQUENCY TUNING mode with
AUTO TUNING on, press a DOWN/UP
button to start auto tuning. The tuner begins
automatically scanning up or down through
the frequencies until the next receivable signal is detected. If this is not the desired station, repeat the automatic tuning procedure
to find the next station. Weak stations will be
skipped during auto tuning. If no receivable
signal is detected, the tuner will revert to the
last previously tuned station.
PRESET button and AUTO TUNING button
sections for details on changing the tuning
modes.
See the TUNE/PRE-
See the TUNE/
In the PRESET TUNING mode, press a
DOWN/UP button to advance to the next
memorized station preset.
SET button section for details on changing the
tuning modes.
In the RDS PTY search mode, press a
DOWN/UP button to select the desired program type from the scrolling list in the display.
See the RDS PTY button in the section on RDS
tuning for details.
NOTE
: Several indicators in the display assist
tuning. A large display shows the tuned frequency. A signal strength indicator shows the
strength of the incoming signal. A TUNED indicator lights when a sufficiently strong signal is received. A ST indicator lights when a
stereo FM signal is received. Indicators show
the currently selected tuning mode.
See the TUNE/PRE-
NUMERIC Buttons: Station Presets
The RT-1080 can store up to 30 station presets for recall using the NUMERIC keypad.
These station presets can be used for any
combination of AM stations and FM stations.
The RT-1080 is delivered from the factory with
a set of generic station presets that may or may
not match available stations in your area. To
memorize a new station preset:
1. Tune to the desired station, AM or FM.
2. Press the MEMORY button. A MEMORY
indicator will flash in the display.
3. While the MEMORY indicator is flashing,
press the number of the preset where you
wish to store the station frequency. For example, to memorize preset 3, press the 3
button. To memorize preset 15, press the
1 button followed by the 5 button.
4. A previously stored frequency is erased from
memory when a new frequency is memorized for the same preset.
To tune to a previously memorized
station preset, press the preset number using the NUMERIC buttons. For
example, to tune to preset 3, press the 3 button. To tune to preset 30, press the 3 button
and then press the 0 button within 5 seconds.
NOTE
: The NUMERIC buttons can also be used
for FREQUENCY DIRECT tuning.
9
English
FREQUENCY DIRECT Button: Direct Access Tuning
If you know the frequency of the desired station, you may tune it directly using the FREQUENCY DIRECT button (remote only) and
the NUMERIC buttons.
1. Press the FREQUENCY DIRECT button to
change the NUMERIC buttons from station
preset to direct access mode. The display
will change to a series of bars, representing the digits of a station frequency, with
the first bar blinking.
2. Enter the first digit of the station frequency
using the NUMERIC buttons. The digit will
appear in the frequency display and the
next bar will flash. Enter the remaining digits
of the frequency. When all of the digits have
been entered, the tuner will automatically
tune to the displayed station frequency.
NOTE
: On the USA version only, pressing 1
in the FM mode will enter 10 as the digit in
the frequency display. On the European
version, press 1 and then 0 to enter 10. For
US FM stations, press only one digit following the decimal point as shown in the first
example following. For European FM stations, press two digits after the decimal
point as shown in the second example.
EXAMPLES:
(USA FM) 87.50MHz Press 8>7>5
(Europe FM) 87.50MHz Press 8>7>5>0
(all AM) 1610kHz Press 1>6>1>0
If no frequency is entered within 5 seconds,
the tuner will cancel FREQUENCY DIRECT
tuning mode and revert to the last previously tuned station.
AUTO TUNING Button
The AUTO TUNING button toggles between
the frequency search tuning feature and manual
frequency tuning. When using the DOWN/
UP buttons in AUTO TUNING mode, the tuner
will begin automatically scanning up or down
through the frequencies until the next receivable signal is detected. If this is not the desired station, use the DOWN/UP buttons again
to find the next station. Weak stations will be
skipped during auto tuning. If no receivable
signal is detected, the tuner will revert to the
previously tuned station.
To toggle between FREQUENCY TUNING
mode and AUTO TUNING mode, press the
AUTO TUNING button. An AUTO indicator
will appear in the display.
NOTE
: AUTO TUNING mode is disengaged
when the TUNE/PRESET button is set to PRESET tuning mode. See the following section.
TUNE/PRESET Button
The TUNE/PRESET button toggles between
FREQUENCY TUNING mode (the DOWN/
UP buttons advance to the next station frequency) and PRESET TUNING mode (the
DOWN/UP buttons advance to the next station preset). To toggle between the two modes,
press the TUNE/PRESET button. A PRESET indicator in the display will light when the PRESET mode is active.
NOTE
: AUTO TUNING mode is disengaged
when the TUNE/PRESET button is set to PRESET tuning mode.
PRESET SCAN Button
This button activates a preset scanning feature.
When you press the button, the tuner will automatically scan through all memorized station presets, playing each for five seconds before moving to the next. To stop the station scanning when the desired station preset is reached,
press the button again.
NOTE
: If a PRESET station is currently tuned
when the PRESET SCAN button is pressed,
scanning will start with the next higher preset
number and continue through all presets, stopping on the initial preset. If a PRESET station
is not currently tuned when the button is
pressed, scanning will start from PRESET 1
and continue to PRESET 30.
RDS and RBDS Reception
The Rotel RT-1080 is equipped with RDS (Radio Data Systems) capabilities for Europe and
RBDS (Radio Broadcast Data Service) capabilities for the United States. These broadcast
systems provide additional functionality to FM
radio reception by transmitting encoded information along with the radio signal. This signal is decoded by an RDS or RBDS receiver
and can provide a range of informational
features including:
1. a display of the station’s identifying name
(e.g. BBC1)
2. a display of the station’s program content
(e.g. ROCK or NEWS)
3. traffic information broadcasts
4. a scrolling text display for announcements
or information
In addition, RDS provides several advanced
search features including:
1. Search for a station with the desired program content (PTY)
2. Search for traffic information (TP)
3. Search for stations broadcasting special
traffic announcements (TA).
RDS broadcasting has been widely available
in many European markets for years. There
are a large number of RDS stations and most
users will be familiar with the features and
operation. In the USA, implementation of the
RBDS system is more recent. Fewer stations
are broadcasting RBDS signals and the features may be less familiar to many users. Ask
your authorized Rotel dealer for information
on RDS or RBDS broadcasting in your area.
NOTE
: The RDS and RBDS features are en-
tirely dependent on the broadcaster sending
properly encoded signals. Thus, they will only
be available where RDS or RBDS is currently
implemented and where stations are broadcasting these data signals. If there are no RDS
or RBDS stations, the RT-1080 will function
as a standard radio receiver.
NOTE
: RDS and RBDS services are only avail-
able on FM broadcasts. The features described are only operational in FM mode.
DISPLAY Button
There are five display options when the tuned
station is broadcasting RDS data and the RDS
indicator in the display is lit. Press the DISPLAY
button to step through the five available options:
1. Standard FREQUENCY display.
2. PROGRAM SERVICE name. This is typically
the station’s call letters, such as BBC1. If
the current station is not broadcasting an
RDS signal, the display will show a blinking PS indication.
RT-1080 AM/FM Stereo Tuner
10
3. PROGRAM TYPE. This is a description of
the station’s content from a list of program
types (for example:
INFO, SPORT, EDUCATION, DRAMA, CULTURE, SCIENCE,
VARIED, POP, ROCK, EASY LISTENING, LIGHT CLASSI-
CAL, SERIOUS CLASSICAL, OTHER MUSIC, WEATHER,
FINANCE, CHILDREN, SOCIAL AFFAIRS, RELIGION, PHONE
IN, TRAVEL, LEISURE, JAZZ, COUNTRY, NATIONAL MUSIC,
OLDIES, FOLK, and DOCUMENTARY). If the station
is not broadcasting an RDS signal, the display will show a blinking PT indication.
4. CLOCK TIME. A time and date display
broadcast by the station. If the station is
not broadcasting an RDS signal, the display will show a blinking CT indication.
5. RADIO TEXT. Scrolling text messages broadcast by the station. If the station is not broadcasting an RDS signal, the display will show
a blinking RT indication.
NEWS, CURRENT AFFAIRS,
PTY Button
The PTY search function scans for RDS stations
broadcasting a particular type of program.
TA Button
Searches for an RDS station broadcasting
special traffic announcements:
1. Press the TA button. The tuner will attempt
to find an RDS station broadcasting traffic announcements.
2. If no station is located, the tuner will return to the last previously tuned station.
3. Cancel the TA function by pressing any
button (except DIMMER or FM MONO).
AF Button
In some cases, an RDS station is part of a
network of stations broadcasting the same
programming (for example, BBC1 programming in the UK may be available at several
different frequencies). Stations broadcasting
this programming may transmit an RDS data
signal providing the tuner with a list of alternate frequencies where this programming is
available. If this data list is transmitted, an AF
indicator will appear in the display.
dicator will light in the display. In mono mode,
a mono signal will be heard even if the station is broadcasting a stereo signal.
NOTE
: Switching to mono mode can be a use-
ful way to improve the reception of weak or
distant FM signals. Less signal strength is required for clean mono reception than for stereo reception.
ANT ATT Button
Sometimes known as a LOCAL/DISTANCE
switch, the ANT ATT button reduces the signal level at the FM antenna input. For the best
reception of stations located some distance
away, this button should be in the default or
OFF position. However, if you are located in
an urban area very close to the radio transmitter, the incoming signal may be high enough
to overload the FM inputs. Press this button to
reduce the incoming signal. When activated,
a LOC indicator appears in the display. Press
the button again to toggle back to normal operation. This switch only effects FM reception.
1. Press the PTY button. The current RDS program content type appears in the display.
2. If desired, change to a different PROGRAM
TYPE using the DOWN/UP buttons to scroll
through the list.
3. Press the PTY button a second time within
5 seconds. The tuner will attempt to find
an RDS station broadcasting the selected
type of program. If the button is not pressed
within 5 seconds after selecting a program
type, the PTY function will be cancelled.
4. If no station is located for the desired content type, the tuner will return to the last
previously tuned station.
5. Cancel the PTY function by pressing any
button (except DIMMER or FM MONO).
TP Button
Searches for an RDS station broadcasting traffic
information programming:
1. Press the TP button. The tuner will attempt
to find an RDS station broadcasting the
traffic programming.
2. If no station is located, the tuner will return
to the last previously tuned station.
3. Cancel the TP function by pressing any
button (except DIMMER or FM MONO).
The AF button is used to scan the alternate
frequencies to find a stronger signal. The button
is only functional when the AF indicator is lit.
1. Press the AF button. The tuner will scan each
of the alternate frequencies for the same
programming in the stored list and tune to
the strongest signal.
2. If no station is located, the tuner will return
to the last previously tuned station.
3. If the signal strength of the new station is
weaker, the tuner will revert to the previously tuned station.
4. Cancel the AF function by pressing any
button (except DIMMER or FM MONO).
Additional Tuning Features
The following buttons provide features which
may be used to improve FM reception and/
or provide additional functionality:
FM MONO Button
The FM MONO button changes the FM mode
from stereo reception to mono reception. In
stereo mode, a stereo signal will be heard if
the station is broadcasting a stereo signal and
there is sufficient signal strength. A stereo in-
FM IF NARROW Button
FM reception works by receiving and decoding a carrier signal centered at the tuned frequency. To accommodate broadcast stations
that may be misadjusted off this carrier frequency, the receiver accepts signals slightly
to either side of the tuned frequency. This
generally provides satisfactory performance.
If you are located in an urban area with a large
number of stations at closely spaced frequencies, you may occasionally notice interference
from adjacent stations. To provide better performance under these conditions, the RT-1080
allows you to reduce the range of frequencies
to either side of the precise tuned frequency,
thus reducing inter-station interference. Press
the FM IF NARROW button to use this feature.
A NARROW indication will appear in the
display. Press the button again to toggle back
to normal operation.
ANT A/B Button
As described in the REAR PANEL CONNECTIONS section of this manual, the RT-1080 provides two FM antenna connections, labeled
A and B. This button toggles between the two
antenna inputs. An A or B indicator will appear in the display, indicating which FM antenna input is active.
Specifications
FM Tuner
Usable Sensitivity:
12.2 dBf
50dB Quieting Sensitivity:
20.2 dBf (mono)
45.3 dBf (stereo)
Signal to Noise Ratio (at 65 dBf):
75 dBf (mono)
72 dBf (stereo)
Harmonic Distortion (at 65 dBf):
0.2% (mono)
0.3% (stereo)
Frequency Response:
10 Hz-15 kHz, ± 3 dB
Capture Ratio:
2.0 dB
Alternate Channel Selectivity:
47 dB (± 400 kHz)
Spurious Response Ratio:
90 dB
Image Rejection Ratio:
80 dB
IF Rejection Ratio:
80 dB
AM Suppression Ratio:
55 dB
Stereo Separation (100Hz/1 kHz/10 kHz):
40 dB/45 dB/35 dB
Output level:
1.2V
Antenna Input:
75 ohms unbalanced
11
English
AM Tuner
Usable Sensitivity:
300 µV/m
Selectivity:
25 dB
Harmonic Distortion:
0.5%
Image Rejection Ratio:
45 dB
Signal to Noise Ratio:
48 dB
Output level:
165 mV
Antenna Input:
Loop Antenna
General
Power Consumption:
10 watts
Power Requirements (AC):
115 volts, 60 Hz (USA version)
230 volts, 50 Hz (European version)
Weight:
4.7 Kg/10.4 lb.
Dimensions (W x H x D):
430 x 92 x 340 mm
16
15/16" x 35/8" x 137/16"
All specifications are accurate at the time of
printing.
Rotel reserves the right to make improvements
without notice.
Rotel and the Rotel HiFi logo are registered
trademarks of The Rotel Co, Ltd., Tokyo, Japan.
The Rotel Co. Ltd.
10-10 Shinsen-Cho
Shibuya-Ku
Tokyo 150-0045
Phone: +81 3-5458-5325
Fax: +81 3-5458-5310
North Reading, MA 01864-2699
Phone: +1 978-664-3820
Fax: +1 978-664-4109
Worthing, West Sussex BN11 2RX
Phone: +44 (0)1903 524 813
Fax: +44 (0)1903 524 831
Phone: +49 05201-87170
Fax: +49 05201-73370
Japan
Rotel of America
54 Concord Street
USA
Rotel Europe
Meadow Road
England
Rotel Deutschland
Kleine Heide 12
D-33790 Halle/Westf.
Germany
www.rotel.com
082 OM-RT-1080 ENGLISH 102700
Loading...
